RBK-1080型可燃气体报警控制器鲁制01000105 产品使用说明书济南瑞安电子有限公司目录1.概述 (1)2.主要技术指标 (2)3.结构特征 (3)3-1 外形尺寸图示 (3)3-2 产品安装 (4)3-3 产品结构 (6)3-4 控制器与探测器的接线方式 (10)3-5控制器信号输出 (10)4.操作与应用 (16)5.产品的维护 (18)5-1注意事项 (18)5-2 常见故障的分析与排除 (18)5-3售后服务 (19)附1:系统结构及工作原理 (19)附2关于连接上位机的问题 (20)1.外部485连接 (20)2.级联485连接 (20)1.概述RBK-1080型可燃气体报警控制器，是一款功能实用、操作方便的可燃气体报警控制器,可与我公司的RBT-8000系列气体探测器配套组成工业用可燃气体报警系统。

本产品为非防爆产品，应安装在非防爆场合，采用壁挂式安装。

特点：⚫液晶显示，全中文菜单操作；⚫单回路3线分线制4～20mA控制器，具有自动保护功能，系统抗干扰能力强，布线经济，安装方便；⚫自动故障检测，能准确指示故障部位及类型；⚫内置大容量数据存储，能记录100条报警信息、100开关机时间信息，信息掉电不丢失；⚫RS485总线通讯接口（选配，标准Modbus/RTU协议），能实现与上位机控制系统联网，实现异地监控，大大提高可监控的及时性、准确性。

⚫内置2组继电器触点信号输出，可联动控制排风扇或电磁阀等设备。

联动信号可手动或自动输出。

本产品的设计、制造及检验均遵循以下国家标准：GB16808-2008《可燃气体报警控制器》2.主要技术指标安装方式：非防爆场合的壁挂式安装工作电压：主电：AC220V±15%,50Hz±1%备电：3.7VDC/2200mAH功耗：≤10W工作温度：-20℃～+55℃工作湿度：≤93%RH容量：1信号传输：4～20mA信号连接线缆：≥3×1.5mm2国标线报警方式：声、光报警声音报警：分故障报警，低浓度报警，高浓度报警三种不同的声音。

FAF28-14-1动叶可调轴流送风机产品安装和使用说明书（A本）SBW工程号2008-30上海鼓风机厂有限公司二○○八年三月1 风机技术参数1.1 一般资料风机型号FAF28-14-1工程号2006-30合同号电06/06-024建造年份2006年风机性能参数:1.2 机械参数风机内径φ2818叶轮直径φ1412叶轮级数 1叶型DA16叶片数16叶片和叶柄的连接高强度螺栓液压缸径和行程φ336/H100MET叶片调节范围-40~+10o风机机壳内径和叶片外径间的间隙应符合JB/T4362-1999 标准要求：为转子直径的0.001~0.002倍（对本风机来讲为2.8~5.66mm）（叶片在关闭位置）1.3 风机起动力矩风机转速n =990 r/min飞轮力矩J = 0.25GD2 =580Kgm2电机轴端径向力F R = 3200 N电机轴端轴向力F A = 1850N电机功率Ne = 2850kw从电机轴伸端看电机转向为顺时针旋转，风机转向为逆时针。

1.4 风机特性曲线风机型号FAF28-14-1用户新密1000MW工程号2006-30风机转速990r/min介质密度 1.1990kg/m3风机叶片16DA16 (4GD3448)2 转子图和总图汇总的拧紧力矩件号拧紧力矩（Nm）名称11.551170轴承箱螺母M170X311.561170轴承箱螺母M175x311.80 454.72 轴承箱与机壳支承环连接螺钉M20×11013.81 105.84 叶片螺钉M12×1.25×4014.52181.1调节杆拧紧螺母M16×9519.34 53.9 调节环与推盘连接螺钉M10×6519.61 94.08 液压缸与调节盘连接螺钉M12×6019.74 231.28 液压支承体与支承环连接螺钉M16×4019.71 53.9 液压支承体与液压缸连接螺钉M10×4026.11.05 454.72 中间轴连接螺钉M20×7551.39.02 784 机壳中分面连接螺栓M24×12069.01 750 机壳和整流导叶环地脚螺钉M4269.02 750 机壳和整流导叶环双地脚螺钉M42-18069.03 500 进气箱和扩压器地脚螺栓M30×80069.29 1600电动机地脚螺栓M48×12503 联轴器的参数5 图样清单名称图号风机总图S1GA3708风机转子S0GA2469（借05-54）叶片指示和调节机构1TY0165 (TY0044-06) 轴承箱油管路0TY0179(H180) (TY056-07) 液压调节装置油管路1TY0320 (TY0041-07)温度和防喘振装置1TY0228（双支）(TY0045-06) 进气膨胀节1TY0047 (TY026-06)排气膨胀节1TY0048 (TY027-06)围带1TY0071(TY032-06) 地脚螺钉M42 2TY0003(TY003-06) 双地脚螺钉M42-180 2TY0017 (TY004-06)消声器DZL330-1转子补充加工图S4GA6381。

易（上海）有限公司联系。
4
R 注意
整体 ●使用电动机、驱动器时，请勿超过其规格值，否则有可能引起触电、致伤或造成机器破损。 ●电动机、驱动器的开口部中请勿伸进手指或插入物体，否则有可能引起火灾、触电或致伤。 ●运转中或停止后一段时间内，请勿碰触电动机和驱动器，否则有可能因电动机和驱动器表面的高温而引起烫伤。 搬运 ●搬运时请勿利用电动机的输出轴和电动机电缆线，否则有可能致伤。 安装 ●电动机、驱动器周围请勿堆放可燃物，否则有可能引起火灾或烫伤。 ●电动机、驱动器周围请勿堆置妨碍通风的障碍物，否则有可能造成机器破损。 ●请在电动机的旋转部（输出轴）上安装防护罩，否则有可能致伤。 运转 ●电动机与驱动器请按指定的搭配使用，否则有可能引起火灾。 ●运转之前，请采取措施，使机器在任何时候都能紧急停止，否则有可能致伤。 ●要接通驱动器的电源之前，请先将驱动器的输入信号全部设定为「OFF」，否则电动机会起动，有可能造成机器破
·规格认定品的认定取得品名为电动机单体品名及驱动器单体品名。
·VDE 规格所要求的温升试验是在带铝制散热板状态下进行的。散热板的尺寸、厚度如下表所示﹕ [单位﹕mm]
安装尺寸
尺寸
厚度
□ 42
80×80
□ 60
160×160
10
□ 85、□ 90 250×250
●安装条件（EN 规格） 电动机
单相 100-115 V
重要
为了使您能正确使用产品，在正文的相关使用项目中记载着请用户务必遵守的事项。
R 警告
整体 ●请勿在爆炸性环境、可燃性气体环境、腐蚀性环境、容易沾上水的场所以及可燃物的附近使用本产品，否则有可能
引起火灾、触电或致伤。 ●安装、接线、运转·操作、点检·故障诊断作业请由有适当资格的人实施，否则有可能引起火灾、触电或致伤。 ●请勿在通电状态下进行移动、安装、接线和点检作业。请切断电源后再进行作业，否则有可能引起触电。 ●驱动器前面板上的 l R 标志表示这是有高电压的端子。通电中请勿接触该端子，否则有可能引起火灾或触电。 ●在升降装置上使用时，请采取措施来保持可动部的位置。在切断电源后，电动机会失去保持力，可动部落下有可能
