H512人体秤说明书V10篇一：H512 人体秤说明书 V10 H512 人体秤说明书 V1.0 一、简述 1. 重量显示精度：1500分度数（可设定）； 2. 最大称量：150Kg（可设定）; 3. 14bit ADC 分辨率； 4. 1/3 bias、1/4 duty LCD驱动电路； 5. 秤重单位：Kg，lb，ST （按键选单位无ST）；单位转换可选按键或拨动开关； 6. 2 - 4点标定，标定位置任选； 7. 传感器分时供电功能（省电30%左右）； 8. 省电模式：10S内(可设定)不操作系统进入TURN OFF; 9. 功耗：（条件：采用1K欧姆LoadCell, HT24LC02） 10. LoadCell的供电方式可选：用IO口供电或VS供电。
（Vs供电在电压降到较低时，还能保持较高的精度，但功耗比IO口供电大）。
11. 电力不足警告，过载声音报警；二、 I/O 口定义 1. 功能键：P10、P13、P14； 2. EEPROM接口：WP（P15）、SCL（P17）、SDA（P16）； 3. 校正使能（P14）； 4. 开关选单位（P11、P12）； 5. Buzzer推动：P27； 6. Loadcell电源E+：P26。
7． WDTEN （P3）：看门狗定时功能，若选开机归零则不使用（该脚接地）；若选定时归零（开机不归零）则该脚接电源。
三、基本功能 1．按键操作 P10：ON键； P13：（单位状态存于RAM而未存EEPROM）；（EEPROM选）称重模式下为单位转换键（UNIT）校准模式下无定义。
P14：校准模式下为校准确认键，称量状态下为关机键；关机状态下为校准使能端。
2. 开关选单位(P11,P12)（可选）：JMP2、JMP1：11—Kg，10—LB；（JMP断开为1，短路接地为0） 01—ST，00—ST。
3．开机自检项目： (1) 在校准使能下（JMP3短路）开机，LCD全亮2S，然后进入校准模式。
