透明微晶玻璃、黑色微晶玻璃、耐高温微晶玻璃耐高温玻璃——透明微晶玻璃、黑色微晶玻璃(英文名Glass Ceramic，也称玻璃陶瓷)材料提供：国产微晶玻璃，常规最大尺寸350*450*4mm，也可以选择进口微晶玻璃，常规最大尺寸1954*1100,2100*1266，厚度4\5。

透明微晶玻璃介绍：由于其极低的热膨胀度，透明微晶玻璃不会受高温(760℃）的影响，也不受显著温度变化或温度差异的影响，且十分优越的耐热冲击性能。

另外，透明微晶玻璃具有良好的热辐射，特别是短波红外辐射透过性。

而正是在为火炉燃烧过程中释放的强烈热辐射为我们带了舒适暖意。

因此，微晶玻璃特别知合应用在既有高热能又需要良好透光性的场合，作为室内加热装置（如壁炉和火炉）的观察窗。

图 1 透明微晶玻璃 150 999 63668产品应用：◈室内加热/取暖器的视窗面板（燃油/燃气室内取暖器/炉、传统燃料的室内取暖器/炉）◈红外辐射加热/取暖器的面板◈加热电暖炉的盖板玻璃◈反光杯和高性能泛光照明灯的盖板◈红外烘干器的盖板◈投影仪的保护盖片◈隔紫外线护罩◈烤肉/烧烤设备的面板◈大功率泛光灯和反射器上耐高温的面板加工：①切割、②倒角、③钻孔、④丝印、⑤镀膜黑色微晶玻璃面板说明：由特殊微晶玻璃制成，该材料的最大特点是：可耐高达750℃的急剧升温。

微晶玻璃面板非常环保，不含砷、锑等有毒重金属。

它的主要原料是石英，这种原料在自然界取之不尽、用之不竭。

黑色微晶玻璃灶具面板非常坚固、耐受冲击，经久耐用。

灶具面板横向热传导低，靠近烹调区的地方温度相对较低，热量会直接传导至烹饪锅具。

图 2 黑色微晶玻璃 150 999 63668黑色微晶玻璃主要物理属性：◈热膨胀几乎为零；◈温度稳定性和耐久性好；◈机械稳定性高；◈系统优化的红外透射率；◈热传导率低；◈抗热冲击能力强。

产品特点补充说明：•◈能连续承受600℃高温5000小时而不破裂；•◈具有极高的热稳定性，即使温度骤变高达750℃时也能坦然面对；•◈横向导热性低•◈智能化一根据要求提供包括触摸传感器的智能用户界面•◈容易清洗，可毫不费力地清除其表面的污溃。
