中国安防知名品牌康 联 视 频 压 缩 卡用户手册目录一、系统简介 (2)二、硬件安装 (5)三、驱动程序安装 (5)四、系统程序安装 (16)附录常见问题解答 (17)- 1 -第一章系统简介1.1简介本用户手册描述了康联视频压缩卡有关的硬件安装、软件安装、系统设置、软件使用等方面的内容，请务必按照用户手册的指导进行这些工作，以确保监控系统正常、稳定地运行。

1.1建议系统标准配置CPU 赛扬 2.8G以上(24路)，赛扬2.4G以上(16路),赛扬 1.8G以上(8路)主板华硕、技嘉等商用主板或更高845主板芯片组 IntelDDR或更高内存 256M硬盘 80G（根据通道数量和录像时间确定）至少分两个区电源350－400W AT显示器 17英寸SVGAPCI插槽 3.3V PCI2.1显卡64M独立显存，支持DirectDraw和Overlay技术，操作系统 WindowsXP，Windows 2000，Windows 2003,Windows Me, Windows 98 Se8.0以上显示驱动 DirectX其他外设声卡、光驱等根据需要配置- 2 -注：1、显示器分辨率设定为1024×768。

2、在系统安装完后，在控制面版中的电源选项里将关闭硬盘、关闭监视器和系统待机等选项设置为“从不”。

3、检查所有设备是否存在冲突，对于存在冲突的设备，可以通过调整中断号、内存地址或者重新安装驱动程序等方法来解决。

1.2系统参数视频特性*视频输入：CVBS输入*支持制式：PAL、NTSC*压缩分辨率：352×288(PAL)，320×240(NTSC)*单通道帧率：25F/S（PAL），30F/S(NTSC)音频特性*语音输入：语音线路输入*监听采样率：32KHz*录音采样率：8 KHz功能特性录像输出格式可选音视频符合流或单独视频流单路录像帧率在1-25帧(1-30帧)- 3 -压缩方式:H.264画面显示方式:满屏、4、9、16、25通道、循环切换实时显示.智能搜索标准:时间,日期,摄像机,报警,事件录像模式设置：全速实时录像、定时录像、事件录像支持静态图像捕捉实时录像：所有信道并行全帧速录像智能搜索/直观回放:利用时间日期表/报警事件/视频移动探测进行搜索回放回放操作：播放、暂停、快进、快倒、开始、结尾、逐帧多功能操作：支持边录边监视，边录边回放动态检测：多区域多灵敏度移动侦测,实现“动则录，不动则不录”，有效节省磁盘空间；摄像控制功能：本地及远程控制全方位云台/镜头/预置功能开机自动恢复功能：内置WATCH DOG安全访问：完备的系统访问安全措施,具有功能很强的存储区保护功能；网络功能:可以使用PC客户端软件或IE流览器通过以太网或广域网远程设置系统的参数、实时监控、录像、回放.录像大小:100M/路/小时支持压缩流/预览流叠加时钟，多国文字的功能录像格式全面兼容微软播放器超低功耗设计，板卡结构紧凑，系统稳定- 4 -第二章硬件安装1、打开机箱，露出主机板和PCI 插槽。
