LG2200操作手册(1)

TYPE: Multi VOWNER’S MANUALAIR CONDITIONERPlease read this manual carefully before operatingyour set and retain it for future reference.Safety PrecautionsSafety PrecautionsnMeanings of symbols used in this manual are as shown below.Have all electric work done by a licensed electrician according to "Electric Facility Engineering Standard" and "Interior Wire Regulations" and the instructions given in this manual and always use a special circuit.• If the power source capacity is inadequate or electric work is performed improperly, electric shock or fire may result.Ask the dealer or an authorized technician to install the air conditioner.• Improper installation by the user may result in water leak-age, electric shock, or fire.Always ground the product.• There is risk of fire or electric shock.Always intstall a dedicated circuit and breaker.• Improper wiring or installation may cause fire or electric shock.For re-installation of the installed product, always con-tact a dealer or an Authorized Service Center.• There is risk of fire, electric shock, explosion, or injury.Do not install, remove, or re-install the unit by yourself (customer).• There is risk of fire, electric shock, explosion, or injury.Do not store or use flammable gas or combustibles near the air conditioner. • There is risk of fire or failure of product.Use the correctly rated breaker or fuse.• There is risk of fire or electric shock.Prepare for strong wind or earthquake and install the unit at the specified place.• Improper installation may cause the unit to topple and result in injury.Do not install the product on a defective installation stand.• It may cause injury, accident, or damage to the product.Safety PrecautionsVentilate before operating air conditioner when gas leaked out.• It may cause explosion, fire, and burn.Securely install the cover of control box and the panel.• If the cover and panel are not installed securely, dust or water may enter the outdoor unit and fire or electric shock may result.If the air conditioner is installed in a small room, measures must be taken to prevent therefrigerant concentration from exceeding the safety limit when the refrigerant leaks. • Consult the dealer regarding the appropriate measures to prevent the safety limit from being exceeded. Should the refrig-erant leak and cause the safety limit to be exceeded, harzards due to lack of oxygen in the room could result.Don't use the existing manifold gage for R22 refriger-ant.• Use the manifold gage for high pressure (R410A) as possible as for stable refrigerant filling.Don't mix and use the R22 pipe and the installation appliances that were used until now • Mixing the oil of R22 and R410A may cause failure of the unit due to hydrolysis.When installing and moving the air conditioner to another site, do not charge it with a different refriger-ant from the refrigerant specified on the unit.• If a different refrigerant or air is mixed with the original refrigerant, the refrigerant cycle may malfunction and the unit may be damaged.Do not reconstruct to change the settings of the pro-tection devices.• If the pressure switch, thermal switch, or other protection device is shorted and operated forcibly, or parts other than those specified by LGE are used, fire or explosion may result.Do not open the inlet grill of the product during operation. (Do not touch the electrostatic filter, if the unit is so equipped.)• There is risk of physical injury, electric shock, or product failure.Be cautious not to touch the sharp edges when installing.• It may cause injury.Take care to ensure that nobody could step on or fall onto the outdoor unit.• This could result in personal injury and product damage.• There is risk of fire, electric shock, explosion, or injury.• There is risk of fire or electrical shock.Be cautious that water could not enter the product.• There is risk of fire, electric shock, or product damage.Do not touch the power switch with wet hands.• There is risk of fire, electric shock, explosion, or injury.Take care so that children should not randomly oper-ate the wire remote control for play.• Frequent conversion to cold or heat mode may cause fail-ure of the unit.When the product is soaked (flooded orsubmerged), contact an Authorized Service Center.• There is risk of fire or electric shock.Safety Precautions• Low refrigerant levels may cause failure ofproduct.• It may cause a problem for your neighbors.Keep level even when installing the product.• To avoid vibration or water leakage.Do not install the unit where combustible gas may leak.• If the gas leaks and accumulates around the unit, an explosion may result.Use power cables of sufficient currentcarrying capacity and rating.• Cables that are too small may leak, generate heat, and cause a fire.Do not use the product for special purposes, such as preserving foods, works of art, etc. It is a consumer air conditioner, not a precision refrigeration system. • There is risk of damage or loss of property.Keep the unit away from children. The heat exchanger is very sharp.• It can cause the injury, such as cutting the finger. Also the damaged fin may result in degradation of capacity.When installting the unit in a hospital, communication station, or similar place, provide sufficient protection against noise.• The inverter equipment, private power generator, high-frequen-cy medical equipment, or radio communication equipment may cause the air conditioner to operate erroneously, or fail to oper-ate. On the other hand, the air conditioner may affect such equipment by creating noise that disturbs medical treatment or image broadcasting.Do not install the product where it is exposed to sea wind (salt spray) directly.• It may cause corrosion on the product. Corrosion, particularly on the condenser and evaporator fins, could cause productmalfunction or inefficient operation.• Oil, steam, sulfuric smoke, etc. can significantly reduce theperformance of the air conditioner or damage its parts.• It may cause failure of appliance or accident.Make the connections securely so that the outside force of the cable may not be applied to the terminals.• Inadequate connection and fastening may generate heat and cause a fire.Be sure the installation area does not deteriorate with age.• If the base collapses, the air conditioner could fall with it, causing property damage, product failure, and personal injury.Install and insulate the drain hose to ensure that water is drained away properly based on the installation manual.• A bad connection may cause water leakage.Safety PrecautionsBe very careful about product transportation.• Only one person should not carry the product if it weighs more than 20 kg.• Some products use PP bands for packaging. Do not use any PP bands for a means of transportation. It is dangerous.• Do not touch the heat exchanger fins. Doing so may cut your fingers.• When transporting the outdoor unit, suspending it at the specified positions on the unit base. Also support the outdoor unit at four points so that it cannot slip sideways.Safely dispose of the packing materials.• Packing materials, such as nails and other metal or wooden parts, may cause stabs or other injuries.• Tear apart and throw away plastic packaging bags so that chil-dren may not play with them. If children play with a plastic bag which was not torn apart, they face the risk of suffocation.Turn on the power at least 6 hours before starting operation.(In case of outdoor temperature below 10°C)• Starting operation immediately after turning on the main power switch can result in severedamage to internal parts. Keep the power switch turned on during the operational season.Do not touch any of the refrigerant piping during and after operation.• It can cause a burn or frostbite.Do not operate the air conditioner with the panels or guards removed.• Rotating, hot, or high-voltage parts can cause injuries.Do not directly turn off the main power switch after stopping operation.• Wait at least 5 minutes before turning off the main power switch. Otherwise it may result in water leakage or other problems.Auto-addressing should be done in condition of connect-ing the power of all indoor and outdoor units. Auto-addressing should also be done in case of changing the Indoor unit PCB.Use a firm stool or ladder when cleaning or maintain-ing the air conditioner. • Be careful and avoid personal injury.Do not insert hands or other objects through the air inlet or outlet while the air conditioner is plugged in. • There are sharp and moving parts that could cause per-sonal injury.Avoid a place where rain may enter since the HR unit is for indoor• There is risk of property damage, failure of product or elec-tric shock.Install the HR unit at a place in which it is not affected by operation mode changing noise.• Installation within cell such as meeting room etc, may dis-turb business due to noise.Sor Juana lnés de la Cruz No. 555Col. San Lorenzo IndustrialTlalnepantla de Baz, Estado de México C.P . 54033Tel. 5321 1919Teléfono sin costo 01 800 347 1919Página web .mxMODELSARUV60LT3ARUV80LT3ARUV100LT3ARUV120LT3ARUV140LT3ARUV160LT3ARUV180LT3ARUV200LT3ARUN80LT3ARUN100LT3ARUN120LT3ARUN140LT3ARUN160LT3ARUN180LT3ARUN200LT3ARUN80LN3ARUN100LN3ARUN120LN3ARUN140LN3ARUN160LN3ARUN180LN3ARUN200LN3ARUV80DT3ARUV100DT3ARUV120DT3ARUV140DT3ARUV160DT3ARUV180DT3ARUV200DT3ARUN80DT3ARUN100DT3ARUN120DT3ARUN140DT3ARUN160DT3ARUN180DT3ARUN200DT3ARUN80BT3ARUN100BT3ARUN120BT3ARUN140BT3ARUN160BT3ARUN180BT3ARUN200BT3ARUB80LT3ARUB100LT3ARUB120LT3ARUB140LT3ARUB160LT3ARUB180LT3ARUB200LT3ARUB80DT3ARUB100DT3ARUB120DT3ARUB140DT3ARUB160DT3ARUB180DT3ARUB200DT3ARUB80LN3ARUB100LN3ARUB120LN3ARUB140LN3ARUB160LN3ARUB180LN3ARUB200LN3ARUB80BT3ARUB100BT3ARUB120BT3ARUB140BT3ARUB160BT3ARUB180BT3ARUB200BT3ARUV80BT3ARUV100BT3ARUV120BT3ARUV140BT3ARUV160BT3ARUV180BT3ARUN80LM3ARUN100LM3ARUN120LM3ARUV100LM3ARUV120LM3ARUV140LM3ARUV180LM3ARUV200LM3。

E2251VR E2351VRE1951C E2051C E2251COWNER’S MANUALLED LCD MONITORPlease read this manual carefully before operating your set and retain it for future reference.LED LCD MONITOR MODELS ENGLISHE1951T E2051T E2251T E2351T E2351TCE1951S E2051S E2251S E2251VQ E2351VQ2TABLE OF CONTENTS CONTENTS3ASSEMBLING ANDPREPARING3 Unpacking4 Parts and buttons6 Setting up the Monitor6 - Assembling the Stand Body and Base7 - Mounting on a table8 - Detaching the Stand Base and theStand Body9 - Mounting on a wall11USING THE MONITOR11 Connecting to a PC11 - D-SUB connection12 - DVI-D connection13 - HDMI connection14CUSTOMIZING SETTINGS14 Accessing The Main Menus15 Customizing Settings15 - MENU Settings16 - SUPER ENERGY SAVING Settings17 - SUPER+ RESOLUTION Settings17 - VOLUME Settings (Only supported inHDMI)18 - DUAL MONITOR Settings18 - DUAL WEB Settings19TROUBLESHOOTING 21SPECIFICATIONS26 Preset Modes (Resolution)27 - HDMI Video Timing27 Indicator28PROPER POSTURE28 Proper posture for using the Monitor. 29LICENSES3ASSEMBLING AND PREPARING4ASSEMBLING AND PREPARING5ENG ENGLISHASSEMBLING AND PREPARING6ASSEMBLING AND PREPARINGSetting up the MonitorAssembling the Stand Body and Base1 Place the Monitor with the screen side down ona flat and cushioned surface.3 Secure the Stand Body the monitor using 2screws.2 Attach the Stand Body from the Monitor.Insert the two Lockers of the Stand Body right into the groove of the Monitor head and secure them by pressing the left and right bottom sides.4 Check the direction of the Stand Base andassemble it with the Stand Body . Using a coin , turn the screw clockwise to secure the Stand Base .ENG ENGLISH8ASSEMBLING AND PREPARINGUsing the Kensington security systemThe Kensington security system connector is located at the back of the Monitor. For more information of installation and using, refer to the manual supplied with the Kensington security system or visit .Connect the Kensington security system cable between the Monitor and a table.NOTEDetaching the Stand Base and the Stand Body1 Place the Monitor with the screen side down ona flat and cushioned surface.2 Using a coin , turn the screw in the Stand Basecounterclockwise. Detach the Stand Base fromthe Stand Body .39ASSEMBLING AND PREPARINGMounting on a wallFor proper ventilation, allow a clearance of 10 cm on each side and from the wall. Detailedinstructions are available from your dealer, see the optional Tilt Wall Mounting Bracket Installation andSetup Guide.ModelE1951SE2051S E2251S E1951T E2051T E2251T E2351T E2351TCE1951C E2051C E2251C E2251VR E2351VR E2251VQ E2351VQVESA (A x B)75 x 75Screw SizeM4Number of screws 4Wall mount bracket (optional)RW120carefully so it will not fall.1 2 3 for it.4 VESA compatible only with respect to screwmounting interface dimensions and mounting screw specifications.5 Please use a VESA standard as below.y 784.8 mm (30.9 inch) and under * Wall Mount Pad Thickness : 2.6 mm * Screw : Φ 4.0 mm x Pitch 0.7 mm x Length 10 mmy 787.4 mm (31.0 inch) and above * Please use VESA standard wall mount pad and screws.10ASSEMBLING AND PREPARING11USING THE MONITOR SETD-SUBDC-IN /䏳㵎幑‣RGB OUTD-SUBDVI-D DC-IN /䏳㵎幑‣HDMID-SUBDVI-D RGB OUTDC-IN /䏳㵎幑‣USING THE MONITORConnecting to a PCy Your Monitor supports Plug & Play*. *Plug & Play: A PC recognizes a connected device that users connect to a PC and turn on, without device configuration or user intervention.D-SUB connectionTransmits analog video from your PC to theMonitor. Connect the PC and the Monitor with the supplied D-sub 15 pin signal cable as shown in the following illustrations.E2251VR E2351VR E2251VQ E2351VQE1951C E1951S E2051C E2051S E2251CE2251S E2051T E1951T E2251TE2351T E2351TC12USING THE MONITOR SETDVI-D connectionTransmits the digital video signal from your PC tothe Monitor. Connect the PC and the Monitor set with the DVI-D cable as shown the following illustrations.D-SUBDVI-D DVI OUTDC-IN /䏳㵎幑‣HDMID-SUBDVI-DDVI OUTDC-IN /䏳㵎幑‣E2251VR E2351VR E2251VQ E2351VQE2051T E1951T E2251TE2351T E2351TC13ENG ENGLISHUSING THE MONITOR SETSelf Image Setting FunctionHDMI connection14CUSTOMIZING SETTINGSCUSTOMIZING SETTINGSAccessing The Main Menus1Press any button on the front of the Monitor to display the MONITOR SETUP OSD menu.15CUSTOMIZING SETTINGSCustomizing SettingsMENU Settings1 MONITOR SETUP OSD menu.2 Press the MENU menu.3 Set the options by pressing the ◄ or ► or ▼ buttons.4 Select EXIT to leave the OSD menu.To return to the upper menu or set other menu items, use theup arrow () button.y Analog: D-SUB(Analog signal) input.y Digital: DVI-D(Digital signal) input.y HDMI: HDMI(Digital signal) input. The available MENU settings are described below.161 2 3 456 The available SUPER ENERGY SAVING settings are described below.The available SUPER+ RESOLUTION settings are described below.19TROUBLESHOOTINGTROUBLESHOOTING20TROUBLESHOOTING21SPECIFICATIONS SPECIFICATIONSE1951S E1951T E1951CProduct specifications shown above may be changed without prior notice due to upgrade of product functions.22SPECIFICATIONSE2051S E2051T E2051CProduct specifications shown above may be changed without prior notice due to upgrade of product functions.23SPECIFICATIONSE2251S E2251T E2251C24SPECIFICATIONSE2251VR E2251VQProduct specifications shown above may be changed without prior notice due to upgrade of product functions.25SPECIFICATIONS E2351TCE2351T E2351VR E2351VQProduct specifications shown above may be changed without prior notice due to upgrade of product functions.26SPECIFICATIONSPreset Modes (Resolution)E1951S/ E1951T/ E1951CE2051S/ E2051T/ E2051CE2251S/ E2251T/ E2251C/ E2251VR/ E2251VQ/ E2351T/ E2351TC/ E2351VR/ E2351VQ● : HDMI PC mode is not supported.27SPECIFICATIONS HDMI Video TimingE2251VR / E2251VQ / E2351VR / E2351VQIndicator28PROPER POSTUREPROPER POSTUREProper posture for using the Monitor.29LICENSES LICENSESSupported licenses may differ by model. For more information of the licenses, visit .HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarksor registered trademarks of HDMI Licensing LLC.Make sure to read the Safety Precautions before using the product.Keep the Owner’s Manual (CD) in an accessible place for future reference.The model and serial number of the SET is located on the back and one side of the SET . Record it below should you ever need service.As an ENERGY STAR Partner LGE U. S. A.,Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency.ENERGY STAR is a set of power-saving guidelines issued by the U.S.Environmental Protection Agency(EPA).MODELSERIAL。

2200 SERIES COMMON DRIVE PACKAGESpecial Capabilities Specification Sheet 975CottonwoodAve.,POBox20,Hartland,Wisconsin53029-0020,USA||***************COMMON DRIVE CONVEYOR SETUPUp to (4) conveyors can be coupled together and driven from a single gearmotor.• Conveyors move at same relative belt speed.• Creates single lanes for handling parts.• Wide parts or pallets can be carried by each conveyor to allow access from below.• Conveyors can be of different widths and lengths.Uses Standard 2200 Series End Drive Conveyors• Aluminum Extruded Frame with T-slot Construction• Sealed Ball Bearings• V-Guided and Non-V-Guided Belt Compatible• Rack and Pinion Belt Tensioning• Conveyor Widths: 1.75" to 24" wide• Conveyor Lengths: End Drive = 2' to 18' long• Belt Speeds: up to 264 ft/minSee Product Engineering Manual or for details.Common Drive Specifications• Drive up to (4) Conveyors from a Single Drive Gearmotor• Fixed Conveyor Locations• Load Capacity: Contact Factory for Details• Compatible with all Standard End Drive Gearmotor Mounting Packages• Includes Aluminum Extruded Conveyor Tie Bar Assembly with Belt Return Roller• Includes Common Drive Couplings and Guarding• Multiple Conveyor Spacing Options• 2" Belt Edge to Belt Edge• 3" Belt Edge to Belt Edge• 4.75" to 24" Belt Edge to Belt Edge1/4-20 T -N U T S6[52]C o m p a t i b l e w i t h a l l W +Profiles:• All 2200 Series profiles are applicable.See Product Engineering Manual or for details. •Belting:• All 2200 Series belting is applicable.• Finger Splice is preferred, plastic and metal clipper splices are available.See Product Engineering Manual or for details. •Mounting Packages & Gearmotors:• All 2200 Series mounting packages and gearmotors are applicable.See Product Engineering Manual or for details. •Support Stands:• All 2200 Series support stands are applicable.See Product Engineering Manual or for details. •EXPRESS INQUIRY FORM: GENERAL INFORMATIONAlong with completing the Express Inquiry form below, please complete the specific 2200 Series Common Drive Conveyor application questions on the next page to the best of your ability.ContactTechnicalSalesat1-800-259-1510(Press3)***************************************************.CONTACT INFORMATIONCompany: ____________________________________________________________ Date: ____________________ Name: _________________________________________________________________________________________ Phone: __________________________ Fax: ________________________ E-Mail: _________________________ Address: _______________________________________________________________________________________ City: ______________________________________ State: ____________ Zip: ___________________________PRODUCTDescription/Material: ______________________________________________________________________________ Dimensions:_____________________________________________________________________________________ Weight: ____________________________________ Total Weight to be Placed on Conveyor: ____________________ Temperature: ________________________________ Leading Edge Dimension: ______________________________ENVIRONMENTChemicals or Fluids Present: ________________________________________________________________________ Unusual Ambient Temperature Conditions: ______________________________________________________________ Other Concerns: __________________________________________________________________________________Complete individual conveyor specifications on page 6.EXPRESS INQUIRY FORM: GENERAL INFORMATIONPage may need to be copied to communicate multiple conveyorsFAX COMPLETED FORMS TO 800.369.2440 or 262.367.5827BELT SPEED CALCULATORHow to calculate minimum conveyor belt speed:(Part rate in parts per minute) x (part size in inches)12Example (30 parts per minute) x (6" dia. part) = 180 = 15 ft/min. Minimum Belt Speed12 12How to calculate conveyor belt speed incorporating a product spacing:(Part rate in parts per minute) x (desired part spacing in inches + part size in inches)12Example (30 parts per minute) x (6" dia part + 12" spacing between parts) = (30) x (18) = 540 = 45 ft/min. Belt Speed12 12 12Please highlight the conveyor, dimensions, belt flow and motor positions required.Belt Edge to Belt Edge Options:• 2"• 3"• 4.75" to 24"Note: Conveyors over 7' (2134mm) require additional tie-together brackets.。

connection. You can also use the Internet WAN port on the router to connect toa broadband cable or DSL modem.4.Close the SIM card compartment door.Attach the Antennas1.2.3.March 20144G LTE not available in all areas. See your service provider for complete coverage details. LTE is a trademark of ETSI. NETGEAR, the NETGEAR logo, and NETGEAR genie are trademarks and/orregistered trademarks of NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Other marks are the property of their respective owners. © 2014 NETGEAR, Inc. All rights reserved.NETGEAR, Inc.350 East Plumeria Drive San Jose, CA 95134 USAInstall the Router 1.Connect the power adapter to the router and plug it into an electrical outlet.2.If no LEDs light, press the Power On/Off button on the rear panel to poweron the router.3.Connect your router to a computer.To connect from your wireless device using WiFi, use the WiFi network name and password on the router label.For a wired connection, use an Ethernet cable to connect your computer to an unused yellow Ethernet LAN port on your router.To connect wirelessly, press the WPS buttonon the front of the router. Within two minutes, press the WPS button on your wireless device, or follow the WPS instructions that came with the device. For more information, refer to the user manual at . .Note: If you purchased the router online, you might need to provide ICCID and MEID(DEC) values to activate the router. These values display on the product packaging.connectorUse a Web Browser to Access the RouterWhen you connect to the network, you can use a web browser such as Chrome, Firefox, or Internet Explorer to access the router to view or change its unch a web browser from a computer or wireless device that isconnected to the network.2.Type or in theaddress field of the browser.A login screen displays. 3.Enter your user name and password.The default user name is admin and the default password is password .The BASIC Home screen displays.For more information, refer to the 4G LTE Router (LG2200D) User Manualon .4.To verify the mobile Internet signal quality, check the Signal Quality LED.To improve signal quality, adjust the antennas or move the router.When the router connects to the Internet, the Internet LED lightswhite.Once you have set up your router, you can use NETGEAR genie for tasks such as creating parental controls, changing your security settings, and monitoring your Internet usage.Note: If the router cannot detect the SIM card, the message No SIM Card Detected displays and the NETGEAR genie Mobile Internet pane shows Not Connected . If you see this message, unplug the router and reseat the SIM card.LEDsThe front panel of the router includes the following LEDs and buttons:Signal Quality of the mobile broadband servicePowerInternetEthernet LAN ports 1–4USB portsWAN Internet portWiFi On/Off buttonWPS buttonTroubleshootingIf the login screen does not display, try the following:•Close and reopen the browser.•Make sure that your computer is connected to one of the four yellow Ethernet LAN ports on the router, or that you are connected to your WiFi network.•Make sure that the router has full power, and that its Power LED is lit.•If your computer is set to a static or fixed IP address, change it to obtain an IPaddress automatically from the router.。

GM2200型面筋仪 操作手册一 2200型面筋仪装箱清单1.1 仪器清单2200 仪器零件号编号描述1×具有可设定时间定时器的2200型面筋仪2× 21.18.10 A 塑料杯（600ml）2× 21.10.26 B 无环洗涤室——88微米（用于面粉）30× 21.10.31 C 细的聚酯筛网——88微米2× 21.10.27 D 有环洗涤室——840微米（用于全麦粉）4× 21.10.41 E 粗的聚酯筛网——840微米2× 21.17.53 F 硅胶管——2米1× 21.18.01 G 10升带盖的容器1× 21.18.02 H 过滤器1× 21.18.11 I 连接面粉和全麦粉洗涤室的塑料环1× 21.18.12 J 可自动调节的移液器1× 21.18.13 K 250ml带嘴洗瓶1× 21.22.02 L 装配洗涤室用的白色塑料模块1× 21.18.14 M 一组0.6，0.7，0.8mm的筛规1× 10.01.18 N 220V的电源线4× 21.10.21 塑料洗涤杯2× 21.10.22 细筛筛架—无环形标记2× 21.10.32 粗筛筛架—有环形标记应提供的零备件2× 21.16.24 O 泵管（93mm）用的备用硅胶管2× 12.22.09 P 备用指示灯12V，T5. 51× 10.02.14 Q 塑料管2× 90.91.03 R 315mA备用保险丝（220V）2× 90.91.25 R 2.5A备用保险丝（220V）1×操作说明书注：部件编号如图1所示技术数据电源要求：110/220/240V 50/60Hz（参见仪器铭牌）外形尺寸：330×350×320mm（宽×深×高）净重： 24kg图1 有机玻璃体，混合钩，筛架和塑料洗涤室1.2 检查交货中定购的任选附件1．任选附件——2015离心机1× 2015离心机包括：1× 10.02.14 塑料管1× 12.22.09 备用指示灯12V，T5.52× 20.08.09 金属筛网（仅用于ICC137方法）2× 20.15.10 面筋指数筛盒1× 90.91.20 2A备用保险丝（220V）1× 20.15.06 镊子1× 20.15.08 刮刀技术要求：电源要求：110/220/240V 50/60Hz（参见仪器铭牌）外形尺寸：265×220×165mm（宽×深×高）净重： 8.7kg2．任选附件——2020 GLUTORK烘干机1× 2020 GLUTORK烘干机2× 90.91.03 315mA备用保险丝（220V）技术要求：电源要求：110/220/240V 50/60Hz（参见仪器铭牌）外形尺寸：265×220×165mm（宽×深×高）净重： 8.7kg检查交货中定购的任选附件。

TYPE : WINDOWP/NO : MFL67740303Please read this manual carefully before operating your set and retain it for future reference.ENGLISHSafety PrecautionsENGLISHOwner’s Manual 3Safety PrecautionsDo not allow water to runinto electric parts.•It will cause failure of machineor electric shock.conditioner may deteriorate,change color, or developVentilate the room well whenusing this appliancetogether with a stove, etc.•An oxygen shortage mayTurn off the power andbreaker firstly whencleansing the unit.•Since the fan rotates at highTurn off the main powerswitch when not using it fora long time.•Prevent accidental startup andIf strange sounds, or small orsmoke comes from product.Turn the breaker off ordisconnect the power supplycable.•There is risk of electricshock or fire.Do not open the suction inletgrill of the product duringoperation.•Otherwise, it may electricalshock and failure.If water enters the product, turnoff the power switch of the mainbody of appliance. Contactservice center after taking thepower-plug out from the socket.installation may cause fireor electric shockelectrical shock.ENGLISHSafety PrecautionsENGLISHOwner’s Manual 5Safety PrecautionsBe cautious not to touch thesharp edges wheninstalling.•It may cause injury.Avoid excessive cooling andperform ventilationsometimes.•Otherwise, it may do harm toyour health.Do not insert the hands orbars through the air inlet oroutlet during operation.•Otherwise, it may causepersonal injury.•It may cause injury.•It may cause product failure.•The appearance of the airconditioner may deteriorate,change color, or developsurface flaws.Do not step on theindoor/outdoor unit and donot put anything on it.•It may cause an injurythrough dropping of the unitor falling down.Always insert the filtersecurely.Clean it every two weeks.•Operation without filters willcause failure.Do not drink water drainedfrom air conditioner.•It contains containments andwill make you sick.6Room Air ConditionerBefore to OperationENGLISHOwner’s Manual 7IntroductionThis symbol alerts you to the risk of electric shock.This symbol alerts you to hazards that could cause harm tothe air conditioner.This symbol indicates special notes.This appliance should be installed in accordance with the National Electric Code.IntroductionVertical Air Deflector0DQXDO 7\SH0LFRP 7\SH8Room Air ConditionerInstallationENGLISHOwner’s Manual 910Room Air ConditionerStep 1Remove the air conditioner from its packaging and slide the air conditioner out of it ’s housing.Step 2Prepare the hole in the wall so that the bottom of the housing is well supported, the top has minimumcleara n ce and the air inlet louvers have clearance as shown. Holes from the outside through to the cavity should be sealed. The housing should slope down towards the rear by about 5mm to allow water formed during operation to drain.Step 3Install the housing into the wall and secure. Ensure the foam seals are not damaged. Flash, seal or fill gaps around the inside and outside to provide satisfactory appearance and protection against the weather, insects and rodents.Installation1.Slide the unit into the housing until it is firmly against the rear of the housing. Care is required to ensure the foam sealing strips on the housing remain in position.2.Connect the air conditioner to the power and coil excess cord length beneath the air conditioner base or control box.3.Engage the Chassis Lock into the bottom housing rail and secure to the base with the screwprovided.4.Remove the front panel from i t s carton and plastic bag and fit as per the Operating Instruction.5.Switch unit on. Check for operation of the unit and check for vibration in the installation.6.Fit the drain chute to the housing and run a drain line to a suitable location if required.Preferred method of installation into a timber framed wall, partition or window.UNIT MAY BE SUPPORTED BY A SOLID FRAME FROM BELOW OR BY A HANGER FROM A Alternative method of installation if externalsupport cannot be provided.45° BRICK CUT AWAY 45° BRICK CUT AWAY AIR OUTOPTION BInstallationscrew-driver tip (b).4.Then, rotate the inlet grille 180 degrees and insert the hooks into bottom holes of the front grille.5.Insert the filter and attach the front grille to the cabinet.B. If you want to pull out the filter downward;The grille is already designed that way.ENGLISHInstallationENGLISHOperating InstructionsOperating Instructions The controls will look like one of the following.Operating Instructionss COOLING DESCRIPTIONSFor Normal Cooling - Select High Cool or Med Cool with the Operation knob at the midpoint ofThermostat knob.For Maximum Cooling - Select High Cool with the Operation knob at the highest number available onyour Thermostat knob.For Quieter & Nighttime Cooling - Select Low Cool with the Operation knob at the midpoint ofThermostat knob.s AUTO SWING (available in some models), SI ) : Air swing is operated while OPERATION knob is set to the COOL position.OFF(, NO ) : Stops the operation of air swing.•When the air conditioner has been performed its cooling operation and is turned off or set to the fan position, wait at least 3 minutes before resetting to the cooling operation again.Operating InstructionsENGLISHOperating Instructions1.Push out the cover on the back of the remote control with your thumb2.Pay attention to polarity and insert two new AAA 1.5V batteries.3.Reattach the cover.In case the power comes on again after a power failure, Auto Restarting Operation is the function to operate procedures automatically to the previous operating conditions.Do not use rechargeable batteries. Make sure that both batteries are new. •if the air conditioner is not going to be used for an extended period of time Keep the remote control away from extremely hot or humid places.To maintain optimal operation of the remote control, the remote sensor should not be exposed to direct sunlight.•The remote control can be mounted on a wall using the mountable holder.Operating InstructionsENGLISHpart .Air DirectionOperating InstructionsThere are two drain holes at the product. (Fig. 1)One is at the rear and the other is at the bottom of the air conditioner unit.In case of cooling only model , there are two drain hole caps at the drain holes, but heat-pump model case, there is one drain hole cap at the rear. Additional drain hole cap is provided for heat pump model and drain pipe and washer are provided at the accessory.Select a drain method according to the following by each model.•Cooling only model1.Connecting drain from rear1)Remove the drain hole cap from rear at the product.2)After assembling washer and drain pipe, secure the drain pipe to the rear hole of the base pan. (Fig. 2) Press the drain pipe into the hole by pushing.3)Connect a drain hose of 9/16 inside diameter to the drain pipe as shown Fig. 32.Connecting drain from bottom1)Remove the drain hole cap from bottom at the product.2)After assembling washer and drain pipe, secure the drain pipe to the bottom hole of the base pan. (Fig. 4) Press the drain pipe into the hole by pushing.3)Connect a drain hose of 9/16 inside diameter to the drain pipe as shown Fig. 5Fig. 2Fig. 1Drain hole aFig. 4Fig. 5Fig. 3WASHER DRAIN HOLE CAPDRAIN PIPEWASHERDRAIN PIPEWASHERDRAIN PIPEOperating Instructions•Heat pump model1.Operating cooling mode1)As mentioned above, in case of heat pump model, there is no drain hole cap at thebottom,but for maximum cooling capacity,drain hole should be blocked by drain hole cap which is inside the accessory.2)For drain, please follow drain method same as cooling only model.2.Operating heating mode1)When it is operating heating mode, drain hole cap of bottom sideshould be removed.2)And please secure the drain pipe to the bottom hole of the basepan (Fig. 4) Press the drain pipe into the hole by pushing.3)Connect a drain hose of 9/16 inside diameter to thedrain pipe as shown Fig. 5ENGLISHMaintenance and ServiceENGLISHOwner’s Manual 21Maintenance and ServiceListed below are important instructions which will prevent malfunctions of the unit or serious problem with your air conditioner.1.Operate the unit from a stable power supply voltage variation must be within ±10 percent of therated voltage.2.DO NOT modify any part of the unit.3.DO NOT put sticks, rods, etc. into any part of the unit.4.DO NOT operate the unit without an air filter because dirt and lint will clog it and reduceperformance.5.DO NOT hold the power cord plug with wet hand.6.DO NOT obstruct the air inflow of the evaporator, it may cause some trouble.7.Turn the mode control to "O" or "OFF" and unplug your unit during the cool season or when youare checking the unit.8.Close the ventilation damper on windy days and/or during heavy rains.We strongly recommend that any servicing be performed by a qualified individual.22Room Air ConditionerMaintenance and ServiceA. WHEN AIR CONDITIONER DOESNOT OPERATE;1.Is the air conditioner plugged into the receptacle properly?2.Is the unit connected to a live receptacle supplying the proper voltage?3.Is the fuse blown or is the automatic circuit breaker off?4.Is there a local power failure?Try another electrical product.5.Has the air conditioner been accidentally switched off?6.Is the circuit overloaded by other devices on the same line?7.Is the thermostat knob set too low comparing to the temperature of indoor?8.If an extension cord is used, is the wire diameter large enough to carry the current?B. WHEN AIR CONDITIONER DOESNOT COOL AS IT SHOULD;1.Is the operation switch set properly?2.Is the thermostat control set properly to provide the desired cooling?3.Are there too many people than the usual number in the room?4.Is the air circulation restricted by drapes, furniture, etc., or by an improper vane setting?5.Are the doors or windows open, or is there an unusual heat source in the room?6.Is the ventilation damper closed for maximum cooling?7.Is the air filter clean so that it will not obstruct the air flow?8.Have all the steps outlined in the Installation Instructions been followed?9.Is the evaporator frosted? Frosting of the evaporator may occur during the spring and autumn months if there is a considerable temperature drop or during cool weather. If so, turn the operation switch to “MED FAN”. The fast air circulation will quickly defrost the coil so that normal cooling operating may be resumed.When you find something wrong with your room air conditioner, please check carefully referringto the following items. If you can’t find out the causes of trouble, get into contact with your dealer.Owner’s Manual 23Maintenance and Service Details of LG serial No.123456789101112*→*→*→H. G. IBRAHIM SHAKER COMPANY, LTD. SERVICE CENTER JEDDAH RIYADH AL-KHOBARP. O. BOX 200, JEDDAH 21411 KINGDOM OF SAUDI ARABIA P. O. BOX 15, RIYADH 11411 KINGDOM OF SAUDI ARABIA P. O. BOX 78, AL-KHOBAR 31952 KINGDOM OF SAUDI ARABIA CUSTOMER SERVICE CALL CENTER Toll Free No. 8002445454Service Centre No. 92000605424 Room Air ConditionerMaintenance and ServiceENGLISH Owner’s Manual 2526Room Air Conditioner。

ENGLISH •Grounding(Except for devices which are not grounded.)Ensure that you connect the earth ground wireto prevent possible electric shock (i.e., a TVwith a three-prong grounded AC plug mustbe connected to a three-prong grounded ACoutlet).If grounding methods are not possible, havea qualified electrician install a separate circuitbreaker. Do not try to ground the unit byconnecting it to telephone wires, lightning rods,or gas pipes.CircuitBreakerPowerSupply•As long as this unit is connected to the AC walloutlet, it is not disconnected from the AC powersource even if the unit is turned off.•Do not attempt to modify this product in anyway without written authorization from LGElectronics. Unauthorized modification couldvoid the user’s authority to operate this product.•Outdoor Antenna Grounding(Can differ by country):If an outdoor antenna is installed, follow theprecautions below. An outdoor antenna systemshould not be located in the vicinity of overheadpower lines or other electric light or powercircuits, or where it can come in contact withsuch power lines or circuits as death or seriousinjury can occur. Be sure the antenna system isgrounded to provide some protection againstvoltage surges and built-up static charges.Section 810 of the National Electrical Code (NEC)in the U.S.A. provides information with respectto proper grounding of the mast and supportingstructure, grounding of the lead-in wire toan antenna discharge unit, size of groundingconductors, location of antenna dischargeunit, connection to grounding electrodes, andrequirements for the grounding electrode.Antenna grounding according to the NationalElectrical Code, ANSI/NFPA 70Ground ClampGrounding Conductor(NEC Section 810-21)Antenna Lead in WireElectric ServiceEquipmentAntenna Discharge Unit(NEC Section 810-20)Ground Clamp Power Service GroundingElectrode System(NEC Art 250, Part H)NEC: National Electrical Code•CleaningWhen cleaning, unplug the power cord and wipegently with a soft cloth to prevent scratching. Donot spray water or other liquids directly on theTV as electric shock may occur. Do not clean withchemicals such as alcohol, thinners, or benzene.•MovingMake sure the product is turned off, unplugged,and all cables have been removed. It may take 2or more people to carry larger TVs. Do not pressor put stress on the front panel of the TV.•VentilationInstall your TV where there is proper ventilation.Do not install in a confined space such as abookcase. Do not cover the product with cloth orother materials while plugged in. Do not installin excessively dusty places.•If you smell smoke or other odors coming fromthe TV, unplug the power cord and contact anauthorized service center.•Keep the product away from direct sunlight.•Never touch this apparatus or antenna during alightning storm.•When mounting a TV on the wall, make sure notto install the TV by hanging the power and signalcables on the back of the TV.•Do not allow an impact shock or any objects tofall into the product, and do not drop anythingonto the screen.•DISCONNECTING THE DEVICE FROM THEMAIN POWERThe power plug is the disconnecting device.In case of an emergency, the power plug mustremain readily accessible.•BatteriesStore the accessories (battery, etc.) in a safelocation out of the reach of children.•This apparatus uses batteries. In your communitythere might be regulations that require youto dispose of these batteries properly due toenvironmental considerations. Please contactyour local authorities for disposal or recyclinginformation.•Do not dispose of batteries in a fire.•Do not short circuit, disassemble, or allow thebatteries to overheat.4If a fixed image displays on the TV screen for a long period of time, it will be imprinted and become a permanent disfigurement on the screen. This is image burn or burn-in and notENGLISH FCC Radio Frequency InterferenceRequirements (for UNII devices)High power radars are allocated as primary usersof the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands.These radar stations can cause interference withand/or damage this device. This device cannot beco-located with any other transmitter.FCC RF Radiation Exposure Statement[For having wireless function (WLAN, Bluetooth,...)]This equipment complies with FCC radiationexposure limits set forth for an uncontrolledenvironment. This transmitter must not becolocated or operating in conjunction with anyother antenna or transmitter. This equipmentshould be installed and operated with minimumdistance 20 cm (7.8 inches) between the radiatorand your body. Users must follow the specificoperating instructions for satisfying RF exposurecompliance.Industry Canada Statement(For Canada)[For having wireless function (WLAN, Bluetooth,...)]This device complies with RSS-210 of the IndustryCanada Rules. Operation is subject to the followingtwo conditions:1. this device may not cause interference and2. t his device must accept any interference,including interference that may cause undesiredoperation of the device.IC Radiation Exposure Statement(For Canada)[For having wireless function (WLAN, Bluetooth,...)]This equipment complies with IC radiationexposure limits set forth for an uncontrolledenvironment. This equipment should be installedand operated with minimum distance 20 cm(7.8 inches) between the antenna & your body.NOTE: THE MANUFACTURER IS NOT RESPONSIBLEFOR ANY RADIO OR TV INTERFERENCE CAUSEDBY UNAUTHORIZED MODIFICATIONS TO THISEQUIPMENT. SUCH MODIFICATIONS COULDVOID THE USER’S AUTHORITY TO OPERATE THEEQUIPMENT.WARNING(For Canada)[For product having the wireless function using5 GHz frequency bands]•The device for operation in the band 5150–5250MHz is only for indoor use to reduce thepotential for harmful interference to co-channelmobile satellite systems;•The maximum antenna gain permitted fordevices in the bands 5250–5350 MHz and5470–5725 MHz shall comply with the EIRP limit;and•The maximum antenna gain permitted fordevices in the band 5725–5825 MHz shallcomply with the e.i.r.p. limits specified for point-to-point and non point-to-point operation asappropriate.•High-power radars are allocated as primary users(i.e. priority users) of the bands 5250–5350 MHzand 5650–5850 MHz and that these radars couldcause interference and/or damage to LE-LANdevices.Note to Cable/TV Installer(For USA and Canada)This reminder is provided to call the CATV systeminstaller’s attention to Article 820-40 of theNational Electric Code (U.S.A.). The code providesguidelines for proper grounding and, in particular,specifies that the cable ground shall be connectedto the grounding system of the building, as closeto the point of the cable entry as practical.67ENGLISHViewing 3D Imaging (For 3D models)WARNINGViewing Environment•Viewing Time - W hen watching 3D content, take 5 to 15 minute breaks every hour. Viewing 3D content for a long period of time may cause headache, dizziness, fatigue, or eye strain.Those that have a photosensitive seizure or chronic illness•Some users may experience a seizure or other abnormal symptoms when they are exposed to a flashing light or particular pattern from 3D content.•Do not watch 3D videos if you feel nauseous, are pregnant and/ or have a chronic illness such as epilepsy, cardiac disorder, or blood pressure disease, etc.•3D Content is not recommended for those who suffer from stereo blindness or stereo anomaly. Double images or discomfort in viewing may be experienced.•If you have strabismus (cross-eyed), amblyopia (weak eyesight), or astigmatism, you may have trouble sensing depth and easily feel fatigue due to double images. It is advised to take more frequent breaks than the average adult.•If your eyesight varies between your right and left eye, correct your eyesight prior to watching 3D content.Symptoms which requirediscontinuation or refraining from watching 3D content•Do not watch 3D content when you feel fatigue from lack of sleep, overwork, or intoxication. •When these symptoms are experienced, stop using/watching 3D content and get enough rest until the symptom subsides. - C onsult your doctor when the symptoms persist. Symptoms may include headache, eyeball pain, dizziness, nausea, palpitation, blurriness, discomfort, double image, eyestrain, or fatigue.CAUTIONViewing Environment•Viewing Distance - M aintain a distance of at least twice the screen’s diagonal length when watching 3D content. If you feel discomfort in viewing 3D content, move further away from the TV.Viewing Age•Infants / Children-Usage/ Viewing 3D content for children under the age of 5 are prohibited.-Children under the age of 10 may overreact and become overly excited because their vision is in development, for example, trying to touch the screen or trying to jump into it. Special monitoring and extra attention is required for children watching 3D content.-Children have greater binocular disparity of 3D presentations than adults because the distance between the eyes is shorter than one of adults. Therefore they will perceive more stereoscopic depth compared to adults for the same 3D image. •Teenagers-Teenagers may be stimulated to light coming from 3D videos. Advise them not to watch 3D videos for a long time when they are tired. •Elderly-The elderly may perceive less of a 3D effect than the youth. Do not sit closer to the TV than the recommended distance.Cautions when using the 3D glasses•Only use LG 3D glasses. Otherwise, you may not be able to view 3D videos properly.•Do not use 3D glasses instead of your normal glasses, sunglasses, or protective goggles.•Using modified 3D glasses may cause eye strain or image distortion.•Do not keep your 3D glasses in extremely high or low temperatures. It will cause deformation. •The 3D glasses are fragile and are easilyscratched. Use a soft, clean piece of cloth when wiping the lenses. Do not scratch the lenses of the 3D glasses with sharp objects or clean/wipe them with chemicals.ENGLISH PreparingNOTE•Image shown may differ from your TV.•Your TV’s OSD (On Screen Display) may differslightly from that shown in this manual.•The available menus and options may differ fromthe input source or product model that you areusing.•New features may be added to this TV in thefuture.•The items supplied with your product may varydepending upon the model.•Product specifications or contents of this manualmay be changed without prior notice due toupgrade of product functions.•For an optimal connection, HDMI cables andUSB devices should have bezels less than 10 mm(0.39 inches) thick and 18 mm (0.7 inches) width.•Use an extension cable that supports USB 2.0 ifthe USB cable or USB flash drive does not fit intoyour TV’s USB port.•Use a certified cable with the HDMI logoattached. If you do not use a certified HDMIcable, the screen may not display or aconnection error may occur.•Recommended HDMI cable types (3 m or less)-High-Speed HDMI®/TM cable-High-Speed HDMI ®/TM cable with EthernetBA AB*A 10 mm (0.39 inches)*B 18 mm (0.7 inches)CAUTION•Do not use any unapproved items to ensure thesafety and product’s lifespan.•Any damages or injuries by using unapproveditems are not covered by the warranty.•Some models appear to have a thin film on thescreen. It is actually part of the screen; do notremove it.•Do not remove the panel with your fingers orany tools. Doing so may damage the product.(For 55/65UF9500)•When attaching the stand to the TV set, placethe screen facing down on a cushioned table orflat surface to protect the screen from scratches.•Make sure that the screws are fastened tightly.(If they are not fastened securely enough, the TVmay tilt forward after being installed.)•Do not fasten the screws with excessive force;otherwise, they may be worn out and becomeloose.Optional ExtrasOptional extras can be changed or modified forquality improvement without any notification.Contact your dealer for buying these items.These devices work only with certain models.The model name or design may be changed due tothe manufacturer’s circumstances or policies.(Depending upon model)AG-F***Cinema 3DGlassesAG-F***DPDual PlayGlassesAN-VC550Smart CameraAN-MR6**Magic RemoteLG AudioDevice89ENGLISHMaintenanceCleaning Your TVClean your TV regularly to keep it at peakperformance and to extend the product’s lifespan.CAUTION•Before cleaning, turn the power off anddisconnect the power cord and all other cables. •When the TV is left unattended or unused for a long time, disconnect the power cord from the wall outlet to prevent possible damage from lightning or power surges.Screen, Frame, Cabinet, and StandTo remove dust or light dirt, wipe the surface with a dry, clean, and soft cloth.To remove major dirt, wipe the surface with a soft cloth dampened in clean water or a diluted mild detergent. Then wipe immediately with a dry cloth.CAUTION•Do not push, rub, or hit the surface with your fingernail or a sharp object, as this may result in scratches on the screen and image distortions. •Do not use any chemicals, such as waxes, benzene, alcohol, thinners, insecticides, air fresheners, or lubricants, as these may damage the screen’s finish and cause discoloration. •Do not spray liquid onto the surface. If water enters the TV, it may result in fire, electric shock, or malfunction.Power CordRemove the accumulated dust or dirt on the power cord regularly.Lifting and Moving the TVWhen moving or lifting the TV, read the following to prevent the TV from being scratched ordamaged and for safe transportation regardless of its type and size.•It is recommended to move the TV in the box or packing material that the TV originally came in. •Before moving or lifting the TV, disconnect the power cord and all cables. •When holding the TV, the screen should face away from you to avoid damage.•Hold the top and bottom of the TV frame firmly. Make sure not to hold the transparent part, speaker, or speaker grille area.•Use at least two people to move a large TV.•When transporting the TV byhand, hold the TV as shown in the following illustration.•When transporting the TV, do not expose the TV to jolts or excessive vibration.•When transporting the TV, keep the TV upright; never turn the TV on its side or tilt towards the left or right.CAUTION•Avoid touching the screen at all times, as this may result in damage to the screen.•Do not place the product on the floor with its front facing down without padding. Failure to do so may result in damage to the screen. •Do not move the TV by holding the cable holders, as the cable holders may break, and injuries and damage to the TV may occur. (Depending upon model)Si se muestra una imagen fija en la pantalla del televisor durante un período largo, esta quedará impresa y se convertirá en una distorsión permanente de la pantalla. A este desperfecto secdac d+b12e118723645ENGLISHThickness DepthMODELS55UG8700(55UG8700-UA)65UG8700 (65UG8700-UA)Dimensions (W x H x T) (D)With stand1,241 x 773 x 236 (mm)1,461 x 897 x 255 (mm)48.8 x 30.4 x 9.2 (inches)57.5 x 35.3 x 10.0 (inches) Without stand1,241 x 723 x 60 (98) (mm)1,461 x 846 x 60 (99.9) (mm)48.8 x 28.4 x 2.3 (3.8) (inches)57.5 x 33.3 x 2.3 (3.9) (inches)Weight With stand24.2 kg (53.3 lbs)33.7 kg (74.2 lbs) Without stand 21.7 kg (47.8 lbs)30.4 kg (67.0 lbs)Power requirement AC 100-240 V ~ 50/60 Hz AC 120 V ~ 50/60 Hz Current value / Power consumption 1.7 A / 170 W 2.2 A / 220 WESPAÑOLGrosor ProfundidadMODELOS55UG8700(55UG8700-UA)65UG8700 (65UG8700-UA)Dimensiones(Ancho x altura x grosor) (profundidad)Con base1 241 x 773 x 236 (mm) 1 461 x 897 x 255 (mm)48,8 x 30,4 x 9,2 (Pulgadas)57,5 x 35,3 x 10,0 (Pulgadas) Sin base1 241 x 723 x 60 (98) (mm) 1 461 x 846 x 60 (99,9) (mm)48,8 x 28,4 x 2,3 (3,8) (Pulgadas)57,5 x 33,3 x 2,3 (3,9) (Pulgadas)Peso Con base24,2 kg (53,3 Libras)33,7 kg (74,2 Libras) Sin base21,7 kg (47,8 Libras)30,4 kg (67,0 Libras)Potencia requerida AC 100-240 V ~ 50/60 Hz AC 120 V ~ 50/60 Hz Corriente de consumo / Consumo de la potencia1,7 A / 170 W2,2 A / 220 W*MFL68684962*(For USA and Canada only)(Para Estados Unidos y Canadá)This product qualifies for ENERGY STAR inthe factory default (Home configuration)setting. Changing the factory defaultsettings or enabling other features may increase power consumption that could exceed the limits necessary to quality for ENERGY STAR. Refer to for more information on the ENERGY STAR program.(Pour les États-Unis et le Canada)Ce produit est conforme aux normesENERGY STAR lorsque le « réglaged’usine par défaut (Résidentiel) » estsélectionné. Modifier les réglages d’usine par défaut ou activer d’autres fonctionnalités augmente la consommation d’énergie qui pourrait alors dépasser les limites de la qualification Energy Star. Consultez le site pour en savoir plus au sujet du programme ENERGY STAR.FRANÇAISÉpaisseur ProfondeurMODÈLES55UG8700(55UG8700-UA)65UG8700 (65UG8700-UA)Dimensions (L x H x É) (P)Avec support1 241 x 773 x 236 (mm) 1 461 x 897 x 255 (mm)48,8 x 30,4 x 9,2 (po)57,5 x 35,3 x 10,0 (po) Sans support1 241 x 723 x 60 (98) (mm) 1 461 x 846 x 60 (99,9) (mm)48,8 x 28,4 x 2,3 (3,8) (po)57,5 x 33,3 x 2,3 (3,9) (po)Poids Avec support24,2 kg (53,3 lb)33,7 kg (74,2 lb) Sans support21,7 kg (47,8 lb)30,4 kg (67,0 lb)Alimentation AC 100-240 V ~ 50/60 Hz AC 120 V ~ 50/60 Hz Valeur courante/Consommation électrique1,7 A/170 W2,2 A/220 W。

1 前言LineGuard 电子型管线破裂检测系统，是一种安装在管线阀门处的自力式管线监控和管线破裂保护装置。

该装置能采集数据，能（就地和远距离）监控单个阀门执行机构。

LineGuard 2200产品由一套Fisher ROC300系列远距离操作控制器和FlashPAC流量管理硬件和固件组成。

一套两用户程序可提供LineGuard功能。

Fisher公司的Windows RocLink负责进行压力监控、数据记录和阀门控制；Daniel产业公司的SpectraCom负责Modbus信息处理。

可提供客户定义型显示器，对两种程序的运行进行配置和监控。

2功能说明LineGuard 2200装置可进行压力采样并根据压力采样进行压力和“压降速率（RoD）”计算。

LineGuard 2200能连续监控和检测某些压力条件和压降速率（Rod）条件。

这些条件分为“小”（Minor）事件条件和“大”（Major）事件条件，它们在本装置中可以进行配置。

当探测到这些事件时，LineGuard 2200能按常规的配置间隔保持“压力”和“RoD”记录。

如果“大”事件在可配置的“事件持续”时间里继续存在，LineGuard 2200装置就会驱动阀门关闭。

可以选择性地关闭阀门。

LineGuard 2200还能保存标明有日期和时间的“事件/报警”记录。

借助Daniel Modbus协议，通过LineGuard 2200可以实现所有外部通信。

3操作原理3.1 用户计算程序用户计算程序负责监控管线压力，计算压降速率（RoD），保持小事件和大事件记录和阀门控制。

3.2 管线压力监控对管线静压每5秒钟采样一次，并作为“当前压力”（Live Pressure）加以保存。

对“当前压力”按一个配置周期（称之为“平均采样周期”）进行平均，并作为“平均压力”（Average Pressure）加以保存。

“平均采样周期”（Average Sample Period）可在5秒到60秒之间按5秒间隔进行配置。

1一、产品简介与性能参数1、产品简介IGK2200是对单门(或通道)出入进行管制的控制主机。

结合门禁管理软件，实现对门(或通道)进行权限设定、管制、数据采集及安全监控。

从而实现门禁管理自动化，安全防范科学化。

2、性能参数卡 片 类 型： IGK2200A/EM 使用EM 及其兼容卡IGK2200/TE 使用TEMIC 及其兼容卡 IGK2200A/M1 使用mifare 及其兼容卡用户卡容量： 10000张 记 录 容 量： 8000条读卡器端口： 标准WG26/34/36/37/42自适应或RS485接口读卡器 输 入 ： 四路开关量输入（1路开门按钮、1路门磁、1路报警、1路消防联动）输 出 ： 2路1A 继电器干接点输出（1路电锁控制、1路报警输出） 通 讯 ： RS485/4800～115200bps （默认19200bps ） 工 作 电 压： DC6～36V （额定DC12V ） 功 耗 ： <3W(不包括电锁) 工 作 温 度： -10～60℃体 积 ： 126mm×83mm×18mm 重 量 ： 125g界 面 ：LCD 中/英文双语菜单/信息显示 键 盘 ：12键门 铃 接 口：干接点开关输出二、安装说明1、整体安装2、接口图与说明图2.02图2.012（1）电源接口（2）通讯接口（3）控制信号输入口（4）继电器输出端口（5）门铃输出口（6）外接读卡器接口3（1）门禁专用电源接线图门禁单元接线图一（2）通用电源（通电开锁型）接线图门禁单元接线图二图2.03 图2.044（3）通用电源（断电开锁型）接线图门禁单元接线图三5、系统安装说明(1) 单元连接及系统连接示意图6、安装注意事项● 所有通讯线以及控制线等要单独走管，不能与强电靠近或平行走线。

●若周围有无线发射设备，要减少无线电磁干扰，可以使用屏蔽线或金属管。

● 此一体机不可安装于日晒雨淋的地方，避免在潮湿的环境下使用。

LG2200参数设定值1、低压设定1）、低压关阀值---2.4MPa（348PSI）2）、低压报警值---3.0 MPa（435PSI）2、高压设定1）、高压报警值---10.5 MPa（1523PSI）2）、高压关阀值---11MPa（1595PSI）（不投用，进行闭锁）3、压降速率设定值1）压降速率关阀值0.15 MPa/ min（21.75PSIG）2）压降速率报警值0.10MPa/min（14. 5PSIG）4、时间设定值1）阀门开关动作时间---30s2）压降速率、高低压报警采样周期---30s3）阀门动作延迟时间---180s注：参数设定单位选取PSI，1MPa=145PSILINEGUARD2200参数设置方法1、连接电池及电源线；2、使用DB9M/ DB9F电缆连接笔记本电脑和控制箱。

控制箱内的连接口为“INTERFACE”；3、连接电路板的电源，其接口为“INTERFACE”接口旁边的接口；4、启动笔记本电脑，启动ROCLINK FOR WINDOWS软件，输入用户名为“LOI”，密码为“1000”；5、在启动窗口内选择“ROC”下拉菜单，选择“DIRECT CONNECT”选项；6、进入CONFIGURE菜单中设定用户程序，然后选择USER DATA选项。

选择LOG CONFIGURATION选项。

有两个页面，LINEGUARD STATUS用于显示报警设定实时报警情况，激活的报警可以在这个页面中清除。

第二个页面叫做“LOG/ALARM SETUP”，在这个页面中主要事件周期、次要事件周期和平均采样周期可以被设定。

激活主要和次要事件报警，设定设定值为合适的值。

分别点击应用、刷新、确认按钮，保存设置。

7、选择V ALVE CONTROL选项。

有两个页面，第一个叫做LINEGUARD valve control,在这个页面中可以设置每个电磁阀的带电时间，点击APPLY。

第二个页面为EVENT CONTROL，选择需要的自动关断的功能的开启，将事件周期设定为合适值，选择OK并确认已保存设定。
