文献翻译-数控技术和装备发展趋势及对策

数控技术和装备进展趋势及计谋原文来源：Zhao Chang-ming Liu Wang-ju (CNC Machining Process and equipment, 2002,China)一、摘要Equip the engineering level, level of determining the whole national economy of the modernized degree and modernized degree of industry, numerical control technology is it develop new developing newhigh-tech industry and most advanced industry to equip (such as information technology and his industry, biotechnology and his industry, aviation, spaceflight, etc. national defense industry) last technology and getting more basic most equipment. Numerical control technology is the technology controlled to mechanical movement and working course with digital information, integrated products of electromechanics that the numerical control equipment is the new technology represented by numerical control technology forms to the manufacture industry of the tradition and infiltration of the new developing manufacturing industry,Keywords:Numerical ControlTechnology, E quipment, industry二、译文数控技术和装备进展趋势及计谋装备工业的技术水平和现代化程度决定着整个国民经济的水平和现代化程度，数控技术及装备是进展新兴高新技术产业和尖端工业（如信息技术及其产业、生物技术及其产业、航空、航天等国防工业产业）的使能技术和最大体的装备。

1.1.3:数控技术和装备开展趋势与对策开展趋势表现为一下几点:1 高速化〔1〕主轴转速：机床采用电主轴〔内装式主轴电机〕，主轴最高转速达200000r/min；〔2〕进给率：在分辨率为0.01μm时，最大进给率达到240m/min且可获得复杂型面的准确加工；〔3〕运算速度：微处理器的迅速开展为数控系统向高速、高精度方向开展提供了保障，开发出CPU已开展到32位以与64位的数控系统，频率提高到几百兆赫、上千兆赫。

由于运算速度的极大提高，使得当分辨率为0.1μm、0.01μm时仍能获得高达24～240m/min的进给速度；〔4〕换刀速度：目前国外先进加工中心的刀具交换时间普遍已在1s左右，高的已达0.5s。

德国Chiron公司将刀库设计成篮子样式，以主轴为轴心，刀具在圆周布置，其刀到刀的换刀时间仅0.9s。

2 高精度化数控机床精度的要求现在已经不局限于静态的几何精度，机床的运动精度、热变形以与对振动的监测和补偿越来越获得重视。

〔1〕提高C系统控制精度：采用高速插补技术，以微小程序段实现连续进给，使C控制单位精细化，并采用高分辨率位置检测装置，提高位置检测精度〔日本已开发装有106脉冲/转的内藏位置检测器的交流伺服电机，其位置检测精度可达到0.01μm/脉冲〕，位置伺服系统采用前馈控制与非线性控制等方法；〔2〕采用误差补偿技术：采用反向间隙补偿、丝杆螺距误差补偿和刀具误差补偿等技术，对设备的热变形误差和空间误差进展综合补偿。

研究结果说明，综合误差补偿技术的应用可将加工误差减少60%～80%；〔3〕采用网格解码器检查和提高加工中心的运动轨迹精度，并通过仿真预测机床的加工精度，以保证机床的定位精度和重复定位精度，使其性能长期稳定，能够在不同运行条件下完成多种加工任务，并保证零件的加工质量。

3 功能复合化复合机床的含义是指在一台机床上实现或尽可能完成从毛坯至成品的多种要素加工。

根据其结构特点可分为工艺复合型和工序复合型两类。

Numerical control technology and equiping development trend and countermeasureEquip the engineering level , level of determining the whole national economy of the modernized degree and modernized degree of industry, numerical control technology is it develop new developing new high-tech industry and most advanced industry to equip (such as information technology and his industry, biotechnology and his industry, aviation , spaceflight,etc. national defense industry industry) last technology and getting more basic most equipment. Marx has ever said " the differences of different economic times, do not lie in what is produced , and lie in how to produce, produce with some means of labor ". Manufacturing technology and equiping the most basic means of production that are that the mankind produced the activity, and numerical control technology is nowadays advanced manufacturing technology and equips the most central technology. Nowadays the manufacturing industry all around the world adopts numerical control technology extensively, in order to improve manufacturing capacity and level, improve the adaptive capacity and competitive power to the changeable market of the trends . In addition every industrially developed country in the world also classifies the technology and numerical control equipment of numerical control as the strategic materials of the country, not merely take the great measure to develop one's own numerical control technology and industry, and implement blockading and restrictive policy to our country in view of " high-grade , precision and advanced key technology of numerical control " and equiping. In a word, develop the advanced manufacturing technology taking numerical control technology as the core and already become every world developed country and accelerate economic development in a more cost-effective manner, important way to improve the overall national strength and national position. Numerical control technology is the technology controlled to mechanical movement and working course with digital information, integrated products of electromechanics that the numerical control equipment is the new technology represented by numerical control technology forms to the manufacture industry of the tradition and infiltration of the new developing manufacturing industry, namely the so-called digitization is equipped, its technological range covers a lot of fields: (1)Mechanical manufacturing technology; (2)Information processing , processing , transmission technology; (3)Automatic control technology; (4)Servo drive technology;(5)Technology of the sensor ; (6)Software engineering ,etc..Development trend of a numerical control technologyThe application of numerical control technology has not only brought the revolutionary change to manufacturing industry of the tradition, make the manufacturing industry become the industrialized symbol , and with the constant development of numerical control technology and enlargement of the application, the development of some important trades (IT , automobile , light industry , medical treatment ,etc. ) to the national economy and the people's livelihood of his plays a more and more important role, because the digitization that these trades needed to equip has already been the main trend of modern development. Numerical control technology in the world at present and equiping the development trend to see, there is the following several respect [1- ] in its main research focus .1.A high-speed , high finish machining technology and new trend equippedThe efficiency , quality are subjavanufacturing technology. High-speed , high finish machining technology can raise the efficiency greatly , improve the quality and grade of the products, shorten production cycle and improve the market competitive power. Japan carries the technological research association first to classify it as one of the 5 great modern manufacturing technologies for this, learn (CIRP ) to confirm it as the centre in the 21st century and study one of the directions in international production engineering.In the field of car industry, produce one second when beat such as production of 300,000 / vehicle per year, and many variety process it is car that equip key problem that must be solved one of; In the fields of aviation and aerospace industry, spare parts of its processing are mostly the thin wall and thin muscle, rigidity is very bad, the material is aluminium or aluminium alloy, only in a situation that cut the speed and cut strength very small high, could process these muscles , walls . Adopt large-scale whole aluminium alloy method that blank " pay empty " make the wing recently, such large-scale parts as the fuselage ,etc. come to substitute a lot of parts to assemble through numerous rivet , screw and other connection way, make the intensity , rigidity and dependability of the component improved. All these, to processing and equiping the demand which has proposed high-speed , high precise and high flexibility.According to EMO2001 exhibition situation, high-speed machining center is it give speed can reach 80m/min is even high , air transport competent speed can up to 100m/min to be about to enter. A lot of automobile factories in the world at present, including Shanghai General Motors Corporation of our country, have already adopted and substituted and made the lathe up with the production line part that the high-speed machining center makes up . HyperMach lathe of U.S.A. CINCINNATI Company enters to nearly biggest 60m/min of speed, it is 100m/min to be fast, the acceleration reaches 2g, the rotational speed of the main shaft has already reached 60 000r/min. Processing a thin wall of plane parts, spend 30min only, and same part general at a high speed milling machine process and take 3h, the ordinary milling machine is being processed to need 8h; The speed and acceleration of main shaft of dual main shaft lathes of Germany DMG Company are up to 12* separately! 000r/mm and 1g.In machining accuracy, the past 10 years, ordinary progression accuse of machining accuracy of lathe bring 5¦Ìm up to from 10¦Ìm already, accurate grades of machining center from 3- 5¦Ìm, rise to 1- 1.5¦Ìm, and ultraprecision machining accuracy is it enter nanometer grade to begin already (0.01¦Ìm).In dependability, MTBF value of the foreign numerical control device has already reached above 6 000h, MTBF value of the servo system reaches above 30000h, demonstrate very high dependability .In order to realize high-speed , high finish machining, if the part of function related to it is electric main shaft , straight line electrical machinery get fast development, the application is expanded further.1.2 Link and process and compound to process the fast development of the lathe in 5 axesAdopt 5 axles to link the processing of the three-dimensional curved surface part, can cut with the best geometry form of the cutter , not only highly polished, but also efficiency improves by a large margin . It is generally acknowledged , the efficiency of an 5 axle gear beds can equal 2 3 axle gear beds , is it wait for to use the cubic nitrogen boron the milling cutter of ultra hard material ismilled and pared at a high speed while quenching the hard steel part, 5 axles link and process 3 constant axles to link and process and give play to higher benefit. Because such reasons as complicated that 5 axles link the numerical control system , host computer structure that but go over, it is several times higher that its price links the numerical control lathe than 3 axles , in addition the technological degree of difficulty of programming is relatively great, have restricted the development of 5 axle gear beds.At present because of electric appearance of main shaft, is it realize 5 axle complex main shaft hair structure processed to link greatly simplify to make, it makes degree of difficulty and reducing by a large margin of the cost, the price disparity of the numerical control system shrinks . So promoted 5 axle gear beds of head 无效of complex main shaft and compound to process the development of the lathe (process the lathe including 5 ).At EMO2001 exhibition, new Japanese 5 of worker machine process lathe adopt complex main shaft hair, can realize the processing of 4 vertical planes and processing of the wanton angle , make 5 times process and 5 axles are processed and can be realized on the same lathe, can also realize the inclined plane and pour the processing of the hole of awls . Germany DMG Company exhibits the DMUV oution series machining center, but put and insert and put processing and 5 axles 5 times to link and process in once, can be controlled by CNC system or CAD/CAM is controlled directly or indirectly.1.3 Become the main trend of systematic development of contemporary numerical control intelligently , openly , networkedlilyThe numerical control equipment in the 21st century will be sure the intelligent system, the intelligent content includes all respects in the numerical control system: It is intelligent in order to pursue the efficiency of processing and process quality, control such as the self-adaptation of the processing course, the craft parameter is produced automatically; Join the convenient one in order to improve the performance of urging and use intelligently, if feedforward control , adaptive operation , electrical machinery of parameter , discern load select models , since exactly makes etc. automatically automatically; The ones that simplified programming , simplified operating aspect are intelligent, for instance intelligent automatic programming , intelligent man-machine interface ,etc.; There are content of intelligence diagnose , intelligent monitoring , diagnosis convenient to be systematic and maintaining ,etc..Produce the existing problem for the industrialization of solving the traditional numerical control system sealing and numerical control application software. A lot of countries carry on research to the open numerical control system at present, such as NGC of U.S.A. (The Next Generation Work-Station/Machine Control), OSACA of European Community (Open System Architecture for Control within Automation Systems), OSEC (Open System Environment for Controller ) of Japan, ONC (Open Numerical Control System ) of China ,etc.. The numerical control system melts to become the future way of the numerical control system open. The so-called open numerical control system is the development of the numerical control system can be on unified operation platform, face the lathe producer and end user, through changing, increasing or cutting out the structure target(numerical control function), form the seriation, and can use users specially conveniently and the technical know-how is integrated in the control system, realize the open numerical control system of different variety , different grade fast, form leading brand products with distinct distinction. System structure norm of the open numerical control system at present,communication norm , disposing norm , operation platform , numerical control systematic function storehouse and numerical control systematic function software developing 包含ument ,etc. are the core of present research.The networked numerical control equipment is a new light spot of the fair of the internationally famous lathe in the past two years. Meeting production line , manufacture system , demand for the information integration of manufacturing company networkedly greatly of numerical control equipment, realize new manufacture mode such as quick make , fictitious enterprise , basic Entrance that the whole world make too. Some domestic and international famous numerical control lathes and systematic manufacturing companies of numerical control have all introduced relevant new concepts and proto无效s of a machine in the past two years, if in EMO2001 exhibition, " CyberProduction Center " that the company exhibits of mountain rugged campstool gram in Japan (Mazak ) (intellectual central production control unit, abbreviated as CPC); The lathe company of Japanese big Wei (Okuma ) exhibits " IT plaza " (the information technology square , is abbreviated as IT square ); Open Manufacturing Environment that the company exhibits of German Siemens (Siemens ) (open the manufacturing environment, abbreviated as OME),etc., have reflected numerical control machine tooling to the development trend of networked direction.1.4 Pay attention to the new technical standard , normal setting-up1.4.1 Design the norm of developing about the numerical control systemAs noted previously, there are better commonability , flexibility , adaptability , expanding in the open numerical control system, such countries as U.S.A. , European Community and Japan ,etc. implement the strategic development plan one after another , carry on the research and formulation of the systematic norm (OMAC , OSACA , OSEC ) of numerical control of the open system structure, 3 biggest economies in the world have carried on the formulation that nearly the same science planned and standardized in a short time, have indicated a new arrival of period of change of numerical control technology. Our country started the research and formulation of standardizing the frame of ONC numerical control system of China too in 2000.1.4.2 About the numerical control standardThe numerical control standard is a kind of trend of information-based development of manufacturing industry. Information exchange among 50 years after numerical control technology was born was all because of ISO6983 standard, namely adopt G, M code describes how processes, its essential characteristic faces the processing course, obviously, he can't meet high-speed development of modern numerical control technology's needs more and more already. For this reason, studying and making a kind of new CNC system standard ISO14649 (STEP-NC) in the world, its purpose is to offer a kind of neutral mechanism not depending on the concrete system , can describe the unified data model in cycle of whole life of the products , thus realize the whole manufacture process, standardization of and even each industrial field product information.The appearance of STEP-NC may be a revolution of the technological field of the numerical control, on the development and even the whole manufacturing industry of numerical control technology , will exert a far-reaching influence. First of all, STEP-NC puts forward a kind of brand-new manufacture idea , in the traditional manufacture idea, NC processes the procedures toall concentrate on individual computer. Under the new standard, NC procedure can be dispersed on Internet, this is exactly a direction of open , networked development of numerical control technology. Secondly, STEP-NC numerical control system can also reduce and process the drawing (about 75% ) , process the procedure to work out the time (about 35% ) and process the time (about 50% ) greatly .At present, American-European countries pay much attention to the research of STEP-NC, Europe initiates IMS plan (1999.1.1- 2001.12.3 ) of STEP-NC. 20 CAD/CAM/CAPP/CNC users , manufacturers and academic organizations from Europe and Japan participated in this plan. STEP Tools Company of U.S.A. is a developer of the data interchange software of manufacturing industry in the global range, he has already developed the super model (Super Model ) which accuses of information exchange of machine tooling by counting, its goal is to describe all processing courses with the unified norm. Such new data interchange form has already been verified in allocating the SIEMENS , FIDIA and European OSACA-NC numerical control at present.2 pairs of basic estimations of technology and industry development of numerical control of our countryThe technology of numerical control of our country started in 1958, the development course in the past 50 years can roughly be divided into 3 stages: The first stage is from 1958 to 1979, namely closed developing stage. In this stages, because technology of foreign countries blockade and basic restriction of terms of our country, the development of numerical control technology is comparatively slow. During " Sixth Five-Year Plan Period " , " the Seventh Five-Year Plan Period " of the country in second stage and earlier stage in " the Eighth Five-Year Plan Period ", namely introduce technology, digest and assimilate, the stage of establishing the system of production domesticization arisesing tentatively. At this stage , because of reform and opening-up and national attention , and study the improvement of the development environment and international environment, research , development and all making considerable progress in production domesticization of the products of the technology of numerical control of our country. The third stage is and during the " Ninth Five-Year Plan Period " on the later stage in " the Eighth Five-Year Plan Period " of the country, namely implement the research of industrialization, enter market competition stage. At this stage , made substantive progress in industrialization of the domestic numerical control equipment of our country. In latter stage for " the Ninth Five-Year Plan ", the domestic occupation rate of market of the domestic numerical control lathe is up to 50%, it is up to 10% too to mix the domestic numerical control system (popular ).Make a general survey of the development course in the past 50 years of technology of numerical control of our country, especially through tackling key problems of 4 Five-Year Plans, all in all has made following achievements.a.Have establish the foundation of the technical development of numerical control, has mastered modern numerical control technology basically. Our country has already, the numerical control host computer , basic technology of special plane and fittings grasped and driven from the numerical control system and servoly basically now, among them most technology have already possessed and commercialized the foundation developed , some technology has already, industrialization commercialized.b.Have formed the industrial base of numerical control tentatively. In tackling key problems the foundation that the achievement and some technology commercialize , set up the systematic factories of numerical control with production capacity in batches such as numerical control in Central China , numerical control of the spaceflight etc.. Electrical machinery plant of Lanzhou, such factory and the first machine tool plant of Beijing , the first machine tool plant of Jinan ,etc. several numerical control host computer factories of a batch of servo systems and servo electrical machineries as the numerical control in Central China,etc.. These factories have formed the numerical control industrial base of our country basically.c.Have set up a numerical control research, development , managerial talent's basic team . Though has made considerable progress in research and development and industrialization of numerical control technology, but we will realize soberly, the research and development of the technology of advanced numerical control of our country, especially there is greater disparity in current situation and current demand of our country of engineering level in industrialization. Though very fast from watching the development of our country vertically, have disparity horizontally more than (compare foreign countries with ) not merely engineering level, there is disparity too in development speed in some aspects, namely the engineering level disparity between some high-grade , precision and advanced numerical control equipment has the tendency to expand . Watch from world , estimate roughly as follows about the engineering level of numerical control of our country and industrialization level.a.On the engineering level, in probably backward 10- 1 years with the advanced level in foreign countries, it is bigger in high-quality precision and sophisticated technology.b.On the industrialization level, the occupation rate of market is low, the variety coverage rate is little, have not formed the large-scale production yet; The specialized level of production of function part and ability of forming a complete set are relatively low; Appearance quality is relatively poor; Dependability is not high, the commercialized degree is insufficient; One's own brand effect that the domestic numerical control system has not been set up yet, users have insufficient confidence.c.On the ability of sustainable development, research and development of numerical control technology , project ability are relatively weak to the competition; It is not strong that the technological application of numerical control expands dynamics; Research , formulation that relevant standards are normal lag behind.It is analysed that the main reason for having above-mentioned disparity has the following several respect.a.Realize the respect. Know to industry's process arduousness , complexity and long-term characteristic of domestic numerical control insufficiently; It is difficult to underestimate to add strangling , system ,etc. to the unstandard , foreign blockade of the market; It is not enough to analyse to the technological application level and ability of numerical control of our country.b.System. Pay close attention to numerical control industrialization many in the issue , consider numerical control industrialization little in the issue synthetically in terms of the systematic one , industry chain in terms of technology; Have not set up related system , perfect training , service network of intact high quality ,etc. and supported the system.c.Mechanism. It causes the brain drain, restraining technology and technological route from innovating again , products innovation that the bad machine is made, and has restricted the effective implementation of planning , has often planned the ideal , implement the difficulty.d.Technology. The autonomous innovation in technology of enterprises is indifferent, the project of key technology is indifferent. The standard of the lathe lags behind, the level is relatively low, it is not enough for new standard of the numerical control system to study.3 pairs of strategic thinking of technology and industrialized development of numerical control of our country3.1 Strategic considerationOur country make big country, industry is it is it accept front instead of transformation of back end to try one's best to want in shifting in world, namely should master and make key technology advancedly, otherwise in a new round of international industrial structure adjustment, the manufacturing industry of our country will step forward and " leave the core spaces ". We regard resource , environment , market as the cost, it is only an international " machining center " in the new economic pattern of the world to exchange the possibility got and " assemble the centre ", but not master the position of the manufacturing center of key technology , will so influence the development process of the modern manufacturing industry of our country seriously.We should stand in the height of national security strategy paying attention to numerical control technology and industry's question , at first seen from social safety, because manufacturing industry whether our country obtain employment most populous trade, the development of manufacturing industry not only can improve the people's living standard but also can alleviate the pressure of employment of our country , ensure the stability of the society; Secondly seen from national defence security, the western developed country has classified all the high-grade , precision and advanced numerical control products as the strategic materials of the country, realizing the embargo and restriction to our country, " Toshiba incident " and " Cox Report " is the best illustration.3.2 Development tacticsProceed from the angles of the fundamental realities of the country of our country, regard the strategic demand of the country and market demand of national economy as the direction, regard improving our country and making the comprehensive competitive power of equiping industry and industrialization level as the goal, use the systematic method , be able to choose to make key technology upgraded in development of equiping industry and support technology supporting the development of industrialization in our country in initial stage of 21st century in leading factor, the ability to supply the necessary technology realizes making the jump 无效development of the equiping industry as the content of research and development.Emphasize market demand is a direction, namely take terminal products of numerical control as the core, with the complete machine (Such as the numerical control lathe having a large capacity and a wide range, milling machine , high speed high precise high-performance numerical control lathe , digitized machinery of model , key industry key equipment ,etc.) drive the development of the numerical control industry. Solve the numerical control system and relevant functions part especially The dependability that (digitized servo system and electrical machinery , high speed electric main shaft system and new-无效enclosure that equip ,etc. ) and production scale question. There are no products that scale will not have high dependability ; Will not have cheap and products rich in the competitiveness without scale ; Certainly, it is difficult to have day holding up one's head finally that there is no scale Chinese numerical control equipment.In equiping researching and developing high-grade , precision and advancedly , should emphasize the production, learning and research and close combination of the end user, regard " drawing, using, selling " as the goal, tackle key problems according to the national will, in order to solve the needing badly of the country.Numerical control technology, emphasized innovation, put emphasis on researching and developing the technology and products with independent intellectual property right before the competition, establish the foundation for the industry of numerical control of our country , sustainable development of equipment manufacture and even the whole manufacturing industry.List of references:[1]China machine tool industrial association Development department of the trade. CIMT2001 tour [J ]. The manufacturing technology in the world and equiping the market, 2001 (3): 18-20. [2]The roof beam trains a king to declare , the distribution is helped. New tendency [J ] of the technical development of the lathe . The manufacturing technology in the world and equiping the market, 2001 (3): 21-28.[3]China machine tool industrial association Systematic branch of numerical control. CIMT2001 tour [J ]. The manufacturing technology in the world and equiping the market, 2001 (5): 13-17. [4]Yang XueTong, Li DongRu, He WenLi ,etc.? Numerical control lathe technical development strategic research [M ] from now to century. Beijing: State Bureau of Machinery Industries, 2000.数控技术和装备发展趋势及对策装备工业的技术水平和现代化程度决定着整个国民经济的水平和现代化程度，数控技术及装备是发展新兴高新技术产业和尖端工业（如信息技术及其产业、生物技术及其产业、航空、航天等国防工业产业）的使能技术和最基本的装备。

NC technology and equipment数控技术与装备In China,the development of NC technology and equipment has been attached great importance to the considerable progress made in recent years.Especially in the common areas of computer numerical control,PC-based CNC system made that we have been in the forefront of the world.However,the technology research and industrial development in NC is also plagued with problems,especially in the technical innovation capability commercialization process,and other aspects of market share is particularly prominent.At the dawn of the new century,how to effectively address these issues,NC areas along the path of sustainable development in China.into the overall comprehensive advanced in the world,so we have a pivotal position in international competition.NC will be the research and development sector and the important tasks facing manufacturers.在我国，数控技术与装备的发展亦得到了高度重视，近年来取得了相当大的进步。

数控技术和装备发展趋势及对策数控技术是指以数字控制系统为核心，通过自动化技术和机电一体化技术，对加工过程中的各种工艺参数和运动轨迹进行控制的一种现代化制造技术。

它已经在各个领域得到广泛应用，包括航天航空、汽车制造、船舶制造、机床制造等。

随着科技的不断进步和经济的快速发展，数控技术和装备也在不断地发展壮大。

本文将从数控技术和装备的发展趋势以及对策两方面进行分析。

首先，数控技术和装备的发展趋势是数字化、智能化、网络化和柔性化。

随着信息技术的快速发展，数控技术和装备在制造过程中的数字化程度不断提高。

通过采用CAD/CAM技术，可以实现产品的数字化设计和制造。

智能化是指数控技术和装备具备智能化的功能，能够根据工艺要求自动调整参数和运动轨迹。

网络化是指数控技术和装备可以通过网络进行远程监控和控制，实现集中管理和远程操作。

柔性化是指数控技术和装备具备较强的适应性，可以灵活地实现不同产品的加工和生产。

其次，针对数控技术和装备的发展趋势，我们可以采取一系列的对策。

首先，要加大对数控技术研发的投入，提高核心技术的创新能力。

目前国内的数控技术和装备与国际先进水平相比仍存在一定差距，需要加强基础理论研究和关键技术攻关，提升自主创新能力。

其次，要加强产学研用一体化的合作，实现技术和市场的有机结合。

通过与企业合作开展技术研发，可以更好地解决实际生产中的问题，并加快技术转化和推广应用的速度。

同时，要加强人才培养，培养一支高素质的数控技术和装备的研发人员队伍。

还要完善相关政策，提供必要的政策支持和资金支持，鼓励企业加大对数控技术的投资，推动数控技术和装备的普及和应用。

总之，数控技术和装备的发展趋势是数字化、智能化、网络化和柔性化。

为了适应这一发展趋势，我们需要采取一系列的对策，包括加大对数控技术的研发投入、加强产学研用一体化的合作、加强人才培养和完善相关政策等。

通过这些对策的实施，可以推动数控技术和装备的更快发展，促进制造业的转型升级。

数控技术和装备趋势及对策装备的技术水平和程度决定着整个国民经济的水平和程度，数控技术及装备是新兴高和尖端（如信息技术及其、生物技术及其、航空、航天等国防)的使能技术和最基本的装备。

曾经说过“各种经济时代的区别，不在于生产什么,而在于怎样生产，用什么劳动资料生产".制造技术和装备就是人类生产活动的最基本的生产资料,而数控技术又是当今先进制造技术和装备最核心的技术.当今世界各国制造业广泛采用数控技术，以提高制造能力和水平，提高对动态多变市场的适应能力和竞争能力.此外世界上各发达国家还将数控技术及数控装备列为国家的战略物资，不仅采取重大措施来自己的数控技术及其，而且在“高精尖”数控关键技术和装备方面对我国实行和限制策。

总之，大力以数控技术为核心的先进制造技术已成为世界各发达国家加速经济、提高和国家地位的重要途径。

数控技术是用数字信息对机械运动和工作过程进行控制的技术,数控装备是以数控技术为代表的对传统制造和新兴制造业的渗透的机电产品，即所谓的数字化装备，其技术范围覆盖很多领域:（1）机械制造技术；（２）信息处理、加工、传输技术；(３)自动控制技术；（4）伺服驱动技术；（5)传感器技术；(6）软件技术等．1 数控技术的趋势数控技术的应用不但给传统制造业带来了性的变化，使制造业成为化的象征，而且随着数控技术的不断和应用领域的扩大,他对国计民生的一些重要行业(、汽车、轻工、医疗等）的起着越来越重要的作用,因为这些行业所需装备的数字化已是现代的大趋势.从目前世界上数控技术及其装备的趋势来看，其主要研究热点有以下几个方面[1～4]．１。

１高速、高精加工技术及装备的新趋势效率、质量是先进制造技术的主体。

高速、高精加工技术可极大地提高效率,提高产品的质量和档次，缩短生产周期和提高市场竞争能力。

为此先端技术研究会将其列为5大现代制造技术之一，国际生产工程学会（）将其确定为21世纪的中心研究方向之一．在轿车领域，年产３0万辆的生产节拍是40秒／辆,而且多品种加工是轿车装备必须解决的重点问题之一；在航空和宇航领域，其加工的零部件多为薄壁和薄筋，刚度很差,材料为铝或铝合金,只有在高切削速度和切削力很小的情况下,才能对这些筋、壁进行加工．近来采用大型整体铝合金坯料“掏空"的方法来制造机翼、机身等大型零件来替代多个零件通过众多的铆钉、螺钉和其他联结方式拼装，使构件的强度、刚度和可靠性得到提高。

Not only the Chinese numerical control lathe present situation and thetrend of development(中国数控车床的现状和发展趋势分析)analysis numerical control technology application has brought the revolutionary change for the traditional manufacturing industry, causes the manufacturing industry to become the industrialization the symbol, moreover along with numerical control technology unceasing development and application domain expansion, it to national economy and the people's livelihood some important professions (IT, automobile, light industry, medical service and so on) development more and more vital role, because these professions must equip the digitization already was the modern development major tendency. The current numerical control lathe presents following trend of development.1. high speed, high precisionHigh speed, precise is the engine bed development eternal goal.Development progresses by leaps and bounds which along with the science and technology, the mechanical and electrical products renewal speed speeds up, increasingly is also high to the components processing precision and the surface quality request.In order to satisfy this complex changeable market the demand, the current engine bed to the high-speed cutting, is doing the cutting and does the direction of cut to develop, the processing precision also in unceasingly enhances. On the other hand, the electricity main axle and the straight line electrical machinery success application, the ceramics ball bearing, the high accuracy lead greatly hollow in cold and the ball bearing nut strong cold low temperature high speed ball bearing guide screw vice-and the belt ball bearing retainer straight line guide rail vice-and so on engine bed function part appearing on the market, also for the engine bed to high speed, the precise development has created the condition. The numerical control lathe picks uses electricity the main axle, has cancelled links and so on leather belt, band pulley and gear, reduced the master drive rotation inertia greatly, enhanced the main axle dynamic speed of response and the work precision, when thorough settlement main axle high-speed operation transmission and so on leather belt and band pulley vibrations and noise question.Picks uses electricity the main axle structure to be possible to enable the main axle rotational speed to achieve above 10000r/min.The straight line motor-driven speed is high, adds the moderating properties to be good, has the superior response characteristic and the followed precision. Made the servo with the straight line electrical machinery to actuate, to omit the ball bearing guide screw this intermediate drive link, eliminated the transmission gap (including reverse gap), the movement inertia was small, the system rigidity was good, could locate precisely under high speed, thus increased the servo precision enormously.Straight line trundle guide rail, because it has respectively to the gap for the zero and the extremely small rolling friction, wears slightly, gives off heat may ignore, has the extremely good thermostability, increased the entire journey pointing accuracy and the repetition pointing accuracy. Through the straight line electrical machinery and the straight line trundle guide rail vice-application,may make the engine bed the rapid traverse speed to enhance 60~80m/min from present10~20m/mim, even reaches as high as 120m/min.2. redundant reliablenumerical control engine bed reliability is a numerical control engine bed product quality crucial target.Whether does the numerical control engine bed display its high performance, the high accuracy and the high efficiency, and obtains the good benefit, the key is decided by its reliable height.3. function recombinefunction recombine goal is further enhances the engine bed the production efficiency, uses reduces to few in the non-processing non-cutting time.Through the function recombine, may expand the engine bed the use scope, enhances the efficiency, realizes multipurpose one machine, one machine many energy, namely a numerical control lathe already may realize the turning function, also may realize the milling processing; Or in also may realize the abrasive machining by the mill primarily engine bed on.4. intellectualizations, the network, the flexibility and the integrated21st century numerical control equipments has certain intellectualized system. In order to pursue the processing efficiency and the processing quality aspect intellectualization, like processing process adaptive control, craft parameter automatic production; In order to enhance the actuation performance and the use connection aspect intellectualization, like feed-forward control, electrical machinery parameter auto-adapted operation, automatic diagnosis load automatic designation model, self regulating grade; Simplification programming, simplification operation aspect intellectualization, like intellectualized automatic programming, intellectualized man-machine contact surface and so on; Also has the intelligence to diagnose, aspect and so on intelligent monitoring contents, by facilitates the system the diagnosis and the service and so on. The numerical control engine bed the tendency which develops to the flexibility automated system is: From (numerical control single plane, processing center and numerical control compound processing engine bed), line (FMC, FMS, FTL, FML) to surface (construction section workshop independent manufacture island, FA), body (CIMS, distribution network integration manufacture system) the direction develops, on the other hand develops to the attention utility and the efficient direction. The flexible automation technology is the manufacturing industry adapts the dynamic market demand and the product rapid renewal main method, is the various countries' manufacturing industry development mainstream tendency, is the advanced manufacture domain foundation technology.Its key point is by enhances the system the reliability, changes into the premise practical, take the easy networking and the integration as the goal, the attention enhancement unit technology development and the consummation.The CNC single plane to the high accuracy, the high velocity and the high flexible direction develops. The numerical control engine bed and the constitution flexibility manufacture system can conveniently and joints and so on CAD, CAM, CAPP and MTS, develops to the information integration direction.The network system to the opening, the integration and the intellectualized direction develops.中国数控车床的现状和发展趋势分析数控技术的应用不但给传统制造业带来了革命性的变化，使制造业成为工业化的象征，而且随着数控技术的不断发展和应用领域的扩大，它对国计民生的一些重要行业(IT、汽车、轻工、医疗等)的发展起着越来越重要的作用，因为这些行业所需装备的数字化已是现代发展的大趋势。

第一章数控技术及应用领域1.1数控技术基本概念1.1.1 数控技术产生及发展机械工业是我国国民经济的重要支柱产业，必须改变早期生产过程操作与控制实施主要由人来完成造成的金字塔式管理结构，其中关键问题是如何构建综合自动化系统来实现扁平化管理和综合生产指标优化。

数控技术的应用不但给传统制造业带来了革命性的变化，使制造业成为工业化的象征，而且随着数控技术的不断发展和应用领域的扩大，他对国计民生的一些重要行业（IT、汽车、轻工、医疗等）的发展起着越来越重要的作用，因为这些行业所需装备的数字化已是现代发展的大趋势。

1.1.2 C数控机床及组成数控机床一般由输入输出设备、CNC装置（或称CN C单元）、伺服单元、驱动装置（或称执行机构）、可编程控制器PLC 及电气控制装置、辅助装置、机床本体及测量装置组成。

1）机床本体CNC机床由于切削用量大、连续加工发热量大等因素对加工精度有一定影响，加之在加工中是自动控制，不能像在普通机床上那样由人工进行调整、补偿，所以其设计要求比普通机床更严格，制造要求更精密，采用了许多新的加强刚性、减小热变形、提高精度等方面的措施。

2）CNC装置CNC装置是CNC系统的核心，主要包括微处理器CPU、存储器、局部总线、外围逻辑电路以及与CNC系统的其他组成部分联系的接口等。

数控机床的CNC系统完全由软件处理数字信息，因而具有真正的柔性化，可处理逻辑电路难以处理的复杂信息，使数字控制系统的性能大大提高。

3）输入/输出设备键盘、磁盘机等是数控机床的典型输入设备。

除上述以外，还可以用串行通信的方式输入。

数控系统一般配有CRT显示器或点阵式液晶显示器，显示的信息较丰富，并能显示图形。

操作人员通过显示器获得必要的信息。

4）伺服单元伺服单元是CNC和机床本体的联系环节，它把来自CNC装置的微弱指令信号放大成控制驱动装置的大功率信号。

根据接收指令的不同，伺服单元有脉冲式和模拟式之分，而模拟式伺服单元按电源种类又可分为直流伺服单元和交流伺服单元。

附录附录ANumerical control technology and equipment trend ofdevelopment and countermeasureThe equipment industry technical level and the modernized degree were deciding the entire national economy level and the modernized degree, the numerical control technology and the equipment are the development emerging high technology and new technology industry and the state-of-art industry (for example defense industry industries and so on information technology and industry, biological technology and industry, aviation, astronautics) enables the technology and the most basic equipment. Marx had said “each kind of economical time difference, does not lie in produces any, but how lies in produces, with any means of labor production”. The technique of manufacture and the equipment is the humanity produces active the most basic producer goods, but the numerical control technology also is advanced now the technique of manufacture and the equipment most core technology. Now the various countries manufacturing industry widely uses the numerical control technology, sharpens the manufacturing capacity and the level, enhances to the dynamic changeable market adaptiveness and competitive ability. In addition in the world various industries developed country also lists as the national strategic resources the numerical control technology and the numerical control equipment, not only takes the significant measure to develop own numerical control technology and the industry, moreover implements the blockade and the limit policy in “precise and advanced” the numerical control key technologies and the equipment aspect to our country. In brief, develops vigorously take the numerical control technology has become the world each developed country acceleration economy development as the core advanced technique of manufacture, enhances the comprehensive national strength and the national status important way.The numerical control technology is carries on the control with the numerical information to the mechanical movement and the work process the technology, thenumerical control equipment is take the numerical control technology as representative's new technology the integration of machinery product which forms to the traditional manufacture industry and the emerging manufacturing industry seepage, namely so-called digitized equipment, its technical scope cover very many domains: (1) machine manufacture technology; (2) information processing, processing, transmission technology; (3) automatic control technology; (4) servo actuates the technology; (5) sensor technology; (6) software technology and so on.1 numerical control technology trend of developmentNot only the numerical control technology application has brought the revolutionary change for the traditional manufacturing industry, causes the manufacturing industry to become the industrialization the symbol, moreover along with numerical control technology unceasing development and application domain expansion, he to national economy and the people's livelihood some important professions (IT, automobile, light industry, medical service and so on) development more and more vital role, because these professions must equip the digitization already was the modern development major tendency. The numerical control technology and the equipment development tendency looked from the present world that, its main research hot spot has following several aspect [1~4].1.1 high speed, high precision work technology and equipment new tendencyThe efficiency, the quality are the advanced technique of manufacture main bodies. High speed, the high precision work technology may enhance the efficiency enormously, enhances the product the quality and the scale, reduces the production cycle and sharpens the market competition ability. Lists as one of 5 great modern techniques of manufacture for this Japan Tip Technology Research board it, the international production project learns (CIRP) its determination is one of 21st century central research directions.In the passenger vehicle industry domain, yearly produces 300,000 production metres was 40/s，moreover the multi-variety processing is one of key questions which the passenger vehicle equipment must solve; In the aviation and the astronavigation industry domain, its processing spare part many for the thin wall and the thin muscle, the rigidity is very bad, material for aluminum or aluminum alloy, only then in the high cutting speed and the cutting force very small situation, can to these muscles, the wall carry on the processing. Recently uses the large-scale overall aluminum alloy semifinished mat erials “pull out spatially” the method to make the wing, the fuselage and so on the large-scale componentssubstitutes many components through the multitudinous rivets, the bolt and other joint way assembling, causes the component the intensity, the rigidity and the reliability obtains the enhancement. These all to processed the equipment to propose high speed, Gao Jing and the high flexible request.Unfolds from EMO2001 meets the situation to look that, processes the center feed rate to be possible high speed to reach 80m/min, even higher, the aerial transport stroke speed may reach 100m/About min. At present in the world many automotive factories, including our country's Shanghai General Motors, already used by the high speed processing center composition production line part substitution aggregate machine-tool. American CINCINNATI Corporation's HyperMach engine bed feed rate reaches 60m/most greatlymin, fast is 100m/min, the acceleration reaches 2g, the main axle rotational speed has reached 60 000r/min. Processes a thin wall airplane part, only uses 30min, but the same components need 3h in the common high speed milling machine processing, needs 8h in the plain milling machine processing; The German DMG Corporation's double main axle lathe main axle speed and the acceleration respectively reach 12*! 000r/mm和1g。
