T a bl eo f C on t e n t s ECu 7ENi6617SCu 7Special Metals W elding Products Company is the world’s leading developer andmanufacturer of wrought nickel alloys and nickel based welding consumables forjoining nickel alloys, high performance steels, cast irons and dissimilar metals as well asoverlaying on steel for corrosion or erosion protection. It offers industry the widestrange of welding consumables, supported by over 100 years experience in nickel alloytechnology. Product trademarks such as MONEL, INCO-WELD, NI-ROD, INCONEL,INCOLOY , INCO-CORED, and INCOFLUX have earned worldwide recognition as thestandard for quality and product performance.Special Metals W elding Products Company operates a fully integrated manufacturingfacility that encompasses every step from acquisition of raw materials to packagingof the finished products. This melting-pot-to-weld-puddle control provides completetraceability and control of product quality. Rigorous quality control is applied atevery production step using quality systems such as ISO 9001, ASME Section IIINC3800, and TUV .In support of this comprehensive product line is a tradition of first class techinicalservice and customer support made available through our extensive gobal distributionnetwork. Direct access to additional information is available through our websites and in chinese .Nickel Welding Electrode 141is used for shielded-metal-arc welding of Nickel 200 and Nickel 201, welding the clad side of nickel-clad steel, and surfacing of steel. The reaction of titanium with carbon in the weld metal holds free carbon to a low level so that the electrode can be used with low-carbon nickel (Nickel 201). The weld metal has good corrosion resist-ance, especially in alkalies. The electrode is also used for dissimilar welding, including joints between Nickel 200 or 201 and various iron-base and nickel-base alloys. Nickel W elding Electrode 141 can be operated in all welding positions. Power supply: direct current, electrode Ni Welding Electrode Nickel Welding Electrode 141Diameter Length Current N i c k e l W e l d i n g E l e c t r o d e 141Minimum T ensile Strength, psi 60,000Mechanical MPa 414Properties Elongation, (4d) %20Limiting Ni+Co..............92.0 min.Cu............................0.25 max.Chemical C........................0.10 max.Al................................1.0 position Mn ..................0.75 max.Ti....................................1.0-4.0Fe ....................0.75 max.P ..............................0.03 max.S ......................0.02 max.Others..................0.50 max.Si........................1.25 max.Specifications A WS A5.11, ENi-1UNS W82141ASME II, SFA-5.11, ENi-1 W erkstoff Nr. 2.4156ASME IX, F-No. 41ISO ENi2061DIN 1736 EL-NiTi3Europe ENiTi3VdTÜV 1286.01T ab l e o f C o n t e n t s , C o n t i n u e dM O N E L®W el d i n g E l e c t r o d e 190MONEL Welding Electrode 190is used for shielded-metal-arc welding of MONEL alloys 400, R-405, and K-500. It is also used for surfacing of steel. The weld metal is resistant to corrosion by sea water, salts, and reducing acids. The electrode is capable ofproducing weld deposits that meet stringent radiographic requirements. Although the electrode produces sound joints in MONEL alloy K-500, the weld metal has lower strength since, unlike the base metal, it is not age hardenable. Dissimilar-welding applica-tions for MONEL W elding Electrode 190 include joints between MONEL nickel-copper alloys and carbon steel, low-alloy carbon steel, copper, and copper-nickel alloys.MONEL W elding Electrode 190 can be operated in all positions. Power supply: direct cur-rent, electrode positive.MONEL ®Welding Electrode 190Minimum T ensile Strength, psi 70,000Mechanical MPa 483Properties Elongation, (4d) %30Limiting Ni+Co ............62.0-68.0Cu..........................Remainder Chemical C........................0.15 max.Al............................0.75 position Mn......................4.0 max.Ti..................................1.0 max.Fe........................2.5 max.P ..............................0.02 max.S......................0.015 max.Others..................0.50 max.Si..........................1.0 max.Specifications A WS A5.11, ENiCu-7DIN 1736 EL-NiCu30Mn MIL-E-22200/3 Type MIL-9N10UNS W84190ASME II,SFA-5.11, ENiCu-7W erkstoff Nr. 2.4366ASME IX, F-No. 42ISO ENi4060VdTÜV 2106.00Europe ENiCu30Mn3Ti Diameter Length CurrentMONEL Welding Electrode 187is used for shielded-metal-arc welding of wrought or cast 70/30, 80/20, and 90/10 copper-nickel alloys. Like the base metals with which it is used, the weld metal resists fouling and corrosion in sea water and is useful for many marine and desalination applications. Dissimilar joints welded with the electrode include those between copper-nickel alloys and MONEL alloy 400 or Nickel 200. MONEL W elding Electrode 187 can be operated in all positions. Power supply: direct cur-rent, electrode MONEL ®Welding Electrode 187Diameter Length Current M O N E L ®W e l d i n g E l e c t r o d e 187Minimum T ensile Strength, psi 50,000Mechanical MPa 345Properties Elongation, (4d) %30Limiting Ni+Co..............29.0 min.Si ............................0.50 max.Chemical C ......................0.05 max.Cu..........................Remainder Composition Mn........................1.0-2.50Ti ............................0.50 max.Fe ....................0.40-0.75P ............................0.020 max S......................0.015 max.Others..................0.50 max.Specifications A WS A5.6, ECuNi W erkstoff Nr. 2.0838MIL-E-22200/4 Type MIL-CuNi(70:30)UNS W60715ASME II,SFA-5.6, ECuNi ISO ECu 7158ASME IX, F-No. 34Europe ECu 7158DIN 1733 S-CuNi30Mn Ni-Cu Welding ElectrodeCu-Ni Welding ElectrodeI N C O -W E L D ®A W e l d i n g E l e c t r o de INCO-WELD A Welding Electrode is used for shielded-metal-arc welding of INCOLOYalloys 800 and 800HT, INCONEL alloys 600 and 601, and nickel steels. The weld metal has excellent strength and oxidation resistance at high temperatures and retains impact resistance at cryogenic temperatures. The electrode is an exceptionally versatile product for dissimilar welding. It can be used on a variety of austenitic and ferritic steels and nickel alloys. Examples are combinations of stainless steels, carbon steels, INCONEL alloys, INCOLOY alloys, MONEL alloys, and copper-nickel alloys. Because of its versatility , INCO-WELD A W elding Electrodeis especially useful for general maintenance welding of equipment exposed to strenuous serv-ice conditions.INCO-WELD A W elding Electrode can be operated in all welding positions. Power supply:direct current, electrode positive.INCO-WELD ®A Welding Electrode Minimum T ensile Strength, psi 80,000Mechanical MPa 552Properties Elongation, (4d) %30Limiting Ni+Co..............62.0 min.Cu ..........................0.50 max.Chemical C........................0.10 max.Cr ..............................13.0-17.0Composition Mn ..........................1.0-3.5Nb+T a ........................0.5-3.0Fe ......................12.0 max.Mo ................................0.5-2.5S ......................0.02 max.P ..............................0.03 max.Si......................0.75 max.Others..................0.50 max.Specifications A WS A5.11, ENiCrFe-2W erkstoff Nr. 2.4805ASME II, SFA-5.11, ENiCrFe-2DIN 1736 EL-NiCr15FeNbUNS W86133ISO ENi6092ASME IX, F-No. 43Europe ENiCr16Fe9NbMo VdTÜV 2104.00Diameter Length CurrentINCONEL Welding Electrode 152is used for shielded-metal-arc welding of INCONEL alloy 690. It has a higher chromium content which improves resistance to stress-corrosion cracking in the nuclear, pure water environment. It was designed to produce high quality welds in all positions. This electrode also produces corrosion-resistant overlays on most low-alloy and stainless steels. Other uses include applications requiring INCONEL alloy 690 "glass melters" used for the disposal of nuclear waste. It is also useful for dissimilar joints involving INCONEL and INCOLOY alloys, and stainless, low-alloy and carbon steels.INCONEL W elding Electrode 152 can be operated in all welding positions. Power supply: direct current, electrode INCONEL ®Welding Electrode 152Diameter Length Current I N C O N E L ®W e l d i n g E l e c t r o d e 152Minimum T ensile Strength, psi 80,000Mechanical MPa 552Properties Elongation, (4d) %30Limiting Ni+Co ..........Remainder Cu ..........................0.50 max.Chemical C ......................0.05 max.Cr..............................28.0-31.5Composition Mn......................5.0 max.Ti ............................0.50 max.Fe ........................7.0-12.0Al............................0.50 max.S......................0.015 max.P ..............................0.03 max.Si......................0.75 max.Nb+T a..........................1.0-2.5Mo....................0.50 max.Others..................0.50 max.Specifications AMSE Boiler & Pressure V essel Code Case 2143A WS A5.11, ENiCrFe-7UNS W86152ASME II, SFA-5.11, ENiCrFe-7 ISO ENi 6152ASME IX, F-No. 43Europe ENiCr30Fe9NbI N C O NE L ®W e l d i n g E l e c t r o d e 182INCONEL Welding Electrode 182is used for shielded-metal-arc welding of INCONELalloys 600, 601 and 690. The weld metal has excellent high-temperature strength and oxida-tion resistance and can meet stringent radiographic requirements.Dissimilar welds for which the electrode are used include INCONEL alloys and INCOLOY alloys joined to carbon steels, stainless steels, nickel and MONEL alloys, MONEL alloys joined to carbon steels; nickel joined to stainless steels; and stainless steels joined to carbon steels.INCONEL W elding Electrode 182 can be operated in all welding positions. Power supply: direct current, electrode positive.INCONEL ®Welding Electrode 182Minimum T ensile Strength, psi 80,000Mechanical MPa 552Properties Elongation, (4d) %30Limiting Ni a ......................59.0 min.Cu ..........................0.50 max.Chemical C........................0.10 max.Cr ..............................13.0-17.0Composition Mn ........................5.0-9.5Ti..................................1.0 max.Fe......................10.0 max.Nb b ..................................1.0-2.5S......................0.015 max.P............................0.030 max.Si..........................1.0 max.Others..................0.50 max.a Plus Co. Co 0.12 max. when specifiedb Plus T a. T a 0.30 max. when specifiedSpecifications A WS A5.11, ENiCrFe-3DIN 1736 EL-NiCr15FeMn ASME II, SFA-5.11, ENiCrFe-3 W erskoff Nr. 2.4807ASME IX, F-No. 43ISO ENi6182UNS W86182Europe ENiCr15Fe6Mn VdTÜV 2105.00MIL-E-22200/3 Types MIL-8N12, MIL-8N12H Diameter Length Current INCONEL ®Welding Electrode 112 I N C O N E L ®W e l d i n g E l e c t r o d e 112INCONEL Welding Electrode 112is used for shielded-metal-arc welding of INCONEL alloy 625, INCOLOY alloy 825, INCOLOY alloy 25-6MO, and other molybdenum-containing stainless steels. It is also used for surfacing of steel and for welding various corrosion- resist-ant alloys such as alloy 20. The weld metal has high strength at room and elevated tempera-tures and has exceptional corrosion resistance, including resistance to pitting, crevice corro-sion, and polythionic acid stress-corrosion cracking. INCONEL W elding Electrode 112 is useful for many dissimilar joints involving INCONEL alloys, INCOLOY alloys, stainless steels, low-alloy steels, and carbon steels.INCONEL W elding Electrode 112 can be operated in all welding positions. Power supply: direct current, electrode positive.Minimum T ensile Strength, psi 110,000Mechanical MPa 758Properties Elongation, (4d) %30Limiting Ni+Co ............55.0 min.Si ............................0.75 max.Chemical C ......................0.10 max.Cr ..........................20.0-23.0Composition Mn........................1.0 max.Nb+T a ....................3.15-4.15Fe........................7.0 max.Mo ............................8.0-10.0S ......................0.02 max.P ............................0.03 max.Cu ..................0.50 max.Others ................0.50 max.Specifications A WS A5.11, ENiCrMo-3DIN 1736 EL-NiCr20Mo9Nb ASME II, SFA-5.11, ENiCrMo-3W erkstoff Nr. 2.4621ASME IX, F-No. 43ISO ENi6625MIL-E-22200/3 Type MIL-IN12Europe ENiCr22Mo9Nb UNS W86112Diameter Length CurrentI N C O N EL ®W e l d i n g E l e c t r o d e 122INCONEL Welding Electrode 122is used for shielded-metal-arc welding of INCONELalloys 622 and 625, INCOLOY alloy 25-6MO, and INCOLOY alloy 825. This is an excellent dissimilar metal welding electrode that offers protection against preferential weld metal cor-rosion when used for joining molybdenum-containing stainless steels, INCONEL alloy C-276,and INCONEL alloy 625. It is a versatile welding product for the chemical, power, petroleum,and marine industries.INCONEL W elding Electrode 122 can be operated in all positions. Power supply: direct current,electrode positive.INCONEL ®Welding Electrode 122Minimum T ensile Strength, psi 100,000Mechanical MPa 690Properties Elongation, (4d) %25Limiting Ni ..................Remainder Cu ..........................0.50 max.Chemical C ....................0.02 max.Co ............................2.5 position Mn........................1.0 max.Cr ..........................20.0-22.5Fe ..........................2.0-6.0Mo ............................12.5-14.5P ......................0.03 max.V ..............................0.35 max.S......................0.015 max.W..................................2.5-3.5Si ....................0.20 max.Others ................0.50 max.Specifications A WS A5.11, ENiCrMo-10ISO ENi6022ASME II, SFA-5.11, ENiCrMo-10Europe ENiCr21Mo13W3UNS W86022ASME IX, F-No. 43Diameter Length CurrentDiameter Length Current INCO-WELD C-276Welding Electrode is used for shielded-metal-arc welding of INCONEL alloy C-276 and other nickel-chromium-molybdenum alloys. It is also used for sur-facing of steel. The weld metal has excellent corrosion resistance in many media and is espe-cially resistant to pitting and crevice corrosion. INCO-WELD C-276 W elding Electrode is use-ful for various dissimilar joints involving nickel alloys, stainless steels, and low-alloy steels.INCO-WELD C-276 W elding Electrode can be operated in all welding positions. Power sup-ply: direct current, electrode INCO-WELD ®C-276 Welding Electrode I N C O -W E L D ®C -276 W e l d i n g E l e c t r o d e Ni-Cr-Mo Welding ElectrodeNi-Cr-Mo Welding ElectrodeI N C O -W E L D ®686C P T ®E l e c t r o de INCO-WELD 686CPT Welding Electrode is an all-position shielded-metal-arc welding electrode used to join duplex, super-duplex and super-austenitic stainless steels, as well asnickel alloys such as UNS N06059 and N06022, INCONEL alloy C-276, and INCONEL alloys 622, 625 and 686. INCO-WELD 686CPT W elding Electrode offers a level of corrosion-resist-ance attractive for welding operations in pollution control engineering as well as the chemi-cal, process, petrochemical, oil and gas, and marine industries.INCO-WELD 686CPT W elding Electrode can be operated in all welding positions. Power sup-ply: direct current, electrode positive.INCO-WELD ®686CPT ®Welding ElectrodeTypical T ensile Strength, psi 110,000Mechanical MPa 758Properties Elongation, (4d) %35Hardness. HRB 95Limiting Nickel ..........Remainder Si ............................0.25 max.Chemical C ....................0.02 max.Ti ............................0.25 max.Composition Mn........................1.0 max.Cr ............................19.0-23.0Fe........................5.0 max.Mo ..........................15.0-17.0P ......................0.02 max.W..................................3.0-4.4Cu....................0.50 max.Others ................0.50 max.Specifications A WS A5.11, ENiCrMo-14UNS W86026ASME II, SFA-5.11, ENiCrMo-14 ISO ENi6686ASME IX, F-No. 43Europe NiCr21Mo16W4Diameter Length CurrentDiameter Length Current INCONEL Welding Electrode 117is used for shielded-metal-arc welding of INCONEL alloy 617. The weld metal has high strength, good metallurgical stability and excellent resist-ance to corrosion and high-temperature oxidation. INCONEL W elding Electrode 117 also gives good results in welding many dissimilar materials, especially for high-temperature applica-tions. Examples are INCONEL alloys 600 and 601, INCOLOY alloys 800HT and 802, and cast alloys such as HK-40, HP and HP-45 Modified.INCONEL W elding Electrode 117 can be operated in all welding positions. Power supply: direct current, electrode INCONEL ®Welding Electrode 117I N C O N E L ®W e l d i n g E l e c t r o d e 117Ni-Cr-Mo Welding ElectrodeNi-Cr-Co-Mo Welding ElectrodeIN C O -W E L D ®CW e l d i n g E l e c t r o de INCO-WELD ®C Welding ElectrodeDiameterLength Current NI-ROD Welding Electrode is used for shielded-metal-arc welding of gray , ductile, and mal-leable cast irons. It is also used for joints between cast irons and carbon steel or low-alloy steel.The electrode is particularly useful for thin sections and for joints to be machined.NI-ROD W elding Electrode can be operated in all welding positions. Power supply: direct current,electrode positive is preferred although alternating current can be NI-ROD ®Welding Electrode N I -R O D ®W e l d i n g E l e c t r o d e INCO-WELD C Welding Electrode is a stainless-alloy electrode especially designed for shielded-metal-arc welding of a broad range of materials, including many difficult-to-weld compositions. It can be used on stainless steels, mild and medium-carbon steels, and springsteels. The weld metal can accept a wide range of dilution; its high ferrite content provides exceptional cracking resistance. W eld deposits have high tensile and impact strength along with good resistance to heat and corrosion. The electrode's characteristics make it outstand-ing for general-purpose maintenance welding of machinery and process equipment. The weld metal is also a good buffer or padding for hard-facing alloys.INCO-WELD C W elding Electrode can be operated in all welding positions. Power supply:direct current, electrode positive is preferred although alternating current can be used.Typical T ensile Strength, psi 110,000 - 120,000Mechanical MPa 758 - 827Properties Elongation, (4d) %24 - 30Specifications UNS W31310Diameter Length Current Ni-Fe-CrWelding Electrode Cast Iron Nickel Welding ElectrodeN I -R O D ®99X W e l d i n g E l e c t r o de NI-ROD ®99X Welding ElectrodeTypical T ensile Strength, psi 57,000-84,000Mechanical MPa 393-579Properties Elongation, (4d) %6-13Typical Ni+Co........................53.0S......................................0.005Chemical C....................................1.20Si ......................................0.70Composition Mn..............................0.30Cu........................................0.10Fe................................45.0Limiting Ni ......................85.0 min.S..............................0.03 max.Chemical C ........................2.0 max.Si ..............................2.0 max.Composition Mn......................2.5 max.Cu ............................2.5 max.Fe........................8.0 max.Specifications A WS A5.15, ENiFe-CI ISO E C NiFe-CI ASME II, SFA-5.15, ENiFe-CI Europe E C NiFe-CI UNS W82002NI-ROD 55 Welding Electrode is used for shielded-metal-arc welding of gray , ductile,malleable, and Ni-Resist cast irons. It is also used for welding cast irons to various wrought materials, including carbon steels, low-alloy steels, and nickel alloys. The electrode is espe-cially useful for welding heavy sections and high-phosphorus irons.NI-ROD 55 W elding Electrode can be operated in all welding positions. Power supply: direct current, electrode positive is preferred although alternating current can be NI-ROD ®55 Welding Electrode N I -R O D ®55 W e l d i n g E l e c t r o d e NI-ROD 99X Welding Electrode is a premium quality consumable for cast iron, offering trueout-of-position welding capability with an ease of operation rivalling carbon steel electrodes.99X Electrode has a commercially pure nickel core, and is recommended for welding thin cast iron sections and for where optimum machinability of single-pass or single-layer weldments is required.NI-ROD 99X W elding Electrode is used for joining gray iron, ductile iron, compacted graphite iron, malleable iron and various alloyed irons to themselves, to each other, to steels, to stainless steels, and to nickel alloys.NI-ROD 99X W elding Electrode can be operated in all welding postions. Power supply: direct cur-rent, electrode positive is preferred although alterating current can be used.Typical T ensile Strength, psi 55,000Mechanical MPa 378Properties Elongation, (4d) %8Specifications NoneDiameter Length Current Diameter Length Current Cast Iron NickelWelding Electrode Cast Iron Nickel Iron Welding ElectrodeN I -R O D ®55X W e l d i n g E l e c t r o deNI-ROD ®55X Welding ElectrodeStraight Lengths - 915 mm (36”) or 1000 mm (39”)Limiting Ni ............................45-60S ............................0.30 max.Chemical C ........................2.0 max.Si ..............................2.0 positionMn ....................2.5 max.Cu..............................2.5 max.Fe....................Remainder mm inNickel Filler Metal 61is used for gas-tungsten-arc, gas-metal-arc, and submerged-arc welding of Nickel 200 and 201. It is also used for surfacing of steel. INCOFLUX 6 Submerged Arc Flux is used with the submerged-arc process. The reaction of titanium with carbon main-tains a low level of free carbon and enables the filler metal to be used with Nickel 201. The weld metal has good corrosion resistance, particularly in alkalies.Dissimilar-welding applications for Nickel Filler Metal 61 include joining Nickel 200 and 201 to stainless steels, carbon steels, INCONEL alloys, INCOLOY alloys, copper-nickel alloys, and MONEL alloys. It is also used for joining MONEL alloys and copper-nickel alloys to carbon steels, and for joining copper-nickel alloys to INCONEL and INCOLOY Nickel Filler Metal 61N i c k e l F i l l e r M e t a l 61NI-ROD 55X Welding Electrode is a premium quality consumable for cast iron, offering true out-of-position welding capability with an ease of operation rivalling carbon steel elec-trodes. NI-ROD 55X Electrode has a nickel-iron core wire to produce strong welds with low residual shrinkage stresses, and is well suited for welding thick sections. It has high tolerance for phosphorus and other contaminants in the base metal, so high strength, good ductile welds can be made in low-grade cast irons.NI-ROD 55X W elding Electrode is used for joining gray iron, ductile iron, compacted graphite iron, malleable iron and various alloyed irons to themselves, to each other, to steels, to stain-less steels, and to nickel alloys.NI-ROD 55X W elding Electrode can be operated in all welding positions. Power supply: direct current, electrode positive is preferred although alternating current can be used.TypicalT ensile Strength, psi 75,000Mechanical MPa517Properties Elongation, (4d) %22Specifications NoneDiameter Length CurrentCast Iron Ni-Fe Welding ElectrodeNi Filler MetalsM O N E L ®F i l l e r M e t a l 6MONEL ®Filler Metal 60Straight Lengths - 915 mm (36”) or 1000 mm (39”)mm inMONEL Filler Metal 67is used for oxyacetylene, gas-tungsten-arc, gas-metal-arc, and submerged-arc welding of MONEL alloy 450 (70/30 Copper-Nickel) and other copper-nick-el alloys. It is used for surfacing of steel if a barrier layer of Nickel Filler Metal 61 is first applied. If applied by the submerged-arc process, MONEL Filler Metal 60 can be used for the barrier layer. Submerged-arc welding with MONEL Filler Metal 67 is done with INCOFLUX 8Submerged Arc Flux.The copper-nickel weld metal has excellent resistance to corrosion in sea water, and is wide-ly used for marine and desalination applications.Dissimilar-welding applications for MONEL Filler Metal 67 are joints between MONEL alloys or Nickel 200 and copper-nickel MONEL ®Filler Metal 67M O N E L ®F i l l e r M e t a l 67Straight Lengths - 915 mm (36”) or 1000 mm (39”)mm inMONEL Filler Metal 60is used for gas-tungsten-arc, gas-metal-arc, and submerged-arc welding of MONEL alloys 400, R404, and K-500. It is also used for surfacing of steel by the gas-metal-arc or submerged-arc processes. For certain gas-metal-arc conditions, a barrier layer of Nickel Filler Metal 61 is recommended. Submerged-arc welding with MONEL Filler Metal 60 is done with INCOFLUX 5 Submerged Arc Flux.W eld metal deposited by MONEL Filler Metal 60 has properties similar to those of MONEL alloy 400. It has good strength and resists corrosion in many media, including sea water, salts,and reducing acids. The weld metal is not age hardenable and when used to join MONEL alloy K-500 has lower strength than the base metal.Ni-Cu Filler MetalCu-Ni Filler MetalsI N C O N E L ®F i l l e r M e t a l 72INCONEL ®Filler Metal 72Straight Lengths - 915 mm (36”) or 1000 mm (39”)mminNC 80/20 Filler Metal Wire is a Nickel Chromium material used for the inert gas weld-ing of INCONEL alloy 600, NIMONIC 75, INCOLOY alloys 800 and DS, and the Brightray alloys to themselves and to each other. The shielding gas should be Argon, Helium, or a mix-ture of the two. It may also be used in many dissimilar metal applications, especially where carbon steels are joined to stainless steels and to Nickel-based alloys. W eld overlaying of car-bon and low alloy steels is another popular application.NC 80/20 Filler MetalN C 80/20 F i l l e r M e t a lMinimum T ensile Strength, psi 106,000Mechanical MPa731PropertiesYield Strength (0.2% offset), psi 72,000MPa496Elongation, (4d) %30Limiting Ni....................................55S ....................................0.008ChemicalCr....................................44Si ..........................................0.1Composition (%)Ti ....................................0.6Ci ........................................0.2Mn ..................................0.1Fe ..................................0.2SpecificationsA WS A5.14, ERNiCr-4ASME IX, F-No. 43ASME II, SFA-5.14, ERNiCr-4ISO SNi6072Europe NiCr44Ti UNS N06072INCONEL Filler Metal 72is used for the gas-tungsten-arc welding of INCONEL alloy 671cladding on INCO-CLAD ®671/800HT Clad Tubing. INCONEL Filler Metal 72 is also used for the overlaying of carbon steels and stainless steels to provide a nickel-chromium alloy corro-sion resistant surface. The high chromium level provides excellent resistance to high tempera-ture corrosion, including fuel-ash atmospheres containing sulfur and vanadium.Ni-Cr Filler MetalsNi-Cr Filler MetalsI N C O N E L ®F i l l e r M e t a l 82INCONEL ®Filler Metal 82Minimum T ensile Strength, psi 80,000Mechanical MPa552Properties Elongation, (4d) %30Typical Ni....................................72C ........................................0.04ChemicalCr......................................19Ti ........................................0.25Composition (%)Mn ....................................3S........................................<0.01Nb..................................2.5Si ..........................................0.3Fe ..................................2.5P........................................<0.01Al................................0.05Others..............................<0.5Cu................................0.05SpecificationsThe products have been proposed to A WS and are expected to be listed in A WS A5.34 as ERNiCr3T0-4 and ENiCr3T1-4. Other specifications will follow.INCO-CORED FC82DH and FC82AP Flux Cored Wires are identical in chemistry and properties to the bare wire INCONEL Filler Metal 82. They have excellent weldability , and benefit from the higher deposition rates associated with flux-cored wires. Both use a shield-ing gas of 75% Argon and 25% Carbon Dioxide.The products are used to weld INCONEL alloys 600 and 601, INCOLOY alloys 800 and 800HT, and INCO alloy 330. They are also used in many dissimilar metal applications, espe-cially where carbon steels are joined to stainless steels and to nickel-based alloys. W eld over-laying of carbon and low alloy steels is another popular application for INCO-CORED 82DH and 82AP Flux Cored Wire.Power supply: direct current, electrode INCO-CORED FC82DH & FC82AP Flux Cored WireI N C O -C O R E D ®F C 82D H & F C 82A P F l u x C o r e d W i r eMinimum T ensile Strength, psi 80,000Mechanical MPa552Properties Elongation, (4d) %30Limiting Ni a......................67.0 min.Si ............................0.50 max.ChemicalC........................0.10 max.Cr..............................18.0-22.0Composition (%)Mn ........................2.5-3.5Ti ............................0.75 max.Fe........................3.0 max.Nb b..............................2.0-3.0S......................0.015 max.P............................0.030 max.Cu....................0.50 max.Others..................0.50 max.a Plus Co. Co 0.12 max. when specified.bPlus T a. T a 0.30 max. when specified.SpecificationsA WS A5.14, ERNiCr-3VdTÜV 2117.00; 2118.00,ASME II, SFA-5.14, ERNiCr-32110-00; 2111.00MIL-E-21562DIN 1736 SG-NiCr20Nb Types MIL-RN82, MIL-EN82, W erkstoff Nr. 2.4806MIL-RN82H, MIL-EN82H UNS N06082ASME IX, F-No. 43ISO SNi6082BS 2901 (NA35)Europe NiCr20Mn3Nb INCONEL Filler Metal 82is used for gas-tungsten-arc, gas-metal-arc and submerged-arc weld-ing of INCONEL alloys 600, 601 and 690, INCOLOY alloys 800 and 800HT, and INCOLOY alloy 330. It is also used for surfacing of steel. Submerged-arc welding is done with INCOFLUX 4Submerged Arc Flux. For submerged-arc surfacing INCOFLUX 6 Submerged Arc Flux can be used to a maximum of three layers.W eld metal deposited by INCONEL Filler Metal 82 has high strength and good corrosion resist-ance, including oxidation resistance and creep-rupture strength at elevated temperatures.Dissimilar-welding applications include joining INCONEL alloys, INCOLOY alloys and INCOLOY alloy 330 to nickel, MONEL alloys, stainless steels, and carbon steels. It is also used to join stain-less steels to nickel alloys and carbon steels.Filler metals available on spool and in cut straight lengths in a variety of sizes selected from the following diameters:Straight Lengths - 915 mm (36”) or 1000 mm (39”)mm inNi-Cr Filler MetalsNi-Cr Filler Metals。
