_______________________________________________________________ Maxim Integrated Products 1For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642, or visit Maxim’s website at .Touch-Screen Controller with Haptic DriverMAX11811General DescriptionThe MAX11811 low-power touch-screen controller oper-ates from a 1.7V to 3.6V single supply targeting power-sensitive applications such as handheld equipment. Thedevice contains a 12-bit SAR ADC and a multiplexer tointerface with a resistive touch-screen panel. A digitalserial interface provides communications.The MAX11811 includes digital preprocessing of thetouch-screen measurements, reducing bus loading and application processor (AP) resource requirements. The included smart interrupt function generator greatly reduces the frequency of interrupt servicing to the devic-es. The MAX11811 enters low-power mode automatically between conversions to save power, making the device ideal for portable applications.The MAX11811 offers two modes of operation: directand autonomous. Direct mode allows the application processor to control all touch-screen controller activ-ity. Autonomous mode allows the MAX11811 to control touch-screen activity, thereby freeing the application processor to perform other functions. In autonomous mode, the device periodically scans the touch screen for a touch event without requiring host processor intervention. This can be used to reduce system power consumption. An on-chip FIFO is used during autono-mous mode to store results and increase effective data throughput and lower system power.The MAX11811 supports data-tagging, which records the type of measurement performed; X, Y, Z1, or Z2, and the type of touch event; initial touch, continuing touch, or touch release.The MAX11811 features a haptic driver to either drive a vibration motor directly or to interface with an externalpiezo actuator driver. The device generates PWM sig-nals that can drive the MAX11835 haptic piezo control-ler. The device includes a general-purpose current DACoutput and a general-purpose input that can be used to drive IR and visible LEDs, as well as IR photo-detectors in applications such as proximity detectors.The MAX11811 supports the I 2C serial bus. The MAX11811ETP+ is available in a 20-pin TQFN package and is specified over the extended industrial tempera-ture range of -40N C to +85N C. The MAX11811GTP/V+ isspecified over the -40N C to +105N C automotive tempera-ture range. Features S 4-Wire Touch-Screen Interface S X/Y Coordinate Measurement and Touch Pressure Measurement S Ratiometric Measurement S 12-Bit SAR ADC S Single 1.7V to 3.6V Supply S Two Operating Modes—Direct and Autonomous S Data Tagging Provides Measurement and Touch Event InformationSData Filtering Provides Noise Reduction S Aperture Mode Provides Spatial Filtering S Digital Processing Reduces Bus Activity and Interrupt Generation S Programmable Touch-Detect Pullup Resistors S Auto Power-Down Control for Low-Power OperationS General-Purpose Current DAC OutputS General-Purpose InputS Integrated Proximity Sensing SystemS Integrated Motor Haptic Driver*S PWM Output for MAX11835 Haptic Piezo Controller † (HPC)S 400kHz I 2C InterfaceS 20-Pin, 4mm x 4mm TQFNS Low-Power Operation250µW at V DD = 1.7V, 34.4kspsS ESD ProtectionQ 8kV HBM (X+, X-, Y+, Y-)Applications Mobile Communication DevicesPDA, GPS Receivers, Personal Navigation Devices, Media PlayersDigital Still CameraDigital Video CameraDigital Photo FramePOS Terminals and Financial Terminals Handheld GamesAutomotive Center ConsolesOrdering Information and Typical Operating Circuits nnm,nappear at end of data sheet.*Use of Haptic technologies in an end product may require third-party licensing.†Quickview available.TacTouch is a trademark of Maxim Integrated Products, Inc.A B R I D GE D。

宝马1系118i 保养费用周期表,北京博睿通达整理宝马1系保养费用明细表供大家参考
首保：10000公里或12个月 二保：20000公里或24个月 保养间隔：10000公里或12个月 机油 一百一升 金装美孚1号全合成机油 嘉实多极护全合成机油
宝马1系保养费用周期表，供大家参考：可以参考保养手册和保养记录来选择，积碳清洗根据车况，环境选择。

下面附上几张车间图片.
宝马F20 1系 116i118iN13B16A 一万 公里 两万公里 三万公里 四万公里 五万公里 六万公里 七万公里 八万公里 价格 工加料 备注 机油机滤
556 空气滤清器
222 汽油滤清器
420 外置 空调滤清器
427 火花塞
744 刹车油
304 防冻液
538 自动变速箱油
(8HP)
5380 滤清器和油底壳 发电机皮带
皮带 涨紧器 惰轮 清洗节气门
90 免费清洗 清洗进气道
302 3M 清洗喷油嘴
(直喷专用）
415 3M 清洗燃烧室
404 署牌 （四缸） 洗三元催化器
317 3M。

商标深圳市道通科技股份有限公司（下称“道通公司”）已经在中国及海外若干国家进行了商标注册。

Autel®，MaxiSys TM，MaxiDAS®，MaxiScan®，MaxiTPMS®，MaxiVideo TM ，MaxiRecorder TM，和 MaxiCheck TM 均是道通公司的注册商标。

本手册中所提及的其他商标，都属于相应公司所有。

版权信息未征得道通公司的书面同意，任何公司或个人不得以任何形式（电子、机械、影印、录制或其它形式）对本说明书进行复制和备份。

免责声明和责任限制说明书中的所有信息、规格及示图均为出版截止时的最新信息。

道通公司保留对其进行更改而不另行通知的权利。

说明书中的内容已经过认真审核，但不保证其内容（包括但不限于产品规格、功能及示图）的完整性和准确性。

本公司不承担任何直接、间接、特殊、附带的损坏赔偿或任何间接经济损害（包括但不限于利润损失）。

注意：设备进行操作与维护前，请认真阅读本说明书，尤其是安全注意事项。

服务与支持销售服务热线：400-009-3838转1售后服务热线：400-009-3838转2*********************其它国家与地区的用户，请联系当地经销商寻求技术支持。

安全信息为了自身与他人的安全，同时避免对设备及车辆造成损坏，所有操作该设备的人员请务必阅读本手册中所提到的安全注意事项。

由于进行车辆维修时会使用各种程序、工具、部件及技术，同时工作人员的操作方式也各有不同，但因诊断应用程序和该设备所检测产品的种类繁多，本手册无法对每种情况进行预测并提供安全建议。

汽车维修技术人员有责任对所测试的系统进行充分的了解，并合理使用适当的维修方法和测试程序。

进行测试时，必须使用适当的操作方法，以避免对自身和工作区域内其他人员的人身安全造成威胁，同时避免对正在使用的设备或正在测试的车辆造成损坏。

使用设备前，请参考并遵守车辆或设备生产商提供的安全信息及适用的测试程序。

13款宝马118i原车屏幕升级导航,新款宝马118i改装手写导航,新款宝马1系安装倒车轨迹,宝马118i选配数字电视
高端车型为什么要做原车屏升级？
宝马，奔驰，奥迪，在马路上出现的频率也越来越多，可是，随着大家对车不断提高的要求，就算是世界的名牌汽车，其实就算是再好的品牌，细细数来，也有一些不尽人意之处。

出于成本的考量，对于很多进口级别的豪华车来说，原车屏幕所具有的功能非常有限，几乎沦为一个摆设，有的取消了GPS导航，有的则取消了DVD影音娱乐系统，有的则两者都不具备。

可是车型内饰上是共用的国外版的液晶显示屏，在理论上是可以通过无缝升级，在保留原车所有功能的前提下，实现触摸手写GPS导航和DVD等功能的。

整个过程不破坏原车线路、不影响4S店保修，真正的免剪线无损安装解决方案！
无损-原厂开发：
安装过程不破坏原车任何线路；在原车风格基础上，不改变原车音响并保留原汁原味播放效果的基础上，用原车液晶显示屏升级触摸手写导航系统，并实现后加线路与原厂接口的无损对插，不影响原车任何协议功能。

全面-功能齐全：
支持原车控制与及原车按键切换+全触摸操控，随心操控后加装的GPS导航、DVD影音系统、数字电视等功能；智能倒车辅助系统，一挂倒档即可实时显示倒车系统！采用SD卡存储地图软件，升级只需要到更换SD卡即可，方便简单。

Y amaxunwudan 5-06。

2022款宝马x1说明书
外观方面，2022款宝马X1外观基本保留了原本的设计，仅在一些细节处有所变化，整体的造型还是比较耐看的，而且辨识度也很高。

车身颜色上，2022款宝马X1共有6种颜色可选，分别是开士米银、矿石白、星光棕、量子蓝、神秘灰、馥郁红。

内饰方面，2022款宝马X1内饰布局简洁明了，每个功能区块的划分很清晰，黑棕双色的设计也更有时尚感，总体来说这个内饰还是不错的。

内饰的颜色方面，2022款宝马X1共有2种颜色可选，分别是黑色和黑色/棕色。

动力方面，2022款宝马X1搭载了2套动力系统，分别是1.5TL3发动机，最大功率140马力，最大扭矩220牛·米；
2.0TL4发动机，最大功率192马力，最大扭矩280牛·米。

传动系统根据配置不同，分别匹配了7挡湿式双离合与8挡手自一体变速箱。

配置方面，宝马X12022款sDrive20Li时尚型标配主驾驶位座椅记忆、车身稳定控制、倒车影像、第二排座椅前后调节、雨量感应式雨刷、蓝牙/车载电话、零胎压继续行驶、CarPlay等配置，毕竟是一款豪华品牌的产品，即便是入门车型配置也不少。

宝马
X12022款sDrive20Li尊享型相比2022款sDrive20Li时尚型增加了前驻车雷达、后座出风口、自动空调、温度分区控制以及车联网等配置。

宝马使用手册第一章安全驾驶指南1.1 安全带使用：在驾驶宝马汽车时，请务必系好安全带，不仅可以保护您自己的安全，也可以提供额外的安全保障。

1.2 驾驶员姿势：在调整座椅和方向盘时，请确保您能够保持舒适的姿势，并且能够清晰地看到所有控制面板和后视镜。

1.3 安全驾驶守则：请遵守交通法规，不要超速、酒后驾驶或使用手机。

保持车辆在良好的状态，包括定期检查车辆及更换磨损零部件。

第二章宝马汽车功能介绍2.1 汽车控制面板：宝马汽车的控制面板布局合理，易于操作。

您可以通过仪表盘上的显示屏或者控制旋钮来控制音响、空调、导航等功能。

2.2 智能驾驶辅助系统：宝马汽车配备了各种智能辅助系统，如自适应巡航控制、自动泊车系统、盲点监测等，可以提高驾驶安全性和舒适度。

2.3 电子车载系统：宝马汽车的电子车载系统包括蓝牙连接、手机投屏、车载导航等功能，可以满足您的多媒体娱乐需求。

第三章汽车维护与保养3.1 定期保养：宝马汽车需要按照制造商规定的保养周期进行定期保养，包括更换机油、机滤、空气滤等，并进行全面的检查。

3.2 车辆清洁与保养：定期对汽车进行清洁和保养，包括洗车、打蜡、内饰清洁等，可以延长汽车的使用寿命，减少零部件的磨损。

3.3 注意事项：在使用过程中，遇到异常噪音、漏油、故障灯亮等情况，应立即停车，并联系宝马授权经销商进行维修。

结语本手册旨在帮助您更好地使用和保养您的宝马汽车，希望能够为您的驾驶生活带来更多的便利和安全保障。

如果您在使用过程中有任何疑问或需要帮助，请随时联系宝马授权经销商或客户服务中心。

祝您驾驶愉快！。

BMW 118i 运动型技术参数功率 / 马力 / 转数： 125千瓦 / 170匹马力 / 4800 转每分扭矩： 250牛米 / 1500-4500转每分（涡轮增压）气缸数 / 排量： 4 / 1598毫升耗油量（总平均）： 5.6升 / 100公里最高车速： 222公里 / 小时0 – 100 公里 / 小时：7.5 秒标准配置铝合金轮圈，星式轮辐376型，7J x16，205/55 R16，防爆轮胎，8速手自一体变速箱，动态稳定控制系统 DSC，运动型多功能真皮方向盘，可变运动型转向系统，双前座安全气囊，前后排头部安全气囊，驾驶者和前排侧面安全气囊，驾驶体验控制系统，报警系统，与车身同色外部组件， Follow-me-Home（回家照明）功能，电动玻璃天窗，警告三角标及急救包，吸烟配套，前排座椅电动调节，驾驶者座椅带记忆功能，前排运动型座椅，前排中央扶手，大灯清洗系统，前后部驻车距离报警器，雨量探测器及大灯自动控制，远近光氙气前灯，高级自动空调，BMW专业级收音机，雾灯，电动随速助力转向，iDrive，6.5英寸显示屏，自动泊车辅助系统，运动设计套件：黑色高光内饰，带亚光珊瑚红装饰条，Track布料，金属漆。

Technical data Power : 125 kw / 170 hp / 4800 rpmNominal torque : 250 Nm / 1500-4500 rpm(TwinPower Turbo)Cylinders / Capacity : 4 / 1598 mlFuel Consumption : 5.6ltr / 100 kmTop Speed : 222 km/hAcceleration : 7.5 s ( 0-100 km/h)Standard equipment 16'' light alloy wheel star- style 376, Runflat Tires, 7J x16, 205/55 R16,Automatic transmission extended feature, Dynamic Stability Control, Variable sportsteering, Airbags for driver and front passenger, Head airbag front and rear, Side airbagsfor driver and front passenger, Sports leather steering wheel, Multi-function SteeringWheel, Driving experience control, Alarm System, Exterior Parts in Body Colour, Follow-me-home function, Electric Glass Sunroof, Warning Triangle and First-aid Kit, SmokerPackage, Electric Front Seats with Memory for Driver, Front sport seat, Front armrest,Headlight washer system, PDC , Auto headlights and Rain sensor, Fog lights, Xenonheadlights, Automatic air-condition, BMW professional radio, Electrical power steeringincluding servotronic, iDrive, 6.5’ screen , Parking assist, Sport line：Black high-gloss,only with highlight trim finishers Coral Red matt,Cloth "Track", Metallic paint.零售价Price306,000.00 RMB以上配置仅供参考，确切信息请咨询当地授权经销商（Above information just for you reference, exact information please contact BMW dealer）。

Quick start user manualSection 1The warnings in this manual must be observed together with the "USER MANUAL - Section 2".Le avvertenze nel presente manuale devono essere osservate congiuntamente al “MANUALE D’USO – Sezione 2”.Die Warnungen in diesem Handbuch müssen in Verbindung mit der "BEDIENUNGSANLEITUNG - Abschnitt 2" beobachtet werden”.Les avertissements specifiés dans ce manuel doivent être respectés ainsi que les "CARACTERISTIQUES TECHNIQUES -Section 2"Las advertencias del presente manual se deben tener en cuenta conjuntamente con las del “MANUAL DEL USUARIO” - Sección 2”.A.E.B. Industriale Srl Via Brodolini, 8 Località Crespellano 40053 VALSAMOGGIA BOLOGNA (ITALIA)Thank you for choosing a dBTechnologies Product!VIO S118 is an active horn loaded subwoofer, designed for professional use, easy to fly, equipped with one 18” woofer (voice coil: 4”). The powerful DIGIPRO® G4 amplifier section, capable of handling up to 1600 W (RMS power), is controlled by a DSP, which can perform a detailed customization of the output sound of the subwoofer. In particular, thanks to the complete control interface, it is possible to accurately tune various types of configurations, like cardioid or end-fire. The RDnet connections allow in-depth remote control, thanks also to free available software (dBTechnologies Network, dBTechnologies Composer). WPD (wireless position detection) is a new feature which allows recognizing the placement of the subwoofer in line-array (in the real use). Professional accessories (like FSA-VIOL210 flown adapter, GSA-VIOL210 stack adapter, DRK-210 fly-bar, DO-VIOS118 dolly) ensure easy set-up to create different configurations, completing live installations with VIO-L210 line-arrays.Check the site for the complete user manual!1) UnpackingThe box contains:No. VIO S118No. 1 Mains cable with Neutrik® powerCON TRUE1connectorNo. 1 FuseThis quick start and warranty documentation2) Easy installationThe quick assembly in line-array is guaranteed by:UPPER SIDEfront retractable brackets (A), for anchoring to ahigher subwoofer or DRK-210 fly-bar (flowninstallation)rear retractable brackets(B), for anchoring to ahigher subwoofer, to DRK-210 fly-bar (flowninstallation) or to GSA-VIOL210 (stacked installation)quick-release pins (C) for securing the retractablebracketsLOWER SIDEfront anchorage system(D), for anchoring to alower subwoofer or to VIO-L210 module (flowninstallation)rear anchorage system (E), for anchoring to alower subwoofer or to FSA-VIOL210 (flowninstallation)TOP AND LATERAL SIDESpick points forDRK- 210 fly-bar (F)(stacked mounting)pole-mount adapter (G)(M20 threaded hole)handles (H) (2 for eachside)The use of main accessories for each type ofinstallation is illustrated in the pictures below. Pleaserefer to the related instructions and complete manualsfor further information.The product and accessories must be handled bytrained personnel only! The user is required tofollow regulations and mandatory laws onsafety of the country in which the product is used. Don’tuse handles and/or roping points to suspend VIO S118!3) First switch-onThe DIGIPRO G4 amplifier of VIO S118 is controlled by a powerful DSP. All the connections and controls are in the rear amplifier control panel:The subwoofer is supplied with a mounted fuse for operation within the 220-240V~ range. If you need to operate in the 100-120V~ voltage range:▪ Disconnect all connections, including the powersupply▪ Wait 5 minutes▪ Replace the fuse with the one provided in thepackage for the 100-120V~ range1 – Input (balanced) connector2 – Link/Xover Out (balanced) connector3 – Subwoofer attenuation rotary control4 – Delay rotary controls5 – Polarity switch6 – Cardioid preset switch7 – Link/Xover Out switch8 – Xover LPF9 – Status LEDs (Limiter, Signal, Mute/Protection, Ready)10 – RDNet Data In 11 – RDNet Data Out 12 – RDNet status LEDs 13 – System test switch14 – USB Data Service (USB-standard Type B) 15 – Full Range Mains input connector 16 – Mains Link connector 17 – Mains Fusea) Once you have properly set up the desiredconfiguration (see also the VIO S118 complete user manual and accessories instructions for further information), connect the audio input (1). Set the Subwoofer attenuation (3) to 0 dB.b) Connect the possible output direct link (2), and set the Link/Xover Out switch (7). If your choice is Xover, you can choose the LPF frequency with (8) Xover rotary. This filter does not affect the “Link” output, if selected with (7).c) Choose the Subwoofer Setup (Delay 4, Polarity 5) In cardioid configuration, please note that thecardioid preset switch (6), when active, bypass these controls.d) In case of remote control, connect the Data Input (10) to the hardware remote controller (RDNetControl 2 or RDNet Control 8) with cables equipped with etherCON connectors. Then connect the Data Output (11) to the Data Input (10) of a possiblesecond device, and so on. When the RDNet network is on and it has recognized the connected device, the LED “Link” (12) is on. The other LEDs (12) “Active” start blinking at the presence of data transmission, the “Remote Preset Active” advise that all the local controls set on the amplifier panel (level, DSPpresets, etc.) are by-passed and controlled remotely by RDNet. In remote control it is essential the use of free dBTechnologies software:∙ dBTechnologies Network,useful for an in-depth control of different devices in remote connection;∙ dBTechnologies Composer,useful for the complete sound system design for various professional needs, particularly developed for VIO series.e) Connect the power supply (15). Link the power to other subwoofer or modules (see Technical Data for further information) using mains link connector (16).For further information, download the complete user manual and the free software:/EN/Downloads.aspx or scan the QR code.Technical DataSpeaker Type: Active horn-loaded subwooferAcoustical dataFrequency Response [-6 dB]:36 Hz – Cut frequency(crossover - dependent)Frequency Response [-10 dB (HPF)]:33 HzMax SPL (1 m): 139 dBLF: 1 x 18”LF Voice Coil: 4”Crossover freq.: 60 to 110 Hz + full-rangeDirectivity: (omnidirectional) Cardioid with DSPAmplifierAmp Technology: Digipro® G4Power supply: Full range with PFCAmp Class: Class-DRMS Power: 1600 WPeak Power: 3200 WCooling: Passive (convection)Operating voltage:100-240V~ 50-60 Hz (Full Range)Wireless position recognition: WPD technologyProcessorController: DSP, 64 bit 96 kHzLimiter: Peak, RMS, ThermalControls: Rotary Delay Control (0-9.9 ms, steps: 0.1 ms),switches (Link/Xover, Cardioid Preset, System test,Phase), Subwoofer level, Xover LPFInputMains connections: PowerCON® TRUE1 In/linkMaximum number of subwoofer for each daisy chainpower connection [mains input + mains link]: 1+3 VIOS118** (220-240V~), 1+1 VIO S118** (100-120V~)Signal Input: (Balanced)1x IN (female)Signal Out: (Balanced) Link OUT (male)RDNET connectors:Data In / Data OutUSB connector: standard USB B-type (for SERVICE DATA)MechanicsHousing: Wooden box/black polyurea finishGrille: Full metal (CNC machining)Handles: 2 per sideRigging points: 4 in the upper side, 4 in the lower sidePick points (stack mode): yes (on top for DRK210)Width: 720 mm (28.34 in)Height: 520 mm (20.47 in)Depth: 695 mm (27.36 in)Weight: 45.1 kg (99.42 lbs.)Download the complete user manual on:/EN/Downloads.aspxEMI CLASSIFICATIONAccording to the standards EN 55103 this equipment is designed and suitable to operate in E5 Electromagnetic environments.FCC CLASS A STATEMENT ACCORDING TO TITLE 47, PART 15, SUBPART B, §15.105This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.WARNING: This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference. WARNING: Make sure that the loudspeaker is securely installed in a stable position to avoid any injuries or damages to persons or properties. For safety reasons do not place one loudspeaker on top of another without proper fastening systems. Before hanging the loudspeaker check all the components for damages, deformations, missing or damaged parts that may compromise safety during installation. If you use the loudspeakers outdoor avoid spots exposed to bad weather conditions.Contact dB Technologies for accessories to be used with speakers. dBTechnologies will not accept any responsibility for damages caused by inappropriate accessories or additional devices.Features, specification and appearance of products are subject to change without notice.dBTechnologies reserves the right to make changes or improvements in design or manufacturing without assuming any obligation to change or improve products previously manufactured.Scan withyour QRReader App todownload thecomplete UserManual。
