CB1N4520zh s4520ACVATIX TM电动执行器SQL321B..SQL361B..SQL351B..用于 VKF42..蝶阀·SQL321B..工作电压 AC 220 V 、2位 (SPDT)控制信号及辅助开关信号反馈·SQL361B..工作电压 AC 220 V 、DC 0…10 V 、4…20 mA 控制信号·SQL351B..工作电压 AC 220 V 、4…20 mA 控制信号，断信号保位·SQL361B150…B2650和SQL351B150…B2650可选辅助开关·标称旋转角度 90°·具有手轮和阀位指示·内置防凝加热元件·底法兰符合标准 EN ISO 5211用途在暖通空调系统中用于驱动 VKF42..系列蝶阀，作为截止阀和控制阀。
2 / 13型号概览产品型号物料编号工作电压控制信号位置反馈信号50 Hz 、90°情况下的定位时间额定扭矩[Nm]法兰连接EN ISO 5211SQL321B25S55164-A100AC 220 V 两位 (SPDT)辅助开关对1125F07SQL361B25S55164-A113AC 220 V DC 0…10 V, 4…20 mADC 0…10 V, 4…20 mA辅助开关对1125F07SQL351B25S55164-A114AC 220 V 4…20 mA 4…20 mA 辅助开关对1125F07SQL321B50S55164-A101AC 220 V 两位 (SPDT)辅助开关对2250F07SQL361B50S55164-A102AC 220 V DC 0…10 V ，4…20 mADC 0…10 V ，4…20 mA辅助开关对2250F07SQL351B50S55164-A115AC 220 V 4…20 mA 4…20 mA 辅助开关对1950F07SQL321B150S55164-A103AC 220 V 两位 (SPDT)辅助开关对39150F07SQL361B150S55164-A104AC 220 V DC 0…10 V ，4…20 mA DC 0…10 V ，4…20 mA39150F07SQL351B150S55164-A116AC 220 V 4…20 mA 4…20 mA 39150F07SQL321B270S55164-A105AC 220 V 两位 (SPDT)辅助开关对39270F10SQL361B270S55164-A106AC 220 V DC 0…10 V ，4…20 mA DC 0…10 V ，4…20 mA39270F10SQL351B270S55164-A117AC 220 V 4…20 mA 4…20 mA 39270F10SQL321B570S55164-A107AC 220 V 两位 (SPDT)辅助开关对47570F12/F10SQL361B570S55164-A108AC 220 V DC 0…10 V ，4…20 mA DC 0…10 V ，4…20 mA47570F12/F10SQL351B570S55164-A118AC 220 V 4…20 mA 4…20 mA 47570F12/F10SQL321B1400 S55164-A109AC 220 V 两位 (SPDT)辅助开关对471400F14SQL361B1400 S55164-A110AC 220 V DC 0…10 V ，4…20 mA DC 0…10 V ，4…20 mA471400F14SQL351B1400S55164-A119AC 220 V 4…20 mA 4…20 mA 471400F14SQL321B2650 S55164-A111AC 220 V 两位 (SPDT)辅助开关对1052650F16SQL361B2650 S55164-A112AC 220 V DC 0…10 V ，4…20 mA DC 0…10 V ，4…20 mA1052650F16SQL351B2650S55164-A120AC 220 V4…20 mA4…20 mA1052650F16订货执行器、蝶阀和附件均须单独定购。
iF product design award 2012:SAX and SAL产品概览Acvatix 阀门执行器─经济高效的HVAC 系统的决定性组成部件以多年的实践经验、广泛的专业知识和先进的技术为依托，西门子推出了AcvatixTM系列阀门和执行器产品，为暖通水力系统提供理想的解决方案。
这些阀门执行器主要应用于暖通系统中的冷热源、能源分配及末端控制，并可用于区域供热。
因此，Acvatix能够满足HVAC领域以及制冷和工业应用的各种需要。
无论是单户住宅还是公寓，无论是现代办公大楼里复杂的空调还是流量非常大的设备，Acvatix阀门执行器都以高质量和长寿命著称。
他们不仅让您感到舒适、安宁，还可以在能源优化使用、项目改造中助您一臂之力。
适用于各种应用的阀门执行器产品只有机组内每个设备都能可靠、精确的运转时，HVAC 和制冷系统才能正常的工作。
来自西门子的Acvatix 产品线根据您的需要、介质类型和应用类型，总能为您提供合适的阀门执行器：- 用于小型、中型和大型HVAC 和制冷系统的阀门执行器- 用于房间、区域等末端控制的阀门执行器- 两通和三通座阀、蝶阀- 法兰、螺纹和焊接连接- 用于高精度、复杂控制系统的电磁调节阀- 带调节功能和3位或开／关控制信号的执行器地板采暖，辐射采暖TEVA 产品线，见第16页利用散热器控制区域温度TEVA 产品线，见第15和16页生活热水混合系统反应迅速的电磁调节阀， 见第5页法兰和螺纹连接的阀， 见第7-10页生活热水存储罐反应迅速的电磁调节阀，见第5页法兰和螺纹连接的阀， 见第7-10页法兰和螺纹连接的阀， 见第7-10页关闭功能蝶阀，见第13页区域供热分站法兰和螺纹连接的阀， 见第7-10页关闭冷却水塔见第13页控制风机盘管装置TEVA 产品线，见第16页冷吊顶TEVA 产品线，见第16页控制终端装置TEVA 产品线，见第16页用于空气调节设备的制冷盘管反应迅速的电磁调节阀，见第5页法兰和螺纹连接的阀，见第7-12页用于空气调节设备的供暖盘管法兰和螺纹连接的阀，见第7-12页冷冻水环路反应迅速的电磁调节阀，见第5页法兰和螺纹连接的阀，见第7-13页冷却水环路反应迅速的电磁调节阀，见第5页法兰和螺纹的阀，见第7-13页■ 实现能源优化■产品种类多样，适合于各种应用■ 便捷选择阀门执行器■高效配送- 工作电压为AC / DC 24 V 或AC 110 / 230 V 的执行器- 大量专利技术应用于各阀门或执行器，优化系统控制便捷选型西门子为您提供了各种阀门执行器的选型工具，阀门选型尺，技术资料和在线工具。
西门子风阀执行器原理西门子风阀执行器原理是指通过电动执行器来实现风阀的开启和关闭操作。
该执行器采用了先进的电动技术和控制系统，能够对风阀进行精确的控制，从而实现对空调系统的温度、湿度和风量的调节。
首先，西门子风阀执行器采用了高性能的电动机作为动力源。
电动机通过电能转化为机械能，通过转轴带动风阀的运动，实现对风阀的控制。
电动机的特点是响应速度快、调节精度高，能够满足实时调节的需求。
其次，西门子风阀执行器配备了高精度的位置传感器。
位置传感器能够实时监测风阀的开启程度，将具体的位置信息反馈给控制系统。
控制系统根据位置传感器的信号调节电动机的运行，使得风阀能够精准地达到要求的开启程度。
位置传感器可以是光电编码器、霍尔效应传感器等，具有高精度、可靠性强的特点。
此外，西门子风阀执行器还采用了先进的控制系统。
控制系统是整个执行器的核心部分，负责接收外部控制信号，并根据信号的要求调节风阀的开闭状态。
控制系统还可以根据环境温度、湿度和风量等参数来进行智能调节，实现对空调系统的自动化控制。
控制系统可以采用PLC（可编程逻辑控制器）或微处理器等硬件实现，具有高可靠性和稳定性。
最后，西门子风阀执行器还具备人性化的操作界面。
操作界面可以是触摸屏或按钮式控制面板，用户可以通过界面进行对风阀的开关、调节等操作。
同时，界面还可以显示风阀的开闭状态、运行参数等信息，方便用户对系统进行监控和管理。
总结起来，西门子风阀执行器的原理是通过电动机、位置传感器和控制系统的协同工作，实现对风阀的精确控制。
它具有响应速度快、调节精度高、自动化程度高、可靠性强等特点，适用于各类空调系统中风阀的开关控制。
20…40 mm行程∙SBX31、SBV31工作电压 AC 230 V，三位控制信号∙SBX81、SBV81工作电压 AC 24 V，三位控制信号∙SBX61、SBV61工作电压 AC 24 V， DC 0…10 V控制信号∙SBX61、SBV61可选4…20 mA控制信号功能，由AZX420功能模块来实现，断信号时执行器回到全关位∙SBX151.00、SBV151.00工作电压AC 24 V，4…20 mA控制信号，断信号时保持阀位∙直接安装在阀门上，无需调节∙手动调节扳手和阀杆行程指示用于西门子二通阀 VVF47..、VVI47和三通阀VXF47.. VXI47..系列型号的阀门执行器，驱动行程为 20 mm和 40 mm，在暖通空调系统中作为控制阀使用。
产品型号物料编号定位信号行程驱动力工作电压 [V]运行时间[s]手动操作SBX61S55160-A100DC 0…10 V20 mm 700 N AC 24 V120手动调节扳手SBX81S55160-A101三位SBX31S55160-A102AC 230 V SBX151.00S55160-A1084…20 mA AC 24 VSBV61S55160-A103DC 0…10 V40 mm 1600 N AC 24 V180手动调节扳手SBV81S55160-A104三位SBV31S55160-A105AC 230 VSBV151.00S55160-A1094…20 mA AC 24 V 附件产品型号物料编号说明SBX31SBV31SBX81SBV81SBX61SBV61SBX151.00SBV151.00AZX420 S55845-Z120功能模块--最多1个-示例产品型号订货号说明数量SBX61S55160-A100执行器1AZX420S55845-Z120功能模块1交付执行器、阀门和附件分开包装和供货。
