CPL2000低频AC DC电流探头

RCP-2000系列
2000W 前置电源系统
‧国际通用全范围交流输入‧内建5V/0.3A,12V/0.8A 辅助电源‧内建主动式PFC 功能，PF>0.98‧效率可高达92%
‧可承受浪涌输入秒
‧保护种类：短路/过负载/过电压/过温度
‧高功率密度‧内建直流风扇强制冷却，具风扇转速控制功能‧1U 外型
‧可遥控单一单元‧具有遥感功能‧输出电压调整功能‧热插拔(Hot Swap)操作‧PMBus 串行通信
‧AC OK, DC OK 信号,风扇关闭, OTP 警报信号‧内部OR-ing FET ‧3年保固300VAC 53
21.4w/inch
■ 特性:
■ 描述:
AC-DC 整流器RCP-2000系列1U SIZE 并且具有高功率密度，单体瓦数向上提升至2000W 提供服务器应用，资讯技术设备：网络，电信与分布电力构造大范围工业应用，具有热插拔功能与PMBus 通讯协定， RCP-2000 可以装入1U 19 RACK,籍由外部监测设备(RKP-CMU1)与PC 达到监测与控制
3
21.4 W/in
File Name:RCP-2000-SPEC 2013-08-05。

dc电流探头原理
DC电流探头的工作原理主要基于霍尔效应。

当电流经过一根导线时，会在导线周围产生磁场。

霍尔器件能够感应到这个磁场，并输出相应的电压信号。

通过测量这个电压信号，可以推算出流过导线的电流大小和方向。

在DC电流探头中，被测量的直流电流通过一个导磁材料（例如坡莫合金）传递到一个霍尔器件上。

霍尔器件能够将磁场变化转化为电信号，从而反映出被测电流的大小和方向。

为了消除误差和提高测量精度，DC电流探头通常会采用一系列的校准和补偿措施，例如温度补偿、零点校准等。

此外，DC电流探头通常还需要与一个测量仪表或示波器配合使用，以便将电信号转化为易于观察和测量的形式。

不同类型的DC电流探头具有不同的规格和适用范围，例如量程、精度、频率响应等。

选择合适的DC电流探头需要根据实际需求和应用场景来决定。

低频交流电流探头CP1000A(1000A/20Hz~100kHz)深圳市知用电子有限公司CY B E R TE K为安全使用本机器必须严格遵守以下安全注意事项。

如果不按照该说明书使用的话，有可能会损害机器和造成人身伤害。

此外，因违反注意事项进行操作所产生的问题，本公司概不负责。

● 确保产品在额定电压和额定电流范围内使用。

● 探头在使用过程中不要打开外壳和试图接线。

● 不要在潮湿或易燃易爆的环境使用。

● 使用前保证仪器的干燥和清洁。

● 如产品出现问题，请及时与我公司联系。

请不要擅自打开外壳维修，以免发生意外。

1. 概 述CP1000A 电流探头用于交流电流测量，被测电流达到1000A 有效值，2000A 的峰值电流，带宽到100kHz 。

钳口直径约54mm ；标准的BNC 输出接口，可接任何厂家示波器；3个量程可切换，方便小电流测量；增加可选配件BNC 转香蕉插座，可实现和数字万用表的连接。

广泛应用于电机驱动，逆变器，开关电源，航空电子等测量中。

2. 产品及附件说明◆主体说明1. 钳口：夹住被测导线，直径54mm2. 量程选择：提供10A(100mV/A),100A(10mV/A),1000A(1mV/A) 3个量程3. 输出线：约2米，标准的BNC输出接口4. 电流指示方向：电流方向，按照电流方向流过电流，输出为正，否则为负CY B E R TE K选件说明K可选件：BNC(母)转香蕉插座(公)3. 产品规格4. 操作步骤● 连接探头到示波器或者其它测量设备，并正确设置相关参数； ● 探头接入到被测电路，确保电路在关机情况下操作； ● 被测电路开机工作，进行正确测量；●测量完毕后，先关闭被测电路，再取下探头，并保管好。

5. 装箱单CYBERTEK深圳市知用电子有限公司SHENZHEN ZHIYONG ELECTRONICS CO.,LTD. 深圳市龙岗区黄阁北路天安数码城4号大厦A1702 Tel: 400 852 0005*************Q Q: 400 852 0005 Fax**************Email: ******************** © Zhiyong Electronics, 2017 Url: Published in China, May 1, 2017CY B E K。

N2780A Series AC/DC Current ProbesA wide selection of current probes to meet your application's needsData Sheet• Various bandwidths: DC to 2 MHz, 10 MHz, 50 MHz, 100 MHz• DC and AC measurements• Superior 1% accuracy and high signal-to-noise ratio• Overload-protect function prevents probe damage from excessive input • Direct connection to high-impedance 1 MΩBNC input of oscilloscope • “Demagnetize” button to remove any residual magnetism that builds up in the magnetic core• External power supply (N2779A) lets you connect up to three N278xA current probes to a single power supplyCompatible with any oscilloscope with a high-impedance BNC input, the new N2780A Series current probes offer accurate and reliable solution for measuringDC and AC currents. Hybrid technology for AC and DC measurementsUsing hybrid technology that includes a Hall-effect sensor and an AC current transformer, the probes provide accurate measurement of DC or AC currents up to 500 Arms (for model N2780A) or DC–100 MHz (for model N2783A), without breaking into the circuit. Using split core construction, the probe easily clips on and off of a conductor.Wide range of applicationsThe current probes feature broad measurement ranges (up to 500 A), flat frequency response, low noise and low insertion loss that make the probes ideal for current measurements in areas such as measuring steady state or transient current of motor drives, switching power sup-plies, inverters, controllers, sensors, disk drives, LCD displays, elec-tronic ballasts and amplifiers. The high signal-to-noise ratio of theN2782A and N2783A makes them ideal for making low-level current measurements in milliampere ranges.Accurate current measurementA built-in DEMAG (demagnetize) function allows the removal of any residual magnetism that has built up in the magnetic core due to power on/off switching or excessive input current. In addition, voltage offset or temperature drift on the probe can be easily corrected by using thezero adjustment control.Figure 1 N2780A Series current probeswith N2779A power supplyFigure 2 N2783A, N2780A, N2781A and N2782A current probe (from left to right)2Figure 3 Frequency response of N2783AFigure 4 Continuous maximum input rating of N2783ACompatible OscilloscopesAny oscilloscope offering 1 MΩBNC input including Agilent 3000Series, 6000 Series, and Infiniium8000 Series oscilloscopes. Youmust select the input impedanceof the oscilloscope to be 1 MΩinorder to make accurate measure-ments. If the oscilloscope you areusing does not have a 1 MΩinputimpedance setting, you can pur-chase the Agilent E2697A 50Ωto1 MΩadapter.Ordering InformationN2780A2 MHz/500A AC/DC current probeN2781A10 MHz/150A AC/DC current probeN2782A50 MHz/30A AC/DC current probeN2783A100 MHz/30A AC/DC current probeN2779A3-channel power supply forN2780A Series current probes3For more information on AgilentTechnologies’ products, applications or services, please contact your local Agilent office. The complete list is available at:/find/contactus Phone or Fax United States:(tel) 800 829 4444(fax) 800 829 4433Canada:(tel) 877 894 4414(fax) 800 746 4866China:(tel) 800 810 0189(fax) 800 820 2816Europe:(tel) 31 20 547 2111Japan:(tel) (81) 426 56 7832(fax) (81) 426 56 7840Korea:(tel) (080) 769 0800(fax) (080) 769 0900Latin America:(tel) (305) 269 7500Taiwan :(tel) 0800 047 866 (fax) 0800 286 331Other Asia Pacific Countries:(tel) (65) 6375 8100 (fax) (65) 6755 0042Email:*****************Revised: February 5, 2007Product specifications and descriptions in this document subject to change without notice.© Agilent Technologies, Inc. 2007Printed in USA, April 3, 20075989-6432EN/find/emailupdates Get the latest information on the products and applications you select./find/quick Quickly choose and use your test equipment solutions with confidence./find/openAgilent Open simplifies the process of connecting and programming test systems to help engineers design, validate and manufacture electronic products. Agilent offers open connectivity for a broad range of system-ready instruments, open industry software, PC-standard I/O and globalsupport, which are combined to more easily integrate test system development.Microsoft ®and Windows ®are U.S. registered trademarks of Microsoft Corporation.Pentium ®is a U.S. registered trademark of Intel Corporation.Agilent Email UpdatesAgilent DirectAgilent OpenRemove all doubtOur repair and calibration services will get your equipment back to you, performing like new, when promised. You will get full value out of your Agilent equipment throughout its lifetime. Your equipment will be serviced by Agilent-trained technicians using the latest factorycalibration procedures, automated repair diagnostics and genuine parts. You will always have the utmost confidence in your measurements.Agilent offers a wide range of additional expert test and measurement services for your equipment, including initial start-up assistance onsite education and training,as well as design, system integration, and project management.For more information on repair and calibration services, go to/find/removealldoubt。

CX2000 CONDUCTIVITY/RESISTIVITY TRANSMITTERPRODUCT SPECIFICATION SHEET SPECIFICATIONSORDERING INFORMATIONPart Number DescriptionCX2000Conductivity, Resistivity, Controller requires 110-240V AC power. 2 relays, 2 each 4-20mA outputs & wash control. 1/4 DIN enclosure. note: RS485 output version is also available. Please contact Sensorex for details.Measuring Range(Conductivity) (Resistivity)0.000 uS/cm -200.0 mS/cm in 5 ranges0.01/.01/1 uS/cm, 0.01/0.1mS/cm resolution, +/-1% Accuracy (+/- 1 digit)0.00-20.00 MΩ • cm, 0.01 MΩ • cm resolution, +/-1% Accuracy(+/- 1 digit)Temperature Range-30 °C to 130 °C, 0.1 °C resolution, 0.2 °C accuracyCalibration Mode Automatic with built-in standard solutions manual cell constant adjustmentCell Constants0.01, 0.05, 0.1, 0.5, 10/cm fixed or freely selectable 0.0080 - 19.99/cmAnalog Output 1Isolated DC 0/4 -20mA, corresponding to conductivity or resistivity. Max load 500 Ω.Analog Output 2Isolated DC 0/4 -20mA, corresponding to temperature output. Max load 500 Ω.Set-Points Contact: 240V AC, 5A maxActivate: setpoints Hi/Low, Hi/Hi, Low/Low, ON/OFFEnclosure NEMA 4X IP65, with push-button control pad. HWD: 96 mm (3.77”) x 132 mm (5.20”), 1/4 DINPanel Cut-Out93mm (3.66”) x 93mm (3.66”)Weight approx. 0.50kg (1.1lb)Mounting Options Panel or Wall MountAmbient Temperature0 ° C to 50 ° CStorage Temperature-10 ° C to 70 ° CTemperatureCompensationNTC 30K or Pt1000 RTD with automatic compensation or manualTemperatureCoefficientLinear comp 0.00-40.00%, Non-linear comp for natural waters Power Requirement100-240V AC +/- 10%, 5W max, 50/60 Hz 4-20mA outputs for conductivity or resistivity + temp 2 Hi/Lo Relays for controlling alarms, pumps and moreLarge LCD display with auto-sense backlight and contrast settingNEMA 4X, IP65 enclosureSample averaging to enhance stabilityCompatible with Sensorex CS8000 and CS150 series sensorsThe CX2000 is a full-featured Conductivity or Resistivity transmitter/controller. Simply power up your CX2000 with 110-240V AC power and you get a controller with a wide range of useful features:2 relays, 1 wash control, 2 each 4-20mA outputs (Cond & Temp or Resistivity & Temp).Calibration is simple with preset standards and can be password protected with a programmable security code. Mounting choices include: wall or panel.The large LCD display with auto-sense backlight and contrast adjust makes the CX2000 display so it can be easily viewable in all areas.PARTS COVERED BY THIS PRODUCT DATA SHEET INCLUDE: CX2000。

目录一、产品简介 (1)1.1产品型号命名规则 (1)1.2选配功能代号命名规则 (2)1.3产品铭牌 (3)1.4产品外观 (4)1.5技术规范 (5)1.6产品设计执行标准 (6)1.7安全事项 (6)1.8注意事项 (8)1.9日常检查和保养 (10)二、控制面板介绍 (11)2.1控制面板概述 (11)2.2控制面板及安装支架结构尺寸 (12)2.3控制面板操作说明 (13)2.4参数设置方法 (13)2.5功能码区内与区间的切换方法 (14)2.6四行液晶界面切换操作说明 (16)2.7面板显示内容介绍 (18)三、安装接线 (19)3.1变频器安装 (19)3.2接线 (19)3.3主回路的电压、电流和功率的测量方法 (24)3.4控制端子功能简介 (26)3.5功率回路推荐配线（铜材质） (30)3.6保护导体（地线）的截面积 (30)3.7总体接线示意图 (31)3.8传导和辐射干扰对策 (32)四、简易操作与运行指南 (38)4.1产品基本知识 (38)4.2简易操作指南 (39)4.3基本控制运行指南 (42)五、功能参数 (49)5.1基本参数 (49)5.2运行控制 (60)5.3多功能输入输出端子 (68)5.4模拟量输入输出 (80)5.5脉冲输入输出控制 (85)5.6多段速度控制 (89)5.7辅助功能 (94)5.8故障与保护 (103)5.9电机参数区 (109)5.10通讯参数 (114)5.11PID参数区 (118)5.12保留参数区 (125)5.13转矩控制参数区 (125)5.14显示参数区 (128)附录1 常见故障处理 (130)附录2 供水系统参考连线图 (133)附录3 产品一览表及结构型式一览表 (136)附录4 制动电阻选型表 (140)附录5 通讯手册 (141)附录6 功能码速查表 (153)附录7 主/从控制调试 (191)升级记录: (200)敬告用户: (201)产品简介一、产品简介本使用手册简要介绍了EP66系列变频器的安装接线、参数设定及操作使用的有关事项，务请妥善保管。

AC/DC Current Measurement SystemsTCPA300, TCP312A, TCP305A, TCP303, TCPA400, TCP404XL DatasheetThe TCP300 and TCP400 Series AC/DC current measurement family is a highly advanced current measurement system for today's current measurement needs. When connected to Tektronix oscilloscopes with TEKPROBE Level II, TekConnect (w/ TCA-BNC), or TekVPI (w/ TPA-BNC)interfaces, current measurements and calculations are simple and easy.Key performance specificationsDC - 100 MHz, Current Probe Amplifier (TCPA300) uses:DC - 100 MHz, 30 A DC (TCP312A)DC - 50 MHz, 50 A DC (TCP305A)DC - 15 MHz, 150 A DC (TCP303)DC - 50 MHz, Current Probe Amplifier (TCPA400) Uses:DC - 2 MHz, 750 A DC 1 (TCP404XL) (500 A DC Continuous)1Derated with duty cycleKey featuresAutomatic scaling and units 2 - Oscilloscope on-screen readout of magnitude and amps reduces measurement errors with no more hand calculations AC/DC input couplingLow insertion impedance reduces device under test loading Split-core construction allows easy circuit connectionStatus indicators provide visual operating status and notification of potential error conditions - degauss, probe open, overload, not terminated into 50 Ω, noncompatible probe typeLow DC drift and noise allows improved low-level current measurements3rd party safety certification2 Requires a TDS TEKSCOPE oscilloscope or a TekConect oscilloscopewith TCA-BNC adapterApplicationsDevelopment and analysis solutions for designers, installers, and service personnel in telecom, data comm, computer, and semiconductor power electronics environments for:Power supplies (switching and linear)Semiconductor devices (SCRs, IGBTs, MOSFETs, CMOS, BJTs)Power inverters/converters Electronic ballastsIndustrial/consumer electronicsMobile communications (phone, satellite, relay stations)Motor drivesTransportation systems (electronic vehicles, electric trains, locomotives,avionics)Meets today's AC/DC current measurement applicationsThe TCPA300 amplifier, when used with TCP312A, TCP305A, or TCP303probes, provides a wide range of current measurement capability and spans the gap between low-level milliamp measurements to very high current levels. These three probes provide current measurement capabilities of 30 A, 50 A, and 150 A DC continuous. For even higher current levels, the TCPA400 amplifier with the TCP404XL current probe measures 500 A DC continuous and 750 A DC continuous, derated with duty cycle.Higher-frequency performance is available with the TCP312A w/TCPA300providing ≥100 MHz bandwidth and a maximum current of 30 A DC.Measurement errors and manual calculations are now a thing of the pastWith this new series of current measurement tools, automatic control and on-screen scaling and units is provided for users of Tektronix TDS3000, TDS500, TDS600, TDS700, TDS5000, TDS6000, and TDS7000B series oscilloscope systems (the DPO3000, MDO/MSO/DPO4000, MSO/DPO5000, and DPO7000 series oscilloscopes, the TPA-BNC adapter is required).The TCP300/TCP400 current measurement systems seamlessly integrate with your TDS series oscilloscope.Even non-TEKPROBE systems can use the TCPA300/400 series to make proper current measurements by simply multiplying the measured output voltage on the oscilloscope by the TCPA300/400 series range setting.SpecificationsAll specifications apply to all models unless noted otherwise. Model overviewDatasheet2 CharacteristicsMaximum current ratingsHigh-current sensitivityLow-current sensitivityRange 1 A/V 5 A/V 5 A/V N/A DC (continuous) 5 A 25 A 25 A N/A RMS (sinusoidal) 3.5 A 17.7 A 17.7 A N/A Peak50 A50 A500 AN/APhysical characteristicsAmplifiersProbesMaximum conductor sizeCable length1.5 m (60 in)1.5 m (60 in)2 m (78.7 in)8 m (315 in)EMC environment and safetySafety complianceElectromagnetic compatibility,amplifiers only EC Council Directive 89/336/EEC, FCC Part 15, Subpart B Class A, AS/NZS 2064.1/2.TemperatureOperating 0 °C to +50 °C (32 °F to 122 °F)Nonoperating-40 °C to +75 °C (-40 °F to 167 °F)AC/DC Current Measurement Systems 3HumidityOperating5% to 95% R.H. to +30 °C (86 °F)5% to 85% R.H. +30 °C to +50 °C (86 °F to 122 °F)Nonoperating5% to 95% R.H. to +30 °C (86 °F)5% to 85% R.H. +30 °C to +75 °C (86 °F to 167 °F)AltitudeOperating2000 m (6800 ft.) maximumNonoperating12,192 m (40,000 ft.) maximumOrdering informationModelsProbesTCP312A Probe AC/DC current, DC to 100 MHz; 30 A DC (Requires TCPA300 amplifier)TCP305A Probe AC/DC current, DC to 50 MHz; 50 A DC (Requires TCPA300 amplifier)TCP303 Probe AC/DC current, DC to 15 MHz; 150 A DC (Requires TCPA300 amplifier)TCP404XL Probe AC/DC current, DC to 2 MHz; 500 A DC (750 A DC derated with duty cycle) (Requires TCPA400 amplifier) AmplifiersTCPA300 Amplifier AC/DC current probe, DC to 100 MHz, (Requires TCP305A or TCP312A or TCP303 probes)TCPA400 Amplifier AC/DC current probe, DC to 50 MHz, (Requires TCP404XL probe)Recommended accessoriesCover, large probe protective; (forTCP303, TCP404XL)016-1924-00Case, transit; currentmeasurement systems016-1922-0050 Ω feedthrough termination011-0049-0250 Ω BNC-to-BNC coaxial cable012-0117-00TEKPROBE interface cable,TCPA300 or TCPA400 amplifier toTDS series oscilloscopes012-1605-00Current loop, 1 turn, 50 Ω, BNCconnector (for TCP305A, TCP312A,TCP202A)067-2396-00Current loop, 1 turn, 50 Ω, BNCconnector (for TCP303, TCP404XL)015-0601-50TCPA300/TCPA400 amplifiercalibration adapter174-4765-00Power measurements deskew fixture for TCP202A, TCP305A, TCP312A, TCP303 probes 067-1478-00Datasheet4 WarrantyOne year parts and labor.Power requirementsAmplifiers90 V to 264 V, 47 to 440 Hz, 50 W; Maximum CAT II (auto switch)Probes TCP312A, TCP305A, TCP303 probes require a TCPA300 Amplifier; TCP404XL probe requires a TCPA400 Amplifier OptionsPower plug optionsOpt. A0North America power plug (115 V, 60 Hz)Opt. A1Universal Euro power plug (220 V, 50 Hz)Opt. A2United Kingdom power plug (240 V, 50 Hz)Opt. A3Australia power plug (240 V, 50 Hz)Opt. A5Switzerland power plug (220 V, 50 Hz)Opt. A6Japan power plug (100 V, 110/120 V, 60 Hz)Opt. A10China power plug (50 Hz)Opt. A11India power plug (50 Hz)Opt. A12Brazil power plug (60 Hz)Opt. A99No power cordServiceOptionsOpt. C3Calibration Service 3 YearsOpt. C5Calibration Service 5 YearsOpt. D1Calibration Data ReportOpt. D3Calibration Data Report 3 Years (with Opt. C3)Opt. D5Calibration Data Report 5 Years (with Opt. C5)Opt. R3Repair Service 3 Years (including warranty)Opt. R3DW Repair Service Coverage 3 Years (includes product warranty period). 3-year period starts at time of instrument purchase Opt. R5Repair Service 5 Years (including warranty)Opt. R5DW Repair Service Coverage 5 Years (includes product warranty period). 5-year period starts at time of instrument purchase Opt. SILV400Standard warranty extended to 5 years (TCP305A, TCP312A, TCPA300, TCPA400 )Opt. SILV600Standard warranty extended to 5 years (TCP303, TCP404XL)Tektronix is registered to ISO 9001 and ISO 14001 by SRI Quality System Registrar.AC/DC Current Measurement Systems 5DatasheetASEAN / Australasia (65) 6356 3900 Austria 00800 2255 4835*Balkans, Israel, South Africa and other ISE Countries +41 52 675 3777 Belgium 00800 2255 4835*Brazil +55 (11) 3759 7627 Canada180****9200Central East Europe and the Baltics +41 52 675 3777 Central Europe & Greece +41 52 675 3777 Denmark +45 80 88 1401Finland +41 52 675 3777 France 00800 2255 4835*Germany 00800 2255 4835*Hong Kong 400 820 5835 India 000 800 650 1835 Italy 00800 2255 4835*Japan 81 (3) 6714 3010 Luxembourg +41 52 675 3777 Mexico, Central/South America & Caribbean 52 (55) 56 04 50 90Middle East, Asia, and North Africa +41 52 675 3777 The Netherlands 00800 2255 4835*Norway 800 16098People's Republic of China 400 820 5835 Poland +41 52 675 3777 Portugal 80 08 12370Republic of Korea 001 800 8255 2835 Russia & CIS +7 (495) 6647564 South Africa +41 52 675 3777Spain 00800 2255 4835*Sweden 00800 2255 4835*Switzerland 00800 2255 4835*Taiwan 886 (2) 2722 9622 United Kingdom & Ireland 00800 2255 4835*USA180****9200* European toll-free number. If not accessible, call: +41 52 675 3777 Updated 10 April 2013 For Further Information. Tektronix maintains a comprehensive, constantly expanding collection of application notes, technical briefs and other resources to help engineers working on the cutting edge of technology. Please visit . Copyright © Tektronix, Inc. All rights reserved. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material. Specification and pricechange privileges reserved. TEKTRONIX and TEK are registered trademarks of Tektronix, Inc. All other trade names referenced are the service marks, trademarks, or registered trademarks of their respective companies.24 Apr 201360W-16458-7 。

USER MANUALCP2100 Series AC/DC Current ProbeUser ManualProduct IntroductionThe CP2100 series current probe is a BNC type that can measure both DC and AC. With split design and compact look, it also can be connected to multimeters via connector. Automatic and manual zero adjustment, powered by USB, no need additional power supply, making measurement more convenient, often used in motor drives, industrial frequency, inverters, power supplies, avionics and other fields.Safety Precautions➢The measurable circuit should be CAT II 600V or below➢Do not measure bare conductors➢Do not touch the measured conductor and sensor head during measurement➢Do not use in a humid environment➢Do not touch the instrument or the measured object with wet hands➢Please ground this product through the USB power cord➢Please use this product as required SpecificationsOperation Instructions1.Connect BNC interface to the oscilloscope (or other instruments), then plug the USB cable to power the probe;2.Select appropriate range according to current range, the corresponding button light will turn Green;3.Adjust the oscilloscope settings: Input impedance 1MΩ; select probe to Current or display as A; Set attenuationratio on corresponding channel, 100A（0.01V/A）to 100X, range 10A（0.1V/A）to 10X；4.Press Zero button to do zero calibration, after success, the buzzer will “beep” one time; if “beep” three times，meaning zero calibration has failed; can also go Manual to adjustment. The external magnetic field may have slight influence on the DC zero position, do not move it in a large range after zero adjustment is completed; 5.Clamp the conductor under test according to the direction indicated by the jaws. Note: If the measured currentUSER MANUALflows in the opposite direction, the output will be negative;6.Adjust the oscilloscope to get the best waveform;Note: When the current exceeds the range, the buzzer will beep for a long time and the button light will flash. ReferencesF1. - Maximum current vs Frequency curve F2 - Amplitude-frequency characteristic curve - CP2100A F3 - Amplitude-frequency characteristic curve-CP2100B F4 - DC signal linearity (0.01V/A)MaintenanceDuring the warranty period of the product (one-year) and under normal use, the company will be responsible for free repairs due to fault caused by the quality of the product itself, and the product must not be disassembled or repaired without Micsig permission. Please keep the product dry, clean and tidy. If there is dirt, use a soft cloth or sponge with alcohol to wipe off. Do not use water. In order to ensure the performance of the product, it is recommended to check or calibrate once a year.StatementThe information provided in this document is subject to change in future versions without notice. In addition, to the maximum extent permitted by applicable laws, Micsig does not provide any express or implied warranty for this manual and any information contained in it.Shenzhen Micsig Instruments Co., Ltd.Tel:+86 (0)755 88600880 Email:****************Add: A106, Huafeng International Robot Industrial Park,Bao’An district, Shenzhen, 518126, Guanddong, China。

®i3000s/i2000 FlexAC Current Probe说明书简介i3000s 24 Flex、i3000s 36 Flex 和 i2000 Flex 交流电流探头（以下简称为“探头”）可与示波器、数字万用表、记录器或数据记录仪配套使用。

i3000s 探头可用于测量 3000 A 以内的交流电流。

i2000 则可用于测量 2000 A 以内的交流电流。

柔性测量头可以测量常规钳式电流探头难以触及或接近的导体上的电流。

探头可以提供一个低电压（i3000s 型为 3 V 交流电，i2000 为 2 V 交流电）输出，该输出与被测电流成正比。

使用 i3000s 型时，探头可提供 30 A、300 A 和 3000 A 满刻度直接读数；若使用 i2000 则为 20 A、200 A 和 2000 A。

符号下表所示为产品上和/或本手册中所用的符号。

符号描述~请勿将本品作为未分类的城市垃圾处理。

请联系 Fluke或专业的回收者进行处理。

W重要信息。

参见手册。

T双重/加强绝缘。

-请勿直接在危险带电导体上使用。

P符合有关欧洲标准。

>符合 UL 标准。

PN 2560447March 2006 (Simplified Chinese)©2006 Fluke Corporation. All rights reserved.安全说明本说明书中，警告一词代表对使用者构成危险的情况或行为。

小心一词代表对校准器或测试仪器可能造成损坏的情况或行为。

WX警告为了避免触电或人身伤害：•探头只能由具备资格的人士使用。

•在安装和使用探头时要小心；被测电路上可能带有高压和电流。

•探头只能由合格的维修人员负责进行维护。

•防止探头受潮和进水。

•视需要穿戴防护服和手套。

•不要将本产品安装在带电导体上。

在安装柔性测量头之前，始终记住断开被测电路的电源。

•在使用探头之前，总是先检查电子装置、连接电缆及柔性测量头是否损坏。

L2000-C射频导纳物位控制器说明书一、概述山东中煤工矿物资集团有限公司（原济宁中煤机械制造厂）生产的L2000-C系列射频导纳物位开关是一种新颖的物位测量仪表，它采用先进（抗粘附）射频导纳技术，克服了电容式物位计不能消除导电挂料影响的缺陷，仪表具有运行可靠，能抗挂料层的影响。

L2000-C标准探头中心信号杆采用直径10mm不锈钢，保护套长150mm，总长450mm，坚固实用。

有L890C平板探头，解决大固体物料冲击棒的问题。

有L863WC钢缆探头，使L2000C适用于几乎所有工业现场对液体；粉料；块料；高温场合的物位检测。

仪表还具有安装方便，免维护，价格低等特点。

仪表广泛用于石油、化工、冶金、医药、电力、食品、造纸等工业领域。

二、参数特点：开关控制，射频导纳原理，NULL-KOTE抗粘附电子线路。

继电器容量：DPDT，额定10A，115V/AC延时/模式：0~30秒可调/开关型电源：230Vac，3瓦或24V/DC<3瓦灵敏度：小于0.5Pf探头耐温：40℃～+80℃(可定制高温探头800C°)电路部份耐温；-40℃～+80℃失电保护（Fail—Safe）模式：采用高低模式，现场可调外壳：IP65，重型铸铝外壳三、选型指南1）在测非导电介质时，可以为水平或垂直安装，如需要垂直安装时，要求探头长至少大于控制位置6英寸左右。

2）在测导电液体时、泥浆或界面检测时，可以水平垂直安装，但探头穿过容器壁时，保护电极应比容器壁上的积料厚度长出2英寸。

如用户需要，我们可以提供液介质为Teflon或Kyanr材料的防腐探头（采用涂层法兰连接）。

校准1）灵敏度的校正当进行调节时，请注意这些总的规则：*将2个灵敏度调节电位器逆时针旋转增加灵敏度。

*当两个灵敏度控制调好后，红色灯亮，表示探头上“有”物料存在，绿色灯亮，表示（无）物料存在。

*安装方法有水平或垂直两种。

为保证设备稳定工作应有5分钟预热。
