FSP30罗德与施瓦茨FSP30频谱分析仪
Rohde & Schwarz FSP30 频谱分析仪以其创新的测量和大量标准功能而出类拔萃。
FSP30 提供了最先进的频谱分析仪所期望的所有功能和接口作为标准，而不是提供多种选择。
Rohde & Schwarz FSP30 在手动操作中每秒测量100 次，数字滤波器的扫描时间比同类模拟滤波器快 2.5 倍，事实证明，罗德与施瓦茨 FSP30 在产品开发的日常任务中也很有用。
罗德与施瓦茨 FSP30 的分辨率带宽高达 100 kHz，是全数字的，除了高选择性之外，由于最大带宽偏差为 3%，它还为精确（相邻）信道功率测量提供了理想的基础。
RMS 检波器是当前所有罗德与施瓦茨频谱分析仪的一项独特功能，即使对于 CDMA 等复杂信号也能快速产生稳定且可重现的结果。
由于其模块化设计，罗德与施瓦茨FSP30 配备了最佳装备来处理所有当前和未来的任务。
该设计同时考虑了硬件和固件扩展，以保护您在未来的投资。
ROHDE & SCHWARZ FSP30 频谱分析仪的规格包括：
频率范围 9 kHz 至 3 GHz
分辨率带宽 1 赫兹至 10 兆赫兹
显示的平均噪音水平 -155 分贝米（1 赫兹）
相位噪声 -113 dB (1 Hz) 在 10 kHz。
