机械——焊接专业术语中英文对照(郭运)整理1Single 单面的2V—groove V型坡口3Joint 焊接接头4Edges overlap 接头形式5Butt 对接6T T型焊接7Fillet 角焊缝8Edge 端接9Corner 角接10Radius 半径11Joint root 焊接根部12Bevel angle 削边角度13Groove angle 坡口角度14Root face 根部钝边15Groove face 坡口面16Plug weld 塞焊17Spot weld 点焊18Seam weld 缝焊19Slot weld 槽焊20Double—flare—bevel—groove K型坡口焊缝21Single—flare—V 单面V型22Edge flange 翻边端接23Corner flange 卷边端接24Flange weld 卷边焊缝25Flare weld 扩口焊缝26Fillet weld 角焊缝27Slot weld 槽焊缝28Spot weld 点焊缝29Surfacing weld 堆焊焊缝30Melt—through weld 熔透焊缝31Backing weld 打底焊缝32Back weld 背面焊缝33Root weld 根部焊缝34Crown weld 隆起部分35Weld reinforcement 焊缝加强36Weld face 焊缝表面37Cap pass 盖面焊道38Weld edge 焊缝边缘39Leg 焊脚40Toe 焊趾41Buildup 堆焊42Weld reinforcement 焊缝加强高43Effective throat 有效焊喉44Concave weld 凹形焊缝45Convex weld 凸形焊缝46Unequal leg fillet 不等脚角焊47Oversize weld 大尺寸焊缝48Depth of fusion 熔合深度49Depth of penetration 熔透深度50Root penetration 根部熔深51Joint penetration 接头熔深52Weld interface 焊缝分界面53Diameter of weld at point of contact 焊缝在接触点上的直径54Thickness 厚度55Tail 尾部56Arrow 箭头57Reference line 参考线58Arrow side 箭头一边59Weld symbol 焊缝符号60Near side 近侧61Arrow side 箭头侧62Far side 远侧63Other side 另一侧64Put the weld on either—side 在任意一侧施焊65There is no side significance 没有方向区别66Edge flange 双卷边67Corner flange 单卷边68Weld size 焊缝尺寸69Effective throat 有效厚度70Root opening 根部间隙71Full penetration double bevel—groove weld K形坡口全焊透焊缝72Full penetration double V—groove weld 双V形坡口全焊透焊缝73Partial penetration double bevel—groove weld K形坡口部分焊透焊缝74Partial penetration double V—groove weld 双V形坡口部分焊透焊缝75Bevel groove 削边坡口76Flare groove 喇叭形坡口77Flange groove 卷边坡口78V—groove V形坡口79Staggered intermittent fillet weld 交错间断角焊缝80Chain intermittent fillet weld 链状间断角焊缝81Segmented fillet weld 分段角焊缝82Pitch distance 间距83Depth of filling 填充深度84Slot weld width 槽焊缝宽度85Plug weld diameter 塞焊缝的直径86Angle of countersink 深孔角度87A dimension to the right of the symbol 在符号右边的尺寸88A dimension of the required suggest diameter 所要求的直径尺寸89A value for the required shear strength per spot 每点所要求的剪切强度值90Spot weld size 点焊缝尺寸91Spot weld length 点焊缝的长度92Number of spot required 所要求的点的数量93Pitch distance between adjacent spots 两个相邻点的间距94Reference line 参考线95Melt—through of weld from other side 焊缝在另一侧熔透96Single bevel—groove weld with backing weld 加垫板的单边坡口焊缝97Single bevel—groove weld with back weld 背面焊的单边坡口焊缝98Single bevel—groove weld with backing weld 带垫板的V 形坡口焊缝99Single bevel—groove weld with back weld背面焊的V形坡口焊缝100Square groove 直边坡口101Skewed groove 斜坡口102Sloped groove 倾斜坡口103Scarf 斜嵌接104Gas metal arc spot weld 气体保护点焊105Resistance spot weld 电阻点焊106Gas metal arc seam weld 气体保护滚焊缝107Resistance seam weld 电阻滚焊缝108Gas metal arc slot weld 气体保护槽焊缝109The type of electrode to use 所要求焊条形式110The weld quality standard 焊缝质量标准111The weld procedure to use 所用的焊接程序112Codes 规范113Drawing 图纸114Specifications 技术要求115Contracts 合同116General 一般注解117Local 局部注解118The point for lifting an object 吊装一物体的点119Filler metals 填充金属120Pressure vessel fabrication 压力容器制造121Be as simple as possible 尽可能简单122Welder 焊工123Code body 规范本身124Shielded metal arc 手工电弧焊125Submerged arc 埋弧焊126Face bend 面弯127Root bend 背弯128Side bend 侧弯129Nick break 缺口破坏130Tensile 拉伸131Monitoring production welding 监视生产中的焊接132Strength 强度133Toughness 韧性134Hardness 硬度135Ductility 延展性136Compressive 压缩137Impact 冲击138Fatigue 疲劳139Undercut 咬边140Overlap 焊瘤141Cracking 裂纹142Porosity 气孔143Ultimate tensile strength 极限拉伸强度144Percent elongation 延伸率145Percent reduction of area 断面收缩率146Impact strength 冲击强度147Yield strength 屈服强度148Brinell 布氏149Vickers 韦氏150Rockwell 洛氏151Knoop 努氏152Fatigue test 疲劳试验153Tensile test 拉伸试验154Micro--hardness test 显微硬度试验155Charpy impact test 夏比冲击试验156Soundness test 致密性测试157Fillet break 角焊缝断裂158Metallographic 金相159Transverse fillet weld shear test 横向角焊缝剪切试验160Quality of the fractured weld 焊缝端口的质量161Ductility of the weld metal 焊缝金属的延展性162Impact strength of the weld 焊缝的冲击强度163Tensile strength of the base metal 母材的拉伸强度164Weld—ability 可焊性165Scratches caused by improper handling 由不适当的处理导致的划痕166Incomplete fusion 未熔合167Distortion 变形168Slag inclusions 夹渣169Vibratory stress relief 振动消除应力170External restraint 外部拘束171Thermal stress relief 热消除应力172Peening 锤击173Annealing 退火174Quenching 淬火175Tempering 回火176Normalizing 正火177Decrease current 降低电流178Decrease voltage 降低电压179Increase travel speed 加快焊接速度180Change from weave to stringer bead technique 从横向摆动焊道改成直线焊道技术181Result in a wider heat—affected zone hardness导致热影响区更宽182Produce a lower heat—affected zone hardness 降低热影响区硬度183Slow down the cooling rate 降低冷却速度184Reduce the tendency to produce martensite in the heat—affected zone 减少在热影响区形成马氏体的倾向185Stress relief 消除应力186Crater crack 弧坑裂纹187SMAW 手动电弧焊188PAW 等离子焊189FCAW 药芯焊190SAW 埋弧焊191Underfill 未焊满192Excess convexity 太凸193Excess weld reinforcement 焊缝余高太高194Overfill 过充195Scratch start 擦伤196Arc strike 引弧烧伤197Tungsten inclusion 夹钨198Lamination 分层199Lamellar tear 片状撕裂200Seam 划伤201Pipe shrinkage 缩孔202Longitudinal crack 纵向裂纹203Transverse crack 横向裂纹204Underbead crack 焊道中裂纹205Toe crack 焊趾裂纹206Root crack 根部裂纹207Base metal crack 母材裂纹208Before welding 焊接前209During welding 焊接时210After welding 焊接后211Waiting time 等待时间212Penetrating time 渗透时间213Soak time 吸入时间214Dwell time 驻留时间215AC 交流电216DC 直流电217DCEP 直流反接218。
常用焊接术语中英文对照焊接Welding10.1 焊接种类Varieties of Welding电弧焊arc welding电熔焊electric fusion welding (EFW)气熔焊fusion gas welding (FGW)电阻焊electric resistance welding (ERW)有保护的金属电弧焊shielded metal arc welding (SMAW)手工或自动隋性气体保护钨极电弧焊manual and automatic inert gas tungsten arc welding (GTAW)自动埋弧焊automatic submerged arc welding金属极隋性气体保护电弧焊gas metal arc weiding (GMAW)氩弧焊argon-arc welding,气体保护电弧焊gas-shielded arc welding气焊gas welding; flame welding等离子焊plasma welding硬钎焊braze welding电渣焊electroslag welding爆炸焊explosive welding10.2 焊接形式Type of Welding角焊fillet welding间断焊intermittent welding点焊spot welding对焊butt welding搭焊lap welding塞焊plug welding珠焊bead welding槽焊slot welding堆焊build up welding垫板焊backing weld坡口grooveV形坡口V groove单面U形坡口single U grooveK形坡口double bevel grooveX形坡口double V groove双面U形坡口double U grooveU-V组合坡口combination U and V groove 根部间隙root gap焊接符号symbol of weld错边量alignment tolerance10.3 焊接位置Welding Position仰焊overhead welding现场焊field weld (F.W.)封底焊back run welding立焊vertical welding平焊flat welding工厂(车间)焊接shop weld定位焊tack weld跳焊skip welding节距pitch10.4 焊接缺陷Defects of Welding焊接裂纹weld crack根部裂纹root crack微裂纹micro crack错位mismatch弧坑pit; crater焊穿burn through夹渣slag inclusion咬边;咬肉undercut焊瘤overlap气孔porosity, blow hole砂眼blister针孔pin hole严重飞溅excessive spatter未溶合incomplete fusion; lack of fusion 根部未焊透incomplete penetration10.5 其它母材;基层金属base metal预热preheating热影响区heat affected zone (HAZ) 焊条welding electrode (rod)焊丝welding wire焊药(剂)flux。
钢结构焊接英语术语大全以下是一些常见的钢结构焊接英语术语:1. Welding:焊接2. Weld:焊缝3. Joint:焊接接头4. Fillet weld:角焊缝5. Butt weld:对接焊缝6. Fillet size:角焊缝尺寸7. Throat thickness:鞍部厚度8. Penetration:焊透9. Welding position:焊接位置10. Welding procedure:焊接工艺11. Welding current:焊接电流12. Welding voltage:焊接电压13. Welding speed:焊接速度14. Shielding gas:保护气体15. Preheating:预热16. Post-weld heat treatment:焊后热处理17. Groove:槽口18. Bevel:坡口19. Backing strip:补强条20. Welding helmet:焊接面罩21. Welding electrode:焊接电极22. Welding rod:焊条23. Welding wire:焊丝24. Welding machine:焊接机器25. Welding procedure specification (WPS):焊接工艺规范26. Welding inspector:焊接检验员27. Defect:缺陷28. Porosity:孔隙29. Inclusion:夹杂物30. Undercut:侵彻31. Cracking:裂纹32. Slag:焊渣33. Welding consumables:焊接材料34. Arc length:电弧长度35. Arc voltage:电弧电压36. Arc blow:电弧偏转37. Weld quality:焊接质量38. Non-destructive testing (NDT):无损检测39. Visual inspection:目视检验40. Ultrasonic testing (UT):超声波检测41. Radiographic testing (RT):射线检测42. Magnetic particle testing (MT):磁粉检测43. Liquid penetrant testing (PT):渗透检测44. Welder qualification:焊工资格证书45. Welding symbol:焊接符号46. Tack welds:点焊缝47. Crater:焊缝尾部凹坑48. Back gouging:反刮槽49. Weld toe:焊接母材交线处50. Arc welding:弧焊希望对你有所帮助!。
AW——ARC WELDING——电弧焊AHW——atomic hydrogen welding——原子氢焊BMAW——bare metal arc welding——无保护金属丝电弧焊CAW——carbon arc welding——碳弧焊CAW-G——gas carbon arc welding——气保护碳弧焊CAW-S——shielded carbon arc welding——有保护碳弧焊CAW-T——twin carbon arc welding——双碳极间电弧焊EGW——electrogas welding——气电立焊FCAW——flux cored arc welding——药芯焊丝电弧焊FCW-G——gas-shielded flux cored arc welding——气保护药芯焊丝电弧焊FCW-S——self-shielded flux cored arc welding——自保护药芯焊丝电弧焊GMAW——gas metal arc welding——熔化极气体保护电弧焊GMAW-P——pulsed arc——熔化极气体保护脉冲电弧焊GMAW-S——short circuiting arc——熔化极气体保护短路过度电弧焊GTAW——gas tungsten arc welding——钨极气体保护电弧焊GTAW-P——pulsed arc——钨极气体保护脉冲电弧焊MIAW——magnetically impelled arc welding——磁推力电弧焊PAW——plasma arc welding——等离子弧焊SMAW——shielded metal arc welding——焊条电弧焊SW——stud arc welding——螺栓电弧焊SAW——submerged arc welding——埋弧焊SAW-S——series——横列双丝埋弧焊RW——RWSISTANCE WELDING——电阻焊FW——flash welding——闪光焊RW-PC——pressure controlled resistance welding——压力控制电阻焊PW——projection welding——凸焊RSEW——resistance seam welding——电阻缝焊RSEW-HF——high-frequency seam welding——高频电阻缝焊RSEW-I——induction seam welding——感应电阻缝焊/> RSEW-MS——mash seam welding——压平缝焊RSW——resistance spot welding——点焊UW——upset welding——电阻对焊UW-HF——high-frequency——高频电阻对焊UW-I——induction——感应电阻对焊SSW——SOLID STATE WELDING——固态焊CEW——co-extrusion welding——CW——cold welding——冷压焊DFW——diffusion welding——扩散焊HIPW——hot isostatic pressure diffusion welding——热等静压扩散焊EXW——explosion welding——爆炸焊FOW——forge welding——锻焊FRW——friction welding——摩擦焊FRW-DD——direct drive friction welding——径向摩擦焊FSW——friction stir welding——搅拌摩擦焊FRW-I——inertia friction welding——惯性摩擦焊HPW——hot pressure welding——热压焊ROW——roll welding——热轧焊USW——ultrasonic welding——超声波焊S——SOLDERING——软钎焊DS——dip soldering——浸沾钎焊FS——furnace soldering——炉中钎焊IS——induction soldering——感应钎焊IRS——infrared soldering——红外钎焊INS——iron soldering——烙铁钎焊RS——resistance soldering——电阻钎焊TS——torch soldering——火焰钎焊UUS——ultrasonic soldering——超声波钎焊WS——wave soldering——波峰钎焊B——BRAZING——软钎焊BB——block brazing——块钎焊DFB——diffusion brazing——扩散焊DB——dip brazing——浸沾钎焊EXB——exothermic brazing——反应钎焊FB——furnace brazing——炉中钎焊IB——induction brazing——感应钎焊IRB——infrared brazing——红外钎焊RB——resistance brazing——电阻钎焊TB——torch brazing——火焰钎焊TCAB——twin carbon arc brazing——双碳弧钎焊OFW——OXYFUEL GAS WELDING——气焊AAW——air-acetylene welding——空气乙炔焊OAW——oxy-acetylene welding——氧乙炔焊OHW——oxy-hydrogen welding——氢氧焊PGW——pressure gas welding——气压焊OTHER WELDING AND JOINING——其他焊接与连接方法AB——adhesive bonding——粘接BW——braze welding——钎接焊ABW——arc braze welding——电弧钎焊CABW——carbon arc braze welding——碳弧钎焊EBBW——electron beam braze welding——电子束钎焊EXBW——exothermic braze welding——热反应钎焊FLB——flow brazing——波峰钎焊FLOW——flow welding——波峰焊LBBW——laser beam braze welding——激光钎焊EBW——electron beam welding——电子束焊EBW-HV——high vacuum——高真空电子束焊EBW-MV——medium vacuum——中真空电子束焊EBW-NV——non vacuum——非真空电子束焊ESW——electroslag welding——电渣焊ESW-CG——consumable guide eletroslag welding——熔嘴电渣焊IW——induction welding——感应焊LBW——laser beam welding——激光焊PEW——percussion welding——冲击电阻焊TW——thermit welding——热剂焊THSP——THERMAL SPRAYING——热喷涂ASP——arc spraying——电弧喷涂FLSP——flame spraying——火焰喷涂FLSP-W——wire flame spraying——丝材火焰喷涂HVOF——high velocity oxyfuel spraying——高速氧燃气喷涂PSP——plasma spraying——等离子喷涂VPSP-W——vacuum plasma spraying——真空等离子喷涂TC——THERMAL CUTTING——热切割OC——OXYGEN CUTTING——气割OC-F——flux cutting——熔剂切割OC-P——metal powder cutting——金属熔剂切割OFC——oxyfuel gas cutting——氧燃气切割CFC-A——oxyacetylene cutting——氧乙炔切割CFC-H——oxyhydrogen cutting——氢氧切割CFC-N——oxynatural gas cutting——氧天然气切割CFC-P——oxypropanne cutting——氧丙酮切割OAC——oxygen arc cutting——氧气电弧切割OG——oxygen gouging——气刨OLC——oxygen lance cutting——氧矛切割AC——ARC CUTTING——电弧切割CAC——carbon arc cutting——碳弧切割CAC-A——air carbon arc cutting——空气碳弧切割GMAC——gas metal arc cutting——熔化极气体保护电弧切割GTAC——gas tungsten arc cutting——钨极气体保护电弧切割PAC——plasma arc cutting——等离子弧切割SMAC——shielded metal arc cutting——焊条电弧切割HIGH ENERGY BEAM CUTTING——高能束切割EBC——electron beam cutting——电子束切割LBC——laser beam cutting——激光切割LBC-A——air——空气激光切割LBC-EV——evaporative——蒸气激光切割LBC-IG——inert gas——惰性气体激光切割LBC-O——oxygen——氧气激光切割。
焊接用语中英对照焊接专业英语词汇(熔化焊)熔接fusion welding压接pressure welding焊接过程welding process焊接技术welding technique焊接工艺welding technology/procedure焊接操作welding operation焊接顺序welding sequence焊接方向direction of welding焊接位置welding position熔敷顺序build-up sequencedeposition sequence焊缝倾角weld slope/inclination of weld axis焊缝转角weld rotation/angle of rotation平焊位置flat position of welding横焊位置horizontal position of welding立焊位置vertical position of welding仰焊位置overhead position of welding平焊downhand welding/flat position welding横焊horizontal position welding立焊vertical position welding仰焊overhead position welding全位置焊all position welding:熔焊时,焊件接逢所处空间位置包括平焊、横焊、仰焊等位置所进行的焊接。
如水平固定管所进行的环缝焊接向下立焊vertical down welding/downward welding in the vertical position 向上立焊vertical up welding/upward welding in the vertical position 倾斜焊inclined position welding上坡焊upward welding in the inclined position下坡焊downward welding in the inclined position对接焊butt welding角焊fillet welding搭接焊lap welding船形焊fillet welding in the downhand position/fillet welding in the flat position平角焊horizontal fillet welding立角焊fillet welding in the vertical position仰角焊fillet welding in the overhead position坡口焊groove weldingI形坡口对接焊square butt welding喇叭形坡口焊 flare groove welding卷边焊flanged edge welding纵缝焊接welding of l0ngitudinal seam横缝焊接welding of transverse seam环缝焊接girth welding/ circumferential螺旋缝焊接welding of spiral seam/welding of helical seam 环缝对接焊butt welding of circumferential seam定位焊tack welding单面焊welding by one side双面焊welding by both sides单道焊single pass welding/single run welding多道焊multi-pass welding单层焊single layer welding多层焊multi-layer welding分段多层焊block sequence/ block welding分层多道焊multi-layer and multi-pass welding连续焊continuous welding断续焊intermittent welding打底焊backing weld封底焊back sealing weld盖面焊cosmetic welding深熔焊deep penetration welding摆动焊welding with weaving/weave bead welding前倾焊 foreward welding (英国)/ forehand welding (美国) 后倾焊 backward welding(英国)/ backhand welding(美国)分段退焊backstep welding跳焊skip welding对称焊balanced welding/ balanced welding sequence左焊法leftward welding forehand welding右焊法rightward welding/backhand welding挑弧焊whipping method自动焊automatic welding手工焊manual welding/hand welding车间焊接shop welding工地焊接site welding(英国)/ field welding (美国)拘束焊接restraint welding堆焊surfacing/building up/overlaying隔离层堆焊buttering端部周边焊boxing/end return返修焊rewelding补焊repair welding塞焊plug welding槽焊slot welding衬垫焊welding with backing焊剂垫焊welding with flux backing窄间隙焊narrow-gap welding强制成形焊enclosed welding脉冲电弧焊pulsed are welding电弧点焊arc spot welding螺柱焊stud welding热风焊hot gas welding高能焊high grade energy welding固态焊接solid-state welding单面焊双面成形one-side welding with back formation 焊接条件welding condition焊接工艺参数welding parameter极性polarity正接electrode negative/straight polarity反接electrode positive/reversed polarity运条方式manipulation of electrode焊接电流welding current焊接电流增加时间welding current upslope time焊接电流衰减时间welding current downslope time电流密度current density短路电流short circuit current脉冲电流pulse level/pulse current level脉冲电流幅值pulse current amplitude基值电流background level脉冲频率pulse frequency脉冲焊接电流占空比duty cycle of pulse duration电弧电压arc voltage再引弧电压reignition voltage焊接速度welding speed行走速度rate of travel/travel speed送丝速度wire feed rate线能量heat input/energy input热输入heat input预热preheat后热postheat焊后热处理posweld heat treatment/postheat treatment 预热温度preheat temperature层间温度interpass temperature焊接终了温度finishing temperature后热温度postheating temperature焊丝伸出长度wire extension弧长arc length熔化速度melting rate熔化时间melting time熔化系数melting coefficient熔敷速度rate of deposition/deposition rate熔敷系数deposition coefficient熔敷效率deposition efficiency损失系数loss coefficient飞spatter飞溅率spatter loss coefficient融合比fusion ratio稀释dilution稀释率rate of dilution合金过度系数transfer efficiency/recovery (of an element)坡口groove坡口面groove face坡口面角度angle of bevel (英国)/ bevel angle (美国)坡口角度included angle(英国)/groove angle(美国)坡口高度groove depth钝边root face钝边高度thickness of root face/width of root face根部间隙root gap(英国)/root opening (美国)根部半径root radius/groove radius根部锐边root edge卷边高度height of flange卷边半径radius of flange单面坡口single groove双面坡口double groove坡口形式groove typeI形坡口square grooveV形坡口single V grooveY形坡口single V groove with root face双Y形坡口double Vgroove with root face带钝边U形坡口single U groove带钝边双U形坡口double U grooveVY形坡口single compound angle groove带钝边J形坡口single J groove带钝边双J形坡口double J groove单边V形坡口single bevel groove双V形坡口double V groove不对称双V形坡口 asymmetric double V groove双单边V形坡口 double bevel groove/K groove带垫板V形坡口 V groove with backing/ single V groove with backing 喇叭形坡口flare groove锁底坡口single bevel groove with backing locked坡形板边 tapered edge焊缝 weld接逢 seam焊缝符号 welding symbol焊缝金属 weld metal填充金属 filler metal熔敷金属 deposited metal焊缝表面weld face/ face of weld焊缝背面 back of weld焊缝轴线axis of weld焊缝尺寸 size of weld焊缝宽度weld width/ width of weld焊缝长度 weld length/ length of weld焊缝有效长度 effective length of weld焊缝厚度 throat depth/ throat thickness焊缝计算厚度theoretical throat焊缝实际厚度actual throat熔深penetration/ depth of penetration焊缝成形appearance of weld焊缝成形系数form factor of weld余高 reinforcement/ excess weld metal背面余高root reinforcement削平焊缝flush weld/ weld machined flush对接焊缝butt weld角焊缝fillet焊脚leg/ fillet weld leg角焊缝断面形状profile of fillet weld平形角焊缝flat fillet凸形角焊缝convex fillet weld凹形角焊缝concave fillet weld角焊缝凹度concavity侧面角焊缝side fillet weld/ fillet weld in parallel shear 正面角焊缝front fillet weld/ fillet weld in normal shear 立角焊缝fillet weld in the vertical position横角焊缝fillet weld in the horizontal position平角焊缝fillet weld in the flat position斜角焊缝oblique fillet weld连续焊缝continuous weld断续焊缝intermittent weld连续角焊缝continuous fillet weld断续角焊缝intermittent fillet weld交错断续角焊缝staggered intermittent fillet weld并列断续角焊缝chain intermittent fillet weld端接焊缝edge weld卷边焊缝flanged edge weld塞焊焊缝plug weld纵向焊缝l0ngitudinal weld横向焊缝transverse weld熔化焊环行焊缝girth weld/ circumferential weld螺旋形焊缝spiral weld/ helical weld密封焊缝seal weld承载焊缝strength weld联系焊缝connective weld定位焊缝tack weld焊道bead/ run/ pass焊波ripple焊根weld root/ root of weld焊趾weld toe/ toe封底焊道sealing run (after making main weld)/ back weld打底焊道backing weld (before making main weld)/ back weld根部焊道root pass/ root run填充焊道filling bead盖面焊道cosmetic bead/ cover pass回火焊道temper bead/ annealing bead熔透焊道penetration bead焊层 layer焊接接头welded joint接头形状joint geometry等强匹配接头equalmatching weld joint低强匹配接头undermatching weld joint超强匹配接头overmatching weld joint接头根部root of joint对接接头butt jointI形对接接头square butt jointV形对接接头single V butt jointU形对接接头single U butt jointJ形坡口接头single J butt joint双V形对接接头double V butt joint双单边V形对接接头double bevel butt joint/ K groove butt joint 带钝边U形对接接头double U butt joint带钝边J形坡口接头double J joint角接接头corner jointT形接头T joint斜T形接头inclined T joint十字接头cruciform joint/ cross-shaped joint三联接头joint among three members搭接接头lap joint套管接头muff joint/ sleeve joint双盖板接头double strapped joint盖板接头strapped joint端接接头edge joint卷边接头flanged edge joint锁底对接接头lock butt joint斜对接接头oblique butt joint混合接头mixed joint/ composite joint有间隙接头open joint无间隙接头closed joint焊接电弧welding arc电弧形态arc shape电弧物理行为arc physics behaviour引弧striking arc引弧电压striking voltage电弧气氛arc atmosphere阴极cathode热阴极hot cathode冷阴极cold cathode阴极斑点cathode spot阴极区cathode region阴极区电场强度intensity of the electric field in the cathode region 阴极压降cathode drop阳极anode阳极斑点anode spot斑点压力spot pressure阳极区anode region阳极区电场强度intensity of the electric field in the anode region 阳极压降anode drop弧柱arc column/ arc stream弧柱压降voltage drop in arc column弧柱电位梯度potential gradient in the arc column弧焰arc flame弧心arc core硬电弧forceful arc/ hard arc软电弧soft arc旋转电弧rotating arc脉冲电弧pulsed arc脉冲喷射电弧pulsed spray arc起皱现象puckering phenomena起皱电弧puckering arc起皱临界电流 puckering critical current间接电弧 indirect arc压缩电弧 compressive arc磁控电弧 magnetic controlling arc电弧力 arc force电磁力 electromagnectic force电磁收缩效应 pinch effect电弧飘移 wandering of arc电弧稳定性 arc stability电弧静特性 static characteristic of arc电弧动特性 dynamic characteristic of arc最小电压原理 principle of minimum voltage电弧挺度arc stiffness电弧偏吹 arc blow磁偏吹 magnetic blow阴极清理作用 cleaning action of the cathode电弧自身调节 arc self-regulation挖掘作用 digging action极性效应 polarity effect熔滴 droplet熔滴比表面积 specific surface of droplet熔滴过渡metal transfer过度频率 transition frequency粗滴过渡globular transfer; drop transfer短路过渡short circuiting transfer喷射过渡spray transfer旋转喷射过渡 rotating spray transfer脉冲喷射过渡 pulsed spray transfer爆炸过渡 explosive transfer渣壁过渡 flux wall guided transfer熔池 molten pool沸腾状熔池 boiling molten pool弧坑crater熔渣slag渣系 slag system渣系相图 slag system diagram碱性渣 basic slag酸性渣 acid slag碱度 basicity酸度 acidity长渣 l0ng slag短渣 short slag粘性熔渣 viscous slag氧化物型熔渣 oxide melting slag盐型熔渣 salt melting slag盐-氧化物型熔渣 salt-oxide melting slag熔渣流动性 fluidity of the slag; slag fluidity 熔渣solidified slag多孔焊渣 porous slag玻璃状焊渣 vitreous slag自动脱落焊渣 self-releasing slag脱渣性 slag detachability焊接设备 welding equipment; welding set焊机 welding machine; welder电焊机 electric welding machine; electric welder焊接电源 welding power source焊接热循环 weld thermal cycle焊接温度场 field of weld temperature; weld temperature field 准稳定温度场 quasi-stationary temperature field焊接热源 welding heat source点热源 point heat source线热源 linear heat source面热源 plane heat source瞬时集中热源 instantaneous concentration heat source热效率 thermal efficiency热能集中系数 coefficient of heat flow concentration峰值温度 peak temperature瞬时冷却速度 momentary cooling rate冷却时间 cooling time置换氧化 substitutionary oxydation扩散氧化 diffusible oxydation脱氧 desoxydation先期脱氧 precedent desoxydation扩散脱氧 diffusible desoxydation沉淀脱氧 precipitation desoxydation扩散氢 diffusible hydrogen初始扩散氢 initial diffusible hydrogen100℃残余扩散氢diffusible hydrogen remained at 100℃残余氢 residual hydrogen去氢 dehydrogenation去氢热处理 heat treatment for dehydrogenation脱硫 desulphurization脱磷 dephosphorization渗合金 alloying微量合金化 microalloying一次结晶组织 primary solidification structure二次结晶组织 secondary solidification structure联生结晶 epitaxial solidification焊缝结晶形态 solidification mode in weld-bead结晶层状线 ripple多边化边界 polygonization boundary结晶平均线速度 mean solidification rate针状铁素体 acicular ferrite条状铁素体 lath ferrite侧板条铁素体 ferrite side-plate晶界欣素体 grain boundary ferrite; polygonal ferrite; pro-entectoid ferrite粒状贝氏体 granular bainite板条马氏体 lath martensite过热组织 overheated structure魏氏组织 Widmannst?tten structureM-A组元 martensite-austenite constituent焊件失效分析 failure analysis of weldments冷裂判据 criterion of cold cracking冷裂敏感系数 cold cracking susceptibity coefficient脆性温度区间 brittle temperature range氢脆 hydrogen embrittlement层状偏析 lamellar segregation愈合 healing effect断口金相fractography断口 fracture延性断口 ductile fracture韧窝断口dimple fracture脆性断口 brittle fracture解理断口 cleavage fracture准解理断口 quasi-cleavage fracture氢致准解理断口 hydrogen-embrittlement induced沿晶断口 intergranular fracture穿晶断口 transgranular fracture疲劳断口 fatigue fracture滑移面断口 glide plane fracture断口形貌 fracture apperance断口试验 fracture test宏观断口分析 macrofractography放射区 radical zone纤维区 fibrous zone剪切唇区 shear lip aone焊接性weldability使用焊接性 service weldability工艺焊接性 fabrication weldability冶金焊接性 metallurgical weldability热焊接性 thermal weldability母材 base metal; parent metal焊接区 weld zone焊态 as-welded (AW)母材熔化区 fusion zone半熔化区 partial melting region未混合区 unmixed zone熔合区 bond area熔合线 weld junction (英);bond line (美)热影响区 heat-affected zone (HAZ)过热区 overheated zone粗晶区 coarse grained region细晶区 fine grained region过渡区 transition zone硬化区 hardened zone碳当量 carbon equivalent铬当量 chromium equivalent镍当量 nickel equivalent舍夫勒组织图 Schaeffler's diagram德龙组织图Del0ng’s diagram连续冷却转变图(CCT图)continuous cooling transformation 裂纹敏感性 cracking sensibility焊接裂纹 weld crack焊缝裂纹 weld metal crack焊道裂纹 bead crack弧坑裂纹crater crack热影响区裂纹 heat-affected zone crack纵向裂纹 l0ngitudinal crack横向裂纹 transverse crack微裂纹 micro-crack; micro-fissure热裂纹 hot crack凝固裂纹 solidification crack晶间裂纹 intercrystalline crack穿晶裂纹 transcrystalline crack多边化裂纹 polygonization crack液化裂纹 liquation crack失延裂纹 ductility-dip crack冷裂纹 cold crack延迟裂纹 delayed crack氢致裂纹 hydrogen-induced crack焊道下裂纹 underbead crack焊根裂纹 root crack焊趾裂纹 toe crack锯齿形裂纹 chevron cracking消除应力处理裂纹 stress relief annealing crack (SR crack) 再热裂纹 reheat crack焊缝晶间腐蚀 weld intercryctalline corrosion刀状腐蚀 knife line attack敏化区腐蚀 weld decay层状撕裂 lamellar tearing焊接性试验 weldability裂纹试验 cracking testIIW裂纹试验 IIW cracking testY形坡口裂纹试验 slit type cracking test分块形槽热裂纹试验 segmented circular groove cracking testH形裂纹试验 H-type cracking test鱼骨形裂纹试验 fishbone cracking test指形裂纹试验 finger (cracking) testT形裂纹试验 Tee type cracking test环形槽裂纹试验 circular-groove cracking test可调拘束裂纹试验 varestraint testBWRA奥氏体钢裂纹试验 BWRA cracking test for austenitie steel圆棒裂纹试验 bar type cracking test; round bar cracking test里海裂纹试验 Lehigh restraint cracking test圆形镶块裂纹试验 circular-path cracking test十字接头裂纹试验 cruciform cracking testZ向窗口拘束裂纹试验 Z-direction window type restraint cracking test G-BOP焊缝金属裂纹试验 G-BOP weld metal crack test巴特尔焊道下裂纹试验 Battelle type underbead cracking testU形拉伸试验 U-tension test缪雷克期热裂纹试验 Murex hot cracking test菲斯柯裂纹试验 FISCO (type) cracking testCTS裂纹试验 controlled thermal severity拉伸拘束裂纹试验(TRC试验)tensile restraint cracking test刚性拘束裂纹试验(RRC试验)rigid restraint cracking test插销试验 implant testTigamajig 薄板焊接裂纹试验 Tigamajing thin plate cracking test焊道纵向弯曲试验 l0ngitudinal-bead test柯麦雷尔弯曲试验 Kommerell bead bend test肯泽尔弯曲试验 Kinzel test缺口弯曲试验 notch bend test热朔性试验 hot-ductility test热影响区冲击试验 impact test of HAZ热影响区模拟试验 synthetic heat-affected zone test最高硬度试验 maximum hardness test落锤试验 NRL (Naval Research Laboratory)测氢试验 Hydrogen test焊接材料电极焊接材料welding consumables电极electrode熔化电极consumable electrode不熔化电极nonconsumable electrode钨电极tungsten electrode焊丝welding wire. Welding rod实心焊丝solid wire渡铜焊丝copper-plating welding wire自保护焊丝self-shielded welding wire药芯焊丝flux-cored wire复合焊丝combined wire堆焊焊丝surfacing welding rod填充焊丝filler wire焊条electrode/ covered electrode焊芯core wire药皮coating (of an electrode)/ covering (of an electrode)涂料coating flux/coating material造气剂gas forming constituents造渣剂slag forming constituents合金剂alloying constituent脱氧剂dioxidizer稳弧剂arc stabilizer粘接剂binder水玻璃water glass水玻璃模数modules of water glass酸性焊条acid electrode高钛型焊条high titania (type) electrode钛钙型焊条lime titania type electrode钛铁矿形焊条ilmenite type electrode氧化铁型焊条iron oxide type electrode/ high iron oxide type electrode 高纤维素型焊条high cellulose (type) electrode石墨型焊条graphite type electrode碱性焊条basic electrode/ lime type covered electrode低氢型焊条low hydrogen type electrode高韧性超低氢焊条high toughness super low hydrogen electrode奥氏体焊条austenitic electrode铁素体焊条ferritic electrode不锈钢焊条stainless steel electrode珠光体耐热钢焊条pearlitic heat resistant steel electrode低温钢焊条low temperature steel electrode/ steel electrode for low temperature铝合金焊条aluminum alloy arc welding electrode铜合金焊条copper-alloy arc welding electrode铜芯铸铁焊条cast iron electrode with steel core纯镍铸铁焊条pure nickel cast iron electrode球墨铸铁焊条electrode for welding spheroidal graphite cast iron铸芯焊条electrode with cast core wire镍基合金焊条nickel base alloy covered electrode蒙乃尔焊条Monel electrode纯铁焊条pure iron electrode渗铝钢焊条alumetized steel electrode高效率焊条high efficiency electrode铁粉焊条iron powder electrode焊接欠缺与检验焊接欠缺welding imperfection焊接缺陷weld defect气孔blowhole/ gas pore针尖状气孔pinhole密集气孔porosity条虫状气孔wormhole裂纹crack表面裂纹surface crack咬边undercut焊瘤overlap凹坑pit烧穿burn through塌陷excessive penetration未焊透incomplete penetration/ lack of penetration 未熔合lack of fusion/ incomplete fusion未焊满incompletely filled weld根部凹陷root concavity电弧擦伤arc scratch夹渣slag inclusion夹杂物inclusion夹钨tungsten inclusion白点fish eye/ flake错边misalignment/ dislocation焊接检验试件test piece试样test specimen面弯试验face bend testing背弯试验root bend test侧弯试验side bend test横弯试验horizontal bend test纵弯试验axial bend test压扁试验squeezing test电阻焊摩擦焊爆炸焊扩散焊超声波焊等电阻焊 resistance welding (RW)点焊 spot welding; resistance spot welding凸焊 projection welding缝焊 seam welding滚点焊 roll-spot welding连续点焊 stitch welding多点焊 multiple spot welding手压点焊 push welding; poke welding脉冲点焊 pulsation spot welding; multiple-impulse welding 双面点焊 direct spot welding单面点焊 indirect spot welding串联点焊 series spot welding多点凸焊multiple projection welding频道进缝焊 step-by-step seam welding压平缝焊 mash seam welding串联缝焊 series seam welding对接缝焊 butt seam welding; foil-butt seam电阻对焊 upset butt welding闪光对焊 flash butt welding (FBW)储能焊 stored energy welding电容储能点焊 condenser discharge spot welding高频电阻焊 high frequency resistance welding冲击电阻焊 percussion welding胶接点焊 spot weld-bonding; weld-bonding闪光 flashing; flash过梁 bridge; lintel顶锻 upsetting; upset夹紧力 clamping force顶锻力 upsetting force; upset force电极压力 electrode force; electrode pressure电极滑移 electrode skid焊接循环 welding cycle预压时间 squeeze time锻压时间 forge-delay time; forge time焊接通电时间(电阻焊)welding time (resistance welding) 预热时间 preheat time加热时间 heat time冷却时间 cool time间歇时间 quench time; chill time回火时间 temper time维持时间 hold time休止时间 off time闪光时间flash time; flashing time顶锻时间 upset time; upsetting time有电顶锻时间 upset current time无电顶锻时间 upset current-off time闪光速度 flashing speed闪光电流 flashing current; flash current顶锻电流 upset current预热电流 preheat current回火电流 temper current调伸长度 initial overhange; extension闪光留量 flash allowance顶锻留量 upset allowance顶锻速度 upset speed电极接触面 electrode contact surface贴合面 faying surface焊点 welding spot熔核 nugget熔核直径 diameter of nugget塑性金属环区corona bond焊透率penetration rate压痕indentation压痕深度depth of indentation压深率indentation ratio翘离sheet separation缩孔shrinkage cavity胡须intrusion电极粘损electrode pick up喷溅splash/ expulsion毛刺fin飞边upset metal/ fin焊点距weld spacing/ spot weld spacing边距edge distance分流shunt current接触电阻contact resistance电阻焊机resistance welding machine点焊机spot welding machine多点焊机multiple spot welding machine移动式点焊机portable spot welding machine缝焊机seam welding machine纵横两用缝焊机universal seam welder对焊机butt resistance welding machine凸焊机projection welding machine三相低频焊机three phase low frequency welder二次整流电阻焊机direct current resistance welder secondary rectification电容储能电阻焊机condenser discharge resistance welder电容储能点焊机condenser type spot welder/ capacitor spot welding machine 工频电阻焊机mains frequency resistance welding machine低频电阻焊机frequency converter resistance welding machine高频焊机high frequency induction welder逆变式电阻焊机inverter type resistance welding machine全波阻焊电源full wave resistance welding power source斩波阻焊电源chopped wave resistance welding power source旋转焊接变压器rotary welding transformerC形点焊钳C-type welding head/ C-type gunX形点焊钳pincer spot welding head/ pliers spot welding head 断续器contactor同步断续器synchronous contactor异步断续器non-synchronous contactor程序控制器sequencer程序时间调节器sequencer timer电极臂arm电极握杆electrode holder电极台板backup die/ bolster电极水冷管electrode cooling tube电极头electrode tip电极帽electrode cap锥头电极truncated tip electrode平头电极flat tip electrode尖头电极pointed tip electrode球面电极radius tip electrode偏心电极offest electrode直电极straight electrode弯电极cranked electrode双弯电极double cranked (swannecked) electrode滚轮电极circular electrode/ welding wheel斜棱滚轮电极bevelled wheel顶锻机构upsetting mechanism电极总行程total electrode stroke工作行程operational stroke辅助行程electrode travel/ electrode stroke臂间距离horn spacing/ throat opening电极臂伸出长度arm extension摩擦焊friction welding (FW)转速friction speed摩擦压力friction pressure/ heating pressure摩擦时间friction time摩擦变形量burn-off length摩擦变形速度burn-off rate停车时间stopping time顶锻变形量forge length顶锻变形速度forge rate摩擦表面friction surface储能摩擦焊fly-wheel type friction welding径向摩擦焊radial friction welding扩散焊diffusion welding (DW)过渡液相扩散焊transient liquid phase diffusion welding 热等静压扩散焊hot isotatic pressure diffusion welding 热轧扩散焊roll diffusion welding扩散缝焊seam diffusion welding超塑成形扩散焊supperplastic forming diffusion bounding 隔离剂buttering material爆炸焊explosive welding (EW)爆炸点焊explosive spot welding爆炸线焊explosive line welding多层板爆炸焊explosive welding of multiplayer plates多层管爆炸焊explosive welding of multiplayer tubes覆板(覆管)cladding plat (tube)/ flyer plate (tube)基板(基管)base plate(tube)/ parent plate (tube)保护层buffer/ protector基础base预置角preset angle间距initial stand-off/ spacing装药量explosive load装药密度charge density/ loading density质量比mass ratio平行法parallel plate configuration角度法preset angle configuration均匀布药average arranging explosive梯形布药gradient arranging explosive爆炸焊参数explosive welding parameters初始参数initial parameters动态参数dynamic parameters界面参数interface parameters爆轰速度detonation velocity覆板速度cladding plate velocity碰撞点impact point碰撞点速度velocity of the impact point弯折角bending angle碰撞角collision angle碰撞压力impact pressure格尼能Gurney energy垂直碰撞normal impact倾斜碰撞oblique impact/ inclined impact对称碰撞symmetrical impact来流upper stream出流down stream再入射流re-entrant jet自清理oneself cleaning结合区bond zone平面结合plane bond波状结合wave-like bond界面波长length of the interfacial wave界面波幅amplitude of the interfacial wave熔化层molten layer熔化袋molten pocket雷管区detonator zone边界效应edge effect焊接性窗口weldability windows焊着率ratio of welding area内爆法internal explosion process外爆法external explosion process半圆柱试验法semi-cylinder experiment method超声波焊ultrasonic welding (UW)超声波点焊ultrasonic spot welding超声波缝焊ultrasonic seam welding超声波点焊机ultrasonic spot welder超声波缝焊机ultrasonic seam welder冷压焊cold pressure welding (CPW)热压焊hot pressure welding热轧焊hot roll welding旋弧压力焊rotating arc pressure welding埋弧压力焊submerged arc pressure welding电渣压力焊electroslag pressure welding气压焊gas pressure welding锻焊forge-welding/ blacksmith welding磁力脉冲焊magnetic-pulse welding焊接专业英语词汇(焊接卫生与安全)焊接烟尘weld fume焊接发尘量total amount of fumes焊接烟尘浓度weld fume concentration焊接烟尘容限浓度threshold limit values of weld fume (TLV)焊接发尘速率weld fume emission rate焊接有害气体welding toxic gases/ weld harmful gases标定卫生空气需要量nominal hygienic air requirement焊工尘肺pheumocomsis of welder焊工锰中毒chronic occupational manganese poisoning of welder 焊工氟中毒fluorosis of welder焊工金属烟热metal fume fever of welder电光性眼炎eye-flash (arc eye)电光性皮炎electro-photo dermatitis电弧紫外线灼伤ultraviolet ray burn防电击装置voltage reducing device 除尘装置dust collection device焊工手套welding gloves护脚welding spats防护鞋shielding shoes。
焊接相关的英语术语以下是我⾃⼰搜集汇总的,如有错误,还望指正!false soldering "假焊"poor soldering(个⼈建议)“虚焊”=焊接得不够牢固不够好cold solder "冷焊"poor-wetting "润湿不良"insufficient solder "少錫"open solder "开路"unsoldering 拆焊假焊是指焊点表⾯上好像焊接成功,但实际上并没有焊住,有时⽤⼿⼀拨,引线就可以从焊接点中拨出。
关键字:没有焊住。
虚焊是焊点处只有少量的锡焊柱,造成接触不良,时通时断。
关键字:接触不良。
可以理解为:假焊实际是没有焊上去,器件不能使⽤,⽽虚焊是焊接的不牢靠,会出现接触不良时好时坏的情况。
补充⼀些:空焊是焊点应焊⽽未焊。
锡膏太少、零件本⾝问题、置件位置、印锡后放置时间过长等会造成空焊。
关键字:空的。
冷焊是在零件的吃锡接⼝没有形成吃锡带,(即焊锡不良)。
流焊温度太低、流焊时间太短、吃锡性问题等会造成冷焊。
关键字:温度不够,“冷”嘛!“虚焊”的英语表达:I support the answer "poor soldering", "cold soldering" should be another defect mode. I think "cold soldering" should be caused by low peak temperature or short reflow time, the solder paste doesn't melt well at peak temperature. but " poor soldering" is mainly cuased by oxidation. the surface ot the component termination or PCB is oxidized, so although the solder paste is melt, but the flux is not enough to remove the oxid. ---但本编辑认为poor soldering其实还是可以的。
焊接工艺英文简介焊接工艺是制造业中常见的一种工艺,用于将金属零件通过熔化和固化的方式连接在一起。
在焊接工艺中,专业的术语和表达方式有助于促进国际间的交流和合作。
本文将介绍一些常见的焊接工艺英文术语,以便工程师和从事焊接工作的人员能够更好地理解和运用。
常见术语1.Welding(焊接): The process of joining two or more metal partstogether by melting and solidifying.2.Arc welding(电弧焊接): A welding process that uses an electric arcto melt metals and join them together.3.Gas welding(气焊): A welding process that uses a gas flame to meltmetals and join them together.4.Spot welding(点焊): A welding process in which metal parts arejoined together by a series of small spot welds.5.Seam welding(焊缝焊接): A welding process that joins metalsalong a continuous seam.6.Butt joint(对接焊接): A joint that occurs when two metal parts arealigned end-to-end and welded together.7.Fillet weld(角焊缝): A weld that joins two metal parts at an angle.8.Weld bead(焊缝): The material left behind after a weld iscompleted.9.Flux(熔剂): A substance used to facilitate the welding process bypreventing oxidation and promoting proper fusion.10.Shielding gas(保护气体): A gas used to protect the weld area fromatmospheric contamination during welding.常见缩写1.GTAW(Gas Tungsten Arc Welding): 氩弧焊,一种常用的金属焊接方法。
1. welding circuits焊接电路2. welding processes焊接工艺3. welding wire conduit 焊丝导管4. workpiece 工件5. cable电缆6. stick-electrode焊条7. welding gun 焊枪8. electrical current电流9. welding machine电焊机10. electrode holder焊钳11. electrode焊条,电极,焊丝12. alternating current(AC) 交流电13. direct current(DC) 直流电14. power source 电源15. power line 电源线16. transformer 变压器17. rectifier 整流器18. torch 焊炬19. welding materials焊接材料20. arc blow 电弧偏吹21. solid wire 实心焊丝22. flux-cored wire 药芯焊丝23. welding flux 焊剂24. arc welding (AW) 电弧焊25. manual arc welding 手工电弧焊26. core wire 焊芯27. coating (or covering) 药皮28. filler metal 填充金属29. base metal 母材金属30. weld 焊缝31. slag 熔渣32. gas welding 气焊33. welding wire 焊.丝34. submerged arc welding (SAW) 埋弧焊35. electroslag welding (ESW) 电渣焊36. metal inert-gas arc welding (MIG) 熔化极惰性气体保护焊37. wire-feeding mechanism(wire feeder)送丝机构38. arc stability 电弧稳定性39. electrode feed rate送丝速度40. electrode feed unit 送丝装置41. wire drive-roll 送丝滚轮42. wire reel 焊丝盘43. welded joint 焊接接头44. butt joint 对接接头45. corner joint 角接接头46. T joint T形接头47. lap joint 搭接接头48. edge joint 端接接头49. bond area 熔合区50 heat-affected zone热影响区51. flat position 平焊位置52. horizontal position 横焊位置53. vertical position 立焊位置54. overhead position 仰焊位置55. undercut 咬边56. overlap 焊瘤57. lack of fusion 未熔合58. molten metal熔池金属59. vertical down welding 向下立焊60. vertical up welding 向上立焊61. pinch effect 电磁收缩效应62. porosity 气孔63. molten iron 铁水64. stainless steel不锈钢65. carbon steel碳钢66. low-alloy steel低合金钢67. aluminum alloys铝合金68. heat input 热输入69. weld pool(molten pool; puddle)熔池70. electric arc电弧71. metal rod金属棒72. arc voltage 电弧电压73. travel rate (travel speed; welding speed; arc speed; torch speed)焊接速度74. electrode angle 焊丝角度75. nozzle-to-work distance 喷嘴与工件之间的距离76. gas-flow rate 气流速度77. penetration 熔深78. molten metal 熔融金属79. deposition rate熔敷速度80. contact tube(tip)导电嘴81. nozzle 喷嘴82. building up (surfacing, overlaying)堆焊83. welding position 焊接位置84. welding equipment 焊接设备85. preheat 预热86. wire extension (stickout) 焊丝伸出长度87. are length 弧长88. groove 坡口89. Self-shielded Flux Cored Process自保护药芯电弧焊90. Shielded Metal Arc Process(Shielded Metal Arc Welding SMAW)焊条电弧焊91. Gas Metal Arc Process/Welding (GMAW)熔化极气体保护电弧焊92. striking arc 引弧93. crater 弧坑94. crack 裂纹95. run-off tab 引出板96. oscillator 振荡器97. Gas Tungsten Arc Process (GTA)钨极气保焊98. square butt joint I形对接接头99. single V butt joint V形对接接头100. double V butt joint 双V形对接接头。
焊接常用中、英文术语定义及解释1 母材金属base mental, parent mental被焊金属材料的统称。
2 热影响区heat-affected zone焊接或切割过程中,材料因受热的影响(但未熔化)而发生金相组织和机械性能变化的区域。
3 过热区overheated zone焊接热影响区中,具有过热组织或晶粒显著粗大的区域。
4 焊缝weld焊件经焊接后所形成的结合部分。
5 焊缝区weld zone焊缝及其邻近区域的总称。
6 定位焊缝tack weld焊前为装配和固定构件接缝的位置而焊接的短焊缝。
7承载焊缝strength weld焊件上用作承受载荷的焊缝。
8 连续焊缝continuous weld连续焊接的焊缝。
9 断续焊缝intermittent weld焊接成具有一定间隔的焊缝。
10 纵向焊缝longitudinal weld沿焊件长度方向分布的焊缝。
11 横向焊缝transverse weld垂直于焊件长度方向的焊缝。
12 环缝girth weld, circumferential weld沿筒形焊件分布的头尾相接的封闭焊缝。
13 密封焊缝seal weld主要用于防止流体渗漏的焊缝。
14 并列断续角焊缝chain intermittent fillet weldT形接头两侧互相对称布置、长度基本相等的断续角焊缝。
15 交错断续角焊缝staggered intermittent fillet weldT形接头两侧互相交错布置、长度基本相等的断续角焊缝。
16 凸形角焊缝convex fillet weld焊缝表面突起的角焊缝。
17 凹形角焊缝concave fillet weld焊缝表面下凹的角焊缝。
18 焊缝正面face of weld焊后,从焊件的施焊面所见到的焊缝表面。
19 焊缝背面root surface焊后,从焊件施焊面的背面所见到的焊缝表面。
20 焊缝宽度weld width焊缝表面两焊趾之间的距离。
焊接专业术语中英对照焊接欠缺与检验焊接欠缺welding imperfection焊接缺陷weld defect气孔blowhole/ gas pore针尖状气孔pinhole密集气孔porosity条虫状气孔wormhole裂纹crack表面裂纹surface crack咬边undercut焊瘤overlap凹坑pit烧穿burn through塌陷excessive penetration未焊透incomplete penetration/ lack of penetration未熔合lack of fusion/ incomplete fusion 未焊满incompletely filled weld根部凹陷root concavity电弧擦伤arc scratch夹渣slag inclusion夹杂物inclusion夹钨tungsten inclusion白点fish eye/ flake错边misalignment/ dislocation焊接检验试件test piece试样test specimen无损检验nondestructive test破坏检验destructive test外观检查visual examination超声波探伤ultrasonic inspection直射法超声波探伤straight beam method斜射法超声波探伤angle beam method液浸法超声波探伤immersion method射线探伤radiographic inspection/ radiographyX射线探伤X-ray radiographic inspection γ射线探伤gamma-ray inspectionX射线工业电视探伤X-ray industrial television inspection磁粉探伤magnetic particle inspection电磁探伤electromagnetic inspection/ eddy current test 探伤灵敏度flaw detection sensitivity渗透探伤penetration inspection荧光探伤flurescent penetrant inspection 着色探伤dye penetrant inspection密封性检验leak test气密性检验air tight test枕形气密检验pillow test耐压检验pressure test水压检验hydraulic test气压检验pneumatic test液晶检验liquid crystal test声发射检测acoustic emission testing面弯试验face bend testing背弯试验root bend test侧弯试验side bend test横弯试验horizontal bend test纵弯试验axial bend test压扁试验squeezing testactual weld-throat thick-ness焊缝厚度all-around weld整周焊缝all-around weld (整周焊缝)环焊缝angle butt weld斜对接焊angle weld角焊appearance of weld焊缝成形arc-seam weld电弧缝焊arc-spot weld电弧点焊arc-weld电弧焊aspect ratio of weld焊缝成形系数at weld edge在焊缝边上attachment weld连接焊缝automatic spot weld自动点焊法automatic weld自动焊接axis of a weld焊缝行南? 焊接轴线axis of weld焊缝轴线; 焊接轴线back of weld焊缝背面backing groove of weld焊缝反面坡口backing weld底焊; 底焊焊缝bare metal arc weld裸焊条电弧焊bead weld珠焊; 堆焊bead-on-plate weld堆焊焊缝beading weld凸焊beam-to-beam weld梁间焊接; 梁式引线焊接block sequence weld分段多层焊bond weld钢轨接头焊接bridge seam weld桥缝焊接; 桥线焊brize weld硬焊页脚.butt weld对接焊缝butt weld ends对头焊接端butt-weld碰焊; 平式焊接; 对头焊接butt-weld in the downhand position对接平焊butt-weld joint对头焊接butt-weld pipe mill对焊管轧机button spot weld按电钮点焊cap weld最后焊层; 盖面焊缝carbon content of weld materials焊接材料的碳含量cast-weld construction铸焊结构caulk weld填缝焊caulking weld密实焊缝chain intermittent fillet weld链式分段角焊; 并列间断角焊缝chain intermittent weld并列焊接circular weld环形焊缝circumferential weld环缝; 环焊缝cleft weld裂口焊closed weld底边无缝焊; 无间隙焊缝closed-chamber fusion weld闭室熔焊cluster weld丛聚焊缝coil weld卷板对接焊; 卷板对接焊; 板卷焊cold weld冷压接commutator-controlled weld换向控制焊接complete penetration butt weld贯穿对焊composite weld紧密焊缝; 强度密封焊缝concave filled weld凹形角焊缝concave filler weld凹角焊concave fillet weld凹面填角焊concave weld凹焊缝; 凹面焊; 凹形焊缝; 轻型焊connective weld联系焊缝continuous butt-weld mill连续式炉焊管机组continuous fillet weld连续(填)角焊缝; 连续角焊缝; 连续贴角焊continuous weld连续焊缝continuous weld process连续式炉焊管法contour weld特形焊接convex fillet weld凸角焊缝; 凸形角焊缝convex weld凸焊缝; 凸形焊缝copper weld wire包铜钢丝corner flange weld单卷边角焊缝corner weld角焊corner-flange weld卷边角焊缝; 卷边角焊缝crack of weld焊部裂纹cross weld十字交叉焊缝; 横向焊缝cross-wire weld十字焊crotch weld楔接锻接; 楔接焊接cup weld带盖板焊缝depth of weld焊接深度dissimilar weld metal不同的焊接金属; 不同金属的焊接distance between the toes of a weld焊缝宽度double groove weld双面坡口焊缝double-bevel groove weld双斜边坡口焊缝; 双斜坡口焊double-flanged butt weld双弯边对接焊缝double-V groove weld双斜边坡口焊缝; 双斜坡口焊downhand weld平焊缝duplex spot weld双点点焊接头edge joint weld边缘焊edge weld端接焊; 端接焊缝; 端面焊缝; 对边焊electric resistance weld mill电阻焊管机electric weld-pipe mill电焊管机焊接专业英语词汇(通用部分)acetylene 乙炔 ampere 电流安培angle welding 角焊 arc 电弧argon arc welding 氩弧焊接 bare electrode 光熔接条butt welding 对接焊接 camber 电弧弯曲cascade 阶叠熔接法 clad weld 被覆熔接crator 焊疤 excess metal 多余金属filler rod 焊条 fillet weld 填角焊接gas shield 气体遮蔽 groove welding 起槽熔接hand face shield 手握面罩 hard facing 硬表面堆焊jig welding 工模焊接 laser beam welding 雷射光焊接metal electrode insert gas welding MIG熔接nugget 点焊熔核overlaying 堆焊 peening of welding 珠击熔接法plug welding 塞孔熔接 positioned welding 正向熔接pressure welding 压焊 propane gas cutting 丙烷气切割页脚.pure nickel electrode 纯镍熔接条reinforcement of weld 加强焊接resist 抗蚀护膜 root running 背面熔接seam 焊缝 seaming 接合seam welding 流缝熔接 series seam welding 串联缝熔接skip welding process 跳焊法 spark 火花spot welding 点焊接 stitch welding 针角焊接stud arc welding 电弧焊接 under laying 下部焊层void 焊接空隙 weld flow mark 焊接流痕weld flush 焊缝凸起 weld line 焊接纹weld mark 焊接痕 weld penetration 熔接透入weld zone 焊接区 welding 焊接welding bead 焊接泡 welding direction 焊接方向welding distortion 焊接变形 welding flux 焊剂welding ground 电熔接地 welding interval 焊接周期welding stress 熔接应变 welding torch 熔接气炬welding electrode production line 电焊条生产线welding electrode 焊条welding fixture 焊接夹具welding generator 电焊机welding goggles 焊工护目镜welding gun 焊枪welding helmet 电焊帽welding inspection ruler 焊接检验尺welding machine 焊接机welding mill 焊管机welding motor generator 电动焊接发电机welding nozzle 焊嘴welding paste 焊接药膏welding pipe 焊接管welding powder 焊粉welding rectifier 焊接整流器welding robot 焊接机器人welding rod extrusion press 焊条挤压机welding rod with acidic coating 酸性焊条welding rod with alkaline coating 碱性焊条welding rod 焊条welding simulator 焊接模拟器welding stainless electrode 不锈电焊条welding steel tube 焊接钢管welding tin billet 焊锡棒料welding tongs 焊接夹钳welding torch 焊炬welding transformer 电焊变压器welding unit 焊机welding wire machine 焊线机welding wire 焊丝welding-cutting hose 熔焊及切割胶管welding-cutting tool 焊割具welding-rod core 焊条芯welding-seam cleaner 焊缝清理机weldless pipe 无缝管weldless steel tube 无缝钢管well borer 凿井机well counter 井式计数器well deck vessel 井形甲板船well drill 钻井机well platform 钻井平台well rig 钻井机well testing truck 试井车well thermometer 井温计well tube filter 井管滤管well type tempering electric furnace 井式回火电炉well winch 矿井绞车well-logging probe 测井探头well-type counter 井型计数器Wella Balsam Conditioner 威娜宝护发素Wella Balsam shampoo 威娜宝香波Wellene 韦纶聚酯短纤维wellhead acid preventer 井口防酸器wellington 惠灵顿防雨呢Wellingtons 长筒皮靴Welltite 韦纶泰特聚丙烯和聚乙烯单丝Welsbach's alloy 韦尔斯巴赫发火合金Welsh flannel 威尔士法兰绒Welsh wool 威尔士粗羊毛welsh-onion stalk 葱白welsh-onion 葱welt cementing machine 贴边粘合机welt coloring machine 贴边染色机welt cutting machine 切沿条机welt fitting machine 贴边机welt footwear 加贴边的鞋页脚.welter screen 翻滚筛welter 镶边机Wepsin 三唑磷胺Werlisa 威里沙牌照相机Werner 维尔纳牌手表weskit 紧身背心Wessel silver 韦塞尔铜镍锌合金West cigarette 威狮牌香烟West ginseng 西洋参West Lake Dragon Well tea 西湖龙井茶West Lake silk umbrella 西湖绸伞West Lake silk 西湖丝绸West Lake water shield 西湖莼菜Westeeco 韦斯蒂科镍铬铁耐热合金Western king prawn 宽沟对虾Western saddle pants 西式马裤Western sand cherry 沙樱桃Western shirt 西式衬衫western style bed sheet 西式床单Western style hat 西式呢帽Western style pajamas 西式睡衣裤Western style pants 西裤Western style shirt 西式衬衫Western style shirt-waist blouse 西式衬衫上衣Western style suit 西服western tie 西式领带Western wool 美国西部羊毛Western-made shirt in plaid gingham 长方格贞咸布西式衬衫Westinghouse alloy 西屋镍铜热磁补偿合金wet spinning frame 湿纺细纱机wet air compressor 湿空气压缩机wet air pump 湿空气泵wet and dry bulb hygrometer 干湿球湿度计wet and dry bulb recording hygrometer 干湿球自记湿度计wet and dry bulb thermometer 干湿球温度计wet ball mill 湿式球磨机wet blue goat leather 山羊蓝湿革wet blue goat skin 蓝湿山羊皮wet board machine 湿式纸板机wet brush 湿刷wet chrome goat skin 铬湿山羊皮wet cleaner 湿法清洗器wet cloth 湿光布wet clutch 湿式离合器wet collector 湿式除尘器wet condenser 湿式冷凝器wet crude 含水原油wet crushing mill 湿粉碎机wet cylinder liner 湿式气缸套wet drill 湿式风钻wet dust collector 湿式收尘器wet dust separator 湿式除尘器wet electro-magnet 湿式电磁铁wet electrolytic capacitor 电解液电容器wet feeder 湿式给料机wet fiber filter 湿式纤维过滤器wet filter 湿式过滤器wet fourdrinier board machine 长网湿抄机wet frame 湿纺机wet furfural condenser 含水糖醛冷凝器wet gas meter 湿式气量计wet gas scrubber 湿法气体洗涤质量合格证书certification of fitness原材料rawmaterial底板 bottom plate垫层 cushion侧壁 sidewall中心线center line条形基础 strip footing附件 accessories型钢 profile steel钢板 steel plate熔渣 slag飞溅 welding spatter定位焊 tacking引弧 generating of arc熄弧 quenching of arc焊道 welding bead坡口 beveled edges外观检查 visual inspection重皮 doubleskin水平方向弧度 radian in horizontal direction 成型 molding直线度 straightness accuracy焊缝角变形 welding line angular distortion 水平度 levelness铅垂度 verticality翘曲变形 buckling deformation角尺 angle square页脚.对接焊缝 butt weld母材 parent metal法兰密封面 flange sealing surface夹层interlayer表面锈蚀浓度 surface corrosion concentration挠曲变 bending deformation超声波探伤 ultrasonic testing/ ultrasonic examination压力容器 pressure vessel预制下料prefabrication baiting排版直径 set-type diameter焊缝 welding line中幅板 ? center plate测量方法 measuring method基准点 datum mark跳焊 skip welding允许偏差 allowable variation补强板 stiffening plate开孔 tapping对接接头 banjo fixing butt jointing角钢 angle iron安装基准圆 installation fundamental circle 吊装立柱 hoisting upright column焊接钢管 welded steel pipe向心斜拉筋 centripetal canting pull rope 带板 band plate槽钢胀圈 channel steel expansion ring环口 collar extension局部变形 local distortion环缝 circumferential weld顶板 top plate拱顶 vault顶板加强肋 stiffening rib对接 butt joint胎具 clamping fixture卷板机 plate bending rolls中心支架 center bearing bracket椭圆度 ovality等分线 bisectrix搭接宽度lap width点焊spot welding搭接焊 overlap welding对称:symmetrically螺旋爬梯cockle stairs放料阀baiting valve 液位计 content gauge充水试验 filling water test错边量 unfitness of butt joint底圈 foundation ring真空度检漏 vacuum degree leak test丁字焊缝 tee welding渗透探伤 oil whiting test充水试验 filling water test侧角焊缝接头 interior angle welding line jointfoundation settlement 基础沉降测量基准点 datum mark?稳定性试验 stability test排气阀 outlet valve角钢 angle steel构件 component part机械损伤 mechanical damage缩孔 shrinkage cavityenfoldment 折迭碳钢管 carbon steel tube公称直径 nominal diameter预埋件 embedded part轴测图 axonometric drawing布置图arrangement diagram氧乙炔气割 oxyacetylene gas cutting低合金钢管low alloy steel热影响区 heat affected area修磨polish砂轮片grinding wheel等离子plasma panel重皮 coldlap凹凸unevenness缩口necking down端面 head face倾斜偏差 dip deviation外径 external diameter砂轮grinding wheel管件 pipe casting单线图single line drawing平齐parallel and level两端 two terminals满扣 buckle螺栓紧固 bolton周边 periphery附加应力 additional stress页脚.同轴度 axiality平行度 parallelism随机 stochastic允许偏差 allowable variation重直度verticality水平度 levelness隔离盲板 blind plate氩弧焊argon arc welding压盖螺栓 gland bolt间距spacing有效期 period of validity担任 take charge of ;undertake焊条 welding rod碳钢焊条carbon steel焊丝 welding wire熔化焊 melting钢丝 steel wire气体保护焊 gas shielded arc welding 烘干drying清洗ablution制度system焊接工艺welding procedure相应corresponding手工电弧焊manual electric arc welding 手工钨极 manual tungsten electrode打底render电源power source交流alternating current焊件 weldment管壁厚度 pipe thickness对接焊缝 butt weld工件壁厚 workpiece飞溅物 splash沾污 smirch油污 oil stain细锉 smooth file铣刀 milling cutter氧化膜 oxide film脱脂处理 ungrease treatment]棉质纤维 cotton fibre丙酮acetone硫 sulfur焊剂 welding flux钢板 steel plate纵向焊缝 l0ngitudinal weld l0ngitudinal seam筒节 shell ring 封头 end socket卷管 reelpipe强度试验strength test起弧arc starting穿堂风draught熔合fusion反面reverse side整体integral封堵block up焊口 weld bond医用胶布medical proof fabric高频 high frequency焊炬welding torch送气air supply焊接专业英语词汇(熔化焊)熔接fusion welding压接pressure welding焊接过程welding process焊接技术welding technique焊接工艺welding technology/procedure焊接操作welding operation焊接顺序welding sequence焊接方向direction of welding焊接位置welding position熔敷顺序build-up sequencedeposition sequence焊缝倾角weld slope/inclination of weld axis 焊缝转角weld rotation/angle of rotation平焊位置flat position of welding横焊位置horizontal position of welding立焊位置vertical position of welding仰焊位置overhead position of welding平焊downhand welding/flat position welding 横焊horizontal position welding立焊vertical position welding仰焊overhead position welding全位置焊all position welding:熔焊时,焊件接逢所处空间位置包括平焊、横焊、仰焊等位置所进行的焊接。
焊接专业术语中英对照焊接欠缺与检验焊接欠缺welding imperfection焊接缺陷weld defect气孔blowhole/ gas pore针尖状气孔pinhole密集气孔porosity条虫状气孔wormhole裂纹crack表面裂纹surface crack咬边undercut焊瘤overlap凹坑pit烧穿burn through塌陷excessive penetration未焊透incomplete penetration/ lack of penetration未熔合lack of fusion/ incomplete fusion 未焊满incompletely filled weld根部凹陷root concavity电弧擦伤arc scratch夹渣slag inclusion夹杂物inclusion夹钨tungsten inclusion白点fish eye/ flake错边misalignment/ dislocation焊接检验试件test piece试样test specimen无损检验nondestructive test破坏检验destructive test外观检查visual examination超声波探伤ultrasonic inspection直射法超声波探伤straight beam method斜射法超声波探伤angle beam method液浸法超声波探伤immersion method射线探伤radiographic inspection/ radiographyX射线探伤X-ray radiographic inspection γ射线探伤gamma-ray inspectionX射线工业电视探伤X-ray industrial television inspection磁粉探伤magnetic particle inspection电磁探伤electromagnetic inspection/ eddy current test 探伤灵敏度flaw detection sensitivity渗透探伤penetration inspection荧光探伤flurescent penetrant inspection 着色探伤dye penetrant inspection密封性检验leak test气密性检验air tight test枕形气密检验pillow test耐压检验pressure test水压检验hydraulic test气压检验pneumatic test液晶检验liquid crystal test声发射检测acoustic emission testing面弯试验face bend testing背弯试验root bend test侧弯试验side bend test横弯试验horizontal bend test纵弯试验axial bend test压扁试验squeezing testactual weld-throat thick-ness焊缝厚度all-around weld整周焊缝all-around weld (整周焊缝)环焊缝angle butt weld斜对接焊angle weld角焊appearance of weld焊缝成形arc-seam weld电弧缝焊arc-spot weld电弧点焊arc-weld电弧焊aspect ratio of weld焊缝成形系数at weld edge在焊缝边上attachment weld连接焊缝automatic spot weld自动点焊法automatic weld自动焊接axis of a weld焊缝行南? 焊接轴线axis of weld焊缝轴线; 焊接轴线back of weld焊缝背面backing groove of weld焊缝反面坡口backing weld底焊; 底焊焊缝bare metal arc weld裸焊条电弧焊bead weld珠焊; 堆焊bead-on-plate weld堆焊焊缝beading weld凸焊beam-to-beam weld梁间焊接; 梁式引线焊接block sequence weld分段多层焊bond weld钢轨接头焊接bridge seam weld桥缝焊接; 桥线焊brize weld硬焊文案大全butt weld对接焊缝butt weld ends对头焊接端butt-weld碰焊; 平式焊接; 对头焊接butt-weld in the downhand position对接平焊butt-weld joint对头焊接butt-weld pipe mill对焊管轧机button spot weld按电钮点焊cap weld最后焊层; 盖面焊缝carbon content of weld materials焊接材料的碳含量cast-weld construction铸焊结构caulk weld填缝焊caulking weld密实焊缝chain intermittent fillet weld链式分段角焊; 并列间断角焊缝chain intermittent weld并列焊接circular weld环形焊缝circumferential weld环缝; 环焊缝cleft weld裂口焊closed weld底边无缝焊; 无间隙焊缝closed-chamber fusion weld闭室熔焊cluster weld丛聚焊缝coil weld卷板对接焊; 卷板对接焊; 板卷焊cold weld冷压接commutator-controlled weld换向控制焊接complete penetration butt weld贯穿对焊composite weld紧密焊缝; 强度密封焊缝concave filled weld凹形角焊缝concave filler weld凹角焊concave fillet weld凹面填角焊concave weld凹焊缝; 凹面焊; 凹形焊缝; 轻型焊connective weld联系焊缝continuous butt-weld mill连续式炉焊管机组continuous fillet weld连续(填)角焊缝; 连续角焊缝; 连续贴角焊continuous weld连续焊缝continuous weld process连续式炉焊管法contour weld特形焊接convex fillet weld凸角焊缝; 凸形角焊缝convex weld凸焊缝; 凸形焊缝copper weld wire包铜钢丝corner flange weld单卷边角焊缝corner weld角焊corner-flange weld卷边角焊缝; 卷边角焊缝crack of weld焊部裂纹cross weld十字交叉焊缝; 横向焊缝cross-wire weld十字焊crotch weld楔接锻接; 楔接焊接cup weld带盖板焊缝depth of weld焊接深度dissimilar weld metal不同的焊接金属; 不同金属的焊接distance between the toes of a weld焊缝宽度double groove weld双面坡口焊缝double-bevel groove weld双斜边坡口焊缝; 双斜坡口焊double-flanged butt weld双弯边对接焊缝double-V groove weld双斜边坡口焊缝; 双斜坡口焊downhand weld平焊缝duplex spot weld双点点焊接头edge joint weld边缘焊edge weld端接焊; 端接焊缝; 端面焊缝; 对边焊electric resistance weld mill电阻焊管机electric weld-pipe mill电焊管机焊接专业英语词汇(通用部分)acetylene 乙炔 ampere 电流安培angle welding 角焊 arc 电弧argon arc welding 氩弧焊接 bare electrode 光熔接条butt welding 对接焊接 camber 电弧弯曲cascade 阶叠熔接法 clad weld 被覆熔接crator 焊疤 excess metal 多余金属filler rod 焊条 fillet weld 填角焊接gas shield 气体遮蔽 groove welding 起槽熔接hand face shield 手握面罩 hard facing 硬表面堆焊jig welding 工模焊接 laser beam welding 雷射光焊接metal electrode insert gas welding MIG熔接nugget 点焊熔核overlaying 堆焊 peening of welding 珠击熔接法plug welding 塞孔熔接 positioned welding 正向熔接pressure welding 压焊 propane gas cutting 丙烷气切割文案大全pure nickel electrode 纯镍熔接条reinforcement of weld 加强焊接resist 抗蚀护膜 root running 背面熔接seam 焊缝 seaming 接合seam welding 流缝熔接 series seam welding 串联缝熔接skip welding process 跳焊法 spark 火花spot welding 点焊接 stitch welding 针角焊接stud arc welding 电弧焊接 under laying 下部焊层void 焊接空隙 weld flow mark 焊接流痕weld flush 焊缝凸起 weld line 焊接纹weld mark 焊接痕 weld penetration 熔接透入weld zone 焊接区 welding 焊接welding bead 焊接泡 welding direction 焊接方向welding distortion 焊接变形 welding flux 焊剂welding ground 电熔接地 welding interval 焊接周期welding stress 熔接应变 welding torch 熔接气炬welding electrode production line 电焊条生产线welding electrode 焊条welding fixture 焊接夹具welding generator 电焊机welding goggles 焊工护目镜welding gun 焊枪welding helmet 电焊帽welding inspection ruler 焊接检验尺welding machine 焊接机welding mill 焊管机welding motor generator 电动焊接发电机welding nozzle 焊嘴welding paste 焊接药膏welding pipe 焊接管welding powder 焊粉welding rectifier 焊接整流器welding robot 焊接机器人welding rod extrusion press 焊条挤压机welding rod with acidic coating 酸性焊条welding rod with alkaline coating 碱性焊条welding rod 焊条welding simulator 焊接模拟器welding stainless electrode 不锈电焊条welding steel tube 焊接钢管welding tin billet 焊锡棒料welding tongs 焊接夹钳welding torch 焊炬welding transformer 电焊变压器welding unit 焊机welding wire machine 焊线机welding wire 焊丝welding-cutting hose 熔焊及切割胶管welding-cutting tool 焊割具welding-rod core 焊条芯welding-seam cleaner 焊缝清理机weldless pipe 无缝管weldless steel tube 无缝钢管well borer 凿井机well counter 井式计数器well deck vessel 井形甲板船well drill 钻井机well platform 钻井平台well rig 钻井机well testing truck 试井车well thermometer 井温计well tube filter 井管滤管well type tempering electric furnace 井式回火电炉well winch 矿井绞车well-logging probe 测井探头well-type counter 井型计数器Wella Balsam Conditioner 威娜宝护发素Wella Balsam shampoo 威娜宝香波Wellene 韦纶聚酯短纤维wellhead acid preventer 井口防酸器wellington 惠灵顿防雨呢Wellingtons 长筒皮靴Welltite 韦纶泰特聚丙烯和聚乙烯单丝Welsbach's alloy 韦尔斯巴赫发火合金Welsh flannel 威尔士法兰绒Welsh wool 威尔士粗羊毛welsh-onion stalk 葱白welsh-onion 葱welt cementing machine 贴边粘合机welt coloring machine 贴边染色机welt cutting machine 切沿条机welt fitting machine 贴边机welt footwear 加贴边的鞋文案大全welter screen 翻滚筛welter 镶边机Wepsin 三唑磷胺Werlisa 威里沙牌照相机Werner 维尔纳牌手表weskit 紧身背心Wessel silver 韦塞尔铜镍锌合金West cigarette 威狮牌香烟West ginseng 西洋参West Lake Dragon Well tea 西湖龙井茶West Lake silk umbrella 西湖绸伞West Lake silk 西湖丝绸West Lake water shield 西湖莼菜Westeeco 韦斯蒂科镍铬铁耐热合金Western king prawn 宽沟对虾Western saddle pants 西式马裤Western sand cherry 沙樱桃Western shirt 西式衬衫western style bed sheet 西式床单Western style hat 西式呢帽Western style pajamas 西式睡衣裤Western style pants 西裤Western style shirt 西式衬衫Western style shirt-waist blouse 西式衬衫上衣Western style suit 西服western tie 西式领带Western wool 美国西部羊毛Western-made shirt in plaid gingham 长方格贞咸布西式衬衫Westinghouse alloy 西屋镍铜热磁补偿合金wet spinning frame 湿纺细纱机wet air compressor 湿空气压缩机wet air pump 湿空气泵wet and dry bulb hygrometer 干湿球湿度计wet and dry bulb recording hygrometer 干湿球自记湿度计wet and dry bulb thermometer 干湿球温度计wet ball mill 湿式球磨机wet blue goat leather 山羊蓝湿革wet blue goat skin 蓝湿山羊皮wet board machine 湿式纸板机wet brush 湿刷wet chrome goat skin 铬湿山羊皮wet cleaner 湿法清洗器wet cloth 湿光布wet clutch 湿式离合器wet collector 湿式除尘器wet condenser 湿式冷凝器wet crude 含水原油wet crushing mill 湿粉碎机wet cylinder liner 湿式气缸套wet drill 湿式风钻wet dust collector 湿式收尘器wet dust separator 湿式除尘器wet electro-magnet 湿式电磁铁wet electrolytic capacitor 电解液电容器wet feeder 湿式给料机wet fiber filter 湿式纤维过滤器wet filter 湿式过滤器wet fourdrinier board machine 长网湿抄机wet frame 湿纺机wet furfural condenser 含水糖醛冷凝器wet gas meter 湿式气量计wet gas scrubber 湿法气体洗涤质量合格证书certification of fitness原材料rawmaterial底板 bottom plate垫层 cushion侧壁 sidewall中心线center line条形基础 strip footing附件 accessories型钢 profile steel钢板 steel plate熔渣 slag飞溅 welding spatter定位焊 tacking引弧 generating of arc熄弧 quenching of arc焊道 welding bead坡口 beveled edges外观检查 visual inspection重皮 doubleskin水平方向弧度 radian in horizontal direction 成型 molding直线度 straightness accuracy焊缝角变形 welding line angular distortion 水平度 levelness铅垂度 verticality翘曲变形 buckling deformation角尺 angle square文案大全对接焊缝 butt weld母材 parent metal法兰密封面 flange sealing surface夹层interlayer表面锈蚀浓度 surface corrosion concentration挠曲变 bending deformation超声波探伤 ultrasonic testing/ ultrasonic examination压力容器 pressure vessel预制下料prefabrication baiting排版直径 set-type diameter焊缝 welding line中幅板 ? center plate测量方法 measuring method基准点 datum mark跳焊 skip welding允许偏差 allowable variation补强板 stiffening plate开孔 tapping对接接头 banjo fixing butt jointing角钢 angle iron安装基准圆 installation fundamental circle 吊装立柱 hoisting upright column焊接钢管 welded steel pipe向心斜拉筋 centripetal canting pull rope 带板 band plate槽钢胀圈 channel steel expansion ring环口 collar extension局部变形 local distortion环缝 circumferential weld顶板 top plate拱顶 vault顶板加强肋 stiffening rib对接 butt joint胎具 clamping fixture卷板机 plate bending rolls中心支架 center bearing bracket椭圆度 ovality等分线 bisectrix搭接宽度lap width点焊spot welding搭接焊 overlap welding对称:symmetrically螺旋爬梯cockle stairs放料阀baiting valve 液位计 content gauge充水试验 filling water test错边量 unfitness of butt joint底圈 foundation ring真空度检漏 vacuum degree leak test丁字焊缝 tee welding渗透探伤 oil whiting test充水试验 filling water test内侧角焊缝接头 interior angle welding line jointfoundation settlement 基础沉降测量基准点 datum mark?稳定性试验 stability test排气阀 outlet valve角钢 angle steel构件 component part机械损伤 mechanical damage缩孔 shrinkage cavityenfoldment 折迭碳钢管 carbon steel tube公称直径 nominal diameter预埋件 embedded part轴测图 axonometric drawing布置图arrangement diagram氧乙炔气割 oxyacetylene gas cutting低合金钢管low alloy steel热影响区 heat affected area修磨polish砂轮片grinding wheel等离子plasma panel重皮 coldlap凹凸unevenness缩口necking down端面 head face倾斜偏差 dip deviation外径 external diameter砂轮grinding wheel管件 pipe casting单线图single line drawing平齐parallel and level两端 two terminals满扣 buckle螺栓紧固 bolton周边 periphery附加应力 additional stress文案大全同轴度 axiality平行度 parallelism随机 stochastic允许偏差 allowable variation重直度verticality水平度 levelness隔离盲板 blind plate氩弧焊argon arc welding压盖螺栓 gland bolt间距spacing有效期 period of validity担任 take charge of ;undertake焊条 welding rod碳钢焊条carbon steel焊丝 welding wire熔化焊 melting钢丝 steel wire气体保护焊 gas shielded arc welding 烘干drying清洗ablution制度system焊接工艺welding procedure相应corresponding手工电弧焊manual electric arc welding 手工钨极 manual tungsten electrode打底render电源power source交流alternating current焊件 weldment管壁厚度 pipe thickness对接焊缝 butt weld工件壁厚 workpiece飞溅物 splash沾污 smirch油污 oil stain细锉 smooth file铣刀 milling cutter氧化膜 oxide film脱脂处理 ungrease treatment]棉质纤维 cotton fibre丙酮acetone硫 sulfur焊剂 welding flux钢板 steel plate纵向焊缝 l0ngitudinal weld l0ngitudinal seam筒节 shell ring 封头 end socket卷管 reelpipe强度试验strength test起弧arc starting穿堂风draught熔合fusion反面reverse side整体integral封堵block up焊口 weld bond医用胶布medical proof fabric高频 high frequency焊炬welding torch送气air supply焊接专业英语词汇(熔化焊)熔接fusion welding压接pressure welding焊接过程welding process焊接技术welding technique焊接工艺welding technology/procedure焊接操作welding operation焊接顺序welding sequence焊接方向direction of welding焊接位置welding position熔敷顺序build-up sequencedeposition sequence焊缝倾角weld slope/inclination of weld axis 焊缝转角weld rotation/angle of rotation平焊位置flat position of welding横焊位置horizontal position of welding立焊位置vertical position of welding仰焊位置overhead position of welding平焊downhand welding/flat position welding 横焊horizontal position welding立焊vertical position welding仰焊overhead position welding全位置焊all position welding:熔焊时,焊件接逢所处空间位置包括平焊、横焊、仰焊等位置所进行的焊接。
焊接英语专业术语1.1焊接方法焊接方法与设备(Welding process& f acility)手工电弧焊(MAW:manual arc weldin g)电弧焊(arc weldi n)g埋弧电弧焊(S 横焊 horizontal welding立焊 vertical welding仰焊 overhead welding全位置焊 all position welding/positional welding半自动电弧焊 Semi-automatic arc w点焊机 spot welding machine缝焊机 seam welding machine对焊机 butt resistance welding machine凸焊机 projection welding machine2、焊接材料及焊接工艺(welding maA W:submerged arc welding)气焊(gas weldi n)g氩弧焊(argon arc weldi n)g气体保护电弧焊 CO2 保护焊(CO2 shie lded arc welding)熔化焊(GMAW —gas metal arc weldi n g)fusion welding 电渣焊(ESW—electr oslag welding)激光焊(L W—laster welding)等离子焊(PAW—plasma arc welding) 摩擦焊(FR W—friction welding)焊接压力焊超声波焊(U W—ultrason ic welding)welding pressure welding 冷压焊(C P W—cold pressure welding)锻焊(F W—forge-welding)对焊 but t welding电阻焊(R W—resistance welding) 缝焊 seam welding点焊 spot welding烙铁钎焊 iron soldering火焰钎焊 torch brazing/ torch sol dering钎焊炉中钎焊 furnace brazing/ fu rnace solderingsoldering/brazing 盐浴钎焊 saltba th dip brazing (soldering)真空钎焊 vacuum brazing堆焊 overlaying welding平焊 downhand welding/flat weldin g elding钨极惰性气体保护电弧焊 (TIG) tungsten inert-gas arc welding熔化极惰性气体保护电弧焊(MI G)m etal inert-gas arc welding1.2焊接设备电弧焊机 arc welding machine 直流弧焊机 DC arc welding machine 交流弧焊机 AC arc welding machine交直流两用弧焊机 AC/DC arc welding machine氩弧焊机 argon arc welding machine二氧化碳弧焊机 CO2 arc welding machine埋弧焊机 submerged arc welding machine焊接机头 welding head行走机构 traveller送丝机构 wire feeder焊丝盘 wire reel焊钳 electrode holder焊枪 welding gun碳弧气割 carbon arc air gouging火焰气刨 flame gouging焊接夹具 welding jig/ fixture等离子弧焊机 plasma arc welding machine等速送丝方式 constant wire-feed system变速送丝方式 alternate wire-feedsystemterials&procedur)e2.1焊接材料碳钢 carbon steel合金钢 alloy steel不锈钢 stainless steel耐热钢 high-temprature steel 铸铁 casting铜/黄铜 copper青铜 bronze铝 aluminium镁 magnisium钛 titanium钨 tungsten镍 nickel铬 chromium2.2焊接工艺焊接技能 welding technique焊接方法 welding process焊接工艺 welding procedure焊接操作 welding operation焊接顺序 welding sequence焊接方向 welding progress焊缝宽度 weld width焊缝厚度 weld throat焊缝余高 weld reinforcement焊缝长度 weld length焊接参数 welding parameter焊接电流 welding current焊接速度 welding speed焊接电压 welding voltage焊接变形 welding deformation根部间隙 root opening•焊接缺陷与检验(welding defects and inspection )1、 焊接缺陷焊缝正面 face of weld焊缝背面 root surface of weld 对接接头 butt joint 角接接头 corner joint 焊接性 weldability T 型接头 T- joint 搭接接头 lap joint 十字接头 cruciform joint 热影响区 heat-affected zone 接头设计 joint design 熔合线 weld interface 过热区 overheated zone 后热 postheat 预热 preheat熔深 depth of fusion 焊 道 weld bead焊缝成型系数 form factor of the w eld碳当量 carbon equivalent 焊接经验 welding experience 考试机构 examining body焊接工艺规程 (WPS ) welding proce dure specification标准焊接工艺规程 (SWPS )standard welding procedure specification 工艺评定记录( P Q R ) procedure qual ification record焊接工艺预规程 (pWPS )preliminary welding procedure specification 试验的焊接材料 tested welding mat erials/consumable焊接管理人员 welding co-ordinatio n/manage personnel预生产焊接试验 pre-production wel ding test3、 焊接缺陷与无损检验(welding de fects and non-destructive te )st 3.1 焊接缺陷夹渣 slag inclusion 夹钨 tungsten inclusion 夹杂物 inclusion 白 点 fish eye 气孔 porosity 烧穿 burn-through 咬边 undercut焊接裂纹 welding crack 焊瘤 overlap 弧坑裂纹 crater crack 弧坑 pit/crater 热裂纹 hot crack 冷裂纹 cold crack 延迟裂纹 delayed crack 层状撕裂 lamellar tearing 纵向裂纹 longitudinal crack 横向裂纹 transverse crack 焊接应变 welding strain焊接残余应力 welding residual str ess焊接应力 welding stress焊接变形 welding deformation 未焊透 incomplete penetration, la ck of penetration未熔合 incomplete fusion,lack of penetration 3.2 无损检验 试件 test piece 试样 test specimen无损检验 non-destuctive test/exam ination裂纹试验 cracking test外观检验 visual examination 耐压试验 pressure test射线探伤 radiographic inspection 面弯试验 face bend testing 超声波探伤 ultrasonic inspection 背弯试验 root bend test磁粉探伤 magnetic particle inspec tion侧弯试验 side bend testX 射线探伤 X-ray radiographic insp ection横弯试验 horizontal bend test 破坏检验 destructive test 纵弯试验 axial bend test渗透探伤 penetration/transmission inspection4、 焊接生产及安全(welding produ ction&safet )y焊接工作台 welding bench 焊接操作台 welding manipulator 焊接变位器 welding positioner 焊工升降台 welder’s lifting platf orm质量检查 QC=quality control 质量保证 QA=quality assurance 焊接车间 welding shop 面罩 helmet滤光玻璃 filter plate 焊工手套 welder’s glove 电焊电缆 Welding cable 电焊发动机 Welding generator 焊接电源 Welding source 电焊工 manual arc welder 气焊工 gas welder 焊 把 weld handle 焊 枪 welding pistol 焊接烟尘 welding fume 防护鞋 shielding shoes焊工尘肺 pheumocomsis of welder 焊接检验员 weld inspector焊工合格证 welder qualification c ertification焊工操作资格 welder performance/o peration qualification在焊接过程中,由于受到材质、结构、工艺、操作等因素的影响,焊接接头区域常产生各种各样的缺陷,这些缺陷将直接影响焊接接头的使用寿命和安全。
Aactual weld-throat thick-ness焊缝厚度all-around weld (整周焊缝)环焊缝angle butt weld斜对接焊angle weld角焊appearance of weld焊缝成形arc-seam weld电弧缝焊arc-spot weld电弧点焊arc-weld电弧焊arc welding 弧焊aspect ratio of weld焊缝成形系数at weld edge在焊缝边上attachment weld连接焊缝automatic spot weld自动点焊法automatic weld自动焊接axis of a weld焊缝中心线; 焊接轴线axis of weld焊缝轴线; 焊接轴线arc seam weld电弧缝焊缝arc spot weld 电弧焊点arc strike 碰弧as–brazed 钎接态as–welded 焊态argon (shielded) arc welding氩弧焊接argon tungsten-arc welding钨极氩弧焊argon-arc welding氩弧焊argonaut welding自动氩弧焊atomic H welding氢原子焊atomic hydrogen welding原子氢焊atomic-hydrogen welding原子氢焊接austenite welding不锈钢焊接autogenous pressure welding自动压合热焊autogenous welding气焊automatic arc welding head自动电弧焊接机头automatic arc welding machine自动电焊机; 自动弧焊机automatic drying line for welding electrode电焊条自动烘焙线automatic slag pool welding自动电渣焊automatic spot welding自动点焊automatic submerged arc welding自动埋弧焊automatic submerged slag welding of rail钢轨自动埋弧电弧焊automatic submerged-arc welding machine埋弧自动焊机automatic transverse welding横向自动焊automatic welding自动焊; 自动焊接automatic welding head自动焊头automatic welding machine自动焊接机automatic welding of circumferential seams环缝自动焊automatic welding process自动焊接工艺规程automation of welding焊接自动化arc-welded pipe弧焊管arc-welded steel pipe电弧焊接钢管around openings for welded attachments环绕焊接附件孔口as welded焊态as-welded焊后状态automatic arc welded tube自动电弧焊缝管air-acetylene welding空气-乙炔焊接argon arc welding 氩弧焊automatic slag-pool welding 自动电渣焊aircomatic welding 自动调弧氩弧焊, 惰性气体保护金属极弧焊aluminothermic welding 铸焊, 铝热剂焊接austenite welding 不锈钢(焊条)焊接automatic submerged arc welding 自动埋弧焊argon shielded arc welding 氩护电弧焊all-welded全焊接all-welded construction全焊构造automatic spot weld 自动点焊法AC & D. C. arc welding machine交直流弧焊机AC arc welding交流电弧焊AC gas metal-arc welding process交流熔化极气保护焊AC gas tungsten arc welding交流钨极气保护焊AC welding set交流焊机; 交流焊接变压器AC-dc welding machine交直流两用焊机acetylene welding气焊; 乙炔焊; 乙炔焊接acetylene welding torch乙炔焊炬; 乙炔接焊吹管air-acetylene welding空气-乙炔焊接all-position welding全位置焊接alloy steel gas welding rod合金钢气焊条alternating current arc welding交流电弧焊alternating current welding machine交流电焊机aluminium alloy arc welding electrode铝合金焊条aluminothermic welding铝热焊; 铸焊angle backwards welding后倾焊axial bend test纵弯试验angle butt welding斜口对接焊angle forwards welding前倾焊annealing welding wave退火焊波antogenous welding氧炔焊apparatus for butt welding平接压焊夹具arc braze welding电弧钎焊arc flash welding电弧闪光焊arc spot welding电铆焊arc stud welding柱钉电弧焊; 螺柱电弧焊arc voltage feedback controlling arc welding弧压反应电弧焊arc welding电弧焊; 电弧焊接; 弧焊arc welding electrode电弧焊条arc welding generator电弧焊接用发电机; 弧焊发电机arc welding generator with independent excitation自激弧焊发电机; 他激电焊发电机arc welding generator with self-excitation自激电焊发电机arc welding machine弧焊机; 电焊机; 电弧焊机arc welding mask电弧焊遮罩arc welding process电弧焊接工艺过程arc welding rectifier弧焊整流器arc welding robot弧焊机器人arc welding set电弧焊机组arc welding transformer弧焊变压器arc-welding electrode电弧焊用焊条arc-welding plant电焊厂arcogen welding电弧氧乙炔焊air-acetylene welding空气-乙炔焊接aircomatic welding自动调弧氩弧焊, 惰性气体保护金属极弧焊aluminothermic welding铸焊, 铝热剂焊接argon arc welding氩弧焊argon shielded arc welding氩护电弧焊austenite welding不锈钢(焊条)焊接automatic slag-pool welding自动电渣焊automatic submerged arc welding自动埋弧焊Bback of weld焊缝反面back gouging 反面清根backing 衬垫backing gas 反面保护气base metal 母材backing groove of weld焊缝反面坡口backing weld底焊; 底焊焊缝bare metal arc weld裸焊条电弧焊bead weld珠焊; 堆焊bead-on-plate weld堆焊焊缝beading weld凸焊beam-to-beam weld梁间焊接; 梁式引线焊接block sequence weld分段多层焊bond weld钢轨接头焊接bridge seam weld桥缝焊接; 桥线焊brize weld硬焊braze 钎接接头brazer 钎接工brazing 钎接butt weld对接焊缝butt weld ends对头焊接端butt-weld碰焊; 平式焊接; 对头焊接butt-weld in the downhand position对接平焊butt-weld joint对头焊接butt-weld pipe mill对焊管轧机button spot weld按电钮点焊back hand welding后退焊; 反手焊接back step welding反手焊接back ward welding反手焊接back welding底焊; 退焊法back-step welding分段退焊法backhand welding逆向焊; 右焊法; 后焊法; 向后焊backing welding打底焊backstep welding分段逆焊; 分段退焊; 反向焊; 逐步退焊法; 逆向焊 backstep welding sequence分段退焊次序backward welding后倾焊; 后退焊; 向右焊balanced welding对称焊bare welding rod光焊条bare wire arc welding光焊丝电弧焊bead welding窄焊道焊接bench arc welding machine台式弧焊机bevel welding斜角焊blacksmith welding锻工焊接; 锻焊block sequence welding分段多层焊; 分段连续焊接block welding块焊接big diameter welded tube大口径焊缝管blacksmith welded joint煅接接头butt welded (bw)对焊机butt welded seam对焊缝butt-welded drill对头焊接钻头butt-welded joint对焊接头butt-welded pipe对缝焊接收butt-welded rail ends对焊轨端butt-welded tube对缝焊管; 对焊钢管; 对口焊接钢管butt-welded with square ends方头对焊braze welding硬焊, 铜焊, 钎焊butt welding对接焊, 对焊butt weld对接焊缝blasting welding factory爆破焊接厂braze welding 硬焊, 铜焊, 钎焊butt welding 对接焊, 对焊butt weld 对接焊缝backing run; backing weld打底焊道block welding sequence分段多层焊body welding machine罐身焊接机both sides welding双面焊接brass welding rod黄铜焊条braze welding钎焊; 钎焊接; 钎接; 铜焊braze-welding钎接焊bridge spot welding带接合板点焊; 单面衬垫点焊; 单面搭板点焊 bridge welding桥接焊; 盖板焊brize welding硬焊build (built) up welding堆焊build-up welding堆焊building-up by welding堆焊butt resistance welding电阻对焊; 对接电阻焊butt seam welding对接滚焊butt seam welding machine对接缝焊机butt welding对接焊; 平对焊butt welding machine对接焊机butt welding process对接焊法butt-welding对接焊butt-welding machine对焊机Ccap weld最后焊层; 盖面焊缝carbon content of weld materials焊接材料的碳含量cast-weld construction铸焊构造caulk weld填缝焊contour weld 特形焊接concave fillet weld 凹角焊carbon arc weld 碳极弧焊capability of welding vertically upwards直上焊接才能capacitor-discharge welding电容放电焊接carbon arc welding碳弧焊; 碳极弧焊carbon in materials for welding焊接用材料中的碳carbon-dioxide arc welding二氧化碳保护焊carriage of automatic welding machine自动焊机走架cascade welding阶梯式焊; 山形多层焊cascade welding sequence串级叠置法cast welding铸焊concave fillet weld凹形角焊缝carbon arc weld碳极弧焊concave fillet weld凹角焊contour weld特形焊接cement-welding金属陶瓷焊接centralized installation of welding machine多站焊接chain intermittent fillet welding并列断续角焊缝; 链式断续角焊chemical welding化学焊circular seam welding环缝对接焊circular seam-welding machine环形滚焊机cleaning before welding焊接前的清理cleaning of welding deposits焊接沉积的清理closed butt gas pressure welding闭式加压气焊cold welding冷焊; 冷压焊cold-pressure welding冷压焊combined cutting and welding torch焊割两用炬combined cutting and-welding blow-pipe焊割两用炬combined thermit welding加压铸焊complete penetraction and fusion in welding全焊透complete fusion 完全熔合caulking weld密实焊缝chain intermittent fillet weld链式分段角焊; 并列连续角焊缝chain intermittent weld并列焊接circular weld环形焊缝circumferential weld环缝; 环焊缝cleft weld裂口焊closed weld底边无缝焊; 无间隙焊缝closed-chamber fusion weld闭室熔焊cluster weld丛聚焊缝coil weld 卷板对接焊; 卷板对接焊; 板卷焊cold weld 冷压接commutator-controlled weld 换向控制焊接complete penetration butt weld 贯穿对焊composite weld 严密焊缝; 强度密封焊缝concave filled weld 凹形角焊缝concave filler weld 凹角焊concave fillet weld 凹面填角焊concave weld 凹焊缝; 凹面焊; 凹形焊缝; 轻型焊connective weld 联络焊缝continuous butt-weld mill 连续式炉焊管机组continuous fillet weld连续(填)角焊缝; 连续角焊缝; 连续贴角焊continuous weld 连续焊缝continuous weld process连续式炉焊管法contour weld 特形焊接convex fillet weld 凸角焊缝; 凸形角焊缝convex weld 凸焊缝; 凸形焊缝copper weld wire 包铜钢丝corner flange weld 单卷边角焊缝corner weld 角焊corner-flange weld 卷边角焊缝; 卷边角焊缝crack of weld 焊部裂纹cross weld十字穿插焊缝; 横向焊缝cross-wire weld十字焊crotch weld 楔接锻接; 楔接焊接cup weld 带盖板焊缝condenser (discharge) spot-welding machine 电容器放电点焊机 condenser discharge spot welding 电容储能点焊; 电容贮能点焊 constant current welding machine 恒流电焊机constant energy welding machine 恒功率电焊机constant voltage welding machine 恒压电焊机constant-current arc welding power source 垂降特性弧焊电源constant-current welding source 恒流式焊接电源constant-power welding source 恒功率式焊接电源constant-pressure pressure welding 恒压压力焊constant-temperature pressure welding恒温压力焊constant-voltage welding machine恒电压焊机constant-voltage welding source恒压式焊接电源; 平特性焊接电源 consumable electrode welding 熔化极电弧焊consumable guide electroslag welding自耗定向电渣焊contact welding 接触焊continuous feed welding 连续送丝电弧焊continuous welding 连续焊; 连续焊接contour welding 绕焊controlled arc welding 可控电弧焊接controlled atmosohere arc welding 充气室电弧焊controlled atmospere arc welding 充气式电弧焊controlled tungsten-arc welding 自动控制弧长的钨极电弧焊 controlled-transfer welding 可控过渡电弧焊convex fillet welding 凸面角焊缝copper arc welding electrode 铜焊条copper welding rod 铜焊条copper-alloy arc welding electrode 铜合金焊条copper-aluminium welding rod 铜铝焊条copper-nickel welding rod 铜镍焊条copper-silicon welding rod 铜硅焊条copper-tin welding rod 铜锡焊条copper-zinc welding rod 铜锌焊条core welding-wire 焊芯core wire for welding rod 焊条芯线corrosion due to welding 焊接腐蚀cosmetic welding 盖面焊cover chain welding 链节式药皮包丝焊接CO2arc welding machine 二氧化碳弧焊机cracking test for automatic welding 自动焊抗裂试验crankshaft flashbutt welding 曲轴电阻弧花压焊cross welding 横向焊缝cyc-arc welding 圆环电弧焊cast welded rail joint 铸焊钢轨接头continuous welded rail 连续焊接钢轨carbon arc welding 碳弧焊carbon dioxide gas arc welding二氧化碳气体保护焊Ddepth of weld焊接深度dissimilar weld metal不同的焊接金属; 不同金属的焊接distance between the toes of a weld焊缝宽度double groove weld双面坡口焊缝double-bevel groove weld双斜边坡口焊缝; 双斜坡口焊double-flanged butt weld双弯边对接焊缝double-V groove weld双斜边坡口焊缝; 双斜坡口焊downhand weld平焊缝duplex spot weld双点点焊接头deck welding重力焊double fillet welded T-joint双面丁字形焊接double-welded butt joint双面焊对接接头double-welded lap joint双面焊搭接接头deep fillet welding深熔角焊downhand welding俯焊downward welding平焊, 俯焊downhand weld 平焊缝double-bevel groove weld 双斜边坡口焊缝, K形坡口焊缝deep fillet welding深角焊deep penetration welding深熔焊deep penetration welding electrode深熔焊条deep welding深焊die welding模焊; 冲模堆焊diesel engine driven DC arc welding machine柴油机驱动直流弧焊机 differential-excited welding generator差激电焊发电机diffusion welding扩散焊接direct spot welding双面点焊direct welding双面点焊direction of welding焊接方位; 焊接方向discontinuous welding断续焊dot welding点焊double carbon-arc welding间接碳弧焊double side welding双面焊接down-hand welding俯焊downhand welding平焊downward welding in the inclined position下坡焊downward welding in the vertical position向下立焊dual-arc welding双弧焊double-bevel groove weld双斜边坡口焊缝, K形坡口焊缝downhand weld平焊缝Eedge joint weld边缘焊edge weld端接焊; 端接焊缝; 端面焊缝; 对边焊electric resistance weld mill电阻焊管机electric weld-pipe mill电焊管机groove weld坡口焊; 坡口焊缝; 有坡口焊缝; 凹槽焊electric-weld pipe mill电焊管机emporary weld临时点定焊缝excess weld metal焊补缀强金属; 补强; 补强焊料; 补强金属excess weld metal(焊缝的)余高electric welded anchor cable电焊锚链electric welded steel pipe电焊钢管electric-resistance-welded steel pipe电阻焊钢管electric-welded pipe电焊管electrically welded tube电焊管expanded and welded tube joint胀焊electric butt welding welding电阻接触焊electrogas welding气电焊electrogas flux-cored welding气电管状焊条焊接electro-beam welding电子束焊接electrode [electrical arc] welding电弧焊electron-bombardment welding真空电子束焊electronic arc welding直流电弧焊electrons leaves welding电子束焊接electropercussive welding电冲击焊, 电接触焊, 电点焊 electroslag welding电渣焊electrostatic percussion welding静电焊接eutectic welding低温焊exothermic welding铝热焊edge seam welding端面接头滚焊edge welding边缘焊接edgewise welding沿边焊接electric and pressure welding电压力焊接electric arc spot welding电弧点焊electric arc welding generators电弧焊接发电机electric arc welding machine电弧焊机electric butt welding电阻接触焊electric resistance welding电阻焊接; 热电阻焊electric slag welding电渣焊electric spot welding电点焊electric welding电焊electric welding cast copper solder铸铜电焊条electric welding equipment电焊设备electric welding generator电焊发电机electric welding hammer电焊锤electric welding machine电焊机electric welding plant电焊厂electric welding pliers电焊钳electric welding rod电焊条electric welding strip电焊片electric-arc welding电弧焊electric-resistance seam-welding电阻缝焊edge weld端接焊缝explosive weld 爆炸焊接explosive weld爆炸焊接Fface of weld焊缝外表; 焊接面fibrous weld纤维状焊缝field weld现场焊接filler weld填角焊缝fillet weld角焊缝; 填角焊; 贴角焊fillet weld in normal shear (搭接接头的)正面角焊缝fillet weld in parallel shear侧面角焊缝; 侧面填角焊fillet weld in the flat position角接平焊; 程度角焊缝fillet weld in the horizontal position横向角焊缝fillet weld size焊角尺寸; 填角焊缝尺寸flame weld火焰焊接flange weld卷边焊缝; 卷边焊缝flange-to-web weld卷边焊缝; 卷边焊缝flanged butt weld弯边对接焊flanged edge weld卷边焊; 卷边焊flash butt weld闪光焊flash weld闪速对焊flat faced fillet weld平顶角焊缝焊接flat fillet weld平角焊ing of fillet weld角焊缝平焊; 船形角焊flush fillet weld平角焊flush weld削平补强的焊缝; 平焊接; 无加强高的焊缝forge weld锻焊焊缝forged weld (焊后锻压的)锻压焊缝form factor of the weld焊缝成形系数formation of weld焊缝成形front fillet weld正侧面填角焊缝; 正面填角焊front(al) fillet weld正面角焊缝full fillet weld满角焊缝; 全角焊full penetration butt weld满对接焊full weld满焊full-fillet weld满角焊full-sized weld全尺寸焊缝full-strength weld (与母材等强)等强焊缝fillet welding in the downhand position船形角焊fillet welding in the flat position船形焊fillet welding in the horizontal position横角焊fillet welding in the vertical position立角焊fine welding精细焊接fine wire welding细丝焊fire cracker welding躺焊fire welding锻焊; 锻接fixed welding machine固定式焊机fixed-position welding定位焊接flame welding熔气焊flare welding喇叭形坡口焊接flash butt welding闪光对焊; 闪光对接焊flash welding闪光电弧焊; 闪光焊; 闪焊; 火花电弧焊; 火花对焊 flash-butt welding电阻闪光焊接flashover welding闪光焊flat position welding平焊; 顶面平卧焊flat position welding of fillet weld角焊缝平焊; 船形角焊flat welding平卧焊flexible welding rod软焊条flexible wire for electric welding电焊软线flow welding流注焊接; 浇焊fluid welding流焊flux-cored welding包芯焊条焊接fly-wheel type friction welding贮能摩擦焊; 储能摩擦焊flywheel friction welding惯性摩擦焊forehand welding向前焊; 向左焊; 左焊法; 左向焊; 正手焊forge welding锻焊; 锻接焊forward welding正手焊; 左焊法; 左向焊; 前进焊; 前倾焊; 向前焊 friction welding摩擦焊; 摩擦焊接friction welding machine摩擦焊接机frontal fillet welding正面角焊full automatic welding全自动焊full-automatic arc welding全自动电弧焊full-fillet welding满角焊full-fusion thermit welding热剂铸焊full-fusion welding全熔合焊full-length welding满焊fusion pressure welding熔化压接fusion thermit welding热剂熔焊; 熔化铝热焊fusion type plasma arc welding熔透型等离子弧焊fusion type welding熔透型焊接法fusion welding熔焊接forge-welded (monolayered) cylinder锻焊式单层圆筒forged and welded vessel锻焊式容器fine welding精细焊接fine wire welding细丝焊接fire cracker welding躺焊fixed-position welding定位焊接flare welding喇叭形坡口焊接flash butt welding闪光对接焊flat position welding(顶面)平卧焊flux-cored welding包芯焊条焊接flat position of welding平焊位置forehand welding顺手焊接foreward welding左焊法fusion welding熔焊fusion pressure welding熔化压接fusion thermit welding熔化铅热焊furnace butt-welded pipe对接炉焊管flywheel type friction welding; inertia welding储能摩擦焊fusion welding metal熔焊金属fabrication weldability工艺焊接性Ggap weld特殊点焊; 双极单点焊gas-pressure weld气压焊girth weld环形焊缝gravity weld倚焊groove-weld joint有坡口焊接接头galvanized and welded steel pipe镀锌焊缝钢管galvanized electric welded mesh镀锌电焊网galvanized welded tube镀锌焊缝管galvanized welded wire mesh镀锌电焊网gas welded joint气焊接头guided-bend test for butt welded joint对接接头靠模弯曲试验 gas-electric welding气电结合焊接gas metal arc welding气体保护金属极电弧焊, 熔化极气体保护焊 gas shielded arc welding气体保护焊, 气体保护弧焊gas shielded magnetic flux arc welding磁性焊剂气体保护焊gas tungsten arc welding钨电极惰性气体保护焊girth welding环缝焊接gravity welding重力焊, 重力式电弧焊gas carbon-arc welding气保护碳弧焊gas electric welding气电结合焊接gas metal arc welding气体保护金属极电弧焊gas metal-arc welding气保护金属极电弧焊gas shield welding气体保护弧焊gas shielded arc welding气体保护电弧焊; 气体保护焊gas shielded arc welding machine气保护弧焊机gas shielded arc-welding machine气体保护弧焊机gas shielded magnetic flux arc welding磁性焊剂气体保护电弧焊 gas shielded metal-arc welding气体保护金属弧焊gas shielded welding气体保护焊gas torch welding气炬焊gas tungsten arc welding气体保护钨极电弧焊gas tungsten-arc welding气保护钨极电弧焊gas tungstun arc welding钨极气体保护焊gas welding气焊; 乙炔焊gas welding device气焊设备gas welding equipment气焊设备gas welding machine气焊机gas welding outfit气焊机gas welding rod气焊焊丝gas welding rubber hose气焊橡胶管gas welding technique气焊工艺gas welding torch butt气焊进气硬管gas welding tube mill瓦斯焊接机gas welding work气焊工作gas-arc welding气电焊; 气体保护电弧焊gas-arc welding gun气电焊焊嘴gas-press welding气压焊gas-pressure welding machine气压焊接机gas-shielded stud welding气保护柱钉焊接girth welding环缝横向焊接gravity type arc welding重力焊gravity type welding倚焊gravity welding重力焊; 重力式电弧焊groove welding槽焊; 坡口焊; 开槽焊guided automatic welding导向自动焊接gun welding machine手提式点焊机; 点焊枪groove weld 坡口焊gas-pressure weld气压焊 groove weld坡口焊。
air-acetylene welding空气-乙炔焊接aircomatic welding自动调弧氩弧焊, 惰性气体保护金属极弧焊aluminothermic welding铸焊, 铝热剂焊接argon arc welding氩弧焊argon shielded arc welding氩护电弧焊austenite welding不锈钢(焊条)焊接automatic slag-pool welding自动电渣焊automatic submerged arc welding自动埋弧焊braze welding硬焊, 铜焊, 钎焊butt welding对接焊, 对焊carbon arc welding碳弧焊carbon dioxide gas arc welding二氧化碳气体保护焊deep fillet welding深熔角焊downhand welding俯焊downward welding平焊, 俯焊electric butt welding welding电阻接触焊electrogas welding气电焊electrogas flux-cored welding气电管状焊条焊接electro-beam welding电子束焊接electrode [electrical arc] welding电弧焊electron-bombardment welding真空电子束焊electronic arc welding直流电弧焊electrons leaves welding电子束焊接electropercussive welding电冲击焊, 电接触焊, 电点焊electroslag welding电渣焊electrostatic percussion welding静电焊接eutectic welding低温焊exothermic welding铝热焊fine welding精密焊接fine wire welding细丝焊接fire cracker welding躺焊fixed-position welding定位焊接flare welding喇叭形坡口焊接flash butt welding闪光对接焊flat position welding(顶面)平卧焊flux-cored welding包芯焊条焊接forehand welding顺手焊接foreward welding左焊法fusion welding熔焊fusion pressure welding熔化压接fusion thermit welding熔化铅热焊gas-electric welding气电联合焊接gas metal arc welding气体保护金属极电弧焊, 熔化极气体保护焊gas shielded arc welding气体保护焊, 气体保护弧焊gas shielded magnetic flux arc welding 磁性焊剂气体保护焊gas torch welding气炬焊gas tungsten arc welding钨电极惰性气体保护焊girth welding环缝焊接gravity welding重力焊, 重力式电弧焊hammer welding锻接hard facing arc welding表面加硬电弧焊heated-tool welding热烙铁焊接helium shielded welding氦气保护焊接hidden arc welding潜弧焊, 埋弧焊high-frequency induction welding高频感应焊接horizontal fillet welding水平角焊接horizontal-rolled-position welding滚动水平焊, 水平转动焊接hydrogen atomic welding原子氢焊接induction resistance welding感应电阻焊接indirect spot welding间接点焊inert gas shielded-arc welding惰性气体保护焊inert gas tungsten arc welding钨板惰性气体保护焊inertial welding惯性焊接jump welding丁字形焊keyhole mode plasma arc welding小孔型等离子弧焊接lap welding搭焊; 搭头焊接lap fillet welding搭角焊light ga(u)ge welding薄板焊接line welding(电阻)缝焊liquid metal welding熔焊, 浇注补焊longitudinal seam welding纵缝焊接, 纵向滚焊(焊缝)magnetic discharge welding电磁焊magnetic-force welding磁力焊接法manual eletro-slag welding手工电渣焊mash stitch welding多针缝式焊接match assemble welding装架焊接metal barie welding埋渣焊microgap welding微隙间隙焊micro resistance welding显微电阻焊mitre welding斜接焊接multiple-electrode welding多焊条焊接multiple-impulse welding多脉冲焊multiple projection welding多点凸焊multiple resistance welding复式电阻焊multiple-wire multiple-power submerged-arc welding 多丝埋弧焊multi-run welding多道焊narrow gap one side welding窄间隙单面焊non-gas shielded arc welding无气体保护电弧焊non-vacuum electron beam welding 大气压电子束焊接open arc welding明弧焊接open butt gas pressure welding开式加压气焊orbit welding环形轨道自动焊接overhead position welding仰焊overlap welding搭接焊overlaying welding堆焊, 补焊pad welding垫块焊接parallel gap welding平行间隙焊接, 平行间隙熔焊penetration fusion welding深熔焊接percussion arc pile-up welding振动电弧堆焊percussive welding锻接pile-up welding堆焊pinpoint welding点焊plasma-MIG welding等离子熔化极气体保护焊plate electrode slag pool welding 板极电渣焊pressure thermit welding加压铝热焊接progressive induction seam welding 连续感应滚焊puddle welding熔焊pulsation welding脉冲接触焊pulsed laser welding脉冲激光焊接push welding手压点焊(接)quasi-arc welding潜弧自动焊radio-frequency welding射频焊接, 高频焊接resistance butt-seam welding电阻对缝焊接resistance electro-slag welding接触[电阻]电渣焊resistance-flash welding电阻闪光焊接resistance seam welding电阻缝焊resistance spot welding接触点焊resistance stud welding电阻栓焊resurfacing welding堆焊ring welding滚焊rotating arc welding旋转电弧焊sandwich welding夹紧冷焊scarf welding两端搭接焊, 嵌焊, 斜面焊接self-adjusting [self-regulating] arc welding 自动调节电弧焊series welding单边多电极焊接, 串焊, 系列焊接series projection welding单边多极凸焊series seam welding单边双电极焊缝, 单边多极滚焊series-spot welding单面点焊shape welding异形焊shield-arc welding封闭电弧焊, 保护式电弧焊, 气体保护焊shielded carbon arc welding碳弧保护焊, 气体保护碳极电弧焊Sigma welding惰性气体保护金属极弧焊, 西格马焊接single-impulse welding单脉冲焊接single-pass [run] welding单道焊skip block welding分段多层跳焊skys welding间隔焊接slag pile-up welding电渣堆焊slant angle type welding低角度式焊接slanting butt seam welding斜对接缝焊solid-phase (pressure) welding固相压焊solid-state welding固态焊special build-up welding特殊堆焊spin welding旋转熔接spring type welding弹力式焊接stack welding多层接触点焊staggered welding错列焊staggered-intermittent fillet welding 错综式间断角焊step-by-step welding跨步焊stitch welding叠焊(法); 跳焊; 针脚点焊(法)stitch-and-seam welding点线焊, 断续焊缝straight bead welding直线焊接stud welding螺柱焊接submerged arc welding潜弧焊submerged slag pool welding埋弧电渣焊接symmetry welding对称焊接tack welding平头焊接, 点焊tee spot welding丁字点焊thermal compression welding热压焊接three o'clock welding横向自动焊three-phase arc welding三相电弧焊接tie welding搭接焊torch welding吹管焊接torch braze welding焊矩钎焊track welding轨道焊接ultrasonic spot welding超声波点焊underside welding仰焊, 顶焊union melt welding埋弧自动焊upset butt welding电阻对接焊vacuum diffusion welding真空扩散焊(接)vertical position welding立焊water gas welding水煤气焊接water vapor arc welding水蒸汽保护焊接weaving welding摆动焊Westing-arc welding惰性气体保护金属板弧焊, 西屋电弧焊wire welding焊网。
焊接专业术语中英对照焊接欠缺与检验焊接欠缺welding imperfection焊接缺陷weld defect气孔blowhole/ gas pore针尖状气孔pinhole密集气孔porosity条虫状气孔wormhole裂纹crack表面裂纹surface crack咬边undercut焊瘤overlap凹坑pit烧穿burn through塌陷excessive penetration未焊透incomplete penetration/ lack of penetration未熔合lack of fusion/ incomplete fusion 未焊满incompletely filled weld根部凹陷root concavity电弧擦伤arc scratch夹渣slag inclusion夹杂物inclusion夹钨tungsten inclusion白点fish eye/ flake错边misalignment/ dislocation焊接检验试件test piece试样test specimen无损检验nondestructive test破坏检验destructive test外观检查visual examination超声波探伤ultrasonic inspection直射法超声波探伤straight beam method斜射法超声波探伤angle beam method液浸法超声波探伤immersion method射线探伤radiographic inspection/ radiographyX射线探伤X-ray radiographic inspection γ射线探伤gamma-ray inspectionX射线工业电视探伤X-ray industrial television inspection磁粉探伤magnetic particle inspection电磁探伤electromagnetic inspection/ eddy current test探伤灵敏度flaw detection sensitivity渗透探伤penetration inspection荧光探伤flurescent penetrant inspection 着色探伤dye penetrant inspection密封性检验leak test气密性检验air tight test枕形气密检验pillow test耐压检验pressure test水压检验hydraulic test气压检验pneumatic test液晶检验liquid crystal test声发射检测acoustic emission testing面弯试验face bend testing背弯试验root bend test侧弯试验side bend test横弯试验horizontal bend test纵弯试验axial bend test压扁试验squeezing testactual weld-throat thick-ness焊缝厚度all-around weld整周焊缝all-around weld (整周焊缝)环焊缝angle butt weld斜对接焊angle weld角焊appearance of weld焊缝成形arc-seam weld电弧缝焊arc-spot weld电弧点焊arc-weld电弧焊aspect ratio of weld焊缝成形系数at weld edge在焊缝边上attachment weld连接焊缝automatic spot weld自动点焊法automatic weld自动焊接axis of a weld焊缝行南焊接轴线axis of weld焊缝轴线; 焊接轴线back of weld焊缝背面backing groove of weld焊缝反面坡口backing weld底焊; 底焊焊缝bare metal arc weld裸焊条电弧焊bead weld珠焊; 堆焊bead-on-plate weld堆焊焊缝beading weld凸焊beam-to-beam weld梁间焊接; 梁式引线焊接block sequence weld分段多层焊bond weld钢轨接头焊接bridge seam weld桥缝焊接; 桥线焊brize weld硬焊butt weld对接焊缝butt weld ends对头焊接端butt-weld碰焊; 平式焊接; 对头焊接butt-weld in the downhand position对接平焊butt-weld joint对头焊接butt-weld pipe mill对焊管轧机button spot weld按电钮点焊cap weld最后焊层; 盖面焊缝carbon content of weld materials焊接材料的碳含量cast-weld construction铸焊结构caulk weld填缝焊caulking weld密实焊缝chain intermittent fillet weld链式分段角焊; 并列间断角焊缝chain intermittent weld并列焊接circular weld环形焊缝circumferential weld环缝; 环焊缝cleft weld裂口焊closed weld底边无缝焊; 无间隙焊缝closed-chamber fusion weld闭室熔焊cluster weld丛聚焊缝coil weld卷板对接焊; 卷板对接焊; 板卷焊cold weld冷压接commutator-controlled weld换向控制焊接complete penetration butt weld贯穿对焊composite weld紧密焊缝; 强度密封焊缝concave filled weld凹形角焊缝concave filler weld凹角焊concave fillet weld凹面填角焊concave weld凹焊缝; 凹面焊; 凹形焊缝; 轻型焊connective weld联系焊缝continuous butt-weld mill连续式炉焊管机组continuous fillet weld连续(填)角焊缝; 连续角焊缝; 连续贴角焊continuous weld连续焊缝continuous weld process连续式炉焊管法contour weld特形焊接convex fillet weld凸角焊缝; 凸形角焊缝convex weld凸焊缝; 凸形焊缝copper weld wire包铜钢丝corner flange weld单卷边角焊缝corner weld角焊corner-flange weld卷边角焊缝; 卷边角焊缝crack of weld焊部裂纹cross weld十字交叉焊缝; 横向焊缝cross-wire weld十字焊crotch weld楔接锻接; 楔接焊接cup weld带盖板焊缝depth of weld焊接深度dissimilar weld metal不同的焊接金属; 不同金属的焊接distance between the toes of a weld焊缝宽度double groove weld双面坡口焊缝double-bevel groove weld双斜边坡口焊缝; 双斜坡口焊double-flanged butt weld双弯边对接焊缝double-V groove weld双斜边坡口焊缝; 双斜坡口焊downhand weld平焊缝duplex spot weld双点点焊接头edge joint weld边缘焊edge weld端接焊; 端接焊缝; 端面焊缝; 对边焊electric resistance weld mill电阻焊管机electric weld-pipe mill电焊管机焊接专业英语词汇(通用部分)acetylene 乙炔 ampere 电流安培angle welding 角焊 arc 电弧argon arc welding 氩弧焊接 bare electrode 光熔接条butt welding 对接焊接 camber 电弧弯曲cascade 阶叠熔接法 clad weld 被覆熔接crator 焊疤 excess metal 多余金属filler rod 焊条 fillet weld 填角焊接gas shield 气体遮蔽 groove welding 起槽熔接hand face shield 手握面罩 hard facing 硬表面堆焊jig welding 工模焊接 laser beam welding 雷射光焊接metal electrode insert gas welding MIG熔接nugget 点焊熔核overlaying 堆焊 peening of welding 珠击熔接法plug welding 塞孔熔接 positioned welding 正向熔接pressure welding 压焊 propane gas cutting 丙烷气切割pure nickel electrode 纯镍熔接条reinforcement of weld 加强焊接resist 抗蚀护膜 root running 背面熔接seam 焊缝 seaming 接合seam welding 流缝熔接 series seam welding 串联缝熔接skip welding process 跳焊法 spark 火花spot welding 点焊接 stitch welding 针角焊接stud arc welding 电弧焊接 under laying 下部焊层void 焊接空隙 weld flow mark 焊接流痕weld flush 焊缝凸起 weld line 焊接纹weld mark 焊接痕 weld penetration 熔接透入weld zone 焊接区 welding 焊接welding bead 焊接泡 welding direction 焊接方向welding distortion 焊接变形 welding flux 焊剂welding ground 电熔接地 welding interval 焊接周期welding stress 熔接应变 welding torch 熔接气炬welding electrode production line 电焊条生产线welding electrode 焊条welding fixture 焊接夹具welding generator 电焊机welding goggles 焊工护目镜welding gun 焊枪welding helmet 电焊帽welding inspection ruler 焊接检验尺welding machine 焊接机welding mill 焊管机welding motor generator 电动焊接发电机welding nozzle 焊嘴welding paste 焊接药膏welding pipe 焊接管welding powder 焊粉welding rectifier 焊接整流器welding robot 焊接机器人welding rod extrusion press 焊条挤压机welding rod with acidic coating 酸性焊条welding rod with alkaline coating 碱性焊条welding rod 焊条welding simulator 焊接模拟器welding stainless electrode 不锈电焊条welding steel tube 焊接钢管welding tin billet 焊锡棒料welding tongs 焊接夹钳welding torch 焊炬welding transformer 电焊变压器welding unit 焊机welding wire machine 焊线机welding wire 焊丝welding-cutting hose 熔焊及切割胶管welding-cutting tool 焊割具welding-rod core 焊条芯welding-seam cleaner 焊缝清理机weldless pipe 无缝管weldless steel tube 无缝钢管well borer 凿井机well counter 井式计数器well deck vessel 井形甲板船well drill 钻井机well platform 钻井平台well rig 钻井机well testing truck 试井车well thermometer 井温计well tube filter 井管滤管well type tempering electric furnace 井式回火电炉well winch 矿井绞车well-logging probe 测井探头well-type counter 井型计数器Wella Balsam Conditioner 威娜宝护发素Wella Balsam shampoo 威娜宝香波Wellene 韦纶聚酯短纤维wellhead acid preventer 井口防酸器wellington 惠灵顿防雨呢Wellingtons 长筒皮靴Welltite 韦纶泰特聚丙烯和聚乙烯单丝Welsbach's alloy 韦尔斯巴赫发火合金Welsh flannel 威尔士法兰绒Welsh wool 威尔士粗羊毛welsh-onion stalk 葱白welsh-onion 葱welt cementing machine 贴边粘合机welt coloring machine 贴边染色机welt cutting machine 切沿条机welt fitting machine 贴边机welt footwear 加贴边的鞋welter screen 翻滚筛welter 镶边机Wepsin 三唑磷胺Werlisa 威里沙牌照相机Werner 维尔纳牌手表weskit 紧身背心Wessel silver 韦塞尔铜镍锌合金West cigarette 威狮牌香烟West ginseng 西洋参West Lake Dragon Well tea 西湖龙井茶West Lake silk umbrella 西湖绸伞West Lake silk 西湖丝绸West Lake water shield 西湖莼菜Westeeco 韦斯蒂科镍铬铁耐热合金Western king prawn 宽沟对虾Western saddle pants 西式马裤Western sand cherry 沙樱桃Western shirt 西式衬衫western style bed sheet 西式床单Western style hat 西式呢帽Western style pajamas 西式睡衣裤Western style pants 西裤Western style shirt 西式衬衫Western style shirt-waist blouse 西式衬衫上衣Western style suit 西服western tie 西式领带Western wool 美国西部羊毛Western-made shirt in plaid gingham 长方格贞咸布西式衬衫Westinghouse alloy 西屋镍铜热磁补偿合金wet spinning frame 湿纺细纱机wet air compressor 湿空气压缩机wet air pump 湿空气泵wet and dry bulb hygrometer 干湿球湿度计wet and dry bulb recording hygrometer 干湿球自记湿度计wet and dry bulb thermometer 干湿球温度计wet ball mill 湿式球磨机wet blue goat leather 山羊蓝湿革wet blue goat skin 蓝湿山羊皮wet board machine 湿式纸板机wet brush 湿刷wet chrome goat skin 铬湿山羊皮wet cleaner 湿法清洗器wet cloth 湿光布wet clutch 湿式离合器wet collector 湿式除尘器wet condenser 湿式冷凝器wet crude 含水原油wet crushing mill 湿粉碎机wet cylinder liner 湿式气缸套wet drill 湿式风钻wet dust collector 湿式收尘器wet dust separator 湿式除尘器wet electro-magnet 湿式电磁铁wet electrolytic capacitor 电解液电容器wet feeder 湿式给料机wet fiber filter 湿式纤维过滤器wet filter 湿式过滤器wet fourdrinier board machine 长网湿抄机wet frame 湿纺机wet furfural condenser 含水糖醛冷凝器wet gas meter 湿式气量计wet gas scrubber 湿法气体洗涤质量合格证书certification of fitness原材料rawmaterial底板 bottom plate 垫层 cushion侧壁 sidewall中心线center line条形基础 strip footing附件 accessories型钢 profile steel钢板 steel plate熔渣 slag飞溅 welding spatter定位焊 tacking引弧 generating of arc熄弧 quenching of arc焊道 welding bead坡口 beveled edges外观检查 visual inspection重皮 doubleskin水平方向弧度 radian in horizontal direction 成型 molding直线度 straightness accuracy焊缝角变形 welding line angular distortion 水平度 levelness铅垂度 verticality翘曲变形 buckling deformation角尺 angle square对接焊缝 butt weld母材 parent metal法兰密封面 flange sealing surface夹层interlayer表面锈蚀浓度 surface corrosion concentration挠曲变 bending deformation超声波探伤 ultrasonic testing/ ultrasonic examination压力容器 pressure vessel预制下料prefabrication baiting排版直径 set-type diameter焊缝 welding line中幅板 center plate测量方法 measuring method基准点 datum mark跳焊 skip welding允许偏差 allowable variation补强板 stiffening plate开孔 tapping对接接头 banjo fixing butt jointing角钢 angle iron安装基准圆 installation fundamental circle 吊装立柱 hoisting upright column焊接钢管 welded steel pipe向心斜拉筋 centripetal canting pull rope 带板 band plate槽钢胀圈 channel steel expansion ring环口 collar extension局部变形 local distortion环缝 circumferential weld顶板 top plate拱顶 vault顶板加强肋 stiffening rib对接 butt joint胎具 clamping fixture卷板机 plate bending rolls中心支架 center bearing bracket椭圆度 ovality等分线 bisectrix搭接宽度lap width点焊spot welding搭接焊 overlap welding对称:symmetrically螺旋爬梯cockle stairs放料阀baiting valve液位计 content gauge充水试验 filling water test错边量 unfitness of butt joint底圈 foundation ring真空度检漏 vacuum degree leak test丁字焊缝 tee welding渗透探伤 oil whiting test充水试验 filling water test内侧角焊缝接头 interior angle welding line jointfoundation settlement 基础沉降测量基准点 datum mark稳定性试验 stability test排气阀 outlet valve角钢 angle steel构件 component part机械损伤 mechanical damage缩孔 shrinkage cavityenfoldment 折迭碳钢管 carbon steel tube公称直径 nominal diameter预埋件 embedded part轴测图 axonometric drawing布置图arrangement diagram氧乙炔气割 oxyacetylene gas cutting低合金钢管low alloy steel热影响区 heat affected area 修磨polish砂轮片grinding wheel等离子plasma panel重皮 coldlap凹凸unevenness缩口necking down端面 head face倾斜偏差 dip deviation外径 external diameter砂轮grinding wheel管件 pipe casting单线图single line drawing平齐parallel and level两端 two terminals满扣 buckle螺栓紧固 bolton周边 periphery附加应力 additional stress同轴度 axiality平行度 parallelism随机 stochastic允许偏差 allowable variation重直度verticality水平度 levelness隔离盲板 blind plate氩弧焊argon arc welding压盖螺栓 gland bolt间距spacing有效期 period of validity担任 take charge of ;undertake焊条 welding rod碳钢焊条carbon steel焊丝 welding wire熔化焊 melting钢丝 steel wire气体保护焊 gas shielded arc welding 烘干drying清洗ablution制度system焊接工艺welding procedure相应corresponding手工电弧焊manual electric arc welding 手工钨极 manual tungsten electrode打底render电源power source交流alternating current焊件 weldment管壁厚度 pipe thickness对接焊缝 butt weld工件壁厚 workpiece飞溅物 splash沾污 smirch油污 oil stain细锉 smooth file铣刀 milling cutter氧化膜 oxide film脱脂处理 ungrease treatment]棉质纤维 cotton fibre丙酮acetone硫 sulfur焊剂 welding flux钢板 steel plate纵向焊缝 l0ngitudinal weld l0ngitudinal seam筒节 shell ring封头 end socket卷管 reelpipe强度试验strength test起弧arc starting穿堂风draught熔合fusion反面reverse side整体integral封堵block up焊口 weld bond医用胶布medical proof fabric高频 high frequency焊炬welding torch送气air supply焊接专业英语词汇(熔化焊)熔接fusion welding压接pressure welding焊接过程welding process焊接技术welding technique焊接工艺welding technology/procedure焊接操作welding operation焊接顺序welding sequence焊接方向direction of welding焊接位置welding position熔敷顺序build-up sequencedeposition sequence焊缝倾角weld slope/inclination of weld axis 焊缝转角weld rotation/angle of rotation平焊位置flat position of welding横焊位置horizontal position of welding立焊位置vertical position of welding仰焊位置overhead position of welding平焊downhand welding/flat position welding 横焊horizontal position welding 立焊vertical position welding仰焊overhead position welding全位置焊all position welding:熔焊时,焊件接逢所处空间位置包括平焊、横焊、仰焊等位置所进行的焊接。
焊接常用中、英文术语定义及解释1 母材金属base mental, parent mental被焊金属材料的统称。
2 热影响区heat-affected zone焊接或切割过程中,材料因受热的影响(但未熔化)而发生金相组织和机械性能变化的区域。
3 过热区overheated zone焊接热影响区中,具有过热组织或晶粒显著粗大的区域。
4 焊缝weld焊件经焊接后所形成的结合部分。
5 焊缝区weld zone焊缝及其邻近区域的总称。
6 定位焊缝tack weld焊前为装配和固定构件接缝的位置而焊接的短焊缝。
7承载焊缝strength weld焊件上用作承受载荷的焊缝。
8 连续焊缝continuous weld连续焊接的焊缝。
9 断续焊缝intermittent weld焊接成具有一定间隔的焊缝。
10 纵向焊缝longitudinal weld沿焊件长度方向分布的焊缝。
11 横向焊缝transverse weld垂直于焊件长度方向的焊缝。
12 环缝girth weld, circumferential weld沿筒形焊件分布的头尾相接的封闭焊缝。
13 密封焊缝seal weld主要用于防止流体渗漏的焊缝。
14 并列断续角焊缝chain intermittent fillet weldT形接头两侧互相对称布置、长度基本相等的断续角焊缝。
15 交错断续角焊缝staggered intermittent fillet weldT形接头两侧互相交错布置、长度基本相等的断续角焊缝。
16 凸形角焊缝convex fillet weld焊缝表面突起的角焊缝。
17 凹形角焊缝concave fillet weld焊缝表面下凹的角焊缝。
18 焊缝正面face of weld焊后,从焊件的施焊面所见到的焊缝表面。
19 焊缝背面root surface焊后,从焊件施焊面的背面所见到的焊缝表面。
20 焊缝宽度weld width焊缝表面两焊趾之间的距离。
21 焊缝厚度actual throat在焊缝横截面中,从焊缝正面到焊缝背面的距离。
22 焊趾weld toe焊缝表面与母材的交界处。
23 焊脚fillet weld leg角焊缝的横截面中,从一个直角面上的焊趾到另一个直角表面的最小距离。
24 熔深depth of fusion在焊接接头横截面上,母材或前道焊缝熔化的深度。
25 焊缝成形系数form factor(of the weld)熔焊时,在单道焊缝横截面上焊缝宽度(B)与焊缝计算厚度(H)的比值。
26 余高weld reinforcement超出母材表面连线上面的那部分焊缝金属的最大高度。
27 工地焊接field welding焊接结构在工地安装后就地进行的焊接,也称现场焊接。
28 补焊(返修焊)repair welding为修补工件(铸件、锻件、机械加工件或焊接结构件)的缺陷而进行的焊接。
29 焊接参数welding parameter焊接时,为保证焊接质量而选定的各项参数(例如,焊接电流、焊接电压、焊接速度、线能量等)的总称。
30 送丝速度wire feed rate焊接时,单位时间内焊丝向焊接熔池送进的长度。
31 保护气体流量shield gas flow rate气体保护焊时,通过气路系统送往焊接区的保护气体的流量。
通常用流量计进行计量。
32 预热preheat焊接开始前,对焊件的全部(或局部)进行加热的工艺措施。
33 后热postheat焊接后立即对焊件的全部(或局部)进行加热或保温,使其缓冷的工艺措施。
它不等于焊后热处理。
34 预热温度preheat temperature按照焊接工艺的规定,预热需要达到的温度。
35 后热温度postheat temperature按照焊接工艺的规定,后热需要达到的温度。
36 道间温度(俗称层间温度)interpass temperature多层多道焊时,在施焊后继焊道之前,其相邻焊道应保持的温度。
37 焊态as welded焊接过程结束后,焊件未经任何处理的状态。
38 焊后热处理postweld heat treatment焊后,为改善焊接接头的组织和性能或消除残余应力而进行的热处理。
39 焊接性weldability材料在限定的施工条件下焊接成按规定设计要求的构件,并满足预定服役要求的能力。
焊接性受材料、焊接方法、构件类型及使用要求四个因素的影响。
40 焊接性试验weldability test评定母材焊接性的试验。
例如:焊接裂纹试验、接头力学性能试验、接头腐蚀试验等。
41 焊接残余应力residual stress焊后残留在焊件内的焊接应力。
42 焊接变形welding deformation焊件由焊接而产生的变形。
43 焊接残余变形welding residual deformation焊后,焊件残留的变形。
44 拘束度restraint intensity衡量焊接接头刚性大小的一个定量指标。
拘束度有拉伸和弯曲两类:拉伸拘束度是焊接接头根部间隙产生单位长度弹性位移时,焊缝每单位长度上受力的大小;弯曲拘束度是焊接接头产生单位弹性弯曲角变形时,焊缝每单位长度上所受弯矩的大小。
45 碳当量carbon equivalent把钢中合金元素(包括碳)的含量按其作用换成碳的相当含量。
可作为评定钢材焊接性的一种参考指标。
46 扩散氢diffusible hydrogen焊缝区中能自由扩散运动的那一部分氢。
47 残余氢residual hydrogen焊件中扩散氢充分逸出后仍残存于焊缝区中的氢。
48 焊件weldment由焊接方法连接的组件。
49 焊接车间welding shop以生产焊件为主的车间。
50 熔池molten pool;puddle熔焊时在焊接热源作用下,焊件上所形成的具有一定几何形状的液态金属部分。
51 弧坑crater弧焊时,由于断弧或收弧不当,在焊道末端形成的低洼部分。
52 熔敷金属deposited mental完全由填充金属熔化后所形成的焊缝金属。
53 熔敷顺序build up sequence堆焊或多层焊时,在焊缝横截面上各焊道的施焊次序。
54 电弧自身调节arc self-regulation熔化极电弧焊中,当焊丝等速送进时,电弧本身具有的自动调节并恢复其弧长的特性。
55 电弧偏吹(磁偏吹)arc blow电弧受磁力作用而产生偏移的现象。
56 弧长arc length焊接电弧两端间(指电极端头和熔池表面间)的最短距离。
57 短路过渡short circuiting transfer焊条(或焊丝)端部的熔滴与熔池短路接触,由于强烈过热和电磁收缩的作用使其爆断,直接向熔池过渡的形式。
58 喷射过渡spray transfer熔滴呈细小颗粒并以喷射状态快速通过电弧空间向熔池过渡的形式59 极性polarity直流电弧焊或电弧切割时,焊件的极性。
焊件接电源正极称为正极性,接负极为反极性。
60 正接straight polarity焊件接电源正极,电极接电源负极的接线法。
61 反接reversed polarity焊件接电源负极,电极接电源正极的接线法。
62 船形焊fillet welding in the flat positionT形、十字形和角接接头处于平焊位置进行的焊接。
63 向上立焊vertical up position welding立焊时,热源自下向上进行的焊接。
64 向下立焊vertical down position welding立焊时,热源自上向下进行的焊接。
65 倾斜焊inclined position welding焊件接缝置于倾斜位置(除平、横、立、仰焊位置以外)时进行的焊接。
66 左焊法forehand welding焊接热源从接头右端向左端移动,并指向待焊部分的操作法。
67 右焊法back hand welding焊接热源从接头左端向右端移动,并指向已焊部分的操作法。
68 分段退焊backstep sequence将焊件接缝划分成若干段,分段焊接,每段施焊方向与整条焊缝增长方向相反的焊接法。
69 跳焊skip sequence将焊件接缝分成若干段,按预定次序和方向分段间隔施焊,完成整条焊缝的焊接法。
70 单面焊welding by one side只在接头的一面(侧)施焊的焊接。
71 双面焊welding by both sides在接头的两面(侧)施焊的焊接。
72 单道焊single-pass welding只熔敷一条焊道完成整条焊缝所进行的焊接。
73 多道焊multi-pass welding由两条以上焊道完成整条焊缝所进行的焊接。
74 多层焊multi-layer welding熔敷两个以上焊层完成整条焊缝所进行的焊接。
75 窄间隙焊narrow gap welding厚板对接接头,焊前不开坡口或只开小角度坡口,并留有窄而深的间隙,采用气体保护焊或埋弧焊的多层焊完成整条焊缝的高效率焊接法。
76 渣池slag bath电渣焊过程中,由焊剂熔化并覆盖在金属熔池上面的有一定深度的液态熔渣。
77 焊钳electrode holder用以夹持焊条(或碳棒)并传导电流以进行焊接的工具。
78 焊枪arc welding gun具有导送焊丝、馈送电流、给送保护气体或贮送焊剂等功能的装置(器具)。
79 喷嘴nozzle焊炬或焊枪的嘴头部分,保护气体或可燃气体由此喷出。
80 气体喷嘴gas nozzle送输保护气体的焊枪或焊炬的出口装置。
81 导电嘴contact tube熔焊时,焊枪和焊接机头上用以将焊丝导向熔池并向焊丝馈送电流的零件。
82 送丝机构wire feeder焊接设备中,用以输送焊丝的专用装置。
83 铜滑块backing shoe电渣焊或气电立焊时,为保持熔池形状,强制焊缝成形,在接头一侧或两侧使用的成形器具。
84 清根backgouging从焊缝背面清理焊根,为背面焊接做准备的操作。
85 飞溅spatter熔焊过程中向周围飞散的金属颗粒。
86 飞溅率spatter lose rate飞溅损失的金属量与熔化的焊丝(或焊条)金属质量的百分比。
87 焊接烟尘weld fumes焊接时由焊接材料和母材蒸发、氧化产生的烟雾状微粒。
88 焊接有害气体weld harmful gasses焊接时由焊接材料,母材及其冶金反应产生的有害气体,如CO,NO,HF和O3等。
89 焊接发尘量total amount of weld fumes焊接时,单位质量的焊接材料(如焊条、焊丝等)所产生的烟尘量,单位为mg/g或g/kg。
90 飞边fin电阻对焊和摩擦焊时,顶锻后残留在接头处向两侧翻卷的光滑的金属。
