西门子产品介绍

MICROMASTER 420一、应用:MICROMASTER 420 变频器适合用于各种变速驱动装置，尤其适合用于水泵，风机和传送带系统的驱动装置。

它的特点是设备性能面向用户的需求，并且使用方便。

它的电源电压规格很多，因而可在世界范围内应用。

二、主要特征1、调试简单2、模块化的结构，因而组态具有最大的灵活性3、具有三个完全可编程的隔离的数字输入4、一个可标定的模拟输入 (0V至 10V) ；它也可以作为第 4个数字输入来使用。

5、一个可编程的模拟输出(0mA 至 20mA)6、一个完全可编程的继电器输出 (30V，直流/5A，电阻负载或 250V，交流/2A，感性负载)7、采用较高的开关频率时，电动机运行的噪声很小 (在脉冲的开关频率较高的情况下，额定输出电流要降格使用)8、完善的变频器和电动机保护功三、可选项 (概览)1、 A 级/B 级 EMC 滤波器2、 LC 滤波器3、进线电抗器4、输出电抗器5、密封盖6、对变频器进行参数化的BOP 基本操作板7、具有多种文本显示功能的高级操作板 AOP8、适合亚洲地区使用的高级操作板A A O P，带有汉语和英语解释的文本显示。

9、通讯模块 PROFIBUS DeviceNet CANopen10、 PC 连接组合件11、控制柜门上安装操作板的组合件12、 PC 调试工具，在 windows95/98 和 NT/2000 /XP Professional下运行13、与Drive ES 的TIA 集成。

四、设计1、 MICROMASTER 420 具有模块化的设计。

操作面板和通讯模块可以不使用任何工具，非常方便地用手进行更换。

西门子G120变频器说明书一、产品概述西门子G120变频器是一种可满足多样化要求的模块化变频器，组件采用模块化设计，功率范围宽，0.55 kW ~ 250kW，可确保始终能够组合出一种满足要求的理想变频器。

该系列变频器提供有三种电压型号，可连接 200 V、400 V 和 690 V 电网。

³西门子G120变频器由两部分组成：控制单元（CU）和功率模块（P M）。

控制单元负责控制和监视功率模块和连接的电机，并提供操作员界面和通信接口。

功率模块负责将输入的交流电转换为可调节的输出电压和频率，以驱动连接的电机。

高效能：采用空间矢量脉宽调制（SVPWM）技术，提高了输出电压的利用率，降低了谐波损耗，提高了效率和功率因数。

高可靠性：采用先进的散热设计，保证了功率模块的稳定运行。

具有过载、过压、欠压、过温、短路等多种保护功能，保证了变频器和电机的安全运行。

高灵活性：提供多种控制单元和功率模块的组合选择，满足不同的应用需求。

支持多种现场总线协议，如PROFINET、PROFIBUS、EtherNet/IP、CANopen、USS、Bacnet、Modbus等，实现与上位控制系统的无缝对接。

高智能化：具有自动调节功能，可根据电机参数和负载情况自动优化控制策略。

具有故障诊断功能，可显示故障代码和故障原因，并提供相应的解决方案。

具有数据备份功能，可将变频器参数保存在存储卡中，方便更换或复制。

二、产品型号G120C：是一种紧凑型变频器，集成了控制单元和功率模块于一体，适用于简单的应用场合，如风机、水泵等。

功率范围为0.55 kW ~ 18.5 kW。

G120 CU240B-2/CU240E-2：是一种标准型变频器，采用分离式的控制单元和功率模块，适用于中等复杂度的应用场合，如输送机、起重机等。

功率范围为0.55 kW ~ 132 kW。

G120 CU250S-2：是一种高性能型变频器，采用分离式的控制单元和功率模块，适用于高精度和高动态性能要求的应用场合，如数控机床、纺织机械等。

产品介绍产品特点 (2)产品外形图 (3)安全注意事项 (3)电器连接 (4)产品标准 (4)安装安装注意事项 (5)安装步骤 (6) (9)环保/节约注意事项 (9)控制面板结构图 (10)控制面板功能及操作说明 (10)保养维护外部清洁 (16)内部清洁 (16)疑难解答常见故障分析与排除 (17)电路图及技术参数电路图 (18)技术参数 (19)装箱单装箱单 (20)非常感谢您选购了西门子电热水器！为了保证您和家人能最佳体验这款性能卓越的产品，请仔细阅读本说明书。

目录机产品特点 1. 舒适与节能⏹ 热水输出高，适合多点供水，多路热水同时使用。

⏹ 有本机控制和线控两种使用方式，方便用户使用。

LED 显示温度，随时随地了解水温变化。

⏹ 时间预约功能，灵活控制。

⏹ 具有温度显示，加热指示，运行状态一目了然。

⏹ “谷时”功能，热水器在满足基本用水的前提下，充分利用谷电时段来加热，节约电费。

⏹ “即时加热”当用户临时大量用水时，可以启动即时加热功能满足用水需求。

⏹ “插入式加热”当用户需要更多用水时，可一次性加热至所设水温。

⏹ 热水器采用整体式环戊烷发泡技术，多点绝热技术，节能环保。

2. 安全与耐用⏹ 微电脑控制；可靠的电气设计，强电与弱电控制分离，确保用户安全。

⏹ 欧洲最先进的自动焊接技术、超厚钢质内胆、进口搪瓷粉附着均匀，牢固，耐高温，耐压，耐腐蚀，确保内胆长寿命。

⏹ 国际一流不锈钢加热管，智能防干烧；内置式感温装置，自带传感器故障保护功能。

⏹ 一旦接地系统异常时，能够提供应急防护措施。

⏹ 防冻结功能，使用更安全，在严寒条件时提供安全保障。

⏹ 热水器具有“阳极消耗指示”功能⏹ 采用普通牺牲阳极的产品，用户被随时告知阳极是否有效，何时需要更换。

此项功能，可以避免用户在不知情的情况下，由于内胆欠保护而腐蚀漏水，造成不必要的财产损失。

产品介绍机机产品外形图1 外壳2 阳极棒更换口3 出水口4 进水口5 电源线6 控制器7 挂板8 维修盖板9 出线盖板安全注意事项 ⏹ 电热水器在安装前，首先要确定安装环境的电源容量及电源配线是否满足电热水器功率的要求（电热水器参数详见电热水器铭牌）。

■ 上海西门子开关有限公司2的严格管理不仅贯穿于内部生产的各个流程，同时延伸至对供应商的日年在闵行经年底公司二期厂房扩建工程的竣平方米，体现了西门子根植于中国、长期服务于中国客户的信心和承诺。

2004年研发中心作为西门子输配电全球研发中心的组成部分，可同步共享西门子最新的技术和资源。

通过预测客户的需求，开发质量稳定可靠的创新型产品和为客户度身定制方案，使客户的业务增值。

一支反应迅速、装备精良、经验丰富的售后服务队伍和遍布全国的服务网点构成了公司一套高效的现场服务应对系统，负责指导产品现场安装和操作，并承诺在最短时间内对紧急情况作出应对，将客户的断电年位列上海市年被上海市电器行业协会评为行业名优产品。

公司因其良好的商业信誉被评为“守合同重信而被电气时代以及专3AH3及面向全球同步发售所有产品均在西安高压电器研究所通过型式试验，确保产品的运行安全和操作人员的人身安全。

目 录ContentsSiemens Switchgear Ltd., Shanghai (SSLS) is a joint venture of Siemens Ltd., China (SLC) and Shanghai Power Transmission & Distribution Company, holding the manufacturing license to apply the latest tech-nology of Siemens vacuum circuit-breaker and medium voltage switchgear in P. R. China.Since established in 1993, relying on Siemens powerful resources and internal boundless cooperation, SSLS has provided reliable products, first-class service and innovative solutions for more than two thousand key projects both for domestic and overseas. SSLS has established a good reputation and leading position in China due to its large contribu-tion to the technique innovation and development of local switchgear industry.SSLS is a market oriented company with commitment to customers’satisfaction and to fulfill the demands for the medium voltage switchgear, with high quality and excellent reliability, by means of dynamically intro-ducing and constantly developing the applicable technique and prod-ucts to the local market. Customer’s success is our first priority. We pledge to provide the most value-added product and service, promise on-time delivery, and establish solid business partner relationship with customers, in result to create the maximum value for our customers.SSLS began to implement the customer-oriented quality management early in1996, and established a comprehensive quality management system in 2004 integrated with ISO9001, ISO14001 and OHSAS18001. The company utilizes the highly sophisticated machines and testing fa-cilities in production process. The high qualification of operators along with continuous in process quality control guarantee our well established and high quality standards at all times. The strict quality control is not only carried out throughout entire production processes, but also ex-tended to the daily management of our suppliers. We take environment protection as our social responsibility; meanwhile closely look after employees’ occupational safety and health.To meet the growing marketing demands, a modern factory was built up in Minhang Economic & Technological Development Zone in 2004. With the completion of second phase expansion at the end of 2006, the land plot increased to 50000sqm and shop floor to 23000sqm, which em-bodies Siemens’ commitment to root in China and serve long-term for Chinese customers.According to company’s strategy to create more competence and shorter time-to-market, SSLS R&D center was established in 2004. R&D cen-ter closely integrates into the Siemens PTD global R&D network, could share the latest Siemens technique and resources in-phase. By pre-dicting the market needs, SSLS fosters R&D in developing reliable and innovative products and tailored solutions to add value for customer’s business.Siemens switchgear has an effective system of on-site servicing from a quick-respondent, well-equipped and rich experienced field service team and a network setup all over China. The team is responsible for the guidance of on-site installation and operational safety, commit to re-spond to emergency calls within the shortest possible time and to mini-mize down time.SSLS was ranged as the Top 500 Revenue of Industrial Companies in Shanghai 7 years in row since 2000. The products won the title of Shang-hai Reputed Product 4 years in row since 2003. The company was awarded as “Good Credit Enterprise” due to its high commercial credit, and won the title of “Top 10 Fast-growing Companies in China Electric Industry” in 2006 due to over 30% increase of sales revenue continu-ously over the past three years.PRODUCT INTRODUCTIONSSLS provides air insulated Switchgear rated from 7.2 to 24kV with type 8BK20, 8BK30, 8BK40 and specially designed for Chinese market in 2007 NXAIR S, and vacuum circuit breakers type 3AH3, 3AH5, 3AH2-EP as well as SION, the latest generation of Siemens VCB synchro-nously selling world wide.All products are type tested in XIHARI to ensure the safety of personnel and operation.公司简介Company Introduction■产品介绍3■ 上海西门子开关有限公司4● Draw-out section and access door fully inte-grated interlock system.● Safe and easy draw-out section movementbehind closed cubicle door.● Easy draw-out section transfer or exchange,using central service truck, independent of floor quality.● Earthed metal partitions and shutters.● Connection of HV cables is available from front or rear part of the panel optionally.● Back-to-back or face-to-face designs available for double bus-bar design.●Reinforced insulation which fulfills Chinese system and local climate.●Direct line-up with 8BK30 Vacuum ContactorSwitchgear.● 可移开部分与柜门之间有可靠的联锁● 前门关闭后，能够很安全而且容易地移动可移开部分● 先进的中置式结构，使用专门的小车能够方便地搬运或更换可移开部分，不受现场地面平整度的限制● 金属隔板与活门均接地● 根据用户需要，可由前门或开关柜的后部进行电缆接线● 开关柜可以面对面布置，也可以背靠背布置(双母线回路)●加强了绝缘，更适合中国电力系统和气候● 可直接与8BK30型开关柜(F - C 回路)联接供电典型客户上海供电局北京供电局兰溪电厂秦皇岛港口宁波小港纸业兰州石化TYPICAL CUSTOMER Shanghai PSBBeijing PSBLanxi Power PlantQinghuangdao HarborNingbo Xiaogang Paper MillLanzhou Petro 产品特点SPECIFIC FEATURES 电气技术数据 ELECTRICAL DATA (MAXIMUM VALUES )8BK20 Switchgear with Draw-Out Circuit-Breakers, Air-Insulated, Metal Clad8BK20型金属封闭/铠装可移开式空气绝缘断路器柜■ 产品介绍5● Draw-out section and door integrated in the inter-lock system.● Minimal space requirement.● Vacuum contactor and HVHRC fuses on draw-outsection. Vacuum contactor is able to operate fre-quently due to its long mechanic life-1 millionoperations.● Draw-out section easily to move inside the cubicle.● Cable connection in front of cubicle.● Directly line-up with circuit-breaker panel of type 8BK20.● Special wheels on bottom of draw-out section provide an easy movement during in and out the cubicle.● Reinforced insulation to meet Chinese system andlocal climate.● 可移开部分与室门之间装有可靠的联锁装置● 占用空间少● 可移开部分装有真空接触器和高压限流熔断器。

西门子S7-1200小型PLC 介绍
西门子控制器系列是一个完整的产品组合，包括从高性能可编程逻辑控制器的书本型迷你控制器LOGO!到基于PC 的控制器，无论多么苛刻的要求，它都能满足要求—根据具体应用需求及预算，灵活组合、定制(系列化的控制器家族产品满足你的不同应用及需求)。

西门子S7-1200小型PLC充分满足于中小型自动化的系统需求。

在研发过程中充分考虑了系统、控制器、人机界面和软件的无缝整合和高效协调的需求。

SIMATIC S7-1200 系列的问世，标志着西门子在原有产品系列基础上拓展了产品版图，代表了未来小型可编程控制器的发展方向，西门子也将一如既往开拓创新，引领自动化潮流。

西门子S7-1200小型PLC具有集成 PROFINET 接口、强大的集成工艺功能和灵活的可扩展性等特点，为各种工艺任务提供了简单的通信。

Siemens GBS PortfolioMedium Voltage & SystemsRestricted © Siemens AG 2017/generatorswitchgearA Tale of Two Technologies For MV Generator Breaker SwitchgearSF6 VacuumVacuum Technology – Success Story Overview of the global market share of MV Circuit Breakers Market Penetration of vacuum breakers for MV•In 1980 – 20%•Nowadays – around 80%Reasons for success•High number of operation cycles•Preservation of the quality of the vacuumthroughout the entire life time•No monitoring system required •Maintenance-free •Environmentally friendly •Compact construction194656 6165 7075 8071520222220202036282417 1310 50%10%20%30%40%50%60%70%80%90%100%19801985199019952000200520102015 MarketShareforMVCircuitBreakersVacuum SF6Magnetic Min. Oil Bulk OilAdvantages of Vacuum Interruption over GasVacuum Interrupters are sealed for life•Breaking capability not affected by pressure and temperature of gas• No maintenance and monitoring of contact system• No capacitor required for High short circuit applications• No low ambient temperature concernsSpring-Spring Drive Mechanism•Opening time and speed are not affected by pressure andtemperature of hydraulic oil• No blocking of trip on low gas/hydraulic pressureNumber of Operations:• 10,000 operation electrical and mechanical cycles at rated current• 30 interruptions at 100% of short circuit current• 300 interruptions at 10-100% of short circuit currentSiemens TechnologyComparison of Lifecycle CostsLifecycleC o s t sMinimum operational andmaintenance costsG C BVacuumSignificantly lower lifecycle costGCBPurchase priceHigher number of switching operationsBreaking current [kA]O p e r a t i n g c y c l e sInstallation costSF61101001000100001000000.1110100Vacuum GCB -100kA (*)SF6 GCB -100kA (**)(*) SF6 GCB according to manualHECS – 100L document no. 1HC0066312 AC D01 Up to 70% reduction in lifecycle costsGenerator Circuit-Breaker Switchgear PortfolioHB1 - Horizontal BusbarRemovable type up to 170 MW up to 24 kV up to 6,700 A up to 72 kA, 1 sHB3 - Horizontal BusbarRemovable type up to 400 MW up to 24 kV up to 12,500 A up to 100 kA, 3 sVB1 – Vertical busbarRemovable type up to 140 MW up to 24 kV up to 5,500 A up to 72 kA, 1 sVB1-D – Vertical busbar, DrawableWithdrawable type up to 110 MW up to 17.5 kV up to 5,100 A up to 63 kA, 3 sGM-SGWithdrawable type, ANSI up to 80 MW up to 15 kV up to 4,000 A up to 63 kA, 3 sNXAIRWithdrawable type, IECup to 50 MW up to 17.5 kV up to 4,000 A up to 50 kA, 3 sGenerator Circuit-Breaker Switchgear GM-SG – Technical Data Application:Practical range 10 - 80 MW GeneratorsRatings:•U r:15 kV•I r:up to 3,000 A (4,000 A - forced cooling) •I sc (3 s):up to 63 k ABreaker types:•Type tested to IEEE C37.013a•Arc Resistant - Type 2B Dimensions:•914 x 2,507 x 2,419 mm (W x D x H) Installation•Indoor or outdoor application Connection methods •Cable•Bus ductsDegree of protection NEMA1 / NEMA3RRetrofit SolutionsMedium Voltage & SystemsRestricted © Siemens AG 2017/generatorswitchgearContact InformationDanish Mirza BaigBusiness Developer,Energy Management, Medium VoltageCalgary, ABMobile: +1 (403) 607-7617E-mail: ***********************siemens.ca/energymanagementSiemens Canada 2018Seite 50 /generatorswitchgear。

/diagnosticsADVIA, Aptio, HemaPrep,Hematek, and all associated marks are trademarks of Siemens Healthcare Diagnostics Inc. or its affiliates. CellaVision is a trademark ofCellaVision AB. All other trademarks and brands are the property of their respective owners. Product availability may vary from country to country and is subject to varyingregulatory requirements. Please contact your local representative for availability.Order No. A91DX-HHS-150744-UC1-4A00 05-2015 | All rights reserved© 2015 Siemens Healthcare Diagnostics Inc.Global DivisionS iemens Healthcare Diagnostics Inc.511 Benedict AvenueTarrytown, NY 10591-5005 USA/diagnosticsGlobal Siemens Headquarters Siemens AGWittelsbacherplatz 280333 Muenchen GermanyGlobal Siemens Healthcare HeadquartersSiemens AG, Healthcare Henkestrasse 12791052 Erlangen GermanyTelephone: +49 9131 84-0 /healthcareScalable Hematology Systems:Offering the Right Fit for Every LaboratoryADVIA 360, ADVIA 560, and ADVIA 560 AL Hematology SystemsThe Siemens Family of Hematology Analyzers: Scalable Solutions that Evolve with Your Needs While the driving trend in today’s clinical testingenvironment is consolidation, not every laboratory is affected by this paradigm shift. With major swings in testing volumes from laboratory to laboratory and network to network, one model does not fit all. Such diversity in laboratory workload builds a demand for diversity in analyzers—and scalable options are paramount.Scalable Hematology TestingOptions to Meet Your Laboratory’s Unique ChallengesSiemens now offers feature-rich, lower-capacityhematology testing systems with the flexibility to scale up to meet increases in testing demands. No matter what your capacity requirements, Siemens offers the system to fit your needs. With the ADVIA® 360 System, ADVIA 560 System, and ADVIA 560 AL System, Siemens offersstate-of-the-art hematology testing capabilities for small to mid-sized laboratories—or as back-up for systems in your main laboratory.The ADVIA 360, ADVIA 560,and ADVIA 560 AL Hematology SystemsThree options to fit your workflow needs and budgetThe low- and mid-volume family of ADVIA hematology systems offers cost-efficient solutions for various hematology testing volumes and environments. The systems help optimize and manage workflow through convenient features, including the choice of open- or closed-tube sampling, and customizable result printing. Automatic anti-clogging and cleaning procedures are employed after every fifteenth sample to ensure reliability of results. Along with automated maintenance, this reduces manual procedures and biohazard exposure.Fast, high-quality CBC testing in any laboratory environmentFast, reliable, and flexible, these systems can run up to 60 samples per hour. The systems have been engineered for safety and ease-of-operation, and deliver a wealth of user benefits, including:Intuitive hardware features for accurate and rapid results• C ap-piercing function for accurate sampling and reduced biohazard risk • Easy-to-operate color touchscreen with intuitive icon-based software • Choice of manual or automatic calibration procedures • H andheld bar-code reader for easy entry of patient ID and control information• Result printing does not delay tests in progressIntuitive software features and customizable options• Multilingual operating menu enables usability among diverse staff • B idirectional LIS communication facilitates easy patient data transfer between laboratories and minimizes paper-based work lists• F lexible and efficient interface enables uploading reference data via USB and QR codes• C ustomizable printing options include tabular reports• B uilt-in diagnostic flagging system automatically alerts operator of abnormal resultsYour Laboratory Requirementsare EvolvingADVIA 360 Hematology SystemADVIA 560 Hematology SystemADVIA 560 AL Hematology SystemADVIA 360 Hematology SystemCompact footprint and remarkable accuracy in a cost-efficient systemThe ADVIA 360 System allows smaller laboratories to efficiently generate reliable and accurate results. With a compact footprint, the ADVIA 360 System conserves precious benchtop space.• Runs up to 60 samples per hour• Processes aspiration volumes as low as 100 μL• F acilitates efficient manual sampling of both open and closed tubes• M easures 16 parameters, including a 3-part white blood cell differential • Provides storage capacity of 10,000 results • S treamlines result reporting via an integrated ticket printerADVIA 560 and 560 AL Hematology SystemsMaximum output with minimal user interventionThe ADVIA 560 System can serve as the primaryhematology analyzer in small to mid-sized laboratories, or as a backup for the ADVIA 2120i System in largerlaboratories. The ADVIA 560 AL System offers automatic sampling with an optional autoloader that can be added to the system at any time to adapt to your ever-evolving needs.Optimal performance and adaptabilityThe ADVIA 560 System offers the same convenience and safety features of the ADVIA 360 System, with the following capabilities:• Runs up to 60 samples per hour• Processes aspiration volumes as low as 110 μL • F acilitates efficient manual sampling of both open and closed tubes• M easures 20 parameters and employs laser-based optical measurement to provide a 5-part white blood cell differential• Provides storage capacity of up to 100,000 results • A ids in interpreting disease-state information with two scattergrams and two histograms per resultADVIA 560 AL System with AutoloaderA true “walk-away” systemFor even greater workflow efficiency, the ADVIA 560 AL System streamlines automated sampling. The autoloader simply plugs into the side of the system and provides even more convenient features, including:• 100 primary sample tube capacity (10 racks of 10 sample tubes each)• Ability to accept a variety of tubes• O nboard mixing system and cap-recognition sensor to ensure that only cap piercable tubes are mixed and processed• I ntegrated bar-code reader for positive sample ID • F lexibility to add the autoloader to anyADVIA 560 System at any timeSiemens scalable hematology systemsoffer the right fit for youThe Siemens family of hematology systems offers a systematic, end-to-end approach specifically designed to adapt to your changing needs. Our scalable system portfolio enables laboratories of all sizes to benefit from reliable, easy-to-use, and cost-efficient hematology solutions. From manual staining to fully automated slide creation, staining and analysis, we have a solutionto meet your needs. Our broad portfolio is adaptable enough to support even the largest laboratory, offering track-based automation and multidisciplinary connectivity, with integrated chemistry, immunoassay, and hematology testing systems.•H emaPrep® Automated Blood Smearing Systemoffers simple and consistent creation of blood films•H ematek® 3000 System standardizes semi-automated slide staining• A DVIA 360 System processes up to 60 CBCs and3-part differentials per hour• A DVIA 560 System processes up to 60 CBCs and5-part differentials per hour• A DVIA 560 AL System automates processing of CBCsand 5-part differentials• C ellaVision® DM1200 Digital Microscopy Systempreclassifies cells and offers a review rate of up to20 slides per hour• C ellaVision DM9600 Digital Microscopy Systempreclassifies cells and offers a review rate of up to35 slides per hour• A DVIA 2120i System automates the processingof up to 120 CBC/Diff samples per hour• A DVIA Autoslide System streamlines automated,reflexive, slide-making and staining•A ptio™ Automation enablesmulti-disciplinary connectivityWith Siemens as your primary diagnostic equipmentpartner, you enjoy a broad range of benefits including:• E ase of ordering to reduce accounting andprocurement hassles• C onvenient and comprehensive training and educationto enhance productivity• I ndustry-leading Siemens service and support to minimizeunnecessary downtimeLearn more about the entire family of scalableSiemens hematology systems.Visit /hematology,or contact your local Siemens sales representative.。
