White Electronic Designs Corp. reserves the right to change products or specifi cations without notice.2x512Kx8 DUALITHIC™ SRAM

FEATURES

󰀂 Access Times 17, 20, 25, 35, 45, 55ns

󰀂 Revolutionary, Center Power/Ground Pinout

󰀂 Packaging:

• 32 pin, Her met ic Ceramic DIP (Package 300)

• 36 lead Ceramic SOJ (Package 100)

• 36 lead Ceramic Flatpack (Package 226)

36 CSOJ

36 FLATPACK

TOP VIEW

123456789101112131415161718363534333231302928272625242322212019A0A1A2A3A4CS1#I/O0I/O1VCCGNDI/O2I/O3WE#A5A6A7A8A9NCA18A17A16A15OE#I/O7I/O6GNDVCCI/O5I/O4A14A13A12A11A10CS2#

Block Diagram

512K x 8512K x 8A0-18OE#WE#

CS1#CS2#I/O0-7

(1)(1)PIN CONFIGURATION FOR WS1M8-XDJX

AND WS1M8-XFX

Pin Description

A0-18Address Inputs

I/O0-7Data Input/Output

CS1-2#Chip Selects

OE#Output Enable

WE#Write Enable

VCC+5.0V Power

GNDGround

NOTE:

1. CS1# and CS2# are used to select the lower and upper 512Kx8 of the device. CS1# and CS2# must not be enabled at the same time.󰀂 Organized as two banks of 512Kx8

󰀂 Commercial, Industrial and Military Temperature Ranges

󰀂 5 Volt Power Supply

󰀂 Low Power CMOS

󰀂 TTL Compatible Inputs and Outputs

PIN CONFIGURATION FOR WS1M8-XCX

32 DIP

TOP VIEW

512K x 8512K x 8A0-18WE#

CS1#CS2#I/O0-7

(1)(1)1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

1632

31

30

29

28

27

26

25

24

23

22

21

20

19

18

17A18

A16

A14

A12

A7

A6

A5

A4

A3

A2

A1

A0

I/O0

I/O1

I/O2

GNDVCCA15

A17

WE#

A13

A8

A9

A11

CS2#

A10

CS1#

I/O7

I/O6

I/O5

I/O4

I/O3

Pin Description

A0-18Address Inputs

I/O0-7Data Input/Output

CS1-2#Chip Selects

WE#Write Enable

VCC+5.0V Power

GNDGround

Block Diagram元器件交易网www.cecb2b.com2

White Electronic Designs Corporation • (602) 437-1520 • www.wedc.comWhite Electronic DesignsWS1M8-XXX

July 2004Rev. 5White Electronic Designs Corp. reserves the right to change products or specifi cations without notice.ABSOLUTE MAXIMUM RATINGS

Parameter SymbolMinMaxUnit

Operating TemperatureTA-55 +125°C

Storage TemperatureTSTG-65+150°C

Signal Voltage Relative to GNDVG-0.5VCC +0.5V

Junction TemperatureTJ150°C

Supply VoltageVCC-0.57.0VTRUTH TABLE

CS#OE#WE#ModeData I/O Power

HXXStandbyHigh ZStandby

LLHReadData OutActive

LXLWriteData InActive

LHHOut DisableHigh ZActive

NOTE: OE# is internally tied to the GND and not accessible on the WS1M8-XCXX.

RECOMMENDED OPERATING CONDITIONS

ParameterSymbolMinMaxUnit

Supply VoltageVCC4.55.5V

Input High VoltageVIH2.2VCC + 0.3V

Input Low VoltageVIL-0.3+0.8V

Operating Temp. (Mil.)TA-55+125°CCAPACITANCE

TA = +25°C

ParameterSymbolConditionMaxUnit

Input capacitance CINVIN = 0V, f = 1.0MHz20pF

Output capicitanceCOUTVOUT = 0V, f = 1.0MHz20pF

This parameter is guaranteed by design but not tested.

DC CHARACTERISTICS

VCC = 5.0V, VSS = 0V, -55°C ≤ TA ≤ +125°C

ParameterSymConditionsMinMaxUnits

Input Leakage CurrentILIVCC = 5.5, VIN = GND to VCC10µA

Output Leakage CurrentILO1CS# = VIH, OE# = VIH, VOUT = GND to VCC10µA

Operating Supply Current ICC1CS# = VIL, OE# = VIH, f = 5MHz, VCC = 5.5180mA

Standby CurrentISB1CS# = VIH, OE# = VIH, f = 5MHz, VCC = 5.540mA

Output Low VoltageVOLIOL = 6mA0.4V

Output High VoltageVOHIOH = -4.0mA2.4V

NOTE: DC test conditions: VIH = VCC -0.3V , VIL = 0.3V

1. OE# is internally tied to the GND and not accessible on the WS1M8-XCXX.元器件交易网www.cecb2b.com3

White Electronic Designs Corporation • (602) 437-1520 • www.wedc.comWhite Electronic DesignsWS1M8-XXX

July 2004Rev. 5White Electronic Designs Corp. reserves the right to change products or specifi cations without notice.

ICurrent Source

D.U.T.

C = 50 pfeffIOL

V ≈ 1.5V

(Bipolar Supply)Z

Current SourceOHAC TEST CIRCUITAC TEST CONDITIONS

ParameterTypUnit

Input Pulse LevelsVIL = 0, VIH = 3.0V

Input Rise and Fall5ns

Input and Output Reference Level1.5V

Output Timing Reference Level1.5V

Notes:

VZ is programmable from -2V to +7V.

IOL & IOH programmable from 0 to 16mA.

Tester Impedance Z0 = 75 Ω.

VZ is typically the midpoint of VOH and VOL.

IOL & IOH are adjusted to simulate a typical resistive load cir cuit.

ATE tester includes jig capacitance.AC CHARACTERISTICS

VCC = 5.0V, VSS = 0V, -55°C ≤ TA ≤ +125°C

Parameter

Read CycleSymbol-17-20-25-35-45-55UnitsMinMaxMinMaxMinMaxMinMaxMinMaxMinMax

Read Cycle TimetRC172025354555ns

Address Access TimetAA172025354555ns

Output Hold from Address ChangetOH000000ns

Chip Select Access TimetACS172025354555ns

Output Enable to Output ValidtOE291012252525ns

Chip Select to Output in Low ZtCLZ1222444ns

Output Enable to Output in Low ZtOLZ2000000ns

Chip Disable to Output in High ZtCHZ191012152020ns

Output Disable to Output in High ZtOHZ291012152020ns

1. This parameter is guaranteed by design but not tested.

2. OE# is internally tied to the GND and not accessible on the WS1M8-XCXX.

AC CHARACTERISTICS
