立体发光LED灯片的光学性能研究邹军;李杨;朱伟;陈浩;曲士巍;王艺燃;吴晓枫;林宇杰【摘要】立体发光灯片的关键是在保证光通量的前提下,如何获得均匀的正反面发光.本文对3种荧光粉平面涂覆立体灯片的正面和反面的瞬态和稳态光通量、色温、色品坐标进行了研究,发现直接涂覆荧光粉胶的灯片总的光通量最大,但正反面的发光性能相差很大;在涂覆荧光粉之前先平面涂覆一层硅胶,可获得正反面发光较均匀的灯片;而在该硅胶层内掺杂扩散粉的灯片,不但没有提高灯片的正反面发光均匀度,反而大幅度降低了光通量值.此外,测试3种样品的发光角度,发现其发光角度分布相似,而发光强度与积分球测试的光通量比值相近.结果表明,涂覆荧光粉之前先平面涂覆一层硅胶工艺,既可以保证立体发光灯片具有较大的光通量又可以获得均匀的正反面发光.【期刊名称】《发光学报》【年(卷),期】2015(036)006【总页数】4页(P657-660)【关键词】立体发光;LED灯片;光通量;色温;色品坐标【作者】邹军;李杨;朱伟;陈浩;曲士巍;王艺燃;吴晓枫;林宇杰【作者单位】上海应用技术学院理学院,上海201418;上海应用技术学院材料与工程学院,上海201418;浙江亿米光电科技有限公司,浙江嘉兴314100;浙江亿米光电科技有限公司,浙江嘉兴314100;浙江亿米光电科技有限公司,浙江嘉兴314100;浙江亿米光电科技有限公司,浙江嘉兴314100;浙江亿米光电科技有限公司,浙江嘉兴314100;上海博恩世通光电股份有限公司,上海201108【正文语种】中文【中图分类】O482.31;TN383+.1市场化的LED封装技术为正装芯片通过绝缘胶或银胶固定于凹杯中，通过金线将正负极连接出来，然后再其上点上混有荧光粉的硅胶，点亮后即产生白光。
该产品的缺点有3个[1-2]：(1) 金线受到硅胶热胀冷缩易断；(2) 受到金线弧度影响，混合荧光粉的硅胶形状难以控制，导致荧光粉分布不均匀；(3) 芯片生长于蓝宝石衬底上，芯片厚度约为8 μm，而蓝宝石厚度约为150 μm，芯片热量要通过蓝宝石传导到支架上，路径长且热阻大，散热性能差。
led屏芯片LED屏芯片（LED Display Chip）是指用于驱动LED屏显示的集成电路芯片。
它是将数字信号转换为控制LED点亮的电流信号的关键组件，具有过流保护、灰度控制、亮度调节、扫描控制等功能。
LED屏芯片通常由控制器和驱动器组成。
控制器用于接收来自上游的视频信号，并对信号进行处理、分解，将每个像素点的RGB颜色值转换为对应的电流值。
驱动器则负责通过驱动电路将电流信号传输到对应的LED像素。
LED屏芯片的种类多样，主要包括串行驱动芯片、平行驱动芯片、RGB三合一驱动芯片等。
其中，串行驱动芯片常用于大屏幕显示，具有串行通信功能，可以简化线路结构，减少接线数量。
平行驱动芯片则常用于小屏幕显示，能够实现高刷新率和高灰度控制。
RGB三合一驱动芯片则将红、绿、蓝三个像素点的驱动电路集成到一个芯片中，可以减少组装成本和体积。
LED屏芯片的特点主要有以下几个方面：首先，高集成度。
LED屏芯片具有高度集成的特点，可以实现复杂的图像处理和控制功能，提高显示效果。
其次，高亮度和色彩饱和度。
LED屏芯片能够提供高亮度和丰富的颜色，使得显示效果更加鲜艳生动。
再次，低功耗。
LED屏芯片采用低功耗设计，可以有效降低能耗，延长屏幕的使用寿命。
此外，可靠性和稳定性强。
LED屏芯片具有较高的抗干扰能力和可靠性，能够应对各类环境和工作条件。
最后，易于控制和维护。
LED屏芯片具有直观的控制界面和灵活的参数调节功能，方便用户进行显示内容的设置和调整。
同时，芯片本身也具有自动检测和故障显示功能，便于维护人员进行故障排查和修复。
综上所述，LED屏芯片是LED显示屏中至关重要的组成部分，承担着将数字信号转换为可视化图像的关键任务。
随着科技的进步和技术的不断创新，LED屏芯片将会进一步提升其集成度、亮度、颜色饱和度和稳定性，为用户提供更好的显示效果和使用体验。
为什么要用覆晶LED覆晶焊技术支持的LED光源与传统封装光源相比，具有热阻低，电压低，大电流密度光效高的特点，综合研究表明覆晶LED光源在应用上有其独特的潜力和优势。
优点：（1）、高可靠性,最稳定的SMT锡制程，承受拉力是传统LED的数十倍。
（2）、低热阻(3014热阻为40℃/W,倒裝为5.8℃/W)，高散热性，防止热量过高而烧坏晶片或荧光粉和封装胶。
（3）、无金线可实现多芯片的集成，特别是COB和高压LED灯源。
也有效的避免金线引起的各种风险，比如热膨胀使之断裂，外部冲击波或压力造成金钱断裂等优势。
（4）、导电面积大,内阻小，能承受大电流通过，减少因为内阻大引起的过大热量。
（5）、发光率高，发光角度大等优点。
（6）、封装工艺简化，降低封装成本，高提生产良率。
（7）、低光衰，不因为热引起的快速光衰，从而延长了芯片的寿命，是普通灯具的10倍以上一、结构优势首先，相对于正装和垂直的芯片封装方式，覆晶封装没有金线存在，可以有效避免金线可能引起的各种风险。
下表为硅胶、金线、芯片的热膨胀系数值，其数量级的差距说明了硅胶热膨胀对金线的拉扯会造成可靠性的隐患。
材料热膨胀系数其次，覆晶焊采用金属与金属直接接触的方式，其大电流散热能力比传统封装更好。
如图为传统封装与覆晶封装在散热通道方面的区别，传统正装封装通过蓝宝石和固晶银胶散热，覆晶焊通过金属通道散热，传统封装的蓝宝石和固晶胶成为散热瓶颈。
下表所示的数值为蓝宝石、固晶胶、金属三者在导热系数大小，三者对比明显可以发现覆晶焊金属导热通道的巨大优势。
材料导热系数传统封装光源散热通道覆晶焊封装光源散热通道最后，覆晶焊的封装不存在金线的焊线弧度，能够实现超薄型的平面封装。
传统封装方式金线的拉力仅10g左右，而覆晶焊的接触面推力达到500g以上，覆晶封装可以抵抗一定的表面挤压而不影响LED的光电性能，适合于狭小的应用空间内。
例如手机、摄像机、背光等领域。
同时在多芯片的集成，均能发挥超薄易安装高集成的优势。
LED背光源的CHIP与Package技术发展随着光电子技术的不断进步，LED（Light Emitting Diode）背光源在显示技术中的应用越发广泛。
作为一种绿色、高亮度、低能耗的照明方式，LED背光源在液晶显示器、广告牌、室内照明等领域发挥着重要作用。
其中，CHIP与Package技术的发展是推动LED背光源应用广泛的重要因素。
首先，我们将重点关注LED背光源的CHIP技术方面的发展。
CHIP是LED芯片的核心部分，决定了LED的发光效果与性能。
随着技术的进步，CHIP的发展呈现以下几个主要趋势。
第一，芯片尺寸的不断缩小。
随着半导体工艺的进步，LED芯片的尺寸越来越小。
这不仅使得LED背光源更加薄型化，还能在一定程度上提高LED的亮度和发光效率。
第二，芯片的转形发展。
目前，常见的LED芯片形式有方形、圆形和椭圆形等。
而随着技术的进步，人们正在研究新的形状，如星形、六边形等，以满足不同应用场景对光照均匀度和亮度的要求。
第三，颜色显示范围的扩展。
传统的LED芯片主要发出红、黄、绿、蓝等基本颜色。
而随着技术的进步，人们已经研发出了能够显示更多颜色的RGB（红、绿、蓝）LED芯片，甚至可以实现全彩显示。
这大大扩展了LED背光源的应用范围，满足了人们对颜色显示的各种需求。
接下来，我们将关注LED背光源的Package技术方面的发展。
Package技术是将LED芯片封装起来，以保护芯片并提高外部光的输出效果。
随着技术的发展，Package技术也在不断创新，展现出以下几个主要特点。
首先，封装材料的进步。
以前，LED的封装材料主要是有机玻璃和环氧树脂等，但它们的导光性能相对较差。
而如今，人们已经开发了新的材料，如磷光材料和高导热材料，以提高LED的发光效果和散热性能。
其次，封装技术的多样化。
之前，LED的封装形式主要有DIP（双列直插式）、SMD（表面贴装）、COB（芯片封装）等。
而随着技术的进步，人们已经开发了新的封装技术，如MCPCB（金属基板封装技术）、FCPCB（柔性电路板封装技术）等。
BGA(球栅阵列)和Flip Chip(倒装片)作为当今大规模集成电路的封装形式，逐渐引起电子组装行业的关注，并且已经在不同领域中得到应用。
随着表面安装技术的发展，器件引线间距在不断下降，传统的2.54mm和1.27mm间距的器件渐渐被0. 5mm的细间距器件所替代(图1)，这种趋势持续至今，随之又出现有0.4mm、0.3mm乃至更细间距的表面安装器件。
此外，更先进的封装技术，如自动载带焊(TAB)等，可以使得引线间距降至0.2mm或更细的间距。
随着向超细间距领域的发展，表面安装技术受到了诸如器件间距、引线框架制造精度、设备、材料等各种因素的限制。
在芯片(die)级，为增强器件的功能和性能不得不增加I/O数和硅片的尺寸，对于如此之高的I/O数，如果采用传统形式的标准间距的封装，则器件尺寸势必会相当大，而如果采用较小尺寸的封装形式，则又会引起引线间距的急剧减小。
较大尺寸封装的采用，将会使得器件在PCB上占用的面积增大，而且互联的通道会更长，难免会降低预期的使用性能，况且这些较大尺寸封装的制造并不容易，组装到P CB上的过程也并非如人们所料想的那么简单，对生产产量也会有一定的影响，从而也就增大了整个过程的组装费用。
而对于满足了较大的I/O数，但间距更小的封装，在制造和组装方面也同样存在挑战，因此，电子组装者不得不从封装尺寸、引线间距、可制造性等多方面来考虑，力求寻求更好的封装解决办法。
图1 IC封装发展状况面积阵列封装(area array package)就是一种可以解决上述问题的封装形式，它可以在不牺牲器件可制造性的前提下提高器件的功能和性能。
QFP器件的I/O引出端通常采用向周边走线的形式，而面积阵列封装的I/O引出端则在器件底部呈矩阵分布，I/O数的增大和封装体尺寸的减小是特别明显的，见表1和表2。
表1 封装体尺寸为20mm×20mm的不同间距BGA和QFP的I/O数对比表2 I/O数为300的不同间距BGA和QFP的封装体尺寸对比从这两个表可以看出面积阵列封装在器件功能和封装尺寸方面的优点。
