Device Command Codes
The system CPU provides control of all in-system READ, WRITE, and ERASE operations
of the device via the system bus. The device manages all block-erase and word-program
algorithms.
Device commands are written to the CUI to control all device operations. The CUI does
not occupy an addressable memory location; it is the mechanism through which the
device is controlled.
Note: For a dual device, all setup commands should be re-issued to the device when a
different die is selected.
Table 10: Command Codes and Definitions
Table 10: Command Codes and Definitions (Continued)
256Mb and 512Mb (256Mb/256Mb), P30-65nm
Device Command Codes
sequence error occurs during an ERASE SUSPEND, the status register contains the com-
mand sequence error status (SR[7,5,4] set). When the ERASE operation resumes and fin-
ishes, possible errors during the operation cannot be detected via the status register be-
cause it contains the previous error status.
3.When bits 5:4 indicate a PROGRAM/ERASE operation error, either a CLEAR STATUS REG-
ISTER 50h) or a RESET command must be issued with a 15µs delay.
Clear Status Register
The CLEAR STATUS REGISTER command clears the status register. It functions inde-
pendently of V PP. The device sets and clears SR[7,6,2], but it sets bits SR[5:3,1] without
clearing them. The status register should be cleared before starting a command se-
quence to avoid any ambiguity. A device reset also clears the status register.
Configuration Register
Read Configuration Register
The read configuration register (RCR) is a 16-bit read/write register used to select bus
read mode (synchronous or asynchronous) and to configure device synchronous burst
read characteristics. To modify RCR settings, use the CONFIGURE READ CONFIGURA-
TION REGISTER command. RCR contents can be examined using the READ DEVICE
IDENTIFIER command and then reading from offset 0x05. On power-up or exit from re-
set, the RCR defaults to asynchronous mode. RCR bits are described in more detail be-
low.
Note: Reading the configuration register is a nonarray READ operation. When the oper-
ation occurs in asynchronous page mode, only the first data is valid, and all subsequent
data are undefined. When the operation occurs in synchronous burst mode, the same
word of data requested will be output on successive clock edges until the burst length
requirements are satisfied.
Table 17: Read Configuration Register
Read Mode
The read mode (RM) bit selects synchronous burst mode or asynchronous page mode
operation for the device. When the RM bit is set, asynchronous page mode is selected
(default). When RM is cleared, synchronous burst mode is selected.
Latency Count
The latency count (LC) bits tell the device how many clock cycles must elapse from the
rising edge of ADV# (or from the first valid clock edge after ADV# is asserted) until the
first valid data word is driven to DQ[15:0]. The input clock frequency is used to deter-
mine this value. The First Access Latency Count figure shows the data output latency for
different LC settings.
Figure 13: First Access Latency Count
CLK [C]
Address [A]
ADV# [V]
DQ[15:0] [D/Q]
DQ[15:0] [D/Q]
DQ[15:0] [D/Q]
DQ[15:0] [D/Q]
DQ[15:0] [D/Q]
DQ[15:0] [D/Q]
DQ[15:0] [D/Q]
DQ[15:0] [D/Q]
Note: 1.First Access Latency Count Calculation:
•1 / CLK frequency = CLK period (ns)
•n x (CLK period) ≥t AVQV (ns) – t CHQV (ns)
•Latency Count = n。
