光电子课件lesson_7

4/1/2004
Q.J.Zhang
25
+ laser Ar
structure
4/1/2004
Q.J.Zhang
26
Working chatacteristic
Threshold current, 488nm and 514.5nm (lowest) Drive current
4/1/2004
4/1/2004
Q.J.Zhang 28
Absorption and emission spectra of Rhodamine 6G
4/1/2004
Q.J.Zhang
29
Energy level
4/1/2004
Q.J.Zhang
30
Absorption and emission process
4/1/2004
Q.J.Zhang 2

Gas lasers classification
Neutral-atom gas lasers He-Ne laser Cu atom vapor laser Ion gas lasers + Argon (Ar ) ion laser Molecular gas lasers Carbon dioxide (CO2) laser Nitrogen (N2) gas laser Excimer laser
Q.J.Zhang
27
Liquid lasers
Classification organic dye laser Inorganic liquid laser Advantage wide variety of wavelength (from 340nm to 1.2μm) Narrow spectrum line-width (10~50MHz) ultrashort pulse laser (femto second, 10-15s) Sing pulse energy 10J 8 Peak power 10 W applications: Biomedical, chemical Isotopic separation
4/1/2004
Q.J.Zhang
3
Exciting mode
Optical pumping Electron impact excitation Thermal excitation Chemical energy excitation
4/1/2004
Q.J.Zhang
4
Electron impact excitation
Q.J.Zhang
16
Working parameters
Mixture gas ratio CO2:N2:He:Xe:H2=1:1.5:8:0.3:0.05 Working pressure: Pd=4400 (Pa· mm) Current: 20mA Voltage: 20kV small-signal gain: G=(0.012~0.0025)d (cm) Saturation gain: Is=72/d2 (W/cm2) Output power: P=14.4 π(I0/ Is)
4/1/2004
Q.J.Zhang
8
Melles Griot company
4/1/2004
Q.J.Zhang
9
Energy level diagram
4/1/2004
Q.J.Zhang
10
The plasma tube
4/1/2004
Q.J.Zhang
11
Working parameters
4/1/2004
Q.J.Zhang
23
Energy level diagram
4/1/2004
Q.J.Zhang
24
Lambda photometrics company
•528.7nm to 476.2nm wavelengths •Up to 7 Watts output power •SHG version giving 200mW @ 257nm •Low noise and excellent beam quality •Multiline mirror holder for all lines operation
Г=R/L
4/1/2004
Q.J.Zhang
12
Carbon dioxide (CO2) laser
Developed in 1965 by Bell Lab Most powerful , most efficient Power: 4000 W in 1967, now 2 × 104W (CW), 1012W (pulse) Energy transfer efficiency: 20%~25% Wavelength: 10.6μm. Applications: cut, weld, scribe, engrave, mark distance test, medical, biology
4/1/2004
Q.J.Zhang
1
Gas lasers
Active medium: gas or vapor Wavelength: from ultraviolet to infrared Excellent beam quality, better than solid-state laser Advantages High output power High transfer efficiency Structure simple Low cost Applications Industry, manufacture Biology, medicine Agriculture
4/1/2004
Q.J.Zhang
13
Vibration modes of CO2 molecule
4/1/2004
Q.J.Zhang
14
Energy level of CO2 molecule
4/1/2004
Q.J.Zhang
15
Essential feature of CO2 laser
4/1/2004
Laser classifications
Active mediums: solid gas liquid semiconductor Wavelength Output time characteristics: mode-locked pulse Q-switched pulse normal-mode pulse continous wave(CW)
4/1/2004
Q.J.Zhang
5
Optical pumping
Definition Normal construction
4/1/2004
Q.J.Zhang
6
Optical pumping
4/1/2004
Q.J.Zhang
7
He-Ne laser
First CW laser, first gas laser Wavelength: visible light, near infrared, 632.8nm
Characteristic: good beam quality, low cost, small size, long operating life, convection cooled, easy power services Volume applications: collimation, test, guidance, accuracy measure, holographical, biology
Definition Two electron impact Process Resonance energy transfer A*+B→A+ B*±∆ E (He-Ne, CO2 laser) Charge transfer A++B→A+ (B+)*±∆ E Penning ionization A * +B→A+ (B+)*±e (slow) (metal vapor laser) Electron collision A+e (fast)→ A*+ e (slow) (N2, Ar+ laser)
Q.J.Zhang
20
Potential energy curves
4/1/2004
Q.J.Zhang
21
Excimer lasers structure
4/1/2004
Q.J.Zhang
22
Argon ion laser
Highest output power in visiual laser, hundrieds W Wavelength: 488.8nm, 514.5nm Applications DNA sequencing Flow cytometry Semiconductor inspection and repair Hematology High speed printing Photo processing
4/1/2004
Q.J.Zhang
17
Coherent company
4/1/2004
Q.J.Zhang
18
Excimer lasers
Virtus: highly efficiency, featuring compact design, easy installation and operation. Wavelength: from ultraviolet visible light Applications Refractive Surgery Dye Laser Pumping Material Processing and Analysis for Physics, Chemistry Micromachining Marking
