cadence生成网络表时出现如下错误,解决办法(转)

上一篇 / 下一篇 2012-07-16 18:59:32 / 个人分类:PCB设计查看( 331 ) / 评论( 0 ) / 评分( 0 / 0 )

这样吧,一类一类的来分析。

(1)Warning "No_connect"

#1 Warning [ALG0047] "No_connect" property on Pin "P1.8" ignored forP1: SCHEMATIC1, 13)U

RAT (7.90, 1.20). Connecting pin to net "N16811229".

$k3D3pd-T$W7he

ALG0047,这个警告基本可以忽略;造成这个问题的原因是,设计之初先对器件相关的管脚上

加上'X'(也就是NC符号),更新设计的过程又对管脚做了连接处理;但是后面的连接处理没有去

掉管脚的NC属性,不信的话把那个管脚上的net删掉看看。

解决办法很简单,对这些管脚再做一次NC

(2)Warning Part Name

#5 Warning [ALG0016] Part Name "CAP PN_C100UP-6.3V-SMT-S_100UF/6.3V" is renamed to "C

AP PN_C100UP-6.3V-SMT-S_100UF/"

这个警告不可避免,allegro对相关的属性名称进行合并,超过一定数量的字符就截掉;在命名

规范的前提下就不考虑这个警告了。

无法根治

这个#2 Warning [ALG0016] Part Name

之类的错误在于你建立元件原理图的时候你的原件Value值太长了超过32个字符,从而使系统

在进行命名规范的时候溢出,而出错,很简单的,只写关键元件名,比如 A2541P10_HDR2X5-100MIL_2X5 HEADER" is renamed to "A2541P10_HDR2X5-100MIL_2X5 HEAD错误只需要

把2X5 HEADER更改为A2541P10,去除中间的空格即可.U(ZE0B5L5b%X;n4g Allegro对一些字符[例如"空格","小数点"等等]很在意,可以参阅相关文档

的描述.

(3)Error Illegal character "Dot(.)" found in "PCB Footprint"

#1 Error [ALG0081] Illegal character "Dot(.)" found in "PCB Footprint" property for componen

t instance C255: PG16_AC97, PG16_AC97 (226.06, 132.08) .

封装命名不能包含“.”

(4)Error Illegal character "Forward Slash(/)" found in "PCB Footprint" property

#1 Error [ALG0081] Illegal character "Forward Slash(/)" found in "PCB Footprint" property for

component instance C255: PG16_AC97, PG16_AC97 (226.06, 132.08) .

#2 Error [ALG0081] Illegal character "Forward Slash(/)" found in "PCB Footprint" property for

component instance D3: PG01_LED&Switch&7-Segment Disp, PG01_LED&Switch&7-Segment Disp

(93.98, 33.02) .

#3 Error [ALG0081] Illegal character "Forward Slash(/)" found in "PCB Footprint" property for

component instance C245: PG16_AC97, PG16_AC97 (205.74, 35.56) .

封装命名不能包含“/”

(5)比较隐藏的排除法

Loading... E:\FPGA\SCH\allegro/pstchip.dat

#34 WARNING(SPCODD-34): Expected ';' character on line 5308. Check the name and

value syntax for invalid characters in the

primitive definition before the line number.

ERROR(SPCODD-47): File ./allegro/pstchip.dat could not be loaded, and the pac

kaging operation did not complete. Check the pxl.log file for the errors causing this situ

ation and package the design again.#53 ERROR(SPCODD-53): Packaging cannot be completed because packaging has enc

ountered a null object ID. The design may not have been saved correctly. Save the sc

hematic and rerun packaging.

#187 Error [ALG0036] Unable to read logical netlist data.

Exiting... "D:\Cadence\SPB_16.2\tools\capture\pstswp.exe" -pst -d "E:\FPGA\SCH\motherb

oard.dsn" -n "E:\FPGA\SCH\allegro" -c "D:\Cadence\SPB_16.2\tools\capture\allegro.cfg" -v

3 -j "PCB Footprint"

*** Done*******掌握排错方法,查找文件pstchip.dat,第on line 5308 看看错误,便可以解决

(6)封装命名中不能包含“小数点”、“/”、“空格”,把空格换成下划线或删除,可以解决

********************************************************************************

** Netlisting the design

*********************************************************************************

Design Name:

E:\FPGA\SCH\basicboard.dsn

Netlist Directory:

E:\FPGA\SCH\allegro

Configuration File:

D:\Cadence\SPB_16.2\tools\capture\allegro.cfg

Spawning... "D:\Cadence\SPB_16.2\tools\capture\pstswp.exe" -pst -d "E:\FPGA\SCH\basic

board.dsn" -n "E:\FPGA\SCH\allegro" -c "D:\Cadence\SPB_16.2\tools\capture\allegro.cfg" -

v 3 -j "PCB Footprint"

#1 Error [ALG0081] Illegal character "White space" found in "PCB Footprint" property f

or component instance MG2: Basic, PG06_Stepmotor (180.34, 83.82) .#2 Error [ALG0081] Illegal character "White space" found in "PCB Footprint" property f

or component instance ISO1: Basic, PG05_DC Motor (134.62, 40.64) .

#3 Info: PCB Editor does not support Dots(.), Forward Slash(/) and White space in foot

print names. The supported characters include Alphabets, Numerics, Underscore(_) and

Hyphen(-).

#4 Aborting Netlisting... Please correct the above errors and retry.

Exiting... "D:\Cadence\SPB_16.2\tools\capture\pstswp.exe" -pst -d "E:\FPGA\SCH\basicboa

rd.dsn" -n "E:\FPGA\SCH\allegro" -c "D:\Cadence\SPB_16.2\tools\capture\allegro.cfg" -v 3

-j "PCB Footprint"

*** Done ***封装命名中不能包含“小数点”、“/”、“空格”,把空格换成下划线或删除,可以解决

(7)Warning

#11 Warning [ALG0051] Pin "GND" is renamed to "GND#A6" after substituting illegal ch

aracters in Package XC3S1400A-4FG676-C_0FF , U1A: SCHEMATIC1, PG01_FPGACO

NFIG (2.40, 3.10).

#12 Warning [ALG0051] Pin "GND" is renamed to "GND#A11" after substituting illegal c

haracters in Package XC3S1400A-4FG676-C_0FF , U1A: SCHEMATIC1, PG01_FPGAC

ONFIG (2.40, 3.10).

#13 Warning [ALG0051] Pin "GND" is renamed to "GND#A1" after substituting illegal ch

aracters in Package XC3S1400A-4FG676-C_0FF , U1A: SCHEMATIC1, PG01_FPGACO

NFIG (2.40, 3.10).

#14 Warning [ALG0051] Pin "GND" is renamed to "GND#W8" after substituting illegal c
