材料工程外文翻译--Mg-9Al-1Zn合金的半固体挤压成型

Mg-Al系镁合金半固态坯料制备及触变挤压研究王迎;姜巨福;孙毅;曲建俊;杜之明;罗守靖【期刊名称】《特种铸造及有色合金》【年(卷),期】2009(0)11【摘要】采用拉伸试验机、金相显微镜和等径道角挤压等试验方法对Mg-Al系镁合金半固态坯料制备及触变挤压过程进行了研究。

结果表明,等径道角挤压工艺对Mg-Al系镁合金有很好的应变诱导效果。

经过等径道角挤压的Mg-Al系镁合金力学性能高,晶粒细小。

等径道角挤压+等温处理方法制备的Mg-Al系镁合金半固态坯的微观组织晶粒细小,球化程度高,微观组织非常均匀。

生产的AZ61、AZ80、AZ91D和AM60镁合金角框零件的微观组织细小,抗拉强度分别达到306.8、308.3、299.8、321.6MPa。

伸长率分别达到21.6%、28.4%、14.6%和29.6%。

【总页数】5页(P1019-1023)【关键词】等径道角挤压;Mg-Al系镁合金;半固态坯;触变挤压【作者】王迎;姜巨福;孙毅;曲建俊;杜之明;罗守靖【作者单位】哈尔滨工业大学机电工程学院;哈尔滨工业大学力学博士后流动站;哈尔滨工业大学材料科学与工程学院;哈尔滨工业大学机械工程博士后流动站【正文语种】中文【中图分类】TG249.2;TG146.22【相关文献】1.新SIMA制备坯料触变挤压AZ61镁合金零件的组织与性能 [J], 姜巨福;王迎;柳君;曲建俊;杜之明;罗守靖2.新SIMA制备坯料触变挤压AZ61镁合金零件的组织与性能（英文） [J], 姜巨福;王迎柳君＇，曲建俊2杜之明＇，罗守靖＇;王迎;柳君;曲建俊;杜之明;罗守靖;3.AZ61镁合金半固态触变挤压成形工艺研究 [J], 周冰锋;闫洪4.镁合金半固态触变成形用非枝晶组织坯料制备的研究进展 [J], 杨明波;胡红军;陈健;麻彦龙5.半固态挤压铸造镁合金坯料组织与性能研究 [J], 李东南;陈丁桂;范新凤因版权原因，仅展示原文概要，查看原文内容请购买。

中文翻译半固态挤压铸造工艺参数对AlSi9Mg连杆的显微组织以及力学性能的影响摘要:通过研究施加的压力，浇注和模具的温度的改变过程对连杆的半固态挤压铸造制备（SSSC）过程中的显微组织和力学性能的影响。

结果表明，非树枝状的初生α-Al颗粒均匀分布在整个连杆。

随着施加的挤压力的增加，铝颗粒尺寸减小而增大形状因子，从而增加连杆的力学性能。

当浇注温度和模具的温度增加时，原铝颗粒的大小和形状因子增加。

然而，如果模具温度高于300℃，形状系数突然下降。

在浇注温度575℃得到连杆SSSC过程中最好的显微组织和力学性能，模具约250℃温度，和100兆帕的压力。

1.简介半固态金属加工（SSM）是一个将传统的热锻造和铸造优势结合的技术。

它可以在近净形成型过程中形成的具有高质量的工件，这种技术已经被视为二十一世纪生产中最有前途的技术之一。

在SSM加工可以分为成形和流变成形。

由于在运输和自动化的方便，触变成形广泛用于汽车工业制造镁合金和铝合金。

除了获得非枝晶，小，近球形结构，触变成形的另一个重要特性是它的能力，它能较好地减少缺陷如缩松和液体分离。

高压压铸（HPDC）被广泛用于形成SSM，但很难完全消除孔隙由于其填充率高，导致湍流模腔填充和凝固收缩。

挤压铸造（SC）是一个通用的术语来表示一个制造技术在凝固过程是在高压下的推广，结合压铸的优点和锻造成一个单一的操作，液态金属在压力下凝固的应用。

这使生产部件有着高完整性和好的力学性能。

因此，半固态挤压铸造（SSSC），这可以被看作是半固态成形和挤压铸造的一个组合工艺，能够进一步提高产品性能。

挤压铸造工艺参数对铝合金、镁合金及其复合材料的组织性能的影响已进行了大量的研究。

近年来，应用SC在铝合金半固态加工的研究已在进行了。

Mao .等人研究了流变挤压铸造A356铝合金。

结果表明：当注射压力为22 MPa时，模腔不完全填充的然而，随着压力增加到34 MPa，腔可以完全填充和铸件表面质量很好。

半固态压铸件ADC12铝合金的可行性1。

采矿和材料工程专业,工程学院,大学Songkla王子2。

工业工程专业,工程学院, 科技大学Rajamangala Srivijaya3。

机械工程学系,工程学院,大学Songkla王子2010年5月13日至2010年6月25日文摘研究半固态压铸件ADC12铝合金的可行性。

已经确定活塞速度受壁厚和固态粒度缺陷的影响。

研究表明缺陷是由缩松引起的。

在实验中,采用的是半固态浆料制备半固态gas-induced(GISS)的技术。

然后,液态金属被转移到压铸模具之中,模具和套筒温度分别保持在180 C和250 C结果表明,GISS制作的压铸模具松孔较小没有气泡微观结构均匀。

实验结果表明并可以推论,GISS是可行的,适用于ADC12铝压铸过程。

另外GISS可以改进性能比如减少孔隙度和增加组织均匀性。

关键词:ADC12铝合金;半固态压铸;气体引起的半固态(GISS); 流变铸造第1章在电子、航天、和建筑领域。

多年来一直使用铝制部件这些部件通常使用高压压铸过程大量生产。

压铸过程的优点在于实现了如生产效率高和生产小且复杂的工件压铸过程包括将铝液在高压下注入到一个模具型腔中。

金属液灌到模具型腔中,导致金属反应和铸造的过程中产生气孔。

因此,最终的结构部分充满气泡和氧化物夹杂。

此外，压铸件通常不能进行加工,由于这些缺陷的产生要进行阳极氧化、焊接、热处理,[1-4]。

来提高的压铸过程质量和性能因此在这里介绍了半固态金属技术。

大量的半固态压铸的研究报道,使用半固态压铸有助于改善产品性能和提高质量的压铸零件[5-7]。

半固态金属加工过程使用流变路线可以提供更高粘度的液体与更高的粘度, 能够获得更少的湍流流动,这有助于减少空气孔隙度和氧化物夹杂在模具填充[5-7]。

此外,流变过程可以很容易被应用于传统的压铸模具的生产过程,只需要少量修改便可使效率提高[8]。

许多研究显示成功的半固态压铸与流变过程[7-12]。
