DK-503调光控制器使用说明书（1.1）深圳市必爱歌电子科技有限公司版本作者日期内容1．0 丁度旭2010.09.02 创建1．1 胡冬贤2011.11.11 增加三路单独控制，线性调光。
DK-503调光灯光控制器使用说明书（V1.1）请注意：DK-503和DK-05、DK-08的工作状态设置方法不一样一、DK-503调光灯光控制器基本参数：产品规格：DK－503灯光控制器5路开关控制，3路调光控制工作电压：220V-250V 功耗10W；外型尺寸：220*125*55 (长*深*高)单路负载：可调灯光1500W（7A）开关灯光6000W（30A）产品特点: a、三路调光可实现每路独立控制。
b、每路的亮度开关记忆功能。
d、调光亮度变化渐变，避免视觉冲击。
e、调光每路可编入场景中，且不同场景亮度不同。
F、灯光控制器上可直接按键操作设定灯光亮度。
g、可恢复出厂默认值。
二、DK-503前面板图：前面板自左至右八个按键有两种含义。
含义一：“通道”对应后面板连接的八路负载，按键上方的LED灯表示状态，正常工作时，LED亮表示该路负载接通为亮；设置状态时，LED亮表示该路负载受控制。
含义二：“场景”代表本机的灯光组合（注：另一叫法为“场景”），有八个场景A-H和开机场景共九种场景。
前面板最右边按键代表“确认设置”键，其上方的LED代表“设置指示灯”。
后面板灯光接线图灯控墙板举例（用网线连接灯光墙板至DK系列墙板的任意一个LINK口）三、出厂默认设置：1、出厂默认灯光场景：出场默认开机场景：通道1－8连接的8个灯全亮。
场景A（动感）：通道1灯的亮灭控制场景B（柔和）：通道2灯的亮灭控制场景C（明亮）：通道3灯的亮灭控制场景D（抒情）：通道4灯的亮灭控制场景E（未取名）：通道5灯的亮灭控制场景F（未取名）：通道6灯的亮灭控制场景G（未取名）：通道7灯的亮灭控制场景H（未取名）：通道8灯的亮灭控制2、什么是“灯光场景”：多路灯光的亮灭组合而成的场景就是所谓的“灯光场景”。
452-0051-0201 Rev D. Revised May 12, 2009UPB Standard Dimming Transceiver Switch with Timer Model US1-40Provides ON/OFF, dimming and timed OFF control for:• Incandescent lighting • Magnetic low-voltage lighting • Halogen lightingIMPORTANT!•This incandescent dimmer cannot be used to dimFLUORESCENT, ELECTRONIC LOW-VOLTAGE or METAL HALIDE lighting , unless specifically allowed by the lightingmanufacturer. Please see instructions to configure this product for ON/OFF operation with these types of lighting.•DO NOT WIRE HOT! Permanent damage may result. Improper installation voids the warranty. Model US1-40 shown withactuator faceplate (sold separately)FUNCTIONThe SimplyBrilliant™ UPB Dimming Transceiver Switch, model US1-40, provides direct load control and or remote control of permanently-installed new or existing lighting fixtures, lamps and other electrical devices connected to UPB devices.Incandescent lamps can be turned ON or OFF, and can also be dimmed and brightened. The timer function can be used to automatically turn OFF loads, after a preset time, like bathroom fans or heat lamps. The US1-40 can be configured to turn other types of non-dimmable loads ON and OFF.Single rocker faceplate model series ZS11 are sold separately and available in gloss colors: white, ivory, almond, brown or black. The switch may also act as a transmitter or receiver that can communicate with other UPB devices, either individually or collectively for lighting scenes.IMPORTANT SAFETY INSTRUCTIONSWhen using electrical products, basic safety precautions should always be followed, including the following: 1. READ AND FOLLOW ALL SAFETY INSTRUCTIONS. 2. Installation should be performed by a qualified electrician.3.Keep away from water. If product comes into contact with water or other liquid, disconnect immediately.4. Never use products that have been dropped or damaged.5. Do not use this product outdoors.6. Do not use this product for other than its intended use.7. Do not connect multiple lamps that, when combined, exceed the maximumload rating of the product, de-rated for multi-gang boxes.8. Do not install in areas that can exceed 120°F (e.g., in an attic).9. To avoid the risk of overheating and possible damage to other equipment, donot use this product to control a receptacle.10. Do not cover the product with any material when in use. 11. SAVE THESE INSTRUCTIONS.CAUTION: DO NOT INSTALL TO CONTROL A RECPTACLE. The default switch configuration operates as a dimmer for incandescent lamps. It will also dim magnetic low-voltage and halogen lamps. To control fluorescent, electronic low-voltage or metal halide lamps, or motor-operated appliances, transformer-supplied appliances or fans, the switch must be reconfigured for ON/OFF operation (dimming disabled) prior to use. Refer to the section on Configuration.ATTENTION : NE PAS INSTALLER POUR COMMANDER UNE PRISE. La configuration de changement implicite opère comme un variateur pour les lampes incandescentes. Il baissera aussi le voltage bas magnétique et les lampes d'halogène. Contrôler levoltage bas fluorescent, électronique ou le métal halide les lampes, ou les appareils opérés de moteur, les appareils fournis detransformateur ou les fans, e changement doit être reconfiguré pour SUR/DE l'opération (baissant rendu infirme) avant l'utilisation. Faites allusion à la section sur la Configuration.CAUTION: DO NOT WIRE THIS DEVICE WITH POWERCONNECTED. Injury or permanent damage to the device may result. Improper installation voids the product warranty.INSTALLATIONThe SimplyBrilliant™ UPB Dimming Transceiver Switch (US1-40) is designed to be installed in a junction box that is wired to a readily accessible over-current protection device in the building wiring per NEC and CEC electrical codes.Locate the existing wall switch for the lighting to be controlled. Note that the lamp rating (or the combined rating of all connected lamps) must not exceed what is shown in the de-rating table below.Number of Load Dimmers in J-box Table 1:Power per Dimmer 1 2 3+ 1 600W -- -- 2 800W 500W -- Number of J-box Gangs3+900W700W500W2. Disconnect power at the circuit breaker.3. Remove the existing wall switch hardware. Disconnect the wires to the switch.4. Remove the yellow “INSTALL WITH CARE” label, if present.5. Using a wire nut, connect all white (Neutral) wires together.6.Using a wire nut, connect the brown (load output) wire of the US1-40 to the black wire of the device to be controlled.7. IF THIS IS TO BE A 3- OR MORE-WAY INSTALLATION, use a wire nut toconnect the brown/white “REMOTE 1” traveler wire to the “REMOTE 1”connection of the model USR 3-way switch. See wiring diagrams on page 2. 8. Using a wire nut, connect the black (Line) wire of the US1 switch to the black(Line) power wire.9. Mount the switch inside the J-box using captive screws. DO NOT OVERTIGHTEN THE SCREWS.10. Reconnect power at the circuit breaker.CONFIGURATIONConfiguration requires UPB setup/configuration software and a model UMCComputer Interface Module. Before using UPStart configuration software, be sure to download the latest version from the Simply Automated website. First time users should also download and follow the Quick Start Guide and use the Installation Wizard available in UPStart to save time.The US1-40 default settings assume a ZS11 (single rocker) faceplate. The device will not operate correctly with any other model of faceplate.SETUP MODEWhen configuring a UPB system, it is often necessary to place the US1-40 in SETUP mode in order to initiate self-identification on the powerline. To place the US1-40 in SETUP mode, tap any rocker exactly 5 times consecutively. The LED indicator will continuously blink GREEN when the unit is in SETUP mode. To exit SETUP mode and enter NORMAL mode, tap the rocker twice again.OPERATIONUnless otherwise configured, rocker actuator behaves as follows:Dimmer ActionRockerEventTop RockerBottom RockerSingle-Tap Brighten to 100% at Default Rate Fade to 0% at Default Rate Double-Tap Snap to 100%Snap to 0%Hold Start brightening to 100% atDefault RateStart fading to 0% at Default Rate ReleaseStop brightening and hold current levelStop fading and hold current level1. By linking a transmitting switch to a (non-dimming) UPB Receptacle,Appliance Module or Relay Module, the connected load can be turned ON by tapping the top of the rocker and OFF by tapping the bottom of the rocker. 2.By linking a transmitting switch to a (dimming) UPB Lamp or Fixture Dimmer Module, the connected load can be controlled according to the table above.A timer function is available in the US1-40. Controller commands or rocker taps can turn ON the load and preset the timer period. The US1-40 automatically turns OFF at the end of the period. The available preset times are: 1 Sec., 5 Sec., 30 Sec., 1 Min., 2 Min., 4 Min., 10 Min., 20 Min., 30 Min., 40 Min., 50 Min., 1 Hr., 2 Hrs. 3 Hrs. and 4 Hrs. The default setting is: Timer Off.To turn lights on faster, local response time adjustments are available (300, 450, 600 and the default 750 mSec) and configured with UPStart configuration software. Local response time is the time from rocker press to load response.POWER DISCONNECTIONTo disconnect power to the connected lamp fixture, depress the top of the rocker switch, grab the underside of the clear plastic indicator tab with your fingernail, pull the tab out about 0.2” until it stays in place. The LED indicator will extinguish to show that power is now disconnected. To reconnect power, simply push the tab back into its normal position.452-0051-0201 Rev D. Revised May 12, 2009OVERLOAD PROTECTIONINSTALLING/CHANGING FACEPLATESThe US1-40 SimplyBrilliant Dimming Wall Switch is designed with a removable actuator faceplate, making it possible to change color in the field without disconnecting the switch from the wall.The US1-40 contains a thermal sensor that automatically turns off the connected load if the switch becomes too hot. This can occur when the load exceeds thepower rating of the switch, or when dimming incompatible loads or if the switch is in an environment that exceeds the maximum operating temperature (120° F). If the load begins to turn OFF and ON repeatedly without command or actuation, then the load must be reduced.To install a faceplate assembly, do the following:1. Hold the rocker faceplate assembly so that clear plastic light pipe (LED) on the switch fits nicely into the recess on the top of the rocker.UPB FACTORY DEFAULT SETTINGS2. Align the four prongs on the rocker assembly with the four slots on the switch body.3.With equal pressure on the top and bottom of the faceplate, squeeze prongs as you the press it into the switch body. Ensure that all four prongs are fully inserted and latched into the switch body. If all four prongs are not fully latched, the rocker/button plungers may not function properly.To restore the following default settings, place the US1 in SETUP mode and tap any actuator exactly 10 times. The indicator will continuously blink BLUE. Tap the actuator twice again to exit SETUP mode.4.Exercise each rocker/button several times to ensure proper seating and operation. If the rocker or button doesn’t operate properly, remove and re-install the faceplate to check proper seating and operation .Network Name “Network 1” Room Name “New Room Name” Device Name “New US1-40” Unit ID 34 Network ID 255 To remove the faceplate assembly to change color, do thefollowing:Network Password 1234 Transmit Links None are pre-programmed Receive Links 1 (100%) and 2 (0%),1. Remove the wall plate from the switch.2. Using the thumb and index finger, press the top two prongs of the rocker faceplate assembly inward so that they unlatch from the switch body. This will release the top of the rocker assembly.STANDARD 2-WAY INSTALLATION3. Press the two lower prongs inward, and pull the faceplate assembly away and slightly downward from the switch body, moving it away from the clear plastic light pipe.4. Once the old rocker faceplate is removed, follow steps 1-4 above for instructions on installing a new rocker faceplate assembly.STANDARD 3-WAY (OR MULTI-WAY) INSTALLATIONThis diagram show a 3-way wiring configuration in which a USR remote switch controls the load connected to a US1-40. Additional USR remote switches may be added in parallel for multi-way control.TROUBLESHOOTINGPROBLEM PROBABLE CAUSESOLUTIONMaster switch is wired properlybut has no power. (LED indicator is OFF) Air gap power disconnect may be disengaged (pulled out).Push light pipe (indicator) back into position flush with faceplate assembly housing.3-way remote switch actuator may be binding, causing the switch to be stuck ON or OFF.Loosen mounting screws on remote switch and/or wallplate to relieve pressure on housing.Master switch actuator doesn’t turn load ON and/or OFF. (LED indicator is ON)Actuator faceplate may not be seated properly on the switch body.Exercise actuator several times to ensure proper seating and operation. If necessary, remove and replace faceplate to ensure proper seating and operation.Mounting screws may be too tight or j-box may be deformed, causing the switch body to warp.Loosen mounting screws to relieve pressure on the switch housing. Buttons and/or rockers stick or don’t actuate properly when pressed.Actuator springs may have backed out of their correct location during shipping.Exercise actuator several times to ensure proper seating and operation. If necessary, remove and replace faceplate to ensure proper seating and operation.Switch is overloaded.Reduce the power load by removing bulbs from the circuit.Load turns ON and OFFregularly without actuation or command.Switch is dimming a load that is not rated for use with incandescent dimmers.Reconfigure the switch for ON/OFF operation with no dimming (using UPStart, for example).Multi-button/rocker faceplate is not recognized in UPStart and does not workUS1-40 is configured for a single rocker ONLY. Multi-button/rocker faceplates will not be recognized by UPStartReplace US1-40 with a US2-40 and the desired faceplate (timer option not available in US2-40).Simply Automated, Incorporated6108 Avenida Encinas, Suite B, Carlsbad, CA 92011 USATechnical Support: or 800-630-9234。
通用型调光执行模块，1联产品号 : 3901 REGHE通用型调光执行模块，2联产品号 : 3902 REGHE通用型调光执行模块，4联产品号 : 3904 REGHE使用说明1安全指南电气设备的安装和连接只允许由电气专业人员执行。
可能引发严重伤害、火灾或财物损失。
请完整阅读并遵守操作说明。
电击危险。
在对设备或负载施工前先安全断开。
电击危险。
设备不应断开。
即使在输出端关闭时，负载也不得孤立于电网。
当设置的运行方式与负载类型不匹配时，可能导致调光器和负载毁坏危险。
在连接或更换负载之前正确设置调光原理。
火险。
在使用感应变压器操作时，必须遵守每种变压器相应制造商的使用说明。
只能使用符合EN 61558-2-6（VDE 0570，第 2-6 部分）的安全隔离变压器。
该说明书属于产品的组成部分，必须由最终用户妥善保管。
LED 灯的连接功率和调光质量取决于灯类型和安装情况。
连接功率可能与给定的值存在偏差。
对于功能的正常运作，调光结果和调光质量，我们无法做出任何保证。
2设备结构图像 1: 2 路调光执行器外观图像 2: 4 路调光执行器外观(1)手动操作键盘(2)编程按键和编程 LED(3)KNX 接口(4)电网接口（选配，如果工作时无总线电压，应该配备）(5)状态 LED(6)输出端接线端子3功能系统信息该设备为 KNX 系统的产品，符合 KNX 标准。
可通过 KNX 培训掌握详细的专业知识。
设备功能会根据软件有所不同。
软件版本、功能范围及软件本身的详细信息请参阅制造商的产品数据库。
借助 KNX 认证软件设计、安装及调试设备。
可以在我们的网页上实时查询最新的产品数据库以及技术说明。
正常应用V04 以上设备版本（参见压印）以及应用程序。
–开关和调光：白炽灯，高压卤素灯，可调光的高压 LED 灯，可调光的节能灯，可调光的电感变压器（带低压卤素灯或低压 LED 灯），可调光的电子变压器（带低压卤素灯或低压 LED 灯）–按照 EN 60715 安装至配电箱中的支承轨道上。
规格说明书1通道电容式触摸感应ICLED灯无级调光IC ADA01AL V2.0官方网站: E-mail: info@ 直线电话：0755-8830-2837 8297-7857 自动传真：0755-2263-4057 全国客服中心免费电话：4006-992-661 资料在公司官方网站上会随时更新，敬请留意！目 录 1. 概述 ......................................................................................................................................... 3 2. 特性简介 .................................................................................................................................. 3 3. 功能描述 .................................................................................................................................. 3 4. 标准封装(DIP8/SOP8 封装) ..................................................................................................... 4 5. 管脚描述 .................................................................................................................................. 6 6 电气特性 ................................................................................................................................... 6 7. 应用电路 .................................................................................................................................. 6 8. 应用说明 .................................................................................................................................. 8 9. 修改记录 .................................................................................................................................. 8 第 2 页 共 8 页1. 概述ADA01AL是一款单通道电容式触摸IC, 专门针对LED灯的应用，内置强大的电容感应式触摸算法，广泛适用 于各种类型的LED灯具控制产品。
ZigBee Wireless Dimmer Switch09.ZGK2D.0483711 mmFunction introductionImportant: Read All Instructions Prior to Installation Front sideBack sideBefore the first use, please remove the protective filmProduct DataPress and hold down both keys together to search and pair Note: This switch supports 48 binding tables and 2 groups for binding lighting devices.Click to turn off the paired lighting devices, Press and hold down todecrease light intensity Protocol Operation VoltageTransmission Frequency Transmission Range (free field)Protection Type Dimming Range DimensionsZigBee 3.03VDC (CR2430)2.4GHz 30m IP200.1%-100%71.2x71.2x13.6mm• This device contains a button lithium battery that shall be stored and disposed properly.• DO NOT expose the device to moisture.Safety & WarningsOperation1.This ZigBee dimmer switch is a wireless transmitter that communicates with a variety of ZigBeecompatible systems. This transmitter sends wireless radio signals that are used to remotely control a compatible system.2.This ZigBee dimmer switch supports 1 group for binding lighting devices and enables to control single color ZigBee lighting devices.3.Pair to ZigBee Lighting Device Via TouchLink without Coordinator (Hub or Controller)1)Initiate TouchLink Commissioning of ZigBee lighting device, please consult its manual to learn how.2)Bring the switch within 10cm of the ZigBee lighting device.3)Press and hold down both and keys until the LED indicator on the switch turns on.4)Click button twice continuously to start TouchLink commissioning procedure of the switch.5)The LED indicator will first flash 6 times fast to indicate linking successfully and 4s later it will flash 4 times slowly to indicate successful binding to the device.Note: Each lighting device can only pair to one switch via touchlink, and can not pair to different switches simultaneously. If TouchLink fails, please factory reset the lighting device and initiate TouchLink Commissioning again.4.ZigBee Network Pairing Via ZigBee Coordinator (Hub or Controller Interface)1)Please make sure the switch does not belong to any ZigBee network before pairing, click any key if the• • • • • • • • • ZigBee dimmer switch based on ZigBee 3.0Enables to pair ZigBee lighting devices via touchlink commissioning without coordinatorSupports find and bind mode to pair with ZigBee lighting devices in the same network Supports 1 group for binding lighting devices 2.4 GHz global operationLong battery life mesh technology Transmission range up to 30mCompatible with universal ZigBee Gateway productsCompatible with universal single color ZigBee lighting devicesMountingThe key part of this controller is an universal one, especially rotary standard switch element that can be integrated in numerous frames by different manufactures as below list:BEKER S1, B1, B3, B7 glass GIRA Standard55, E2, Event, EspritJUNG A500, Aplus MERTENM-smart, M-Arc, M-Planindicator turns on, which means the switch has already paired to a network. Please remove it from the network first, otherwise the pairing will fail.2)Press and hold down both and keys until the LED status indicator turns on, then immediately click button to enable the switch to search nearby network, LED indicator will flash every 1 second. 20 seconds timeout if there is no network, the indicator will turn off, repeat the operation.3)From your ZigBee Controller or hub interface, choose to add device and enter Locating/Pairing mode as instructed by the controller.4)Network Pairing Begins Automatically: LED indicator on the switch blinks 6 times quickly as it scans for a compatible network controller to pair with.5)After the remote is located and paired to the ZigBee network, the indicator will stop blinking and turn off, then the remote will appear in your controller's menu.6)The switch is now paired to the ZigBee network.5.Battery Power Monitor Function, the switch will report battery power value to the coordinator under following situations:When powered on.When user clicks both and keys simultaneously.When user operates the switch to send data packets (over 4 hours since last operation).When added to the network by a coordinator.6.Pair with A ZigBee Lighting Device Via Find and Bind Mode without Coordinator1)Start find and bind mode on the ZigBee lighting device (initiator node) and enable it to find and bind target, please consult its manual to learn how.2)Press and hold down both and keys on the switch until the LED indicator turns on.3)Click button to enable the switch (target node) to find and bind initiator.4)The binding will be successful within 4 seconds, and LED indicator on the switch will flash 4 times. If binding fails, LED indicator will flash twice.7.Unpair with A ZigBee Lighting Device Via Find and Bind Mode without Coordinator1) Start find and bind mode on the ZigBee lighting device (initiator node) and enable it to find and unbind target, please consult its manual to learn how.2)Press and hold down both and keys on the switch until the LED indicator turns on.3)Click button twice continuously to enable the switch (target node) to find and unbind initiator.4)The unbinding will be successful within 4 seconds, and LED indicator on the switch will flash 4 times. If unbinding fails, LED indicator will flash twice.8.Unpair with All ZigBee Lighting Devices Bind with The Switch without Coordinator 1)Press and hold down both and keys on the switch until the LED indicator turns on.2)Click button five times continuously to clear all bind lighting devices with this remote.3)LED indicator on the switch will flash 4 times to indicate successful unbinding of all devices.9.Binding Between the Switch and ZigBee Lighting Devices Via Coordinator (Hub or Controller Interface)1)Once the switch and compatible ZigBee lighting devices are paired to the same network, click any button to activate the switch, then from your ZigBee controller or hub interface, choose to bind devices to the remote as instructed by the controller. Then the devices can be controlled by the remote.2)Once the binding operation is done between the remote and ZigBee lighting devices, the remote can still control the devices in the event of gateway/coordinator loss.Note: This switch supports 48 binding tables and 1 group for binding lighting devices.10.Unbinding Between the Remote and ZigBee Lighting DevicesTo unbind the remote and ZigBee lighting devices, first click any button to activate the switch, then from your ZigBee controller or hub interface, choose to unbind the device from a remote as instructed by the controller.• • • • 11.Factory Reset the Switch (Remove From ZigBee Network)From the ZigBee Controller or Hub Interface1)From your ZigBee controller or hub interface, choose to remove or reset the remote as instructed. The LED indicator on the remote will turn on and flash 3 times quickly to indicate successful reset to factory default setting.Manual2)Press and hold down both and keys until the LED indicator on the switch turns on -> immediately click button 5 times continuously -> LED indicator flashes 3 times quickly to indicate successful removal from the network and reset to factory default.Note: All configuration parameters will be reset after the remote is removed from the network.12.ZigBee Clusters Supported by This Remote Are As Follows:Input clusters:BasicPower Configuration IdentifyDiagnostics Output clusters:Identify On/offLevel control Ota。
ApplicationDownlightPanel LightFlood LightSpotlightCeiling LightFloor LightDecorative LightSummaryProduct FeaturesEUP30D-1HMC-0 (Product No.:102100250101)Technical Paramaters220VAC-240VAC 50/60Hz87%@230VAC,Full load ≥0.95@230VAC,Full load Cold start,28A(twidth=30us measured at 50% Ipeak)@230VAC 0.17Amax@230VAC IP20-20℃~50℃-40℃~85℃, 20-90%RH 90℃EN50515,EN61000-3-2 Class C,IEC61000-3-3,GB/T17743EN61000-4-2,3,4,5,6,8,11 EN61547,GB17625.1IEC/EN61347-1,IEC/EN61347-2-13,GB19510.1,GB19510.14,L-N:500VI/P-O/P: 3000VAC/1min/5mAPC 30,000h@tc:80℃0.1%-100% Dimming to off50V Max±5%<3%DALI /Touch DIM(Push DIM)>15,000 times1550mA/9-45VDC/24.75W 650mA/9-45VDC/29.25W 600mA/9-45VDC/27W 700mA/9-43VDC/30.1W 750mA/9-40VDC/30W 850mA/9-35VDC/29.75W800mA/9-38VDC/30.4W900mA/9-34VDC/30.6W<10%@230VAC, Full load EUP30D-1HMC-0SurgeWithstand VoltageIEC 62386-101: 2014, IEC 62386-102: 2014; IEC 62386-207: 2009, DALI 1.0DALI Standard Safety Standards EMC Eission EMC Immunity tc LifetimeMaterialDimming Range IP Rating Working Temp.Storage Temp., Humidity Dimming Type Switch Cycle Warranty Condition 3 Years No load output voltageEfficiency AC Current(max)Standby power <0.5WInrush Current(max)THD(full load)Current(mA)/Voltage (VDC)Power(W)Ripple CurrentChannel Current Tolerance VoltageFrequency Range(Hz)Power Factor Short CircuitOver Load Over temperature Close output, recovers automatically after fault removedShut down the output, recovers automatically when temp. back to normal.When the output voltage is exceeded, the output current decreases and, recovers automatically when the load is reduced.Safety&EMCOthersFunctionModelOutputInputProtectionNet weight: 155g±5%/PCS; 50PCS/Carton; 8.25kg±5%/Carton; Carton Size : 319*254*136mm(L*W*H)Packing(weight)150*42.5*28.5mm （L*W*H ）DimensionEUP30D-1HMC-0 is a 30W AC/DC constant current mode output LED driver featuring the multiple levels selectable by DIP switch and complies with DALI standard protocol IEC 62386. EUP30D-1HMC-0 can be connected to DALI main controller or Touch DIM to a chieve a smooth dimming effect.·Single channel output, output current level selectable by DIP S.W.·Meet DALI Protocol IEC 62386·Support Touch-DIM function ·High efficiency up to 87%·Built-in active PFC function ·Dimming effect smooth, no flicker·Protections: Short circuit, over load, over temperature·Suitable for indoor LED lighting application, such as down light, panel light, and so onCurrent Selection TableRemark: Function default setting is: 550mA (@switch are all OFF state)DALI WiringPush DIM(Touch DIM) DiagramPush DIM Function1. Press the Push DIM (Touch DIM) switch for 8s or more,the driver can be controlled via Push DIM switch.2. Short press the Push DIM (Touch DIM) switch (<0.5s) to control the lamp on or off.3. Long press the Push DIM (Touch DIM) switch (>0.5s) to dim the brightness of light. The dimming direction will change every time after pressing switch.4. Double-click the Push DIM (Touch DIM) switch (<0.3s), then all lamps connected on the device will be set maximum brightness.5. The brightness adjustment range is 1%-100%, and the light can be turned off through short pressing when doing the adjustment with long pressing Push DIM (Touch DIM) switch.6. With the Power off memory function, the power-down state will be recovered when power on again.DALI DiagramRemark: Only use open push button without indicator light. Maximum cable length between each Unit: 20 meters.※ The contents of this manual are updated without prior notice. If the function of the product you are using is inconsistent with the instructions, the function of the product shall prevail.Please contact us if you have any questions .Dimming CurveCautionsDerating CurveAmbient Temperature(℃)-20020406080100120L o a d (%)-10010203040506020406080100120DALI Dimming LevelO u t p u t C u r r e n t (%)1.This product should be installed by qualified personnel.2.This product is non waterproof, need to avoid sun and rain.In case of outdoor use, please ensure it is mounted in a water proof enclosure.3.Good heat dissipation conditions extend product life. Please install the product in a well-ventilated environment.4.Please make sure LED power supply output voltage, current is used to meet the product requirements.5.Please ensure that adequate sized cable is used from the controller to the LED lights to carry the current. Please also ensure that the cable is secured tightly in the connector.6.Due to safety concerns, PVC or rubber cord of 0.75- 1.5mm ² is recommended for input and output terminal(s)(excluding signal terminals). Flat power cord is not suitable.Ensure all wire connections and polarities are correct before applying power to avoid any damages to the LED lights.7.In case of malfunction, do not repair it yourself.220VAC-240VAC 50/60Hz87%@230VAC, 满载≥0.95@230VAC, 满载<0.5W冷启动, 28A(在 50%Ipeak 下测twidth=14us)@230VAC 0.17Amax@230VAC 150*42.5*28.5mm （长*宽*高）IP20-20℃~50℃-40℃~85℃, 20-90%RH 85℃PC 30,000小时@tc:75℃0.1%-100% 变暗直至关闭50V Max±5%<3%>15,000次1<10%@230VAC, 满载EUP30D-1HMC-0浪涌耐压标准DALI标准安全标准电磁兼容EMC 抗扰度tc寿命材质调光范围尺寸包装尺寸(重量)防水等级工作温度储存温度、湿度调光方式开关周期3年质保空载输出电压效率待机功耗电流浪涌电流THD 电流/电压/功率波纹电流通道电流精度电压频率功率因素短路过载过温关断输出，移除故障后自恢复关闭输出，温度恢复后， 电源正常工作。
阿达电子公司主要PWM调光开关、LED调光开关主要IC有：ADA01AL/ADPT005/ADPT008/ADPT012/ADA16/ADPT01。
PWM调光就是通过调整灯亮的时间与灯灭时间的比例来调整平均感观亮度的方法。
在微小的时间片里，LED或灯要么是全开、要么是全关，没有半开的中间状态。
PWM调光可以是分档的，也可以是无级的。
阿达电子公司部分PWM调光开关、LED调光开关芯片介绍：ADA01AL单通道电容式触摸IC芯片：ADA01AL是一款单通道电容式触摸IC, 专门针对LED灯的应用，内置强大的电容感应式触摸算法，广泛适用于各种类型的LED灯具控制产品。
ADPT005_5通道触摸感应IC芯片：ADPT005 是一款有5个独立的电容式触摸感应通道和5个输出端口的8位专用集成电路。
ADPT008_8通道触摸感应IC芯片：ADPT008 是一款有8个独立的电容式触摸感应通道和10个控制端口的专用集成电路。
ADPT012_12通道触摸感应IC芯片：ADPT012 是一款有12个独立的电容式触摸感应通道和多个控制端口的专用集成电路。
抗电源干扰及手机干扰特性好。
EFT可以达到4KV以上；近距离、多角度手机干扰、对讲机干扰，触摸响应灵敏度及可靠性不受影响。
ADA16 TSSOP28封装16通道触摸感应IC：本产品经过多年类型客户的检验，稳定性和抗干扰能力等各方面表现优秀，目前已广泛使用于：门禁，考勤机，安防，小家电，便携式产品，KTV面板，智能家居，智能控制面板，汽车周边电子产品等等。
请注意，当触摸介质比较厚时，单个触摸点的面积要相对的大一些，比如用3mm以上的非导电介质时，单个按键的触摸面积最好在直径为15mm左右以上是我们为您整理阿达电子公司的部分PWM调光开关、LED调光开关芯片资料，更多详细资料请稳步到资料下载或者产品中心进行更详细的查看。
关键词：PWM调光开关、LED调光开关。
led调光开关原理
LED调光开关是一种用来控制LED的亮度的装置。
它基于PWM（脉宽调制）原理工作。
PWM是一种通过改变高电平和低电平的时间比例来调节电流的方法。
LED调光开关主要由一个微控制器和一组三极管组成。
微控
制器通过控制三极管的开关状态来控制电流的流动。
当微控制器通过控制三极管的开关，使LED接通时，电流通过LED使
其发光。
为了实现调光功能，微控制器会改变LED的开和关的时间比例。
通过改变每个周期高电平和低电平的时间比例，可以改变LED的亮度。
例如，如果高电平时间比例较长，低电平时间
比例较短，那么平均电流会较大，LED会更亮。
反之，如果
高电平时间比例较短，低电平时间比例较长，LED会更暗。
LED调光开关还可以根据用户的需求来实现不同的亮度调节
方式。
一种常见的方式是使用旋钮或按钮来改变LED的亮度。
当用户旋转旋钮或按下按钮时，微控制器会接收到信号，然后改变PWM的参数以改变LED的亮度。
此外，LED调光开关还可以与其他控制设备进行连接，如智
能家居系统或遥控器。
通过与这些设备的连接，用户可以通过手机、平板电脑或遥控器来远程控制LED的亮度。
总之，LED调光开关通过微控制器和PWM技术实现LED的
亮度调节。
它是一种灵活、方便的装置，可以满足用户不同场景下的亮度需求。
本产品可支持钨丝灯、卤素灯、可控硅调光LED ，可调21档亮度（调亮10档，调暗10档） 。
单路调光开关单路调光开关背面双路调光开关双路调光开关背面二、安装说明1）断开总电源开关 （请务必先断电）轻轻地顺时针方向旋转即可打开钢化玻璃面板3）按照背后标识接入相对应的相线并锁紧单路接线示意图双路接线示意图5）扣上钢化玻璃面板（请务必 在断电状态下扣钢化玻璃面 板，否则会影响触摸灵敏度）4）固定到暗盒里6）通电正常使用①主机的操作按【】键进入主菜单，按【2 1】键，选择【未学习】；按【】键，再按【】键提示“学习等待中……”。
学习其它智能设备如上操作。
②控制器的操作长按【开关】3秒以上，指示灯闪烁慢闪（1分钟后未对码超时退出）。
学习成功主机语音提示“学习正确”。
2）方式二：手机APP控制主机与智能开关学习打开APP选择“设备”界面，在“智能设备”里选择“调光灯”根据图示长按“开关”键3秒，直至按键灯闪烁后点击APP上的“开始学习”，此时主机自动学习成功后会语音提示“学习正确”，即学习成功。
可在APP上进行相关设置，例如按键名称、定时任务和语音控制等。
四、技术参数【额定电压】220V/50Hz【待机功率】≤0.5W【输出功率】≤500W/路【无线方式】LORA【工作环境】温度:0~40℃湿度:≤80％RH【规格尺寸】86x86x30 mm (长x宽x厚)【无线距离】≥1000m（开阔地）本产品可支持钨丝灯、卤素灯、可控硅调光LED ，可调21档亮度（调亮10档，调暗10档） 。
单路调光开关单路调光开关背面双路调光开关双路调光开关背面二、安装说明1）断开总电源开关 （请务必先断电）轻轻地顺时针方向旋转即可打开钢化玻璃面板3）按照背后标识接入相对应的相线并锁紧单路接线示意图双路接线示意图5）扣上钢化玻璃面板（请务必 在断电状态下扣钢化玻璃面 板，否则会影响触摸灵敏度）4）固定到暗盒里6）通电正常使用①主机的操作按【】键进入主菜单，按【2 1】键，选择【未学习】；按【】键，再按【】键提示“学习等待中……”。
PWM调光技术详解
PWM 调光技术详解
PWM 调光是一种利用简单的数字脉冲，反复开关白光LED 驱动器的调光技术。
应用者的系统只需要提供宽、窄不同的数字式脉冲，即可简单
地实现改变输出电流，从而调节白光LED 的亮度。
PWM 调光的优点在于能够提供高质量的白光，以及应用简单，效率高！例如在手机的系统中，利
用一个专用PWM 接口可以简单的产生任意占空比的脉冲信号，该信号通过一个电阻，连接到驱动器的EN 接口。
多数厂商的驱动器都支持PWM 调光。
不管用Buck, Boost, Buck-Boost 还是线性调节器来驱动LED，它们的共同思路都是用驱动电路来控制光的输出。
一些应用只是简单地来实现开和
关地功能，但是更多地应用需求是要从0 到100%调节光的亮度，而且经常要有很高的精度。
设计者主要有两个选择：线性调节LED 电流（模拟调光），
或者使用开关电路以相对于人眼识别力来说足够高的频率工作来改变光输出
的平均值（数字调光）。
使用脉冲宽度调制（PWM）来设置周期和占空度
（图1）可能是最简单的实现数字调光的方法，并且Buck 调节器拓扑往往能够提供一个最好的性能。
图1：使用PWM 调光的LED 驱动及其波形。
各种LED恒流驱动及恒流IC芯片盘点LED恒流驱动简介山于LED是特性敬感的半导体器件，乂具有负温度特性，因而在应用过程中需要对其进行稳定工作状态和保护，从而产生了驱动的概念。
LED器件对驱动电源的要求近乎于苛刻, LED不像普通的白炽灯泡，可以直接连接220V的交流市电。
LED是2〜3伏的低电压驱动, 必须要设计复杂的变换电路，不同用途的LED灯，要配备不同的电源适配器。
国际市场上国外客户对LED驱动电源的效率转换、有效功率、恒流精度、电源寿命、电磁兼容的要求都非常高，设计一款好的电源必须要综合考虑这些因数，因为电源在整个灯具中的作用就好比像人的心脏一样重要。
LED驱动电源把电源供应转换为特定的电压电流以驱动LED发光的电压转换器，通常情况下：LED驱动电源的输入包括高压工频交流（即市电）、低压直流、高压直流、低压高频交流（如电子变压器的输出）等。
而LED驱动电源的输出则大多数为可随LED正向压降值变化而改变电压的恒定电流源。
LED电源核心元件包括开关控制器、电感器、开关元器件（MOSFET）.反馈电阻、输入滤波器件、输出滤波器件等等。
根据不同场合要求、还要有输入过压保护电路、输入欠压保护电路，LED开路保护、过流保护等电路。
LED的恒流驱动用LED作为显示器或其他照明设备或背光源时，需要对其进行恒流驱动，主要原因是:1.避免驱动电流超出最大额定值，影响其可鼎性。
2.获得预期的亮度要求，并保证各个LED亮度、色度的一致性3.能有效的避免雷击，电网的浪涌，过电流，过电压的保护，使LED寿命提高。
存在问题：要处理好散热问题，散热问题没有处理好就会影响LED寿命。
口前LED均采用直流驱动，因此在市电与LED之间需要加一个电源适配器即LED驱动电源。
它的功能是把交流市电转换成合适LED的直流电。
根据电网的用电规则和LED的驱动特性要求，在选择和设计LED驱动电源时要考虑到以下儿点：1•高可鼎性特别像LED路灯的驱动电源，装在高空，维修不方便，维修的花费也大。
YX009K3-RW 3按键五档带无级调光LED控制IC一、概述宇鑫科技：是一家专门服务于LED照明行业和消费电子产品行业的方案公司。
主要从事各类消费类电子产品控制方案芯片的研发与销售。
目前主要有:LED调光控制IC、分档调光IC、无级调光IC、调光调色温控制IC、移动电源控制IC、电量显示IC、应急灯控制IC、RGB七彩控制IC、红外遥控IC、定时控制IC、迷你风扇IC、及其他各类消费电子产品的专用控制IC等，主分:YX009K系列、YX017A系列、YX007系列、等都是公司自主研发与销售。
目前公司有近百款产品，若需选型手册，可联系客服索取，公司同时也根据用户不同需求进行针对性控制IC设计、销售和售后技术支持,本公司诚信经营，并热诚服务于不同规模公司的需求。
主要特点:1、芯片3按键控制方式，外围电路简单好用，可适用于LED台灯等调光控制*休眠微功耗设计，OFF状态时，芯片本身静态电流最低可小于1微安*点按5级分档步进调光*长按无级调光*PWM输出最大最小极限指示灯2、3按键方式控制逻辑如下:芯片每次上电默认为60%开机状态,后续调光记忆,直到掉电复位点按全程档位：20%-40%-60%-80%-100%点按或无级调光最大最小极限值：100%-20%OFF状态: 点按开关键-开机/点按开关键-关机 如此循环ON状态： 点按UP键-向上加20%,点按DOWN键-向下减20%ON状态： 长按UP键-向上无级调光/长按DOWN键-向下无级调光长按无级调光后,再点按，则是从当前值向上或向下20%这样步进3、 无级调光行程: 无级调光最大值与最小值之间的总行程时间是6秒左右4、 芯片驱动波形输出为31KHZ PWM,能实现平滑无闪烁调光,可直接驱动MOS管也可与支持高频调光的恒流芯片组合驱动，应用于各类灯具调光方案5、 调光极限值指示灯: 当PWM调到最大或最小值时，芯片6脚输出指示灯二、IC引脚功能说明三、 芯片引脚参考线路: (具体线路需工程师根据自己产品特点进行应用设计) 序号名称 功能说明 1V DD 电源+，2.5-5.0V 2UP “UP ”加按键 3DOWN “DOWN ”减按键 4ON/OFF “ON/OFF ”开关按键 5PWM 31KHZ调光PWM输出端口 6S ec 1 LED指示输出(调光极限值时,引脚输出高电平) 7IR NC 8 GND 电源地四、封装信息。
通用型LED按键调光芯产品号 : 1711DE使用说明1安全指南电气设备的安装和连接只允许由电气专业人员执行。
可能引发严重伤害、火灾或财物损失。
请完整阅读并遵守操作说明。
电击危险。
在对设备或负载施工前先安全断开。
电击危险。
设备不应断开。
即使在关闭仪器的情况下，负载也没有断开电源。
当设置的运行方式与负载类型不匹配时，可能导致毁坏危险。
在连接或更换负载时正确设置运行方式。
火险。
在使用感应变压器操作时，必须遵守每种变压器相应制造商的使用说明。
只能使用符合EN 61558-2-6（VDE 0570，第 2-6 部分）的安全隔离变压器。
该说明书属于产品的组成部分，必须由最终用户妥善保管。
2正常应用–开关和调节照明–根据 DIN 49073 安装至设备插座内–配置 LB 管理系统中合适的顶盖进行使用3产品特性–设备根据相位导通原理工作–自动或手动设置与负载相匹配的调光原理–通过 LED 显示设置的运行方式–可以在无零线情况下运行–通过节能型软启动接通–以上次设置的亮度或保存的开启亮度接通–开启亮度可长久保存–最小亮度可长久保存–可以连接分站–最迟 7 秒后长久切断电子短路保护–电子超温保护–酒店卡功能通过功率放大器可以提升功率。
4操作本说明书介绍了按键端的使用。
相应套筒的说明书中介绍其它套筒的操作。
通过带电键套或按键的双线或三线分机进行操作基本符合主机上的操作。
开关灯￭短按按键端：接通或关闭照明。
三线分机：按上端接通，按下端关闭。
设置亮度灯已开。
￭长按按键上端。
灯光变亮至最大亮度。
￭长按按键下端。
灯光变暗至最小亮度。
以最小亮度打开灯￭长按按键下端。
将灯开到最小亮度。
￭长按按键上端或按键。
将灯开到最小亮度并且灯光变亮。
保存开启亮度发货时会将最大亮度设置为开启亮度。
￭设置亮度。
￭全方位长按按键端超过 4 秒。
开启亮度已保存。
灯短暂熄灭又重新亮起即为按下。
以上次设置的亮度接通要以最后设置的亮度打开，必须删除打开的亮度。
L E D遥控调光多彩R G B W球泡灯规格书型号：ADL-B-IR28名称：红外28键RGBW球泡灯产品说明红外28键RGB+W球泡灯，可通过遥控器进行静态亮度调节，静态颜色选择，动态速度调节，自定义任意颜色等灯光变化效果，具有掉电记忆功能。
色彩丰富，动态效果炫丽，流行于世界各地的装饰，照明。
适用于居家室内装饰，提高生活质量，使所处空间浪漫温馨，兴致盎然。
球泡灯性能参数●电源电压：AC 85~265V●频率范围：50-60Hz●球泡灯功率：6W●静态功耗：<0.3W●平均寿命：50000h●色温范围：7彩●功率因素：0.65●灯头型号：E27遥控器参数●工作温度：-20-60℃●供电电压：DC3 V（CR2025纽扣电池供电）●遥控器尺寸：L94×W52×H7.4mm●静态电流：<5uA●工作电流：<8-12mA●遥控距离：>5m外型尺寸使用说明●操作时，先将遥控电池绝缘片拔出然后将遥控器对着红外接收头，确保遥控器与接收头之间没有隔光障碍物（如纸板，墙壁等）；各按键功能如下表所示（按照按键的位置排列）：亮度加/速度加亮度减/速度减关灯开灯静态红色静态绿色静态蓝色静态白色静态黄色静态青色静态粉色三色跳变DIY蓝色光加七色跳变DIY红色光加DIY绿色光加DIY蓝色光减三色渐变DIY红色光减DIY绿色光减自定义颜色3 七色渐变自定义颜色1 自定义颜色2自定义5色跳变三色礼花自定义颜色4 自定义颜色5●补充说明：关于DIY的键，当它被第一次按下，将进入DIY的色彩模式，你可以自由地通过调整上述6个红绿蓝加减键来调节对应的R / G / B颜色的亮度（如果其他模式键被按下，就会跳出DIY设置模式同时保存当前DIY颜色）。
当下一次这个DIY键被按下时，它会显示最后一次保存的颜色。
有5个DIY键，您可以自定义保存您所喜欢的5种颜色。
他们都是独立的，彼此没有任何影响，还可以随时调整。
视窗之星VS-BN系列——PWM太阳能控制器产品手册Models:VS1024BN/VS2024BNVS3024BN/VS6024BN控制器使用之前请仔细阅读本手册，并遵循手册内容进行相应操作。
若由于客户原因使用不当或未遵循本使用手册进行操作，而造成控制器损坏的，本公司概不负责！维修程序参照下述流程进行，只收取维修成本费。
■维修程序在要求维修前，对照使用手册来确定控制器确实有问题。
若无法解决，将有问题的控制器通过快递寄回本公司，运费预付，并提供与购买相关的票据、日期和地点信息。
为了享受返修服务，返回的产品需标明型号，序列号和故障的详细原因，以及系统中组件的类型及相关参数，蓄电池和系统负载的情况，这些信息对于解决您的维修要求很重要。
1 注意事项 (1)2 产品信息 (2)2.1 产品概述 (2)2.2 特征描述 (3)2.3 选配件 (5)3 安装指导 (7)3.1安装 (7)3.2接线 (8)4 功能 (11)4.1串联型脉宽调制技术的特点 (11)4.2电池充电信息 (11)4.3人机界面 (13)4.4控制器的操作及显示 (15)5故障排除与维护 (40)5.1控制器具有的保护功能 (40)5.2发电系统的故障排除 (41)5.3发电系统的维护 (43)6技术参数 (43)附录 (48)1注意事项警告：表示有潜在危险，执行此任务时要格外小心注意：表示控制器安全、正确操作的一个关键程序※安全事项※■使用之前请仔细阅读手册中的说明和注意事项■控制器内部没有需要维护或维修的部件，用户不要自行拆卸和维修控制器■室外安装时应避免阳光直晒■建议在控制器外部安装合适的保险丝或断路器■在安装和调整控制器的接线前断开光伏阵列及蓄电池回路■安装蓄电池时要小心，对于开口式铅酸蓄电池的安装应戴上防护镜一旦接触到蓄电池酸液时，请及时用清水冲洗■蓄电池附近避免放置金属物件，避免蓄电池发生短路■蓄电池充电时可能产生酸性气体，确认环境周围通风良好■虚接的连接点和腐蚀的电线可能造成较大的发热融化电线绝缘层，燃烧周围的材料，甚至引起火灾；所以要拧紧连接头，用扎带固定好电线，避免移动应用时电线摇晃而造成连接头松散■控制器上的蓄电池接线端子既可以同一只蓄电池连接，也可以同一组蓄电池连接手册里后续说明都是针对单只蓄电池使用时，但是同样适用于一组蓄电池的系统■系统连接线按照不大于3.5A/mm2 的电流密度进行选取2感谢您选择“视窗之星”系列太阳能电源控制器。
