BladeCenter EProduct Guide (withdrawn product)Lenovo BladeCenter® remains an innovative solution to running business solutions. BladeCenter E efficiently integrates servers, storage, networking, I/O, and applications, enabling organizations to build flexible IT infrastructures by using common building blocks. In 7U of rack space, the BladeCenter E chassis can contain up to 14 blade servers, four switch modules, and four power supplies to provide the necessary I/O network switching, power, and cooling to support the individual servers.Figure 1 shows the BladeCenter E.Figure 1. The BladeCenter EDid you know?BladeCenter E delivers extreme density, energy efficiency, and reliability for space- and power-constrained enterprise IT environments.The chassis supports up to four traditional fabrics by using networking switches, storage switches, or pass-through devices. The chassis offers light path diagnostics, one front USB input, and an optical drive.Click here to check for updatesFigure 2. Front of the BladeCenter E chassisFigure 3. Rear of the BladeCenter E chassis Standard specificationsStandard specificationsTable 1 lists the standard specifications of the BladeCenter E chassis. Table 1. Standard specificationsComponents SpecificationMachine type x-config: 8677.Form factor7U rack-mounted unit.Server bays14.Servers supported Intel Xeon processor-based HS12, HS22, HS22V, HS23, and HS23E servers IBM POWER® processor-based PS700 serversCertain older BladeCenter serversStandard I/O bays Four (Bays 1 - 4). Support for 1 Gb Ethernet, 4 Gb and 8 Gb Fibre Channel, and 3 Gb SAS I/O modules.ConnectivitytypeEthernet, Fibre Channel, iSCSI, and SAS.Management modules Up to two redundant hot-swap Advanced Management Modules (AMM): One AMM standard, the second AMM optional.Optical drivebaysOne. Support for an optional DVD-ROM or multi-burner.Ports AMM: One DB-15 video port, two USB 2.0 ports for keyboard and mouse, one RJ-45 serial port, one RJ-45 10/100 Mb Ethernet port for remote management.Front: One USB 2.0 port.Cooling IBM Calibrated Vectored Cooling with two redundant hot-swap blower modules.Power modules Up to four redundant hot-swap 2000 W or 2320 W power modules support two power domains; redundancy is provided within a pair in the same power domain. Power modules 1 and 2 supply power to server bays 1 - 6; power modules 3 and 4 supply power to server bays 7 - 14. (See the "Power modules" section for details.)Hot-swappartsServers, I/O modules, management modules, power modules, and blowers.Systems management AMM, light path diagnostics, Predictive Failure Analysis, IBM Systems Director, and IBM Systems Director Active Energy Manager. Remote presence (graphics, keyboard and mouse, and virtual media) through AMM.SecurityfeaturesRole-based user security, LDAP, SSH, and SSL.Limited warranty Three-year customer-replaceable unit and onsite limited warranty with 9x5/next business day response time.Service and support Optional service upgrades are available through IBM ServicePacs: 9x5 or 24x7 4-hour or 2-hour response time, 1-year or 2-year warranty extension, remote technical support for IBM hardware and selected IBM and third-party (Microsoft, Linux, VMware) software.Dimensions Height: 304 mm (12.0 in.), width: 444 mm (17.5 in.), depth: 711 mm (28.0 in.). Weight Minimum: 39 kg (85 lb), maximum 102 kg (225 lb).ModelsModelsTable 2 lists the specifications of the standard BladeCenter E models.Table 2. BladeCenter E standard modelsFeature SpecificationsMachine type/model8677-3Tx†*8677-4Tx†Server bays (total / open)14 / 1414 / 14Management modules (std. / max.) 1 / 2 1 / 2Standard I/O bays (total / open) 4 / 4 4 / 4I/O modules standard None NonePower supplies (std. / max.)2x 2000 W / 42x 2320 W / 4 Blowers (std. / max.) 2 / 2 2 / 2Optical drive Optional Optional† x is a region-specific letter (for example, EMEA MTM is 86774TG, and the US MTM is 86774TU).* The model 3Tx is not available in EMEA.Supported serversTable 3 lists the blade servers that are supported in the BladeCenter E. The table also lists the maximum number of installable servers based on the thermal design power (TDP) of the Intel Xeon processor that is installed in the servers.Table 3. Supported blade servers and maximum quantitiesBlade server CPU TDP Maximum number of server per BladeCenter E chassis2000 W power supplies2320 W power suppliesBladeCenter HS12 (8028)All1414BladeCenter HS22 (7870) BladeCenter HS22V (7871)130 W None None 95 W5+614 80 W5+714 60 W6+714 40 W1414BladeCenter HS23 (7875, E5-2600 v2)Up to 130 W(excl. 80 W)†None None80 W†6+7*14*95 W#5+7*§14*§70 W#14*14*50 W#1414 BladeCenter HS23 (7875, E5-2600)Up to 130 W(excl. 80W)††None None80 W††6+71495 W##5+71470 W##1414 BladeCenter HS23E (8038)95 W5+61480 W5+714Up to 70 W1414 BladeCenter HX5 (7872 and 7873)All None None BladeCenter PS700All14**14** BladeCenter PS701All None None BladeCenter PS702All None None BladeCenter PS703All None None BladeCenter PS704All None None† The support that is shown is for Intel Xeon standard thermal profile processors (all except Intel Xeon E5-2618L v2, E5-2628L v2, E5-2648L v2, and E5-2658 v2).* When one blower fails, the HS23 (7875, E5-2600 v2) with specified processor TDP only supports ambient temperature of up to 28 °C when installed in the BladeCenter E chassis.§ The HS23 (7875, E5-2600 v2) with the Intel Xeon processor E5-2658 v2 (95 W) only supports one DIMM per channel when installed in the BladeCenter E chassis.†† The support that is shown is for Intel Xeon standard thermal profile processors (all except Intel Xeon E5-2648L and E5-2658).# The support that is shown is for Intel Xeon robust thermal profile processors: Intel Xeon E5-2618L v2 (50 W), E5-2628L v2 (70 W), E5-2648L v2 (70 W), and E5-2658 v2 (95 W).## The support that is shown is for Intel Xeon robust thermal profile processors: Intel Xeon E5-2648L (70 W) and E5-2658 (95 W).** Only specific models of the BladeCenter E are supported by the PS700: 8677-3Sx, 4Sx, 3Tx, 4Tx.For the latest information about the servers that are supported in the BladeCenter E chassis, see IBM ServerProven® at the following web address:/servers/eserver/serverproven/compat/us/I/O architectureThe BladeCenter E chassis provides connection paths between the server blade bays and I/O bays through a hardwired dual redundant midplane.Each blade bay has four dedicated I/O connections (two per midplane) linked to four I/O bays (one blade bay connection to one I/O bay). Thus, each I/O bay has a total of 14 I/O connections (to 14 blade bays). Figure 4 shows the I/O topology.Figure 4. BladeCenter E I/O topologyEach blade server has at least two integrated Gigabit Ethernet ports (Ethernet 1 and Ethernet 2). Ethernet 1 is routed to I/O bay 1 and Ethernet 2 is routed to I/O bay 2, which means that only Ethernet-capable I/O modules can be used in I/O bays 1 and 2.I/O expansion cards that you optionally install in blade servers have two ports, which are routed to I/O bays 3 and 4. Thus, depending on the expansion card that is installed, compatible I/O modules must be chosen for those I/O bays. Unless an expansion card is installed in one or more processor blades, there is no need for I/O modules 3 and 4.The I/O modules must be compatible with the I/O interfaces present in the blade servers. For example, when a Fibre Channel expansion card is installed in a blade server, I/O modules 3 and 4 must also be Fibre Channel-based (that is, an FC switch module), and vice versa. If you install FC switches in bays 3 and 4, then any expansion cards that are installed in all other blade servers in the same chassis must be Fibre Channel.Table 4 shows the connections between adapter slots in the compute nodes to the switch bays in the chassis.Table 4. Adapter to I/O bay correspondenceI/O adapterin each server Port on the adapter Corresponding I/O module bayin the chassisOnboard 1 Gb Ethernet Port 1I/O bay 1Port 2I/O bay 2CIOv adapter Port 1I/O bay 3Port 2I/O bay 4Supported I/O modulesTables 5 through 7 list the I/O modules that are supported by the BladeCenter E chassis and the corresponding I/O bay into which the I/O module can be installed.Table 5. Supported Ethernet I/O modulesI/O module Part number Feature code I/O bay number1234 Gigabit EthernetCisco Catalyst Switch Module 3012*43W43955450Y Y Y Y Cisco Catalyst Switch Module 301246C9272A3FE Y Y Y Y Cisco Catalyst Switch Module 3110G*41Y85232989Y Y Y Y Cisco Catalyst Switch Module 3110G00Y3254A3FD Y Y Y Y Cisco Catalyst Switch Module 3110X*41Y85222988Y Y Y Y Cisco Catalyst Switch Module 3110X00Y3250A3FC Y Y Y Y IBM 1/10Gb Uplink Ethernet Switch Module44W44041590Y Y Y Y IBM L2/3 Copper GbE Switch Module32R18601495Y Y Y Y IBM L2/3 Fiber GbE Switch Module32R18611496Y Y Y Y IBM L2-7 Gb Ethernet Switch Module32R18591494Y Y Y Y IBM Server Connectivity Module39Y93241484Y Y Y Y* Withdrawn, not available for ordering.Figure 5. Advanced Management ModuleExternal backup unitsThe following table lists the external backup options that are offered by Lenovo. Table 13. External backup optionsPart number DescriptionExternal RDX USB drives4T27A10725ThinkSystem RDX External USB 3.0 DockExternal SAS tape backup drives6160S7E IBM TS2270 Tape Drive Model H7S6160S8E IBM TS2280 Tape Drive Model H8S6160S9E IBM TS2290 Tape Drive Model H9SExternal SAS tape backup autoloaders6171S7R IBM TS2900 Tape Autoloader w/LTO7 HH SAS6171S8R IBM TS2900 Tape Autoloader w/LTO8 HH SAS6171S9R IBM TS2900 Tape Autoloader w/LTO9 HH SASExternal tape backup libraries6741A1F IBM TS4300 3U Tape Library-Base Unit6741A3F IBM TS4300 3U Tape Library-Expansion UnitFull High 8 Gb Fibre Channel for TS430001KP938LTO 7 FH Fibre Channel Drive01KP954LTO 8 FH Fibre Channel Drive02JH837LTO 9 FH Fibre Channel DriveHalf High 8 Gb Fibre Channel for TS430001KP936LTO 7 HH Fibre Channel Drive01KP952LTO 8 HH Fibre Channel Drive02JH835LTO 9 HH Fibre Channel DriveHalf High 6 Gb SAS for TS430001KP937LTO 7 HH SAS Drive01KP953LTO 8 HH SAS Drive02JH836LTO 9 HH SAS DriveFor more information, see the list of Product Guides in the Backup units category: https:///servers/options/backupTop-of-rack Ethernet switchesPower distribution unitsThe following table lists the power distribution units (PDUs) that are offered by Lenovo.Table 15. Power distribution unitsPart number Feature code Description 0U Basic PDUs00YJ776ATZY 0U 36 C13/6 C19 24A 1 Phase PDU N Y Y N N N N N N Y Y Y N 00YJ779ATZX 0U 21 C13/12 C19 48A 3 Phase PDU N N Y N N N Y N N Y Y Y N 00YJ777ATZZ 0U 36 C13/6 C19 32A 1 Phase PDU Y Y N Y Y Y Y Y Y N N Y Y 00YJ778AU000U 21 C13/12 C19 32A 3 Phase PDU Y Y N Y Y Y Y Y Y N N Y Y 0U Switched and Monitored PDUs00YJ783AU040U 12 C13/12 C19 Switched and Monitored48A 3 Phase PDUN N Y N N N Y N N Y Y Y N 00YJ781AU030U 20 C13/4 C19 Switched and Monitored 24A 1 Phase PDUN N Y N Y N Y N N Y Y Y N 00YJ782AU020U 18 C13/6 C19 Switched and Monitored 32A 3 Phase PDUY Y Y Y Y Y Y Y Y N Y N Y 00YJ780AU010U 20 C13/4 C19 Switched and Monitored 32A 1 Phase PDUY Y Y Y Y Y Y Y Y N Y N Y1U Switched and Monitored PDUs 4PU7A81117BNDV 1U 18 C19/C13 switched and monitored 48A 3P WYE PDU - ETLN N N N N N N N N N N Y N 4PU7A77467BLC41U 18 C19/C13 Switched and Monitored 80A 3P Delta PDUN N N N N N N N N Y N Y N 4PU7A77469BLC61U 12 C19/C13 switched and monitored 60A 3P Delta PDUN N N N N N N N N N N Y N 4PU7A77468BLC51U 12 C19/C13 switched and monitored 32A 3P WYE PDUY Y Y Y Y Y Y Y Y N Y Y Y 4PU7A81118BNDW 1U 18 C19/C13 switched and monitored 48A 3P WYE PDU - CEY Y Y Y Y Y Y Y Y N Y N Y 46M400258961U 9 C19/3 C13 Switched and Monitored DPI PDUY Y Y Y Y Y Y Y Y Y Y Y Y 46M400458941U 12 C13 Switched and Monitored DPI PDUY Y Y Y Y Y Y Y Y Y Y Y Y46M400358971U 9 C19/3 C13 Switched and Monitored 60A 3 Phase PDUY Y Y Y Y Y Y Y Y Y Y Y Y 46M400558951U 12 C13 Switched and Monitored 60A 3Phase PDUY Y Y Y Y Y Y Y Y Y Y Y Y1U Ultra Density Enterprise PDUs (9x IEC 320 C13 + 3x IEC 320 C19 outlets)71763NU 6051Ultra Density Enterprise C19/C13 PDU 60A/208V/3PHN N Y N N N N N N Y Y Y N 71762NX6091Ultra Density Enterprise C19/C13 PDU ModuleY Y Y Y Y Y Y Y Y Y Y Y Y1U C13 Enterprise PDUs (12x IEC 320 C13 outlets)39M28166030DPI C13 Enterprise PDU Plus Module (WW)Y Y Y Y Y Y Y Y Y Y Y Y YA N ZA S E A NB r a z i lE E T M E A R U C I S W E H T K I N D I A J A P A NL AN A P R C39Y89416010DPI C13 Enterprise PDU Module (WW)Y Y Y Y Y Y Y Y Y Y Y Y Y 1U C19 Enterprise PDUs (6x IEC 320 C19 outlets)39Y89486060DPI C19 Enterprise PDU Module (WW)Y Y Y Y Y Y Y Y Y Y Y Y Y 39Y89236061DPI Three-phase 60A/208V C19 EnterprisePDU (US)N N Y N N N Y N N N Y Y N1U Front-end PDUs (3x IEC 320 C19 outlets)39Y89386002DPI Single-phase 30A/120V Front-end PDU (US)Y Y Y Y Y Y Y Y Y Y Y Y Y 39Y89396003DPI Single-phase 30A/208V Front-end PDU (US)Y Y Y Y Y Y Y Y Y Y Y Y Y 39Y89346005DPI Single-phase 32A/230V Front-end PDU (International)Y Y Y Y Y Y Y Y Y Y Y Y Y 39Y89406004DPI Single-phase 60A/208V Front-end PDU (US)Y N Y Y Y Y Y N N Y Y Y N 39Y89356006DPI Single-phase 63A/230V Front-end PDU (International)Y Y Y Y Y Y Y Y Y Y Y Y Y1U NEMA PDUs (6x NEMA 5-15R outlets)39Y89055900DPI 100-127V NEMA PDUY Y Y Y Y Y Y Y Y Y Y Y Y Line cords for 1U PDUs that ship without a line cord40K96116504 4.3m, 32A/380-415V, EPDU/IEC 3093P+N+G 3ph wye (non-US) Line Cord Y Y Y Y Y Y Y Y Y Y Y Y Y 40K96126502 4.3m, 32A/230V, EPDU to IEC 309 P+N+G (non-US) Line CordY Y Y Y Y Y Y Y Y Y Y Y Y 40K96136503 4.3m, 63A/230V, EPDU to IEC 309 P+N+G (non-US) Line CordY Y Y Y Y Y Y Y Y Y Y Y Y 40K96146500 4.3m, 30A/208V, EPDU to NEMA L6-30P (US) Line CordY Y Y Y Y Y Y Y Y Y Y Y Y 40K96156501 4.3m, 60A/208V, EPDU to IEC 309 2P+G (US) Line CordN N Y N N N Y N N Y Y Y N 40K96176505 4.3m, 32A/230V, Souriau UTG Female to AS/NZ 3112 (Aus/NZ) Line Cord Y Y Y Y Y Y Y Y Y Y Y Y Y 40K961865064.3m, 32A/250V, Souriau UTG Female to KSC 8305 (S. Korea) Line CordY Y Y Y Y Y Y Y Y Y Y Y YPart number Feature code Description For more information, see the Lenovo Press documents in the PDU category:https:///servers/options/pduA N ZA S E A NB r a z i lE E T M E A R U C I S W E H T K I N D I A J A P A NL AN A P R CUninterruptible power supply unitsThe following table lists the uninterruptible power supply (UPS) units that are offered by Lenovo.Table 16. Uninterruptible power supply unitsPart number Description55941AX RT1.5kVA 2U Rack or Tower UPS (100-125VAC)55941KX RT1.5kVA 2U Rack or Tower UPS (200-240VAC)55942AX RT2.2kVA 2U Rack or Tower UPS (100-125VAC)55942KX RT2.2kVA 2U Rack or Tower UPS (200-240VAC)55943AX RT3kVA 2U Rack or Tower UPS (100-125VAC)55943KX RT3kVA 2U Rack or Tower UPS (200-240VAC)55945KX RT5kVA 3U Rack or Tower UPS (200-240VAC)55946KX RT6kVA 3U Rack or Tower UPS (200-240VAC)55948KX RT8kVA 6U Rack or Tower UPS (200-240VAC)55949KX RT11kVA 6U Rack or Tower UPS (200-240VAC)55948PX RT8kVA 6U 3:1 Phase Rack or Tower UPS (380-415VAC)55949PX RT11kVA 6U 3:1 Phase Rack or Tower UPS (380-415VAC)55943KT†ThinkSystem RT3kVA 2U Standard UPS (200-230VAC) (2x C13 10A, 2x GB 10A, 1x C19 16A outlets)55943LT†ThinkSystem RT3kVA 2U Long Backup UPS (200-230VAC) (2x C13 10A, 2x GB 10A, 1x C19 16A outlets)55946KT†ThinkSystem RT6kVA 5U UPS (200-230VAC) (2x C13 10A outlets, 1x Terminal Block output) 5594XKT†ThinkSystem RT10kVA 5U UPS (200-230VAC) (2x C13 10A outlets, 1x Terminal Block output)† Only available in China and the Asia Pacific market.For more information, see the list of Product Guides in the UPS category:https:///servers/options/upsThe BladeCenter E chassis is supported in the rack cabinets that are listed in Table 18.Table 17. Rack cabinetsPart number Description201886X IBM 11U Office Enablement Kit93072PX IBM 25U Static S2 Standard Rack93072RX IBM 25U Standard Rack93072SX IBM 25U Standard Rack93074EX IBM 42U Standard Rack Extension93074RX IBM 42U Standard Rack93074SX IBM 42U Standard Rack93074XX IBM 42U Standard Rack Extension930842E NetBAY42 Enterprise Expansion Rack Cabinet (EX)930842S NetBAY42 Enterprise Rack Cabinet93084EX IBM 42U Enterprise Expansion Rack93084PX IBM 42U Enterprise Rack93084RX NetBAY42 Enterprise Rack Cabinet93084XX NetBAY42 Enterprise Expansion Rack Cabinet (EX)93604EX IBM 42U 1200mm Deep Dynamic Expansion Rack93604PX IBM 42U 1200mm Deep Dynamic Rack93614EX IBM 42U 1200mm Deep Static Expansion Rack93614PX IBM 42U 1200mm Deep Static Rack93624EX IBM 47U 1200mm Deep Static Expansion Rack93624PX IBM 47U 1200mm Deep Static Rack93634CX IBM PureFlex™ System 42U Rack93634DX IBM PureFlex System 42U Expansion Rack93634EX IBM 42U 1100mm Dynamic Expansion Rack93634PX IBM 42U 1100mm Dynamic Rack99564RX IBM S2 42U Dynamic Standard Rack99564XX IBM S2 42U Dynamic Standard Expansion RackFor more information, see the list of Lenovo Press Product Guides in the Rack cabinets and options category at https:///servers/options/racksThe BladeCenter E chassis supports the rack console switches and monitor kits that are listed in Table 19. Table 18. Rack optionsPart number DescriptionMonitor kits and keyboard trays172317X1U 17in Flat Panel Console Kit172319X1U 19in Flat Panel Console KitConsole switches1754D2X IBM Global 4x2x32 Console Manager (GCM32)1754D1X IBM Global 2x2x16 Console Manager (GCM16)1754A2X IBM Local 2x16 Console Manager (LCM16)1754A1X IBM Local 1x8 Console Manager (LCM8)Rack conversion options46M5382IBM Serial Conversion Option (SCO)46M5383IBM Virtual Media Conversion Option Gen2 (VCO2)39M2895IBM USB Conversion Option (UCO)For more information, see the list of Lenovo Press Product Guides in the KVM Switches & Consoles category at https:///servers/options/kvmLenovo Financial ServicesLenovo Financial Services reinforces Lenovo’s commitment to deliver pioneering products and services that are recognized for their quality, excellence, and trustworthiness. Lenovo Financial Services offers financing solutions and services that complement your technology solution anywhere in the world.We are dedicated to delivering a positive finance experience for customers like you who want to maximize your purchase power by obtaining the technology you need today, protect against technology obsolescence, and preserve your capital for other uses.We work with businesses, non-profit organizations, governments and educational institutions to finance their entire technology solution. We focus on making it easy to do business with us. Our highly experienced team of finance professionals operates in a work culture that emphasizes the importance of providing outstanding customer service. Our systems, processes and flexible policies support our goal of providing customers with a positive experience.We finance your entire solution. Unlike others, we allow you to bundle everything you need from hardware and software to service contracts, installation costs, training fees, and sales tax. If you decide weeks or months later to add to your solution, we can consolidate everything into a single invoice.Our Premier Client services provide large accounts with special handling services to ensure these complex transactions are serviced properly. As a premier client, you have a dedicated finance specialist who manages your account through its life, from first invoice through asset return or purchase. This specialist develops an in-depth understanding of your invoice and payment requirements. For you, this dedication provides a high-quality, easy, and positive financing experience.For your region-specific offers, please ask your Lenovo sales representative or your technology provider about the use of Lenovo Financial Services. For more information, see the following Lenovo website: https:///us/en/landingpage/lenovo-financial-services/TrademarksLenovo and the Lenovo logo are trademarks or registered trademarks of Lenovo in the United States, other countries, or both. A current list of Lenovo trademarks is available on the Web athttps:///us/en/legal/copytrade/.The following terms are trademarks of Lenovo in the United States, other countries, or both:Lenovo®BladeCenter Interoperability GuideBladeCenter®RackSwitchServerProven®System x®ThinkSystem®The following terms are trademarks of other companies:Intel® and Xeon® are trademarks of Intel Corporation or its subsidiaries.Linux® is the trademark of Linus Torvalds in the U.S. and other countries.Microsoft® is a trademark of Microsoft Corporation in the United States, other countries, or both.Other company, product, or service names may be trademarks or service marks of others.。

IBM BladeCenter H之北电网络L2/3千兆以太网交换机模块配置与网络整合(一)2010-08-18 17:20:45标签：IBM刀片服务器北电网络以太网交换机模块原创作品，允许转载，转载时请务必以超链接形式标明文章原始出处、作者信息和本声明。

否则将追究法律责任。

/68212/379383这个是简略翻译一下手册第7章的配置部分的内容，讲的是交换机模块怎么与思科交换机互连。

什么是Trunk failover，当GbESM上联的trunk链路中断时，它会关闭下联刀片服务器的INT口，让刀片服务器的流量走另一个INT口和另外的上联的Trunk链路。

有点像VRRP 的Master路由器检测上联链路，如果上联链路失效，就降低Master路由器的优先级，让另一台Backup路由器成为Master，流量走新的Master路由器。

Nic teaming允许两个或者多个物理NICs在Windows里被当作单个逻辑的网络对象，在Linux则被当作单个/dev/eth文件。

这个是刀片NIC冗余的精髓...由Broadcom的 Broadcom Advanced Control Suite (BACS)软件提供，使用的协议是Broadcom Advanced Services Protocol (BASP) 。

BASP的刀片服务器配置用BASP Advanced Control Suite软件把刀片服务器的Nic制作成Nic teaming，Smart Load Balance 和 Failover是这份文档所使用到的特性。

下面是刀片服务器的Vlan设置：Blade Server 1: VLAN 20Blade Server 2: VLAN 10, 20Blade Server 3: VLAN 10, 20Blade Server 4: VLAN 99刀片服务器1，它的NIC team被设置成第一块以太网接口配置成primary，第二块配置为Standby。

如何配置IBM刀片式集群的管理模块如何配置IBM刀片式集群的管理模块刀片式集群的管理是通过BladeCenter管理模块和管理节点间构成的网络来实现的，如何配置BladeCenter 管理模块（Management Module），是配合xcat实现刀片节点管理的重要组成部分。

公司这次购进的刀片集群，共有64个计算节点，5个刀片中心。

每个刀片中心服务器(BladeCenter Server)上面装载14个刀片节点，bcmm01~bcmm05，IP为192.168.1.101~192.168.1.105。

在具有192.168.1.*网段IP的任何一台微机上都可以进行管理模块配置。

管理模块的默认IP地址为192.168.70.125，打入此地址，弹出登录窗口，用户名和密码分别为：USERID和PASSW0RD（0为零）。

之后，可进入配置界面。

（在此过程中，可以将其IP分别设置为192.168.1.101~192.168.1.105，这里所显示的都是已经设置了IP之后的界面。

）点击Continue，出现：1，点击Blade Tasks→Configurati on，出现：把各个刀片改名，此处为node101~node114。

点击Boot Sequence中的node101，设置启动顺序为网络、软盘、光盘、硬盘。

并选中Apply to all blade servers，点击保存。

这一步就完成了。

2，点击I/O Module Tasks→Management→Advanced Setup，选择Exteral ports中的Enabled，出让所有端口。

3，点击MM Control→General Settings, 设置管理模块Name为bcmm01.点击MM Control→Network Interfaces：设置eth0和eth1。

对于bcmm01，设置eth0的IP为192.168.1.101，设置eth1内部通信专用地址为192.168.1.106；对于bcmm02，设置eth0的IP为192.168.1.102，设置eth1内部通信专用地址为192.168.1.107；对于bcmm03，设置eth0的IP为192.168.1.103，设置eth1内部通信专用地址为192.168.1.108；对于bcmm04，设置eth0的IP为192.168.1.104，设置eth1内部通信专用地址为192.168.1.109；对于bcmm05，设置eth0的IP为192.168.1.105，设置eth1内部通信专用地址为192.168.1.110；4，点击Restart MM，使所有设置生效。

IBM BladeCenter S－可为小型办公室带来巨大优势要点■一体化－将服务器、存储设备、网络和I/O 集成到一个机柜中■无需专门布线－使用100-240V的标准办公室电源插头■灵活的模块技术－集成一系列的IBM 刀片服务器，以支持各种操作系统和应用程序■易于部署、使用和管理－允许您将注意力集中于您的业务而不是IT■有助于构建更环保的I T基础架构－IBM Cool Blue TM技术可提供一整套工具，可协助计划、管理和控制电源及散热大型企业和小型公司均同样依赖其IT 系统来提供客户和合作伙伴所需的高性能、可用性及灵活性。

而要保持竞争力，各公司必须寻求经济的方式来简化和有效管理不断发展的技术需求。

尤其是中小型企业，他们不得不利用更少的空间、更少的IT资源和更紧的预算完成更多工作。

对许多企业而言，IBM BladeCenter®正是适合他们的解决方案。

许多大型企业很早就知道刀片系统可以提供下列帮助：●减少一般企业经常遇到的物理服务器无序扩展。

●尽量减少管理对日常企业运作至关重要的应用程序所需的IT 员工数量。

●能够随需添加更多服务器、存储设备和网络，从而可降低成本。

●功耗比机架服务器更低，从而可节约能源。

现在，IBM将BladeCenter的强大功能带给了中小型企业。

推出行业第一款专门针对中小型办公室和分布式环境而设计的刀片机柜IBMBladeCenter S。

简单、经济的BladeCenterS 可利用最少的IT员工实现丰硕的IT成果。

正确尺寸，正确之选小到可以放在办公桌下的新型BladeCenter S机柜可让中小型企业轻松经济地实现通常只有大型企业才可实现的IT 成果。

机柜拥有六台刀片服务器，可轻易插入一般的墙上插座，从而使您无需拥有和操作昂贵的数据中心。

位于单个机柜中的BladeCenter S几乎可支持您的所有应用程序，包括在M i c r o s o f t®Windows®、IBM AIX®和Linux®上运行的应用程序，并可集成中型企业最常用的硬件和软件：●防病毒/防火墙保护●Voice over IP●电子邮件和协作应用程序●备份和恢复●文件和打印应用程序●管理存储的简易工具BladeCenter S可与BladeCenter系列产品兼容，从而有助于实现投资保护和无缝增长。

March 2009BladeCenter SSAS Raid Module配置指南Writer An YuanIBM Technical Sales SupportBladeCenter S SAS Raid Module配置指南该配置指南包含三部分内容：一．使用SCM软件向导配置BladeCenter S 的RSSM。

设置Linux系统下的Multipath驱动。

二．RSSM Q&A 。

三．一．使用SCM配置BladeCenter S的RSSM阵列测试环境：BladeCenter S 一台，HS21(8853) 刀片服务器一台，2个SAS RAID Module （RSSM），2个RSSM电池备份单元，1个以太网交换模块，4块SAS Hot swap Disk ，SAS Expansion card (cFFv) 一块配置前准备：BCS机箱内Bay3/4插入2个SAS RAID Module，在BCS前面插入相应的电池备份模块。

在Bay1位置插入1个以太网交换模块，插入SAS热插拔硬盘以及带有SAS HBA卡的HS21 ；连接所有所需的电源线以及网络线缆。

配置步骤：1.安装SCM软件首先在刀片外的管理机(可以是台式机、笔记本或者可以和AMM通讯的管理服务器)上，安装SCM软件(图1-1)。

图1-1按照向导可以逐步完成SCM的安装，选择完全安装，如下图(图1-2)所示：图1-2安装向导结束后重启管理节点的机器，完成安装(图1-3)：图1-32.运行SCM图1-4运行SCM会通过IE窗口打开登陆界面，启动时需要输入用户名和密码（图1-3）：SCM使用本机的用户名和密码，也就是安装SCM软件这台机的管理员用户名和密码。

输入正确的用户名和密码后，选择Log in 登陆。

提示：1.SCM 1.2 不支持Firefox 3.x，请使用Firefox2.x;2.SCM自动识别浏览器首选语言，修改浏览器设置，可使用相应语言版本的SCM。

請速上網或撥0800-016-888行銷推廣處亦可洽詢 IBM 經銷業務人員System x 伺服器保固昇等與維護服務 線上訂購與諮詢/tw/ma/svrweb.htmlSystem x 伺服器售後服務網址：/support/tw/zh高效能、低耗電的運算刀鋒，適用需要大量記憶體的應用程式產品特性IBM BladeCenter LS22■ 以最新的 AMD OpteronTM四核處理器快速執行隨選的高效能工作量■ 以節能刀鋒來控制耗電量，此款刀鋒使用高效率處理器、低耗電記憶體、選購固態硬碟及 IBM Systems Director Active Energy Man-ager TM 系統管理■ 以高速 800 MHz 選項與標準記憶體優化器 (memory booster) 加速記憶體的效能IBM BladeCenter ® LS22 是一款 2 插槽四核心刀鋒伺服器，為需要大量記憶體的應用程式提供高度的效能。

IBM BladeCenter LS42 甚至還能提供更高的效能與價值，成為一個適用 2 插槽與4 插槽工作量的終極可擴充式解決方案。

有關更多的資訊，請造訪： /systems/bladecenter/hardware/servers/ls42/index.html 。

部分 LS22 刀鋒的架構屬於 IBM Ex-press Advantage TM Portfolio 的一部份，其設計與定價均以滿足中型企業的需求為前提。

在不同國家提供易於管理的 Express TM機型／架構。

臺灣銀行採購部 (案號：LP5-980029)得標項次：第四組伺服器BladeCenter LS22 項次 16, 17, 18第16項次 119,403元 (Microsoft作業系統)第17項次 107,676元 (Linux作業系統)第18項次 99,147元 (無作業系統)中央政府機關、學校、國營事業的最佳選擇 項次 16, 17, 18（型式：7901系列）1. 中央處理器1-1. 提供 2 顆 Quad-Core AMD Opteron 2.3GHz1-2. 1000MHz 的超傳輸匯流排 (HyperTransport) 時脈1-3. 每顆 CPU 整體快取 (cache) 記憶體 2MB1-4. 含 CPU 散熱裝置2. 主機板2-1. 晶片組：2-1-1. 支援Quad-Core AMD Opteron 2.3GHz2-1-2. 支援超傳輸匯流排 (HyperTransport) 時脈1000MHz 2-2. 系統記憶體：2-2-1. 8xDIMM (Dual Inline Memory Module) sockets2-2-2. 支援 ECC DDR2 800 可擴充至 64GB2-2-3. ECC (Error Checking and Correction) Support 2-3. 處理器：2-3-1. 可擴充至2顆3. 主記憶體3-1. 提供 2GB x 2 ECC (Error Checking and Correction) DDR2 667 (Double Data Rate) SDRAM (Synchronous DynamicRandom Access Memory) (雙倍資料率同步動態隨機存取記憶體) DIMM (Dual Inline Memory Module) Module 3-2. 記憶體模組有標示4. 硬碟及控制介面4-1. 提供 SAS (Serial Attached SCSI) 磁碟控制介面，支援 RAID 0, 14-2. 提供 10000RPM (Round Per Minute)，SAS (Serial Attached SCSI) 146GB 硬碟 2 顆4-3. 獨立主機本身具有提供可正常操作硬碟盒 (Bay) 2個，即現行獨立主機本身己可放入 2 個硬碟且可正常操作6. 顯示介面6-1. 解析度：1024x768 (含) 以上6-2. 具 16MB SDRAM 顯示記憶體13. 主機外殼13-1. 採用機箱型式能安裝至刀鋒機箱內14. 系統管理14-1. 具自我診斷燈號顯示功能，可顯示硬體狀況14-2. 提供上述完整功能操作手冊（IBM Director 6.1所列系統管理功能）15. 作業系統（此項目由經銷商提供）15-1. Windows 2008 Server x64 64bit 或 x86 32bit 中文版最新版作業系統含 5 個 Users15-4. Red Hat Enterprise Linux 最新版或 SUSE Linux Enterprise Server 最新版以上軟體均有合法授權證明，並附原版光碟及使用手冊。

高性能计算集群与商业应用集群的理想平台，支持AIX 和Linux 的刀片服务器IBM BladeCenter JS21刀片服务器• 面向高性能计算集群• 面向商业应用集群• 针对64位UNIX 和Linux 优化设计的刀片服务器• 基于POWER 架构的可靠性和性能• BladeCenter 产品家族的一员，支持多种连接技术，轻松整合企业应用要点面向高性能计算集群面对性能要求苛刻的高性能计算(HPC)领域，需要创新型的服务器集群系统来优化整个运算环境，服务器不仅仅要性能卓著，而且要更为可靠和易用，并且具有更为优异的性价比以适应用户的需求。

IBM BladeCenter JS21刀片服务器集群系统以其强大的技术优势来满足用户对高性能计算集群系统的各项要求：• 针对高性能计算环境，卓越的性能价格比。

• 通过内置于PowerPC970处理器内部的AltiVec 向量处理单元来加速数据的分析和计算。

• 节省能耗，减少维护成本，提高操作的有效性。

• 节省空间，在标准机架中可以容纳更多的处理器。

领先的POWER 架构I BM BladeCenter JS21刀片服务器采用了IBM 领先的POWER 架构技术 - PowerPC970MP 处理器，它是64位PowerPC 系列的处理器，具有尖端的超标量体系结构设计，具有多管线执行单元，可提供强大的通用计算处理能力。

PowerPC970MP 的每个内核有64KB 一级指令高速缓存，32KB 一级数据高速缓存和1MB 二级高速缓存。

更为重要的是目前JS21可以支持4-core(2个双核)CPU 结构，使之对于诸如网格、生命和地球科学研究以及其他数据密集型或浮点计算密集型等应用，都具备了更为显著的性能属性，可以满足绝大多数高性能计算的性能要求。

Po w e r P C 970M P 处理器具有AltiVec SI MD(Single I nstruction Multiple Data)加速器特性。

IBM eServer BladeCenter JS20快速设置配置Management Module 的IP 地址BladeCenter JS20 默认使用DHCP。

若您希望使用静态IP，请执行以下步骤：1、将提供的交叉线缆连接到BladeCenter Management Module 卡和一个具有web 浏览器的工作站。

详情请参见图2。

2、Management Module（MM）默认IP 地址是192.168.70.125。

使用w eb 浏览器连接该IP。

输入用户名USERID 和密码PASSW0RD。

注意PASS W0RD 中的0 是数字零（0）。

3、在MM web 界面中，选择MM Control > Network Interfaces。

图1：BladeCenter Management Module Network Interfaces在相应的表单中输入需要的外部（eth0）IP 地址、主机名、子网和网关，并点击Save 按钮。

建议您保留内部网络接口（eth1 ——IP 地址是192.168.70. 126）的默认设置。

选择MM Control > Restart MM重启MM，然后点击表单中显示的Restart 按钮。

这会重启MM，同时更新为新的IP 配置。

使用标准以太网线缆将MM 联网。

BladeCenter JS20 连线将以太网线缆连接到BladeCenter 背部下方交换机模块（I/O module 2）的第一个端口。

使用另一条以太网线缆连接到BladeCenter 背部右方的Managem ent Module 卡。

然后将这两条线缆连接到您的网络中。

详情参见图2。

注意：如果您是第一次连接BladeCenter 到网络，建议不要使用DHCP，请按照本文开始部分的指示完成配置。

当前，第一个交换机模块专门用于Serial O ver LAN（SOL）而不是其他目的。

IBM BladeCenter HS22VProduct Guide (withdrawn product)The IBM® BladeCenter® HS22V is a two-way high-performance blade server that offers outstanding performance for virtualization with new levels of memory capacity and CPU performance. It offers 18 DIMM slots supporting up to 288 GB of DDR3 memory for more and larger virtual machines per blade. HS22V supports durable solid-state drives and hardware RAID 0,1 providing outstanding reliability when virtualizing multiple workloads on a single blade. Combining the HS22V with Virtual Fabric from IBM BladeCenter provides flexible, easy, fast, and reliable I/O that supports up to 40 GbE to each blade and up to a total of eight ports of I/O per blade.The HS22V is shown in Figure 1.Figure 1. IBM BladeCenter HS22VDid you know?BladeCenter HS22V delivered leadership performance for a 2-processor blade server running virtualization applications based on SPECvirt_sc2010 benchmark. The HS22V achieved an overall performance score of 1,*************************************************************(3.46GHzwith256KB L2 cache per core and 12MB L3 cache per processor—2 processors/12 cores/6 cores per chip), 288 GB of memory, two 50 GB disk drives, and Red Hat Enterprise Linux 6.0, and Kernel-based Virtual Machine (KVM) hypervisor.Click here to check for updatesLocations of key components and connectors Figure 2 shows the inside of the server indicating key components.Figure 2. IBM BladeCenter HS22VStandard specificationsThe following table lists the standard models. Table 2. Standard modelsModel Processor** (2 max)Memory(std / max)Eth†RAID Bays(used/max)DiskdrivesSlots(used/max)Models with Intel Xeon 5500 Series Processors: 4-core and 2-core7871-B4x*1x Xeon E5540 4C2.53GHz8MB 1066MHz 80w3x 2GB / 144GB2x 1Gb SASRAID0 / 2Open0 / 27871-C4x*1x Xeon X5570 4C2.93GHz8MB 1333MHz 95w3x 2GB / 144GB2x 1Gb SASRAID0 / 2Open0 / 2Models with Intel Xeon 5600 Series Processors: 4-core7871-A5x*1x Xeon E5603 4C1.60GHz4MB 1066MHz 80w1x 4GB / 288GB2x 1Gb SASRAID0 / 2Open0 / 27871-A7x*1x Xeon E5607 4C2.26GHz8MB 1066MHz 80w1x 4GB / 288GB2x 1Gb SASRAID0 / 2Open0 / 27871-G2x1x Xeon E5620 4C2.40GHz12MB 1066MHz 80w 3x 2GB / 288GB2x 1Gb SASRAID0 / 2Open0 / 27871-B5x*1x Xeon X5647 4C2.93GHz12MB 1066MHz 130w3x 4GB / 288GB2x 1Gb SASRAID0 / 2Open0 / 27871-H5x*1x Xeon X5667 4C3.06GHz12MB 1333MHz 95w3x 2GB / 288GB2x 1Gb SASRAID0 / 2Open0 / 27871-C5x*1x Xeon X5672 4C3.20GHz12MB 1333MHz 95w3x 4GB / 288GB2x 1Gb SASRAID0 / 2Open0 / 27871-C7x*1x Xeon X5687 4C3.60GHz12MB 1333MHz 130w3x 4GB / 288GB2x 1Gb SASRAID0 / 2Open0 / 2Models with Intel Xeon 5600 Series Processors: 6-core7871-N2x*1x Xeon L5640 6C2.26GHz12MB 1333MHz 60w3x 2GB / 288GB2x 1Gb SASRAID0 / 2Open0 / 27871-B6x*1x Xeon E5649 6C2.53GHz12MB 1333MHz 80w3x 4GB / 288GB2x 1Gb SASRAID0 / 2Open0 / 27871-D4x*1x Xeon E5649 6C2.53GHz12MB 1333MHz 80W3x 4 GB / 288GB2x 1 Gb SASRAID0 / 2Open0 / 27871-H2x*1x Xeon X5650 6C2.66GHz12MB 1333MHz 95w3x 2GB / 288GB2x 1Gb SASRAID0 / 2Open0 / 2Processor optionsThe HS22V supports the processor options listed in the following table. The server supports one or two processors. The table also shows which server models have each processor standard. If there is no corresponding where-used model for a particular processor, then this processor is only available through Configure to Order (CTO).Table 6. Processor optionsPart number Intel Xeon processor description Modelswhere usedIntel Xeon 5600 Series Processors: 4-core81Y6038Xeon E5603 4C 1.60GHz 4MB 1066MHz 80w A5x81Y6039Xeon E5606 4C 2.13GHz 8MB 1066MHz 80w-81Y6040Xeon E5607 4C 2.26GHz 8MB 1066MHz 80w A7x69Y0927Xeon E5620 4C 2.40GHz 12MB 1066MHz 80w G2x69Y0926Xeon E5630 4C 2.53GHz 12MB 1066MHz 80w-69Y4746Xeon L5609 4C 1.86GHz 12MB 1066MHz 40w-69Y4743Xeon L5618 4C 1.86GHz 12MB 1066MHz 40w-81Y6041Xeon X5647 4C 2.93GHz 12MB 1066MHz 130w B5x81Y6043Xeon X5672 4C 3.20GHz 12MB 1333MHz 95w C5x81Y6045Xeon X5687 4C 3.60GHz 12MB 1333MHz 130w C7xIntel Xeon 5600 Series Processors: 6-core69Y4744Xeon E5645 6C 2.40GHz 12MB 1333MHz 80w-81Y6042Xeon E5649 6C 2.53GHz 12MB 1333MHz 80w B6x69Y4745Xeon L5638 6C 2.0GHz 12MB 1333MHz 60w-69Y0928Xeon L5640 6C 2.26GHz 12M 1333MHz 60w N2x69Y0924Xeon X5650 6C 2.66GHz 12M 1333MHz 95w H2x, HAx69Y0923Xeon X5660 6C 2.80GHz 12MB 1333MHz 95w HXx69Y0922Xeon X5670 6C 2.93GHz 12MB 1333MHz 95w H4x81Y6044Xeon X5675 6C 3.06GHz 12MB 1333MHz 95w C6x69Y4748Xeon X5680 6C 3.33GHz 12MB 1333MHz 130w F2x81Y6046Xeon X5690 6C 3.46GHz 12MB 1333MHz 130w C8xIntel Xeon 5500 Series Processors: 4-core49Y5151Xeon E5506 4C 2.13GHz 4MB 800MHz 80w-49Y5163Xeon E5540 4C 2.53GHz 8MB 1066MHz 80w B4x49Y5172Xeon X5570 4C 2.93GHz 8MB 1333MHz 95w C4xMemory optionsIBM DDR3 memory is compatibility tested and tuned for optimal System x performance and throughput. IBM memory specifications are integrated into the light path diagnostics for immediate system performance feedback and optimum system uptime. From a service and support standpoint, IBM memory automatically assumes the IBM system warranty, and IBM provides service and support worldwide.Part number Description Maximumquantitysupported Models where used49Y1427 1 GB (1x 1 GB, 1Rx8, 1.5 V) PC3-10600 CL9 ECC DDR3 1333 MHz18-49Y1428 2 GB (1x 2 GB, 2Rx8, 1.5 V) PC3-10600 CL9 ECC DDR3 1333 MHz18-49Y1429 2 GB (1x 2 GB, 1Rx4, 1.5 V) PC3-10600 CL9 ECC DDR3 1333 MHz18-44T1594 2 GB (1x 2 GB, 1Rx8, 1.5 V) PC3-10600 CL9 ECC DDR3 1333 MHz18-46C0560 2 GB (1x 2 GB, 1Rx8, 1.35 V) PC3L-10600 CL9 ECC DDR3 1333 MHz18-49Y1430 4 GB (1x 4 GB, 2Rx4, 1.5 V) PC3-10600 CL9 ECC DDR3 1333 MHz18-44T1596 4 GB (1x 4 GB, 2Rx8, 1.5 V) PC3-10600 CL9 ECC DDR3 1333 MHz18-46C0563 4 GB (1x 4 GB, 1Rx4, 1.35 V) PC3L-10600 CL9 ECC DDR3 1333 MHz18-46C0564 4 GB (1x 4 GB, 2Rx8, 1.35 V) PC3L-10600 CL9 ECC DDR3 1333 MHz18-46C05688 GB (1x 8 GB, 2Rx4, 1.35 V) PC3L-10600 CL9 ECC DDR3 1333 MHz18-49Y14318 GB (1x 8 GB, 2Rx4, 1.5 V) PC3-10600 CL9 ECC DDR3 1333 MHz18-Table 8. Memory options for servers with Xeon 5600 series processorsPart number Description MaximumquantitysupportedModelswhere usedStandard DIMMs (1.5 V)49Y1427 1 GB (1x 1 GB, 1Rx8, 1.5 V) PC3-10600 CL9 ECC DDR3 1333 MHz18-49Y1428 2 GB (1x 2 GB, 2Rx8, 1.5 V) PC3-10600 CL9 ECC DDR3 1333 MHz18F2x, F3x,G2x,G4x, GDx,H2x,H4x, H5x,HAx,N2x49Y14292GB (1x 2GB, 1Rx4, 1.5V) PC3-10600 CL9 ECC DDR3 1333 MHz18-44T15942GB (1x 2GB, 1Rx8, 1.5V) PC3-10600 CL9 ECC DDR3 1333 MHz18-44T1596 4 GB (1x 4 GB, 2Rx8, 1.5 V) PC3-10600 CL9 ECC DDR3 1333 MHz18-49Y14304GB (1x 4GB, 2Rx4, 1.5 V) PC3-10600 CL9 ECC DDR3 1333 MHz18HXx49Y14318GB (1x 8GB, 2Rx4, 1.5V) PC3-10600 CL9 ECC DDR3 1333 MHz18-Low Power DIMMs (1.35 V)46C05602GB (1x 2GB, 1Rx8, 1.35V) PC3L-10600 CL9 ECC DDR3 1333 MHz18-46C05634GB (1x 4GB, 1Rx4, 1.35V) PC3L-10600 CL9 ECC DDR3 1333 MHz18A5x, A7x,B5x,B6x, C5x,C6x,C7x, C8x 46C05644GB (1x 4GB, 2Rx8, 1.35V) PC3L-10600 CL9 ECC DDR3 1333 MHz18-46C05688GB (1x 8GB, 2Rx4, 1.35V) PC3-10600 CL9 ECC DDR3 1333 MHz18-46C059916GB (1x16 GB, 2Rx4, 1.35V) PC3L-10600 CL9 ECC DDR3 1333 MHz18-Internal disk storage optionsThe HS22V blade server features an onboard LSI Logic 53C1064E SAS controller that connect to two SAS ports at the front of the HS22V motherboard. The LSI Logic 53C1064E SAS controller provides RAID 0 or RAID 1 capability and supports up to two internal non-hot-swap 1.8-inch solid state drives (SSDs).The following table lists the solid state drive options available for internal storage.Table 9. SSD options for internal disk storagePart number Featurecode Description MaximumsupportedEnterprise SSDs49Y6124A3AP IBM 400GB SATA 1.8" MLC Enterprise SSD249Y6119A3AN IBM 200GB SATA 1.8" MLC Enterprise SSD200W1120A3HQ IBM 100GB SATA 1.8" MLC Enterprise SSD243W77465420IBM 200GB SATA 1.8" MLC SSD243W77265428IBM 50GB SATA 1.8" MLC SSD2 Enterprise Value SSDs49Y5993A3AR IBM 512GB SATA 1.8" MLC Enterprise Value SSD200W1227A3TH IBM 256GB SATA 1.8" MLC Enterprise Value SSD200W1222A3TG IBM 128GB SATA 1.8" MLC Enterprise Value SSD249Y5834A3AQ IBM 64GB SATA 1.8" MLC Enterprise Value SSD2Internal backup unitsThe server does not support an internal tape drive option.Optical drivesThe server does not support an optical drive option, however it does interface to the optical drive installed in the BladeCenter chassis media tray if one is installed there.I/O expansion optionsStorage host bus adaptersThe following table lists storage HBAs supported by HS22V server. Table 12. Storage adaptersPart number Description SlotssupportedMaximumsupportedCombination Ethernet and Fibre Channel44X1940QLogic Eth and 8Gb Fibre Channel Exp Card (CFFh)CFFh1Fibre Channel46M6140Emulex 8Gb Fibre Channel Expansion Card (CIOv) for IBM BladeCenter CIOv146M6065QLogic 4Gb Fibre Channel Expansion Card (CIOv) for IBM BladeCenter CIOv144X1945QLogic 8Gb Fibre Channel Expansion Card (CIOv) for IBM BladeCenter*CIOv1SAS46C7167ServeRAID-MR10ie (CIOv) Controller for IBM BladeCenter CIOv143W4068SAS Connectivity Card (CIOv)CIOv1HBAs in the IBM BladeCenter PCI Express I/O Expansion Unit39R6527QLogic 4Gb FC Dual-Port PCIe HBA for IBM System x PCI-E239R6525QLogic 4Gb FC Single-Port PCIe HBA for IBM System x PCI-E2* The QLogic 8Gb Fibre Channel Expansion Card (CIOv) is standard in model HXx as listed in Table 2PCIe SSD adaptersThe HS22V server supports the High IOPS SSD adapters listed in the following table. The adapters must be installed in an IBM BladeCenter PCI Express I/O Expansion Unit.Table 13. SSD adaptersPart number Description Slots supported Maxquantity46M0878IBM 320GB High IOPS SD Class SSD PCIe Adapter PCI Express I/O Expansion Unit(43W4391)246M0877IBM 160GB High IOPS SS Class SSD PCIe Adapter PCI Express I/O Expansion Unit(43W4391)2For information about these adapters, see the IBM High IOPS SSD PCIe Adapters at-a-glance guide: /abstracts/tips0729.html?OpenPower suppliesServer power is derived from the power supplies installed in the BladeCenter chassis. There are no server options regarding power supplies.Integrated virtualizationThe external SAS cables listed in the following table are supported with external expansion enclosures and MR10ie RAID controllers connected to SAS Connectivity Modules.Table 20. External SAS cables for external storage expansion enclosuresPart number Description Maximum quantitysupported per enclosure39R6531IBM 3 m SAS Cable139R6529IBM 1 m SAS Cable1External disk storage systemsThe following table lists the external storage systems that are supported by the server and can be ordered through System x sales channel. The server may support other IBM disk systems that are not listed in this table. Refer to IBM System Storage Interoperability Center for further information,/systems/support/storage/ssic.Table 21. External disk storage systemsPart number Description1746A2D IBM System Storage DS3512 Express Dual Controller Storage System1746A2S IBM System Storage DS3512 Express Single Controller Storage System1746A4D IBM System Storage DS3524 Express Dual Controller Storage System1746A4S IBM System Storage DS3524 Express Single Controller Storage System181494H IBM System Storage DS3950 Model 94181498H IBM System Storage DS3950 Model 98181492H IBM System Storage EXP395 Expansion Unit1746A2E IBM System Storage EXP3512 Express Storage™ Expansion Unit1746A4E IBM System Storage EXP3524 Express Storage Expansion UnitFor more information, see the list of IBM Redbooks Product Guides in the Storage Systems category: /portals/systemx?Open&page=pg&cat=externalstorageExternal backup unitsThe server supports the external backup attachment options listed in the following table.Table 22. External backup optionsPart number DescriptionExternal tape expansion enclosures for internal tape drives87651UX1U Tape Drive Enclosure8767HHX Half High Tape Drive Enclosure87651NX1U Tape Drive Enclosure (with Nema 5-15P LineCord)8767HNX Half High Tape Drive Enclosure (with Nema 5-15P LineCord)Tape enclosure adapters (with cables)44E8869USB Enclosure Adapter Kit40K2599SAS Enclosure Adapter KitInternal backup drives supported by external tape enclosures46C5364IBM RDX Removable Hard Disk Storage System - Internal USB 160 GB Bundle 46C5387IBM RDX Removable Hard Disk Storage System - Internal USB 320 GB Bundle 46C5388IBM RDX Removable Hard Disk Storage System - Internal USB 500 GB Bundle 46C5399IBM DDS Generation 5 USB Tape Drive39M5636IBM DDS Generation 6 USB Tape Drive43W8478IBM Half High LTO Gen 3 SAS Tape Drive44E8895IBM Half High LTO Gen 4 SAS Tape Drive49Y9898IBM Half High LTO Gen 5 Internal SAS Tape DriveExternal backup units*362516X IBM RDX Removable Hard Disk Storage System - External USB 160 GB Bundle362532X IBM RDX Removable Hard Disk Storage System - External USB 320 GB Bundle362550X IBM RDX Removable Hard Disk Storage System - External USB 500 GB Bundle3628L3X IBM Half High LTO Gen 3 External SAS Tape Drive (with US line cord)3628L4X IBM Half High LTO Gen 4 External SAS Tape Drive (with US line cord)3628L5X IBM Half High LTO Gen 5 External SAS Tape Drive (with US line cord)3628N3X IBM Half High LTO Gen 3 External SAS Tape Drive (without line cord)3628N4X IBM Half High LTO Gen 4 External SAS Tape Drive (without line cord)3628N5X IBM Half High LTO Gen 5 External SAS Tape Drive (without line cord)3580S3V System Storage TS2230 Tape Drive Express Model H3V3580S4V System Storage TS2240 Tape Drive Express Model H4V3580S5E System Storage TS2250 Tape Drive Express Model H5S3580S5X System Storage TS2350 Tape Drive Express Model S533572S4R TS2900 Tape Library with LTO4 HH SAS drive & rack mount kit3572S5R TS2900 Tape Library with LTO5 HH SAS drive & rack mount kit35732UL TS3100 Tape Library Model L2U Driveless35734UL TS3200 Tape Library Model L4U Driveless46X2682†LTO Ultrium 5 Fibre Channel Drive46X2683†LTO Ultrium 5 SAS Drive Sled46X2684†LTO Ultrium 5 Half High Fibre Drive Sled46X2685†LTO Ultrium 5 Half High SAS Drive Sled46X6912†LTO Ultrium 4 Half High Fibre Channel Drive Sled46X7117†LTO Ultrium 4 Half High SAS DriveV2 Sled46X7122†LTO Ultrium 3 Half High SAS DriveV2 Sled* Note: The external tape drives listed can be ordered through System x sales channel. Server may support other IBM tape drives that are not listed in this table. Refer to IBM System Storage Interoperability Center for further information.† Note: These part numbers are the tape drives options for 35732UL and 35734UL.For more information, see the list of IBM Redbooks Product Guides in the Backup units category:/portals/systemx?Open&page=pg&cat=tapeIBM Global FinancingTrademarksLenovo and the Lenovo logo are trademarks or registered trademarks of Lenovo in the United States, other countries, or both. A current list of Lenovo trademarks is available on the Web athttps:///us/en/legal/copytrade/.The following terms are trademarks of Lenovo in the United States, other countries, or both:Lenovo®BladeCenter Interoperability GuideBladeCenter®ServeRAIDServerGuideServerProven®System x®The following terms are trademarks of other companies:Intel® and Xeon® are trademarks of Intel Corporation or its subsidiaries.Linux® is the trademark of Linus Torvalds in the U.S. and other countries.Microsoft®, Windows Server®, and Windows® are trademarks of Microsoft Corporation in the United States, other countries, or both.Other company, product, or service names may be trademarks or service marks of others.。
