Key Features

● Ultra-Miniature SMT Package ● Lead Frame Technology

● 1W Output Power ● 5V and 12V Inputs

● -40ºC to +85ºC Operation ●

Low Cost

Electrical Specifi cations

Specifi cations typical @ +25ºC with nominal input voltage & rated output current, unless otherwise noted. Specifi cations subject to change without notice.Input

ParameterConditionsMin.Typ.Max.Units

Input Voltage Range5 VDC Input4.55.05.5VDC12 VDC Input10.812.013.2

Reverse Polarity Input Current1.0A

Input FilterCapacitor

Output

ParameterConditionsMin.Typ.Max.Units

Output Voltage Accuracy±1.0±3.0%

Output Voltage AccuracyDual Output, Balanced Load±0.1±1.0%

Line RegulationFor Vin Change of 1%±1.2±1.5%

Load RegulationSee Model Selection Guide

Ripple & Noise (20 MHz)60120mV P - P

Ripple & Noise (20 MHz)Over Line, Load & Temp.150mV P - P

Ripple & Noise (20 MHz)5mv rms

Output Power Protection120%

Temperature Coeffi cient±0.01±0.02%/ºC

Output Short CircuitMomentary (0.5 Sec.)

General

ParameterConditionsMin.Typ.Max.Units

Isolation Voltage60 Seconds1,000VDC

Isolation Resistance500 VDC1,000MΩ

Isolation Capacitance100 kHz, 1V40100pF

Switching Frequency70100140kHz

Environmental

ParameterConditionsMin.Typ.Max.Units

Operating Temperature Range-40+25+85ºC

Storage Temperature Range-40+125ºC

CoolingFree Air Convection

HumidityRH, Non-condensing95%

Physical

Case Size 0.60 x 0.31 x 0.26 Inches (15.24 x 8.0 x 6.7 mm)

Case MaterialNon-Conductive Black Plastic

Weight0.05 Oz (1.5g)

Reliability Specifi cations

ParameterConditionsMin.Typ.Max.Units

MTBFMIL HDBK 217F, 25ºC, Gnd Benign3.0MHours

Absolute Maximum Ratings

ParameterConditionsMin.Typ.Max.Units

Input Voltage Surge (1 Sec)5 VDC Input-0.79.0VDC12 VDC Input-0.718.0

Internal Power DissipationAll Models450mW

Caution: Exceeding Absolute Maximum Ratings may damage the module. These are not continuous operating ratings.MicroPowerDirect

1W Dual Output

Surface Mountable

DC/DC Converters

LF100D Series

MicroPower Direct ● TEL: (781) 344-8226 ● FAX: (781) 344-8481 ● E-Mail: sales@micropowerdirect.com ● WEB: www/micropowerdirect.com元器件交易网www.cecb2b.comModel Selection Guide

Notes:All dimensions are typical in inches (mm)

Tolerance x.xx = ±0.01 (±0.25)

Pin 1 is marked by a “dot” or indentationon the unitModelNumberInputOutputLoadRegulation(%, Max)Effi ciency(%, Typ)Fuse RatingSlow-Blow(mA)Voltage (VDC)Current (mA)Voltage(VDC)Current(mA, Max)Current(mA, Min)NominalRangeFull-LoadNo-LoadLF101D54.5 - 5.526730±5.0±100.0±2.01075500

LF102D54.5 - 5.526030±9.0±55.0±1.01076500

LF103D54.5 - 5.525530±12.0±42.0±0.8879500

LF104D54.5 - 5.525130±15.0±33.0±0.7779500

LF111D1210.8 - 13.211115±5.0±100.0±2.0875200

LF112D1210.8 - 13.210915±9.0±55.0±1.0876200

LF113D1210.8 - 13.210515±12.0±42.0±0.8580200

LF114D1210.8 - 13.210315±15.0±33.0±0.7580200

232 Tosca Drive, Stoughton, MA 02072www.micropowerdirect.comsales@micropowerdirect.comphone: (781) 344 - 8226 ● fax: (781) 344 - 8481Mechanical Dimensions

MicroPower

DirectPinDescriptionPinDescription

1-Vin6NA

2+Vin7+Vout

3NA8NA

4Common9NA

5-Vout10NAPin Connections

μF Max

±33Capacitive

Load

0.10(2.54)0.42(10.8)0.07(1.70)

0.04(1.0) Min

Board Layout-40-2005152535455565758595105020406080100

OutputPower%

AmbientTemperature1C-5%/1C

0.60 (15.24 )++0.010.25

0.30 (8.0 )++0.0040.100

0.0270.7) ( ++0.0040.1000.25 (6.5 )++0.0040.100

0.27 (7.0 )++0.0040.100

0.35 (9.0 )++0.0080.2000.42 (10.8 )++0.0080.200

SeeNote

SSeating Plane

0.001 (0.25 )++0.0020.0500.04 (1.05 )++0.0060.1500.40 (10.16 )++0.0040.1000.26 (6.7 )++0.0040.1000.078 (2.000 )++0.0040.100

0.01 (0.25 )+0.0 / -0.006+0.0 /- 0.1500.10 (2.54 )++0.0040.100++0.2(

5.0

)OOReferencePlane

Note: The curved edge of the case indicates the Pin 1 side.12345678910

Top ViewDerating CurveNote:1. Load regulation is measured for an output change of 20% to 100%.2. The outputs of these units may be connected to provide a 5 VDC, 18 VDC, 24 VDC or 30 VDC output. To do this, connect the load across the positive (+Vout) and negative (-Vout) ouputs and fl oat the ouput common.3. These units do not require external comonents to operate, but the use of an input capacitor (10 µF) may enhance performance in some applications. For applications requiring lower output ripple levels, the addition of an output capacitor (4.7 µF to 10 µF) will typically achieve good results.元器件交易网www.cecb2b.com
