Revised 11-1-85I-3360-SRelief Valve

CF-16-H(V)-10Service Data

7076 Plug

263522 Plug

105680 Seat

241166 Cover

154079 ‘‘O’’ Ring298184 Screw (4 req’d)

184583 Piston175074 Spring

184586 Spring Retainer

173792 ‘‘O’’ Ring182217 Adj. Screw

1485 Nut192656 Retainer192655 Spacer (As req’d)

136568 Plug241172 Body18456 Seat51564 Piston

NOTEFor information on connectingflanges, refer to Drawing I-3962-S.ModelSpringCF-16-H-10 CF-16-HV-102886025643Vickers®

ValvesModel Code

345612

1

2SealsF3 -Multi-fluid capability (VitonR seals)Viton is a registered trademark of E.I. DuPont

Model SeriesCF -Relief Valve, flange connections3

45

6Nominal Valve Size16 -2 inch

Pressure RangeH -5000 psiSpringV -High vent(Omit if not required)

Design Number

For satisfactory service life of these components, use full flow filtration to provide fluid which meets ISO cleanliness code18/15 or cleaner. Selections from Eaton OFP,OFR and OFRS filter series are recommended.Printed in U.S.A.
