Verilog实现串⼝接收多帧数据
`timescale 1ns / 1ps
//////////////////////////////////////////////////////////////////////////////////
// Company:
// Engineer:
//
// Create Date: 19:50:45 04/19/2015
// Design Name:
// Module Name: Serial_Decoder
// Project Name:
// Target Devices:
// Tool versions:
// Description:
//
// Dependencies:
//
// Revision:
// Revision 0.01 - File Created
// Additional Comments:
//
//////////////////////////////////////////////////////////////////////////////////
module Serial_Decoder(
input wire clk_seri, //串⼝时钟，⽤于从串⼝发送命令给FPGA
input wire rst,
input wire RxD,
output reg[1:0] modu_sel, //BPSK,QPSK,8PSK选择
output reg[13:0] ser_asf, //由串⼝发过来的asf
output reg[31:0] ser_ftw, //由串⼝发过来的ftw
output reg cmd_done, //上位机给FPGA发送指令结束
output reg[31:0] dina, //ROM存储器，⽤于存储外部PN码
output reg wea,
output reg[1:0] addra
);
reg cmd_rdy;//指令接收完成
reg [3:0] instr_code;//⽤于分辨命令，是asf还是ftw还是外部PN码reg [31:0] cmd_data; //接收从上层发过来的命令
wire RxD_data_ready;
wire [7:0] RxD_data;
reg [1:0] instr_cnt;
reg data_rec_valid;
reg data_rec_busy;
reg [1:0] data_cnt;
//instance
receiver i_receiver(
.clk(clk_seri),
.RxD(RxD),
.RxD_data_ready(RxD_data_ready),
.RxD_data_error(),
.RxD_data(RxD_data)
);
//*********上位机发命令给FPGA************//
always @ (posedge clk_seri)
begin
if(rst)
begin
instr_cnt <= 0;
data_rec_valid <= 0;
end
else if(RxD_data_ready && !data_rec_busy)
case(instr_cnt)
2'd0:
if(RxD_data == 8'h55)
begin
instr_cnt <= 2'd1;
data_rec_valid <= 0;
end
else
begin
instr_cnt <= 2'd0;
data_rec_valid <= 0;end
2'd1:
if(RxD_data == 8'h55)
begin
instr_cnt <= 2'd2;
data_rec_valid <= 0;
end
else
begin
instr_cnt <= 2'd0;
data_rec_valid <= 0;
end
2'd2:
if(RxD_data == 8'h55)
begin
instr_cnt <= 2'd3;
data_rec_valid <= 0;
end
else
begin
instr_cnt <= 2'd0;
data_rec_valid <= 0;
end
2'd3:
if(RxD_data == 8'h55)
begin
instr_cnt <= 2'd3;
data_rec_valid <= 0;
end
else
begin
instr_cnt <= 2'd0;
data_rec_valid <= 1;
instr_code <= RxD_data[3:0]; //⽤来分辨各命令
enddefault:
begin
instr_cnt <= 2'd0;
data_rec_valid <= 0;
end
endcase
else
data_rec_valid <= 0;
end
always @ (posedge clk_seri)
begin
if(rst)
begin
data_cnt <= 2'd0;
data_rec_busy <= 0;
cmd_rdy <= 0;
end
else if(data_rec_valid)
begin
data_cnt <= 0;
data_rec_busy <= 1;
cmd_rdy <= 0;
end
else if(RxD_data_ready && data_rec_busy)
case(data_cnt)
2'd0:
begin
data_cnt <= 2'd1;
data_rec_busy <= 1;
cmd_rdy <= 0;
cmd_data[31:24]<= RxD_data;
end
2'd1:
begin
data_cnt <= 2'd2;data_rec_busy <= 1;
cmd_rdy <= 0;
cmd_data[23:16]<= RxD_data;
end
2'd2:
begin
data_cnt <= 2'd3;
data_rec_busy <= 1;
cmd_rdy <= 0;
cmd_data[15:8] <= RxD_data;
end
2'd3:
begin
data_cnt <= 2'd0;
data_rec_busy <= 0;
cmd_rdy <= 1; //命令接收完毕
cmd_data[7:0] <= RxD_data;
end
default:
begin
data_cnt <= 2'd0;
data_rec_busy <= 0;
cmd_rdy <= 0;
end
endcase
else
cmd_rdy <= 0;
end
//*********分辨命令*********//
always @ (posedge clk_seri)
begin
if(rst)
begin
cmd_done <= 0;
modu_sel <= 0;ser_asf <= 0;
ser_ftw <= 0;
end
else if(cmd_rdy)
begin
case(instr_code)
4'h6:
begin
ser_ftw <= cmd_data;
cmd_done <= 0;
end
4'h7:
begin
modu_sel <= cmd_data[25:24];
cmd_done <= 0;
end
4'h8:
begin
ser_asf <= cmd_data[13:0];
cmd_done <= 0;
end
4'hF:
cmd_done <= 1; //上位机命令发送结束default:;
endcase
end
else
begin
ser_ftw <= ser_ftw;
ser_asf <= ser_asf;
modu_sel<= modu_sel;
cmd_done<= cmd_done;
end
end
always @ (posedge clk_seri)
beginif(rst)
begin
dina <= 0;
wea <= 1;
addra <= 0;
end
else if(cmd_rdy)
begin
case(instr_code)
//********A--D是外部PN码，将其存⼊ROM中********//
4'hA:
begin
dina <= cmd_data;
wea <= 1;
addra <= 2'd0;
end
4'hB:
begin
dina <= cmd_data;
wea <= 1;
addra <= 2'd1;
end
4'hC:
begin
dina <= cmd_data;
wea <= 1;
addra <= 2'd2;
end
4'hD:
begin
dina <= cmd_data;
addra <= 2'd3;
wea <= 0;
end
default:;
