Hyundai STARIA.Specifications.Engine Smartstream G3.5R series 2.2 VGTEngine family G6DU 3.5 MPI D4HB 2.2 CRDiConfiguration Transverse front mounted driving front wheels Transverse front mounted driving front and rearwheelsCylinder capacity 3.5 litres (3,470 cc) 2.2 litres (2199 cc)Number of cylinders 6 v-configuration 4 in-lineValve system24 Valve (HLA)16 Valve (HLA)Intake system Naturally aspirated Turbo-charged (E-VGT) Maximum power 200kW @ 6400 RPM130 kW @ 3,800 RPMMaximum torque331Nm @ 5000 RPM430 Nm @ 1,500 - 2500 RPMFuel system Multi Point Injection (MPi)Common Rail Direct injection (CRDi)Fuel type91 RON (ULP), E10 compatible DieselEmissions standard Euro 5Euro 5Bore x stroke92mm x 87mm85.4 mm x 96.0 mm Compression ratio10.6:116:1Weight 3.5 MPi 2WD 2.2 CRDi AWDAutomatic AutomaticKerb weight - lightest2,142 kg2,255 kgKerb weight - heaviest2,212 kg2,325 kgGross Vehicle Mass - GVM2,920 kg3,040 kgPermissible Axle Weight - PAW - front1,610 kg1,610 kgPermissible Axle Weight - PAW - rear 1,780 kg1,780 kgTowing capacity 3.5 MPi 2WD 2.2 CRDi AWDAutomatic AutomaticBraked2,500 kgUnbraked750 kgMaximum towball weight100kgFuel consumption* 3.5 MPi 2WD 2.2 CRDi AWDAutomatic AutomaticCombined (L/100km)10.58.2Urban (L/100km)14.510.4Extra Urban (L/100km)8.27.0CO- combined (g/km)2392182Fuel tank volume75 L*Source: Australian Design Rule 81/02 static laboratory combined average city and highway cycle test. Real world fuel consumption will vary depending on a combination of driving habits, the condition of the vehicle, and other factors such as road, traffic and weather conditions. ADR 81/02 test results are meant for comparison purposes only.Dimensions 3.5 MPi 2WD 2.2 CRDi AWDExteriorLength5,253 mmWidth1,997 mmHeight 1,990 mmWheelbase3,273 mmWheel track - front / rear1,721 mm / 1,732 mmMinimum ground clearance (based on kerb weight) 186 mmApproach / departure / ramp break over angle17.6° / 19.3° / 14.9°InteriorHead room front / centre / rear 1,064 / 1,087 / 1,081 mmLeg room front / centre/ rear1,027 / 1,062 / 1,010 mmShoulder room front / centre / rear1,831 / 1,781 / 1,645 mmHip room front / centre / rear1,527 / 1,676 / 1,438 mmCargo area - VDA (minimum : from 3rd / from 2nd row )831 / 1,303 litresWheels & tyres Staria Elite Highlander Wheel type Alloy Alloy AlloyWheel dimensions18 x 7.0J 18 x 7.0J 18 x 7.0JTyre dimensions235/55 R18 104H235/55 R18 104H235/55 R18 104H Spare wheel type Full size alloy Full size alloy Full size alloy Driving convenience Staria Elite Highlander Electronic Parking Brake (EPB) (with auto hold function)●●●Shift By Wire (SBW) - electronic gear shift buttons●●●One touch turn signal - 3, 5, or 7 flashes●●●Rear wiper - with auto wipe on reverse ●●●Smart Key with push button start-●●Remote start - via Smart Key-●●Steering wheel mounted controls - audio, phone, cruise control &trip computer●●●Tilt & telescopic steering column●●●Driving engagement Staria Elite Highlander4WD lock (Diesel only)●●●Driver profiles - Driver 1, Driver 2 & Guest-●●Drive mode - 4 settings (Comfort, Eco, Sport, Smart)●●●Paddle shifters●●●Active safety Staria Elite Highlander Electronic Stability Control (ESC) including:Anti-lock Braking System (ABS)●●●Brake Assist System (BAS)●●●Electronic Brakeforce Distribution (EBD)●●●Hill-start Assist Control (HAC)●●●Multi-Collision Braking (MCB)●●●Traction Control System (TCS)●●●Vehicle Stability Management (VSM) ●●●Hyundai SmartSense™ including:Blind-Spot Collision-Avoidance Assist - Rear (BCA-R)●●●Blind-Spot View Monitor (BVM)--●Driver Attention Warning (DAW)●●●Forward Collision-Avoidance Assist (FCA) - camera and radar type,including:●●●●●●●●●- Car/Pedestrian/Cyclist detection- City/Urban/Interurban operational speeds- Junction Turning (FCA-JT) functionalityHaptic warning function●●●High Beam Assist (HBA)●●●Lane Following Assist (LFA)●●●Lane Keeping Assist - Line/Road-Edge (LKA-L/R)●●●Leading Vehicle Departure Alert (LVDA)●●●Rear Cross-Traffic Collision-Avoidance Assist (RCCA)●●●Rear Occupant Alert (ROA)●●●Safe Exit Assist (SEA) -●●Safe Exit Warning (SEW)●--Smart Cruise Control (SCC) with Stop & Go●●●Surround View Monitor (SVM)●●●Other featuresParking Distance Warning-Front (PDW-F) - 4 sensors, with guidancedisplay●●●Parking Distance Warning-Reverse (PDW-R) - 4 sensors, with guidancedisplay●●●Surround View Monitor (SVM) - 3D view-●●Front view camera ●●●Rear view camera with dynamic guide lines●●●Intelligent Speed Limit Assist (ISLA) ●●●Emergency Stop Signal (ESS)●●●Tyre Pressure Monitoring System (TPMS) - individual tyre pressurereadout●●●Passive safety Staria Elite Highlander Airbags 7xFront airbags - driver & front passenger●●●Side (thorax) airbags - driver & front passenger●●●Front centre airbag●●●Side curtain airbags - B & C pillars ●●●DoorsImpact sensing auto door unlock●●●Roll-over Sensor●●●Rear door child safety locks●●●SeatbeltsPretensioners, load limiters & height adjustable upper mounts on frontseat belts●●●Pretensioners & load limiters on rear seat belts ●●●Seat belt reminder - front seats●●●Seat belt monitor - rear seats●●●Seat belt holder - 3rd row●●●SeatingHeight adjustable front head restraints ●●●Height adjustable rear head restraints 2nd & 3rd row●●●ISOFIX child restraint anchors - outboard seats - 2nd row●●●Top tether child restraint anchors - 3 anchors - 2nd row●●●Security Staria Elite Highlander Security systemActive lock/unlock operation (user configurable)●●●Anti-theft alarm●●●Central locking●●●Engine immobiliser●●●RemotesKeyless entry remote - 2x●--Smart Key remote - 2x-●●Multimedia system Staria Elite Highlander FunctionsTouch screen - 8” display●--Touch screen - 10.25” display-●●Wireless Apple CarPlay1 & Android Auto2 compatibility●--Apple CarPlay1 & Android Auto2 compatibility●●●Bluetooth phone connectivity●●●Satellite navigation -●●Live traffic updates (RDS-TMC)-●●SpeakersAudio system - 6 speakers (4 speakers, 2 tweeters)●●●Audio/media sourcesAM / FM radio●●●Digital radio (DAB+)-●●Radio Data System (RDS)●●●USB multimedia input●●●Bluetooth audio streaming●●●Bluetooth® Multi-Connection; 1 x phone + 1 x audio (total up to 2devices) ●●●Quiet Mode - Speaker volume limitation for a quieter cabin●●●Occupant comfort & convenience Staria Elite Highlander Upholstery/trimLeather3 appointed seats-●●Leather3 wrapped steering wheel●●●Front seatsDriver’s seat - manual height adjustable●--Driver’s seat - power adjustable - 12-way (including 4-way lumbarsupport)-●●Front centre console - power outlets - 1 x 12V outlet ●●●Front centre console - power outlets - 1 x USB charger outlet●●●Front centre console - 1 x multimedia USB outlet●●●Front centre console - wireless charging pad (Qi standard)4 ●●●Grip handles - 2x (passenger)●●●Rear seats (2nd row)Rear power outlets - 2 x USB charger outlet ●●●Roof mounted air vents 2x ●●●Grip handles - 2x●●●Walk in device - control for slide function to access 3rd row ●●●Rear seats (3rd row)Rear power outlets - 2 x USB charger outlet ●●●Roof mounted air vents - 2x ●●●Floor mounted air vents - 2x ●●●Grip handles - 2x●●●3rd row seat tip up & slide function ●●●Windows/shadesWide glass sunroof - dual panel with tilt and slide front panel and power sunblind (rear)--●Power Windows - one touch up & down function with anti-pinching safety feature●●●Pop-out latch type windows - 2nd row ●--Flush sliding rear window - 2nd row -●●Pop-out latch type windows - 3rd row ●●●Rear window sunshades - 2nd & 3rd row -●●Solar control windshield and front glass●●●Sunvisor (illuminated & extendable) - driver and front passenger ●●●Remote front windows open / close - via keyless entry remote or Smart Key●●●Doors/boot/tailgateRoof mounted controls - power doors & tailgate-●●Power Sliding Doors - smart opening - with anti-pinch safety -●●Smart Tailgate - including:-●●- Anti-pinching safety feature - Smart hands-free opening & closing - Walkaway closing functionRemote power open / close doors & tailgate - via Smart Key -●●Vision & sight StariaEliteHighlanderInterior mirrorElectro-chromatic Mirror (ECM) - auto-dimming -●●Rear passenger view monitor --●Exterior mirrors Heated●●●Power adjustable●●●Power folding with auto fold function ●●●Instrument cluster/driving displaysInstrument cluster - 4.2” TFT LCD with trip computer & digital speedometer●●-Supervision cluster - 10.25” TFT colour LCD with trip computer & digital speedometer--●Ventilation & heating StariaEliteHighlanderAir conditioning Manual controls●--Climate control - front and rear zones with auto defog-●●Climate control tunnel mode - automatic air recirculation (map based)-●●Rear seat climate controls with lockout function●●●Cabin air filter ●●●Cooling/heating roof air vent - 2nd row & 3rd rows●●●Front seatsAir ventilated front seats--●Heated front seats--●Other featuresHeated rear windshield●●●Heated steering wheel--●Auto comfort control - automatic heated / ventilated seat & heatedsteering wheel--●Exterior styling Staria Elite Highlander FrontFront grille - painted ●●●SideDoor frame & beltline moulding - gloss black●●●Exterior door handles - body colour●●●RearSpoiler - gloss black trim, tailgate mounted ●●●Upper taillight garnish ●●●Interior styling Staria Elite Highlander TreatmentsAlloy effect finish (interior door handles)●●●Alloy effect steering wheel insert●●●Alloy effect Shift By Wire (SBW) controls●●●Gloss black garnish - steering wheel controls ●●●Gloss black interior garnish - dashboard, centre controls & airvents ●●●MaterialsCloth headlining --●Interior premium materials - dashboard & door panel--●Lighting Staria Elite Highlander Exterior lighting - frontDaytime Running Light bar (DRL) - LED●●●Headlight functions - automatic dusk sensing with escort and welcome●●●Headlight type - LED (low/high beam)●●●Headlight type - MFR●●●Positioning lights - LED●●●Exterior lighting - rearFog lights - LED●●●High Mount Stop Light (HMSL) - LED●●●Rear combination lights - LED (LED : reverse lights)●●●Exterior lighting - othersSide repeaters -integrated into side mirrors (LED)●●●Interior lighting - frontFront room lights and map lights - LED--●Vanity mirror lights ●●●Interior lighting - rearCentre room light (LED)--●Sliding door courtesy lamps●●●Interior lighting - othersCargo area light - (LED)--●Interior light fade-out delay●●●Safety lights - integrated in doors (front)●●●Storage solutions Staria Elite Highlander Front seatsCup holders - dashboard - 1x●●●Cup holders - centre storage box - 2x●●●Cup holders - front console - 1x●●●Front door bottle bulges and map pockets●●●Front seat back pockets with pocket for personal electronics●●●Bag hooks - front seatbacks●●●Dashboard storage tray ●●-Dashboard multi-box - 2x--●Glovebox compartment●●●Ticket holders - sunvisors (driver and front passenger)●●●2nd rowSliding door map pockets and bottle bulges●●●Storage drawer - rear of centre console●●●2nd row cup holders - rear of centre console - 2x●●●3rd rowCup / bottle holders - 4x●●●Coat hooks - 2x ●●●Seat folding2nd row - 60:40 flat folding●●●3rd row - single flat folding ●●●Boot/luggage areaLuggage compartment - 4x mounting points●●●Luggage net ●●●Notes:1. Apple CarPlay™ requires iPhone 5 or subsequent model (lightning cable) in order to operate.2. Android™ Auto requires a device with Android 5.0 operating system or subsequent version in order to operate.3. Finishes specified as leather may contain elements of genuine leather, polyurethane leather (leather substitute) or man-made materials, or a combination thereof.4. Wireless charging requires a Qi-enabled smartphone or adapter in order to operate.Key:● = Feature is available on trim- = Feature is not available on trim。
品牌事件2010年11月下线2010年11月29日，由江淮汽车打造的欧系多功能商用车星锐，在合肥正式下线，宣告全面进入量产阶段。
江淮星锐起步高端，对标欧洲先进产品、面向国内国际两个市场同时开发。
江淮星锐引领中国商用车实现欧系多功能商用车零的冲破，抢占了世界商用车制高点。
2010年11月乌克兰700台定单江淮星锐还未正式上市已取得国际客户的垂青。
取得乌克兰政府700台采购大单的江淮星锐，现在已拿到了欧洲市场的第一张通行证。
这也是行业内欧洲整车最大定单。
2010年12月广州车展上市2010广州车展上，中国欧系多功能商用车领衔之作——江淮星锐在众镁光灯下惊艳亮相，锋芒上市。
江淮星锐共展示了14座客车、7座奢华商务车及救护车三种车型。
可以看出，江淮星锐是源自欧洲设计理念，在系列化、通用化和模块化的基础上，由客车、厢式货车和专用改装车组成的多功能商用车平台。
2011年4月玉树爱施诊疗车交付江淮星锐上市当日，便迎来首位车主。
来自公益组织——青海省藏区爱施贫困救助中心菲利普先生，订购2台星锐宣传诊疗车，将当即投入在青海玉树地域开展的医疗援助工作。
上市现场，江淮为他准备了隆重的交付仪式。
江淮总裁安进不仅亲自送上了新车钥匙，还代表江淮汽车为救助中心捐赠了10万元善款。
虽然玉树气候和道路条件苛刻，但江淮星锐不仅向他提供了2年8万千米的整车质量担保，和2年25万千米的发动机质量担保，更许诺其“星锐快车”服务小分队将不吝代价为这两辆公益用车做好服务。
2011年4月20日，两台为爱施公益组织量身定制的星锐青藏爱施移动诊疗车正式交付。
同时，江淮汽车还捐赠了企业为玉树召募的善款和物资，并许诺对一名玉树儿童进行就学帮忙。
2011年5月星锐亮相上海车展江淮星锐参加2011年上海国际车展的主题是“美好城市，智能运输”，意在展示欧系多功能商用车作为城市最佳运输解决方案，顺应智能城市发展趋势，向高科技、信息化运输平台延伸拓展的壮大潜力。
江淮1027系列汽车维修手册扬州江淮轻型汽车有限公司前言江淮瑞铃采用鸟巢式车身构造，与瑞风、瑞鹰同一研发平台，同一底盘配置。
既有卡车刚性耐用的特质，又有轿车的舒适安全性。
具有优良的动力性、经济性及舒适性，处于国内先进水平，是真正符合中国国情的汽车。
江淮瑞铃系列车型包括单排、双排、加长等多种系列产品，采用了电喷汽油、电控VE泵柴油、高压共轨柴油等多种发动机型式，提供用户更多选择，代表了国际国内最流行款式。
高品质的产品，更需要高品质的服务。
本公司本着“先卖信誉、后卖服务、再卖产品”的宗旨，提供全方位的服务。
也给售后服务提出了更高的要求。
本手册较详细的介绍了江淮瑞铃的维护技术以及维修的技术常识，认真阅读本手册并严格按规定执行，可尽快掌握和提高维修人员的专业素质和技术水平。
作为技术手册，同时也适合与每一个从事江淮瑞铃服务工作的人员。
由于编写此手册时间仓促，本手册在编写过程中可能存在某些不妥及遗漏之处，如在使用中有误，望指正，以便在今后的工作中及时改进。
扬州江淮轻型汽车有限公司二○一○年七月目录第二部分车身第一章车身的维护车身的维护主要是为了防止喷涂层早期老化和损坏，以保持车身清洁、美观。
此外，经常保持车身清洁，有利于随时发现车身钣金件的损伤，以便及时加以修理。
一、车身的冲洗：为了保持车身良好的油漆表面和美观，经常清洗车身是必要的。
但不应该在强烈的阳光下进行，也不应该在温度太低的情况下进行。
在任何情况都应等车身表面冷却后才清洗。
可采取喷水式冲洗，用压力水流冲掉车身表面粘着的脏物，然后用一块软而清洁的海绵或毛巾在车身上从上而下地擦洗，如果使用汽车洗涤剂，应用大量清水冲清。
在使用高压清洗机的情况下，不要直接把喷头射向变速箱、转向机构及各种部件的橡胶保护件上，也不要直接喷射到外部装饰件，顶蓬接缝，散热器的发动机罩内。
洗完车后，可用麂皮或优质白纱布抹干车身表面。
切勿用汽油、煤油、三氯乙烯、强碱水和酒精等擦洗车身表面和有机玻璃表面，也不许干擦车身。
03□邮箱：yumn-830@05刘向前热点聚焦■ 本报记者 周 静江淮锐捷特2.7CTI发动机：实力征服轻卡用户刚刚走访了河北市场终端用户，江淮汽车发动机公司销售项目组负责人黄宁赶到第六届“我信赖的商用车动力评选”颁奖典礼现场。
他的任务是代表企业领取江淮锐捷特2.7CTI 发动机获得的轻型组“我信赖的商用车动力”奖。
在对主办方致敬之后，他说：“最应该感谢的是江淮锐捷特发动机的用户，谢谢你们对江淮发动机的信任！”以用户价值为导向，这是江淮在产品、营销、服务方面坚持的前进方向，也是锐捷特2.7CTI 发动机得到用户信任、赢得“我信赖的动力”奖最为核心的优势。
产品赢得信赖“我信赖的商用车动力”专家评审会，是由学科、行业第一线的科研、技术专家，内燃机行业标准和政策的起草人员构成。
他们是这么评价江淮2.7CTI 发动机的：“以客户价值为导向，采用高压电控燃油系统与DOC、SCR 后处理系统，承接了国内外先进柴油机技术优势，可靠性好、油耗低、动力性出色。
坚持正向开发，获得多项国家专利，成功配装在江淮帅铃、骏铃、星锐等系列轻型车，为轻型车用户提供了可靠、用户信赖的动力源。
”黄宁表示，能够参与此次活动，与同行特别是轻型发动机同行共聚在一个平台交流，对于锐捷特发动机的未来成长非常有帮助。
而且，锐捷特2.7CTI 发动机此次获奖，代表着行业专家和用户的认可，让江淮发动机备受鼓舞。
本次获奖的江淮锐捷特2.7CTI 发动机，是江淮汽车自主动力品牌——锐捷特旗下的明星产品。
具有可靠性好、油耗低、动力性出色等诸多优势，获得多项国家专利，是江淮汽车旗下轻卡产品的优秀动力。
虽然排量仅为2.7升，但锐捷特2.7CTI 发动机却有着最大功率115千瓦、最大扭矩355N·m 的强劲输出，升功率、升扭矩都居行业前列；高压共轨（1800bar）、增压中冷、DOC+SCR 后处理、新材料及轻量化等先进技术的成熟应用，使该机型拥有出色的环保性和燃油经济性，最低燃油消耗达到202g/kWh，比市场同类产品低7%，结合江淮汽车黄金传动系，整车油耗较同类产品低10%；通过结构优化设计及精细标定，打造更优秀的NVH 品质；成熟的研发体系、严格的质量制度、苛刻的试验验证，保证了发动机50万公里的B10寿命。
上汽大通MAXUS V90与江淮星锐，胜负显而易见对于轻客的选择，江淮星锐与上汽大通MAXUS V90是两款比较受人追捧的车型。
这两款车子在外形与性能方面的表现都非常不错，可以说是轻客中比较有性价比的两款车了。
那江淮星锐和上汽大通MAXUS V90谁更胜一筹呢？相信通过本文的对比，大家或许就能找到答案。
外观上外观方面， V90的前脸十分有力量感，进气格栅采用了八边形设计，中间设计有四条粗壮的镀铬前格栅两侧连接大灯组，配合大通的“众”字形LOGO，整车的辨识度和时尚感都很不错。
车灯方面，采用了全LED自动感应式设计，车头前唇两侧是对称的L形雾灯。
尺寸有标准轴距和长轴距两种，标准轴距版车身尺寸长宽高分别为5546/2062/2555mm，轴距为3366mm。
而长轴距版车型车身尺寸为5940/2110/2525mm，轴距为3760mm。
同时，还有加长轴高顶、加长轴超高顶的9座版车型。
而江淮星锐的前脸进气格栅采用四边形的设计，五条幅中网搭配两侧异形大灯组的设计，让车子的外观看上去较为中规中矩。
车子的尺寸有三种，4系版本车型的长宽高分别为5050(4900)/2080/2395mm，轴距为2960mm；5系车型长宽高分别为5840(5650)/2098/2405mm(2645高顶)，轴距为3570；6系车型长宽高分别为5990/2098/2645mm，轴距为3570mm。
此外，根据不同车型的配置，新车还将有5-13、15、17座的空间布局可选。
整体而言， V90的外观设计更偏重于商务车的沉稳造型，车身更长，内部空间更为宽大，可以说是乘用级别的轻客车型了。
江淮星锐的设计较为中规中矩，缺少抓人眼球的亮点，内部空间也是不够有吸引力。
配置上在配置方面，V90搭载了最新一代蜘蛛智联系统。
蜘蛛智联系统的功能十分丰富，可为行业客户车队管理定制解决方案，还能实现远程控制，并提供车载微信、智能语音等近百种智能服务，让用户享受到最优质的智能出行体验。
