超频软件使用教程1 首先，解压后得到软件。

一个是超频软件，一个是注册码。

另外一个附送的是东芝省电软件，很多朋友都有了，只有个别的朋友没有，这个和超频没有关系，需要就安装，不需要就不安装。

还有一个是系统检测软件，其中CPU_Z 运行后，直接就可以看出CPU 频率了。

运行ASWEF.EXE，安装超频软件。

2这里是问是否要在桌面上放一个快捷方式，需要，点是。

3这里是问是否要在电脑启动的时候自动运行软件，需要，点是。

这样，以后每次软件都按你设置好的自动运行，你就不用管了，只要第一次安装好，设置好，就可以了。

4安装完毕，这里是问是否重启电脑。

点是。

然后机器就重新启动了, 重启后，软件就安装好了。

5安装好后，运行软件。

还没注册,所以刚启动软件的时候会有一个提示,提示注册,好像是10多美元哦,呵呵~!6 按图提示,点击注册的那个地方,然后在弹出的对话框中输入注册码。

这个是注册码.7 在这里填入注册码。

然后点击ok 。

然后记得点击save ，保存。

8注册好后，就开始设置了。

这个设置很重要，要认真，按顺序来。

1（第一行的框那里不用管，不用设置）然后在第二行的框这里选择。

左边第一个框选择ICS，第二个框选择94258。

2然后直接来第二步这里。

这里是设置下次启动时的频率。

这个地方很重要，这个地方设置好了，以后软件启动之后，系统就按该频率运行了。

最关键就是这个设置了。

按向上的小箭头，选择到自己需要的频率。

（按一次小箭头，RAM的频率就会变一次，变到最高后，FSB的频率再变，这样不断按，直到如图所示的频率为止。

）也就是FSB 133.3MHz PCI 33.3MHz RAM 133.3MHz。

3设置完之后，点击保存。

4然后点击这里，把软件关到最小。

然后就重启电脑，重启之后，你用CPU_Z检测软件看看，FSB 是133了，CPU是1 G了，整个系统运行快多了！再来一张频率设置的图。

附一些相关的截图1 未超频之前的CPU－Z 截图。
