凯聪SIP1018型网络摄像机说明书

网络摄像机快速指南前言本节内容的目的是确保用户通过本手册能够正确使用产品，以避免操作中的危险或财产损失。

在使用此产品之前，请认真阅读产品手册并妥善保存以备日后参考。

使用前说明●访问本公司官网（）获取说明书、应用工具和开发资料。

●使用前请先对设备进行校时，校时的具体配置方法请参见《网络摄像机操作手册》。

符号约定对于文档中出现的符号，说明如下所示。

安全使用注意事项●产品安装使用过程中，必须严格遵守国家和使用地区的各项电气安全规定。

●请使用正规厂家提供的电源适配器，电源适配器具体要求参见产品参数表，建议为每台设备配备独立的适配器。

●根据国家相关标准，对弱电设备供电时，要求供电电流不超过8A并且功率不超过100W，防止发生安全事故。

●为减少火灾或电击危险，请勿让产品受到雨淋或受潮。

●应该在建筑物安装配线中组入易于使用的断电设备。

●在设备安装时，请确保产品固定牢固。

●如果产品工作不正常，请联系购买产品的商店或最近的服务中心，不要以任何方式拆卸或修改产品。

（对未经认可的修改或维修导致的问题，本公司不承担任何责任）。

●避免将产品安装到振动或冲击环境，并使产品远离电磁干扰的地点。

（忽视此项可能会损坏产品）。

●请勿直接触碰产品散热部件，以免烫伤。

●室内产品请勿安装在可能淋到水或其他液体的环境。

●请勿在极热、极冷、多尘、有腐蚀性、高盐碱或者高湿度的环境下使用产品，具体温、湿度要求参见产品的参数表。

●设备需存放于干燥无腐蚀性气体环境，避免阳光直射。

●避免将镜头对准强光（如灯光照明、太阳光或激光束等），否则会损坏图像传感器。

●避免热量积蓄，保持产品周边通风流畅。

●请勿直接触碰到图像传感器，若有必要清洁，请将柔软的干净布用酒精稍微湿润，轻轻拭去尘污；当产品不使用时，请将防尘盖加上，以保护图像传感器。

●设备接入互联网可能面临网络安全问题，请您加强个人信息及数据安全的保护。

当您发现设备可能存在网络安全隐患时，请及时与我们联系。

网络摄像机第一次使用,把摄像机和路由器之间用网线连接好,摄像机自带的光盘里面,软件打开,打开查找器工具(此工具使用于局域网内查找和修改摄像机的IP和端口),高级模式进入（要确保电脑和摄像机要在一个路由器下面，这样查找器才可以查找到摄像机的IP地址和端口）,摄像机出厂的IP地址是192.168.1.126,端口是81,查找器右下角的内部访问地址后面的打开按钮,直接点打开按钮即可,（第一次使用的时候,会提示您安装一个小的视频安装软件,下载完后,刷新浏览器就可以直接观看监控画面）第一:摄像机无线设置:首先进路由器里面，以TP-LINK的路由器为例，（路由器的IP地址，登陆的用户名和密码，一般路由器下面有贴）地址是http://192.168.1.1左侧的无线参数点开，基本设置如下图所示：广州市汉之升电子路由器的无线设置按照这个设置(使用无线时把无线路由器的信道（也叫频段）改为1-11以内（手动设置）不要用12或13信道，无线的SSID 用字母和数字的组合，不要用汉字或特殊符号！此外，无线加密也手动指定成某种加密的方式，不要用自动选择之类的（比如手动指定为WPA2-PSK、AES模式）！这样，通过有线连接摄像机打开网页后，搜索无线信号就能正常搜索到了！搜索到无线路由器后，选中自己的无线路由器并输入相应的无线密码，然后拔掉网线，再用查找器查找一下,如果可以查找到无线设置完成)广州市汉之升电子下面看摄像机无线设置，打开查找器，从高级模式进入，如下图：内部访问地址，后面的打开按钮打开摄像机，进入到摄像机的观看界面如下图所示：广州市汉之升电子广州市汉之升电子点击设置按钮，，选择网络设置---无线局域网设置打开，出现下面的界面广州市汉之升电子使用无线局域网打勾，搜索2-3次,选择列表中自己的路由器线相对应的SSID号，网络类型选择infra，广州市汉之升电子广州市汉之升电子 安全模式和路由器保持一致，加密类型和路由器一致，密码和路由器的无线密码保持一致，例如下图：点击设置，摄像机会重启30秒，重启完拔掉网线，就可以无不用接网线了。

[教程]凯聪网络摄像机SIP1406使用说明说明书设置教程视频教程[复制链接]luming版主∙ 串个门∙ 加好友∙ 打招呼∙ 发消息 电梯直达楼主发表于 2012-10-18 13:19:30|只看该作者|倒序浏览 凯聪网络摄像机SIP1406使用说明 说明书 设置教程设备接口和连接说明------------------------------------------------沙发搜索局域网下的网络摄像机---------------------------------------板凳 局域网监控、控件安装、界面介绍-------------------------------地板 远程监控--------------------------------------------------------------五楼 无线设置--------------------------------------------------------------六楼 双向语音、本地录像和回放---------------------------------------七楼 移动侦测、邮件报警和手机卡存储-------------------------------八楼 其他设置--------------------------------------------------------------九楼 集中监控端-----------------------------------------------------------十楼 安卓手机和平板监控---------------------------------------------十一楼SIP1406视频教程-------------------------------------------------十二楼网络摄像机本主题由luming 于 2012-10-26 16:54:25 打开 分享到:QQ 空间腾讯微博腾讯朋友 收藏0使用道具举报∙luming版主∙ 串个门∙ 加好友∙ 打招呼∙ 发消息 沙发发表于 2012-10-26 10:36:40|只看该作者一、设备接口示意图长按复位键15秒钟以上，设备将恢复出厂默认值，并自动重启。

尊敬的用户，因本机功能设置较为专业，使用前，请您仔细阅读本系统用户手册。

高清网络摄像机使用手册声明本手册可能在某些技术细节方面描述不够准确或存在印刷错误，假如您在使用过程中按照使用手册无法解决问题时，请致电我公司技术部垂询相关操作方法。

本手册的内容将做不定期的更新，恕不另行通知。

装箱清单名称数量高清网络摄像机主机1台12V电源1套《高清网络摄像机用户使用说明书》1本配套光盘1张合格证以及保修卡各1张使用注意事项1、安装环境✋远离高温的热源和环境；避免阳光直接照射；✋为确保摄像机的正常散热，应避开通风不良的场所，注意防水，防潮，防雷。

如需安装到户外，则需要安置防水箱，将摄像机固定其中；✋本机应水平安装或壁挂安装，避免安装在会剧烈震动的场所，勿将其它设备放于本机上。

2、避免电击和失火✋切记勿用湿手触摸电源和摄像机；✋勿将液体溅落在摄像机上，以免造成机器内部短路或失火；✋勿将其它设备直接放置于本摄像机上部；✋非专业人员请勿自行拆开机壳，避免损坏和电击；3、运输与搬运✋本机的包装经过抗震设计和实验，确保在运输过程中摄像机不会受到意外损坏，所以在搬运本机时，最好使用原来的包装材料和纸箱；✋避免在过冷、过热的场所间相互搬动摄像机，以免机器内部产生结露，影响机器的使用寿命；✋严禁带电搬动本机，否则会损坏主板；目录1 产品简介 (4)1.1产品简介 (4)1.2功能简介 (4)1.3技术规格 (4)2 外观与说明 (5)3 设备与安装 (6)3.1 运行环境 (7)3.2 设备安装 (7)4 IE 版客户端 (7)4.1 准备工作 (7)4.2 开始登陆 (7)4.3 功能简介 (8)4.3.1实时监视 (8)4.3.2录像回放 (10)4.3.3 参数设置 (11)4.3.3.1基本信息设置 (12)4.3.3.2网络参数设置 (15)4.3.3.3通道参数设置 (20)4.3.3.4报警参数设置 (24)4.3.3.5前端存储设置 (26)5.常见问题解答 (29)5.1无法通过浏览器访问网络摄像机 (29)5.2云台或球型摄像机不能控制 (30)5.3程序升级以后，无法正常播放视频 (30)5.4如何使网络摄像机在公网（Internet）上进行视频传输服务 (30)5.5为何正常数据不能通过交换机 (31)5.6为何升级后通过浏览器访问网络摄像机会出错 (31)6.附录 (32)附录A关于网络摄像机端口占用（映射）的问题说明 (32)附录B 出厂默认参数 (33)7.术语解释 (34)1产品简介1.1产品简介感谢您使用本公司产品，我们将向您提供最好的服务。

（物联网）智能高速球型摄像机使用手册V—序言—本说明书是智能高速球型摄像机用户的基本说明书。

本说明书由重要的安全和警告信息、智能高速球型摄像机产品的功能说明、性能特点及参数、安装步骤、壹般故障及解决方法、维护等使用智能高速球型摄像机时必须了解的内容组成。

首次使用智能高速球型摄像机的用户及以前使用过类似产品的用户于使用本机前最好先阅读壹遍本说明书。

如可能，请最好从第1页开始按顺序阅读。

如用户希望只见需要的部分，也可参考目录加以选择。

目录—重要的安全和警告信息—2—注意事项—3—产品简介—4—性能特点—4—功能说明—5—壹般操作—6—球机设定—7—系统安装—13—球机性能指标—18—壹体化摄像机性能指标—19—常见故障分析—20－维护－21—重要的安全和警告信息—于开始安装和使用之前，请先阅读以下的警告信息：1．应该由经过培训的有资格的服务人员进行安装和维护，且遵守当地的电器安 装规定。

2.室内球机设计制造为室内使用，不能暴露安装于能够淋到雨或非常潮湿的地方。

3．于重新安装或维修后，需测量电路部分和外壳之间的电阻，检查是否绝缘良 好。

应保证电路部分和外壳不短路。

4.于安装中用于支撑重量的材料，应能承受四倍于球机的重量。

产品和手册中有下列标记：—注意事项— 1． 于安装使用全方位智能化高速球型摄像机机之前，请首先仔细阅读本说明书。

2． 球机使用电源：DC12V 。

球机输入额定电压会于球机底座或相应的地方标明。

3． 球机内部为精密光学及电子器件，于运输保管及安装过程中要防止重压、剧烈震动等不正确的操作方法，否则可能对产品造成损坏。

4． 请不要自行拆卸球机内部器件，以免影响使用，里面没有用户自行维修的零件。

5． 使用中必须遵守各项电气安全标准，配用本机自带的专用电源。

RS-485及视频信号于传输过程中应和高压设备或电缆保持足够的距离，必要时仍要做好防雷击、防浪涌等防护措施。

6． 不要直接将高速球置于室外使用，避免球机淋雨、受潮等。

D-Link网络摄像机DCS-950（G）ST-SIP平台使用手册D-Link2008年1月一、产品介绍1、产品简介D-Link网络摄像机为家庭和小型办公用户提供最新和全面的监视系统。

它通过连接到宽带互联网或本地网络来提供远程高质量的音频和视频监控。

您可以通过互联网来访问和控制摄像机。

在你远程监视和接收摄像机捕获的视频和声音时，您可以通过电信专业视频监控平台直接进行快照和记录，并保存到一个本地硬盘上。

通过图像运动检测记录功能，报警消息和强大的多功能摄像机监视和管理软件，此摄像机为用户提供了一个可在本地站点或世界任何地方进行远程监控的方便、快捷、全面的监视系统。

D-Link网络摄像机系列中提供了有线或无线连接有两种规格摄像机供选择：无线模式提供了灵活的安装，以及在不能使用以太网线缆的地方采用自由的无线连接。

本摄像机为您的无线网络建立安全连接支持WPA-PSK，TKIP和WEP加密。

2、产品特点●可通过3G手机访问网络摄像机，支持3GPP协议●高品质图像压缩，可在640*480的分辨率时得到30帧/秒画面的视频流●可通过802.11g无线网络和10/100Mbps自适应有线网络快速访问●MPEG-4视频压缩●4倍Zoom In/Out数位变焦●提供Lux的低照度感光●内建麦克风收音●实时抓拍，方便回放，触发事件浏览。

利用Web管理接口，可远程管理二、使用说明1、网络连接示意图2、接口描述3、指示灯说明● 设备通电时电源指示灯常亮 ● 网络连接成功工作指示灯为绿色 ● 网络工作时工作指示灯为绿色闪烁4、安装步骤 （1）硬件安装步骤、第一步：先将天线安装到设备上第二步：插上设备电源第三步：插上网线，通过网线做初步配置，默认IP 地址为第四部：在配置完毕后可根据需要安装支架固定在墙体上软件安装步骤Case 1.1.1：登陆ipcam1. 在ie 地址栏上输入“.0.20”，回车；2. 出现如下页面后，输入帐号：admin ，密码：admin ；回车或点击“登录”按钮3. 出现如下页面： Case 2.2.1：局域网设置1. 选择“启用DHCP ”，点击上方或下方“保存设置”按钮，ie 重定向至登陆页面，检查ie地址栏，其ip 变为dhcp 所分配的新ip 地址；2. 选择“启用静态ip 地址”，此栏其他选项可更改；3. 在“ip 地址”栏输入新ip 地址，点击上方或下方“保存设置”按钮，等待ie 更新完毕，ip 显示为更改后的ip 地址；4. 在“子网掩码”栏输入新子网掩码，点击上方或下方“保存设置”按钮，等待ie 更新完毕，显示为更改后的子网掩码；5. 在“默认网关”栏输入新默认网关，点击上方或下方“保存设置”按钮，等待ie 更新完毕，显示为更改后的默认网关；6. 在“默认DNS ”栏输入新默认DNS ，点击上方或下方“保存设置”按钮，等待ie 更新完毕，显示为更改后的默认DNS ；7. 在“备用DNS ”栏输入新备用DNS ，点击上方或下方“保存设置”按钮，等待ie 更新完毕，显示为更改后的备用DNS ；Case 2.2.2：PPPoE 设置1. 选择“启用”按钮2. 输入pppoe 用户名和密码3. 点击上方或下方“保存设置”按钮4. 连接成功则显示pppoe 服务器所分配的ip 地址，5. 从internet 连接时，输入此ip ，检查是否连接成功Case 2.2.3：平台参数设置例SIP 设备名：CTC-IPCAM02SIP 用户名: dlink SIP 密码: 123456SIP 服务器域名: SIP 服务端口：事件服务： RJ45 网络接口 5V DC 电源接口无线天线电源指示灯 工作指示灯设备重启按钮 按住5秒以上则恢复到出厂设置Case 2.3.1：无线关闭1. 选择“禁用”2. 点击上方或下方“保存设置”按钮3. 检查“无线网络连接状态”Case 2.3.2：基本无线网络设置1. 选择“启用”2. 点击“基站搜索”，弹出如下页面：3. 选择搜索到的基站，点击“应用”按钮，等待ie自动刷新完毕Case 2.3.3: 无线网络安全设置1.无线网络完全方式选址为无加密模式，需要在AP上无线网络设置为无加密模式2.无线网络完全方式选择为WEP模式，需要在AP上无线网络设置为WEP模式，权限模式：自动加密模式：64Bit 加密格式：HEX安全加密（WEP）密钥中设置密码：123456 再选择生成密钥，AP会自动生成4个密钥复制密钥1，把相应的密钥复制到到web页面上，在web页面上选择KEY1为默认密钥。

Owner’s ManualFull HD IP Bullet CameraO2VLB2Version 1.0WelcomeThank you for purchasing this network camera!This owner’s manual is designed to be a reference tool for your system.Please read this manual carefully before operating the unit and retain it for future reference. Should you require any technical assistance, please contact Speco Technologies Technical Support.Important Safeguards and Warnings1．Electrical safetyAll installation and operation here should conform to local electrical safety codes.Use a certified/listed 12VDC Class 2 power supply only.Please note: Do not connect two power supplying sources to the device at the same time; it may result in device damage! The product must be grounded to reduce the risk of electric shock.Improper handling and/or installation could run the risk of fire or electrical shock.2．Transportation securityHeavy stress, violent vibration or exposure to water is not allowed during transportation, storage and installation.3．InstallationDo not apply power to the camera before completing installation.Please install the proper power cut-off device during the installation connection.Always follow the instructions in this guide.4．Qualified personnelThis camera should be installed by qualified personnel only.All the examination and repair work should be done by qualified personnel.Any unauthorized changes or modifications could void the warranty.5．EnvironmentThis product should be installed in a cool, dry place away from direct sunlight and heat sources.Do not install the product in extreme temperature conditions.Do not expose the camera to electromagnetic radiation. Otherwise it may result in CMOS sensor failure.Do not block any ventilation openings.Do not allow water and liquid intrusion into the camera.6. MaintenancePlease shut down the device and then unplug the power cable before you begin any maintenance work.Do not touch the CMOS sensor optic component. You can use a blower to clean the dust on the lens surface. Always use the dry soft cloth to clean the device. If there is too much dust, use a cloth dampened with a small quantity of neutral detergent. Finally use the dry cloth to clean the device.Please use a professional optical cleaning method to clean the enclosure. Improper enclosure cleaning (such as using cloth) may result in poor IR functionality and/or IR reflection.7. AccessoriesBefore installation, please open the package and check that all the components are included. Contact your distributor immediately if something is broken/missing in your package.Accessory Name AmountNetwork Camera Unit 1Quick Start Guide 1Installation Accessories Bag 1CD 1Table of Contents1General Introduction (1)1.1Overview (1)1.2Specifications (1)1.2.1Performance (1)2Physical Specifications (2)2.1Cable (2)2.2Dimensions (3)3Device Installation (5)4IP Scanner (7)4.1Overview (7)4.2Operation (7)5Web Operation (8)5.1Login and Main Interface (8)6FAQ (9)Appendix Toxic or Hazardous Materials or Elements (10)1 General Introduction1.1 OverviewThis Speco device is a multi-codec (H.264, MJPEG) IP camera that integrates the traditional camera and network video technology. It enables real time transmission of synchronized video of full HD resolution.Built-in IR LEDs allows for a suitable image in low light environments. IP66 compliant housing allows for outdoor installations. Built-in PoE (power over Ethernet) reduces wiring that’s required during installation.1.2 Specifications1.2.1 PerformanceCamera Image Sensor Progressive scan 1/3-inch CMOS Day/Night Mode IR-cut filter Gain Control Fixed/Auto White Balance Manual/Auto BLCOn/OffElectronic Shutter Manual/Auto/Low noise/Low motion blur Range: 1/3 to 1/100000.Video Compression H.264/H.264B/H.264H/MJPEGSupported Resolutions Main stream: 1920x1080 / 1280x720 @30fps Sub stream: 704x576 / 704x480 @ 30fps Video Bit Rate VBR/CBR supportedH.264H: 16Kbps-8192Kbps MJPEG: adjustable Video Flip Mirror and flipPrivacy MaskSupports max 4 privacy mask zonesVideo Information Channel title, time title, motion detection, tampering. Lens 3.6mm fixed NetworkEthernet 10/100 Base-TNetwork Protocol HTTP ，TCP ，ARP ，RTSP ，RTP ，UDP ，RTCP ，SMTP ，FTP ，DHCP ，DNS ，DDNS ，PPPOE ，IPv4/v6，QoS ，UPnP ，NTP ，HTTPS ，Bonjour User Access Max 20 usersSecurityUser ID & password protection, IP address filtering, HTTPS, user access log Operation & UnitIR Range 65’ (depending on scene reflection) Power PoE (802.3af), 12VDC PowerConsumption 6W max Operating Temperature-22F ~ 140F Operating Humidity ≤95%Dimensions 2.6” (diam) x 6.1” (L) Unit Weight1.4 lbs.2Physical Specifications2.1CableRefer to the following figure for cable information.Figure 2-1 CablePlease refer to the following sheet for detailed information.No. Port Name Function Connection Note1 LAN Network port Ethernet port Connect to standard Ethernet cable for power and data2 DC 12V Power input port DC jack Power port. Input DC 12V.2.2DimensionsPlease refer to the following figure for dimension information. The unit is in mm. See Figure 2-3 to Figure 2-6.Figure 2-3Figure 2-4Figure 2-5Figure 2-63Device InstallationImportantPlease make sure the installation surface can support a minimum of 3 times the weight of the camera.Figure 3-1 Device installation 1Please see Figure 3-1 and Figure 3-2.Step 1Put installation template on the designated surface where you will install the device (wall or ceiling).Step 2Drill holes according to position of the holes on the installation template.Step 3Open accessories bag, take out the expansion bolts and insert them into the drilled holes.Step 4Take out the screws. Tighten the 4 screws to fix the device on the installation surface (wall or ceiling). The sunshield can be adjusted. Tighten the screws on the sun shield when finished.Step 5Connect all applicable wiring properly.Figure 3-2 Device installation 2 Step 6Use Philip’s head screw (in accessories bag) to loosen adjusting screw. Step 7Adjust the device to point to the desired angle.Step 8Use Philip’s head screw to tighten the screws.4 IP Scanner4.1 OverviewIP Scanner can search for the device on Please note that only devices that are o 4.2 OperationOpen up IP Scanner. Figure 4-1In the device list, you can view the IP ad applicable device and double click to opce on the local network. are on the same subnet can be discovered.IP address, model number, and MAC address of each devic to open up the web viewer.Figure 4-1 IP Scannerdevice. Select the5 Web OperationThis device supports viewing and manag 5.1 Login and Main Interface Open the browser and input network ca See Figure 5- 1.The login interface is shown as below. S Please input your user name and pass Default user name is admin and passwo Note: For security purposes, pleaseAfter logging in, follow directions to inst management via a web browser on a PC.faceork camera address in the address bar or double click the d Figure 5- 1 IP addresslow. See Figure 5- 2. d password. assword is 1234. ase change the password after initial login.Figure 5- 2 Web loginto install applicable plugins.the device in IP Scanner.6FAQBugWater leakage has occurred. Removal of the front or rear cap may result in water leakage. The glass front cap has sustained heavy push or strike.The waterproof plug of the rear cap has loosened.IR video is poor. If there is not enough power, the IR LEDs may not function properly.The object is out of the IR distance range of current device.Cannot log in to the web viewer. The Active X control is blocked.The graphics card version needs to be dx8.1 or higher. Network connection error has occurred.Invalid network setup.Invalid user name or password.Settings updates After modifying important camera settings, please reboot the device to make sure the new settings are applied.Appendix Toxic or Hazardous Materials or ElementsComponent NameToxic or Hazardous Materials or ElementsPb Hg Cd Cr VI PBB PBDECircuit BoardComponent○ ○ ○ ○ ○ ○ Device Case ○ ○ ○ ○ ○ ○ Wire and Cable ○ ○ ○ ○ ○ ○PackingComponents○ ○ ○ ○ ○ ○ Accessories ○ ○ ○ ○ ○ ○ O: Indicates that the concentration of the hazardous substance in all homogeneous materials in the parts is below the relevant threshold of the SJ/T11363-2006 standard.X: Indicates that the concentration of the hazardous substance of at least one of all homogeneous materials in the parts is above the relevant threshold of the SJ/T11363-2006 standard. During the environmental-friendly use period (EFUP) period, the toxic or hazardous substance or elements contained in products will not leak or mutate so that the use of these (substances or elements) will not result in any severe environmental pollution, any bodily injury or damage to any assets. The consumer is not authorized to process such kind of substances or elements, please return to the corresponding local authorities to process according to your local government statutes.NoteThis user’s manual is for reference only. Slight difference may be found in user interface.All the designs and software here are subject to change without prior written notice.All trademarks and registered trademarks mentioned are the properties of their respective owners.Please visit our website at or contact customer service for more information.。

Network Box Camera Quick Operation GuideUD.6L0201B1320A01Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer.About This DocumentThis manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice. The updates will be added to the new version of this manual. We will readily improve or update the products or procedures described in the manual.DISCLAIMER STATEMENT“Underwriters Laboratories Inc. (“UL”) has not tested the performance or reliability of the security or signaling aspects of this product. UL has only tested for fire, shock or casualty hazards as outlined in UL’s Standard(s) for Safe ty, UL60950-1. UL Certification does not cover the performance or reliability of the security or signaling aspects of this product. UL MAKES NO REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS PRODUCT.0501001031227Regulatory InformationFCC InformationFCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.FCC ConditionsThis device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:1. This device may not cause harmful interference.2. This device must accept any interference received, including interference that may cause undesired operation.EU Conformity StatementThis product and - if applicable - the suppliedaccessories too are marked with "CE" and complytherefore with the applicable harmonized European standards listed under the Low Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC, the RoHS Directive 2011/65/EU.2012/19/EU (WEEE directive): Products markedwith this symbol cannot be disposed of as unsortedmunicipal waste in the European Union. For properrecycling, return this product to your local supplierupon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: .2006/66/EC (battery directive): This productcontains a battery that cannot be disposed of asunsorted municipal waste in the European Union.See the product documentation for specific batteryinformation. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: Safety InstructionThese instructions are intended to ensure that user can use the product correctly to avoid danger or property loss.The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.Cautions: Injury or equipment damage may occur if any of the cautions are neglected. Warnings● In the use of the product, you must be in strict compliance withthe electrical safety regulations of the nation and region. Please refer to technical specifications for detailed information.● Input voltage should meet both the SELV (Safety Extra LowVoltage) and the Limited Power Source with 24 VAC or 12 VDC according to the IEC60950-1 standard. Please refer to technical specifications for detailed information.●Do not connect several devices to one power adapter asadapter overload may cause over-heating or a fire hazard.●Please make sure that the plug is firmly connected to the powersocket. When the product is mounted on wall or ceiling, thedevice shall be firmly fixed.●If smoke, odor or noise rise from the device, turn off the powerat once and unplug the power cable, and then please contact the service center.Cautions●Make sure the power supply voltage is correct before using thecamera.●Do not drop the camera or subject it to physical shock.●Do not touch sensor modules with fingers. If cleaning isnecessary, use clean cloth with a bit of ethanol and wipe itgently. If the camera will not be used for an extended period, please replace the lens cap to protect the sensor from dirt.●Do not aim the camera at the sun or extra bright places.Blooming or smearing may occur otherwise (which is not amalfunction), and affect the endurance of sensor at the same time.●The sensor may be burned out by a laser beam, so when anylaser equipment is in using, make sure that the surface ofsensor will not be exposed to the laser beam.●Do not place the camera in extremely hot, cold (the operatingtemperature shall be-30℃~+60℃,or -40°C ~ 60°C if the camera model has an “H” in its suffix), dusty or damp locations, and do not expose it to high electromagnetic radiation.●To avoid heat accumulation, good ventilation is required foroperating environment.●Keep the camera away from liquid while in use.●While in delivery, the camera shall be packed in its originalpacking, or packing of the same texture.●Regular part replacement: a few parts (e.g. electrolyticcapacitor) of the equipment shall be replaced regularlyaccording to their average enduring time. The average timevaries because of differences between operating environment and using history, so regular checking is recommended for all the users. Please contact with your dealer for more details.●Improper use or replacement of the battery may result inhazard of explosion. Replace with the same or equivalent type only. Dispose of used batteries according to the instructionsprovided by the battery manufacturer.●If the product does not work properly, please contact yourdealer or the nearest service center. Never attempt todisassemble the camera yourself. (We shall not assume anyresponsibility for problems caused by unauthorized repair or maintenance.)Table of Contents1 Appearance Description (8)2 Installation (12)2.1 Ceiling Mounting (13)2.2 Wall Mounting (16)2.3 Installing the SD Card (19)3 Setting the Network Camera over the LAN (20)4 Accessing via Web Browser (25)Appearance Description 1The overview of the box camera is shown below:Overview (1)Figure 1-1The overview of the components and the interface are shown below:Overview (2) Figure 1-243512The interfaces on the rear panel are shown below:Overview (3)Figure 1-3 DescriptionTable 1-1869107181611171413151217 ABF 18 Audio In●Only the models with “A” in its suffix support ABF function.●To reset the camera default parameters, you need to press andhold the RESET button and power on the camera. After thepower on of the camera, you must still press and hold the Reset button for about 20 seconds.●The type of auto-iris interface is shown as below figure:Figure 1-4Auto-iris InterfaceTable 1-2PinsPower, Video and GND pins are used when the auto-iris is driven by video; Damp+, Damp-, Drive+ and Drive- pins are used when the auto-iris is driven by DC.2InstallationBefore you start:●Make sure the device in the package is in good condition and all the assembly parts are included.●Make sure all the related equipment is power-off during the installation.●Check the specification of the products for the installation environment.●Make sure the power supply is matched with your required voltage to avoid damage.●If the product does not function properly, please contact your dealer or the nearest service center. Do not disassemble the camera for repair or maintenance by yourself.●Make sure that the wall is strong enough to withstand three times the weight of the camera.For the camera that supports IR, you are required to pay attention to the following precautions to prevent IR reflection:●Dust or grease on the dome cover will cause IR reflection.Please do not remove the dome cover film until the installation is finished. If there is dust or grease on the dome cover, cleanthe dome cover with clean soft cloth and isopropyl alcohol.●Make sure that there is no reflective surface too close to thecamera lens. The IR light from the camera may reflect back into the lens causing reflection.●The foam ring around the lens must be seated flush against theinner surface of the bubble to isolate the lens from the IR LEDS.Fasten the dome cover to camera body so that the foam ringand the dome cover are attached seamlessly.Ceiling Mounting2.1Steps:1.Install the ceiling mount to the ceiling with the supplied expansion screws.Adjustable NutInstall the MountFigure 2-12.Fit the lens (not supplied) to the camera and rotate it to get it tightened.∙Install the adapter ring to the lens interface if a C-mount lens is used.∙A manual-iris lens can be directly installed to the camera without plugging the power cable of the auto-iris to the auto-iris interface.3.Plug the auto-iris cable to the auto-iris interface.Figure 2-2Install the Lens4.Align the screw hole on the camera with the ceiling mount and rotate the camera to get it fixed.5.Adjust the surveillance angle.1).Loosen the pan nut to adjust the pan angle [0°-360°].2).Loosen the knob on the ceiling mount to adjust the tilt angle[0°-90].6.Adjust the Lens1).Connect the VIDEO OUT interface of the camera to thedebugging monitor.2).Adjust the Zoom Lever and Focus Level to obtain a perfectimage on the monitor.Knob2.2Wall MountingSteps:1.Install the lens (not supplied) to the camera and rotate it to get it tightened.2.Plug the auto-iris cable to the auto-iris interface.Figure 2-4Install the Lens3.Loosen the lock screw on the mount and remove the tilt adjust table from the wall mount.Remove the Tilt Adjust TableFigure 2-54. Fit the removed tilt adjust table to the camera, and fix it with two screws.Install the Tilt Adjust TableFigure 2-65. Secure the wall mount to the wall with the supplied expansion screws.Tilt Adjust TableLock ScrewFigure 2-7Install the Wall Mount6.Install the camera to the wall mount and tighten the two lock screws.7.Adjust the surveillance angle.1).Loosen the pan nut to adjust the pan angle [0 °-360°].2).Loosen the knob on the ceiling mount to adjust the tilt angle[0°-±45°].8.Adjust the Lens1).Connect the VIDEO OUT interface of the camera to thedebugging monitor.2).Adjust the focus level to obtain a perfect image on themonitor.Adjust the Surveillance AngleFigure 2-8 Installing the SD Card2.3∙ Insert the SD card to the SD card slot to get it installed.∙Push the inserted SD card slightly to get it sprung by its built-in springing to remove it.Install the SD CardFigure 2-9Tilt Adjust ScrewPan Adjust Screw3Setting the Network Camera over the LANPurpose:To view and configure the camera via LAN (Local Area Network), you need to connect the network camera in the same subnet with your PC. Then, install the SADP or PCNVR software to search and change the IP of network camera.●The following figure shows the cable connection of networkcamera and PC:Figure 3-1Wiring over LAN●Set the IP address of the camera for accessing via LAN. Steps:1.To get the IP address, you can choose either of the followingmethods:☐Use SADP, a software tool which can automatically detect network camera in the LAN and list the device information like IP address, subnet mask, port number, device serial number, device version, etc., shown in Figure 3-2.☐Use PCNVR software and to list the online devices. Please refer to the user manual of PCNVR client software for detailedinformation.2.Change the IP address and subnet mask to the same subnet as ofyour PC.Refer to the following introductions to set IP address with SADP software:☐Search active devices onlineSearch online devices automatically:After launch the SADP software, it automatically searches theonline devices every 15 seconds from the subnet where yourcomputer locates. It displays the total number andinformation of the searched devices in the Online Devicesinterface. Device information including the device type, IPaddress, port number, gateway, etc. will be displayed.Figure 3-2Search Online DevicesDevice can be searched and displayed in the list in 15 seconds after it goes online; it will be removed from the list in 45 seconds after it goes offline.Search online devices manually:You can also click to refresh the online device list manually. The newly searched devices will be added to the list.You can click or on each column heading to orderthe information; you can click to show the device tableand hide the network parameter panel on the right side, orclick to show the network parameter panel.Modify device informationSteps:1).Select the device to be modified in the device list as shownin Figure 3-3. The network parameters of the device will bedisplayed in the Modify Network Parameters panel on theright side as shown in Figure 3-4.2).Edit the modifiable network parameters, e.g. IP address andport number.3).Enter the password of the admin account of the device inthe Password field and click Save to save the changes.Figure 3-3Select a DeviceFigure 3-4Modify Network Parameters3.Enter the IP address of network camera in the address field ofthe web browser to view the live video.●The default value of the IP address is “192.0.0.64”. The defaultuser name is “admin”, and password is “12345”.●For accessing the network camera from different subnets, pleaseset the gateway for the network camera after you log in.4Accessing via Web BrowserSystem Requirement:Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bitsCPU: Intel Pentium IV 3.0 GHz or higherRAM: 1G or higherDisplay: 1024×768 resolution or higherWeb Browser: Internet Explorer 6.0 and above version, Apple Safari 5.02 and above version, Mozilla Firefox 3.5 and above version and Google Chrome8 and above versionSteps:1.Open the web browser.2.In the browser address bar, input the IP address of the networkcamera, e.g., 192.0.0.64 and press the Enter key to enter the login interface.3.Input the user name and password.4.Click Login.Figure 4-1Login Interface5.Install the plug-in before viewing the live video and managingthe camera. Please follow the installation prompts to install the plug-in.You may have to close the web browser to finish the installation of the plug-in.Figure 4-2Download Plug-inFigure 4-3Install Plug-in (1)Figure 4-4Install Plug-in (2)6.Reopen the web browser after the installation of the plug-in andrepeat steps 2-4 to login.For detailed instructions of further configuration, please refer to the user manual of network camera.。
