国栋国际大酒店及国栋南园五星城景观设计方案说明★★★作者：未知文章来源：互联网更新时间：2008-12-11 9:41:51一、设计背景1、区位位置：国栋国际大酒店及国栋南园五星城位于成都双流县城内，人民广场旁，规划总用地面积87.49亩。
东北临广都大道，西临川藏路。
另两侧与规划道路相临，交通便利，位置极佳。
2、区域环境：（1）气候：双流县位于成都西南部,常年平均气温16.2℃,湿度81%,年降雨量918.2 mm,风向多为静风或北风,风力一般2～3级,为亚热带湿润季风气候,气候温和,四季分明,无霜期长,雨量充沛,日照少，适宜多种动植物生长。
（2）水文地质条件：双流县境河属流域属岷江水系，有金马河、府河、江安河、杨柳河、清水河、白河和鹿溪河，河流纵横，水量丰富，地下水位浅。
二、设计目的在总体规划基础上，深化、完善园林景观设计，体现总体构想的宏观意图，把握高档酒店和高尚住宅区的要求和特点，在总体规划设计上体现自然景观与人文景观和谐统一的主体生态环境，反映人文精神，营造纯静典雅的园林氛围，建成中、西和璧，高品位、有特色、一流的现代化园林式酒店和住区。
三、设计依据1、“国栋国际大酒店及国栋南园五星城景观设计合同”2、“国栋国际大酒店及国栋南园五星城总平面图”及相关资料3、国家有关设计规范四、设计原则1、人本性原则——坚持以人为本的思想，满足酒店、会议、娱乐、居住、生活等功能需求，创造开朗、大气的酒店、会议环境和舒适、健康、宁静的居住环境。
2、功能性原则——合理布置场地，满足使用功能；交通流线顺畅，曲直符合要求。
3、整体性原则——注重园林景观与建筑风格、景观设计目标相一致，在不同的区域空间内形成统一的造园风格。
4、艺术性原则——坚持突出园林景观艺术特色的思想，结合小品、建筑、构筑等的外观设计，表现出幽雅时尚，中、西和璧的艺术特征。
5、生态性原则——运用生态学原理，使绿化与场地建筑相结合，生态与健康相结合，以水为魂，建立分段循环模式，处处有水，处处活水。
