逐步减压缩聚法制备高分子量聚乳酸的研究
马海艳;滕翠青;余木火
【期刊名称】《材料科学与工程学报》
【年(卷),期】2007(025)004
【摘要】以L-乳酸单体为原料,用逐步减压缩聚法合成了相对高分子量的聚乳酸.探讨了反应条件如:温度、反应时间、催化剂用量、酯化时间、逐步减压时间等对聚乳酸分子量的影响,并采用FTIR、1H NMR测试手段对聚合物进行了结构表征.结果表明,催化剂用量为0.5wt%,反应温度180℃,先酯化7小时,再逐步减压7小时,然后在高真空度70Pa下反应45小时,可得到重均分子量约为12万的聚乳酸.【总页数】4页(P554-557)
【作者】马海艳;滕翠青;余木火
【作者单位】东华大学材料科学与工程学院,纤维材料改性国家重点实验室,上海,200051;东华大学材料科学与工程学院,纤维材料改性国家重点实验室,上
海,200051;东华大学材料科学与工程学院,纤维材料改性国家重点实验室,上
海,200051
【正文语种】中文
【中图分类】TQ316.4
【相关文献】
1.直接熔融缩聚法制备聚乳酸／高岭土复合材料及其性能研究 [J], 樊国栋;管园园;刘钰维;王丽娜
2.熔融缩聚法制备聚乳酸的研究 [J], 樊国栋;张昭;蔡强
3.缩聚法制备热固性聚乳酸及其力学性能和热稳定性研究 [J], 谢鹏飞;陈勰;丁峰;张乃文;李建波;任杰
4.通过熔融／固相缩聚法由乳酸酯直接制备聚乳酸的方法 [J],
5.丁二酸酐与SnCl_2·2H_2O共催化含水乳酸缩聚制备高分子量聚乳酸 [J], 白雁斌;王寿峰;雷自强
因版权原因，仅展示原文概要，查看原文内容请购买。
