RFL-P20MX脉冲光纤激光器使用说明书武汉锐科光纤激光技术股份有限公司Wuhan Raycus Fiber Laser Technologies CO.,LTD.安全信息在使用该产品之前，请先阅读和了解这份用户手册并熟悉我们为您提供的信息。
这份用户手册提供了重要的产品操作，安全以及其他信息给您以及所有将来的用户作参考。
为了确保操作安全和产品的最佳性能，请遵循以下注意和警告事项以及该手册的其他信息去操作。
●在打开24VDC电源前，请确保激光器连接正确的24VDC电源并确认正负极；若错误连接电源，将会损坏激光器。
●激光器输出波长在1060~1085nm范围内，工作时可发出超过20W的激光辐射，属于IV级激光产品。
在使用过程中，请避免眼睛和皮肤接触到光输出端直接发出或散射出来的辐射。
●未经许可请不要打开激光器，因为没有可供用户使用的产品零件或配件。
所有保养或维修只能由锐科工作人员进行。
●不要直接观看输出头，在操作该机器时要确保长期配戴激光安全眼镜。
安全标识及位置上面二个安全标识符号表示有激光辐射，安全标识符号标位于产品光纤盒体盖顶。
目录1.产品描述 (1)1.1.产品描述 (1)1.2.实际配置清单 (1)1.3.使用环境要求及注意事项 (2)1.4.技术参数 (2)2.安装 (5)2.1.安装尺寸图 (5)2.2.安装方法 (5)3.控制接口 (6)4.操作流程 (10)4.1.前期检查工作 (10)4.2.操作步骤 (11)4.3.打标过程中应注意的事项 (11)5.质保及返修、退货流程 (11)5.1.一般保修 (11)5.2.保修的限定性 (11)5.3.服务和维修 (12)1.产品描述1.1.产品描述锐科P20MX脉冲光纤激光器采用主振荡器功率放大MOPA（Master Oscillator Power Amplifier）结构，其中主振荡采用半导体激光器作为种子源，功率放大通过光纤放大器来实现。
RFL-ABP系列连续光纤激光器使用说明书适用机型：RFL-1500/1500-ABP RFL-2000/2000-ABP RFL-3000/3000-ABP RFL-4000/2000-ABP RFL-2000/4000-ABP RFL-4000/4000-ABP RFL-6000/6000-ABP武汉锐科光纤激光技术股份有限公司目录1安全信息 (1)1.1安全标识 (1)1.2激光安全等级 (2)1.3光学安全 (2)1.4电学安全 (2)1.5其他安全注意事项 (3)2产品说明 (3)2.1产品特性 (3)2.2实际配置清单 (4)2.3开箱及检查 (4)2.4运行环境 (4)2.5注意事项 (5)2.6产品性能 (6)3安装3.1安装尺寸图 (7)3.2安装注意事项 (11)3.3冷却系统要求 (13)4产品的使用 (15)4.1前面板 (15)4.2后面板 (16)4.3电源连接 (17)4.4控制接口定义 (20)4.4.1SAFETY XP2 24 PIN接口 (21)4.4.2HARDWIRING XP1 64 PIN硬线接口 (25)4.4.3RS232 XP3接口 (27)4.4.4Analog 接口XP4 (28)4.4.5INTERNET接口XP5 (28)4.5安全互锁介绍 (28)4.6激光器内部电气回路示意图 (29)4.7启动操作顺序 (30)5控制模式选择 (31)5.1ON模式 (33)5.1.1AD模式使能 (33)5.1.2出光外控使能 (33)5.1.3红光控制 (33)5.1.4编程模式 (34)5.2REM模式 (34)5.2.1AD模式使能 (34)5.2.2出光外控 (34)5.2.3红光控制 (34)5.2.4编程模式 (35)6激光器接线方式和操作步骤 (36)6.1ON模式下的内控 (36)6.2ON模式下的功率通讯设置出光外控模式 (37)6.3ON模式下功率模拟量设置出光外控 (38)6.4ON模式下的编程模式外控出光 (39)6.5REM模式下功率模拟量设置出光外控 (40)6.6REM模式下功率通讯设置出光外控 (41)6.7REM模式下的编程模式 (42)7RS232与INTERNET通讯指令 (44)7.1端口配置 (44)7.2激光器通讯协议（网口&串口） (44)8上位机软件使用说明 (50)8.1软件主界面 (50)8.2多激光器控制区 (50)8.2.1添加激光器 (51)8.2.2删除激光器 (52)8.2.3修改激光器IP (52)8.3主状态显示区 (54)8.3.1激光器累计工作时间显示区 (55)8.3.2激光器工作状态显示区 (55)8.3.3激光器上电、模式选择、出光控制区 (56)8.3.4编程模式测试区 (57)8.3.5缓升缓降参数区 (57)8.3.6出光参数读取设置区 (58)8.4激光器参数显示区 (60)8.5报警类型显示区 (60)8.6环形光参数设置 (60)8.7上位机软件工作模式选择 (61)8.8语言选择 (62)8.9授权（限时锁定） (63)8.9.1用户模式下的授权 (63)8.9.2授权模式下的授权 (63)8.10关于 (66)8.11日志（诊断模式下） (67)8.11.1下载运行日志 (67)8.11.2下载历史故障记录 (68)8.11.3下载后的文件地址 (68)8.12模块参数（诊断模式下） (69)8.13编程设置（波形编辑） (69)8.13.1查看当前激光器内部的波形条数 (70)8.13.2查看波形内容 (70)8.13.3清空所有波形 (71)8.13.4编辑波形 (71)8.13.5命令解释 (74)9质保及返修、退货流程 (75)9.1一般保修 (75)9.2保修的限定性 (75)9.3技术支持及产品维修 (75)1 安全信息感谢您选择锐科光纤激光器，本用户手册为您提供了重要的安全、操作、维护及其它方面的信息。
小功率脉冲光纤激光器使用说明书武汉锐科光纤激光器技术有限责任公司安全信息在使用该产品之前，请先阅读和了解这份用户手册并熟悉我们为您提供的信息。
这份用户手册提供了重要的产品操作，安全以及其他信息给您以及所有将来的用户作参考。
为了确保操作安全和产品的最佳性能，请遵循以下注意和警告事项以及该手册的其他信息去操作。
●锐科公司脉冲光纤激光器是IV级的激光产品。
在打开24VDC电源前，要确保连接是正确的24VDC的电源并确认正负极，错误连接电源，将会损坏激光器。
●该激光器在1060~1085nm波长范围内发出超过5W、10W、15W、20W、25W、30W（根据不同激光器型号）的激光辐射。
避免眼睛和皮肤接触到光输出端直接发出或散射出来的辐射。
●不要打开机器，因为没有可供用户使用的产品零件或配件。
所有保养或维修只能在锐科公司内进行。
●不要直接观看输出头，在操作该机器时要确保长期配戴激光安全眼镜。
安全标识及位置上面二个安全标识符号表示有激光辐射，我们把这符号标在产品光纤盒体盖顶上。
目录1．产品描述 (1)1.1 产品描述 (1)1.2实际配置清单 (1)1.3使用环境要求及注意事项 (1)1.4技术参数 (2)2．安装 (3)2.1 安装尺寸图 (3)2.2 安装方法 (4)3．控制接口 (5)4．操作程序 (6)4.1 前期检查工作 (6)4.2 操作步骤 (6)4.3打标过程中应注意的事项 (7)5．质保及返修、退货流程 (7)5.1一般保修 (7)5.2保修的限定性 (7)5.3服务和维修 (8)1．产品描述1.1 产品描述锐科脉冲激光器是是为高速和高效的激光打标系统而专门发展的。
为工业激光打标机和其它应用提供了一款理想的高功率激光能量源。
脉冲激光器相对于传统的激光器，能够对每瓦的泵浦光转换效率提高10倍以上，低能量消耗的自动设计，适合实验室或室外操作。
精巧，可独立放置，可随时使用，能够直接嵌入用户的设备上。
1000小体积切割连续激光器说明书武汉锐科光纤激光技术股份有限公司Wuhan Raycus Fiber Laser Technologies Co.,Ltd.目录1安全信息 (1)1.1安全标识 (1)1.2激光安全等级 (1)1.3安全标识 (2)1.4光学安全 (3)1.5电学安全 (3)1.6其它安全注意事项 (3)2产品介绍 (4)2.1产品特性 (4)2.2型号说明 (4)2.3装箱清单 (5)2.4开箱及检查 (5)2.5运行环境 (5)2.6注意事项 (7)2.7产品性能 (7)3安装 (10)3.1整机尺寸图 (10)3.1.1RFL-C1000焊接整机尺寸 (10)3.2输出光缆的尺寸与安装 (11)3.2.1RFL-C1000输出光缆 (11)3.3冷却系统安装与要求 (12)3.4安装注意事项 (13)4产品使用 (15)4.1前面板 (15)4.2后面板 (15)4.3电源连接 (16)4.4接口定义 (17)4.4.1SERVICE安全接口 (17)4.4.2MODULATION调制信号接口 (17)4.4.3控制接口 (17)4.5安装顺序 (22)4.6启动操作顺序 (22)4.7控制模式选择 (23)4.7.1控制模式接线图 (23)4.7.2单机模式（内控模式） (24)4.7.3外控模式 (24)4.7.4AD模式 (25)4.7.5控制时序图 (25)4.7.6红光控制 (27)4.8关闭操作顺序 (27)5常见告警及处理措施 (28)5.1告警显示 (28)5.2告警处理 (28)6质保及返修、退货流程 (31)6.1一般保修 (31)6.2保修的限定性 (31)6.3技术支持及产品维修 (31)1安全信息感谢您选择锐科光纤激光器，本用户手册为您提供了重要的安全、操作、维护及其它方面的信息。
故在使用该产品之前，请先仔细阅读本用户手册。
为了确保操作安全和产品运行在最佳状态，请遵守以下注意和警告事项以及该手册中的其他信息。
RFL-P500 Pulsed Fiber Laser User GuideTABLE OF CONTENTS1 Safety Information (1)1.1 Security Warning (1)1.2 Laser Safety Grade (1)1.3 Safety Identification (2)1.4 Optical Safety (3)1.5 Electrical Safety (3)1.6 Other Safety Rules (3)2 Product Description (4)2.1 Features (4)2.2 Package Parts (4)2.3 Unpacking and Inspection (4)2.4 Operation Environment (5)2.5 Attentions (6)2.6 Specifications (6)3 Installation (7)3.1 Dimensions (7)3.2 Dimensions of Output Head (9)3.3 Cooling Requirements (10)4 Using the Product (12)4.1 Front Panel (12)4.2 Rear Panel (13)4.3 Power Connection (14)4.4 Interface Definitions (15)4.4.1 SERVICE (15)4.4.2Control Interface (16)4.4.3 RS-232 Serial Port (19)5 Application Steps of Laser Device (20)5.1 Pre-inspection (20)5.2 Operational Steps (20)5.3 Attention in the process of operation (21)6 Common Alarms and solutions (21)7 Warranty, Return and Maintenance (22)7.1 General Warranty (22)7.3 Service and Repair (23)1Safety InformationThank you for choosing Raycus fiber laser. This User Guide provides important safety, operation, warranty and other information. Please read it carefully before use this product. In order to ensure safe operation and optimal performance of the product, please follow the warnings, cautions, operating procedures and other instructions accordingly.1.1Security WarningWARNINGCAUTION:product damage.1.2Laser Safety GradeAccording to the European Community standards EN 60825-1, clause 9, this series of lasers are classified as a high power Class 4. This product emits invisible laser radiation at wavelength of 1064 nm, and the maximum power is 500W. Direct or indirect exposure of high power of laser radiation may cause damage to the eyes or skin. Despite the radiation being invisible, the beam may cause irreversible damage to the retina and cornea. Appropriate and approved laser goggles must be worn all the time during the laser device is operating.WARNING:thiswavelength emitted from this product. Users must ensure that the pretectrange of laser goggles over the entire range of laser wavelengths. Pleasedo not directly view the laser output head when laser emitting.1.3Safety IdentificationFigure 1 : Safety identification positionTable 1: Safety identificationEnglish Label Chinese Lable English Label（500W）Chinese Lable（500W）English LabelChinese Lable1: Laser Emit Head 2: Type 4 Laser Product 3: Class 2M Laser Product Label-2mW Red Laser4:CE Label 5: Electrical Hazard 6: ID Label1.4 Optical SafetyAny dust on the end of the collimator assembly can burn the lens and damage the laser device.CAUTION:otherwise the lens or crystal will be damaged.1.5 Electrical Safetya) Ensure the product is grounded through the PE line of the AC power cord. The grounding must be firm and reliable.WARNING: the enclosure, which may result in personal injury.b) Ensure that the AC voltage is supplied normally.CAUTION:un recoverable damage to the laser device.1.6 Other Safety Rulesa) Do not directly view the laser output head when laser emitting. Avoid usingthe laser in a dark environment.b) Do not use fiber lasers in dark environments.c) If this device is used in a manner not specified in this document, theprotection provided by the device may be impaired and the warranty will be voided.d) There are no user serviceable parts, equipment or assemblies inside theproduct. All service and maintenance shall be performed by Raycus. In order to prevent electric shock, please do not break the seal or uncover the shield. Failure to comply with this instruction will void the warranty.2Product Description2.1FeaturesRaycus pulse fiber laser is designed for industrial and scientific research applications with high pump conversion efficiency, low power consumption and excellent beam quality. It is compact and ready to use. It can be used as a stand-alone unit or easily inserted into use r’s apparatus.Main Features:Uniform distribution of stop energyFiber ouputHigh reliability, long-lifeMaintenance free operationHigh photoelectric efficiencyApplications:Laser cleaningScientific research2.2Package PartsPlease refer to package accessoriesare in the packing box.2.3Unpacking and InspectionRaycus fiber laser is delivered in a package, which is designed to offer the maximal safety. Upon the delivery, please inspect all packaging for evidence of mishandling or damage. If you find any evidence of mishandling, please keep the damaged material and contact the shipping agent and Raycus immediately.Please double check if each listed contents is inside the package; and contact Raycus as soon as possible if there is any issue.Take extra care when removing the unit from the package to make the fiber optic cable stay away from collision and vibration. Please do not distort,bend orpull the output cable when unpacking the device; and avoid any collision to the head of laser output.CAUTION:instrument, excessive bend to the cable will damage the instrument.2.4 Operation EnvironmentThe operation conditions are listed as the following table:Table 2: The Operation Environment Conditions for the Laser a) Make sure the product is properly grounded before use.b) The laser output head is connected with fiber optic cable. Please inspect the output head carefully for dust or other contaminations. Use appropriate lens paper to clean it if necessary.c) Failure to follow the instructions when operatingthelaser may cause malfunction and damage.d) It is not allowed to install the output head when the laser is in operation. e) Do not look into the output head directly. Wear appropriate protective eye glasses all the time when operating the laser.f) It is recommended to install the product in an environment with air conditioning.2.5Attentionsa)Make sure that the correct voltage of 220V AC is used. Failure to connectlyconnect power supply will damage the device.b)The output laser is collimated by the collimating lens, it is important tokeep the collimating lens clean, otherwise it will damage the device.c)Please cap the output head when it is not in use. Do not touch the outputlens at any e appropriate lens paper to clean it if necessary.d)Safety keep the cap when using the laser. To avoid dust, make sure theopening direction of the cap is put down.e)Failure to follow the instructions may cause laser power loss, such loss isnot covered by warranty.2.6SpecificationsTable 3 Product Specifications3Installation3.1DimensionsFigure 2 shows dimensions of the product.Figure 2: Dimensions of 200W Product (unit:mm)3.2 Dimensions of Output HeadThe output head of RFL-P500 is QBH, the following figure 3 show the details of the QBH output head.Figure 3 QBH Output head (unit: mm)CAUTION:3.3Cooling RequirementsTable 4 Cooling Requirementsa)Temperature setting of cooling water:25±1℃b)Requirements on Cooling Water:1)Purified water should be used.2)In order to prevent the growth of mould that may lead to blockage,adding alcohol solution to about 10% of the total volume isrecommended.3)If ambient temperature is between -10℃and 0℃, we recommend touse 30% alcohol(volume ratio), and replace it every 2 months.4)If ambient temperature is below -10℃, the chiller with both heating andcooling functions must be used, and keep it in full-time operation.c)Other requirements:1)Before start the device, ensure that the flow and return connections arecorrect connected, and confirm that there is no leakage in all the watercircuits. Any abnormal condition in the water circuits may cause afailure to the operation of the laser.2)If the device is not use in a long time, water must be emptied from thedevice, and then both the inlet and outlet must be blocked with the caps.Failure to do so may cause damage to the device.3)Pleaseuse compressed gas below 0.5MPa when emptying water fromthe device. Failure to do so may cause permanent equipment damage tocooling system.3.4Installation rulea)Place the product in an appropriate position, immobilize it if necessary.b)Check if the power supply has the correct voltage (220V AC±10%，50/60Hz), and the earth line is connected, make sure it is firm and reliable.c)Connect the power cable and control cable to the product when powersupply is OFF.d)Clamp the water pipes ontopipe connector, run the chiller to check if thereis any leakage in the water circulation.e)Check the output head and clean it before installation. This procedure mustbe performed by Raycus personnel or person authorized by Raycus.f)Prevent the delivery cable from treading, pinching or excessive bendingduring installation.g)Make sure the environment is clean, or the output head may becontaminated. It is prohibited to use fan during installation, which will cause dust in the air.h)The minimum bending r adius of the transmission cable of the laser shallnot be less than 20cm in the non-working state (such as transport and storage). The minimum bending r adius should not be less than 30cm when the laser is work.CAUTION:off. Hot plug may damage the device.CAUTION:CAUTION:4 Using the Product 4.1 Front PanelFigure 4 shows the front panel.Figure 4 Front Panel View51 2 3 41.REM/OFF/ON: Key switch, the power switch of the laser. Insert thekey and then turn the key clockwise to the 'ON' to active the laser.2.POWER:Power Indicator, indicates that the power is switched onwhen the green LED illumines.SER:Laser emission button, it’s a button with an red LED indicator.In RS-232 mode and AD mode, when this button is pressed down, theproduct is ready to emit laser, and the LED illumines. Press again willrelease the button, and disable the laser emission.4.ALARM: Alarm indicator, indicates a fault condition when the yellowLED illumines.5.EMERGENCY STOP:Press it down to stop the laser immediately.Turn it clockwise to release, but the laser cannot start before i t’spowered on with key switch for a second time.4.2Rear PanelFigure 5 shows the rear panel:Figure 5: Rear Panel1.INPUT: The socket for supply input that can be only mated with theplug on the power cord we provided.The socket is provided with aprotective cover and a lock catch. Please use the protective cover andlock catch when not use the laser device.2.POWER:Air switch. Controlling the on-off of AC.3.CTRL-INTERFACE:Control interface. This interface provides allcontrol signals, including RS232 communication, laser switch control,laser remote control mode selection, analog control, modulation signal,Interlock interface. Please reference table 4 for specific definition ofcontrol line. The socket is provided with a protective cover and a lockcatch. Please use the protective cover and lock catch when not use thelaser device.4.RS-232:RS-232 interface. Provides remote control and faultinformation storage for lasers. See 4.4.3 for details.5.SERVICE:Provide some external functions for customers. See 4.4.1Interface Specification for details.6.WATER：The pagoda typepipe connector. The intake and outlet areused for inflow and reflux cooling water.4.3Power ConnectionCAUTION:A power cord is provided in the package, as in Figure 6Figure 6 : The Power Cord of the LaserOne end of the power cord is a plug; insert it into the socket ‘AC INPUT’ on the rear panel when using the laser. Notice that the plug is wrong-side preventing. After insert it, lock it with the lever.The other end of the power cord is stripped off，labeled L, N and PE, respectively. You should connect the wires to the 220V AC power supply according to the labels:L--Live WireN--Neutral WirePE--Earth Wire4.4Interface Definitions4.4.1 SERVICETurn the key anticlockwise to the 'REM' can active the laser in remote control mode.WARNING:device in remote control mode!Figure 7: SERVICE Definitions The pin definitions are shown in Table 5:Table 5:SERVICE DefinitionsSERVICE interface is a DB9 header. If the pins 6 and 7 are disconnected, the device will immediately interrupt the light, and the Yellow fault alarm lamp will be lit. Six and seven legs need to be short-jointed before the laser is emitted.CAUTION:4.4.2Control InterfaceFigure 8 shows a schematic diagram of the DB25 control interface.：Figuer 8: DB25 control interface.The DB25 behind the power module is the interface between the control system (such as marking machine) and the laser system. Be sure to connect reliably before working. The pins are defined as follows:Table 6: DB25 Control Interface Definitiona)The pump current of diode laser and the laser output power are controlledby setting the value of PIN1-PIN8 (TTL level). PIN1-PIN8 can be set from 0～255，corresponding to the laser output power from 0～100％(the actual laser power may not be strictly linear with the setting value). The relationship between PIN value and output power is shown in Table7:Table 7:Definition of power control PIN valueb)Pin 17 is an external 5V power input, which supplies power to the outputoptocoupler of the alarm signal; the input current is more than 20mA.c)The external input signals (Pin 1-8, 18, 19, 20, 22) of the laser are allconnected with optocouplers inside the system to ensure that the input level is high in the range of 3.3V-5V and low in the range of 1.7V. Pin input current is greater than 7 mA.d)Warning Signal Definition:Table 8 Warning Signal Definitionoptocouplers, and 17 pins 5V power supply is needed to get an effective signal.f)Note: The pre-output light signal (needle 18) must be at least 5 ms earlierthan the output light signal (needle 19), otherwise the laser will be damaged easily.Schematic diagram of input signal interface circuit：Figure 9: Schematic diagram of input signal interface circuitSignal input needs to be able to provide at least 7 mA of current. The schematic diagram of the output signal interface circuit is shown in Fig. 10.Figure 10: Schematic diagram of output signal interface circuit4.4.3 RS-232 Serial PortFigure 11 shows the RS-232 serial port schematic diagram.Figure 11 RS-232 serial port schematic diagram.The pins are defined as follows:Table 9 RS-232 PIN DescriptionRS232 interface is a special interface for Raycus internal personnel debugging.5Application Steps of Laser Device5.1 Pre-inspectiona)Check whether the size and connection of water pipe are correct, mainlyincluding water temperature, water flow rate, maximum input pressure,refrigeration capacity, whether the water cooler meets the systemrequirements (see Section 3.3 for details), whether the water cooler valve is opened, etc., to ensure that the water cooler is in normal working statebefore the laser is opened.b)Check whether the appearance of the laser device is normal and whetherthe output optical cable is bent or falling off.c)Check whether there is dust or other dirt in the protective lens of the outputoptical cable. Use compressed air to confirm whether it can be blown off. If not, wipe it gently with the lens paper dipped in alcohol, and then check itwith a special flashlight.d)Check whether the power supply and control signal of the laser areconnected correctly.e)Check whether the emergency stop switch is loose.5.2 Operational Stepsa)Start-up operation stepsPower on the laser, turn on the air switch, turn on the key switch (the keyswitch is turned clockwise to ON position, the power indicator lights up,indicating that the main control board has been powered on), wait 10seconds and then press the laser switch (the light of the indicator indicatesthat the power module of the laser has been powered on normally).b)Operational procedures for checking laser cleaning after laser is turned onWhen the device is started normally, the laser power will be increased from 10% to 100% when the laser is first tested. Watch whether the laser isgetting stronger and stronger as a cleaning material.5.3 Attention in the process of operationa)The repetition frequency range of the laser should not exceed 10-50 kHZ.b)Do not adjust the laser repetition frequency during marking.c)Turn OFF the laser until the power to zero, then turn off the laser powersupply, and finally turn off the water cooler.6Common Alarms and solutionsThe instructions and possible solutions of alarms are as follows:Table 10 Error instructions and possible solutionsIn addition to the above, if there are any other questions or errors, please contact Raycus to get help.7Warranty, Return and Maintenance7.1General WarrantyRaycus warrants that all Raycus fiber laser products are comformed to applicable product specifications under normal use and are free from defects in materials and work manship.The warranties start on the date of shipment from Raycus for a period of time as set forth in the applicable purchase contracts or product specifications. Raycus has the right to choose to repair or replace any product that proves to be defective in materials and workmanship selectively during the warranty period. Only products with particular defects are under warranty. Raycus reserves the right to issue a credit note for any defective products produced in normal conditions.7.2Limitations of WarrantyThe warranty does not cover the maintenance or reimbursement of our productof which the problem results from tampering, disassembling, misuse, accident, modification, unsuitable physical or operating environment, improper maintenance, damages due to excessive use or not following the instructions caused by those who are not from Raycus. The customer has the responsibility to understand and follow this instruction to use the device. Any damage caused byfault operating is not warranted. Accessories and fiber connectors are excluded from this warranty.According to the warranty, client should write to us within 31days after the defect is discovered. This warranty does not involve any other party, including specified buyer, end-user or customer and any parts, equipment or other products produced by other companies.WARNINGoperatingoperation-failureconnectors are not covered by this warranty.7.3Service and RepairDo not open the device. There are no user serviceable parts, equipment orassemblies for user in this product. All service and maintenance shall be performedby qualified Raycus personnel.Please contact Raycus as soon as possible when problems under warranty about maintenance happened to the product.The product returned with permission should be placed in a suitable container. If any damage happened to the product, please notify the carrier in document immediately.We reserve the right to make changes in design or constructions of any of our products at anytime without incurring any obligation to make changes or install the same on units previouslypurchased.All the items about warranty and service above provided by Raycus are for uses’reference; formal contents about warranty and service are subject to the contract.© 2021 Wuhan Raycus Fiber Laser technologies Co. Ltd, All Rights Reserved.。
