工业冷水机说明书

.目录中文一、安装要求 (1)二、开机准备 (1)三、操作顺序 (2)四、面板示意图及操作说明 (2)五、修改参数操作说明 (3)六、参数设置表 (5)七、故障代码说明 (6)八、操作注意事项 (6)九、维护与保养 (8)十、故障排除方法 (9)十一、电器连接示意图 (10)十二、风冷式冷冻机内部结构示图 (11)十三、水冷式冷冻机内部结构示意图 (12)十四、风冷式冷水机安装示意图 (13)十五、水冷式冷水机安装示意图 (14)感谢您选用“亨瑞达”冷冻机，为了您能正确高效的使用，请详细阅读说明'..。

书。

注意：温度过低时，防止冷冻介质在设备中结冰损坏冷冻机一、安装要求：1、冷冻机安装前请选择地基平稳，四周空旷，畅通及避免腐蚀、污染、日晒、雨淋，方便安装维修之场所；2、水冷式冷冻机，根据冷冻机制冷量选用匹配的冷却水塔。

冷水机管路配管，请根据机身管路尺寸进行安装，切勿将冷却水管尺寸缩小，这样会引起高压超载，影响制冷效果及增加耗电量；3、风冷式冷冻机，请必须安装在距离墙壁一米以上空间位置，以免造成散热不良引起高压过载影响制冷效果及增加耗电量。

注：（1）电源负载及接地部分，请依照相关法规施工！（2）新安装的冷冻机冷冻水管必须包保温层！二、开机准备首次运转冷冻机必须先检查下列事项是否正确：1、电源电压及相数是否符合型号规格，请对照铭牌所示。

[注：三相电源相位线分别为R、S、T，中性线（零线）N，接地导线为双色线用E表示；机内设有错、缺相保护器，当在第一次开机时出现电源故障报警时，可能出现错相保护，可将相线任意两相对换接妥后合上开关即可；单相电源相线为L，中线为N，地线为E。

]2、检查冷冻水管及冷却循环水管是否接通管路，并保持阀门打开；（请参考安装示意图）3、先将冷冻水箱加满水或其它冷冻介质后方可启动水泵；（注：请根据要求来配用冷冻介质）4、水冷式检查冷却水泵运行方向及水塔风机是否逆转（如水泵是三相，逆转须将电源相位线中任意二相对换，接妥后再把开关合上即可）。

工业冷水机CW-5000/CW-5200 CW-5000/ 5200工业冷水机使用安装说明书目录一．使用注意事项-------------------------------------------------------------- 16二．部件介绍-------------------------------------------------------------------- 17三．安装说明-------------------------------------------------------------------- 18四．运行状况与参数调整----------------------------------------------------- 19五．流量报警与输出端口----------------------------------------------------- 23六．技术参数-------------------------------------------------------------------- 24七．简单故障处理-------------------------------------------------------------- 26感谢您购买广州特域机电有限公司的产品，请在使用前仔细阅读使用安装说明书，并妥善保管。

本使用安装说明书并非质量保证书，对印刷错误的更正, 所述信息谬误的勘误，以及产品的改进，均由广州特域机电有限公司随时做出解释，恕不预先通知，修正内容将编入再版使用安装说明书中。

一、使用注意事项1、请确保电源插座接触良好并且地线可靠接地！虽然冷水机的平均工作电流不大，但是其瞬时工作电流有时高达6~10安培（AC110V电源机型瞬时工作电流有时高达10~15安培)。

2、请确保冷水机的工作电压稳定、正常！由于制冷压缩机对电源电压比较敏感，我公司标准产品的正常工作电压为200~250V（110V机型为100~130V）。

CW-5000/5200 Series Industrial Chiller maintenance manual目录Ⅰ、Chiller Alarm (red light on)--have water circulation ………………………………………P3-7 Ⅱ、Chiller Alarm (red light on)--not water circulation ………………………………………P7-8 Ⅲ、CW-5000 Series Temperature Controller T-503 alarm3.1．Alarm code E1: ultrahigh room temperature ……………………………………………P8-9 3.2．Alarm code E2: ultrahigh water temperature …………………………………………P9-12 3.3．Alarm code E3: ultralow room temperature ……………………………………………P12 3.4．Alarm code E4: room temperature sensor failure ………………………………………P12-13 3.5．Alarm code E5: Water temperature sensor failure ……………………………………P13-14Ⅳ、No power on the chiller …………………………………………………………………P14-15Ⅰ、Chiller Alarm (red light on)--have water circulationTurn off the chiller power, use the water pipe of about 1 meters length to connect the outlet with the inlet short (pictured), turn on the chiller, and continue to observe the condition of the chiller.Observation effect I: water cycle normal, stop alarm (green light on)Cause analysisThe external water pipeline connecting the chiller is blocked (such as pipe blockage, bending, etc.)Suggestion: Clean the external piping, replace the pipeline that has already had the bend or the serious blockageObservation Effect II: Water cycle Normal, continue to alarm (red light on)Cause analysis1、Flow switch problem2、Relay problemsDetection method1）Turn off the chiller power, open the chiller sheet metal, find out the flow switch position (the outlet)Baffle Flow Switch2）Cut off the bezel flow switch two red power wire, and short connection, boot to observe whether continue to alarm2.1）If the alarm stop（green light on），can determine the flow switch failure Recommendation: Replace the baffle flow switch2.2）If the chiller continues to alarm (red light on), please reconnect the flow switch power wire, and do the step 4) detectionHall Flow Switch3）Cut off the hall flow switch four wires, connect the red line with the red line, the black line is connected with the yellow line, boot to see if the alarm continues.3.1）If the alarm stop（green light on），can determine the flow switch failure Recommendation: Replace the hall flow switch3.2）If the chiller continues to alarm (red light on), please reconnect the flow switch power wire, and do the step 4) detection4）Measuring the relay coil Input voltage by measurement toolRemarks: Baffle Flow switch model relay coil AC220V; Hall flow switch model relay coil DC24V4.1）If the relay (such as picture) coil does not enter the normal operating voltage, can be judged flow switch connection relay circuit breakerSuggestion: Check whether the relay line is loose or brokenObservation Effect III: Water intermittent, continue to alarm (red lighton)Cause analysis1、Pipe blockage2、Switching power supply problem3、DC Pump problemDetection method1）Open the chiller sheet metal, observe the water internal piping statusRecommendation: Clean the internal piping, replace the pipe that has been bent or badly blocked.2）Use the measuring tool to detect the switching power supply (picture) Output voltage:CW-5000 Series switching power supply operating voltage is DC24V.2.1）If the switching power supply output is lower than DC18V, the low voltage is affecting the pump lift and flow, can determine the switching power supply or pump failure. Suggestion: Change the switching power supply first to determine whether the pump is faulty too.2.2）If the switching power supply has the output DC24V, may determine the water pumpfailure.Suggestion: disassemble the DC pump casing to observe whether the rotor is plugged or worn, if unable to recover, need to replace DC pumpⅡ、Chiller Alarm (red light on)--not water circulationCause analysis1、Low water level2、Switching power supply problem3、DC Pump problemDetection method1）Observe whether water tank is lower than pumpinletRecommendation: Add Pure water2）Use the measuring tool to detect the switching power supply (picture) Output voltage: CW-5000 Series switching power supply operating voltage is DC24V.2.1）If the switching power supply output is lower than DC18V, the low voltage is affecting the pump lift and flow, can determine the switching power supply or pump failure.Suggestion: Change the switching power supply first to determine whether the pump is faulty too.2.2）If the switching power supply has the output DC24V, may determine the water pump failure.Suggestion: disassemble the DC pump casing to observe whether the rotor is plugged or worn, if unable to recover, need to replace DC pumpⅢ、CW-5000 Series Temperature Controller T-503 alarm Temperature control alarm accompanied by code displayRemarks: In alarming state, the alarm sound could be suspended by pressing any button, but the alarm display remains until the alarm condition is eliminated.3.1、Alarm code E1: ultrahigh room temperaturePress ▼ button will show the room temperature,6 seconds later to display the restore defaults.Cause analysis1、More than 40 ℃ ambient temperature or machine placement is not ventilated Suggestion: The chiller is placed in the ventilated position, there must be at least 30cm from obstructions to the air inlet（The dust gauze）, and should leave at least 50cm between obstruction and the air outlet（The fan）.2、The serious blockage of dust gauzeSuggestion: It is Essential to unpick and wash the dust gauze.3、Serious dust deposition of aluminum fin inside the chillerPeriodically blow away the dust of the condenser3.2、Alarm code E2: ultrahigh water temperatureCause analysis1、External reasons1.1）More than 40 ℃ ambient temperature or machine placement is not ventilated1.2）The serious blockage of dust gauze1.3）Serious dust deposition of aluminum fin inside the chiller1.4）The heat is higher than the refrigerating capacity1.5）The chiller working voltage is lower than required (depending on the model: please refer to the manual technical parameters)2、Fan problem3、Temperature controller problem4、Compressor capacitor problem5、Compressor Protector problem6、Leakage Refrigerant7、Refrigerant solenoid valve problem8、Compressor problemDetection method1）Use the measuring tool to detect the fan input voltage is normal (depending on the model: please refer to the manual technical parameters): if there is voltage input, can determine the fan failure, if there is no voltage input, can determine the line contact bad or fan circuit.2）When the thermostat is in the refrigeration state2.1）Using measuring tools to measure the output terminals of the compressor after the temperature control of the normal operating voltage output: if there is no voltage output, can determine the temperature controller failure, if the voltage output, can be used for next detection;2.2）Using measuring tools to measure the temperature of the back of the solenoid valve output terminals：There is no normal operating voltage output: If the voltage output, can determine the temperature controller failure; If no voltage output, please do next detection3）In the refrigeration state, the compressor cannot start3.1）The use of measuring tools to detect the compressor electric start-up capacity (such as the figure) is below the normal value of 10%, such as less than 10%, can be judged the compressor capacitance capacity is lower than the normal capacity of the capacitor;3.2）Use the measurement tool to detect the compressor input voltage is normal (depending on the model: please refer to the manual technical parameters), such as the voltage below the compressor start-up voltage, the compressor does not run;3.3）Use the measuring tool to detect whether the compressor overload protector output terminal has voltage, such as output voltage output, can determine the compressor overload protector work protection or damage break3.4）Using the measuring tool (ammeter) to measure the compressor input line (white), such as the current is more than 3 times the rated current or above, can determine the internal rotor of the compressor does not rotate;4）In the refrigeration state, the compressor can run4.1）Observe the refrigeration piping (pictured) there is no oil or frosting, such as oil or frost phenomenon, can be j udged refrigerant leakage (such as inside the condenser or evaporator internal pipeline leakage refrigerant need to return to the plant maintenance)4.2）The use of measuring tools to detect the compressor electric start-up capacity (such as the figure) is below the normal value of 10%, such as less than 10%, can be judged the compressor capacitance capacity is lower than the normal capacity of the capacitor;5）Solenoid valve has been guided6）Compressor Rotor not working(The above two points need to return to the factory for further testing)3.3．Alarm code E3: ultralow room temperatureCause analysis1、Low ambient temperature (such as autumn and winter season) when the first boot appears E3 alarm is the normal status, can add a moderate amount of warm water to restore the temperature3.4Alarm code E4: room temperature sensor failureCause analysis1、Wiring Loose2、Sensor failureDetection method1）Find the terminal of the temperature sensor and the temperature transducer, exchange the two terminals.1.1）If the alarm stop can judge the terminal contact bad, reconnect the relative terminal1.2）If there is a E4 alarm, can determine the temperature controller malfunction; If there isa E5 alarm, can determine the room temperature sensor failure1.3）If E4, E5 at the same time alarm, recommended to replace room temperature sensor and temperature sensor and temperature controller3.5．Alarm code E5: Water temperature sensor failureCause analysis1、Wiring Loose2、Detection method3、Detection method1）Find the terminal of the temperature sensor and the temperature transducer, exchange the two terminals.1.1）If the alarm stop can judge the terminal contact bad, reconnect the relative terminal1.2）If there is a E5 alarm, can determine the temperature controller malfunction, such as the emergence of E4 alarm, can determine the temperature sensor failure;1.3）If E4, E5 at the same time alarm, recommended to replace room temperature sensor and temperature sensor and temperature controllerⅣ、 No power on the chillerCause analysis1、Fuse Fusing2、Power switch problemDetection method1）Open the safety tube and check if the fuse is fused (picture). If fuse, replace the standby insurance pipe2）Using universal meter and other measuring tools, detect the power switch on the two groups oflines have AC220V voltage (depending on the model), such as detection of the power switch only a group of lines have AC220V voltage, can be judged as power switch failure, need to replace the power switch。

20℃ 15℃ 35℃ 45℃
二、机器安装程序
冷冻水出口温度 冷冻水出入温差值 冷凝空气出口温度 冷凝空气温差值
工作范围 5℃至 20℃ 2.5℃至 10℃ 42℃至 45℃ 8℃至 10℃
2.1 安装期间请检查机器是否受到损坏，选择合适的地方，以便于安装及日后维修。 2.2 安装机组的场地必须是地板、安装垫或基础、其水平度在 6.4mm 之内，并能承受机组的运行重量。 2.3 机组应放在室温为 4.4-43.3℃的机房内，机组的四周和上方应有足够空间,以便进行日常的维护工作。 2.4 大机组建议放室外空地，方便散热。 2.5 选择合适管径的水管，机组最大功率运行时的冷冻水系统，并正确连接。 2.6 对于普通的应用场合，通过蒸发器水流速度允许在 1.0-3.6m/s 之间。 2.7 在任何负荷情况下，水流量应保持稳定。 2.8 所有冷冻水管道的设计及安装应按常规方法进行，冷冻水泵要位于机组的进水管上，以保证机组内的正压和
a> 过载保护
b> 压缩机高低压力保护
c> 电机过热保护 d> 电源相序保护
3.6 附电气原理图
请不要擅自改变接线, 如有需要，请与我公司取得联系。
