【vivado】clockingwizard时钟配置
1、结构：MMCM和PLL
mixed-mode clock manager (MMCM)，phase-locked loop (PLL)
这两种primitive架构不同，MMCM实现更复杂⼀些，具有更多的features。

MMCM可以实现Spread Spectrum和差分输出，最多可以出7个clock，PLL最多6个。

倍频分频的⽅式也不同。

2、动态配置：Dynamic Reconfig
允许user通过控制接⼝改变clock
3、配置接⼝：AXI4Lite和DRP
控制接⼝可以是AXI总线的，也可以是⼚家的DRP接⼝。

根据逻辑设计需要选择。

dynamic reconfiguration port (DRP)
4、其他Options
a、Phase Duty Cycle Config
相位和占⽐也可以配置，代价是资源占⽤成倍增加。

b、Write DRP registers
相当于⽤AXI接⼝直接控制DRP的寄存器，主要优点是在接⼝这块可以不使⽤DSP资源。

但是也会缺少⼀些可选配置，同时偏移地址不同。

⽐如AXI-0x200位置对主频的重新配置，在DRP-0x300中就没有。

对clkout的三项配置都⼀样。

reg配置完成了，往使能寄存器中写0x03，让配置⽣效。

我的需求：通过ps动态配置，频率档位越细越好，占⽐可变，但同时也希望资源占⽤尽量少点。

所以选择：DynamicReconfig、AXI4Lite、Phase Duty Cycle Config。
