任意波形发生器AWG5000

数据手册DS0805A-CN-02A2022.7.11数据手册SSG5000A系列微波信号发生器SSG5083ASSG5085A产品综述SSG5083A/SSG5085A微波信号发生器，输出频率范围涵盖9 kHz~ 20 GHz，同时支持AM&FM&PM等模拟调制，支持脉冲调制，脉冲序列发生器，功率计控制等功能。

配置了OCXO 参考，具有高稳定度的参考，高输出精度。

具有出色的稳定的信号输出，应用在通信，航空航天和国防等领域，适合研发生产等各种应用场景。

特性与优点最高频率13.6 GHz/20 GHz输出频率分辨率可达0.001 Hz电平设置范围 -130 dBm ~ 20 dBm相位噪声＜-120 dBc/Hz@1 GHz，偏移20 kHz(典型值）幅度精度≤0.7 dB（典型值）支持AM/FM/PM模拟调制，支持内外部调制方式支持脉冲调制功能（选件），脉冲串发生器，用户可自定义脉冲序列（选件）功率计控制套件，能够方便使用功率计测量功率，控制功率的输出，及线损修正支持web 远程控制，可以方便用户远程控制设备5 英寸电容触摸屏，方便用户操作丰富的通信接口：标配USB-HOST，USB DEVICE（USB-TMC），LAN（VXI-11,Socket,Telnet）,选配GPIB2 SSG5000A系列微波信号发生器SSG5000A 系列 射频信号发生器 1型号与主要指标型号 SSG5083ASSG5085A输出频率范围 CW MODE 9 kHz~ 13.6 GHz CW MODE 9 kHz~20 GHz频率设置分辨率 0.001 Hz 幅度分辨率 0.01 dB幅度精度 ≤0.7 dB （典型值）相位噪声 -120 dBc/Hz offset 20 kHz @1 GHz （典型值） 显示 5英寸电容触摸屏，800（RGB ）*480参数规格本规格适用条件为仪器处于校准周期内，在室内温度环境下存放至少两小时，并且预热40分钟。

Arbitrary Waveform GeneratorAWG5000 Series (AWG5014 • AWG5012 • AWG5004 • AWG5002)The AWG5000 Series of Arbitrary Waveform Generators Delivers the Industry’s Best Mixed Signal Stimulus Solution for Today’s Complex Measurement ChallengesThe AWG5000 Series of Arbitrary Waveform Generators delivers theoptimal combination of industry leading sample rate, vertical resolution, signal fidelity and waveform memory length,all in an easy-to-use self-contained package.The series offers the industry’s best solution to the challenging signal stim-ulus issues faced by designers verifying,characterizing and debugging sophisti-cated electronic designs.Meeting the needs of today’s design engineers, the series provides excellent signal dynamic range and integrity.AWG5000 Series models, with a 14bits DA converter based sample rate from 600MS/s to 1.2GS/s, two to four output channels, synchronized four to eight digital marker outputs, and 28-channels of digital data outputs, easily solve the toughest measurement chal-lenges in wireless base band I/Q communications, digital consumer product design such as imaging devices, data conversion equipment and semiconductor design and test. The open Windows (Windows XP)-based instruments are easy and convenient to use and connect easily with peripherals and third-party software.AWG5000 Series.Features & Benefits1.2Gs/s and 600MS/s Models 14 bit Vertical Resolution 2 or 4Arbitrary WaveformDifferential/Single-ended Outputs –Up to 4.5V p-p Single-ended and 9V p-p at Differential Output into 50Ω–0.95ns Tr/Tf (10 to 90%) at 0.6V p-p–+/– 5ns Range (50ps Resolution) Inter Channel Skew Control–SFDR: 80dBc (1MHz),64dBc (10MHz)4 or 8Variable Level Marker Outputs–Up to 3.7V p-p Single-ended Output into 50Ω–300ps Tr/Tf (20 to 80%)at 0 to 1V–Up to 1ns Range (50ps Resolution) Delay Control28 Bits Ch 1/Ch 2Variable Level Digital Data Output–Up to 3.7V p-p Single-ended Output into 50Ω–300ps Tr/Tf (20 to 80%)at 0 to 1VUp to 32M Point Record Length For Longer Data Streams Down to 800ps Resolution Edge Timing Shift Control Real-time Sequencing Creates Infinite Waveform Loops, Jumps,and Conditional BranchesEasy to Use and Learn Shortens Test TimeIntuitive User Interface Based on Windows 2000 XP Convenient Bench Top Form FactorIntegrated PC Supports Network Integration and Provides a Built-in DVD, Removable Hard Drive,LAN and USB portsApplicationsDesigning, Testing and Deploying Wireless Communications: –High Fidelity QuadratureModulation I and Q Base-band Signals (Polar Modulation:I/Q + Magnitude Control, Two Pair of I/Q for MIMO)Imaging–Stimulus Signals for Imaging Display and Recording Devices (CCD, LCD)Data Conversion–Stimulus Signals for DataConversion Devices (ADC, DAC)Mixed Signal Design and Test –2/4Ch Analog + 4/8Ch Marker Outputs + 28 Bit Digital Data OutputsReal-world, Ideal or Distorted Signal Generation – Including All the Glitches, Anomalies and ImpairmentsEnhanced/Corrupted Playback of DSO Captured SignalsWaveform Vectors Imported from Third-party T ools such as MathCAD,MATLAB, Excel and OthersArbitrary Waveform GeneratorAWG5000 Series (AWG5014 • AWG5012 • AWG5004 • AWG5002)AWG5000 Series • /signal_sources2EVM/Constellation measurement.Typical Signal Injection.Arbitrary Waveform GeneratorAWG5000 Series (AWG5014 • AWG5012 • AWG5004 • AWG5002) RTSA Spectrum view.9-PAM with 250 Mbps.Mixed signal test by TDS/TLA iView.™AWG5000 Series • /signal_sources3Arbitrary Waveform GeneratorAWG5000 Series (AWG5014 • AWG5012 • AWG5004 • AWG5002)4AWG5000 Series • /signal_sourcesArbitrary Waveform GeneratorAWG5000 Series (AWG5014 • AWG5012 • AWG5004 • AWG5002)AWG5014AWG5012AWG5004AWG5002Arbitrary WaveformsWaveform Length 1 to 16,200,000 points (or 1 to 32,400,000 points,option 01)Number of Waveforms 1 to 16,000Sequence Length 1 to 4,000stepsSequence Repeat Counter 1 to 65,536 or infiniteSequence Control Repeat count,Trigger,Go-to-N and JumpJump Mode Synchronous and AsynchronousRun ModesContinuous Waveform is iteratively output.If a sequence is defined,the sequence order and repeat functions are appliedTriggered Waveform is output only once when an external,internal,GPIB,LAN or manual trigger is receivedGated Waveform begins output when gate is true and resets to beginning when falseSequence Waveform is output as defined by the sequenceClock GeneratorSampling Frequency10 MS/s to 1.2GS/s10 MS/s to 600 MS/sResolution8digitsInternal ClockAccuracy Within ±(1 ppm + Aging),Aging:within ±1 ppm/yearClock Phase Noise Less than –90dBc/Hz at 100kHz offsetInternal Trigger GeneratorInternal Trigger RateRange 1.0μs to 10.0sResolution3digits,0.1μs minimumSkew Control Between OutputsRange– 5 ns to + 5nsResolution5psAWG5000 Series • /signal_sources5Arbitrary Waveform GeneratorAWG5000 Series (AWG5014 • AWG5012 • AWG5004 • AWG5002)AWG5000 Series • /signal_sources6AWG5014AWG5012AWG5004AWG5002Main Arbitrary Waveform Output Resolution14 bitsAnalog OutputOutput StyleDifferential Output Impedance 50ΩConnectorBNC FrontAmplitude Output Voltage Normal:–4.5 V to + 4.5V,Direct –0.3V to +0.3V Amplitude Normal:20mV p-p to 4.5V p-p ,Direct; 20mV p-p to 0.6V p-pResolution 1mVDC Accuracy±(2.0% of Amplitude + 2mV) at offset = 0V Offset (into 50Ω) Range Normal:–2.25V to +2.25V,Direct:N/A Resolution 1mVAccuracy±(2% of offset +10mV at minimum amplitudePulse Response Rise/Fall time:(10% to 90%).Normal:1.4ns (2.0V p-p ),Direct:0.95ns (0.6V p-p )Bandwidth (–3dB)Normal:250MHz (2.0V p-p ),Direct:370MHz (0.6V p-p )Ringing Normal:750mV p-p (4.5V p-p filter through),80mV p-p (2.0V p-p filter through),Direct:60mV p-p (0.6V p-p )Low Pass Filter High range:100MHz,20MHz,Low range:through,100MHz,20MHz,Direct:N/ADelay from Marker Normal:17.5ns to 19.4ns (20MHz filter),3.8ns to 5.7ns (100MHz filter),0 to 1.9ns (Through),Direct:–1.5ns to 0.4nsSine Wave Characteristics (1.2GS/s clock,32 waveform points,37.5MHz signal frequency)(600MS/s clock,32 waveform points,18.75MHz signal frequency)Harmonics Normal:≤–40dBc (2.0V p-p ),Direct ≤=–49dBc (0.6V p-p )Normal:≤–46dBc (2.0V p-p ),Direct ≤=–55dBc (0.6V p-p )Non Harmonics Normal:≤–60dBc (2.0V p-p ,DC to 600MHz)Normal:≤–60dBc (2.0V p-p ,DC to 300MHz)Phase noise ≤–85dBc/Hz (2.0V p-p ,10kHz offset) –85dBc/Hz (2.0V p-p ,10kHz offset) SFDR 50dBc (Normal,37.5MHz,1.2GS/s,2.0V p-p )56dBc (Normal,18.75MHz,600MS/s,2.0V p-p )60dBc (Normal,10MHz,600MS/s,1.0V p-p )60dBc (Normal,10MHz,600MS/s,1.0V p-p )80dBc (Normal,1MHz,600MS/s,1.0V p-p )80dBc (Normal,1MHz,600MS/s,1.0V p-p )64dBc (Direct,10MHz,600 MS/s,0.6V p-p )64dBc (Direct,10MHz,600MS/s,0.6V p-p )80dBc (Direct,1MHz,600 MS/s,0.6V p-p )80dBc (Direct,1MHz,600MS/s,0.6V p-p )Arbitrary Waveform GeneratorAWG5000 Series (AWG5014 • AWG5012 • AWG5004 • AWG5002) Auxiliary OutputsOutput Style Single-endedOutput Impedance50ΩConnector BNC FrontLevel (into 50Ω)(Twice for Hi_Z input)Output Windows–1.00 V to + 2.7VAmplitude0.10 Vp-p to 3.7 Vp-pResolution10mVDC Accuracy±(10% of setting +120mV) Maximum Output Current±54mA /chRise/Fall Time (20% to 80%)300 ps(1.0 Vp-p,Hi +1.0V,Lo 0V) Skew Adjust Between MarkersRange0 to 1000ps Resolution50psRandom Jitter (Typical)1010 clock patternRMS5psrmsTotal Jitter (Typical)2^15–1PN data patternPeak to Peak (p-p)80psp-pClock (VCO) OutRange600MHz to 1.2GHzAmplitude0.4 Vp-pinto 50Ωto GND Impedance:50Ω,AC coupling Connector BNC Rear10MHz Reference OutAmplitude 1.2 Vp-p into 50Ω.Max 2.5 Vp-popenImpedance50Ω,AC couplingConnector BNC RearDC OutputsNumber of Outputs4:independently controlled outputsRange–3.0 to +5.0VResolution10mVMax.Current±100mAConnector2x4 pin header on front panelAWG5000 Series • /signal_sources7Arbitrary Waveform GeneratorAWG5000 Series (AWG5014 • AWG5012 • AWG5004 • AWG5002)AWG5000 Series • /signal_sources8Trigger In Impedance 1 k Ωor 50ΩPolarity POS or NEG ConnectorBNC FrontInput Voltage Range1 k Ω:±10V.50 Ω:±5V Threshold Level –5.0 V to 5.0VResolution 0.1VTrigger Jitter2.0ns to 4.5ns (Typical) Trigger Mode Minimum Pulse Width 20nsTrigger Hold-off 832* sampling_period – 100ns Delay to Analog Out128* sampling_period + 250ns Gate Mode Minimum Pulse Width 1024* sampling_period + 10ns Delay to Analog Out640* sampling_period + 260ns Event Input Impedance 1 k Ωor 50ΩPolarity POS or NEG ConnectorBNC FrontInput Voltage Range 1 k Ω:±10V.50 Ω:±5V Threshold –5.0 V to 5.0VResolution0.1VSequence Mode Mode Minimum Pulse Width 20nsEvent Hold Off 1024* Sampling Period + 10nsDelay to Analog Out640* Sampling Period + 280 ns (Jump timing:Asynchronous jump)External Clock IN Input Voltage Range 0.2 V p-p to 0.8 V p-p Impedance50Ω,AC coupledConnectorBNC RearReference Clock IN Input Voltage Range 0.2 V p-p to 3.0 V p-p Impedance50Ω,AC coupledFrequency Range 10MHz,20MHz,100MHz (with ±0.1%)ConnectorBNC RearPhase Lock IN Input Ranges5MHz to 600MHz (acceptable frequency drift is ±0.5%)Input Voltage Range 0.2 V p-p to 3 V p-pConnectorBNC RearAdd IN For each analog channel Impedance 50Ω,DC coupledDC Gain 1BandwidthDC to 100MHz at –3 dBInput Voltage Range ±1.0V ConnectorBNC RearArbitrary Waveform GeneratorAWG5000 Series (AWG5014 • AWG5012 • AWG5004 • AWG5002)(Third party software creation waveform data:MATLAB,MathCad,Excel)S/W driver for 3rd party S/W IVI-com driver and MATLAB libraryInstrument Control/Data Transfer PortsGPIB Remote control and data transfer.(Conforms to IEEE-Std 488.1,compatible with IEEE 488.2 and SCPI-1999.0)Ethernet (10/100/1000Base-T)Remote control and data transfer.(Conforms to IEEE 802.3).RJ-45Computer System & Peripherals Windows XP Professional,512 MB SDRAM,80 GB removable Hard Drive at rear (available front mount kit),CD-RW/DVD drive at front,included USB compact keyboard and mousePC I/O Ports USB 2.0 compliant ports (6 total,2 front,4 rear),PS/2mouse and keyboard connectors (rear panel),RJ-45 Ethernet connector (rear panel) supports 10/100/1000BASE-T,XGA outDisplay Characteristics10.4inch,LCD color display with touch screen,1024 (H)x768 (V) (XGA)Power Supply100 to 240VAC,47 to 63HzPower Consumption450WSafety UL61010-1,CAN/CSA-22.2,No.61010-1-04,EN61010-1,IEC61010-1Emissions EN 55011 (Class A),IEC61000-3-2,IEC61000-3-3Immunity IEC61326,IEC61000-4-2/3/4/5/6/8/11Regional CertificationsEurope EN61326Australia/New Zealand AS/NZS 2064AWG5000 Series • /signal_sources9Arbitrary Waveform GeneratorAWG5000 Series (AWG5014 • AWG5012 • AWG5004 • AWG5002)Ordering Information Arbitrary WaveformGenerator MainframeAWG50141.2GS/s,4-channel,14bits,16M point/channel Arbitrary Waveform Generator.AWG50121.2GS/s,2-channel,14bits,16M point/channel Arbitrary Waveform Generator.AWG5004600MS/s,4-channel,14bits,16M point/channel Arbitrary Waveform Generator.AWG5002600MS/s,2-channel,14bits,16M point/channel Arbitrary Waveform Generator.All Models Include:Accessory pouch,front cover, USB mouse,compact USB key board,lead set for DC output,stylus for touch screen 2 each, Windows®XP operating system restore DVD and instructions,AWG5000 Series product software CD and instructions,Document CD with Browser,Quick Start User Manual,registration card,Certificate of Calibration,power cable.Note:Please specify power cord and language option when ordering.Instrument OptionsAWG5014/AWG5012,AWG5004/AWG5002Opt.01 – Waveform Length Expansion (from 16 M to 32 M).AWG5012/AWG5002Opt. 03 –28 bits digital data outputs (digital data of ch 1 and ch 2).Common OptionsInternational Power PlugsOpt. A0 – North America power.Opt. A1 –Universal EURO power.Opt. A2 – United Kingdom power.Opt. A3 – Australia power.Opt. A5 – Switzerland power.Opt.A6 –Japan power.Opt.A10 – China power.Opt.A99 – No power cord or AC adapter.Language OptionsOpt. L0 – English.Opt. L5 – Japanese.Opt. L7 –Simplified Chinese.Opt. L8 – Traditional Chinese.ServiceOpt. CA1 – A single calibration event.Opt. C3 – Calibration service 3 years.Opt. C5 – Calibration service 5 years.Opt. D1 –Calibration data report.Opt. D3 – Calibration data report 3 years (withoption C3).Opt. D5 – Calibration data report 5 years (withoption C5).Opt. R3 –Repair service 3 years.Opt. R5 –Repair service 5 years.Post-sales Service Options:(e.g.,AWG5012-CA1).CA1 – A single calibration event.R3DW – Repair service coverage 3 years.R5DW – Repair service coverage 5 years.R2PW –Repair service coverage 2 yearspost warranty.R1PW –Repair service coverage 1 yearpost warranty.Product UpgradeAWG5014, AWG50UPOpt.M14 – Waveform Length Expansionfrom 16 M point to 32 M point.Product UpgradeAWG5012, AWG50UPOpt. M12 – Waveform Length Expansionfrom 16 M point to 32 M point.Opt.D13 –Digital Data Outputs.Product UpgradeAWG5004, AWG50UPOpt. M04 – Waveform Length Expansionfrom 16 M point to 32 M point.Product UpgradeAWG5002, AWG50UPOpt.M02 – Waveform Length Expansionfrom 16 M point to 32 M point.Opt.D03 –Digital Data Outputs.AWG5000 Series • /signal_sources 10Arbitrary Waveform GeneratorAWG5000 Series (AWG5014 • AWG5012 • AWG5004 • AWG5002)WarrantyOne-year parts and labor.AWG5000 Series • /signal_sources11Arbitrary Waveform GeneratorAWG5000 Series (AWG5014 • AWG5012 • AWG5004 • AWG5002)For Further InformationTektronix maintains a comprehensive, constantly expanding collection of application notes, technical briefs and other resources to help engineers working on the cutting edge of technology. Please visit Copyright © 2008, Tektronix. All rights reserved. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material.Specification and price change privileges reserved. TEKTRONIX and TEK are registered trademarks of Tektronix, Inc. All other trade names referenced are the service marks, trademarks or registered trademarks of their respective companies. 07/08 JS/WOW 76W-20381-3Contact Tektronix:ASEAN/Australasia (65) 6356 3900Austria +41 52 675 3777Balkans, Israel, South Africa and other ISE Countries +41 52 675 3777Belgium 07 81 60166Brazil & South America (11) 40669400Canada 1 (800) 661-5625Central East Europe, Ukraine and the Baltics +41 52 675 3777Central Europe & Greece +41 52 675 3777Denmark +45 80 88 1401Finland +41 52 675 3777France +33 (0) 1 69 86 81 81Germany +49 (221) 94 77 400Hong Kong (852) 2585-6688India (91) 80-22275577Italy +39 (02) 25086 1Japan 81 (3) 6714-3010Luxembourg +44 (0) 1344 392400Mexico, Central America & Caribbean 52 (55) 5424700Middle East, Asia and North Africa +41 52 675 3777The Netherlands ***********Norway 800 16098People’s Republic of China 86 (10) 6235 1230Poland +41 52 675 3777Portugal 80 08 12370Republic of Korea 82 (2) 6917-5000Russia & CIS +7 (495) 7484900South Africa +27 11 206 8360Spain (+34) 901 988 054Sweden 020 08 80371Switzerland +41 52 675 3777Taiwan 886 (2) 2722-9622United Kingdom & Eire +44 (0) 1344 392400USA 1 (800) 426-2200For other areas contact Tektronix, Inc. at: 1 (503) 627-7111Updated 12 November 2007roduct(s) are manufactured in ISO registered facilitie Product(s) complies with IEEE Standard 488.1-1987,RS-232-C,and with Tektronix Standard Codes and Formats.。

Agilent 5000系列便携式示波器技术资料新一代便携式示波器2通用示波器的新标准• 带宽为100 MHz 、300 MHz 和 500 MHz • 2 个或 4 个通道• MegaZoom III 存储与显示技术 • 深达 1 Mpts 的采样存储器 (第4页)• 高达每秒 100,000 个波形的 实时捕获速率 (第5页) • 256 级亮度(辉度)高清晰 XGA (1024 x 768) 显示• 高达12位的垂直分辨率，即使 单次采样也能达到这一水平 (第 7 页)• 完备的标准接口 - 标配 (第 6 页) • USB (3 个端口) • LAN • GPIB • XGA 显示输出• 包括web 浏览器在内，全面实现 远端遥控功能 • 符合 LXI C 类仪器标准• 11种可选语言的用户手册 和示波器在线帮助• 安全环境选项传统台式示波器对于描述您已知的问题非常好。

Agilent 公司MegaZoom III 的深存储器和高捕获速率帮助您找出未知问题。

3适用于所有示波器使用者的前沿技术5000 系列示波器采用了与我们的高性能台式和实验室级示波器相同的第三代 MegaZoom III 技术模块 - 快速响应的深存储器、极小的“死区”时间、高捕获速率、类似模拟示波器的显示系统，我们把这些技术结合在一个紧凑的机箱内，但价格却与采用过去技术的示波器类似。

如果您最近还没有购买过Agilent 示波器，为什么不现在就考虑买一台呢?型号带宽 (MHz)通道数最高取样速度存储深度 捕获速率DSO5012A 100 2 2 GSa/s DSO5014A 100 4 2 GSa/s DSO5032A 300 2 2 GSa/s 最高达 1 Mpts 1 (第 4 页) 最高达每秒 100,000个波形（第 5 页）DSO5034A 300 4 2 GSa/s DSO5052A 500 2 4 GSa/s 2 DSO5054A50044 GSa/s 21 当交叉使用两个通道时获得的最深存储深度2当交叉使用两个通道时获得的最高采样率行业领先的客户支持作为全球领先的测试与测量厂商，Agilent 公司拥有最大的销售工程师、应用工程师、支持工程师与技术人员网络。

选择RF或微波功率传感器/功率计应用指南引言从普及的手机到完善的雷达系统，功率测量是任何RF或微波产品开发周期的基础。

毫不奇怪的是，除了应用以外，调制范围和复用方式变化也非常大。

这种情况再加上以前为高端分析仪预留的功率计中提供的各种新功能，使得RF或微波功率测量系统的选择比以前更加复杂。

由于制造商产品技术资料中提供的产品和技术数据变化很大，因此在制订采购决策前，评价功率传感器的最佳途径是进行对照比较。

本应用指南将介绍购买USB功率传感器时要考虑的部分因素。

应用指南图1. 泰克PSM功率计多路径方框图。

RF输入处理器要考虑的基本因素选择USB功率传感器涉及许多与传统功率计和传感器相同的指标，频率范围、动态范围、准确度、清零和校准、测量速度和触发等因素对选型过程仍至关重要。

频率范围－ 率传感器的频率范围非常广，覆盖从几kHz 到110 GHz的频率范围。

最常用的频率范围是6 GHz -20 GHz。

由于功率传感器是宽带检测器，因此它们在整个频率范围内检测输入上所有RF功率。

传感器内部存储的校准表会考虑传感器的频响变化。

动态范围－ 态范围是传感器能够进行实用测量的功率范围。

这个范围取决于采用的传感器技术类型。

基于二极管的传感器动态范围最宽，通常在-60 dBm - +20 dBm 或更高。

宽动态范围与快速响应时间相结合，使二极管成为大多数应用首选的解决方案。

通过使用校正因数及使用多条二极管路径，二极管传感器把二极管的实用范围扩展到平方律区域之外，实现宽动态范围。

在使用多条路径时，在这些路径之间切换使用的方法可能会影响线性度。

大多数传感器一次测量一条路径，在某个门限上切换，一般是在范围中点周围。

这个跳变点变成潜在的不连续点或粘滞值，可能会导致非线性度或测量延迟。

泰克功率计同时连续数字化两条路径，在跳变点上使用加权后的平均值。

这可以在多条测量通道之间实现平滑连续跳变，在所有时间提供传感器的动态范围，而没有不连续点。

任意波形/函数发生器AFG2021产品技术资料主要特点和优点20 MHz正弦波、10 MHz方波和脉冲波，为大多数应用提供经济的解决方案250 MS/s采样率和14位垂直分辨率，提供同类最优秀的信号保真度直观的类似AFG3000的用户界面，缩短学习周期和客户产品开发周期4 × 128 kS内存和USB存储器扩展装置，存储用户自定义的任意波形标配USB主控端口/设备端口，选配GPIB和LAN接口，在成本和通用性之间实现最佳平衡多种运行模式和调制模式，覆盖大多数客户的作业要求菜单和联机帮助分为8种语言2U高度和半机架宽度，适合台式应用和机架安装应用ArbExpress免费软件，编辑和下载用户自定义波形变得异常简便SignalExpress免费软件，把多种泰克台式仪器组合成低成本自动测试解决方案应用电子测试和设计传感器仿真教育和培训功能测试系统集成产品技术资料2 杰出的性能，经济的价格目前几乎所有消费品都带有电路或器件，要求输入特定电子信号，以便产品正确运行。

这些信号既可以是简单的音频频率或时钟信号，也可以是比较复杂的信号，如碰撞过程中安全气囊传感器发出的串行数据流或信号。

由于提供了20 MHz 带宽、14位分辨率和250 MS/s 采样率，AFG2021任意函数发生器能够以入门级价格，生成简单的信号和复杂的信号。

由于其12种标准波形、调制功能和内置噪声发生器，您可以迅速创建所需信号，全面测试自己的设计。

传承AFG3000直观的用户界面AFG3000系列任意波形/函数发生器创新的简便易用特点首先体现在AF2021的构件上，其可以迅速进入设置和运行特性。

此外，AFG3000客户可以简便地迁移到新的AFG2021上，而不必学习新的用户界面。

3.5英寸彩色TFT 屏幕以图形格式和文本格式显示相关参数，简便地查看波形信息，用户可以对设置全面树立信心，把重点放在手边的任务上。

前面板上的快捷按钮和旋转旋钮可以用最少的工作和时间进入最常用的功能和设置。

数据手册SDG5000系列函数/任意波形发生器主要特性◆采用先进的DDS技术，双通道输出，500MSa/s 采样率，14bit 垂直分辨率◆2ppm高频率稳定度，-116dBc/Hz低相位噪声(SSB)◆具备优越的信号保真度，512K点波形长度，可输出复杂的任意波形，可更精确的显示客户定义的信号◆采用独特的EasyPulse技术，可输出低抖动、快速上升沿/下降沿(不受频率影响)的脉冲信号，占空比极小，边沿和脉宽可以大范围，精细调节◆丰富的调制功能：AM、DSB-AM、FM、PM、FSK、ASK、PWM以及线性/对数扫描和脉冲串◆内置高精度、宽频带频率计，可测量范围：100 mHz ~ 200 MHz（单通道）◆标准配置接口：USB Device，USB Host，支持U 盘存储和软件升级◆大屏幕、高分辨率、高亮度的TFT图形显示，支持直观的操作和参数设置，配置功能强大的任意波编辑软件，支持远程命令控制可编辑任意波可编辑输出14bit、512kpts/16kpts 的任意波形.任意波编辑软件EasyWave 提供9 种标准波形：Sine，Square，Ramp，Pulse，ExpRise，ExpFall，Sinc，Noise 和DC，可满足最基本的需求；同时还为用户提供了手动绘图、直线绘图（包括水平直线、垂直直线、两点直线）、坐标绘图（可以通过鼠标或表格来输入坐标，且有连线和平滑两种方式）和方程式绘图，使创建复杂波形轻而易举；仪器内部提供非易失性波形存储器以存储用户自定义的任意波形.通过EasyWave 可编辑和存储更多任意波形。

信号保真度SDG5000系列函数/任意波形发生器具有高稳定性时基和512kpts任意波形存储长度，可输出更复杂、更精确的任意波.借助该信号发生器能够让客户获得更高的信号保真度。

价格合理，性能优越SDG5000系列函数/任意波形发生器是SIGLENT家族的最新成员.人性化设计：4.3英寸TFT-LCD显示；支持中英文菜单及英文输入；按键帮助，方便信息获取；支持U盘和本地存储，便于文件管理；专用的接地端子。

模拟通道带宽：150 MHz2个模拟通道，1个EXT通道，标配16个数字通道（需选购探头） 实时采样率最高达4 GSa/s最高存储深度达100 Mpts（选件） 波形捕获率高于300,000个波形每秒多达41种波形参数自动测量，更提供全内存硬件测量功能 丰富的串行协议触发和解码功能多达45万帧的硬件实时波形不间断录制和回放功能 独立的搜索、导航按键和事件列表 内置高级的电源分析软件（选件） 支持伯德图环路测试分析功能集7种独立仪器于一身，包括：示波器、逻辑分析仪、频谱分析仪、任意波发生器、数字电压表、频率计和累加器、协议分析仪9英寸多点触控电容屏，256级波形灰度显示，带彩色余辉丰富的接口：USB Host & Device、千兆LAN(LXI)、HDMI、TRIG OUT、 USB-GPIB支持Web Control远程命令控制 独有的在线版本升级功能精致小巧的工业设计，便捷的操作MSO5000-E系列数字示波器是基于RIGOL UltraVision II代技术的高性能数字示波器，采用9英寸多点电容触摸屏，集7种仪器于一身。

具有超高的采样带宽比和存储深度等优异的性能指标，以及精巧便携的外观设计。

支持仪器功能组合和分析功能的软件升级，并可根据不同用户群体的需求量身定制，从而最大程度帮助用户节省预算，使用户享受最优的测试支持与使用体验。

234小身材，大格局创新的仪器外观，双侧减薄设计，提升显示屏大小却依然保持小巧的机身，最大限度方便客户的操作和携带。

9英寸WSVGA（1024×600）多点触控电容屏，256级波形灰度显示Quick action 一键操作HDMI 高清视频输出触摸屏锁定按键搜索导航专用按键手柄接口LAN 接口触发输出接口电源插孔Kensington 安全锁孔5RIGOL示波器中高端系列产品概览6设计特色超性价比七合一 集成示波器在如今的集成设计领域，一款集成度较高的综合示波器已经成为设计工程师必不可少的得力工具。
