西门子温控阀说明书自动化

A6V10421629_en--_e 2021-11-292-port zone valves3-port zone valvesACVATIX™2-port and 3-port zone valves, PN16VVI46../2 VXI46../2With on/off characteristics• Hot-pressed brass valve body • DN 15, DN 20 and DN 25 • k vs 2…5 m 3/h• Internally threaded connections Rp to ISO 7-1•Combined with electromotoric actuators, type SUA.., SSA31.04, SFA.. and electrothermal actuators STA..Use• For use in ventilation and air-conditioning systems for water-side terminal unit control in closed circuits, e.g. for induction units, fan-coil units, small reheaters and small re-coolers.- 2-pipe systems with 1 heat exchanger for heating and cooling- 4-pipe systems with 2 separate heat exchangers for heating and cooling • In closed-circuit zone heating systems, for example: - Separate floors in a building - Apartments- Individual rooms2 / 10Type summaryTypeStock numberDNConnections PN classk vsA →AB [m 3/h]VVI46.15/2 S55249-V106 15 Internally threaded Rp162.15VVI46.20/2 S55249-V107 20 3.5 VVI46.25/2 S55249-V108 25 5.0TypeStock numberDNConnections PN classk vs 1) AB →A [m 3/h]k vs 1) AB →B [m 3/h] VXI46.15/2 S55249-V109 15 Internally threaded Rp162.151.5 VXI46.20/2 S55249-V110 20 3.52.5 VXI46.25/2 S55249-V111 25 5.03.5 VXI46.25T/2S55249-V112255.54.51)The k vs values in bypass B of the 3-port valves represent only 70 % of the k vs value in the straight-through control path AB → A. This compensates for the flow resistance of the heat exchanger or radiator, so keeping the overall flow rate100 as constant as possible.k vs = Nominal flow rate of cold water (5…30 °C) through the fully open valve (H 100), by a differentialpressure of 100 kPa (1 bar)OrderingWhen ordering, please specify the quantity, product name and number.The valves and actuators are delivered in separate packaging.The actuator SUA21/3, SSA31.04, SFA.. and STA.. must be ordered separately.The AL50 supporting ring (necessary for combination with SFA.. or SUA..) is included in the delivery of V..I46…See Revision number overview Revision number overview on page 10.ExampleProduct number Stock number Product nameQuantityVXI46.15/2S55249-V1093-port zone valve, PN16 DN15, kvs 2.15 1DeliveryRev. no.3 / 10Equipment combinations∆p max = Maximum permissible differential pressure across the valve’s control path, valid for the entireactuating range of the motorized valve (maximum recommended operating differential pressure) For noiseless operation, the value of 100 kPa should not be exceeded.∆p s = Maximum permissible differential pressure at which the motorized valve will close securelyagainst the pressure (close off pressure)1) ∆pmax(AB-B) is 50 kPa for VXI46.25T/21) SPST = single pole, single throw2)SSA31.04 could not be used with VVI46.25T/24832Z 01Technical design / mechanical design• Disc throttling element• Seat ring embedded in through-port• Seat machined into through-port and bypass• Reservoir for continuous lubrication of sealing rings •Return spring (to open position)Actuator overview4 / 10SizingExample:100 = 0.27 l/s ∆p v 100 = 9 kPak vs value required = 3.5 m 3/h∆p v 100= Differential pressure across the fully open valve and the valve's control path A → AB (2-port valves), AB → A (3-port diverting valves) by a volume flow100100= Volume flow through the fully open valve (H 100)∆p max= Maximum permissible differential pressure across the valve's control path, valid for theentire actuating range of the motorized valve100 kPa =1 bar≈10 mWC 1 m 3/h = 0.278 l/s water at 20 °C5 / 10Engineering notesRefer to Mounting notes and Commissioning notes . It is NOT allowed to put a shut off at the bypass port B.A strainer should be fitted upstream of the valve. This increases reliability.The direction of flow MUST be as indicated by the arrow, from A → AB.The direction of flow MUST be as indicated by the arrow, from AB → A and AB → B (diverting valves).RecommendationWarningWarning6 / 10Mounting notesThe specified direction of flow must be observed in all cases (refer to Engineering notes ).The mounting instructions 74 123 0114 0 B are enclosed with the packaging. The valve and actuator are easily assembled directly on site. There is no need for special tools or calibration.The AL501) supporting ring must be put into position before mounting the actuator SFA.. and SUA.. onto the valve.1) Included in deliveryOrientationAL50 supporting ringSIEMENSkvs5.0XYYMMAA 6V 10421629Z 017 / 10Commissioning notes In the straight-through control path A → AB, respectively AB → A the valve is opened by a return spring.The straight-through path can be closed manually with the manual adjustment button.With 3-port valves, this method can be used to open bypass B to 70 %. (exception: VXI46.25T/2)Maintenance notesV..I46../2 valves require no maintenance.When doing service work on the valve/actuator:• Deactivate the pump and turn off the power supply • Close the shutoff valves• Fully reduce the pressure in the piping system and allow pipes to completelycool downIf necessary, disconnect the electrical wires.Before putting the valve into operation again, make sure the manual knob or the actuator is correctly fitted.The stem sealing gland cannot be exchanged. In the case of leakage, the entire valve must be replaced. Contact your local office or branch.Disposal• Before disposal, the valve must be dismantled and separated into its various constituent materials.• Legislation may demand special handling of certain components, or it may be sensible from an ecological point of view. • Please observe current local legislation.WarrantyThe technical data given for these applications is valid only in conjunction with the Siemens actuators as detailed under Equipment combinations on page 2. Use with third-party actuators invalidates any warranty offered by Siemens Building Technologies HVAC Products.Manual adjustmentCautionStem sealing glandTechnical data8 / 109 / 10Dimensions 2-port valves 3-port valves VVI46../2VXI46../21)For seamless, round copper tubes according to DIN EN 1057Spare partsMultipack of 40 piecesRevision number overviewIssued by:Siemens Switzerland Ltd.Smart InfrastructureGlobal Headquarters Theilerstrasse 1aCH-6300 ZugSwitzerlandTel. +41 58-724 24 24/buildingtechnologies@ Siemens Switzerland Inc, 2014-2021 Delivery and technical specifications subject to change10 / 10。

iF product design award 2012:SAX and SAL产品概览Acvatix 阀门执行器─经济高效的HVAC 系统的决定性组成部件以多年的实践经验、广泛的专业知识和先进的技术为依托，西门子推出了AcvatixTM系列阀门和执行器产品，为暖通水力系统提供理想的解决方案。

这些阀门执行器主要应用于暖通系统中的冷热源、能源分配及末端控制，并可用于区域供热。

因此，Acvatix能够满足HVAC领域以及制冷和工业应用的各种需要。

无论是单户住宅还是公寓，无论是现代办公大楼里复杂的空调还是流量非常大的设备，Acvatix阀门执行器都以高质量和长寿命著称。

他们不仅让您感到舒适、安宁，还可以在能源优化使用、项目改造中助您一臂之力。

适用于各种应用的阀门执行器产品只有机组内每个设备都能可靠、精确的运转时，HVAC 和制冷系统才能正常的工作。

来自西门子的Acvatix 产品线根据您的需要、介质类型和应用类型，总能为您提供合适的阀门执行器：- 用于小型、中型和大型HVAC 和制冷系统的阀门执行器- 用于房间、区域等末端控制的阀门执行器- 两通和三通座阀、蝶阀- 法兰、螺纹和焊接连接- 用于高精度、复杂控制系统的电磁调节阀- 带调节功能和3位或开／关控制信号的执行器地板采暖，辐射采暖TEVA 产品线，见第16页利用散热器控制区域温度TEVA 产品线，见第15和16页生活热水混合系统反应迅速的电磁调节阀， 见第5页法兰和螺纹连接的阀， 见第7-10页生活热水存储罐反应迅速的电磁调节阀，见第5页法兰和螺纹连接的阀， 见第7-10页法兰和螺纹连接的阀， 见第7-10页关闭功能蝶阀，见第13页区域供热分站法兰和螺纹连接的阀， 见第7-10页关闭冷却水塔见第13页控制风机盘管装置TEVA 产品线，见第16页冷吊顶TEVA 产品线，见第16页控制终端装置TEVA 产品线，见第16页用于空气调节设备的制冷盘管反应迅速的电磁调节阀，见第5页法兰和螺纹连接的阀，见第7-12页用于空气调节设备的供暖盘管法兰和螺纹连接的阀，见第7-12页冷冻水环路反应迅速的电磁调节阀，见第5页法兰和螺纹连接的阀，见第7-13页冷却水环路反应迅速的电磁调节阀，见第5页法兰和螺纹的阀，见第7-13页■ 实现能源优化■产品种类多样，适合于各种应用■ 便捷选择阀门执行器■高效配送- 工作电压为AC / DC 24 V 或AC 110 / 230 V 的执行器- 大量专利技术应用于各阀门或执行器，优化系统控制便捷选型西门子为您提供了各种阀门执行器的选型工具，阀门选型尺，技术资料和在线工具。

嵌入式触屏室内温控器适用于加热应用•大显示屏带背光•2P / PI / P 控制• 2 位（开/关）控制，附带无源加热输出• 2 个通用输入端子, 可用于门禁读卡器、开窗监测、外部温度传感器、存在监测等。

•运行模式：舒适模式、节能模式、保护模式•可设定室内温度最低与最高限值•依据室内温度或外部温度传感器进行控制•可调的调试参数和控制参数•工作电压为 AC 230 V•RDD810: 安装在圆形接线盒（最小直径 60 mm）或嵌入式 86mm 方形接线盒（固定孔距 60.3mm、最小深度 40mm）内•RDD810/NF: 安装在嵌入式 86mm 方形接线盒（固定孔距 60.3mm、最小深度 40mm）内，须另行购置安装框A6V141127894_zh--_e用途加热系统中的室温控制：典型应用：•公寓•商业建筑•学校下列设备的控制：•电热阀或区域阀•燃气或燃油锅炉•泵•地板采暖功能•通过内置温度传感器或室外温度传感器控制室温•触屏选择运行模式•舒适模式延时扩展•显示当前室内温度或室内温度设定值（︒C / ︒F）•室内温度的最低与最高设定限值•按键锁定功能：解锁、全部锁定和设定值• 2 个多功能输入端子，可选连接以下设备：−外部温度/回风温度传感器−开窗监测−故障输入−监测温度传感器或开关状态的输入−存在监测•地板采暖的供热温度限值•出厂设置重新加载功能可恢复因调试而更改的控制参数•通过 HMI 的向导功能简化调试配置注意：温控器的功能描述请参见用户手册 P3174。

应用温控器支持加热应用：•热循环地板采暖•散热器•壁挂式锅炉2 / 18室内温控器控制散热器阀门室内温控器控制地板采暖阀门室内温控器直接控制燃气壁挂式锅炉室内温控器直接控制燃气落地式锅炉室内温控器直接控制热泵（手动混合阀预控制）室内温控器直接控制热循环地板采暖系统F1 热复位限温温控器F2 安全限值温控器M1 循环泵N1 室内温控器V1 二通阀V2 通过手动调节混合三通阀V3 电磁阀3 / 182)不包括安装框（ARG800.1），须另行订购，参见“附件”3)无需安装框订购•订购时，请指明产品型号、库存编号及产品名称。

/sipartps100Positioners are essential to the smooth and reliable operation of your process.They play a vital role in ensuring the best possible performance throughout your plant. A great example is our new electropneumatic positioner, the SIPART PS100. Its ease and speed of initialization make it a winner for valve manufacturers, the chemical industry, the energy sector, and many other fields. Special benefits of the SIPART PS100 includerobust construction and ease of operation. »Device automatically adjusts to the connected valveAnimated video on user-friendliness»Maximum performance for every applicationReady for tough process conditions »Completely enclosed design »Two enclosure versions–Aluminum – resistant to mechanical influences –Polycarbonate – with a clear view of the screenNon-corrosive sound absorber»PcAiPublished by Siemens AGDigital Industries Process AutomationÖstliche Rheinbrückenstr. 50 76187 Karlsruhe, GermanyFor the U.S. published by Siemens Industry Inc.100 Technology Drive Alpharetta, GA 30005 United StatesArticle No.: DIPA-B10208-00-7600 Dispo 27900 WS 04210.0 © Siemens 2021Subject to changes and errors. The information provided in this brochure contains descriptions or performance characteristics which, in case of actual use, do not always apply as described or which may change as a result of further development of the products. The desired performance characteristics are only binding if expressly agreed in the contract. Availability and technical specifications are subject to change without notice.All product designations may be trademarks or product names of Siemens AG or supplier companies, the use of which by third parties for their own purposes may violate the rights of the owners.https:///sipartps100https:///mobileiqSITRANS mobile IQ app Smart app that establishes a connection to Bluetooth® enabled SIPART PS100。

KIT INSTALLATION INSTRUCTION SiemensEnergy & AutomationKIT PN - TGX:16152-540 15900-734Rev 1July 2006MOUNTING THE SIPART PS2 VALVE POSITIONER ON ACOPES 60-160, 0.75 STEM, VALVE ACTUATORThis publication provides installation instructions to mount a Siemens SIPART ® PS2 valvepositioner to an above Copes valve actuator and to install the mechanical feedback linkage. Atypical installation is shown below.15900-734PARTS, KIT TGX:16152-540Description QuantityMounting Bracket 1Stem Block 1Spacer 1J-Bracket 15/16-18 x 3/4" Hex Head Screw 25/16-18 x 2.00" Hex Head Screw 25/16" Split Lockwasher65/16" Flat Washer 63/8-16 X 2.75" Socket Head Screw 2M8 x 16 Hex Head DIN933-A2 23/8" Split Lockwasher 2Other Kits: Linear Feedback Kit, part number 6DR4004-8VLINSTALLATIONRefer to the following procedure and to the positioner and actuator installation instructions while performing the installation. The current revision of the positioner instruction is available at theSiemens Internet site. See Contact Information later in this Instruction for the URL.Before beginning the installation, note the following cautions.Do not apply supply pressure to the actuator or the valve positioner during the installation process. Applying supply pressure before the equipment is properly mounted couldcause unexpected movement that could lead to personalinjury or equipment damage.Do not exceed the maximum actuator and valve positionerair pressures stated in the manufacturer’s literature. Exceeding these ratings could cause personal injury or equipment damage.1. From the TGX:16152-540 kit, get the stem block and two 3/8-16 x2.75" socket head screwsand two 3/8 lockwashers. Refer to the figure on page 1 and remove from the stem couplingtwo 3/8" screws in the locations shown for installation of the stem block. Fasten the stemblock to the actuator stem coupling using the 2.75" socket head screws from the kit.2. From the same kit, get the J-bracket and two 5/16-18 x 3/4" hex head screws and 5/16 flatwashers and lockwashers. Fasten the J-bracket to the stem block.3. From the 6DR4004-8VL kit, get two M6 hex head screws and lockwashers, two V-blocks,and the U-channel. Assemble to the J-bracket as shown on page 1.4. From the same kit, get the feedback arm, feedback pin, and a nut and lockwasher to mountthe pin. Fasten the feedback pin to the feedback arm. Tighten the hardware just enough tohold the pin in place.5. Fasten the feedback arm to the PS2 input shaft as shown. Position the pin such that itsdistance from the PS2 shaft is approximately 70%-100% of the stroke (60-90 degreesrotation). Set the PS2’s gear switch to the “90” position.15900-734 6. From the TGX:16152-540 kit, get the mounting plate, spacer, two 5/16-18 x 2.00" hex headscrews and 5/16 washers and lockwashers. Fasten the mounting bracket and spacer to theactuator frame using the 5/16hardware.7. From the same kit, get two M8 screws and 5/16 flat washers and split lockwashers.8. Read the “Important” note below and then fasten the PS2 to the mounting bracket using theabove M8 and 5/16 hardware, while engaging the feedback pin in the U-channel. Slide themounting bracket along its slotted holes until the feedback arm is approximatelyperpendicular to the valve stem at the 50% stroke position. The feedback pin must movefreely inside the U-channel throughout the actuator stroke.IMPORTANTWhile attaching the positioner to the mounting bracket, be sure thefeedback pin is inserted into the U-channel. The spring in the feedback pinshould be compressed approximately 3/16" to 1/4" (4.5mm to 6.5mm).9. Tighten all hardware.10. Read the “Cautions” on page 2 and then apply the appropriate air pressures to fully strokethe valve. Exercise the positioner/actuator assembly to ensure that:•The feedback linkage does not prevent the valve from fully stroking.•The locator pin moves freely within the U-channel for the entire valve stroke. Adjustthe pin and U-channel positions as necessary.•All linkage hardware is secure.11. Once the feedback arm moves freely for the entire stroke, make electrical and pneumaticconnections and proceed to the PS2 setup instruction found within the PS2 manual.CONTACT INFORMATIONFor Product Support in the U.S.A.Technical SupportTelephone +1 800 569 2132, option 2 for Siemens and Moore Products Co. brandinstrumentsFax +1 215 646 3547E-mail **********************.comHours of Operation 8 a.m. to 4:45 p.m. eastern time, Monday through Friday (except holidays)TechnicalPublicationsin PDF /ia; under Customer Support Process Instrumentation, click on Documentation & Support LinksPublic Internet Site /iaRepair Service +1 215 646 7400 extension 3187For Product Support Outside of the U.S.A.Visit the Siemens public Internet site (see the above table for the URL), locate “Customer Support Process Instrumentation,” and click on the Contact Tech Support link to access the Global Support link. SIPART is a trademark of Siemens Energy & Automation, Inc. Other trademarks are the property of their respective owners. All product designations may be trademarks or product names of Siemens Energy & Automation, Inc. or other supplier companies whose use by third parties for their own purposes could violate the rights of the owners.Siemens Energy & Automation, Inc. assumes no liability for errors or omissions in this document or for the application and use of information in this document. The information herein is subject to change without notice.Procedures in this document have been reviewed for compliance with applicable approval agency requirements and are considered sound practice. Neither Siemens Energy & Automation, Inc. nor these agencies are responsible for repairs made by the user.。

华特牌高性能二氧化氯控制器利用说明书山大华特科技股分有限公司环保分公司目录概述 (2)注意事项 (2)原理框图 (3)性能指标 (4)前面板显示 (5)电气接线 (8)功能说明 (8)异样现象及其处置 (9)概述PLC控制器是专为华特牌二氧化氯发生器自动控制而开发的高新技术产品。

作为控制其核心的PLC是一种新型的通用自动控制装置，功能壮大。

显示系统为外观精美的工业人机界面，可通过按键灵活实现各类操作。

各收集点温度控制自动进行，从PT100铂热电阻输入的温度信号进入温度控制器，经模拟量输入通道收集，与温度设定值进行比较，运算（PID方式，模糊计算），来控制加热输出（智能调压模块）。

通过对计量泵频率的控制实现整个余氯控制进程。

从余氯传感器输入的4~20mA的测量信号，经模拟量输入通道收集，与余氯设定值进行比较，运算（PID方式，模糊计算），（或通过余氯、流量信号复合环）来控制频率输出。

温度控制、余氯控制具有测量精准，抗干扰能力强，靠得住性高等特点。

本产品同时具有缺料报警保护、欠水压报警保护、缺水报警保护、温度传感器短路、断路保护及超温保护等功能。

控制器具有标准通信接口，符合多种通信规约。

该产品将传统的继电器控制技术、运算机技术和通信技术融为一体，自动化程度高，运行更靠得住，动作迅速，显示更直观、生动。

注意事项本产品为电子产品请务必注意以下事项：✧仪表供电为避免仪表损坏或失效，请利用额定电压供电。

为避免触电，所有接线工作完成后方能接通电源。

✧禁止在易燃气体周围利用为防火、防爆或仪表损坏，禁止在易燃、易爆气体，排放蒸汽的场所利用。

✧严禁触及仪表内部为避免触电或事故，严禁触及仪表内部，发生质量问题请与山东华特公司联系。

只有华特公司服务人员能够检查内部线路或改换部件。

✧接地请利用至少2mm2（AWG14）作为接地线，注意接地线不可与电源回路零线相连。

保养断电后方可清洗仪表面板，而且严禁直接用水清洗。

清除显示器上污渍请用软布或棉纸，禁止用硬物擦拭、触及或操作，不然会损坏或划伤界面。

SIEMENS 三立节能Honeywell科技创新、节能环保质量精湛、诚信服务秉德无私、厚重自慎济南三立节能设备有限公司地址：济南立下区窑头路3号邮编：250014电话：0531-******** 82577034传真：*************E-mail:************************SIEMENS 三立节能Honeywell第一章 概述一、 概述智能型温控阀采用德国西门子进口产品。

高科技含量的多功能控制器，具有独特的PID自整定技术，广泛应用于温度、相对湿度、绝对湿度、焓值、压差、流量、及空气质量的测量和控制。

它抗干扰性能强，功能完备、操作简单易懂，具有广泛的适用性。

性能稳定的执行器，采用液压传动机构，执行力大、多条运行曲线（线性或等比例）可选。

西门子阀体加上执行器组合可实现自动保护功能，断电后自动关闭阀门，闸死热源，防止出现事故。

二、 特点▲ 易于安装、参数设置和调试▲ 牢固的EMC设计▲ 电缆连接简单▲ 多个模拟输入、输出和数字输入、输出▲ 可实现多种控制功能温度补偿、昼夜转换、冬夏转换、远程控制、恒温恒湿、串级控制等▲ 具有比例、积分和微分（PID）调节功能▲ Ni1000、Pt1000、0-1000Ω、0-10V信号自由输入，并可扩展任意规格的输入信号▲ 编程简单，程序内置50余种程序可自由选择▲ 短路、断路、过载、超压、联动保护功能▲ 具有极高的性能价格比三、 主要技术指标▲ 工作环境：温度-25…+70℃ 湿度‹95%r.h.▲ 被测介质：蒸汽、热水、冷水、盐水、气体▲ 额定电压：AC24V 二线制▲ 输出信号：0-10V模拟信号 数字量信号▲ 防护等级：IP20,EN60529 IP30,EN60529▲ 产品标准：EN60730 89/336EEC 73/23EEC▲ 传感器响应时间： QAD22 3S QAE22 20S▲ 测量范围：-50…+150℃ -50Pa…40Mpa▲ 测量精度： 0.1℃ 0.5℃▲ 阀体承压：PN16 PN25 PN40▲ 阀体耐温：-25…220℃常见故障分析1. 西门子控制器,执行器,传感器常出现的故障:控制器:控制器不显示或是显示Err,请从以下方面检查a: 变压器坏,用电笔检查,如损坏请更换.b: 控制器端子上的线虚接,请检查接好.c: 控制器坏,请更换.d: 控制器显示Err,请检查连接传感器的接线是否有断接或是虚接,如果没有则为传感器坏,请更换.2. 执行器不动或是显示红灯亮，请从以下方面检查：a: 执行器打在手动上，应断电后拨在自动上。
