EDS-518E Series14+4G-port Gigabit managed EthernetswitchesFeatures and Benefits•4Gigabit plus14fast Ethernet ports for copper and fiber•Turbo Ring and Turbo Chain(recovery time<20ms@250switches),1RSTP/ STP,and MSTP for network redundancy•RADIUS,TACACS+,MAB Authentication,SNMPv3,IEEE802.1X,MAC ACL, HTTPS,SSH,and sticky MAC-addresses to enhance network security •Security features based on IEC62443•EtherNet/IP,PROFINET,and Modbus TCP protocols supported for device management and monitoring•Fiber Check™—comprehensive fiber status monitoring and warning on MST/ MSC/SSC/SFP fiber ports•Supports MXstudio for easy,visualized industrial network management•V-ON™ensures millisecond-level multicast data and video network recoveryCertificationsIntroductionThe EDS-518E standalone,compact18-port managed Ethernet switches have4combo Gigabit ports with built-in RJ45or SFP slots for Gigabit fiber-optic communication.The14fast Ethernet ports have a variety of copper and fiber port combinations that give the EDS-518E Series greater flexibility for designing your network and application.The Ethernet redundancy technologies Turbo Ring,Turbo Chain,RSTP/STP,and MSTP increase the system reliability and availability of your network backbone.The EDS-518E also supports advanced management and security features.In addition,the EDS-518E Series is designed specifically for harsh industrial environments with limited installation space and high protection level requirements,such as maritime,rail wayside,oil and gas,factory automation,and process automation.Additional Features and Benefits•DHCP Option82for IP address assignment with different policies•Supports EtherNet/IP,PROFINET,and Modbus TCP protocols fordevice management and monitoring•IGMP snooping and GMRP for filtering multicast traffic•Port-based VLAN,IEEE802.1Q VLAN,and GVRP to ease networkplanning•QoS(IEEE802.1p/1Q and TOS/DiffServ)to increase determinism•Port Trunking for optimum bandwidth utilization•Port mirroring for online debugging•Automatic warning by exception through email and relay output•SNMPv1/v2c/v3for different levels of network management•RMON for proactive and efficient network monitoring•Fiber Check™provides a comprehensive fiber Digital DiagnosticMonitoring(DDM)function and event warning on MST/MSC/SSC/SFPfiber ports•Bandwidth management to prevent unpredictable network status•Lock port function for blocking unauthorized access based on MACaddress•Supports the ABC-02-USB(Automatic Backup Configurator)forsystem configuration backup/restore and firmware upgrade SpecificationsInput/Output InterfaceAlarm Contact Channels1,Relay output with current carrying capacity of1A@24VDCButtons Reset buttonDigital Input Channels1Digital Inputs+13to+30V for state1-30to+3V for state0Max.input current:8mA1.Gigabit Ethernet recovery time<50msEthernet Interface10/100BaseT(X)Ports(RJ45connector)EDS-518E-4GTXSFP:14EDS-518E-MM-SC-4GTXSFP/MM-ST-4GTXSFP/SS-SC-4GTXSFP:12All models support:Auto negotiation speedFull/Half duplex modeAuto MDI/MDI-X connectionCombo Ports(10/100/1000BaseT(X)or100/1000BaseSFP+)410/100/1000BaseT(X)Ports(RJ45connector)Auto negotiation speedFull/Half duplex modeAuto MDI/MDI-X connection100BaseFX Ports(multi-mode SC connector)EDS-518E-MM-SC-4GTXSFP Series:2100BaseFX Ports(multi-mode ST connector)EDS-518E-MM-ST-4GTXSFP Series:2100BaseFX Ports(single-mode SC connector)EDS-518E-SS-SC-4GTXSFP Series:2Optical Fiber800Typical Distance4km5km40kmWavelength Typical(nm)13001310TX Range(nm)1260to13601280to1340 RX Range(nm)1100to16001100to1600Optical Power TX Range(dBm)-10to-200to-5 RX Range(dBm)-3to-32-3to-34 Link Budget(dB)1229 Dispersion Penalty(dB)31Note:When connecting a single-mode fiber transceiver,we recommend using anattenuator to prevent damage caused by excessive optical power.Note:Compute the“typical distance”of a specific fiber transceiver as follows:Linkbudget(dB)>dispersion penalty(dB)+total link loss(dB).Standards IEEE802.3for10BaseTIEEE802.3u for100BaseT(X)and100BaseFXIEEE802.3ab for1000BaseT(X)IEEE802.3z for1000BaseSX/LX/LHX/ZXIEEE802.3x for flow controlIEEE802.1D-2004for Spanning Tree ProtocolIEEE802.1w for Rapid Spanning Tree ProtocolIEEE802.1s for Multiple Spanning Tree ProtocolIEEE802.1p for Class of ServiceIEEE802.1Q for VLAN TaggingIEEE802.1X for authenticationIEEE802.3ad for Port Trunk with LACPEthernet Software FeaturesFilter802.1Q VLAN,Port-based VLAN,GVRP,IGMP v1/v2/v3,GMRPIndustrial Protocols EtherNet/IP,Modbus TCP,PROFINET IO Device(Slave)Management LLDP,Back Pressure Flow Control,BOOTP,Port Mirror,DHCP Option66/67/82,DHCPServer/Client,Fiber check,Flow control,IPv4/IPv6,RARP,RMON,SMTP,SNMP Inform,SNMPv1/v2c/v3,Syslog,Telnet,TFTPMIB Ethernet-like MIB,MIB-II,Bridge MIB,P-BRIDGE MIB,Q-BRIDGE MIB,RMON MIBGroups1,2,3,9,RSTP MIBRedundancy Protocols Link Aggregation,MSTP,RSTP,STP,Turbo Chain,Turbo Ring v1/v2Security Broadcast storm protection,HTTPS/SSL,TACACS+,SNMPv3,MAB authentication,Sticky MAC,NTP authentication,MAC ACL,Port Lock,RADIUS,SSH,SMTP with TLS Time Management NTP Server/Client,SNTPSwitch PropertiesIGMP Groups2048MAC Table Size16KMax.No.of VLANs64Packet Buffer Size1MbitsPriority Queues4VLAN ID Range VID1to4094USB InterfaceStorage Port USB Type ALED InterfaceLED Indicators PWR1,PWR2,STATE,FAULT,10/100M(TP port),100M(fiber port),Gigabit combo port,MSTR/HEAD,CPLR/TAILSerial InterfaceConsole Port USB-serial console(Type B connector)DIP Switch ConfigurationDIP Switches Turbo Ring,Master,Coupler,ReservePower ParametersConnection2removable4-contact terminal block(s)Input Current EDS-518E-4GTXSFP Series:0.37A@24VDCEDS-518E-MM-SC-4GTXSFP/MM-ST-4GTXSFP/SS-SC-4GTXSFP:0.41A@24VDC Input Voltage12/24/48/-48VDC,Redundant dual inputsOperating Voltage9.6to60VDCOverload Current Protection SupportedReverse Polarity Protection SupportedPhysical CharacteristicsHousing MetalIP Rating IP30Dimensions94x135x137mm(3.7x5.31x5.39in)Weight1518g(3.35lb)Installation DIN-rail mounting,Wall mounting(with optional kit) Environmental LimitsOperating Temperature Standard Models:-10to60°C(14to140°F)Wide Temp.Models:-40to75°C(-40to167°F) Storage Temperature(package included)-40to85°C(-40to185°F)Ambient Relative Humidity5to95%(non-condensing)Standards and CertificationsSafety UL508,EN60950-1(LVD)EMC EN61000-6-2/-6-4EMI CISPR32,FCC Part15B Class AEMS IEC61000-4-2ESD:Contact:8kV;Air:15kVIEC61000-4-3RS:80MHz to1GHz:10V/mIEC61000-4-4EFT:Power:4kV;Signal:4kVIEC61000-4-5Surge:Power:4kV;Signal:4kVIEC61000-4-6CS:10VIEC61000-4-8PFMFHazardous Locations ATEX,Class I Division2Maritime DNV-GL,LR,ABS,NKPower Substation IEC61850-3,IEEE1613Railway EN50121-4Traffic Control NEMA TS2Shock IEC60068-2-27Freefall IEC60068-2-32Vibration IEC60068-2-6MTBFTime723,953hrsStandards Telcordia(Bellcore),GBWarrantyWarranty Period5yearsDetails See /warrantyPackage ContentsDevice1x EDS-518E Series switchCable1x USB type A male to USB type B male Installation Kit4x cap,plastic,for RJ45port4x cap,plastic,for SFP slotDocumentation1x quick installation guide1x warranty card1x product certificates of quality inspection,Simplified Chinese1x product notice,Simplified ChineseNote SFP modules need to be purchased separately for use with this product.DimensionsOrdering InformationModel Name 10/100BaseT(X)PortsRJ45ConnectorCombo Ports10/100/1000BaseT(X)or100/1000BaseSFP+100BaseFX PortsMulti-Mode,SCConnector100BaseFX PortsMulti-Mode,STConnector100BaseFX PortsSingle-Mode,SCConnectorOperating Temp.EDS-518E-4GTXSFP144–––-10to60°C EDS-518E-4GTXSFP-T144–––-40to75°C EDS-518E-MM-SC-4GTXSFP1242––-10to60°CEDS-518E-MM-SC-4GTXSFP-T1242––-40to75°CEDS-518E-MM-ST-4GTXSFP124–2–-10to60°CEDS-518E-MM-ST-4GTXSFP-T124–2–-40to75°CEDS-518E-SS-SC-4GTXSFP124––2-10to60°CEDS-518E-SS-SC-4GTXSFP-T124––2-40to75°C Accessories(sold separately)Storage KitsABC-02-USB Configuration backup and restoration tool,firmware upgrade,and log file storage tool for managedEthernet switches and routers,0to60°C operating temperatureABC-02-USB-T Configuration backup and restoration tool,firmware upgrade,and log file storage tool for managedEthernet switches and routers,-40to75°C operating temperatureSFP ModulesSFP-1FELLC-T SFP module with1100Base single-mode with LC connector for80km transmission,-40to85°Coperating temperatureSFP-1FEMLC-T SFP module with1100Base multi-mode with LC connector for4km transmission,-40to85°Coperating temperatureSFP-1FESLC-T SFP module with1100Base single-mode with LC connector for40km transmission,-40to85°Coperating temperatureSFP-1G10ALC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1310nm,RX1550nm,0to60°C operating temperatureSFP-1G10ALC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1310nm,RX1550nm,-40to85°C operating temperatureSFP-1G10BLC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1550nm,RX1310nm,0to60°C operating temperatureSFP-1G10BLC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1550nm,RX1310nm,-40to85°C operating temperatureSFP-1G20ALC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1310nm,RX1550nm,0to60°C operating temperatureSFP-1G20ALC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1310nm,RX1550nm,-40to85°C operating temperatureSFP-1G20BLC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1550nm,RX1310nm,0to60°C operating temperatureSFP-1G20BLC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1550nm,RX1310nm,-40to85°C operating temperatureSFP-1G40ALC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1310nm,RX1550nm,0to60°C operating temperatureSFP-1G40ALC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1310nm,RX1550nm,-40to85°C operating temperatureSFP-1G40BLC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1550nm,RX1310nm,0to60°C operating temperatureSFP-1G40BLC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1550nm,RX1310nm,-40to85°C operating temperatureSFP-1GEZXLC SFP module with11000BaseEZX port with LC connector for110km transmission,0to60°C operatingtemperatureSFP-1GEZXLC-120SFP module with11000BaseEZX port with LC connector for120km transmission,0to60°C operatingtemperatureSFP-1GLHLC SFP module with11000BaseLH port with LC connector for30km transmission,0to60°C operatingtemperatureSFP-1GLHLC-T SFP module with11000BaseLH port with LC connector for30km transmission,-40to85°C operatingtemperatureSFP-1GLHXLC SFP module with11000BaseLHX port with LC connector for40km transmission,0to60°C operatingtemperatureSFP-1GLHXLC-T SFP module with11000BaseLHX port with LC connector for40km transmission,-40to85°Coperating temperatureSFP-1GLSXLC SFP module with11000BaseLSX port with LC connector for500m transmission,0to60°C operatingtemperatureSFP-1GLSXLC-T SFP module with11000BaseLSX port with LC connector for500m transmission,-40to85°Coperating temperatureSFP-1GLXLC SFP module with11000BaseLX port with LC connector for10km transmission,0to60°C operatingtemperatureSFP-1GLXLC-T SFP module with11000BaseLX port with LC connector for10km transmission,-40to85°C operatingtemperatureSFP-1GSXLC SFP module with11000BaseSX port with LC connector for300/550m transmission,0to60°Coperating temperatureSFP-1GSXLC-T SFP module with11000BaseSX port with LC connector for300/550m transmission,-40to85°Coperating temperatureSFP-1GZXLC SFP module with11000BaseZX port with LC connector for80km transmission,0to60°C operatingtemperatureSFP-1GZXLC-T SFP module with11000BaseZX port with LC connector for80km transmission,-40to85°C operatingtemperatureWall-Mounting KitsWK-51-01Wall-mounting kit,2plates,6screws,51.6x67x2mmSoftwareMXview-50Industrial network management software with a license for50nodes(by IP address)MXview-100Industrial network management software with a license for100nodes(by IP address)MXview-250Industrial network management software with a license for250nodes(by IP address)MXview-500Industrial network management software with a license for500nodes(by IP address)MXview-1000Industrial network management software with a license for1000nodes(by IP address)MXview-2000Industrial network management software with a license for2000nodes(by IP address)MXview Upgrade-50License expansion of MXview industrial network management software by50nodes(by IP address)©Moxa Inc.All rights reserved.Updated Aug06,2019.This document and any portion thereof may not be reproduced or used in any manner whatsoever without the express written permission of Moxa Inc.Product specifications subject to change without notice.Visit our website for the most up-to-date product information.。
1.1 Quidway® S2300系列运营级接入交换机1.1.1 产品概述Quidway® S2300系列运营级接入交换机(以下简称S2300) 是华为公司为满足以太网多业务承载需要、面向精品城域网和企业网而推出的新一代运营级以太网接入交换机，适应各种以太接入场景。
S2300基于新一代高性能硬件和华为公司统一的VRP®（Versatile Routing Platform）软件，可为用户提供丰富灵活的业务特性，有效地提高产品可运营、可管理和业务扩展能力，具备优异的防雷能力和安全特性，支持强大的ACL功能，支持QINQ，支持1：1和N：1 VLAN 交换功能，满足VLAN灵活部署的需求。
S2300为盒式产品设备，机箱高度为1U，从特性上划分SI和EI两个产品版本，包括：S2309TP-SI/EI、S2318TP-SI/EI、S2326TP-SI/EI、S2352P-EI。
1.1.2 产品外观S2309TP-SI/EIS2318TP-SI/EIS2326TP-SI/EIS2352P-EI2309TP-EI：8个10/100Base-T，1个10/100/1000Base-T与100/1000Base-X SFP COMBO，分交流供电和直流供电两种机型；2309TP-SI：8个10/100Base-T，1个10/100Base-T与1个100Base-X SFP COMBO，交流供电；2318TP-EI：16个10/100Base-T，2个10/100/1000Base-T与2个100/1000Base-X SFP COMBO, 分交流供电和直流供电两种机型；2318TP-SI：16个10/100Base-T，2个10/100Base-T与2个100Base-X SFP COMBO，交流供电；2326TP-EI：24个10/100Base-T，2个10/100/1000Base-T与2个100/1000Base-X SFP COMBO，分交流供电和直流供电两种机型；2326TP-SI：24个10/100Base-T，2个10/100Base-T与2个100Base-X SFP COMBO，交流供电；2352P-EI：48个10/100Base-T，2个100/1000Base-X SFP，2个1000Base-X SFP 分交流供电和直流供电两种机型。
T h e i n f o r m a t i o n p r o v i d e d i n t h i s d o c u m e n t a t i o n c o n t a i n s g e n e r a l d e s c r i p t i o n s a n d /o r t e c h n i c a l c h a r a c t e r i s t i c s o f t h e p e r f o r m a n c e o f t h e p r o d u c t s c o n t a i n e d h e r e i n .T h i s d o c u m e n t a t i o n i s n o t i n t e n d e d a s a s u b s t i t u t e f o r a n d i s n o t t o b e u s e d f o r d e t e r m i n i n g s u i t a b i l i t y o r r e l i a b i l i t y o f t h e s e p r o d u c t s f o r s p e c i f i c u s e r a p p l i c a t i o n s .I t i s t h e d u t y o f a n y s u c h u s e r o r i n t e g r a t o r t o p e r f o r m t h e a p p r o p r i a t e a n d c o m p l e t e r i s k a n a l y s i s , e v a l u a t i o n a n d t e s t i n g o f t h e p r o d u c t s w i t h r e s p e c t t o t h e r e l e v a n t s p e c i f i c a p p l i c a t i o n o r u s e t h e r e o f .N e i t h e r S c h n e i d e r E l e c t r i c I n d u s t r i e s S A S n o r a n y o f i t s a f f i l i a t e s o r s u b s i d i a r i e s s h a l l b e r e s p o n s i b l e o r l i a b l e f o r m i s u s e o f t h e i n f o r m a t i o n c o n t a i n e d h e r e i n .Product data sheetCharacteristicsXPSAC5121module XPSAC - Emergency stop - 24 V ACDCMainRange of product Preventa Safety automation Product or component typePreventa safety module Safety module name XPSACSafety module applica-tionFor emergency stop and switch monitoring Function of module Emergency stop Switch monitoringSafety levelCan reach SILCL 3 conforming to EN/IEC 62061Can reach PL e/category 4 conforming to EN/ISO 13849-1Safety reliability dataPFHd = 3.56E-9 1/h conforming to EN/IEC 62061DC > 99 % conforming to EN/ISO 13849-1MTTFd = 210.4 years conforming to EN/ISO 13849-1Type of startUnmonitoredConnections - terminalsCaptive screw clamp terminals (2 x 0.5...2 x 1.5mm²)flexible cable with cable end, with double bezel Captive screw clamp terminals (2 x 0.25...2 x 1mm²)flexible cable with cable end, without bezel Captive screw clamp terminals (2 x 0.14...2 x 0.75mm²)solid cable without cable endCaptive screw clamp terminals (2 x 0.14...2 x 0.75mm²)flexible cable without cable endCaptive screw clamp terminals (1 x 0.25...1 x 2.5mm²)flexible cable with cable end, without bezel Captive screw clamp terminals (1 x 0.25...1 x 1.5mm²)flexible cable with cable end, with bezel Captive screw clamp terminals (1 x 0.14...1 x 2.5mm²)solid cable without cable endCaptive screw clamp terminals (1 x 0.14...1 x 2.5mm²)flexible cable without cable end Output typeRelay instantaneous opening 3 NO, volt-free Number of additional circuits1 solid state output [Us] rated supply volt-age24 V DC (- 20...20 %)24 V AC (- 20...10 %)ComplementarySupply frequency 50/60 Hz Power consumption in W <= 1.2 W DC Power consumption in VA <= 2.5 VA AC Control circuit voltage 24 VBreaking capacity C300: 1800 VA, AC-15 (inrush) for relay output C300: 180 VA, AC-15 (holding) for relay outputBreaking capacity 1.5 A at 24 V (DC-13) time constant: 50 ms for relay output Output thermal current6 A per relay for relay output [Ith] conventional free air thermal current 10.5 AAssociated fuse rating6 A fuse type fast blow for relay output conforming to EN/IEC 60947-5-1, DIN VDE 0660 part 2004 A fuse type gG or gL for relay output conforming to EN/IEC 60947-5-1, DIN VDE 0660 part 200Minimum output current 10 mA for relay output Minimum output voltage 16 V for relay output Response time on input open <= 100 ms[Ui] rated insulation voltage300 V (degree of pollution: 2) conforming to IEC 60647-5-1, DIN VDE 0110 part 1捷多邦，您值得信赖的PCB打样专家！[Uimp] rated impulse withstand voltage 4 kV overvoltage category III conforming to IEC 60647-5-1, DIN VDE 0110 part 1 Local signalling 2 LEDsCurrent consumption90 mA at 24 V AC (on power supply)40 mA at 24 V DC (on power supply)Mounting support35 mm symmetrical DIN railProduct weight0.16 kgEnvironmentStandards EN 1088/ISO 14119EN 60204-1EN/IEC 60947-5-1EN/ISO 13850Product certifications CSATÜVULIP degree of protection IP40 (enclosure) conforming to EN/IEC 60529IP20 (terminals) conforming to EN/IEC 60529Ambient air temperature for operation-10...55 °CAmbient air temperature for storage-25...85 °CDimensions Drawings DimensionsConnections and SchemaWiring DiagramsRefer to the Instruction SheetTo download the instruction sheet, follow below procedure:1Click on Download & Documents.2Click on Instruction sheet.。
