第28卷 第3期2007年6月发 光 学 报C H I N ESE J OURNAL OF LUM I N ESCENCEV ol 128N o 13J un .,2007/文章编号:1000-7032(2007)03-0291-011白光LED 固态照明光转换荧光体刘行仁(中国科学院长春光学精密机械与物理研究所,吉林长春 130033)摘要:报道了当前热点固态照明白光LED 对所用光转换荧光体的特殊要求,从发光学和晶场理论出发,提出研发白光LED 用荧光体的几种方案和原则。
依据多年成果,特别阐述在稀土铝镓石榴石体系,氯硅酸钙及某些钨钼酸盐中,Ce 3+、P r 3+、Tb 3+、Eu 3+、Eu 2+及M n 2+离子的发光特性,能量传递,Eu 2+的特征/阶梯状0光谱以及激活剂在晶体中所占据不同晶体学格位与发光性质的关联性。
这些材料都可用于白光LED 之中。
实践证明,这些基础性研究和原理是研制白光LED 用荧光体的基础。
光转换荧光体与InG a N 蓝光芯片结合可以获得符合严格标准的全色温(2700~8000K )的高显色性白光LED 光源。
白光LED 及InG aN 蓝光LED 的光电性能与正向电流I F 密切相关,器件散热极为重要。
提出的在不同I F 下,LED 的相关色温差(Q T c )可用来表征LED 色温变化幅度及稳定性。
关 键 词:荧光体;白光发光二极管;发光;固态照明;稀土激活剂中图分类号:O 482;O 482.31 PACC :7855 文献标识码:A收稿日期:2007-01-04;修订日期:2007-03-29基金项目:国家/8630计划(715-0030060,2006AA03A138);国家自然科学基金(9574053,19774056,59272083,59782004);吉林省科技厅发展计划基金(953514)资助项目作者简介:刘行仁(1937-),男,湖北天门人,研究员,博士生导师,主要从事发光材料基础和应用的研究。
