48LBSB-17立式斜流泵

OWNER’S MANUALEVOLUTION 10500, 12500, 16500, & 18000 SERIES PUMPSIMPORTANT SAFETY INSTRUCTIONSWhen installing and using this electrical equipment, basic safety precautions should always be followed, including the following:1. READ AND FOLLOW ALL INSTRUCTIONS2. WARNING – To reduce the risk of injury, do not permit children to use thisproduct unless they are closely supervised at all times.3. Do not install within an outer enclosure unless so marked.4. SAVE THESE INSTRUCTIONS.WARNING– All electrical wiring of the motor installation must be done by a qualified electrician in accordance with applicable electrical codes. Before working on any motor, be certain that the source of electrical power is off at the main junction box.BONDING WIRE – Upon installation of the pump, the motor must be used with a No. 8 AWG (8.4mm2) solid copper conductor per National Electric Code. The connection should be from the accessible wire connector on the motor to all metal parts of the water garden and to all electrical equipment, metal conduit and metal piping within 5 feet (1.5m) of the inside walls of the water garden, when the motor is installed within 5 feet of the inside walls of the water garden.NOTE: For electrical connection, see wiring diagram on motor rating plate.CAUTION: This Pump Has Been Evaluated for Use With Water Only.WARNING Risk of Electric Shock – This pump is supplied with a grounding conductor and grounding-type attachment plug. To reduce the risk of electric shock, be certain thatit is connected to a properly grounded, grounding-type receptacle. (56.1 b)INSTALLATION & OPERATING INSTRUCTIONS GENERALYour Evolution pump has been quality built and engineered to give maximum efficiency under normal water pumping conditions. Consult the manufacturer for any other applications. INSTALLATIONI. LOCATION OF PUMPFor best pump performance, locate the system as close to the water source as possible. Provide adequate access around the pump for inspection and maintenance. Place pump on a firm level surface. Pump need not be bolted down unless required by local code.II. MODELS WITH TRAPAvoid excessive tightening of pipe or fittings in any areas where threaded connections are used. For NPT threaded connections, use Quick-Seal Teflon Thread Sealing Compound, Plasto-Joint Stick or any other sealants formulated specifically for plastics. OPERATIONI. STARTING & PRIMING PUMPDo not run unit dry. Always be certain that the pump casing and/or trap is filled with water before starting the unit. Allow a reasonable amount of time for priming. If pump will not start, or will not prime, see trouble shooting section of this manual.II. MAINTENANCEThe trap basket should be inspected frequently and kept clean. To avoid damage to the basket, do not strike when cleaning. Inspect trap cover O-ring regularly and replace as necessary.CAUTION: Do not remove hair and lint strainer lid while pump is running or under pressure! Lid is held in place by lock handles, which can be removed or tightened by hand. Basket must be kept clear of leaves and debris at all times. Keep motor clean. Insure that louvered openings are free from debris and obstructions. Over a period of time, the shaft seals may become damaged or worn and must be replaced. III. WINTERIZATIONTo prevent damage during freezing conditions, turn off all electrical power. Drain thoroughly and clean out any debris. Protect pump and motor from elements by covering or if possible, store in dry well ventilated room.MOTORYour pump is equipped with a permanently lubricated, maintenance-free, heavy-duty industrial quality motor especially designed to withstand the heavy-duty requirements of water garden application. Wiring connection must agree with incoming line voltage. Improper wiring can cause serious injuries and damage to the motor, voiding warranty. (For wiring instructions, see diagram on motor rating plate.)NOTE: Motor is designed to withstand the effects of normal rainfall. To increase the life of your motor observe the following:1.) Do not flood the motor or submerge in water. Todo so voids warranty.2.) Provide ample cross ventilation, minimum of 6” atall points.3.) Keep motor and surrounding area clean.4.) Avoid sweeping or stirring dust near motor whileit is running.5.) Avoid storing or spilling dry chemicals, powders,etc. near motor.6.) Provide protection against the elements.7.) Locate motor on a slight elevation so water willdrain away from motor.8.) Avoid spilling or dripping liquid chemicals on ornear motor.9.) Avoid splashing water or hosing area near motor.Water damage voids warranty. For replacements contact your local supplier or authorized serviceman.TROUBLESHOOTINGMOTOR WILL NOT START:1. Check Circuit Breakers2. Check for incorrect or loose wire connections.3. Make sure the correct power supply is being used.4. Any on/off switch or pneumatic switch should be in the “on” mode.MOTOR OVERHEATING AND CYCLING ON AND OFF:1. Check for incorrect or loose wire connections.2. Check for low voltage supply (frequently caused by undersized wire).3. Make sure the motor gets a fresh air supply and the vents are kept unclogged.MOTOR MAKES HUMMING NOISE BUT WILL NOT START:1. Make sure motor shaft turns free.2. Check for jammed impeller or an obstruction in (volute) casing.3. Check for low voltage and undersized wire.PUMPS WILL NOT PRIME1. Make sure pump is installed at the proper level and the plumbing lines hae been correctly installedto allow the water to enter pump freely.2. Open air control valves to release any possible air lick.3. Make sure all suction and discharge lines are clear and unobstructed and all valves are opened.4. Check for air leaks in the suction line.LOW WATER FLOW:1. Check filter pressure gauge, filter may need cleaning.2. Check for clogged plumbing lines.3. Check for worn or damaged impeller.4. Check for low voltage.WATER LEAKS:1. Check contamination or damage to shaft rotary seal. Replace if necessary.2. Check compression fitting (union connectors), make sure they are properly aligned and secured.Hand tighten only. Do not use tools.3. Make sure O-ring is properly seated and not damaged.NOISES:1. Check plumbing vibration-make sure lines are adequately supported.2. Check for cavitations, due to obstruction in or undersized suction line.IF PUMP LOSES PRIME, OR TOO MANY BUBBLES COME THROUGH RETURN LINE CHECK:1. Hair and lint pot cover is tight and O-ring is in place and free from defects.2. Valves on suction and return lines are working properly and open.3. Water level in water garden is too low.4. Filter O-ring or gasket is in place and free from defects.5. All fittings and connections are secure and air tight.EVOLUTION ASSEMBLY INSTRUCTIONS(Including Impeller and Seal Replacement)WARNING: ALWAYS DISCONNECT THE ELECTRICAL POWER FROM THE PUMP MOTOR BEFORE PERFORMING ANY WORK ON THE PUMP UNIT.To Disassemble Pump:CAUTION: DRAIN THE WATER FROM THE PLUMBING LINES BEFORE DISCONNECTING THE PUMP, ALWAYS PROTECT THE MOTOR FROM POSSIBLE WATER DAMAGE.Removing Suction Cover:1. Remove the cover by removing the screws securing the cover to the volute (casing). These screwsare located at the perimeter of the cover.2. Note the orientation of the loose wear ring on the impeller hub before disassembling.Removing Impeller:1. Hold the motor shaft from rotating as follows: At the rear of the motor, insert a wide bladescrewdriver in the shaft end slot, or use a needle nose “vise grip” or pliers to hold the shaft between the motor face and impeller sleeve opening. Caution: Do not grip impeller sleeve.2. Turn the impeller counter clockwise until it is completely free from the motor shaft thread. Removing the Volute (Casing) from the Motor:1. Unscrew the four (4) bolts located at the rear of the motor. These bolts extend through the entirelength of the motor into the 4 legs of the volute.2. When the 4 legs of the volute are completely disengaged from all the bolts, slide the volute off ofthe motor shaft.Inspecting the Seal:1. Carefully examine the surfaces of the carbon disk (black rigid part of seal rotating assembly,mounted on impeller) and the white ceramic ring (at seal stationary assembly on volute) for edge chipping, surface scratches, or uneven wear. The surfaces should be smooth and free from damage.2. The rest of the seal assembly should be free from cracks and should fit snugly with their respectivemating parts.3. Use alcohol wipes or isopropyl alcohol with clean “lint free” soft cloth to clean the carbon disk andthe ceramic ring surface if reusing the same assemblies.NOTE: IT IS ADVISABLE TO REPLACE THE COMPLETE SEAL ASSEMBLY (BOTH THE CERAMIC AND CARBON SIDES) EVERYTIME THE PUMP IS DISSASSEMBLED.Removing the Seal Assemblies:1. Remove the seal rotating assembly from the impeller by carefully sliding if off the impeller sleeve.2. Remove the ceramic ring and rubber boot by knocking it out and/or prying it loose through the rearopening of the volute. Be sure not to scratch or damage the ceramic surface if you are reusing this part. Caution must be used so as not to damage the volute wall.Installing the New Seal Assemblies:1. Seal Rotating Assembly: Carbon Disk, Spring, Steel Collar, Rubber ringa. Before installing the seal rotating assembly, apply water to the shaft sleeve.b. Grasp the assembly with the carbon disk facing outward. Insert the impeller sleeve through thesteel collar side. Using a twisting motion, push until the steel collar touches the base of thesleeve.2. Seal Stationary Assembly: Ceramic Ring, Rubber Boota. Before installing the stationary assembly, apply water to the rubber boot’s ribbings.b. Being careful not to damage the ceramic ring surface, press the seal assembly squarely intothe seal cavity of the volute.Reinstalling the Volute (Casing) to the Motor:1. Align the four bolts located at the rear of the motor, with the 4 volute legs. These bolts extendthrough the entire length of the motor, into the legs of the volute.2. Pre-tighten the four bolts. Make sure that the motor shaft is accurately located in the center of (nottouching) the ceramic ring.3. When the motor shaft is properly located, tighten the four bolts to secure the volute in place. Reinstalling the Impeller:1. Hold the motor shaft from rotating as follows: At the rear of the motor, insert a wide bladescrewdriver in the shaft end slot, or use a needle nose “vise grip” or pliers to hold the shaft between the motor face and impeller sleeve opening.2. Thread the impeller clockwise over the motor shaft. Hand tighten only. Make sure the seal carbondisk is in contact with ceramic ring. Caution: Do not grip impeller sleeve.3. Reinstall the wear ring over the impeller hub in correct orientation.Reinstalling the Suction Cover:1. Inspect the o-ring for damage. Replace if necessary.2. Properly install the o-ring on the cover before mounting the cover to the volute.3. Cover can be mounted to the volute in one orientation only. An “aligning” feature is built-in witheach part, to ensure proper mounting. When properly aligned, the cover should slide in easily.4. Secure the cover to the volute with screws. Tighten all screws alternately (crisscrossing the cover)to achieve proper o-ring compression and cover seating.5. Rotate the impeller by hand to make sure that it is rotating freely, without any interference. Reconnecting the Pump Unit:1. Clean the seals, gaskets, or o-rings of the plumbing connectors. Replace if cracked, worn, ordamaged.2. Reconnect the plumbing lines to the pump. Hand tighten only.3. Be sure that the pump unit is secured properly to the platform or base, if applicable. Tighten thebolts if necessary.4. Reconnect the power supply. Be sure that all wires are properly and securely connected.To order replacement parts please contact your local authorized dealer.CAUTION: BEFORE TURNING THE POWER ON, BE SURE THAT: 1) THERE IS AN ADEQUATE AMOUNT OF WATER IN THE SYSTEM; 2) ALL VALVES ARE OPEN TO ALLOW WATER CIRCULATION; 3) ALL CONNECTORS AND FITTINGS ARE PROPERLY ALIGNED AND SECURE.EVOLUTION SERIES PUMP LIMITED WARRANTYAdvantage Manufacturing, Inc.WARRANTS TO:The original retail purchaser only, that the products they manufacture are free from defects in material and/or workmanship for a period of one year (pump seals warranty for 30 days) from date of purchase. If within the first two years, any such products shall prove defective, it shall be repaired or replaced at Advantage Manufacturing Inc.’s option as follows:The original retail purchaser shall first contact the installing dealer, as soon as possible after discovery of the defect, but in no event later than the expiration date of this warranty. Or upon notification,Advantage Manufacturing, Inc.Customer Service Department624B South B Street, Tustin, CA 92780Will advise the consumer of the address to which the defective item may be shipped, together with the model number, serial number and date of purchase of item claimed to be defective. The consumer must pay for all shipping charges. EXCLUSIONS:1. This warranty shall not apply to any failuresresulting from negligence, abuse, misuse,misapplication, improper installation, alterationor modification, chemical corrosion, orimproper maintenance.2. Any items manufactured by other companiesand used by Advantage Manufacturing, Inc. inits products may carry warranties by theoriginal manufacturers.3. Advantage Manufacturing, Inc. is not liable forincidental or consequential damages, loss oftime, inconvenience, incidental expenses, laboror material charges in connection with removalor replacement of the equipment.4. Advantage Manufacturing, Inc. is notresponsible for any implied warranties orrepresentations by others and the foregoingwarranty is exclusive and in lieu of allwarranties provided herein.Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.This warranty gives you specific legal rights and you may also have other rights, which vary from state to state.Advantage Manufacturing, Inc.624B South B StreetTustin, CA 92780TEL: 714-505-1166 / FAX: 714-505-1160。

28LBSB-52立式斜流泵 斜流泵又叫做导叶式混流泵，具有占地面积少、外径小、易启动以及效率高等优性，是一种性能和结构介于离心泵和轴流泵之间的水泵，补偿了两者的缺点同时具有两者的优点，。

斜流泵的比转速在290～590,目前其应用范围也开始逐渐向其他泵类产品的领域拓展。

TKX(S)、LKX(S)、LBX(S)型立式斜流泵，适合作大型火电站和核电站的循环泵，作冶金、城市和农田给排水和工矿工程泵，用来输送55℃以下的清水、雨水、污水以及海水。

28LBSB-52立式斜流泵型号说明： 80LKXC-20A 80-泵的吐出口径(寸，即2000/25=80) L-表示立式斜流泵，T表示叶片可调; K-表示泵转子可抽出，B表示转子不可抽; X-表示泵吐出口在基础层之下，S表示吐出口在基础层之上; C-泵的设计顺序; 20-泵设计点扬程; A-表示叶轮经过切割。

28LBSB-52立式斜流泵数据参数： 流量Q 0.20~25m3/s 扬程H 3~60m 28LBSB-52立式斜流泵结构型式： 立式斜流泵轴均为立式安装，吸入口垂直向下，吐出口水平外伸，转子部件有可抽出式和不可抽出式两种形式。

T型泵的叶轮片叶片角度可在机组运行中进行改变。

安装方式有泵、电动机分别安装在两个基础层和泵、电动机直联安装在一个基础层两种形式。

密封用填料密封。

泵的吸入水池有湿坑式和干坑式两种。

立式斜流泵的轴向推力一般由电动机承受，小型立式斜流泵也可由泵自身承受。

叶轮通常为一级，根据需要也可设计成多级。

立式斜流泵的轴承采用橡胶轴承和赛龙轴承两种，当采用橡胶轴承时，泵轴设有保护套管，内心清洁压力水进行润滑。

28LBSB-52立式斜流泵零件材质： 立式斜流泵泵轴为优质碳素钢。

叶轮为铸铁或铸钢或不锈钢。

其余为铸铁，或钢板焊接。

28LBSB-52立式斜流泵成套范围： 成套供应泵，电动机和底座或安装垫板。

28LBSB-52立式斜流泵性能参数：参数 型号流量Q 扬程H 转速n 轴功率Pa 配带电动机效率η必须汽蚀余量叶轮名义直径吐出口径泵重功率型号m 3/s m r/min kw kw %mmm mm t 12LBSA-400.180.240.2940.438.034.5980102.0111.8121.8160YLST355-6W 70.079.081.0 5.105.306.705583006.112LBSA-440.210.270.3244.040.034.51480116.7131.8138.0160YLST355-477.081.079.67.409.0010.904343003.812LBSA-540.160.180.2856.554.046.01480113.4121.3173.6185YKSL355-4W 76.080.072.0 3.003.604463004.014LBSA-160.280.330.3919.016.014.0148064.761.961.390YLST280M-480.087.087.15.906.707.10362.6350 4.512LBSA-600.220.310.3664.055.047.01480181.9202.3207.5250YKSL355-4W80.585.584.28.108.909.30481.43507.016LKXA-160.390.440.5020.017.816.3148084.085.080.0112YLST355S-480.084.078.04.205.006.50393.47400 5.016LBSA-200.340.360.4520.520.018.398085.389.896.1132YLST315L2-680.083.084.04.304.404.90450.88400 3.516LBSA-300.310.360.4037.533.030.0980142.0142.4146.2185YKKL355-6W79.082.081.05.105.706.50579.8400 4.816LBSA-450.350.400.4947.445.039.1980196.2207.7218.6250YKSL450-682.385.085.36.606.807.40617.5400 4.316LBSA-470.280.350.3951.747.043.01480189.5203.8214.9250YKSL355-4W74.378.576.36.838.019.50462.1400 5.016LBSA-650.440.560.5878.265.061.01480399.4416.6414.2500YKKL500-485.485.084.27.6011.4012.00579.8400 4.220LBSA-200.440.560.6722.820.015.6980122.3129.9139.6185YKSL355-6W81.383.973.14.885.387.78450.95005.5。

上海沈泉泵阀制造有限公司是集研究、开发、生产、销售和服务为一体的泵阀生产企业。

产品涉及工矿企业、农业、城市供水、石油化工、电站、船舶、冶金、高层建筑、消防供水、工业水处理和纯净水、食品、制药、锅炉、空调循环系统等行业领域。

一、上海品牌厂家沈泉泵阀生产制造的CDL轻型不锈钢多级离心泵产品特点1、采用优良的水力模型和先进的制造工艺，大大提高泵的性能及使用寿命。

2、由于轴封采用材料为硬质合金及氟橡胶的机械密封，可提高泵运行的可靠性及输送介质的温度。

3、泵的过流部分采用不锈钢板冲压焊接而成，使得泵可适用于轻度腐蚀性介质。

4、整体结构紧凑、体积小、重量轻、噪声低、节能效果显著，检修方便。

5、泵的进水口与出水口位于泵座同一水平线上，可直接用于管路当中。

6、采用标准电机，用户可方便地根据需要配备电机。

7、可根据用户需要配备智能保护器，对泵干转、缺相、过载等进行有效保护。

8、本公司产品全程质量监控，全方位检测，保证产品质量!9、交货快捷：先进生产流水线，备货充足，常规产品现货供应!10、个性定制：高G工程师专业选型报价，各种材质非标产品可根据现场实用要求定做!二、CDL轻型不锈钢多级离心泵产品用途供水：水厂过滤与输送、水厂分区送水、主管增压、高层建筑增压。

工业增压：流程水系统、清洗系统、高压冲洗系统、消防系统。

工业液体输送：冷却和空调系统、锅炉给水和冷凝系统、机床配套、酸性和碱性介质输送。

水处理：超滤系统、反渗透系统、蒸馏系统、分离器和游泳池的水处理系统。

灌溉：农田灌溉、喷灌、滴灌。

各行业不同工况CDL轻型不锈钢多级离心泵适用型号的选型及不同材质和配置下的价格问题欢迎致电24小时报价热线400-6656-887咨询2022年多级管道离心泵厂家直销价格，同时可提供外形尺寸、安装图纸，结构图纸、曲线图谱和安装尺寸等数据。

三、CDL轻型不锈钢多级泵使用条件1、介质温度：-15℃~+120℃。

2、Z大环境温度：+40℃。

大型立式斜流泵型式与基本参数大型立式斜流泵是一种常用的泵类设备，它具有独特的结构和优越的性能。

本文将介绍它的型式和基本参数，希望能为读者提供一定的指导意义。

首先，我们先来了解一下大型立式斜流泵的型式。

根据其结构形式，大型立式斜流泵主要分为单级和多级两种型式。

单级斜流泵通常由一个蜗壳和一个叶轮组成，适用于低扬程、大流量的工况。

而多级斜流泵则由多级叶轮和蜗壳组成，适用于高扬程、小流量的工况。

接下来，我们来看一下大型立式斜流泵的基本参数。

首先是流量。

大型立式斜流泵的流量通常较大，能够满足工业生产的需求。

其次是扬程。

大型立式斜流泵的扬程较高，能够将水从低处输送到高处。

再次是效率。

大型立式斜流泵具有较高的效率，能够将电能转化为水的能量，降低能耗。

最后是轴功率。

大型立式斜流泵的轴功率通常较大，需要配备强大的电机来驱动。

除了以上的基本参数，大型立式斜流泵还有一些其他的特点和性能。

首先是结构紧凑。

大型立式斜流泵的结构紧凑，占地面积小，适合安装在狭小的场地上。

其次是运行稳定。

大型立式斜流泵的叶轮由高精度的动平衡处理，运行平稳，振动小。

再次是维修便捷。

大型立式斜流泵的蜗壳和叶轮采用分体结构，方便维修和更换零部件。

最后是使用寿命长。

大型立式斜流泵采用耐磨材料制作叶轮和蜗壳，使用寿命长，能够满足长期运行的需求。

综上所述，大型立式斜流泵是一种结构紧凑、运行稳定、维修便捷、使用寿命长的泵类设备。

在选择和使用时，需要根据具体的工况和需求来确定型式和基本参数。

希望本文对于读者有所帮助，能够提供一定的指导意义。

立式斜流泵安装及其调试摘要：本文重点介绍了800VZNM型立式斜流泵安装及其调试，对安装过程中存在的问题的产生原因和如何对其采取整改以及安装流程、调试过程和注意事项的论述。

关键词：斜流泵；调试；整改；安装流程；注意事项1. 概况东莞市第六水厂，是采用臭氧－生物活性炭工艺进行深度处理的水厂。

由于比常规水处理多了一道工序，所以在设计上增加了多组臭氧接触池与炭滤池，需要将水位提升至6米，二期安装工程改用由中日合资生产的800VZNM型立式斜流泵，共4台机组。

2. 立式斜流泵的性能参数及其安装流量：4320m3/h，扬程：6.1m，转速：595r/min，功率：132KW2.1安装水泵出厂时，原则上水泵的一体组装在工厂内完成，但是也会有以零部件解体的状态出厂的状况，原因如下。

(1)泵体过长，搬运时需要解体。

(2)泵房的安装高度太低，没有足够的起吊空间。

解体出厂的水泵，在水泵安装现场进行组装。

2.1.1安装前的准备(1)安装动工前须充分研究讨论施工计划与图纸等资料。

(2)卸货吊入时，为了防止损坏零件，请务必注意以下事项。

(a)在起吊易变形的零部件时，还没有组装之前不要拆除它们的加固部件(轴固定部件等)。

(b)为了防止装配在水泵机体上的小配管、阀门、测量仪表等部件的破损，须小心搬运轻拿轻放。

(c)为了防止油漆脱落，请在钢丝绳与泵体接触的部位垫入保护物。

此外，确认钢丝绳不会脱落后，再起吊。

2.1.2安装时的注意事项(1)安装用垫铁(a)尽量把底座与基础面之间的垫铁放置在靠近基础螺栓的地方。

(b)垫铁组合一般有两种：2枚斜垫铁1枚平垫铁为一组；平垫铁2～3枚为一组。

(c)使用斜度为1/20～1/50的垫铁。

(2)基础螺栓的固定方法安装水泵时，最为常见的基础螺栓固定的施工方法有箱式方孔埋入的方法和使用模板（定位板）将基础螺栓与混凝土一起埋入的方法。

(a)箱式方孔埋入法是，浇注基础混凝土的时候事先预留出基础螺栓用的箱式方孔，装入水泵之后再将基础螺栓固定的施工方法。

88LKXE-27型泵安装使用说明书88LKXE-27 SM长沙水泵厂有限公司二○○九年三月目录产品简介 (4)第一章型号说明及资料单 (5)泵资料单 (5)主要零部件大约重量 (6)第二章安装 (7)2.1 安装前的准备 (7)2.2 流程图 (8)2.3 泵基础的灌浆及安装垫板的校水平 (8)2.4 泵、电机和其它部件的安装 (10)2.4.1泵壳部件的安装 (10)2.4.2第二次校水平 (11)2.4.3灌浆 (11)2.4.4可抽部件的安装 (11)2.4.5导流片接管、导流片、填料部件的安装 (12)2.4.6测量转子窜动量、盘车、泵轴中心位置调整 (12)2.4.7泵联轴器的安装 (13)2.4.8 电机支座的安装 (13)2.4.9电机的安装 (13)2.4.10转子调整 (14)2.4.11填料的安装 (14)2.4.12完成其他安装工作 (14)第三章运行 (15)3.1 运行前的准备 (15)3.2 启动与停车 (15)3.2.1启动前的准备 (15)3.2.2启动与停车方法 (15)3.3 运行注意事项 (15)3.4 停车注意事项 (15)3.5 事故停机 (15)第四章泵的运行检查、拆卸、检修、维护 (16)4.1 运行日志 (16)4.2 运行检查 (16)4.3 拆卸 (16)4.4 零件检查 (16)4.5 泵的维修 (17)4.6 泵停用期维护 (17)第五章常见故障、原因及措施 (18)附件清单： (19)欢迎使用长沙水泵厂生产制造的大型立式斜流泵产品简介尊敬的客户，衷心感谢贵单位使用长沙水泵厂有限公司生产的立式斜流泵。

88LKXE-27型立式斜流泵是我公司引进美国I-R公司的先进技术发展起来的产品，适合作大型火电站和核电站的循环泵，作冶金、大型水利、城市给排水和工矿工程泵，用来输送55°以下的清水、雨水、污水和海水。

到目前为止，长沙水泵厂有限公司生产的立式斜流泵已有1200多台。

优秀水泵制造商-上海沈泉泵阀制造有限公司是一家专业生产，销售管道泵，隔膜泵，磁力泵，自吸泵，螺杆泵，排污泵，消防泵，化工泵等给排水设备的厂家，产品涉及工矿企业、农业、城市供水、石油化工、电站、船舶、冶金、高层建筑、消防供水、工业水处理和纯净水、食品、制药、锅炉、空调循环系统等行业领域。

一、LW直立式无堵塞排污泵1.流量：8-2600m³/h2.扬程：7-60m3.转速：2825r/minLW直立式无堵塞排污泵适用于化工、石油、制药、采矿、造纸工业、水泥厂、炼钢厂、电厂、煤加工工业，以及城市污水处理厂排水系统、市政工程、建筑工地等行业输送带颗粒的污水、污物，也适用于抽送清水及带腐蚀性介质。

二、DL型立式多级离心泵1.流量：3.75~850m³/h2.扬程：39~1200m3.转速：2900r/minDL型立式多级离心泵适用于城市供水、消火系统、水力发电厂、海上石油钻探等场合，具有可靠、节能、高效等特点。

三、ISGD型立式管道泵1.流量：6.3~400m³/h2.扬程：5~125m3.转速：1450r/minISGD型立式管道泵适用于输送清水、或物理化学性质类似于清水的液体，具有结构紧凑、运转平稳等特点。

四、YDL型立式旋涡泵1.流量：1.1~122m³/h2.扬程：6~74m3.转速：2900r/minYDL型立式旋涡泵适用于城市给排水、市政工程、供水系统、工业水处理系统等场合，具有自吸功能、无泄漏、运行可靠等特点。

五、JYWQ型立式污水泵1.流量：8~400m³/h2.扬程：5~80m3.转速：2900r/minJYWQ型立式污水泵适用于污水处理、城市污水厂、建筑厂房排污、医院污水处理等场合，具有结构简单、性能可靠、防漏等特点。

六、CDLF不锈钢立式多级管道泵1.流量：4.2-504m3/h2.扬程：24-240m3.转速：1480r/minCDLF立式多级泵是一种广泛应用于供水、消防、工业循环系统等领域的高效能泵，具有重要的作用和功能。

概述LKX（S）（Ⅱ）、LBX（S）（Ⅱ）型立式斜流泵是本公司年经过多年的研究，同时吸取国内外有关厂家所有生产斜流泵的优点而发展起来的新品种。

供输送80℃以下的清水、雨水、污水和海水，广泛用于原生水处理厂、污水处理厂、冶金钢铁行业、发电厂、矿山、市政工程以及农田水利工程。

参数范围；流量；Q；30—25000m3/h扬程；H；7-106m泵型号意义；例400 L K X （S）（Ⅱ）---62A泵设计点扬程（m），A表示叶轮经过切割泵级数（1级时不表示）S表示泵的吐出口在基础层之上X表示泵在吐出口在基础层之下K表示转子可抽出，B表示转子不可抽立式斜流泵泵吐出口径（mm）结构说明；该泵为单、多级立式斜流泵。

泵为立式安装，吸入口垂直向下，吐出口水平外伸；转子部件有可抽出式和不可抽出式两种；泵轴向力可由电动机承受，也可根据需要设计成由泵本身承受；泵的导轴承一般为填充聚四氟乙烯、橡胶或塞龙轴承，也可根据用户要求选用其他轴承材料；泵轴设有保护套管，内通清洁压力水，用于润滑冷却导轴承。

产品特点；1。

采用英格索兰公司、日立制作所、久保田株式会社等知名企业水力模型及结构，运行效率高，与国内同类产品相比，效率普遍高3-5%，配套电机功率普遍减低。

因此，既降低了用户的采购成本，也降低了用户使用成本，达到节能降耗的目的2。

泵吐出口径1000mm以下的泵已系列化、标准化。

既降低了生产成本，也降低了用户使用成本；根据档案，常用备品备件预先储备生产，备品备件做到用户马上订货，马上供货。

3。

泵立式安装，基础占地面积少，节省泵房及土建费用；如采用户外电机，露天安装，无需泵房。

4。

立式泵转子重量在垂直方向，径向力小，运行平稳，震动小，噪声低，使用寿命长。

5。

如采用转子可抽式结构，维护简便，维护量小，节省检修时间。

6。

叶轮淹没于抽送介质中，启动时无需灌引水，且汽蚀性能好。

7。

泵轴，中间接管及泵轴保护套管为多节；中间接轴采用套筒联轴器，径向同轴度高，能最大限度减少机组震动；中间接管数量可根据用户需要增减，适应不同的液下深度。
