M08-Routing and Trunking

EDS-308Series8-port unmanaged Ethernet switchesFeatures and Benefits•Relay output warning for power failure and port break alarm •Broadcast storm protection•-40to 75°C operating temperature range (-T models)CertificationsIntroductionThe EDS-308Ethernet switches provide an economical solution for your industrial Ethernet connections.These 8-port switches come with a built-in relay warning function that alerts network engineers when power failures or port breaks occur.In addition,the switches are designed for harsh industrial environments,such as the hazardous locations defined by the Class 1Div.2and ATEX Zone 2standards.The switches comply with FCC,UL,and CE standards and support either a standard operating temperature range of 0to 60°C or a wide operating temperature range of -40to 75°C.All switches in the series undergo a 100%burn-in test to ensure that they fulfill the special needs of industrial automation control applications.The EDS-308switches can be installed easily on a DIN rail or in a distribution box.SpecificationsInput/Output InterfaceAlarm Contact Channels1relay output with current carrying capacity of 1A @24VDCEthernet Interface10/100BaseT(X)Ports (RJ45connector)EDS-308/308-T:8EDS-308-M-SC/308-M-SC-T/308-S-SC/308-S-SC-T/308-S-SC-80:7EDS-308-MM-SC/308-MM-SC-T/308-MM-ST/308-MM-ST-T/308-SS-SC/308-SS-SC-T/308-SS-SC-80:6All models support:Auto negotiation speed Full/Half duplex modeAuto MDI/MDI-X connection100BaseFX Ports (multi-mode SC connector)EDS-308-M-SC:1EDS-308-M-SC-T:1EDS-308-MM-SC:2EDS-308-MM-SC-T:2100BaseFX Ports (multi-mode ST connector)EDS-308-MM-ST:2EDS-308-MM-ST-T:2100BaseFX Ports (single-mode SC connector)EDS-308-S-SC:1EDS-308-S-SC-T:1EDS-308-SS-SC:2EDS-308-SS-SC-T:2100BaseFX Ports (single-mode SC connector,80km)EDS-308-S-SC-80:1EDS-308-SS-SC-80:2Standards IEEE802.3for10BaseTIEEE802.3u for100BaseT(X)and100BaseFXIEEE802.3x for flow controlOptical Fiber800Typical Distance4km5km40km80kmWavelen-gthTypical(nm)130013101550TX Range(nm)1260to13601280to13401530to1570 RX Range(nm)1100to16001100to16001100to1600Optical PowerTX Range(dBm)-10to-200to-50to-5 RX Range(dBm)-3to-32-3to-34-3to-34 Link Budget(dB)122929 Dispersion Penalty(dB)311Note:When connecting a single-mode fiber transceiver,we recommend using anattenuator to prevent damage caused by excessive optical power.Note:Compute the“typical distance”of a specific fiber transceiver as follows:Linkbudget(dB)>dispersion penalty(dB)+total link loss(dB).DIP Switch ConfigurationEthernet Interface Port break alarmSwitch PropertiesMAC Table Size2kbitsPacket Buffer Size768KProcessing Type Store and ForwardPower ParametersInput Current EDS-308/308-T:0.07A@24VDCEDS-308-M-SC/S-SC Series,308-S-SC-80:0.12A@24VDCEDS-308-MM-SC/MM-ST/SS-SC Series,308-SS-SC-80:0.15A@24VDC Connection1removable6-contact terminal block(s)Operating Voltage9.6to60VDCInput Voltage Redundant dual inputs,12/24/48VDCReverse Polarity Protection SupportedOverload Current Protection SupportedPhysical CharacteristicsHousing MetalIP Rating IP30Dimensions53.6x135x105mm(2.11x5.31x4.13in)Weight790g(1.75lb)Installation DIN-rail mounting,Wall mounting(with optional kit) Environmental LimitsOperating Temperature Standard Models:-10to60°C(14to140°F)Wide Temp.Models:-40to75°C(-40to167°F) Storage Temperature(package included)-40to85°C(-40to185°F)Ambient Relative Humidity5to95%(non-condensing)Standards and CertificationsHazardous Locations ATEX,Class I Division2EMI CISPR32,FCC Part15B Class AMaritime DNV-GLEMC EN55032/24Vibration IEC60068-2-6EMS IEC61000-4-2ESD:Contact:6kV;Air:8kVIEC61000-4-3RS:80MHz to1MHz:20V/mIEC61000-4-4EFT:Power:2kV;Signal:1kVIEC61000-4-5Surge:Power:2kV;Signal:2kVIEC61000-4-6CS:10VIEC61000-4-8PFMFSafety UL508,UL60950-1,CSA C22.2No.60950-1 Shock IEC60068-2-27Freefall IEC60068-2-32MTBFTime255,528hrsStandards MIL-HDBK-217FWarrantyWarranty Period5yearsDetails See /warrantyPackage ContentsDevice1x EDS-308Series switchInstallation Kit1x cap,plastic,for SC fiber port2x cap,plastic,for SC fiber port(-SC models)2x cap,plastic,for ST fiber port(-ST models) Documentation1x quick installation guide1x warranty cardDimensionsOrdering InformationModel Name 10/100BaseT(X)PortsRJ45Connector100BaseFX PortsMulti-Mode,SCConnector100BaseFX PortsMulti-Mode,STConnector100BaseFX PortsSingle-Mode,SCConnectorOperating Temp.EDS-3088–––0to60°CEDS-308-T8–––-40to75°C EDS-308-M-SC71––0to60°CEDS-308-M-SC-T71––-40to75°C EDS-308-MM-SC62––0to60°CEDS-308-MM-SC-T62––-40to75°C EDS-308-MM-ST6–2–0to60°CEDS-308-MM-ST-T6–2–-40to75°C EDS-308-S-SC7––10to60°CEDS-308-S-SC-T7––1-40to75°C EDS-308-SS-SC6––20to60°CEDS-308-SS-SC-T6––2-40to75°C EDS-308-S-SC-807––10to60°CEDS-308-SS-SC-806––20to60°C Accessories(sold separately)Power SuppliesDR-120-24120W/2.5A DIN-rail24VDC power supply with universal88to132VAC or176to264VAC input byswitch,or248to370VDC input,-10to60°C operating temperatureDR-452445W/2A DIN-rail24VDC power supply with universal85to264VAC or120to370VDC input,-10to50°C operating temperatureDR-75-2475W/3.2A DIN-rail24VDC power supply with universal85to264VAC or120to370VDC input,-10to60°C operating temperatureMDR-40-24DIN-rail24VDC power supply with40W/1.7A,85to264VAC,or120to370VDC input,-20to70°Coperating temperatureMDR-60-24DIN-rail24VDC power supply with60W/2.5A,85to264VAC,or120to370VDC input,-20to70°Coperating temperatureWall-Mounting KitsWK-46Wall-mounting kit,2plates,8screws,46.5x66.8x1mmRack-Mounting KitsRK-4U19-inch rack-mounting kit©Moxa Inc.All rights reserved.Updated Jan30,2019.This document and any portion thereof may not be reproduced or used in any manner whatsoever without the express written permission of Moxa Inc.Product specifications subject to change without notice.Visit our website for the most up-to-date product information.。

Data SheetKey SpecificationsKey Features•2x2 MU-MIMO with two spatialstreams per radio•Third 2x2 MIMO radio for dedicated RFand WIPS scanning•802.11ac Wave 2 support •Up to 400 Mbps for 2.4 GHz radio •Up to 867 Mbps for 5 GHz radio •Integrated omnidirectional antennas •20/40/80 MHz channel width support •Integrated BLE •2x Gigabit Ethernet port•Full Operational Capacity with 802.3atPoE+•Distributed Data Plane architecture •Zero-touch deployment through automatic cloud activation and configuration •Cloud or on premises management plane options •Operating modes for dedicated access, dedicated security or dual-mode •Support for up to 8 distinct SSIDs per radio •Integrated firewall, traffic shaping, QoS and BYOD controls per SSID •Dynamic RF optimization through smart steering, band steering and optimal channel selection •Application visibility through layer 7 deep packet inspection •Automated device access logging •Patented Marker Packettm technology for rogue AP detection and classification •Wired VLAN monitoring for “No-WiFi” zone enforcement •Third party analytics integration with real-time data transfer •Self-healing wireless mesh networkingTop Performance at the Best PriceArista W-118 is an enterprise-grade 2x2 MU-MIMO tri-radio 802.11ac wall plate access point with dual concurrent 5 GHz and 2.4 GHz radios supporting 802.11a/n/ ac Wave 2, 802.11b/g/n, two spatial streams, and data rates of up to 876 Mbps and 300 Mbps, respectively. It also contains a third 2x2 MIMO 802.11ac radio for dedicated multi-function scanning and a fourth 2.4 GHz Bluetooth Low Energy (BLE) radio.Why Choose the W-118?The W-118 provides best value amongst high-performing, modern wall plate access points designed for cost conscious organizations. Built using the latest 802.11ac Wave 2 chipsets, the W-118 is perfect for medium density environments looking for the high performance and advanced features of current accesspoints without the high cost. Common deployment scenarios include small and medium schools, distributed remote offices, small meeting rooms, and enterprise campuses.The W-118 provides access to advanced access point features like role-based firewalls and application visibility without the high cost typically associated with Wave 2 devices. The W-118 is also a perfect fit for organizations in need of future-ready dedicated security sensorsiBeacon Bluetooth Low Energy SupportThe Arista W-118 supports the iBeacon Bluetooth Low Energy (BLE) standard. BLE is used for proximity based services on mobile devices via an application ecosystem. W-118 can be configured to advertise a unique identifier through iBeacons at a periodic interval.Arista Cloud Managed WiFiThe W-118 is managed by the Arista cloud and leverages a purpose-built cloud architecture to produce enterprise-grade wireless networks for every application required, ensuring high reliability through an approach that is automated, scalable, secure and cost effective.What Really MattersThe future of WiFi requires intelligent, self-reliant access points that support high-performing, highly reliable networks without the need for antiquated controllers. This approach removes the complexity, instability and high costs associated with enterprise WiFi today.Arista W-118AccessThe W-118 creates WiFi networks that require less time and resources to deploy and maintain compared to traditional devices, resulting in significant cost savings.• Plug and play provisioning using either Cloud or On-premise deployments - Arista Access Points take less than two minutes to activate and configure after connecting to the cloud• Support for up to eight individual SSIDs per radio providing maximum flexibility in network design• Network controls like NAT, Firewall and QoS implemented at the Access Point, ensuring faster and more reliable networks• Continuous scanning of all 2.4 GHz and 5 GHz channels by a dedicated 2x2 third radio provides a dynamic, 360 degree view of the RF environment to assist in RF optimization and client handling• Network availability and performance assurance using the third radio as a client to conduct on-demand and scheduled connectivity and performance tests• Smart steering addresses sticky client issues by automatically pushing clients with low data rates to a better access point• Band steering manages channel occupancy, pushing clients to the 5 GHz channel for optimal throughput• Smart load balancing distributes load evenly across neighbouring APs to optimize the use of network resources• Arista Wi-Fi’s distributed data plane architecture continues to serve users and secure the network even if connection with the management plane is interrupted• Interference avoidance from LTE/3G small/macro cells in commonly used TDD/FDD frequency bandsSecurityThe W-118 offers complete visibility and control of the wireless airspace that keeps the integrity of the network in check and actively protects users without manual intervention.•W-118 is equipped with industry leading fully integrated wireless intrusion prevention capabilities•Multifunction third radio provides uninterrupted spectrum scanning or client emulation for always on security coverage alongside dedicated 2.4G/5G client radios.•Arista’s patented Marker PacketsTM help accurately detect rogue access points on any network while minimizing false positives •Third radio used as a dedicated security sensor for 24x7x365 scanning and automated over-the-air (OTA) prevention •Deterministic rogue AP detection and prevention by monitoring all WiFi and non-WiFi VLANs.•Over-the-air and on-the-wire prevention techniques assure automatic and reliable threat prevention to keep unauthorized clientsand rogue APs off the network without impacting authorized connections.•Access Points autonomously scan for wireless threats and enforce security policy even if disconnected from the cloud management plane•VLAN monitoring enables a virtual connection to non-WiFi networks for complete network rogue detection and prevention AnalyticsThe W-118 collects massive amounts of data and supports immersive guest network experiences that develop and reinforce the relationship between them and the brand.• Reports of customer footfall, demographic, loyalty and other analytics provide insightful and actionable information.• Supports proximity marketing programs that trigger when certain devices are present, which includes automatic messaging vis MMSin-browser notifications and real time notifications sent to 3rd party systems that alert to the presence of enrolled devices.Property SpecificationPhysical Dimensions186.4mm X 123.9mm X 25.5mm / 7.3” X 4.9” X 1”Weight .455kg (1 lb)Operating Temperature 0o C – 40o C (32o F – 104o F)Storage Temperature -25o C – 75o C (-13o F – 167o F)MTBF535,205 hr @ 40o C1,081,559 hr @ 25o CHumidity0%-95% non-condensingP ower consuption11.8W (max) / 5.1W (min) / 8.3W (avg)Chipset Qualcomm QCA4019 SOCProcessor RAMQualcomm IPQ4019 717MHz quad core ARMprocessor with 512 MB RAM and 32 MB Flash Physical SpecificationsPort Description Connector Type Speed/ProtocolPower12V 2A5.5mm overalldiameter/2.1mmcenter pin/holePass-throughportThe pass-through port is used to pluga device into another wired port thatis available on the wall where the AP isinstalled. The pass-through port at therear of the device and pass-throughport on the bottom of the device areinternally connected.RJ-45--Ethernet(LAN3/PSE)Gigabit Ethernet port that can be usedfor wired extension for an SSID. Thisport also provides the power for thedevice using the 802.3af standardRJ-4510/100/1000 MbpsGigabit EthernetEthernet(LAN2/LAN1)Gigabit Ethernet port that can be usedfor wired extension for an SSID.RJ-4510/100/1000 MbpsGigabit EthernetReset Reset to factory default settingsPin hole pushbuttonHold down andpower cycle thedevice to resetOperational Specifications Port DescriptionConnectorTypeSpeed/Pro-tocol PassthroughThis is a wired port that facilitatesextension of the wired network after theAP is mounted on the wall. Another devicecan be plugged in to the pass-through porton the bottom of the W-118 device. Thetraffic on the pass-through port does notinterfere with the AP traffic. No policies canbe applied on the pass-through port traffic.RJ-45-WANEnables the connection to wired LANthrough a switch or hub. The device canthen communicate with the server. Thisport also provides the power for the deviceusing the 802.3af standardRJ-4510/100/1000Mbps EthernetPower overEthernetInput Power12V DC 2ANumber of Radios 3 WiFi Radios: One 2.4 GHz and 5 GHz radio each for simultaneous dual band client access. Athird dual-band radio dedicated to non-access smart scanning; WIPS, RF optimization, Remote Troubleshooting, and network assurance functions.1 BLE Radio: A fourth Bluetooth Low Energy radio for proximity based services on mobile devices via an application ecosystem.Max Clients Supported512 clients per radio (dependent upon use cases)MIMO2x2 for 2.4/5GHz RadiosNumber of Spatial Streams 2 for 2.4/5GHz RadiosRF Transmit Power20 dBm per radio chain (max); Actual power for Tx will depend on Country Regulatory Domain Simultaneous MU-MIMO Clients Two 1x1 MU-MIMO clientsUsers in a MU-MIMO group with a2x2 client1Bandwidth Agility YesFrequency Bands 2.4-2.4835 GHz, 4.9-5.0 GHz, 5.15-5.25 GHz (UNII-1), 5.25-5.35 GHz, 5.47-5.6 GHz,5.650-5.725 GHz (UNII-2), 5.725-5.85 GHz (UNII-3)Dynamic Frequency Selection Supported in compliance to all latest amendments from FCC, CE, IC, CB, TELEC, KCC regarding certifications.Frequency, Modulation and Data RatesIEEE 802.11b/g/nFrequency BandScanning TransmissionAll regionsUSA & Canada(FCC/IC)Europe(ETSI) 2400 ~ 2483.5 MHz2400 ~ 2473.5 MHz2400 ~ 2483.5 MHzModulation Type DSSS, OFDMPeak Data Rates Up to 300 Mbps (MCS 0-15)Antenna Integrated modular high efficiency PIFA antenna x4 (peak gain 5.0 dBi)IEEE 802.11a/n/acFrequency Band Scanning TransmissionAll regions USA & Canada(FCC/IC)Europe(ETSI)4.92 ~5.08 GHz5.15 ~ 5.25 GHz 5.25 ~ 5.35 GHz 5.47 ~ 5.725 GHz 5.725 ~ 5.825 GHz 5.15 ~ 5.25 GHz5.25 ~ 5.35 GHz5.725 ~ 5.825 GHz5.15 ~ 5.25 GHz5.25 ~ 5.35 GHz5.47 ~ 5.725 GHzDynamic Frequency Selection DFS and DFS2Modulation Type OFDMPeak Data Rates Up to 867 Mbps (MCS 0-15)Antenna Integrated modular high efficiency PIFA antenna x4 (peak gain 5.0 dBi)Maximum Aggregate Transmit PowerFor 2.4 GHzMCS Index Transmit Power(dBm)802.11b1 Mbps -11 Mbps22802.11g6 Mbps - 48 Mbps2554 Mbps802.11n HT20MCS 0,1,2,3,4,524802.11n HT40MCS 0,1,2,3,4,5 24For 5 GHzMCS Index Transmit Power(dBm)802.11a6 Mbps - 48 Mbps26.802.11n HT20MCS 0,1,2,3,4,526802.11n HT40MCS 0,1,2,3,4,526802.11ac VHT80MCS 0,1,2,3,4,5,6,726Note:The actual transmit power will be the lowest of:• Value specified in the Device Template• Maximum value allowed in the regulatory domain • Maximum power supported by the radioData Sheet Receive SensitivityFor 2.4 GHzMCS Index Receive Sensitivity (dBm)802.11g6 Mbps -9224 Mbps -36 Mbps -48 Mbps -54 Mbps -75802.11n HT20MCS 0, 8 -92MCS 1,9MCS 2,10MCS 3,11MCS 4.12MCS 5,13MCS 6,14MCS 7, 15 -73802.11n HT40MCS 0, 8 -89MCS 1,9MCS 2,10MCS 3,11MCS 4,12MCS 5,13MCS 6,14MCS 7, 15 -71.5 For 5 GHzMCS Index Receive Sensitivity (dBm)802.11a6 Mbps -9024 Mbps36 Mbps48 Mbps54 Mbps -74.5802.11n HT20MCS 0, 8 -90MCS 1,9MCS 2,10MCS 3,11MCS 4,12MCS 5,13MCS 6,14MCS 7,15 -73802.11n HT40MCS 0, 8 -88.5MCS 1,9MCS 2,10MCS 3,11MCS 4,12MCS 5,13MCS 6,14MCS 7, 15 -70For 5 GHzMCS Index Receive Sensitivity (dBm)802.11n VHT20MCS 0 -90MCS 1MCS 2MCS 3MCS 4MCS 5MCS 6MCS 7MCS 8 -69802.11n VHT40MCS 9-65802.11n VHT80MCS 0 -85.5MCS 1MCS 2MCS 3MCS 4MCS 5MCS 6MCS 7MCS 8MCS 9 -61Data Sheet5 GHz2.4 GHzInternal Antenna Radiation Patterns Internal Antenna Radiation Patterns dBi gaindBi gainData SheetHeadquarters5453 Great America Parkway Santa Clara, California 95054408-547-5500Copyright 2020 Arista Networks, Inc. The information contained herein is subject to change without notice. Arista, the Arista logo and EOS are trademarks of Arista Networks. Other product or service names may be trademarks or service marks of others.Support******************408-547-5502866-476-0000Sales****************408-547-5501866-497-0000Ordering Information : Access Point Power Part Number DescriptionAP-W118-SS-5Y W-118 2x2:2 tri radio 802.11ac Wave-2 wall plate access point with internal antennas and 5 year Cognitive Cloud SW SubscriptionAP-W118-SS-3Y W-118 2x2:2 tri radio 802.11ac Wave-2 wall plate access point with internal antennas and 3 year Cognitive Cloud SW SubscriptionAP-W118W-118 2x2:2 tri radio 802.11ac Wave-2 wall plate access point with internal antennas Part Number DescriptionPWR-AP-W4Universal AC power supply for all APs except for C-110PWR-AP-PLUS-NA One port 802.3at PoE+ injector for use with all Access Point models. Includes USA power cord. Not for outdoor use.”PWR-AP-W2Universal AC power supply for C-120, C-130, W-118 and C-100October 1, 2020Regulatory Specifications RF and ElectromagneticCountry CertificationUSA FCC Part 15.247, 15.407EuropeCE EN300.328, EN301.893Countries covered under Europe certification: Austria, Belgium, Cyprus, Denmark, Estonia, Finland, France,Germany, Greece, Hungary, Ireland, Italy, Iceland, Luxembourg, Latvia, Lithuania, Malta, Netherlands, Norway,Poland, Portugal, Spain, Sweden, Slovakia, Slovenia, Switzerland, The Czech Republic, UK.CountryCertificationUSA UL 60950CanadacUL 60950European Union (EU)EN 60950, RoHSSafety*For complete country certification records, please visit the site: https:///en/support/product-certificate AP-W118-R WW-118-R W 2x2:2 tri radio 802.11ac Wave-2 wall plate access point with internal antennas (bundled with Stand, Power supply, Ethernet cable)PWR-AP-W3Non-discountable purchase. Universal AC power supply for W-118, C-120, C-130 and C-100, 12VDC, 2A, Center +, DC Plug 5.5mm*2.1mm*L9.5mm, US UK Euro AU Plugs。

PT-G7828SeriesIEC61850-328-port Layer3full Gigabit modular managed Ethernet switchesFeatures and Benefits•IEC61850-3Edition2Class2compliant•Hot-swappable interface and power modules for continuous operation•Built-in MMS server based on IEC61850-90-4switch data modeling forpower SCADA•IEEE1588hardware time stamp supported•V-ON™ensures millisecond-level multicast data and video network recoveryCertificationsIntroductionThe PT-G7828modular switches provide up to28Gigabit ports,including4fixed ports,6interface module slots,and2power module slots to ensure sufficient flexibility for a variety of applications.The PT-G7828Series is designed to meet evolving network requirements,including a hot-swappable module design that enables you to change or add devices without shutting down your device.The multiple Ethernet modules(RJ45,SFP,and PoE)and power units(24/48VDC,110/220VAC/VDC)provide even greater flexibility as well as suitability for different operating conditions.The switches support a full Gigabit platform that provides enough bandwidth to set up an Ethernet backbone.Certifications include IEC61850Edition2Class2to ensure high availability and wide usage.SpecificationsEthernet Interface10/100/1000BaseT(X)Ports(RJ45connector)2100/1000BaseSFP Ports2Module6Slot Combination See the LM-7000H datasheet for Gigabit Ethernet module and PoE+module informationStandards IEEE802.3for10BaseTIEEE802.3u for100BaseT(X)and100BaseFXIEEE802.3ab for1000BaseT(X)IEEE802.3z for1000BaseXIEEE802.1D-2004for Spanning Tree ProtocolIEEE802.1w for Rapid Spanning Tree ProtocolIEEE802.1p for Class of ServiceIEEE802.1Q for VLAN TaggingIEEE802.1X for authenticationIEEE802.3ad for Port Trunk with LACPIEEE802.3x for flow controlEthernet Software FeaturesManagement IPv4/IPv6,SNMP Inform,SNMPv1/v2c/v3,DHCP Server/Client,DHCP Option66/67/82,BOOTP,TFTP,LLDP,RARP,HTTP,HTTPS,Telnet,Flow control,Back Pressure FlowControl,Port Mirror,Fiber check,Dying Gasp,SMTP,SyslogMIB MIB-II,Ethernet-like MIB,Bridge MIB,P-BRIDGE MIB,Q-BRIDGE MIB,RSTP MIB,RMON MIB Groups1,2,3,9Filter802.1Q,GMRP,GVRP,IGMP v1/v2/v3,QinQ VLANRedundancy Protocols Link Aggregation,MSTP,RSTP,STP,Turbo Chain,Turbo Ring v1/v2,V-ONSecurity RADIUS,TACACS+,SSH,Port Lock,Broadcast storm protection,MAB authentication,Sticky MAC,Access control listTime Management NTP Server/Client,SNTP,IEEE1588v2PTP(hardware-based)Power Substation IEC61850QoS,GOOSE CheckIndustrial Protocols EtherNet/IP,Modbus TCPUnicast Routing Static Route,RIPV1/V2,OSPFMulticast Routing DVMRP,PIM-DMRouting Redundancy VRRPSwitch PropertiesPriority Queues8Max.No.of VLANs512VLAN ID Range VID1to4094IGMP Groups4096MAC Table Size16KPacket Buffer Size12MbitsJumbo Frame Size9.6KBSerial InterfaceConsole Port Micro USB Type BUSB InterfaceStorage Port USB Type APower ParametersInput Voltage24/48VDC,110/220VDC/VACOperating Voltage46to57VDC(>53VDC for PoE+output recommended)Input Current with PWR-LV-P48installed:PWR input current(switch system)Max.0.49A@24VDCMax.0.25A@48VDCEPS input current(PoE system)Max.0.53A@48VDC(excluding power consumption of PoE devices)with PWR-HV-P48installed:PWR input current(switch system)Max.0.12A@110VDCMax.0.07A@220VDCMax.0.29A@110VACMax.0.18A@220VACEPS input current(PoE system)Max.0.53A@48VDC(excluding power consumption of PoE devices)Physical CharacteristicsIP Rating IP30Dimensions443x44x280mm(17.44x1.73x11.02in)Weight3080g(6.8lb)Installation19-inch rack mountingEnvironmental LimitsOperating Temperature-40to85°C(-40to185°F)Storage Temperature(package included)-40to85°C(-40to185°F)Ambient Relative Humidity5to95%(non-condensing)Standards and CertificationsEMC EN55032/24EMI CISPR32,FCC Part15B Class AEMS IEC61000-4-2ESD:Contact:8kV;Air:15kVIEC61000-4-3RS:80MHz to1GHz:20V/mIEC61000-4-4EFT:Power:4kV;Signal:4kVIEC61000-4-5Surge:Power:4kV;Signal:4kVIEC61000-4-6CS:10VIEC61000-4-8PFMFPower Substation IEC61850-3Edition2.0Class2,IEEE1613Railway EN50121-4Safety EN61010-2-201,UL61010-2-201MTBFTime449,542hrsStandards Telcordia(Bellcore),GBWarrantyWarranty Period5yearsDetails See /warrantyPackage ContentsDevice1x PT-G7828Series switchCable USB cable(Type A male to Micro USB type B)Installation Kit2x cap,for Micro-B USB port1x cap,metal,for ABC-02USB storage port2x rack-mounting ear2x cap,plastic,for SFP slotDocumentation1x quick installation guide1x warranty card1x substance disclosure table1x product certificates of quality inspection,Simplified Chinese1x product notice,Simplified ChineseNote SFP modules,modules from the LM-7000H Module Series,and/or modules from thePWR Power Module Series need to be purchased separately for use with this product.DimensionsOrdering InformationModel Name Layer 100/1000Base SFPSlots10/100/1000BaseT(X)PortsRJ45ConnectorPoE Ports,10/100/1000Base T(X)RJ45ConnectorOperating Temp.PT-G782832to262to260to24-40to85°C Accessories(sold separately)LM-7000H Module SeriesLM-7000H-4GPoE Gigabit Ethernet module for PT-G7728/G7828series with410/100/1000BaseT(X)PoE/PoE+ports LM-7000H-4GSFP Gigabit Ethernet module for PT-G7728/G7828series with4100/1000Base SFP slotsLM-7000H-4GTX Gigabit Ethernet module for PT-G7728/G7828series with410/100/1000BaseT(X)portsSoftwareMXview Industrial network management software designed for converged automation networksSFP ModulesSFP-1FELLC-T SFP module with1100Base single-mode with LC connector for80km transmission,-40to85°Coperating temperatureSFP-1FEMLC-T SFP module with1100Base multi-mode with LC connector for4km transmission,-40to85°Coperating temperatureSFP-1FESLC-T SFP module with1100Base single-mode with LC connector for40km transmission,-40to85°Coperating temperatureSFP-1G10ALC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1310nm,RX1550nm,0to60°C operating temperatureSFP-1G10ALC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1310nm,RX1550nm,-40to85°C operating temperatureSFP-1G10BLC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1550nm,RX1310nm,0to60°C operating temperatureSFP-1G10BLC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1550nm,RX1310nm,-40to85°C operating temperatureSFP-1G20ALC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1310nm,RX1550nm,0to60°C operating temperatureSFP-1G20ALC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1310nm,RX1550nm,-40to85°C operating temperatureSFP-1G20BLC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1550nm,RX1310nm,0to60°C operating temperatureSFP-1G20BLC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1550nm,RX1310nm,-40to85°C operating temperatureSFP-1G40ALC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1310nm,RX1550nm,0to60°C operating temperatureSFP-1G40ALC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1310nm,RX1550nm,-40to85°C operating temperatureSFP-1G40BLC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1550nm,RX1310nm,0to60°C operating temperatureSFP-1G40BLC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1550nm,RX1310nm,-40to85°C operating temperatureSFP-1GEZXLC SFP module with11000BaseEZX port with LC connector for110km transmission,0to60°C operatingtemperatureSFP-1GEZXLC-120SFP module with11000BaseEZX port with LC connector for120km transmission,0to60°C operatingtemperatureSFP-1GLHLC SFP module with11000BaseLH port with LC connector for30km transmission,0to60°C operatingtemperatureSFP-1GLHLC-T SFP module with11000BaseLH port with LC connector for30km transmission,-40to85°C operatingtemperatureSFP-1GLHXLC SFP module with11000BaseLHX port with LC connector for40km transmission,0to60°C operatingtemperatureSFP-1GLHXLC-T SFP module with11000BaseLHX port with LC connector for40km transmission,-40to85°Coperating temperatureSFP-1GLSXLC SFP module with11000BaseLSX port with LC connector for500m transmission,0to60°C operatingtemperatureSFP-1GLSXLC-T SFP module with11000BaseLSX port with LC connector for500m transmission,-40to85°Coperating temperatureSFP-1GLXLC SFP module with11000BaseLX port with LC connector for10km transmission,0to60°C operatingtemperatureSFP-1GLXLC-T SFP module with11000BaseLX port with LC connector for10km transmission,-40to85°C operatingtemperatureSFP-1GSXLC SFP module with11000BaseSX port with LC connector for300/550m transmission,0to60°Coperating temperatureSFP-1GSXLC-T SFP module with11000BaseSX port with LC connector for300/550m transmission,-40to85°Coperating temperatureSFP-1GZXLC SFP module with11000BaseZX port with LC connector for80km transmission,0to60°C operatingtemperatureSFP-1GZXLC-T SFP module with11000BaseZX port with LC connector for80km transmission,-40to85°C operatingtemperaturePower SuppliesPWR-HV-P48Power supply module for PT-G7728/G7828series,(110/220VAC/VDC)with system power input,relayand PoE power inputPWR-LV-P48Power supply module for PT-G7728/G7828series,(24/48VDC)with system power input,relay and PoEpower input©Moxa Inc.All rights reserved.Updated Nov12,2018.This document and any portion thereof may not be reproduced or used in any manner whatsoever without the express written permission of Moxa Inc.Product specifications subject to change without notice.Visit our website for the most up-to-date product information.。

Switchesproduct informationThe Allied Telesis GS950 PS Series of WebSmart network switches features PoE+ for connectivity with security cameras, VoIP phones, RFID readers, and wireless access points. The GS950 PS Series is a cost-effective solution for SMB, retail stores, and at the edge of the network.Ease of Management and High PerformanceThese advanced Allied Telesis WebSmart switches integrate the simplicity of unmanaged switches with theperformance and reliability of managed switches to provide a cost-effective, yet secure and reliable, solution for users to integrate management at the edge of their networks. With user-friendly web-based management, the GS950 Series is an ideal option for integrating simple management and security into a network solution.Power over Ethernet Plus (PoE+)The GS950 PS Series is available in PoE configurations of 10-, 16- and 48-port (24 ports PoE capable). All three switches support PoE+ (IEEE 802.3at), with the capability of delivering up to 30W per port (see chart below for max POE+ capable ports).PoE allows users to network and power a device, using a single Ethernet cable, thus eliminating the need for additional power outlets and simplifying thenetwork installation. Also, this system is unaffected by any local variance in AC power, offering a standardized power infrastructure.PoE+, with up to double the power of regular PoE, provides superior power-management capability, as automatic power allocation can be made on the exact requirement of the power device at any given time.VLAN»IEEE 802.1Q tagged »Port-based»Up to 256 groupsQuality of Service Classification»IEEE 802.1p tagging »Port-based priority»Four priority queues per portIP Multicast Support (IPv4)»IGMP snooping (v1/v2)»Static multicast group (up to 256) »Spanning-Tree, IEEE 802.1d/w/sIEEE 802.3ad Link AggregationIEEE 802.1x Port-based and MAC-based Network Access Control»Local authentication server (MD5 only) »Remote authentication through RADIUS »Dynamic VLAN assignmentRADIUS Client DHCP Client DHCP SnoopingStatistics Charts in Web Jumbo Frames - up to 10K Others»IEEE 802.3x flow control or HOL (†) blocking prevention († when flow control is off) »Port mirroring»Destination MAC filtering »Ingress/egress rate limiting »Broadcast storming control »100FX SFP supportKey FeaturesManagement Features»Web-based configuration »Discovery support »SNMP trap view »LLDP»Firmware upgrade by FTP and HTTP»Configuration backup/restore by FTP and HTTP »Factory reset»Password access control and restricted IP access list»SNMPv1/v2c/v3»Management IP: DHCP client for Web »Management and static IP setting »Syslog support»System time configuration (SNTP, manual)MIBs»RFC 1213 MIB-II»RFC 1643 Ethernet MIB »RFC 1493 Bridge MIB »RFC 2131 DHCP client»Private Enterprise MIB (Allied Telesis provides the spec)RMON Groups (1, 2, 3, 9)»Stats »History »Alarms »EventsACL»240 entries (shared)alliedtelesis .comGS950 PS SeriesGIGABIT WEBSMART POE+ EDGE SWITCHESGS950 PS Series | Gigabit WebSmart PoE+ Edge SwitchesSpecificationsPerformance14,880pps for 10Mbps Ethernet 148,800pps for 100Mbps Ethernet 1,488,000pps for 1000Mbps Ethernet MAC addresses 8,000VLAN IDs available 4,000Max VLANs 256Packet buffer 1MB DRAM 64MB Flash 16MBInterface Connections10/100/1000T RJ-45SFP 100TX, 100FX, 1000T, 1000SX or 1000LXEnvironmental ComplianceRoHS Eu-RoHS China RoHS WEEEMTBF263,000 hours Telcordia SR-332Environmental SpecificationsOperating temperature: 0ºC to 40ºC (32ºF to 104ºF)Non-operating temperature: -25ºC to 70ºC (-13ºF to 158ºF)Operating humidity: 5% to 90% non-condensingStorage humidity: 5% to 95% non-condensingVibration: IEC 68-2-36Shock: IEC 68-2-29Drop: IEC 68-2-32Flammability: UL94V-0Technical SpecificationsWall-mount or desktopAll units come with wall /19 in rack-mount bracketsStandards and ComplianceIEEE 802.3 CSMA/CD IEEE 802.3i 10T IEEE 802.3u 100TX IEEE 802.3z 1000SX/LX IEEE 802.3z/ab 1000T IEEE 802.3x Flow controlIEEE 802.1p Prioritization (four queues)IEEE 802.1x AuthenticationIEEE 802.1xLocal authentication server (MD5)IEEE 802.1x Remote authentication through RADIUSIEEE 802.1x Dynamic VLAN assignment IEEE 802.1x MAC-based authentication IEEE 802.1x RADIUS IEEE 802.1d BridgingIEEE 802.3ad Link aggregationIEEE 802.3ad Port trunking and LACP IEEE 802.1Q Tagged VLAN IEEE 802.1d Spanning-TreeIEEE 802.1w Rapid Spanning-Tree IEEE 802.1s Multiple Spanning-TreeWhere xx =10 for US power cord 20 for no power cord 30 for UK power cord40 for Australian power cord 50 for European power cord617-000478 Rev. DPhysical Specifications and MTBF Figures Electrical/Mechanical ApprovalsUL60950-1 2nd edition (UL)FCC/EN55022/CISPR 22 Class A VCCI Class A C-TickEN60950 (TUV)EN55024CE Mark CSA / cULProduct ContentsSwitch unitRack-mount brackets and screws Power cord Rubber feetOrdering InformationGS950 PS SeriesFast Ethernet SwitchesAT-GS950/10PS-xx10-port 10/100/1000T WebSmart switch with 2 SFP combo ports and PoE+AT-GS950/16PS-xx16-port 10/100/1000T WebSmart switch with 2 SFP combo ports and PoE+AT-GS950/48PS-xx48-port 10/100/1000T WebSmart switch with 4 SFP combo ports and PoE+Small Form Pluggable Optics ModulesAT-SPSXSFP, MMF, 1000Mbps, 220/500 m, 850 nm, LC AT-SPLX10SFP, SMF, 1000Mbps, 10 km, 1310 nm, LCAT-SPFX/2SFP, MMF, 100Mbps, 2 km, 1310 nm, LC AT-SPFX/15SFP, SMF, 100Mbps, 15 km, 1310 nm, LCAT-SPBD10-13SFP, SMF, 1000Mbps, 10 km, 1310/1490 nm, LC-BiDiAT-SPBD10-14SFP, SMF, 1000Mbps, 10 km, 1490/1310 nm, LC-BiDialliedtelesis .com© 2014 Allied Telesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners.North America Headquarters | 19800 North Creek Parkway | Suite 100 | Bothell | WA 98011 | USA | T: +1 800 424 4284 | F: +1 425 481 3895Asia-Pacific Headquarters | 11 Tai Seng Link | Singapore | 534182 | T: +65 6383 3832 | F: +65 6383 3830EMEA & CSA Operations | Incheonweg 7 | 1437 EK Rozenburg | The Netherlands | T: +31 20 7950020 | F: +31 20 7950021。

z COMMUNICATION GATEWAY FOR RED LION PRODUCTS z PROTOCOLS AVAILABLE: RS232, RS485 AND ETHERNET z PROGRAMMABLE VIA CRIMSON SOFTWARE z USB PROGRAMMING PORTz PROTOCOL CONVERSION FEATURE CONVERTS NUMEROUS PROTOCOLS SIMULTANEOUSLY z EXTENSIVE BUILT-IN DRIVER LIST ALLOWS EASY DATA MAPPING TO PLCs, PCs, AND SCADA SYSTEMS z 10 BASE-T/100 BASE-TX ETHERNET CONNECTION CANCONNECT TO AN UNLIMITED NUMBER OF DEVICES VIA FOUR PROTOCOLS SIMULTANEOUSLYGENERAL DESCRIPTIONThe ICM8 is designed to act as a communication gateway offering multiple protocol conversion for any Red Lion Product. With two serial ports (one RS232and one RS485) and a 10 Base-T/100 Ethernet Port, the unit performs protocol conversion, allowing disparate devices to communicate seamlessly with one another. Programming the unit can be accomplished via the RS232 or the USB Port using Crimson Software. It is important to note that this device is designed to function with Red Lion Product and will not offer protocol conversion if a Red Lion Products is not connected to at least one of the serial ports.The ICM8’S DIN rail mounting saves time and panel space and snaps easily onto standard top hat (T) profile DIN rail.SOFTWAREThe ICM8 is programmed with Windows ®compatible Crimson 2.0 software.The software is an easy to use graphical interface which can be purchased as part of a kit that includes a manual and cables, or downloaded free of charge from .SAFETY SUMMARYAll safety related regulations, local codes and instructions that appear in the manual or on equipment must be observed to ensure personal safety and to prevent damage to either the instrument or equipment connected to it. If equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired.Do not use the controller to directly command motors, valves, or other actuators not equipped with safeguards. To do so can be potentially harmful to persons or equipment in the event of a fault to the controller. An independent and redundant temperature limit indicator with alarm outputs is strongly recommended.SPECIFICATIONS1. POWER : 24 VDC ± 10% 200 mA max. Must use a Class 2 or SELV rated power supply.2. COMMUNICATIONS :USB/PG Port : Adheres to USB specification 1.1. Device only using Type B connection.Serial Ports : Format and Baud Rates for each port are individually software programmable up to 115,200 baud.RS232/PG Port : RS232 port via RJ12COMMS Ports : RS485 port via RJ11Ethernet Port : 10 BASE-T / 100 BASE-TX 3. LEDs :STS – Status LED indicates condition of ICM8.TX/RX – Transmit/Receive LEDs show serial activity.Ethernet – Link and activity LEDs.4. MEMORY :On-board User Memory: 4 Mbytes of non-volatile Flash memory.On-board SDRAM: 2 MbytesMODEL ICM8 – COMMUNICATION GATEWAYBulletin No. ICM8-A Drawing No. LP0642Released 1/075. CERTIFICATIONS AND COMPLIANCES : SAFETYIEC 1010-1, EN 61010-1: Safety requirements for electrical equipment for measurement, control, and laboratory use, Part 1.ELECTROMAGNETIC COMPATIBILITYEmissions and Immunity to EN 61326: Electrical Equipment forMeasurement, Control and Laboratory use.Notes:1. Criterion A: Normal operation within specified limits.2. Criterion B: Temporary loss of performance from which the unit self-recovers.3. This device was designed for installation in an enclosure. To avoid electrostatic discharge to the unit in environments with static levels above 4 kV precautions should be taken when the device is mounted outside an enclosure. When working in an enclosure (ex. making adjustments, setting switches etc.) typical anti-static precautions should be observed before touching the unit.6. ENVIRONMENTAL CONDITIONS :Operating Temperature Range: 0 to 50°C Storage Temperature Range: -30 to +70°COperating and Storage Humidity: 80% max relative humidity,non-condensing, from 0 to 50°C Altitude: Up to 2000 meters7. CONSTRUCTION : Case body is black high impact plastic and stainless steel. Installation Category I, Pollution Degree 2.8. POWER CONNECTION : Removable wire clamp screw terminal block.Wire Gage Capacity: 24 AWG to 12 AWG Torque: 4.45 to 5.34 in/lb (0.5 to 0.6 N-m)9. MOUNTING : Snaps onto standard DIN style top hat (T) profile mounting rails according to EN50022 -35 x 7.5 and -35 x 15.10. WEIGHT : 12.3 oz (348g)HARDWAREINSTALLATIONFigure 1 - Attach ICM8 To DIN RailPOWER SUPPLY REQUIREMENTSIt is very important that the power supply is mounted correctly if the unit is to operate reliably. Please take care to observe the following points:– The power supply must be mounted close to the unit, with usually not more than 6 feet (1.8 m) of cable between the supply and the ICM8. Ideally, the shortest length possible should be used.– The wire used to connect the ICM8’s power supply should be at least 22-gage wire. If a longer cable run is used, a heavier gage wire should be used.The routing of the cable should be kept away from large contactors,inverters, and other devices which may generate significant electrical noise.– A power supply with a Class 2 or SELV rating is to be used. A Class 2 or SELV power supply provides isolation to accessible circuits from hazardous voltage levels generated by a mains power supply due to single faults. SELV is an acronym for “safety extra-low voltage.” Safety extra-low voltage circuits shall exhibit voltages safe to touch both under normal operating conditions and after a single fault, such as a breakdown of a layer of basic insulation or after the failure of a single component has occurred.Immunity to Industrial Locations :Electrostatic discharge EN 61000-4-2Criterion B 34 kV contact discharge 8 kV air dischargeElectromagnetic RF fields EN 61000-4-3Criterion A10 V/mFast transients (burst)EN 61000-4-4Criterion B2 kV power 1 kV signalSurge EN 61000-4-5Criterion ARF conducted interference EN 61000-4-6Criterion A3 V/rmsEmissions:Emissions EN 55011Class A 1kV L-L,2 kV L&N-E powerEMC INSTALLATION GUIDELINESAlthough Red Lion Controls Products are designed with a high degree of immunity to Electromagnetic Interference (EMI), proper installation and wiring methods must be followed to ensure compatibility in each application. The type of the electrical noise, source or coupling method into a unit may be different for various installations. Cable length, routing, and shield termination are very important and can mean the difference between a successful or troublesome installation. Listed are some EMI guidelines for a successful installation in an industrial environment.1. To reduce the chance of noise spikes entering the unit via the power lines, connections should be made to a clean source. Connecting to circuits that also power loads such as contactors, relays, motors, solenoids etc. should be avoided.2. The unit should be mounted in a metal enclosure, which is properly connected to protective earth.3. Use shielded (screened) cables for all Signal and Control inputs. The shield (screen) pigtail connection should be made as short as possible. The connection point for the shield depends somewhat upon the application. Listed below are the recommended methods of connecting the shield, in order of their effectiveness.a. Connect the shield to earth ground (protective earth) at one end where theunit is mounted.b. Connect the shield to earth ground at both ends of the cable, usually whenthe noise source frequency is over 1 MHz.c. Connect the shield to common of the Data Station and leave the other endof the shield unconnected and insulated from earth ground.4. Never run Signal or Control cables in the same conduit or raceway with AC power lines, conductors feeding motors, solenoids, SCR controls, and heaters, etc. The cables should be run through metal conduit that is properly grounded. This is especially useful in applications where cable runs are long and portable two-way radios are used in close proximity or if the installation is near a commercial radio transmitter. Also, Signal or Control cables within an enclosure should be routed as far away as possible from contactors, control relays, transformers, and other noisy components.5. Long cable runs are more susceptible to EMI pickup than short cable runs. Therefore, keep cable runs as short as possible.6. In extremely high EMI environments, the use of external EMI suppression devices is effective. The following EMI suppression devices (or equivalent) are recommended:Ferrite Suppression Cores for signal and control cables:Fair-Rite part number 0443167251 (RLC part number FCOR0000)TDK part number ZCAT3035-1330ASteward part number 28B2029-0A0Line Filters for input power cables:Schaffner part number FN610-1/07 (RLC part number LFIL0000)Schaffner part number FN670-1.8/07Corcom part number 1 VR3Visit RLC's web site at for more information on EMIguidelines, Safety and CE issues as they relate to Red Lion Controls products. WIRINGPOWER CONNECTIONPROGRAMMING PORTSUSB/PG* Use appropriate communications cable.See Ordering Information for descriptions ofthe available cables.PORT 3 - ETHERNET CONNECTIONRS485COMMUNICATION PORTSICM8 PORT PIN OUTSTROUBLESHOOTING1. This module is designed to operate with Red Lion panel meters only.Please make sure a Red Lion product is connected to either one of the two serial ports for the gateway to be active.2. The Ethernet port is equipped with data LEDs. If they are blinking,the converter is active and the data is available at the port. Please verify the receiving equipment is properly programmed.3. If for any reason you have trouble operating, connecting, or simply have questions concerning your new ICM8, contact Red Lion’s technical support. For contact information, refer to the back page of this bulletin for phone and fax numbers.EMAIL:***********************Web Site: CONFIGURING THE ICM8The ICM8 is configured using Crimson 2.0 software. Crimson 2.0 is available as a free download from Red Lion’s website, or it can be ordered on CD. Updates to Crimson 2.0 for new features and drivers are posted on the website as they become available. By configuring the ICM8 using the latest version of Crimson 2.0, you are assured that your unit has the most up to date feature set. Crimson 2.0 software can configure the ICM8 through the RS232/PG port or USB/PG port. The USB/PG port is connected using a standard USB cable with a Type B connector.The driver needed to use the USB port will be installed with Crimson 2.0.The RS232/PG port uses a programming cable made by Red Lion to connect to the DB9 COM port of your computer. If making your own cable, refer to the “ICM8 Port Pin Outs” for wiring information.CABLES AND DRIVERSRed Lion has a wide range of cables and drivers for use with many different communication types. A list of these drivers and cables along with pin outs is available from Red Lion’s website. New cables and drivers are added on a regular basis. If making your own cable, refer to the “ICM8 Port Pin Outs” for wiring information.ETHERNET COMMUNICATIONSEthernet communications can be established at either 10 BASE-T or 100BASE-TX. The Crimson 2.0 manual contains additional information on Ethernet communications.RS232 PORTSThe ICM8 has one RS232 port. The port can be used for programming or communications.COMMUNICATING WITH THE ICM8RS485 PORTThe ICM8 has one RS485 port.Note: All Red Lion devices connect A to A and B to B, except for Paradigm devices. Refer to for additional information.LEDSSTS – STATUS LEDThe green Status LED provides information regarding the state of the ICM8.This includes indication of the various stages of the start-up routine (power-up),and any errors that may occur.Contact your Red Lion distributor or visit our website for complete selection.2Use this part number to purchase Crimson on CD with a printed manual, USBcable, and RS-232 cable. Otherwise, download free of charge from .3Red Lion offers RJ modular jack adapters. Refer to the DR literature for complete details.This page intentionally left blankLIMITED WARRANTYThe Company warrants the products it manufactures against defects in materials and workmanship for a period limited to two years from the date of shipment, provided the products have been stored, handled, installed, and used under proper conditions. The Company’s liability under this limited warranty shall extend only to the repair or replacement of a defective product, at The Company’s option. The Company disclaims all liability for any affirmation, promise or representation with respect to the products.The customer agrees to hold Red Lion Controls harmless from, defend, and indemnify RLC against damages, claims, and expenses arising out of subsequent sales of RLC products or products containing components manufactured by RLC and based upon personal injuries, deaths, property damage, lost profits, and other matters which Buyer, its employees, or sub-contractors are or may be to any extent liable, including without limitation penalties imposed by the Consumer Product Safety Act (P.L. 92-573) and liability imposed upon any person pursuant to the Magnuson-Moss Warranty Act (P.L. 93-637), as now in effect or as amended hereafter.No warranties expressed or implied are created with respect to The Company’s products except those expressly contained herein. The Customer acknowledges the disclaimers and limitations contained herein and relies on no other warranties or affirmations.。

PT-7528SeriesIEC61850-328-port Layer2managed rackmount EthernetswitchesFeatures and Benefits•IEC61850-3,IEEE1613(power substations)compliant•Built-in MMS server based on IEC61850-90-4switch data modeling forpower SCADA•Noise Guard™wire speed zero packet loss technology•Turbo Ring and Turbo Chain(recovery time<20ms@250switches),1RSTP/STP,and MSTP for network redundancy•Isolated redundant power inputs with universal24VDC,48VDC,or110/220VDC/VAC power supply range•-40to85°C operating temperature rangeCertificationsIntroductionThe PT-7528Series is designed for power substation automation applications that operate in extremely harsh environments.The PT-7528Series supports Moxa’s Noise Guard technology,is compliant with IEC61850-3,and its EMC immunity exceeds IEEE1613Class2standards to ensure zero packet loss while transmitting at wire speed.The PT-7528Series also features critical packet prioritization(GOOSE and SMVs),a built-in MMS server,and a configuration wizard designed specifically for substation automation.With Gigabit Ethernet,redundant ring,and110/220VDC/VAC isolated redundant power supplies,the PT-7528Series further increases the reliability of your communications and saves cabling/wiring costs.The wide range of PT-7528models available support multiple types of port configuration, with up to28copper or24fiber ports,and up to4Gigabit ports.Taken together,these features allow greater flexibility,making the PT-7528Series suitable for a variety of industrial applications.Additional Features and Benefits•Switch data modeling based on the IEC61850-90-4standard •Fiber Check™provides monitoring and diagnosis functions on MST/MSC/SSC/SFP fiber ports•VLAN Unaware:Supports priority-tagged frames to be received by specific IEDs•EtherNet/IP and Modbus TCP industrial Ethernet protocols supported•Configurable by web browser,Telnet/Serial console,CLI,Windows utility,and ABC-02automatic backup configurator•Turbo Ring and Turbo Chain(recovery time<20ms@250 switches),1RSTP/STP,and MSTP for network redundancy •DHCP Option82for IP address assignment with different policies •IGMP snooping and GMRP for filtering multicast traffic from industrial Ethernet protocols•IEEE802.3ad,LACP for optimum bandwidth utilization•Bandwidth management to prevent unpredictable network status •Multiport mirroring for online debugging•Automatic warning by exception through email and relay output •RMON for proactive and efficient network monitoring•Automatic recovery of connected device’s IP addresses•Line-swap fast recovery•Noise Guard™provides a high level of EMC immunity for critical applications,exceeding IEEE1613Class2Cybersecurity Features•User passwords with multiple levels of security protect against unauthorized configuration•SSH/HTTPS is used to encrypt passwords and data•Lock switch ports with802.1X port-based network access control so that only authorized clients can access the port•RADIUS/TACACS+allows you to manage passwords from a central location •802.1Q VLAN allows you to logically partition traffic transmitted between selected switch ports•Secure switch ports so that only specific devices and/or MAC addresses can access the ports•Disable one or more ports to block network traffic•SNMPv3provides encrypted authentication and access security1.Gigabit Ethernet recovery time<50msSpecificationsEthernet Interface10/100BaseT(X)Ports(RJ45connector)PT-7528-4TX Series:4PT-7528-8TX Series:8PT-7528-12TX Series:12PT-7528-16TX Series:16PT-7528-24TX Series:241000BaseSFP Slots PT-7528-4GSFP Series:4100BaseFX Ports(multi-mode SC connector)PT-7528-8MSC Series:8PT-7528-12MSC Series:12PT-7528-16MSC Series:16PT-7528-20MSC Series:20100BaseFX Ports(multi-mode ST connector)PT-7528-8MST Series:8PT-7528-12MST Series:12PT-7528-16MST Series:16PT-7528-20MST Series:20100BaseFX Ports(single-mode SC connector)PT-7528-8SSC Series:8Optical Fiber800Typical Distance4km5km40km80kmWave-length Typical(nm)130013101550TX Range(nm)1260to13601280to13401530to1570 RX Range(nm)1100to16001100to16001100to1600Optical Power TX Range(dBm)-14to-20*0to-50to-5 RX Range(dBm)-3to-32-3to-34-3to-34 Link Budget(dB)122929 Dispersion Penalty(dB)311*This range only applies to the PT-7528multi-mode SC and ST fiber modules.Note:When connecting a single-mode fiber transceiver,we recommend using anattenuator to prevent damage caused by excessive optical power.Note:Compute the“typical distance”of a specific fiber transceiver as follows:Linkbudget(dB)>dispersion penalty(dB)+total link loss(dB).Cabling Direction Front cablingCompatible Modules PT-7528-24TX Series:Slot1:PM-7500-2GTXSP,PM-7500-4GTXSFP,PM-7500-2MSC/4MSC,PM-7500-2MST/4MST,PM-7500-2SSC/4SSCStandards IEEE802.1D-2004for Spanning Tree ProtocolIEEE802.1p for Class of ServiceIEEE802.1Q for VLAN TaggingIEEE802.1s for Multiple Spanning Tree ProtocolIEEE802.1w for Rapid Spanning Tree ProtocolIEEE802.1X for authenticationIEEE802.3for10BaseTIEEE802.3ab for1000BaseT(X)IEEE802.3ad for Port Trunk with LACPIEEE802.3u for100BaseT(X)and100BaseFXIEEE802.3x for flow controlIEEE802.3z for1000BaseSX/LX/LHX/ZXEthernet Software FeaturesFilter802.1Q,GMRP,GVRP,IGMP v1/v2c,Port-based VLAN,VLAN unawareIndustrial Protocols EtherNet/IP,Modbus TCPManagement Back Pressure Flow Control,BOOTP,DHCP Option66/67/82,DHCP Server/Client,Flowcontrol,HTTP,IPv4/IPv6,LLDP,Port Mirror,RARP,RMON,SMTP,SNMP Inform,SNMPv1/v2c/v3,Syslog,Telnet,TFTP,Fiber checkMIB Bridge MIB,Ethernet-like MIB,MIB-II,P-BRIDGE MIB,Q-BRIDGE MIB,RMON MIBGroups1,2,3,9,RSTP MIBPower Substation IEC61850QoS,MMS,Configuration WizardRedundancy Protocols Link Aggregation,MSTP,RSTP,STP,Turbo Chain,Turbo Ring v1/v2Security Broadcast storm protection,HTTPS/SSL,TACACS+,Port Lock,RADIUS,Rate Limit,SSHTime Management NTP Server/Client,SNTPSwitch PropertiesIGMP Groups256Jumbo Frame Size9.6KBMax.No.of VLANs256VLAN ID Range VID1to4094Priority Queues4Switching Capacity12.8GbpsForwarding Capacity12.8GbpsUSB InterfaceStorage Port USB Type ASerial InterfaceConsole Port USB-serial console(Type B connector)Input/Output InterfaceAlarm Contact Channels Resistive load:3A@30VDC,240VACPower ParametersConnection10-pin terminal blockInput Voltage PT-7528-HV-HV/WV-WV/WV-HV Series:Redundant power modulesPT-7528-WV Series:24/48VDC(18to72VDC)PT-7528-HV Series:110/220VAC/VDC(85to264VAC,88to300VDC)Input Current For models with fewer than8fiber ports:PT-7528-WV Series:0.741A@24VDC,0.364A@48VDCPT-7528-HV Series:0.147/0.077A@110/220VDC,0.283/0.190A@110/220VACFor models with8or more fiber ports:PT-7528-WV Series:1.428A@24VDC,0.735A@48VDCPT-7528-HV Series:0.586/0.382A@110/220VAC,0.313/0.167A@110/220VDC Overload Current Protection SupportedReverse Polarity Protection SupportedPhysical CharacteristicsHousing AluminumIP Rating IP40Dimensions(without ears)440x44x325mm(17.32x1.73x12.80in)Weight4900g(10.89lb)Installation19-inch rack mountingEnvironmental LimitsOperating Temperature-40to85°C(-40to185°F)Note:Cold start requires minimum of100VAC@-40°CStorage Temperature(package included)-40to85°C(-40to185°F)Ambient Relative Humidity5to95%(non-condensing)Standards and CertificationsSafety UL508EMI EN55032Class A,CISPR32,FCC Part15B Class AEMS IEC61000-4-2ESD:Contact:8kV;Air:15kVIEC61000-4-3RS:80MHz to1GHz:35V/mIEC61000-4-4EFT:Power:4kV;Signal:4kVIEC61000-4-5Surge:Power:4kV;Signal:4kVIEC61000-4-6CS:10VIEC61000-4-8PFMFIEC61000-4-11DIPsPower Substation IEC61850-3,IEEE1613Class2,Note:Models with MCS and SSC fiber ports arecompliant with IEEE1613Class1Railway EN50121-4Traffic Control NEMA TS2MTBFTime771,320hrsStandards Telcordia SR332WarrantyWarranty Period5yearsDetails See /warrantyPackage ContentsDevice1x PT-7528Series switchCable1x USB type A male to USB type B maleInstallation Kit4x cap,plastic,for RJ45port4x cap,plastic,for SFP slot2x rack-mounting earDocumentation1x document and software CD1x quick installation guide1x product certificates of quality inspection,Simplified Chinese1x product notice,Simplified Chinese1x warranty cardNote SFP modules and/or modules from the PM-7500Module Series need to be purchasedseparately for use with this product.DimensionsOrdering InformationModel Name 1000Base SFPSlots10/100BaseT(X)100BaseFX Input Voltage1Input Voltage2RedundantPower ModuleOperating Temp.PT-7528-24TX-WV-HV –24–24/48VDC110/220VDC/VAC✓-45to85°CPT-7528-24TX-WV–24–24/48VDC––-45to85°CPT-7528-24TX-HV–24–110/220VDC/VAC––-45to85°CPT-7528-24TX-WV-WV–24–24/48VDC24/48VDC✓-45to85°CPT-7528-24TX-HV-HV –24–110/220VDC/VAC110/220VDC/VAC✓-45to85°CPT-7528-8MSC-16TX-4GSFP-WV 4168x multi-mode,SC connector24/48VDC––-45to85°CPT-7528-8MSC-16TX-4GSFP-WV-WV 4168x multi-mode,SC connector24/48VDC24/48VDC✓-45to85°CPT-7528-8MSC-16TX-4GSFP-HV 4168x multi-mode,SC connector110/220VDC/VAC––-45to85°CPT-7528-12MSC-12TX-4GSFP-WV 41212x multi-mode,SC connector24/48VDC––-45to85°CPT-7528-12MSC-12TX-4GSFP-WV-WV 41212x multi-mode,SC connector24/48VDC24/48VDC✓-45to85°CPT-7528-12MSC-12TX-4GSFP-HV 41212x multi-mode,SC connector110/220VDC/VAC––-45to85°CPT-7528-12MSC-12TX-4GSFP-HV-HV 41212x multi-mode,SC connector110/220VDC/VAC110/220VDC/VAC✓-45to85°CPT-7528-16MSC-8TX-4GSFP-WV 4816x multi-mode,SC connector24/48VDC––-45to85°CPT-7528-16MSC-8TX-4GSFP-WV-WV 4816x multi-mode,SC connector24/48VDC24/48VDC✓-45to85°CPT-7528-16MSC-8TX-4GSFP-HV 4816x multi-mode,SC connector110/220VDC/VAC––-45to85°CPT-7528-16MSC-8TX-4GSFP-HV-HV 4816x multi-mode,SC connector110/220VDC/VAC110/220VDC/VAC✓-45to85°CPT-7528-20MSC-4TX-4GSFP-WV 4420x multi-mode,SC connector24/48VDC––-45to85°CPT-7528-20MSC-4TX-4GSFP-WV-WV 4420x multi-mode,SC connector24/48VDC24/48VDC✓-45to85°CPT-7528-20MSC-4TX-4GSFP-HV 4420x multi-mode,SC connector110/220VDC/VAC––-45to85°CPT-7528-20MSC-4TX-4GSFP-HV-HV 4420x multi-mode,SC connector110/220VDC/VAC110/220VDC/VAC✓-45to85°CPT-7528-8SSC-16TX-4GSFP-WV-WV 4168x single-mode,SC connector24/48VDC24/48VDC✓-45to85°CPT-7528-8SSC-16TX-4GSFP-HV-HV 4168x single-mode,SC connector110/220VDC/VAC110/220VDC/VAC✓-45to85°CPT-7528-8MST-16TX-4GSFP-WV 4168x multi-mode,ST connector24/48VDC––-45to85°CPT-7528-8MST-16TX-4GSFP-WV-WV 4168x multi-mode,ST connector24/48VDC24/48VDC✓-45to85°CPT-7528-8MST-16TX-4GSFP-HV 4168x multi-mode,ST connector110/220VDC/VAC––-45to85°CPT-7528-8MST-16TX-4GSFP-HV-HV 4168x multi-mode,ST connector110/220VDC/VAC110/220VDC/VAC✓-45to85°CPT-7528-12MST-12TX-4GSFP-WV 41212x multi-mode,ST connector24/48VDC––-45to85°CPT-7528-12MST-12TX-4GSFP-WV-WV 41212x multi-mode,ST connector24/48VDC24/48VDC✓-45to85°CPT-7528-12MST-12TX-4GSFP-HV 41212x multi-mode,ST connector110/220VDC/VAC––-45to85°CPT-7528-12MST-12TX-4GSFP-HV-HV 41212x multi-mode,ST connector110/220VDC/VAC110/220VDC/VAC✓-45to85°CPT-7528-16MST-8TX-4GSFP-WV 4816x multi-mode,ST connector24/48VDC––-45to85°CPT-7528-16MST-8TX-4GSFP-WV-WV 4816x multi-mode,ST connector24/48VDC24/48VDC✓-45to85°CPT-7528-16MST-8TX-4GSFP-HV 4816x multi-mode,ST connector110/220VDC/VAC––-45to85°CPT-7528-20MST-4TX-4GSFP-WV 4420x multi-mode,ST connector24/48VDC––-45to85°CPT-7528-20MST-4TX-4GSFP-WV-WV 4420x multi-mode,ST connector24/48VDC24/48VDC✓-45to85°CPT-7528-20MST-4TX-4GSFP-HV 4420x multi-mode,ST connector110/220VDC/VAC––-45to85°CPT-7528-20MST-4TX-4GSFP-HV-HV 4420x multi-mode,ST connector110/220VDC/VAC110/220VDC/VAC✓-45to85°CAccessories(sold separately)PM-7500Module SeriesPM-7500-2GTXSFP Gigabit Ethernet module with2100/1000BaseSFP slots or2100/1000BaseT(X)pliant withIEC61850-3.-40to85°C operating temperaturePM-7500-2MSC Fast Ethernet module with2100BaseFX multi-mode ports with SC pliant with IEC61850-3.-40to85°C operating temperaturePM-7500-2MST Fast Ethernet module with2100BaseFX multi-mode ports with ST pliant with IEC61850-3.-40to85°C operating temperaturePM-7500-2SSC Fast Ethernet module with2100BaseFX single-mode ports with SC pliant with IEC61850-3.-40to85°C operating temperaturePM-7500-4GTXSFP Gigabit Ethernet module with4100/1000BaseSFP slots or4100/1000BaseT(X)pliant withIEC61850-3.-40to85°C operating temperaturePM-7500-4MSC Fast Ethernet module with4100BaseFX multi-mode ports with SC pliant with IEC61850-3.-40to85°C operating temperaturePM-7500-4MST Fast Ethernet module with4100BaseFX multi-mode ports with ST pliant with IEC61850-3.-40to85°C operating temperaturePM-7500-4SSC Fast Ethernet module with4100BaseFX single-mode ports with SC pliant with IEC61850-3.-40to85°C operating temperatureStorage KitsABC-02-USB-T Configuration backup and restoration tool,firmware upgrade,and log file storage tool for managedEthernet switches and routers,-40to75°C operating temperatureSFP ModulesSFP-1G10ALC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1310nm,RX1550nm,0to60°C operating temperatureSFP-1G10ALC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1310nm,RX1550nm,-40to85°C operating temperatureSFP-1G10BLC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1550nm,RX1310nm,0to60°C operating temperatureSFP-1G10BLC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1550nm,RX1310nm,-40to85°C operating temperatureSFP-1G20ALC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1310nm,RX1550nm,0to60°C operating temperatureSFP-1G20ALC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1310nm,RX1550nm,-40to85°C operating temperatureSFP-1G20BLC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1550nm,RX1310nm,0to60°C operating temperatureSFP-1G20BLC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1550nm,RX1310nm,-40to85°C operating temperatureSFP-1G40ALC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1310nm,RX1550nm,0to60°C operating temperatureSFP-1G40ALC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1310nm,RX1550nm,-40to85°C operating temperatureSFP-1G40BLC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1550nm,RX1310nm,0to60°C operating temperatureSFP-1G40BLC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1550nm,RX1310nm,-40to85°C operating temperatureSFP-1GEZXLC SFP module with11000BaseEZX port with LC connector for110km transmission,0to60°C operatingtemperatureSFP-1GEZXLC-120SFP module with11000BaseEZX port with LC connector for120km transmission,0to60°C operatingtemperatureSFP-1GLHLC SFP module with11000BaseLH port with LC connector for30km transmission,0to60°C operatingtemperatureSFP-1GLHLC-T SFP module with11000BaseLH port with LC connector for30km transmission,-40to85°C operatingtemperatureSFP-1GLHXLC SFP module with11000BaseLHX port with LC connector for40km transmission,0to60°C operatingtemperatureSFP-1GLHXLC-T SFP module with11000BaseLHX port with LC connector for40km transmission,-40to85°Coperating temperatureSFP-1GLSXLC SFP module with11000BaseLSX port with LC connector for500m transmission,0to60°C operatingtemperatureSFP-1GLSXLC-T SFP module with11000BaseLSX port with LC connector for500m transmission,-40to85°Coperating temperatureSFP-1GLXLC SFP module with11000BaseLX port with LC connector for10km transmission,0to60°C operatingtemperatureSFP-1GLXLC-T SFP module with11000BaseLX port with LC connector for10km transmission,-40to85°C operatingtemperatureSFP-1GSXLC SFP module with11000BaseSX port with LC connector for300/550m transmission,0to60°Coperating temperatureSFP-1GSXLC-T SFP module with11000BaseSX port with LC connector for300/550m transmission,-40to85°Coperating temperatureSFP-1GZXLC SFP module with11000BaseZX port with LC connector for80km transmission,0to60°C operatingtemperatureSFP-1GZXLC-T SFP module with11000BaseZX port with LC connector for80km transmission,-40to85°C operatingtemperatureSFP-1GTXRJ45-T SFP module with11000BaseT port with RJ45connector for100m transmission,-40to75°C operatingtemperatureSoftwareMXview-50Industrial network management software with a license for50nodes(by IP address)MXview-100Industrial network management software with a license for100nodes(by IP address)MXview-250Industrial network management software with a license for250nodes(by IP address)MXview-500Industrial network management software with a license for500nodes(by IP address)MXview-1000Industrial network management software with a license for1000nodes(by IP address)MXview-2000Industrial network management software with a license for2000nodes(by IP address)MXview Upgrade-50License expansion of MXview industrial network management software by50nodes(by IP address)©Moxa Inc.All rights reserved.Updated Aug06,2019.This document and any portion thereof may not be reproduced or used in any manner whatsoever without the express written permission of Moxa Inc.Product specifications subject to change without notice.Visit our website for the most up-to-date product information.。
