成都航空职业技术学院
《建筑供电与照明工程》
课程设计说明书
设计题目：成都航空职业技术学院建实训楼供电与照明实训设计系别：建筑系专业：楼宇智能化工程技术
班级：313352 指导老师：罗娅红老师
学生姓名：伏仕雷、范禹、刘江涛、刘涛、项羽霏
完成时间：2015年6月11日
摘要
随着社会进步和技术发展，建筑电气技术也有了很大的发展，而且在现代建筑发展过程中发挥着重要作用。
本设计是成都航空职业技术学院实训楼照明电气设计。主要阐述了该实训楼照明电气设计的设计依据、原则和方法及设计选择的结论。设计内容包括：配电系统设计、照明平面设计和系统设计。
本设计的照明系统设计是依据建筑的结构和功能的特点，及有关电气照明设计规范的基础上，利用系数法对光源和灯具进行选择和布置。对于照明配电系统，采用需用系数法进行负荷计算，并根据各回路的计算电流，按导线长期工作允许温升和电压损失选择导线截面，按线路最大工作电流和线路保护选择低压断路器。照明回路和插座回路分别由不同回路供电。最后，利用CAD、T20天正电气软件为设计平台绘制该建筑的照明平面图、照明系统图以及配电系统图。
本设计的目的是通过设计实践，综合运用所学知识，理论联系实际，锻炼独立分析和解决建筑电气设计问题的能力，为未来的工作奠定坚实的基础。
设计符合国家相关技术规程规范要求，设备选型合理，满足使用功能要求，能较好地指导施工。
关键词：建筑电气；电气设计；负荷计算；供配电系统
Abstract
Along with the social progress and technology development, building electrical technology also ha
d th
e very big development, and plays an important role in the development o
f modern architectur
e.
This design is the chengdu institute of technology of profession of aviation training floor lighting
electrical design. Mainly expounds the practice floor lighting design of the electrical design basis, principles and methods, and the conclusion of design choices. Design content including: graphic d esign, lighting power distribution system design and system design.
Lighting system design of this design is based on the characteristics of the structure and function o f building, and on the basis of the relevant electrical lighting design specification, using the metho d of coefficient of the light source and lamps and lanterns choice and layout. For lighting distributi on system, the demand factor method is adopted for the load calculation, and according to the calc ulation of the electric current of each circuit, temperature and voltage loss according to the conduc tor is longterm work allowed to choose wire section, press line maximum working current and line protection of lowvoltage circuit breaker. Lighting circuit and electrical outlet loop, respectively b y different circuits of power supply. Finally, by using CAD, T20 was electrical and software as the building lighting design platform of floor plan, lighting system and distribution system diagram. The purpose of this design is through the design practice, the integrated use of knowledge, theory with practice, to exercise the independent analysis and the ability to solve the problem of building electrical design, lay a solid foundation for future work.
Design conform to the requirements of the relevant national technical regulation standard, equipm ent type selection is reasonable, meet the requirement of use function, and can better guide the con struction.
Keywords: building electric; Electrical design; Load calculation; Power supply and distribution sy stem
目录
摘要
Abstract
目录
1 绪论
1.1 工程背景
1.2 设计范围
1.3 设计依据
1.4 设计目标
1.5 本文的主要工作
2 照明工程设计
2.1 照明设计
2.1.1 确定照明方式及照明种类
2.1.2 选择光源和照明器类型
2.1.3 照度计算及确定安装功率
2.2 开关及插座的选择
2.2.1 开关选择
2.2.2 插座的选择
2.3 计算照度计算书及照明工程数据表
