国华徐州发电有限公司2×1000MW超临界火电机组工程专用HXJX-2800-JSXZ 型胶球清洗装置运行维护手册无锡市鸿翔电力辅机有限公司二0一0年十一月目录一、胶球清洗和胶球清洗工作原理二、胶球清洗系统各设备的作用三、控制系统四、安装五、胶球装置操作运行六、提高收球率的注意事项一、胶球清洗系统和胶球清洗工作原理：1、胶球清洗系统：是由胶球泵、装球室、收球网、阀门及相应的管道所组成，在凝汽器左右两侧各配置1套单独的胶球清洗系统与之配套，以确保胶球清洗系统定期清洗，使凝汽器铜管内壁的泥垢和浮生物去除，长期保持清洁从而达到提高冷却管传热系数的目的。
见图：凝汽器胶球清洗系统图2、胶球清洗工作原理：先将比重与水相近（0.98-1.02）的胶球加进装球室后，启动胶球泵，胶球在比循环水压力略高一点的水流带动下进入凝汽器水室进口，随即同循环水混合并流向水室而进入铜管，由于胶球输送管出口朝下，故球分散均匀进入凝汽器铜管。
胶球虽比铜管内径大1-2mm，然而它是多孔、柔软的弹性体，故仍可在较小的压差作用下，形变而进入凝汽器铜管，在铜管中的胶球形状成卵形，并与铜管内壁有一整圆接触，这样胶球在进行过程中等于把铜管内壁擦抹一遍，当胶球流入凝汽器出水管口时，它在本身弹力的作用下，突然恢复原状，这就消除了胶球表面的污垢（若胶球表面还有些污泥将在运动中消除）并随水流向出水管，而至收球网，在网壁的拦阻及出水的冲动下，球进入网底，由于胶球泵进水管接在此处，故胶球在进口负压的作用下吸入胶球泵，再重新进入装球室重复以上运动。
随机组的大小，胶球管道的长短及循环水流速，胶球在系统中循环一周的时间约在10-30秒。
二、胶球清洗系统各设备的作用：1、胶球清洗泵由于胶球本身无能量，若要使它能从出水管里的收球网中重新进入凝汽器的进水管，没有动力是不可能的，要获得比循环水进口压力略小的压力，必须配有胶球输送装置—胶球泵。
胶球清洗泵的选型随机组容量和胶球系统要求决定。
凝汽器胶球清洗系统Condenser Gum Ball Cleaning System 安装维护使用说明书Installation and MaintenanceManual青岛市胶州发电设备有限公司Qingdao Jiaozhou Power Equipment Co., LTD.电话：0086 532 87286338 /87286299Tel: 0086 532 87286338 /87286299传真: 0086 532 87286078Fax: 0086 532 87286078地址：山东省胶州市郭家庄西工业园Address：Shandong Jiaozhou Guojiazhuang West Industrial Park目录CONTENT第一章胶球清洗系统布置和安装ChapterⅠLayout and Installation of Gum Ball Cleaning System 第二章设备安装Chapter II Equipment Installation第三章胶球清洗系统运行Chapter III Running of Gum Ball Cleaning System第四章停用保养Chapter IV Disable Maintenance第五章管理Chapter V Management第六章检修、检查、维护Chapter VI Overhaul, Inspection and Maintenance第七章故障及处理Chapter VII Failure and Solution第一章胶球清洗系统布置和安装ChapterⅠLayout and Installation of Gum Ball Cleaning System一、胶球清洗系统布置方式有两种Ⅰ. There are two layout ways of gum ball cleaning system１、单元制系统Modular system１、排污口２、清洗蝶阀３、二次滤网４、装球室５、球阀６、胶球泵７、收球网８、收球网板操作机构．1. Outfall 2, Cleaning valve 3, Secondary screen 4, Ball room 5, Ball valve 6, Gum ball pump 7, Ball screen 8, Ball net plate operating mechanism.2. Sharing system２、共用制系统Common control system１、排污口２、清洗蝶阀３、二次滤网４、电动机５、收球网６、装球室７、球阀８、胶球泵９、分汇器．1. Outfall 2, Cleaning valve 3, Secondary screen 4, Motor 5, Ball screen 6, Ball room 7, Ball value 8,Gum ball pump 9, Sub-exchange device.胶球清洗系统安装应遵照供货单位提供的系统布置图和技术要求进行安装，不可随意增减系统中的相对位置．The installation of gum ball cleaning system shall be subject to system layout diagram and technical requirements provided by supply unit, prohibit increase or decrease the relative position of the system arbitrarily.二、不同布置方式的适用范围：II. The scope of application of different layout:a、单元制系统，适合于为100MW以上容量的机组配套使用．优点是对凝汽器各侧可同时进行清洗；另外，任何一侧的胶球清洗系统出现故障，均不会影响另一侧的正常运行．b、共用制系统，适合于小机组使用．优点是设备少，主要缺点是当系统中共用部分发生故障时，凝汽器的任何一侧都无法清洗．a. Modular system is suitable with the units of over 100MW. Advantage is that each side of condenser can be cleaned at the same time; Moreover, any side of the gum ball cleaning system broke down, which will not affect the normal operation of the other side.b. Sharing system is suitable for use in small units. Advantage is less equipment, and the main drawback is that when the common parts of the system broke down, any side of the condenser can not be cleaned.第二章设备安装Chapter II Equipment Installation收球网：Ball screen:收球网尽量采用立式安装，并且收球网胶球引出管尽量高于胶球泵入口．收球网在循环水管弯头后很近处安装时，应使操作轴与弯头方向相平行；对ＳＤ型收球网最好采用操作轴与弯头方向相垂直的布置方式，且在收球位置时，网板进口端靠在内侧筒壁．收球网若采用卧式布置时，胶球引出管应按要求在收球网底面或侧面．Ball screen adopts vertical installation as far as possible, and ball screen gum ball extraction tube shall be higher than gum ball pump.When installing the ball screen closed to circulating water pipe elbow, they should make the operation shaft run parallel to the direction of elbow; about SD-type ball screen, preferable to use the layout of operation axis perpendicular to the direction elbow, and in the position received the ball, head of the halftone leaning against the inner tube wall. If the ball screen adopts horizontal layout, the gum ball extraction tube should bet at the bottom or the side of the ball screen as required.胶球泵：Gum ball pump:胶球泵安装的相对位置不宜过高，以防气蚀．胶球泵的吸上真空高度一般为7m水柱．The relative position of gum ball pump should be not too high to prevent gas etching. The vacuum suction height of gum ball pump is generally the water column of 7m.装球室：Ball room:用于贮存、更换胶球及观察胶球运动，故安装位置应便于操作人员接近，放气、放水管接至排水地沟．For use of storage, replace of gum ball and the observation of gum ball’s movement, so the installation location should be accessible to the operator, exhaust tube and offlet connected to the drainage trench.胶球管路及阀门：Gum ball piping and valves:胶球管路应短直流畅，球阀或蝶阀安装位置应便于操作，装球室进口阀在装球室的进口处安装，管系严密不漏．Gum ball piping should be short, straight and smooth. The installation location of ball valve or butterfly valve should be easy to operate. Suction valve shall be installed on the entrance of ball valve. Piping shall be tight and no leaking.循环水系统中安装有二次滤网时，一般情况下，二次滤网出口至凝汽器间，循环水的长度有限，但布置投球管时，应遵照以下原则，且不可在凝汽器水室中布置．When installing the secondary screen in circulating water system, generally, the circulating water is limited in length from the outlet of the secondary screen to the condenser, but arranging pitch pipes shall be subject to the following principles, and can not do in water room of the condenser.循环水管通径DN<1200时，投球管（伸入循环水管中的胶球管路）用一根，并伸至循环水管中心，DN≥1200mm时，用两根并在循环水管同一正截面内对称布置，两管口中心在循环管同一直径上，管口间距离等于循环水管半径，投球管出口逆循环水流方向．When the circulating water pipe diameter DN <1200, the pitch pipe (the gum ball piping stretching into the circulating water pipe) adopts one, and extended to the center of circulating water pipe. When DN ≥ 1200mm, use two to parallel in the same section of the circulating water pipe with symmetrical arrangement, centers of the two nozzles in the same diameter of the loop pipe, the distance between the nozzle is equal to the radius of the circulating water pipe, and the outlet of the pitch pipe opposes circulating flow direction.控制装置：Control device:控制柜或程控柜，应在通风、干燥、且靠近装球室处安装．Control cabinets or program-controlled cabinets should be installed in ventilated, dry, and close to the ball room.二次滤网：Secondary screen:配装有二次滤网的胶球清洗系统中，二次滤网的安装部位，一般情况下应离开凝汽器进口一段距离，这样对于投球管的布置有利．以海水为冷却水源的电厂，二次滤网宜靠近凝汽器进口布置，以便减少二次滤网后循环水管中海生物的数量，从而减少冷却管、收球网被堵塞的机会．二次滤网的排污管路应短直流畅，尽量减少管路水阻，因为二次滤网排污是依靠循环水压差来实现的，故排污水阻大时会直接影响排污效果．In the gum ball cleaning system with the secondary screen, the installation position of the secondary screen should keep a distance from the entrance of the condenser, so that it’s favorable for the arrangement of pitch pipe. Regard the seawater as the cooling water plant, the secondary screen should be close to the entrance of the condenser in order to reduce the number of sea creatures in the circulating water pipe after the secondary screen, thereby reducing the opportunities of the blocked cooling pipe and ball screen. The blow-off line of the secondary screen should be short, straight and smooth, minimize the water resistance of piping, as the secondary screen scavenging relies on recycled water pressure to achieve, the large sewage water resistance will affect effects of sewage directly.胶球清洗系统的安装，应按照制造厂提供的系统布置图和技术要求进行，不可随意增减系统中配套件的数量和改变设备配套件的数量和改变设备配套件在原系统中相对位置．The installation of gum ball cleaning system should be in accordance with layout diagram and technical requirements provided by factory, prohibit increase or decrease the number of component parts and the relative position of the system arbitrarily.第三章胶球清洗系统运行Chapter III Running of Gum Ball Cleaning System运行必备条件：Running prerequisites:１、凝汽器：Condenser:a、水室中的涡流区、水室中隔板窜通缝隙及窄缝（由于水室四壁、水室隔板与端盖同密封垫尺寸不合适所致，将会引起积球）应于消除；水室中除循环水管外其余通往外部的管道，应在管口加装孔径小于Φ7mm的球面网罩；水室中垢片、锈片及杂物通水前清理干净．The water in the room, water vortex zone partition channeling through cracks and narrow gap (due to water chamber walls, and cover with gasket partition size doesn't fit, will cause the ball) should eliminate product;Water in the room except the circulating water pipes to the rest of the pipeline, should be in the outer tube diameter less t han Φ 7mm installs the spherical nets mask; clean the dirty things ,rust and sundries in the room, before working with the water.b、冷却管每种规格的管径均匀一致，管内无阻碍胶球通过的杂物；胶球清洗系统初始投运时，冷却管内壁应洁净无垢，已结硬垢的应采取措施彻底除垢；管板若涂刷环氧树脂等涂料，应严防因此缩小冷却管口通径；胀管时，管口伸出管板长度不宜超过2.5mm.Cooling tube diameter of each specification uniform, tube unimpeded by sundry ball;when the Rubber ball cleaning systems works first, cooling tube initial operation wall should be clean, has hardened scale measures should be taken to complete removal;If a tube plate coating epoxy coating should be protected, thus narrowing cooling pipe size;When the pipe expanding, tube sheet length is out over 2.5 mm.２.循环水及循环水管：Water and circulating water pipes:a、循环水量宜保持在设计值的±15%范围内．亦可根据以后的清洗效果适当改变对循环水量的控制范围．In the design of water cycle in the range of ± 15% value. Also we can change the control of the water cycle according to the appropriate after cleaning effect.b、一次滤网（包括拦污栅、扒草机等）完好．工作正常，能保持无大于收球网栅格间距的杂物通过，否则必须配装二次滤网．Once filter screen(including Trash rack, grilled grass machine etc)is complete Ok, in proper working order, It can keep the charge of the no more grid spacing sundry through, otherwise we must Equipped with secondary filter.c、循环水需充满凝汽器水室，若充不满则必须采用比重大于循环水的湿态胶球（胶球吸足水后的状态）．Circulating water should be full of the room of the condenser, if it can’t be full of ,we must use proportion than circulating wet glue ball (rubber ball absorb enough water after the state).d、循环水管中的垢片、锈片和杂物通水前清理干净．Clean the dirty things ,rust and sundries in the cycle water pipe before working with the water. ３、胶球：Rubber ball:耐磨、质地柔软、富于弹性、气孔均匀贯通、硬度适中、湿态比重1.00-1.15、在5-45℃水温下及使用期内环境胀大不超标、不老化．Hard wearing, soft,elastic,porosity evenly, hardness moderate, Wet proportion in the 5-115, 100-45 degrees Celsius temperature and use period swell not overweight, environment of aging.４、设备：Equipment:胶球清洗装置及配套件，安装符合要求，具备正常使用条件．Rubber ball cleaning equipment and accessories, installation requirements, with normal conditions of use.５、运行注意事项：Running note:胶球清洗系统安装后，应及时进行调试；调试合格后，按规程要求经常操作运行．After install the rubber ball cleaning system, it should be debugged on time; after debugging it successfully, make it work according to the directive rules.６、胶球规格：Rubber ball specifications:开始使用的胶球湿态直径比冷却管中较小一种规格的内径大1.0-2.0mm,使用中球径磨损到等于或小于上述冷却管内径时及时更换；采用金刚砂球清除冷却管硬垢时，其湿态球径比上述冷却管内径小1.0-2.0mm，待硬垢基本除净后应停用．球径及硬度还与循环水量有关．Start using the wet cooling tube diameter bigger than cooling tube small a specification as 1.0-2.0 mm diameter, during the working, when it wears to equal to or less than the cooling tube diameter, it should be changed; when use emery ball to get rid of the hard scale of the cooling tube,the wet ball diameter less than the cooling tube diameter of 1.0-2.0 mm, after finishing get rid of it, it should be stopped to be used. The sphere diameter and the hardness are also relevant with the water cycle.７、正常投球量：The normal work:投入运行的胶球数量为凝汽器单侧单流程冷却管根数的7%-13%,取下限或靠近下限的数量，胶球循环一次不超过30秒．The rubber ball into operation for single flow condenser cooling tube unilateral number of 7-13% lower limit, or close to the quantity, rubber ball cycle time does not exceed 30 seconds.８、清洗周期和清洗时间：The cleaning cycle and cleaning time:胶球清洗系统每天运行（清洗）一次，每次30分．用户也可根据以后的清洗效果适当改变上述数值．Rubber ball cleaning system operation (cleaning) once every day, each time 30 minutes. The user may change the value according to the cleaning effect.９、胶球补充周期和更换周期：Rubber ball added cycle and change cycle:胶球清洗系统累计运行七次，补充胶球；累计运行60次，进行更换．用户还可根据各自具体情况如投球数量、实际收球率（满足投运条件、系统正常运行30分、收回的胶球数与投入运行的胶球数的百分比）,所用胶球的耐磨性能等，适当调整上述周期．个别胶球可能在水中浸泡一段时间后，胀大过多，球径超标，在检查补充和更换胶球时，均需随时换掉．After the rubber cleaning system runs for seven times, replenish the rubber ball; after it runs 60 times, change it. The user also can according to the specific passion of their own to move the times above, such as pitching quantity、actual charge ball rate（Meet operation conditions、Normal operation system 30 points、The percent of the rubber ball back and operation of the rubber ball）、the Wear-resisting performance of the rubber ball, etc. Several rubber balls maybe swollen a lot after soaking in the water for a period of time, the ball diameter out of limits. When we check or mend or change the rubber balls, they should be changed.安装有循环水二次过滤系统.两个系统不得同时运行；必须在循环水二次过滤系统运行结束之后，胶球清洗系统才允许投入运行．Install a water second filtration system. The two system can’t be run at the same time; it must be u sed after the water second filtration system finish it’s running.二次滤网的网芯网孔为7mm,所有大于7mm的污物杂质，保证不会进入凝汽器水室内，从二次滤网排污管道内排出.The nets core and the net hole of the secondary filter are 7mm,all the dirt impurities are bigger than 7mm, can’t be entered to the cond enser room, they will row out of the sewage pipe of the secondary filter.二次滤网排污是通过网芯前后压差值由差压变送器来实现自动排污，差压变送器动作值设置在P(二次滤网开始运行时测得压力值+0.2MPa)，当网芯前后压差值≥P时，差压变送器开始传送排污信号，来实现排污。
