72MHz，32位ARM7TDMI-S TM处理器这款基于ARM内核的微控制器是专为器件的连接而设计。

它效率高、功能强大、支持10/100以太网、全速（12 Mbps）USB 2.0接口、USB OTG 和CAN 2.0B；含有512KB 的ISP/IAP Flash 98KB的SRAM、一个外部存储器接口，10位A/D和D/A转换器、一个内部RC振荡器，以及一个SD存储卡接口。

该lpc247x增加了QVGA液晶显示控制器。

主要特点：· 72MHz，32位ARM7TDMI-S，带双AHB总线· 512KB 的ISP/IAPFlash 和98KB 的SRAM· SDRAM、SRAM 和Flash 的外部存储器接口· 10/100 Ethernet MAC 接口，带DMA 和MII/RMII 接口· USB2.0 全速OTG/设备/OHCI，带PHY 和DMA· 2个CAN2.0B 接口·通用DMA 控制器·10 位A/D 转换器和10位D/A 转换器· XGA LCD控制器带有支持TFT和STN的专用DMA（仅LPC247x）·多个串行接口：3个I2C、1个I2S、4个UART和3个SPI/SSP· 2个PWM单元· 4个32位的定时器、1个实时时钟和1个看门狗定时器· 4MHz 内部RC（IRC）振荡器，可以调节到1﹪的精度· 160 个通用快速I/O·单个3.3V的电源（3.0～3.6V）·含有几种掉电模式，包括“深度掉电”·封装－ TFBGA180（12×12×0.8mm）－ LQFP208（28×28×1.4mm）－ TFBGA208（15×15×0.8mm）功能特性：NXP 微控制器LPC24xx 系列使用一个工作在72MHz的高性能32位ARM7内核。
