The metal cutting The importance of machining processes can be emphasised by the fact that every product we use in our daily life has undergone this process either directly or indirectly.

(1) In USA, more than $100 billions are spent annually on machining and related operations.

(2) A large majority (above 80%) of all the machine tools used in the manufacturing industry have undergone metal cutting.

(3) An estimate showed that about 10 to 15% of all the metal produced in USA was converted into chips.

These facts show the importance of metal cutting in general manufacturing. It is therefore important to understand the metal cutting process in order to make the best use of it.

A number of attempts have been made in understanding the metal cutting process and using this knowledge to help improve manufacturing operations which involved metal cutting.

A typical cutting tool in simplified form is shown in Fig.7.1. The important features to be observed are follows.

1. Rake angle. It is the angle between the face of the tool called the rake face and the normal to the machining direction. Higher the rake angle, better is the cutting and less are the cutting forces, increasing the rake angle reduces the metal backup available at the tool rake face. This reduces the strength of the tool tip as well as the heat dissipation through the tool. Thus, there is a maximum limit to the rake angle and this is generally of the order of 15°for high speed steel tools cutting mild steel. It is possible to have rake angles at zero or negative.

2. Clearance angle. This is the angle between the machined surface and the underside of the tool called the flank face. The clearance angle is provided such that the tool will not rub the machined surface thus spoiling the surface and increasing the cutting forces. A very large clearance angle reduces the strength of the tool tip, and hence normally an angle of the order of 5~6°is used.

The conditions which have an important influence on metal cutting are work material, cutting tool material, cutting tool geometry, cutting speed, feed rate, depth of cut and cutting fluid used.

The cutting speed, v, is the speed with which the cutting tool moves through the work material. This is generally expressed in metres per second (ms-1).

Feed rate, f, may be defined as the small relative movement per cycle (per revolution or per stroke) of the cutting tool in a direction usually normal to the cutting speed direction.

Depth of cut, d, is the normal distance between the unmachined surface and the machined surface.

Chip Formation Metal cutting process is a very complex process. Fig.7.2 shows the basic material removal operation schematically. The metal in front of the tool rake face gets immediately compressed, first elastically and then plastically. This zone is traditionally called shear zone in view of fact that the material in the final form would be removed by shear from the parent metal.

The actual separation of the metal starts as a yielding or fracture, depending upon the cutting conditions, starting from the cutting tool tip. Then the deformed metal (called chip) flows over the tool (rake) face.

If the friction between the tool rake face and the underside of the chip (deformed material) is considerable, then the chip gets further deformed, which is termed as secondary deformation. The chip after sliding over the tool rake face is lifted away from the tool, and the resultant curvature of the chip is termed as chip curl.

Plastic deformation can be caused by yielding, in which case strained layers of material would get displaced over other layers along the slip-planes which coincide with the direction of maximum shear stress.

A chip is variable both in size and shape in actual manufacturing practice. Study of chips is one of the most important things in metal cutting. As would be seen later, the mechanics of metal cutting are greatly dependent on the shape and size of the chips produced.

Chip formation in metal cutting could be broadly categorised into three types: (Fig.7.3)

(1) Discontinuous chip (2) Continuous chip (3) Continuous chip with BUE (Built up edge)
