AIAG全称Automotive Industry Action Group即汽车工业行动小组。
该组织成立于1982年，由美国三大汽车公司通用、福特和克莱斯勒共同创建，是全球公认的著名的非盈利组织。
AIAG已有超过1000多家的成员公司，其中包括：整车制造商：克莱斯勒、福特、通用、北美丰田和北美本田一级供应商：德尔福、江森自控、固特异、麦格纳、约翰迪尔、伟世通、李尔、博格华纳等。
AIAG CQI-11电镀系统评估的三大目的Plating System Assessment(英文简称：PSA)‧持续改善‧问题与风险预防‧降低制程变异与供应链上的损耗浪费AIAG CQI-11评估准则•原则：1次/年•客户有特别要求对PSA符合程度评估时，则按客户要求执行•评估必须使用ISO/TS16949:2009规定的流程步骤审核/评测AIAG CQI-11审核员资格要求•质量内审员资格（ISO/TS16949 ISO9001）•必须具备电镀专业知识•具有表面处理作业五年以上经验, 或正式的化工与表面处理工作合并共五年以上学经历•接受过TS16949五大手册专业培训AIAG CQI-111.1 现场是否有专门且合格的表面处理人员?•现场需要一位专门且合格的表面处理人员。
•是全职员工，且职位需被列入于组织图中。
•需有化工与表面处理相关知识的描述。
•需包含具有表面处理作业五年以上经验， 或正式的化工与表面处理工作合并共五年以上学经历。
AIAG CQI-111.2 表面处理厂是否执行先期产品质量规划?•公司文件应纳入先期产品质量规划（ＡＰＱＰ）之程序。
•公司可以将相似的零件定义为同一类型的产品进行可行性评估。
•在客户审核通过后，除非客户同意，否则不允许改变任何程序。
•当制造程序需要改变时，电镀厂需与客户联络要求审核。
•重大制造程序改变的客户审核文件，应该以记录归档。
AIAG CQI-111.3 制程处理FMEA是否为最新的且反应出目前的制程？•公司文件应纳入制程失效模式（ＦＭＥＡ）程序，并确保ＦＭＥＡ适时更新以反映出目前产品质量状况。
iso4042电镀标准ISO4042电镀标准是一套国际标准，它提供了一种标准的电镀表面处理方法，用于减少零件表面材料上的损伤及延长其使用寿命。
ISO4042电镀标准作为强有力的国际标准，被广泛应用于各个行业，尤其是航空航天和汽车行业的零部件表面处理领域。
ISO4042电镀标准的主要目的在于提供一种严格一致的表面处理技术，以确保零件能够实现精确的尺寸和表面光滑度，并延伸使用寿命至少达到6年以上。
在设计上，每一种ISO4042电镀标准都包括了许多定量的要求，包括厚度要求(规定不得超过0.003英寸)、耐腐蚀性要求(耐蚀性不得少于800小时)、仪器精度要求(规定精度不得少于0.015英寸)以及其他特定性要求。
此外，根据设计的不同，ISO4042电镀标准同时提供了三种实施的机制，包括定义标准的特殊要求(如特定的特殊要求)、认证机构的特殊要求(如特殊工厂检查程序以及特殊技术术语)和评价机构的特殊审查要求(如特殊技术文件以及特殊报告)。
这三种实施机制能够有效确保ISO4042电镀标准在生产中的准确性以及全面性，从而确保零部件表面质量的合格程度。
另外，ISO4042电镀标准还包括一系列检测和检验项目，以确保按照标准要求施行的表面处理技术的有效性。
这些检测和检验项目包括但不限于：表面处理厚度测试、表面处理均匀度测试、表面处理坚硬度测试以及表面处理耐蚀性测试等。
所有经过ISO4042电镀标准测试的零件必须满足规定的要求，否则将被拒绝生产。
总之，通过IS0 4042电镀标准，旨在确保零件表面处理的质量符合严格的国际标准，保证零件表面的精确尺寸和表面光滑度，并延长其使用寿命。
此外，三种实施机制以及检测检验项目的加入，进一步保障了ISO4042电镀标准在表面处理技术中的准确性与全面性，从而确保输出零件质量的合格率。
东风汽车公司标准电镀层及化学处理层标准(EQY-3—95 代替EQY—3—86)1主题内容与适用范围本标准规定了汽车零(部）件的电镀层和化学处理层的技术规范及膜层的质量要求.本标准适用于汽车零(部)件的电镀层及化学处理层的质量控制和验收。
2引用标准GB4956—85磁性金属基体上非磁性覆盖层厚度测量—磁性方法GB5270—85金属基体上金属覆盖层-附着强度试验方法GB6458-86金属覆盖层—中性盐雾试验(NSS试验)GB6460—86金属覆盖层—铜加速醋酸盐雾试验(CASS试验)GB6461-86金属覆盖层-对底材为阴极的覆盖层腐蚀试验后的电镀试样的评级GB6462—86金属和氧化物覆盖层-横断面厚度显微镜测量方法GB9792—88金属材料上的转化膜—单位面积上膜层质量的测定-重量法GB/T12610-90 塑料上电镀层-热循环试验3术语3.1主要表面在工件的某些表面上，其镀层或化学处理层对制件的外观和(或)使用性能起着重要作用。
3.2厚度工件的主要表面上，凡是能与直径为20mm的球体相接触的部位上的厚度的最小值4 镀覆及化学处理的表示方法4.1电镀表示方法基体材料/镀覆方法·镀覆名称·镀覆层厚度·镀复层特征·后处理4.2化学处理表示方法基体材料/处理方法·处理特征·后处理(颜色）4.3基体材料为钢铁材料时，其符号允许省略.4。
4如果镀层或化学处理层的特征、厚度、颜色及后处理无具体要求时，其符号允许省略。
4。
5表示符号4。
5。
1基体材料表示符号：金属材料用化学元素符号表示，合金材料用其主要成分的化学元素符号表示,非金属材料用国际通用缩写字母表示，如铜用Cu表示，塑料用PL表示。
4。
5.2镀覆方法和处理方法的表示符号见表1。
方法名称符号备注镀覆方法电镀EP化学镀CP机械镀MP锌铬膜JZnCr化学处理方法化学氧化CO 钢铁化学氧化又称发兰阳极氧化AO 包括镀铬阳极松孔锰盐磷化MnPh 磷化无特定要求时只标注Ph锌盐磷化ZnPh 磷化无特定要求时只标注Ph铬酸盐处理(白色) B 简称白钝化铬酸盐处理（彩色）C 简称彩色钝化铬酸盐处理（绿色）G 简称绿钝化铬酸盐处理(黑色）H 简称黑钝化铜及合金钝化P 也用于银层钝化表示4。
车锁零部件镀层标准2007-09-05发布2007-09-06实施韩国现代机电有限公司1. 目的及使用范围颁布本标准是为了统一公司内部镀层标准规范，形成技术指导性文件。
本标准只适用于有防腐、装饰保护要求的车锁零部件，并对其表面镀层要求作出了规定。
2. 参考标准中国汽车行业标准QC/T 625-1999《汽车用涂镀层和化学处理层》中国国家标准 GB/T 10125-1997《人造气氛腐蚀试验——盐雾试验》上汽双龙标准 SES F 204-01 (V4) 《汽车部品用镀锌》日本三菱工业镀锌标准日本三菱工业镀铬标准3. 表面镀层方法及种类3.1方法（见表1）表13.2种类1. 镀锌＋钝化（铁基材，锌合金基材）2. 防护装饰性镀铬4. 镀锌＋钝化4.1镀锌主要适用于锌合金和铁基材料，镀锌的目的在于强化钝化层的附着力，镀锌表示方法见表2注：a.镀锌层不能太薄，否则耐腐蚀能力就会下降。
b.电镀锌后，对于弹簧件、高强度零件应进行消除氢脆危险性的处理。
c.对有消氢脆处理要求的零部件，必须在图纸上注明“消氢脆处理”字样。
4.2.使用条件界定，见表3表34.3钝化4.3.1电镀锌后，通常用铬酸盐进行钝化处理，形成铬酸盐转化膜。
铬酸盐转化膜的分类、典型外观、耐蚀性要求、使用条件见表4表4注a.NSS试验方法参照标准：GB/T 10125-1997，出现白色腐蚀产物的时间不能低于表4所规定的时间。
b.对锌合金的镀锌钝化，在规定的试验时间内，被测产品表面应无白锈产生，否则视为不良；对于铁基材的镀锌钝化，在规定的试验时间内，产品表面应无白锈和红锈产生，否则视为不良。
c.钝化处理过程中，不得使用Cr6+.d.对于锌合金零部件，也可以直接采取钝化处理，一般是黑色钝化。
4.3.2 若直接在锌合金上钝化处理，其铬酸盐转化膜的分类、典型外观、耐蚀性要求、使用条件见表5表54.3表示方法在所有技术文件中，对零部件的镀锌钝化处理的表示方法均采用表 6 中的标识方法。
公司标准电镀层及化学处理层标准（EQY-3-95 代替EQY-3-86）1主题内容与适用范围本标准规定了汽车零(部)件的电镀层和化学处理层的技术规范及膜层的质量要求。
本标准适用于汽车零(部)件的电镀层及化学处理层的质量控制和验收。
2引用标准GB4956-85磁性金属基体上非磁性覆盖层厚度测量-磁性方法GB5270-85金属基体上金属覆盖层-附着强度试验方法GB6458-86金属覆盖层-中性盐雾试验(NSS试验)GB6460-86金属覆盖层-铜加速醋酸盐雾试验(CASS试验)GB6461-86金属覆盖层-对底材为阴极的覆盖层腐蚀试验后的电镀试样的评级GB6462-86金属和氧化物覆盖层-横断面厚度显微镜测量方法GB9792-88金属材料上的转化膜-单位面积上膜层质量的测定-重量法GB/T12610-90 塑料上电镀层-热循环试验3术语3.1主要表面在工件的某些表面上，其镀层或化学处理层对制件的外观和(或)使用性能起着重要作用。
3.2厚度工件的主要表面上，凡是能与直径为20mm的球体相接触的部位上的厚度的最小值4 镀覆及化学处理的表示方法4.1电镀表示方法基体材料/镀覆方法·镀覆名称·镀覆层厚度·镀复层特征·后处理4.2化学处理表示方法基体材料/处理方法·处理特征·后处理(颜色)4.3基体材料为钢铁材料时，其符号允许省略。
4.4如果镀层或化学处理层的特征、厚度、颜色及后处理无具体要求时，其符号允许省略。
4.5表示符号4.5.1基体材料表示符号:金属材料用化学元素符号表示，合金材料用其主要成分的化学元素符号表示，非金属材料用国际通用缩写字母表示，如铜用Cu表示，塑料用PL表示。
4.5.2镀覆方法和处理方法的表示符号见表1。
方法名称符号备注镀覆方法电镀EP化学镀CP机械镀MP 锌铬膜JZnCr化学处理方法化学氧化CO 钢铁化学氧化又称发兰阳极氧化AO 包括镀铬阳极松孔锰盐磷化MnPh磷化无特定要求时只标注Ph锌盐磷化ZnPh磷化无特定要求时只标注Ph铬酸盐处理（白色） B 简称白钝化铬酸盐处理（彩色） C 简称彩色钝化铬酸盐处理（绿色）G 简称绿钝化铬酸盐处理（黑色）H 简称黑钝化铜及合金钝化P 也用于银层钝化表示4.5.3镀层厚度用阿拉伯数字表示，单位为μm。
Q/FAGX长春一汽富维高新汽车饰件有限公司企业标准Q/FAGXES11-B-001-2010-1 汽车用塑料电镀零件检验标准2010-10-29发布2010-11-01实施编制：滕国岩审核：批准：批准：2010-11-29长春一汽富维高新汽车饰件有限公司发布目录1.目的032.范围033.术语03-044.检验规范04 4.1.检验区域划分04 4.1.1.划分区域04-05 4.1.1.1.直视面05 4.1.1.1.1.A区05 4.1.1.1.2.B区06 4.1.1.2.侧视面06 4.1.1.3.俯视面06-07 4.1.1.4.装配隐藏面07 4.1.1.5.装车隐藏面07-08 4..2.缺陷等级定义09 4.2.1.A类缺陷09 4.2.2.B类缺陷09 4.2.3.C类缺陷09 4.3.缺陷定义09-11 4.4.检验方式规定12 4.5.各区域检验标准12-14 4.6分区检验原则15 4.7所有周边类检测面及区域划分15-281. 目的：以顾客为导向，加强对相应缺陷的控制以检验标准为依据，客观进行评价防止不必要的竞争，优化电镀零件制造展望适应新规则以顾客要求和改进能力为基础，进行竞争形势分析引入奥迪特短时间评审2. 范围：适用于汽车塑料电镀零件外观检验客户：一汽大众，一汽轿车，墨西哥大众。
3. 术语：3.1 电镀：电镀就是利用电解的方式使金属或金属合金沉积在工件表面，以形成均匀、致密、结合力良好的金属层的过程；3.2 检验：为确定某一物质的性质、特征、组成等而进行的试验，或根据一定的要求和标准来检查试验对象品质的优良程度。
3.2.1通常把对物理特性的检验称为物理检验；3.2.2对化学性质或组成的检验称为化学检验或简称化验。
3.2.3检验一般有破坏性检验和非破坏性检验，前者只能从整体中取样进行抽查，然后用数理统计方法推定整体的情况；后者可对整体进行逐个检查。
3.2.4 从被检对象的类别考虑，人们又常将它分为半成品检验、成品检验或商品检验等。
AN ISO9002 / QS9000 REGISTERED COMPANYSPECIFICATION LISTINGTHE FOLLOWING IS A PARTIAL LISTING OF THE SPECIFICATIONS THAT MARSH PLATING CORPORATION AND/OR FINISHING SERVICES INC. ARE CAPABLE OF PROCESSING TO. IF YOU REQUIREA FINISH THAT IS NOT LISTED, PLEASE CONTACT THE ESTIMATING DEPARTMENT AT MARSH PLATING ((734) 483-5767) FOR MORE UP TO DATE INFORMATION ON OUR CAPABILITIES.SALT SPRAY ORGANIZATION SPEC.DESCRIPTION THICK.COLOR WHITE RED ASTM B545ELECTRODEPOSITED COATINGS OF TINCLASS A MILD SERVICE CONDITIONS WHERE THE SIGNIFICANT SURFACE IS SHIELDED.00010"SILVER N/ACLASS B MILD SERVICE CONDITIONS .00020"SILVER N/ACLASS C MODERATE EXPOSURE CONDITIONS, USUALLY INDOORS.00032"SILVER N/ACLASS D SEVERE SERVICE, INCLUDING EXPOSURE TO DAMPNESS AND MILD CORROSION.00060"SILVER N/ACLASS E VERY SEVERE SERVICE CONDITIONS, INCLUDING ELEVATED TEMPERATURES.00120"SILVER N/ACLASS F SIMILAR TO CLASS A, BUT FOR SHORTER TERM CONTACT APPLICATIONS.00006"SILVER N/AASTM B633ELECTRODEPOSITED COATINGS OF ZINC ON IRON AND STEELSC 1MILD.00020"SC 2MODERATE.00032"SC 3SEVERE.00050"SC 4VERY SEVERE.00100"TYPE I AS PLATED WITHOUT SUPPLEMENTARY TREATMENT SILVERTYPE II WITH COLORED CHROMATE CONVERSION COATINGS YELLOW*96TYPE III WITH COLORLESS CHROMATE CONVERTION COATINGS SILVER12TYPE IV WITH PHOSPHATE CONVERSION COATING GRAYASTM B689ELECTROPLATED ENGINEERING NICKEL COATINGSCLASS 5THICKNESS 5 MICROMETERS.00020"SILVERCLASS 25THICKNESS 25 MICROMETERS.00100"SILVERCLASS 50THICKNESS 50 MICROMETERS.00200"SILVERCLASS 100THICKNESS 100 MICROMETERS.00400"SILVERCLASS 200THICKNESS 200 MICROMETERS.00800"SILVERX THICKNESS AS SPECIFIED TBD SILVERTYPE 1NICKEL ELECTROPLATED FROM SOLUTIONS NOT CONTAINING HARDENERS, BRIGHTENERS OR STRESS CONT.SILVERTYPE 2NICKEL ELECTRODEPOSITS USED AT MODERATE TEMPERATURES CONTAINING COMPOUNDS THAT INCREAS.SILVERTYPE 3NICKEL ELECTRODEPOSITS USED AT ELEVATED TEMPERATURES CONTAING COMPOUNDS THAT INCREASE H.SILVERAN ISO9002 / QS9000 REGISTERED COMPANYSPECIFICATION LISTINGTHE FOLLOWING IS A PARTIAL LISTING OF THE SPECIFICATIONS THAT MARSH PLATING CORPORATION AND/OR FINISHING SERVICES INC. ARE CAPABLE OF PROCESSING TO. IF YOU REQUIREA FINISH THAT IS NOT LISTED, PLEASE CONTACT THE ESTIMATING DEPARTMENT AT MARSH PLATING ((734) 483-5767) FOR MORE UP TO DATE INFORMATION ON OUR CAPABILITIES.SALT SPRAY ORGANIZATION SPEC.DESCRIPTION THICK.COLOR WHITE RED ASTM B733AUTOCATALYTIC (ELECTROLESS) NICKEL-PHOSHOROUS COATINGS ON METALSC 0MINIMUM THICKNESS.000004"SILVERSC 1LIGHT SERVICE.00020"SILVERSC 2MILD SERVICE.00050"SILVERSC 3MODERATE SERVICE.00100"SILVERSC 4SEVERE SERVICE.00300"SILVERTYPE I NO REQUIREMENT FOR PHOSPHORUS SILVERTYPE II 1 - 3% PHOSPHORUS SILVERTYPE III 2 - 4% PHOSPHORUS SILVERTYPE IV 5 - 8% PHOSPHORUS SILVERTYPE V10% - PHOSPHORUS SILVERASTM B734ELECTRODEPOSITED COPPER FOR ENGINEERING USESCLASS 5THICKNESS 5 MICROMETERS.00020"COPPERCLASS 12THICKNESS 12 MICROMETERS.00050"COPPERCLASS 20THICKNESS 20 MICROMETERS.00080"COPPERCLASS 25THICKNESS 25 MICROMETERS.00100"COPPERCLASS X THICKNESS AS SPECIFIED TBD COPPERASTM B840ELECTRODEPOSITED COATINGS OF ZINC COBALT ALLOY DEPOSITSGRADE 6THICKENSS 6 MICROMETERS.00025"GRADE 12THICKNESS 12 MICROMETERS.00050"GRADE 18THICKNESS 18 MICROMETERS.00075"TYPE A WITH COLORLESS CHROMATE CONVERSION COATINGS SILVERTYPE B WITH YELLOW CHROMATE CONVERTION COATING YELLOWTYPE C WITH BRONZE CHROMATE CONVERSION COATING BRONZETYPE D WITH BLACK CHROMATE CONVERSION COATING BLACKTYPE E ANY OF THE ABOVE TYPES PLUS ORGANIC TOPCOAT TBDASTM B841ELECTRODEPOSITED COATINGS OF ZINC NICKEL ALLOY DEPOSITSCLASS 1DEPOSITS HAVING 5 - 12% NICKEL, THE BALANCE BEING ZINCGRADE 5THICKNESS 5 MICROMETERS.00020"GRADE 8THICKNESS 8 MICROMETERS.00032"GRADE 10THICKNESS 10 MICROMETERS.00040"TYPE A WITH COLORLESS CHROMATE CONVERSION COATINGS SILVERTYPE B WITH YELLOW CHROMATE CONVERTION COATING YELLOWTYPE C WITH BRONZE CHROMATE CONVERSION COATING BRONZETYPE D WITH BLACK CHROMATE CONVERSION COATING BLACKTYPE E ANY OF THE ABOVE TYPES PLUS ORGANIC TOPCOAT TBDAN ISO9002 / QS9000 REGISTERED COMPANYSPECIFICATION LISTINGTHE FOLLOWING IS A PARTIAL LISTING OF THE SPECIFICATIONS THAT MARSH PLATING CORPORATION AND/OR FINISHING SERVICES INC. ARE CAPABLE OF PROCESSING TO. IF YOU REQUIREA FINISH THAT IS NOT LISTED, PLEASE CONTACT THE ESTIMATING DEPARTMENT AT MARSH PLATING ((734) 483-5767) FOR MORE UP TO DATE INFORMATION ON OUR CAPABILITIES.SALT SPRAY ORGANIZATION SPEC.DESCRIPTION THICK.COLOR WHITE RED ASTM B842ELECTRODEPOSITED COATINGS OF ZINC IRON ALLOY DEPOSITSCLASS 1DEPOSITS HAVING APPROXIMATELY 99% ZINC MASS, BALANCE IRONGRADE 6THICKNESS 6 MICROMETERS.00025"GRADE 12THICKNESS 12 MICROMETERS.00050"GRADE 18THICKNESS 18 MICROMETERS.00075"TYPE A ZINC IRON WITH BLACK CHROMATE CONVERSION COATING BLACKTYPE B ZINC IRON WITH IRIDESCENT YELLOW CHROMATE CONVERSION COATING YELLOWASTM B850POST COATING TREATMENTS OF STEEL FOR REDUCING THE RISK OF HYDROGEN EMBRITTLEMENTDELPHI DX150100CORROSION PROTECTIVE COATINGS - ZINC ALLOY PLATINGDX150101ZINC COBALT YELLOW240 DX150102ZINC COBALT CLEAR96 DX150103ZINC COBALT BLACK240 DX150104ZINC NICKEL YELLOW500 DX150105ZINC NICKEL CLEAR240 DX150106ZINC IRON BLACK288 DX150107ZINC IRON YELLOW288 DX150108TIN ZINC YELLOW N/A DELPHI DX551200CORROSION PROTECTIVE COATINGS - HEXAVALENT CHROMIUM FREE ZINC PLATINGDX5512013U24/0.0001"N/A N/A24 DX5512026U48/0.0002"N/A N/A48 DX5512039U72/0.00035"N/A N/A72 DX55120412U96/0.0005"N/A N/A96 DX5512058K96/24.0003"CLEAR2496 DX55120615K240/24.0006"CLEAR24240 DX5512078K240/96G.0003"CLEAR96240 DX5512088K360/120G.0003"CLEAR120360 DX5512098K480/240G.0003"CLEAR240480 DX5512108K72/48.0003"CLEAR4872 DX5512118K240/120T.0003"CLEAR120240 DX5512129K168/120G.00035"CLEAR120168 DX55121312K240/120G.0005"CLEAR120240 DX5512148K500/96GW.0003"CLEAR96500 DX5512159K120/48G.00035"CLEAR48120 DX5512169D168/120G.00035"YELLOW120168 DX5512179K168/120G.00035"CLEAR120168 DX55121812K240/120 .0005"CLEAR120240 DX5512198K72/24.0003"CLEAR2472 DX5512208K96/48.0003"CLEAR4896AN ISO9002 / QS9000 REGISTERED COMPANYSPECIFICATION LISTINGTHE FOLLOWING IS A PARTIAL LISTING OF THE SPECIFICATIONS THAT MARSH PLATING CORPORATION AND/OR FINISHING SERVICES INC. ARE CAPABLE OF PROCESSING TO. IF YOU REQUIREA FINISH THAT IS NOT LISTED, PLEASE CONTACT THE ESTIMATING DEPARTMENT AT MARSH PLATING ((734) 483-5767) FOR MORE UP TO DATE INFORMATION ON OUR CAPABILITIES.SALT SPRAY ORGANIZATION SPEC.DESCRIPTION THICK.COLOR WHITE RED DX5512213K32/8.0001"CLEAR832 DX5512223K24/8.0001"CLEAR824 DELPHI DX551300CORROSION PROTECTIVE COATINGS - ZINC ALLOY PLATING (HEXAVALENT CHROMIUM FREE)DX551301ZINC COBALT CLEAR500 DX551302ZINC IRON CLEAR600 DX551303ZINC NICKEL CLEAR600 DX551304ZINC IRON COBALT CLEAR500 DX551305ZINC IRON BLACK500 FORD ESB-M1P1-A PLATING, CADMIUM AND ZINCCLASS A VERY SEVERE, EXTERIOR.00050"*0144 CLASS B SEVERE, EXTERIOR.00050"096 CLASS C MODERATE, EXTERIOR OR INTERIOR.00035"048 CLASS D LIGHT, INTERIOR.00015"024 CLASS 1GREEN TO OLIVE DRAB / HEAVY CHROMATE PLUS BLACK DYE / DOUBLE DIP CLEAR GREEN96NA CLASS 2YELLOW CHROMATE / BLACKENING SALT AND OIL DIP YELLOW48NA CLASS 3LIGHT YELLOW CHROMATE / SINGLE DIP CLEAR CLEAR24NAAN ISO9002 / QS9000 REGISTERED COMPANYSPECIFICATION LISTINGTHE FOLLOWING IS A PARTIAL LISTING OF THE SPECIFICATIONS THAT MARSH PLATING CORPORATION AND/OR FINISHING SERVICES INC. ARE CAPABLE OF PROCESSING TO. IF YOU REQUIREA FINISH THAT IS NOT LISTED, PLEASE CONTACT THE ESTIMATING DEPARTMENT AT MARSH PLATING ((734) 483-5767) FOR MORE UP TO DATE INFORMATION ON OUR CAPABILITIES.SALT SPRAY ORGANIZATION SPEC.DESCRIPTION THICK.COLOR WHITE RED FORD ESE-M1P2-A PLATING, COPPER.00015"COPPER NA8FORD ESF-M1P3-A PLATING, CADMIUM AND ZINC (SEVERE).00050"SILVER096 YELLOW.00050"YELLOW96NA CLEAR / BLACK.00050"TBD48NAFORD ESF-M1P4-A PLATING, CADMIUM AND ZINC (MODERATE).00035"SILVER048 YELLOW.00035"YELLOW48NA CLEAR / BLACK.00035"TBD48NA FORD ESF-M1P5-A PLATING, CADMIUM AND ZINC (LIGHT).00015"SILVER024 YELLOW.00015"YELLOW24NA CLEAR / BLACK.00015"TBD24NAFORD ESF-M1P6-A PLATING, CADMIUM AND ZINC (LIGHT).00020"SILVER032 YELLOW.00020"YELLOW32NA CLEAR / BLACK.00020"TBD32NA WSB-M1P9-B PLATING, TIN HOT DIP OVER FERROUS, COPPER OR COPPER ALLOY.00001"SILVERFORD WSB-M1P10-B PLATING, TIN ELECTRODEPOSITED ON FERROUS, COPPER OR COPPER ALLOY.00001"SILVERFORD WSB-M1P11-B PLATING, TIN ELECTRODEPOSITED ON FERROUS, COPPER OR COPPER ALLOY.0004"SILVERFORD ESF-M1P30-A PLATING, COPPERCLASS 1IDENTIFICATION.00010"COPPERCLASS 2DRAWING (LUBRICANT).00020"COPPERCLASS 3ELECTRICAL CONTACT AND WEAR RUN-IN.00030"COPPERCLASS 4SALT BATH AND PACK CARBURIZING.00090"COPPERCLASS 5GAS CARBURIZINGFORD ESF-M1P41-A PLATING, ZINC, SUPPLIMENTARY CHROMATE TREATMENT.00020"YELLOW50FORD ESS-M1P45-A PLATING, ZINC AND CHROMATE (S36).0002"YELLOW72FORD WSD-M1P65-B1PLATING, ELECTROLESS NICKEL, HEAT TREATED.00040"SILVER NA24FORD WSD-M1P65-B2PLATING, ELECTROLESS NICKEL, AS DEPOSITED.00040"SILVER NA NAFORD WSD-M1P85-A1PLATING, ZINC OVER FERROUS SURFACES.00020"SILVER NA24FORD WSD-M1P85-A2PLATING, ZINC OVER FERROUS SURFACES.00032"SILVER NA48AN ISO9002 / QS9000 REGISTERED COMPANYSPECIFICATION LISTINGTHE FOLLOWING IS A PARTIAL LISTING OF THE SPECIFICATIONS THAT MARSH PLATING CORPORATION AND/OR FINISHING SERVICES INC. ARE CAPABLE OF PROCESSING TO. IF YOU REQUIREA FINISH THAT IS NOT LISTED, PLEASE CONTACT THE ESTIMATING DEPARTMENT AT MARSH PLATING ((734) 483-5767) FOR MORE UP TO DATE INFORMATION ON OUR CAPABILITIES.SALT SPRAY ORGANIZATION SPEC.DESCRIPTION THICK.COLOR WHITE RED FORD WSD-M1P85-A3PLATING, ZINC OVER FERROUS SURFACES.0005"SILVER NA96 FORD WSH-M1P86-A PLATING, ZINC COBALT OVER FERROUS SURFACES.00032"SILVER NA240 FORD WSA-M1P87-A1PLATING, ZINC NICKEL, CHROMATED.00032"YELLOW NA768AN ISO9002 / QS9000 REGISTERED COMPANYSPECIFICATION LISTINGTHE FOLLOWING IS A PARTIAL LISTING OF THE SPECIFICATIONS THAT MARSH PLATING CORPORATION AND/OR FINISHING SERVICES INC. ARE CAPABLE OF PROCESSING TO. IF YOU REQUIREA FINISH THAT IS NOT LISTED, PLEASE CONTACT THE ESTIMATING DEPARTMENT AT MARSH PLATING ((734) 483-5767) FOR MORE UP TO DATE INFORMATION ON OUR CAPABILITIES.SALT SPRAY ORGANIZATION SPEC.DESCRIPTION THICK.COLOR WHITE REDFORD WSF-M1P89-A1PLATING, ZINC IRON OVER FERROUS SURFACES.00020"SILVER YELLOW BARREL PLATING.00020"YELLOW96240 BLACK (SILVER FREE)BARREL PLATING.00020"BLACK72336 YELLOW RACK PLATING.00020"YELLOW96336 BLACK (SILVER FREE)RACK PLATING.00020"BLACK72552 BLACK (SILVER)RACK PLATING.00020"BLACK72336FORD WSF-M1P89-A2PLATING, ZINC IRON OVER FERROUS SURFACES.00032"SILVER YELLOW BARREL PLATING.00032"YELLOW96480 BLACK (SILVER FREE)BARREL PLATING.00032"BLACK72552 YELLOW RACK PLATING.00032"YELLOW96960 BLACK (SILVER FREE)RACK PLATING.00032"BLACK721440 BLACK (SILVER)RACK PLATING.00032"BLACK72960 FORD WSE-M1P93-A1PLATING TIN ZINC ALLOY, ELECTROPLATED OVER FERROUS SURFACES.00020"YELLOW72288FORD WSE-M1P93-A2PLATING TIN ZINC ALLOY, ELECTROPLATED OVER FERROUS SURFACES.00032"YELLOW72408FORD WSE-M1P93-A3PLATING TIN ZINC ALLOY, ELECTROPLATED OVER FERROUS SURFACES.00040"YELLOW72504FORD WSE-M1P93-A4PLATING TIN ZINC ALLOY, ELECTROPLATED OVER FERROUS SURFACES.00050"YELLOW72600FORD WSE-M1P93-A5PLATING TIN ZINC ALLOY, MECHANICALLY PLATED OVER FERROUS SURFACES.0003"YELLOW72192FORD WSE-M1P93-A6PLATING TIN ZINC ALLOY, MECHANICALLY PLATED OVER FERROUS SURFACES.0004"YELLOW72240FORD ESB-M2P28-B PAINT PERFORMANCE, FUNCTIONAL EXTERIOR PARTS-SEVERE DUTYFORD ESB-M2P29-B PAINT PERFORMANCE, FUNCTIONAL EXTERIOR PARTS-MODERATE DUTYFORD ESB-M2P30-B PAINT PERFORMANCE, FUNCTIONAL EXTERIOR PARTS-LIGHT DUTYFORD ESB-M64J19-B1FORD ESB-M64J25-A1GM9984001METAL SURFACE PREPARATIONAN ISO9002 / QS9000 REGISTERED COMPANYSPECIFICATION LISTINGTHE FOLLOWING IS A PARTIAL LISTING OF THE SPECIFICATIONS THAT MARSH PLATING CORPORATION AND/OR FINISHING SERVICES INC. ARE CAPABLE OF PROCESSING TO. IF YOU REQUIREA FINISH THAT IS NOT LISTED, PLEASE CONTACT THE ESTIMATING DEPARTMENT AT MARSH PLATING ((734) 483-5767) FOR MORE UP TO DATE INFORMATION ON OUR CAPABILITIES.SALT SPRAY ORGANIZATION SPEC.DESCRIPTION THICK.COLOR WHITE RED GM9984120ELECTRODEPOSITION PRIMER, CATHODIC ELPO FOR SMALL PARTS BLACK TYPE I CONTAIN CHROMIUM AND LEAD BLACKTYPE II CHROMIUM FREE BLACKTYPE III CHROMIUM AND LEAD FREE BLACKTYPE IV CHROMIUM AND LEAD FREE BLACKGM GM1000M RESTRICTED AND REPORTABLE CHEMICALSGM GMW3034ABSENCE OF HEXAVALENT CHROME (CR VI) IN COATINGSGM GMW3044M ELECTROLYTICALLY DEPOSITED ZINC COATINGS3U24/0THICKNESS 3 MICROMETERS.0001"24N/A6U48/0THICKNESS 6 MICROMETERS.0002"48N/A9U72/0THICKNESS 9 MICROMETERS.00035"72N/A12U96/0THICKNESS 12 MICROMETERS.0005"96N/A15U120/0THICKNESS 15 MICROMETERS.0006"120N/A9K96/24THICKNESS 9 MICROMETERS.00035"962415K240/24 THICKNESS 15 MICROMETERS.0006"240248K240/24THICKNESS 8 MICROMETERS.00032"24012015K360/120X THICKNESS 15 MICROMETERS.0006"3601208B240/120X THICKNESS 8 MICROMETERS.00032"24012015B360/120X THICKNESS 15 MICROMETERS.0006"36012015D240/96THICKNESS 15 MICROMETERS.0006"240968D360/120J THICKNESS 8 MICROMETERS.00032"36012015D480/120J THICKNESS 15 MICROMETERS.0006"480120GM GMW3059RESTRICTED AND REPORTABLE SUBSTANCES FOR PARTSGM GMW3200TIN ZINC PLATINGGM GM4254M NICKEL PLATING32 CODE 100THICKNESS 100 MICROMETERS.00400"SILVER16 CODE 50THICKNESS 50 MICROMETERS.00200"SILVER NA CODE 30THICKNESS 30 MICROMETERS.00120"SILVER NA CODE 20THICKNESS 20 MICROMETERS.00080"SILVER NA CODE 10THICKNESS 10 MICROMETERS.00040"SILVERGM GM4298P SALT SPRAY (MIST) TESTAN ISO9002 / QS9000 REGISTERED COMPANYSPECIFICATION LISTINGTHE FOLLOWING IS A PARTIAL LISTING OF THE SPECIFICATIONS THAT MARSH PLATING CORPORATION AND/OR FINISHING SERVICES INC. ARE CAPABLE OF PROCESSING TO. IF YOU REQUIREA FINISH THAT IS NOT LISTED, PLEASE CONTACT THE ESTIMATING DEPARTMENT AT MARSH PLATING ((734) 483-5767) FOR MORE UP TO DATE INFORMATION ON OUR CAPABILITIES.SALT SPRAY ORGANIZATION SPEC.DESCRIPTION THICK.COLOR WHITE RED GM GM4344M CORROSION PROTECTIVE COATINGS, ZINC PLATING3U 24/0THICKNESS 3 MICROMETERS.0001"N/A24N/A 6U 48/0THICKNESS 6 MICROMETERS.0002"N/A48N/A 9U 72/0THICKNESS 9 MICROMETERS.00035"N/A72N/A 12U 96/0THICKNESS 12 MICROMETERS.0005"N/A96N/A 15U 120/0THICKNESS 15 MICROMETERS.006"N/A120N/A 3K 32/8THICKNESS 3 MICROMETERS-PASSIVATION OR CONVERSION COATING-BRIGHT.0001"CLEAR328 6K 56/8THICKNESS 6 MICROMETERS-PASSIVATION OR CONVERSION COATING-BRIGHT.0002"CLEAR568 9K 96/0THICKNESS 9 MICROMETERS-PASSIVATION OR CONVERSION COATING-CLEAR OR LIGHT IRID. BLUE.00035"CLEAR96N/A 12K 120/0THICKNESS 12 MICROMETERS-PASSIVATION OR CONVERSION COATING-CLEAR OR LIGHT IRID. BLUE.0005"CLEAR120N/A 15K 144/0THICKNESS 15 MICROMETERS-PASSIVATION OR CONVERSION COATING-CLEAR OR LIGHT IRID. BLUE.006"CLEAR144N/A 3D 72/48THICKNESS 3 MICROMETERS-PASSIVATION OR CONVERSION COATING-BRIGHT YELLOW.0001"YELLOW7248 6D 96/48THICKNESS 6 MICROMETERS-PASSIVATION OR CONVERSION COATING-BRIGHT YELLOW.0002"YELLOW9648 9D 120/48THICKNESS 9 MICROMETERS-PASSIVATION OR CONVERSION COATING-BRIGHT YELLOW.00035"YELLOW12048 12D 144/48THICKNESS 12 MICROMETERS-PASSIVATION OR CONVERSION COATING-BRIGHT YELLOW.0005"YELLOW14448 6D 120/72THICKNESS 6 MICROMETERS-PASSIVATION OR CONVERSION COATING-YELLOW.0002"YELLOW12072 9D 144/72THICKNESS 9 MICROMETERS-PASSIVATION OR CONVERSION COATING-YELLOW.00035"YELLOW14472 10D 192/96THICKNESS 10 MICROMETERS-PASSIVATION OR CONVERSION COATING.0004"NA19296 12D 168/72THICKNESS 12 MICROMETERS-PASSIVATION OR CONVERSION COATING-BROWN.0005"BROWN16872 6D 144/96THICKNESS 6 MICROMETERS-PASSIVATION OR CONVERSION COATING-OLIVE DRAB.0002"OLIVE14496 9D 168/96THICKNESS 9 MICROMETERS-PASSIVATION OR CONVERSION COATING-OLIVE DRAB.00035"OLIVE16896 12D 192/96THICKNESS 12 MICROMETERS-PASSIVATION OR CONVERSION COATING-OLIVE DRAB.0005"OLIVE19296 15D 240/0THICKNESS 15 MICROMETERS-PASSIVATION OR CONVERSION COATING-YELLOW-BROWN OR OLIVE DRAB.006"YELLOW240N/A 6E 240/72THICKNESS 6 MICROMETERS-ZINC PHOSPHATE/ELECTROCOAT/OIL-BLACK.0002"BLACK24072 9E 336/72THICKNESS 9 MICROMETERS-ZINC PHOSPHATE/ELECTROCOAT/OIL-BLACK.00035"BLACK33672 12E 480/72THICKNESS 12 MICROMETERS-ZINC PHOSPHATE/ELECTROCOAT/OIL-BLACK.0005"BLACK48072 9B 0/72THICKNESS 9 MICROMETERS-DECORATIVE BLACK.00035"BLACK N/A72 15B 0/144THICKNESS 15 MICROMETERS-DECORATIVE BLACK.006"BLACK N/A144AN ISO9002 / QS9000 REGISTERED COMPANYSPECIFICATION LISTINGTHE FOLLOWING IS A PARTIAL LISTING OF THE SPECIFICATIONS THAT MARSH PLATING CORPORATION AND/OR FINISHING SERVICES INC. ARE CAPABLE OF PROCESSING TO. IF YOU REQUIREA FINISH THAT IS NOT LISTED, PLEASE CONTACT THE ESTIMATING DEPARTMENT AT MARSH PLATING ((734) 483-5767) FOR MORE UP TO DATE INFORMATION ON OUR CAPABILITIES.SALT SPRAY ORGANIZATION SPEC.DESCRIPTION THICK.COLOR WHITE RED GM GM4345M CORROSION PROTECTIVE COATINGS, ZINC PLATING3U 24/0THICKNESS 3 MICROMETERS.0001"N/A24N/A 6U 48/0THICKNESS 6 MICROMETERS.0002"N/A48N/A 9U 72/0THICKNESS 9 MICROMETERS.00035"N/A72N/A 12U 96/0THICKNESS 12 MICROMETERS.00050"N/A96N/A 15U 120/0THICKNESS 15 MICROMETERS.006"N/A120N/A 3K 32/8THICKNESS 3 MICROMETERS-PASSIVATION OR CONVERSION COATING-BRIGHT.0001"CLEAR328 6K 56/8THICKNESS 6 MICROMETERS-PASSIVATION OR CONVERSION COATING-BRIGHT.0002"CLEAR568 9K 96/0THICKNESS 9 MICROMETERS-PASSIVATION OR CONVERSION COATING-CLEAR OR LIGHT IRID. BLUE.00035"CLEAR96N/A 12K 120/0THICKNESS 12 MICROMETERS-PASSIVATION OR CONVERSION COATING-CLEAR OR LIGHT IRID. BLUE.00050"CLEAR120N/A 15K 144/0THICKNESS 15 MICROMETERS-PASSIVATION OR CONVERSION COATING-CLEAR OR LIGHT IRID. BLUE.006"CLEAR144N/A 3D 72/48THICKNESS 3 MICROMETERS-PASSIVATION OR CONVERSION COATING-BRIGHT YELLOW.0001"YELLOW7248 6D 96/48THICKNESS 6 MICROMETERS-PASSIVATION OR CONVERSION COATING-BRIGHT YELLOW.0002"YELLOW9648 9D 120/48THICKNESS 9 MICROMETERS-PASSIVATION OR CONVERSION COATING-BRIGHT YELLOW.00035"YELLOW12048 12D 144/48THICKNESS 12 MICROMETERS-PASSIVATION OR CONVERSION COATING-BRIGHT YELLOW.00050"YELLOW14448 6D 120/72THICKNESS 6 MICROMETERS-PASSIVATION OR CONVERSION COATING-YELLOW.0002"YELLOW12072 9D 144/72THICKNESS 9 MICROMETERS-PASSIVATION OR CONVERSION COATING-YELLOW.00035"YELLOW14472 10D 192/96THICKNESS 10 MICROMETERS-PASSIVATION OR CONVERSION COATING.0004"NA19296 12D 168/72THICKNESS 12 MICROMETERS-PASSIVATION OR CONVERSION COATING-BROWN.00050"BROWN16872 6D 144/96THICKNESS 6 MICROMETERS-PASSIVATION OR CONVERSION COATING-OLIVE DRAB.0002"OLIVE14496 9D 168/96THICKNESS 9 MICROMETERS-PASSIVATION OR CONVERSION COATING-OLIVE DRAB.00035"OLIVE16896 12D 192/96THICKNESS 12 MICROMETERS-PASSIVATION OR CONVERSION COATING-OLIVE DRAB.00050"OLIVE19296 15D 240/0THICKNESS 15 MICROMETERS-PASSIVATION OR CONVERSION COATING-YELLOW-BROWN OR OLIVE DRAB.00060"YELLOW240N/A 6E 240/72THICKNESS 6 MICROMETERS-ZINC PHOSPHATE/ELECTROCOAT/OIL-BLACK.0002"BLACK24072 9E 336/72THICKNESS 9 MICROMETERS-ZINC PHOSPHATE/ELECTROCOAT/OIL-BLACK.00035"BLACK33672 12E 480/72THICKNESS 12 MICROMETERS-ZINC PHOSPHATE/ELECTROCOAT/OIL-BLACK.00050"BLACK48072 9B 0/72THICKNESS 9 MICROMETERS-DECORATIVE BLACK.00035"BLACK N/A72 15B 0/144THICKNESS 15 MICROMETERS-DECORATIVE BLACK.00060"BLACK N/A144GM GM4435M PROTECTIVE FINISHES, PHOSPHATE TYPECODE A ZINC PHOSPHATE PLUS PROTECTIVE OIL72 CODE B ZINC PHOSPHATE PLUS PROTECTIVE PAINT72 CODE D ZINC PHOSPHATE NA CODE E ZINC PHOSPHATE PLUS PROTECTIVE WATER BASE WAX24 CODE G ZINC PHOSPHATE PLUS APPROVED ORGANIC SEALER72GM GM4465P HUMIDITY TESTGM GMW4700CORROSION PROTECTIVE COATINGS-ZINC ALLOY PLATINGS.00032"ZN-CO ZINC COBALT400 ZN-FE ZINC IRON480 ZN-NI ZINC NICKEL480AN ISO9002 / QS9000 REGISTERED COMPANYSPECIFICATION LISTINGTHE FOLLOWING IS A PARTIAL LISTING OF THE SPECIFICATIONS THAT MARSH PLATING CORPORATION AND/OR FINISHING SERVICES INC. ARE CAPABLE OF PROCESSING TO. IF YOU REQUIREA FINISH THAT IS NOT LISTED, PLEASE CONTACT THE ESTIMATING DEPARTMENT AT MARSH PLATING ((734) 483-5767) FOR MORE UP TO DATE INFORMATION ON OUR CAPABILITIES.SALT SPRAY ORGANIZATION SPEC.DESCRIPTION THICK.COLOR WHITE RED ZN-CO-FE ZINC COBALT IRON480 GM GM6035M PROTECTIVE FINISHES, PHOSPHATE TYPEHEAVY ZINC PHOSPHATE PLUS PROTECTIVE OIL96AN ISO9002 / QS9000 REGISTERED COMPANYSPECIFICATION LISTINGTHE FOLLOWING IS A PARTIAL LISTING OF THE SPECIFICATIONS THAT MARSH PLATING CORPORATION AND/OR FINISHING SERVICES INC. ARE CAPABLE OF PROCESSING TO. IF YOU REQUIREA FINISH THAT IS NOT LISTED, PLEASE CONTACT THE ESTIMATING DEPARTMENT AT MARSH PLATING ((734) 483-5767) FOR MORE UP TO DATE INFORMATION ON OUR CAPABILITIES.SALT SPRAY ORGANIZATION SPEC.DESCRIPTION THICK.COLOR WHITE RED GM GM6138M PLATING-MULTILAYER ELECTROPLATED/BLACK TYPENI-ALLOY LAYER (NOTE1) THICKNESS 5 MICRONS MIN.0002"ZN N1 ALLOY (NOTE 2) THICKNESS 12.5 MICRONS MIN.0005"BLACK ORGANIC THICKNESS 25 MICRONS MAX.0001"GM GM6280M CORROSION PROTECTIVE COATINGS, ZINC ALLOY PLATINGZN/CO ZINC COBALT PLUS YELLOW CHROMATE YELLOW240 ZN/CO ZINC COBALT PLUS BLACK CHROMATE BLACK240 ZN/NI ZINC NICKEL PLUS YELLOW CHROMATE YELLOW500 ZN/NI ZINC NICKEL PLUS CLEAR CHROMATE CLEAR240 ZN/FE ZINC IRON PLUS BLACK CHROMATE BLACK288 SN/ZN TIN ZINC PLUS YELLOW CHROMATE YELLOW96。
