©2002 Fairchild Semiconductor CorporationRev. A1, August 2002BCW66G
Absolute Maximum Ratings *
T
C=25°C unless otherwise noted
* These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.
NOTES:1.These ratings are based on a maximum junction temperature of 150degrees C.2.These are steady state limits. The factory should be consulted on applications involving pulsed or low duty cycle operations.
Electrical Characteristics TC=25°C unless otherwise notedSymbolParameterValueUnitsVCEOCollector-Emitter Voltage45V
VCBOCollector-Base Voltage75V
VEBOEmitter-Base Voltage5V
ICCollector Current- Continuous1A
TJ, TSTGOperating and Storage Junction Temperature Range- 55 ~ +150°C
SymbolParameterTest ConditionMin.Typ.Max.UnitsBVCBOCollector-Base Breakdown VoltageIC = 10µA75V
BVCEOCollector-Emitter Breakdown Voltage IC = 10mA45V
BVEBOEmitter-Base Breakdown VoltageIE = 10µA5V
ICESCollector Cut-off CurrentVCB = 45V, IE = 0VCB = 45V, IE = 0TA = 150°C20nA
20µA
IEBOEmitter Cut-off CurrentVEB = 4V20nA
hFEDC Current GainVCE = 10V, IC = 100µAVCE = 1V, IC = 10mAVCE = 1V, IC = 100mAVCE = 2V, IC = 500mA5011016060400
VCE(sat)Collector-Emitter Saturation VoltageIC = 100mA, IB = 10mAIC = 500mA, IB = 50mA0.30.7V
VBE(sat)Base-Emitter Saturation VoltageIC = 500mA, IB = 50mA2V
CoboOutput CapacitanceVCB = 10V, f = 1MHz12pF
CiboInput CapacitanceVEB = 0.5V, f = 1MHz80pF
fTCurrent gain Bandwidth ProductVCE = 10V, IC = 20mA, f = 100MHz100MHz
NFNoise FigureVCE = 5V, IC = 0.2mA, RS = 1kΩ, f = 1KHz, BW = 200Hz10dB
tonTurn-On TimeIB1 = IB2 = 15mAIC = 150mA, RL = 150Ω100ns
toffTurn-Off Time400BCW66G
NPN General Purpose Amplifier
•This device is designed for general purpose amplifier applications at collector currents to 500mA.•Sourced from process 13.
SOT-23
1. Base 2. Emitter 3. Collector 123
Mark: EG元器件交易网www.cecb2b.com©2002 Fairchild Semiconductor CorporationRev. A1, August 2002BCW66GThermal Characteristics
SymbolParameterMin.Typ.Max.UnitsPDTotal Device DissipationDerate above 25°C3502.8mWmW/°C
RθJAThermal Resistance, Junction to Ambient357°C/W元器件交易网www.cecb2b.comPackage DimensionsBCW66G
0.96~1.140.120.03~0.10
0.38 REF
0.40 ±0.03
2.90 ±0.10
0.95 ±0.030.95 ±0.03
1.90 ±0.030.508REF0.97REF1.30 ±0.100.45~0.60
2.40 ±0.10
+0.05–0.0230.20 MIN
0.40 ±0.03SOT-23
Dimensions in Millimeters
