高压隔离探头使用手册

ZP1500D 用户手册高压差分探头修订历史目录1.安全须知 (1)1.1一般性安全概要 (1)1.2警示标志 (1)1.2.1面板图标意义 (1)1.2.2测量类别介绍 (2)1.3测量类别 (3)1.4保养与清洁 (4)2.产品简介 (5)2.1产品应用 (5)2.2产品特色 (5)3.技术参数 (6)3.1技术指标 (6)3.2普通技术规格 (7)3.3配件 (8)4.快速入门 (9)4.1操作基础 (9)4.1.1面板说明 (9)4.1.2功能检测 (10)4.1.3操作步骤 (10)4.1.4注意事项 (11)5.常见问题 (14)5.1具体问题阐述 (14)5.1.1上电后面板指示灯全灭 (14)5.1.2调零输出值偏大或调零时间较长 (14)5.1.3测量波形不能稳定显示或误差明显 (14)6.性能验证 (15)6.1直流精度 (15)6.2方波响应 (15)6.3直流共模抑制比 (16)7.装箱单 (17)8.免责声明 (18)1.安全须知为保证您能正确安全地使用本仪器，请务必遵守以下注意事项。

如果未遵守本手册指定的方法操作本仪器，可能会损坏本仪器的保护功能。

因违反以下注意事项操作仪器所引起的损伤，广州致远电子有限公司不予以承担责任。

1.1 一般性安全概要了解下列安全性预防措施，以避免受伤，防止损坏本产品或本产品连接的任何产品。

使用推荐的电源适配器电源适配器为5V/2A USB输出，符合CB认证要求。

使用正常接地的示波器不建议探头信号输出端浮地，请将探头输出线缆连接到正常接地的示波器设备上。

查看所有终端额定值为避免起火和过大电流的冲击，请查看产品所有的额定值和标记。

产品使用前，请仔细阅读用户手册以了解额定值的详细信息。

请勿开盖操作请勿在仪器外壳打开时运行本产品。

避免电路外露电源接通后，请勿接触外露的接头和元件。

防止触电危险适配器必须插在墙壁上或在可视范围内的具有保护地的插排上，不可插在引线混乱的插排上，插排不可过流使用。

P5122100X ProbeThe P5122Probe is a high voltage probe with 100X attenuation and a compensation range of 10to 25pF.The probe is designed for use with Tektronix TPS2000and THS3000series floating oscilloscopes with high input impedance (1M Ω).The probe has no user-or Tektronix-serviceableparts.WARNING.The reference contact ring (see below)is always the same voltage as the reference lead.To avoid arc flash,always ensure the insulation sleeve or hook tip is installed to cover the reference contactring.Connecting the Probe to the OscilloscopeConnect the probe as shown in the illustrationsbelow.Compensating the ProbeDue to variations in oscilloscope input characteristics,the low-frequency compensation of the probe may need adjustment after moving the probe from one oscilloscope channel to another.If a 1kHz calibrated square wave displayed at 1ms/division shows signi ficant differences between the leading and trailing edges,perform the following steps to optimize low-frequency compensation:1.Connect the probe to the oscilloscope channel that you plan to use for your measurements.2.Connect the probe to the probe compensation output terminals on the oscilloscope frontpanel.WARNING.To avoid electric shock,only connect to the Probe Comp signal on the oscilloscope when making this adjustment.3.Depress the locking pin inside the protective sleeve.4.Turn the sleeve and the cable end until the adjustment is visible through theopening.5.Push AUTOSET or otherwise adjust your oscilloscope to display a stable waveform.6.Adjust the trimmer in the probe until you see a perfectly flat-top square wave on the display.(Seeillustration.)WARNING.To avoid electric shock,only use the insulated adjustment tool when making compensation adjustments.7.Turn the sleeve back and lock the sleeve inplace.WARNING.To avoid electric shock,ensure that the sleeve is locked in the closed position after making compensation adjustments.Connecting the Probe to the CircuitUse the standard accessories included with the probe to connect to your circuit.(See Table1.)WARNING.To avoid electric shock when using the probe or accessories,keep fingers behind the finger guard of probe body &accessories (as shown).To reduce risk of shock,when using the probe on floating measurements,ensure the reference lead accessories are fully mated before connecting the probe to the circuit under test.Standard AccessoriesThe standard accessories included with the probe can be reordered as a kit.The kit includes one of each item shown below.Order Tektronix part number 020-3046-00.Table 1:Probe accessories kitItemDescription Hook tip 1.Press onto probe tip2.Squeeze the hook tip to extend the conductive hook3.Clamp hook ontoconductor Reference lead,with hook clip 1.Secure lead to probe head ground pin2.Connect hook clip to circuitreferenceReference lead,withmini-alligator clip 1.Secure lead to probe head ground pin2.Squeeze clip and connect to circuitreference CAUTION.This accessory is rated 30VAC maximum.Do not use for MAINS connection.Ground spring for probe tip 1.Press onto probe tip2.Probe circuits with nearby reference testpointsAdjustment tool Use only this insulated tool for compensation adjustmentsP5122200MHz 100X High Voltage Probe Instructions*P071272003*071-2720-03Speci ficationsRead the caution below if you are using the probe with the TPS2000series oscilloscope input set to ACcoupling.CAUTION.When the oscilloscope input is set to AC Coupling,do not probe DC levels >300V or AC signals less than 1Hz and >300V RMS .(See graphbelow.)Refer to the reference lead derating curve below when making floatingmeasurements.Table 2:Electrical and mechanical speci ficationsCharacteristic Speci fication BandwidthDC to 200MHz (–3dB)System attenuation accuracy 100:1Compensation range 10pF–25pF System input resistance 100M ΩSystem input capacitance 4.6pF Maximum tip input voltage1000V CAT IICharacteristic Speci fication Maximum reference lead voltage to ground 600V CAT II Cable length1.2mTable 3:Environmental speci ficationsCharacteristics Description TemperatureMaximum operating Minimum operating Nonoperating +40°C (+104°F)+5°C (+40°F)–55°C to +75°C (–67°F to +167°F)Humidity 80%up to +30°C (+86°F),falling linearly to 50%at +40°C (+104°F)AltitudeOperating Nonoperating2.0km (6,600ft)maximum 15km (50,000ft)maximumTable 4:Certi fications and compliancesCharacteristics Description ECDeclaration ofConformity Compliance was demonstrated to the following speci fication as listed in the Of ficial Journal of the European Communities:Low Voltage Directive 2006/95/EC:EN61010-031:2002Category Examples of Products in this CategoryCAT III Distribution-level mains,fixed installationCAT IILocal-level mains,appliances,portable equipmentMeasurement Category DescriptionsCAT ICircuits not directly connected to mains.Pollution Degree 2Do not operate in environments where cond–uctive pollutants may be present (as de fined in IEC 61010-1).Rated for indoor use only.Additional Safety StandardsUL61010B-1,First Edition &UL61010B-2-031,First Edition.CAN/CSA-C22.2No.1010.1-92,&CAN/CSA-C22.2No.1010.2.031-94IEC61010-031:2002Equipment Recycling.This product complies with the European Union’s requirements according to Directive 2002/96/EC on waste electrical and electronic equipment (WEEE).For more information about recycling options,check the Support/Service section of the Tektronix Web site ().Safety SummaryReview the following safety precautions to avoid injury and prevent damage to this product or any products connected to it.To avoid potential hazards,use this product only as speci fiing the probe or accessories in a manner not speci fied could result in a shock or fire hazard.To Avoid Fire or Personal InjuryFor Use With TPS2000and THS3000Series Oscilloscopes Only.Do not float the reference lead of this probe above the rated float voltage (600V RMS CAT II).Connect and Disconnect Properly.Connect the probe output to the measurement instrument before connecting the probe to the circuit under test.Disconnect the probe input and the probe reference lead from the circuit under test before disconnecting the probe from the measurement instrument.Avoid Electric Shock.To avoid injury or loss of life,do not connect or disconnect probes or test leads while they are connected to a voltage source.Observe All Terminal Ratings.To avoid fire or shock hazard,observe all ratings and markings on the product.Consult the product manual for further ratings information before making connections to the product.Avoid Electric Shock.When using probe accessories,never exceed the lowest rating of the probe or its accessory,whichever is less,including the measurement category and voltage rating.Avoid Electric Overload.To avoid injury or fire hazard,do not apply potential to any input,including the reference inputs,that varies from ground by more than the maximum rating for that input.Avoid Exposed Circuitry and Do not Operate WithoutCovers.Do not touch exposed connections and components when power is present.Inspect The Probe And Accessories.Before each use,inspect probe and accessories for damage (cuts,tears,defects in the probe body,accessories,cable jacket,etc.).Do not use if damaged.Do Not Operate in Wet/Damp Conditions.Do Not Operate in an Explosive Atmosphere.Keep Product Surfaces Clean and Dry.Safety Terms and Symbols Terms in This Manual.These terms may appear in thismanual:WARNING.Warning statements identify conditions or practices that could result in injury or loss oflife.CAUTION.Caution statements identify conditions or practices that could result in damage to this product or other property.Symbols on the Product.These symbols may appear on theproduct:Contacting TektronixWeb site: Phone:1-800-833-9200Address:Tektronix,Inc.Department or name (if known)14200SW Karl Braun Drive P.O.Box 500Beaverton,OR 97077USAEmail:*************************Warranty InformationFor warranty information,go to/warrantyCopyright ©Tektronix,Inc.All rights 。

Item shipped may vary from model p ictured here.Model 1600A High Voltage ProbeMAXIMUM INPUT: 40kV DC or 28kV AC, 50/60Hz.INPUT RESISTANCE: 1000M W .DIVISION RATIO: 1000:1 (into 10M W ).For use with: DMMsModel 1651 50 Ampere Shunt:E xternal 0.001W ± 1%, 4-terminal shunt; extends current mea s ur i ng capability of Keithley DMMs to 50A.CABLE LENGTH: 1.4m (56 in).For use with: DMMsItem shipped may vary from model p ictured here.Model 1681 Clip-On Test Lead Set: Two 1.2m (48 in) leads terminated with banana plugs and spring action clip-on probes.For use with: DMMsItem shipped may vary from model p ictured here.Model 1751 Safety Test Leads: 91.4cm (36 in) test lead set supplied with each Model 175A and 197A. Finger guards and shroud e d banana plugs help minimize the chance of making contact with live circuitry.For use with: All DMMs, Series 2400 SourceMeter ®SMU InstrumentsModel 1752 Premium Safety Test Lead Kit:Includes two banana leads with safety shrouds on both ends, two fully insulated alligator clips, two fully insulated needle probes, and two spring-action clip-on probes with safety blocks, in a carrying case.For use with: All DMMs, Series 2400SourceMeter SMU InstrumentsA C C E S S O R I E SItem shipped may vary from model p ictured here.Model 1754 Universal Test Lead Kit: 10-piece test lead kit with interchangeable plug-in acces-sories. Kit includes: 1 set of test leads, 91.4cm (36 in), 1 red and black; 2 spade lugs, 2 standard banana plugs, 2 hooks, and 2 min i a t ure alligator clips with boots.For use with: All DMMs, Series 2400SourceMeter SMU InstrumentsModel 2187-4 Low Thermal Test Lead Kit: Includes an input cable with banana termina-tions, banana extensions, sprung-hook clips, alligator clips, needle probes, and spade lugs to connect the Model 2182A to virtually any DUT. The kit is also used to connect the Model 2182A directly to the Model 622X guard to improve response time for pulsed measure-ments or to reduce errors when measuring high impedance devices.For use with: 2182A, 6220, 6221, 6220/2182A,6221/2182AModel 2600-BAN: 1m (3.3 ft) banana test leads/adapter cable for a single Series 2600B SourceMeter channel (two needed for use with Model 2602B and 2612B). Provides safety banana connections to Hi, Sense Hi, Lo, Sense Lo, and guard.For use with: 2601B, 2602B, 2611B, 2612BModel 2260-008: Test lead set with lugs, 10AWG, 122m (48 in), red/blue wire pair with #10 terminal lugs on each end.For use with: Series 2260BModel 2260B-EXTERM: Extended Terminal Test Leads, 0.7m (28 in.), and terminal box to bring outputs to the front of the instrument or another location. Magnetic base attaches to side of the instrument.For use with: Series 2260BModel 3706-BAN: 1.4m (4.6 ft) banana test leads/adapter cable for Model 3706A mainframe with high performance multimeter option. Provides direct connection to high performance multimeter utilizing rear panel backplane con-nector. Safety banana connections to HI, LO, Sense HI, Sense LO, and AMP.For use with: Series 3700A mainframesModel 3706-TLK Test Lead Kit: Includes 3706-BAN banana test leads/adapter cable and plug-in test lead accessories. Test lead accessories include: 4 spring hook probes, 2 needle test probes, 4 safety plug adapters, and carrying case.For use with: Series 3700A mainframesModel 5804 Test Lead Set: Designed to be used with Keithley instruments that measure 4-terminal resistance. Contains: 2 test leads, 0.9m (36 in), red and black; 2 test clips, red and black; 2 plunger clip adapters, red and black; 2 alligator clips with boots (accept standard test probe tip); 2 alligator clips with boots (barrels accept standard banana plugs).For use with: Series 2400 SourceMeter ® SMUInstruments, 2750, DMMsItem shipped may vary from model p ictured here.T e s t l e a d s a n d p r o b e sModel 5805 Kelvin Probes: 2 spring-loaded test probes, red and black, 0.9m (36 in) with banana plug termination. De s igned to be used with Keithley in s tru m ents that measure 4-terminal re s is t ance and in-circuit current. 1⁄8-in spacing between pin tips. A package of 8 re p lace m ent contacts (P/N CS-551) is available.Model 5805-12: Similar to 5805 but 3.6m (12 ft) in length.For use with: Series 2400 SourceMeter SMUInstruments, 2750, DMMsModel 5806 Kelvin Clip Lead Set: 2 clip test leads, red and black, 0.9m (36 in) with banana plug ter m i n a t ion. Designed to be used with Keithley instruments that meas u re 4-terminal re s is t ance. Maximum jaw opening ½ in. A package of 8 r eplace m ent elastic bands (P/N 5806-306B) is a vailable.For use with: Series 2400 SourceMeter SMUInstruments, 2750, DMMsModel 5807-7 Helical Spring Point Test Leads: Two excellent Kelvin test probes for Keithley in s tru m ents that measure 4-terminal re s is t ance. The probes have point e d tips that rotate when pressure is exerted on the handle. Good contact is assured, and the handle can be held at any angle to the mea s ure m ent surface. The lead wires ter m i n ate in banana plugs. Lead wire length: 2m (7 ft).For use with: Series 2400 SourceMeter SMUInstruments, 2750, DMMsModel 5808 Low Cost, Single Pin, Kelvin Probes: Two 1.17m (46 in) long, single fixed pin probes with source and sense leads per probe and color coded standard safety banana plugs. Designed for applications requiring Kelvin resistance measurements with the convenience of a single point of circuit contact. The Kelvin connection at the base of each probe pin results in very low resistance errors, eliminating all wire and probe body resistance. For the highest pre-cision sensing applications, use the Model 5805, 5806, or 5809 for complete control over sensing point placement.For use with: 2700, 2701, 2750, Series 2400,DMMsModel 5809 Low Cost, Kelvin Clip Lead Set: Two 0.94m (37 in) long probes with alligator style clips, each with opposing blade source and sense connections to color coded standard safety banana plugs. Designed for applications requiring Kelvin connection to wires, axial lead-ed components, and other terminals able to be clipped onto. The miniature blade design accom-modates narrow available width applications as well as general lighter duty applications. The maximum jaw opening is 9.14mm (0.36 in) and the blade width is 2.92mmm (0.115 in).For use with: 2700, 2701, 2750, Series 2400,DMMsModel 6517-RH Humidity Probe: The 6517-RH comes with a 3m (10 ft) extension cable and is designed to be used with the 6517B Electrom-eter. The 6517-RH measures the relative humidity of the testing environment.OPERATING TEMPERATURE RANGE: –10°C to +60°C OPERATING HUMIDITY RANGE: 0 to 100% RH MEASURING RANGE: 10 to 90% RHTEMPERATURE DEPENDENCE: <±2% from –10°C to +60°CFor use with: 6517A and 6517B ElectrometersA C C E S S O R I E SModel 6517-TP Thermocouple Bead Probe: Designed to be used with the 6517B Electro m -eter, the 6517-TP measures the temperature of the testing en v i r on m ent. 6517-TP is 36 in. long and has a temperature calibration (range) of 0°C to 1250°C. Type K thermocouple.For use with: 6517A and 6517B Electrometersand 2110 DMMModel 7401: Type K ther m o c ou p le wire kit includes 30.5m (100 ft) of type K (chromel-alu-mel) ther m o c ou p le wire.For use with: 2001-TCSCAN, 2110, 3720, 3721,3724, 7057A, 7700, 7706, 7708Model 8605 High Per f or m ance Modular Test Leads: Highest quality lead with sili c one insula-tion, and removable test probes. Rated to 1500V. UL listed.LENGTH: 1m (3.3 ft).For use with: All DMMs, Series 2400 SourceMeter ® SMU InstrumentsItem shipped may vary from model p ictured here.Model 8606 High Per f or m ance Modular Probe Kit: For use with Model 8605 High Per-for m ance Modular Test Leads. Contains 2 each spade lugs, alligator clips, and re t ract a ble hooks.For use with: All DMMs; Series 2400 and Series 2600B SourceMeter SMU Instruments;Series 3700AModel 8608 High Per f or m ance Clip Lead Set: High quality clip lead set with removable test clips. NRTL listed. Rated to 1000V CAT 3 and 20 amps.LENGTH: 1.2m (3.9 ft).For use with: 2450, Series 2400 SourceMeterSMU Instruments, Series 3700A DMMsModel 8681 Low Cost RTD: This inexpensive RTD has small size (0.09 in × 0.09 in) and fast thermal response time. 100W , 0.385%/°C ele-ment. Meets or exceeds DIN 43760-1980-A, IEC 751:1983-A, BS1904: 1984-A, and JIS C1604-1981-0.2. Can be used with Model 8680 RTD Input Probe Adapter. Measures from –200° to +600°C.LENGTH: 0.9m (3 ft).ACCURACY: ±(0.15°C + 0.002 × |t|)/°C, where |t| is absolute value of temperature in °C.For use with: 2001, 2002, 2010 DMMs (with 8680), 7700, 7702, 7706, 7708Item shipped may vary from model p ictured here.Model CA-109A Test Lead Set: For output con-nec t ions (two red, two black).For use with: 2000-SCAN, 2001-SCAN, 2001-TCSCANT e s t l e a d s a n d p r o b e s。
