Medium-Voltage Matrix Converter Design Using Cascaded Single-Phase Power Cell Modules
- 格式:pdf
- 大小:935.32 KB
- 文档页数:7
2007年 3 月电工技术学报Vol.22 No.3 第22卷第3期TRANSACTIONS OF CHINA ELECTROTECHNICAL SOCIETY Mar. 2007矩阵变换器−永磁同步电机矢量控制系统的新型电流控制方法葛红娟周波苏国庆张绍(南京航空航天大学自动化学院南京 210016)摘要分析了基于电流滞环控制的矩阵变换器−永磁同步电机(MC-PMSM)系统的开关组合状态和存在的缺点:系统侧电流存在较大的5次和7次谐波分量。
提出了一种改进电流控制方法,该方法采用电机电流双环控制,得出三相电机电流的6个电流控制信号,并将输入三相电压分成12个相区,根据电流控制信号和相区号的不同,选择不同的输入相与输出相连接,确定出矩阵变换器开关组合状态。
在该方法中,每个输入相在整个周期内都参与调制,降低了系统输入电流的谐波分量,提高了系统输入电流的正弦度。
关键词:矩阵变换器永磁同步电机谐波分量电流双环控制矢量控制中图分类号:TM301Novel Current Modulation Approach for the Vector Control ofMC-PMSM SystemGe Hongjuan Zhou Bo Su Guoqing Zhang Shao(Nanjing University of Aeronautics and Astronautics Nanjing 210016 China)Abstract An improved current hysteresis-loop modulation approach for the vector control of matrix converter-permanent magnet synchronous motor (MC-PMSM) system is presented in this paper.With the approach, the three-phase input voltages are divided into twelve sections and three pairs of current control signals are deduced by comparing the reference values and the measured values of the output currents based on double current loops. Then, the states of the switches in the MC-PMSM system are determined according to the section number of the input voltages and one of the three pairs of current control signals, so that the modulation of every input voltage phase hold in the whole periods.Hence the 5th harmonic, the 7th harmonic, and the total harmonic distortion (THD) of the input currents, which are relative large when the based current hysteresis-loop modulation method is adopted in the system, are obviously reduced and the input currents of the system become more sinusoidal.Keywords:Matrix converter, permanent magnet synchronous motor, harmonic components, double current loop modulation, vector control1引言矩阵变换器可以实现输入电流和输出电压波形的正弦化,输入功率因数可调,没有大体积的直流环节,因此,在交流传动系统中蕴藏着良好的应用前景。
