内置式管状电机控制器的操作说明(标准型)V1.0版本

控制器操作说明书2010年12月V 2.1首先感谢贵公司选用我公司的制冷机组产品.同时感谢您认真阅读本操作说明书。

一、 概述本机组使用的是触摸式操作显示屏。

机组的运行状态和全部操作均在屏幕上进行。

屏幕操作是通过已为该机组设置了各相应的屏幕页面及其按钮，您可以按照您的操作要求轻按各有关的按钮进行实际的操作。

屏幕中的按钮是轻触摸式的，请不使用工具或戴手套操作，以免划伤擦毛屏幕。

本控制器中显示的参数单位：压力：Kpa A 绝压温度：℃电流：Ａ液位：％设备在完全正常的情况下，10分钟内对屏幕无任何操作屏幕的灯光会自动关闭，以延长屏幕使用寿命。

任意触摸一下屏幕立即自动点亮。

屏幕中含有设备的常见故障说明，用户可以随时翻阅。

帮助用户及时查找原因排除故障。

温度巡检仪显示的是主电机的各点温度：CH01 前轴承温度CH02 后轴承温度CH03 Ａ绕组温度CH04 Ｂ绕组温度CH05 Ｃ绕组温度二、 主界面屏幕的操作说明接通电源后屏幕将显示本说明书封面上的图案，触摸该图案一下，屏幕就显示如下：主界面。

此界面中显示了常用的基本运行参数、机组状态和必要的操作按钮，当出现故障、报警时自动弹出信息条并用文字（走马灯形式）显示相应的内容，蓝色信息属报警（机组不停机），红色信息属故障（机组停机，故障复位也不会自动启动）。

触摸“机组启动”按钮，在屏幕上会弹出如下窗条：♦轻按“能量控制手动”按钮，在主界面的右上角能量位置值的下面将出现“＋”、“－”按钮，表示机组运行中能量控制由操作人员人为地增载、减载操作。

但当运行参数超过安全保护设定值，电脑仍会自动强制减载甚至故障停机。

♦轻按“能量控制自动”按钮，“＋”、“－”按钮将不出现，表示机组运行中能量控制由电脑自动地增载、减载操作。

♦轻按“本地启动”按钮，请注意：这是真正的启动按钮。

机组由电脑按指定的程序自动控制启动、运行、自动能量调节和液位控制。

♦启动过程：电脑首先检查无任何故障，再检查吸气压力应大于‘压缩机启动压力设定值’、‘高压电机柜允许’、‘停机到启动间隔时间到’等；电脑启动油泵，检查能量位置应小于 5%（否则自动减载）、喷油压差应大于150Kpa；释放主机停机信号，1秒钟后发主机启动命令。

螺杆空压机微电脑控制器MAM-KY12S（B）-（Ⅻ）型（中文液晶显示-280）用户手册深圳市普乐特电子有限公司地址：深圳市福田区商报路天健工业区25栋西六楼电话：（0755）83172098 83172068 邮编：518034传真：（0755）83172966 E-mail：plt@网址：特点：●LCD中英文显示●对电机具有短路、堵转、缺相、过载、不平衡等全方位保护功能●对电机具有起停控制、运行控制●对空压机进行防逆转保护●对多点温度进行检测与控制保护●自动调节负荷率控制压力平衡●高度集成，高可靠性，高性价比●远程/机旁选择控制●联动/独立选择运行●RS-485通讯功能一、基本操作1、按键说明图1︱——起动键：按此键可起动电机运行○——停机键：按此键可停止电机运行S——设定键：修改完数据后，按此键确认数据存储输入▲——上移键：数据修改时，按此键上翻修改该数位；在菜单选择时作为选择键。

▼——下移键：数据修改时，按此键下翻修改该数位；在菜单选择时作为选择键。

◆——移位键/确认键：修改数据时，此键作为移位键；在菜单选择时作为确定键。

C——返回键/复位键：在菜单操作时作为返回键返回上一级菜单；故障停机时，按此键复位。

2、状态显示与操作机组通电后显示如下界面：5秒后显示以下主界面：按“▼”进入以下菜单选择界面：a、运行参数查看按“▲”或“▼”移动黑色滚动条到“运行参数”菜单后，按确认键“◆”后弹出下一级菜单：再按“◆”弹出如为最后一级菜单，界面不会出现黑色滚动条，按返回键“C”返回上级菜单或主界面。

如在某一界面停止操作，数秒钟后自动返回主界面。

用“▲”、“▼”移动键、确认键“S”和返回键“C”根据上述方法可完全观察到运行时间、本次运行时间、维护参数、历史故障、出厂日期、现场故障等运行参数并返回到上级菜单。

b、用户参数1）、参数修改方法══在运行状态和停机延时过程中不能修改用户参数和厂家参数══用前述运行参数查看的方法可查看和修改用户参数，如修改压力上限，操作方法如下：按“▲”或“▼”移动黑色滚动条到“用户参数”项后按确定键“◆”弹出再按确定键“◆”弹出如不继续按确定键“◆”即可查看用户参数。

ContentsDescription Page 1.0 Setup ................................21.1 Before Installation .....................21.2 Installation ..........................21.2.1 DIN Rail Kits ......................21.3 Wiring ..............................21.3.1 Series Wiring Applications ...........31.3.2 Parallel Wiring Applications ..........31.3.3 Dry Contact Wiring .................31.3.4 Telephone Line Protection ...........31.4 Apply Power .........................3 1.5 Specifications ........................41.6 Warranty . (4)nstallation Instructions for EatonSurge Protective Device XXCFXXX30-RJ2Instruction Manual IM01005027E Rev. 4Effective October 2018Installation Instructions for EatonSurge Protective Device XXCFXXX30-RJEATON WARNINGHAZARDOUS VOLTAGES PRESENTIMPROPER INSTALLATION OR MISAPPLICATION OF THESE DEVICES MAY RESULT IN SERIOUS INJURY TO INSTALLER AND/OR DAMAGE TO ELECTRI-CAL SYSTEM OR RELATED EQUIPMENT. READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE BEGINNING INSTALLATION. PROTECTIVE EYE-WEAR SHOULD BE WORN WHENEVER WORKING AROUND HAZARDOUS VOLTAGES.NOTICEALL INSTRUCTIONS AND MEASUREMENTS MUST BE COMPLETED BY A LICENSED/QUALIFIED ELECTRICIAN IN ACCORDANCE WITH THE U.S. NATIONAL ELECTRICAL CODE, STATE AND LOCAL CODES OR OTHER APPLI-CABLE COUNTRY CODES. THE U.S. NATIONAL ELECTRICAL CODE AND STATE AND LOCAL REQUIREMENTS (OR OTHER APPLICABLE COUNTRY CODES) SUPERSEDE THIS INSTRUCTION.Catalog NumberVoltage RangeModeVPRMCOVInSCCRPeak Surge CurrentXXCF12030-RJ 248 - 149 Vdc 1 100 -127 Vac L-N L-G N-G 5005005001501501505kA 10kA 80kAXXCF23030-RJ 2150 - 300 Vdc 1128 - 230 VacL-N, L-G, N-G8008008002752752753kA 10kA 80kA1 UL 1449 4rd Edition does not list SPD products rated less than 110 Vac or DC voltages.2UL 1449 4th Edition, UL 1283 7th Edition1.0 SetupVerify that system voltages do not exceed those listed in Section 1.5, Specifications. • All AC measurements should be completed with an RMS voltme-ter.• All DC measurements should be completed with a DC voltmeter.•DO NOT INSTALL FILTER IF MEASURED VOLTAGE EXCEEDSMAXIMUM OPERATING LIMITS.Choose location for filter installation so that maximum separation can be maintained between input leads, output leads and ground leads.1.1 Before InstallationREMOVE POWER FROM ELECTRICAL SYSTEM BEFORE MOUNTING FILTER.•Filter MUST be mounted within enclosure to assure personnel safety from exposed terminals.IMPORTANT:FILTER SHOULD BE LOCATED SO THAT THE SHORTEST POSSIBLE CONDUC-TOR LENGTH MAY BE USED.•Filter should be mounted to allow maximum separation between input and output wiring.•Filter contains no position-oriented components and can be mounted upside down or sideways.•Filter should be placed in electrical circuit so that it is the last device in the circuit before equipment to be protected.1.2 InstallationFILTER MUST BE CONNECTED TO ELECTRICAL SYSTEM WITH A CIRCUIT BREAKER:For AC Applications•1 – Single Pole / Single Throw 40A circuit breaker(s). The Interrupting Rating of the Circuit Breaker Shall Not Be LessThan the Available Fault Current. Circuit Breaker Ratings of 40A, 240V/415V, 10kA Min. AIC Rating.ote:N Pre-existing breaker(s) of the rated load size may be utilized if provi-sion for multi-conductor connections are made according to N.E.C. 110-14A.•If Neutral wire is to be utilized as L2/NEU then circuit breaker should be provided for that phase.For DC Applications•DC units to be installed after an overcurrent protective device that is rated not to exceed 100% of the current rating of the unit.•Form C contacts are rated at 0.5 Amps at 125 VAC or 1.0 Amps at 30 VDC. These connections are to be used for alarm hook up.T able 1. Relay state when energized.Catalog Part NumberNormally ClosedNormally OpenXXCFXXX30-RJ Open ClosedREMOVE POWER FROM ELECTRICAL SYSTEM BEFORE INSTALLING FILTER.Mechanically mount filter.•Mount filter using mounting flange holes or optional DIN bracket listed below.•Filter should be mounted to allow maximum separation between input and output wiring.•Filter contains no position oriented components and can be mount-ed upside down or sideways.•Filter should be placed in electrical circuit so that it is the last device in circuit before equipment to be protected.1.2.1 DIN Rail Kits Mounting bracket and foot adaptable to DIN Rail systems DIN EN 50022, DIN EN 50035 and DIN EN 50045 are available through Eaton Order Center and can be ordered separately.• Eaton Cat# DINRAILKIT-30ACF•Eaton Innovative Technology Cat# DINRAILKIT-30ITCF1.3 WiringNOTICEAN INSULATED GROUNDING CONDUCTOR THAT IS IDENTICAL IN SIZE AND INSULATION MATERIAL AND THICKNESS TO THE GROUNDED AND UNGROUNDED CIRCUIT SUPPLY CONDUCTORS, EXCEPT THAT IT IS GREEN WITH OR WITHOUT ONE OR MORE YELLOW STRIPES, IS TO BE INSTALLED AS PART OF THE CIRCUIT THAT SUPPLIES THE FILTER. SEE TABLE 250-122 OF THE NATIONAL ELECTRIC CODE (NEC) REGARDING THE APPROPRIATE SIZE OF THE GROUNDING CONDUCTOR.THE GROUNDING CONDUCTOR IS TO BE GROUNDED TO EARTH AT THE SERVICE EQUIPMENT OR OTHER ACCEPTABLE BUILDING EARTH GROUND SUCH AS THE BUILDING FRAME IN THE CASE OF HIGH-RISE STEEL FRAME STRUCTURE.ANY ATTACHMENT-PLUG RECEPTACLES IN THE VICINITY OF THE FILTER ARE TO BE GROUNDING TYPE, AND THE GROUNDING CONDUCTORS SERV-ING THESE RECEPTACLES ARE TO BE CONNECTED TO EARTH GROUND AT THE SERVICE EQUIPMENT OR OTHER ACCEPTABLE BUILDING EARTH GROUND SUCH AS THE BUILDING FRAME IN THE CASE OF HIGH-RISE STEEL FRAME STRUCTURE.PRESSURE TERMINAL OR PRESSURE SPLICING CONNECTORS AND SOL-DERING LUGS USED IN THE INSTALLATION OF THE FILTER SHALL BEIDENTIFIED AS BEING SUITABLE FOR THE MATERIAL OF THE CONDUCTORS. CONDUCTORS OF DISSIMILAR METALS SHALL NOT BE INTERMIXED IN A TERMINAL OR SPLICING CONNECTOR WHERE PHYSICAL CONTACT OCCURS BETWEEN DISSIMILAR CONDUCTORS UNLESS THE DEVICE IS IDENTIFIED FOR THE PURPOSE AND CONDITIONS OF USE.CONDUCTORS SHOULD BE TWISTED TOGETHER TO REDUCE IMPEDANCE FACTOR. EXCESSIVE WIRE LENGTH AND SHARP BENDS DEGRADE FILTER PERFORMANCE; THEREFORE, AVOID EXCESSIVE WIRE LENGTH AND SHARP BENDS.3Instruction Manual IM01005027E Rev. 4Effective October 2018Installation Instructions for EatonSurge Protective Device XXCFXXX30-RJEATON Table of Maximum Suggested Operating UnitsModel Number Power ProtectionData ProtectionLine to Neutral (MCOV)Line to Ground (MCOV)Neutral to Ground* (MCOV)Maximum All Modes (@60 Hz) Amps Pins Peak Voltage L-L, L-G Max. Continuous Operating Current (mA)Max. Data Rate (Mbps)XXCF12030-RJ 150150150401-4, 2-31341001XXCF23030-RJ27527527540*Note: If Neutral to Ground voltage is greater than 5 VAC then a problem may exist in electrical system. Filter may be installed; however, a qualified person should be consulted to correct problem.1.3.1 Series Wiring Applications•Connect incoming system GROUND wire to terminal labeledGND on unprotected end (labeled as LINE ).•Connect load side GROUND wire to terminal labeled GND on protected end (labeled as EQUIP ).For AC Applications•Connect incoming system NEUTRAL wire to terminal labeled L2/NEU on unprotected end (labeled as LINE ).•Connect load side NEUTRAL wire to terminal labeled as L2/NEU on protected end (labeled as EQUIP ).•Connect incoming system HOT wire to terminal labeled L1 on unprotected end (labeled as LINE ).•Connect load side HOT wire to terminal labeled as L1 on protected end (labeled as EQUIP ).For DC Applications•Connect incoming system NEGATIVE wire to terminal labeled L2/NEU on unprotected end (labeled as LINE ).•Connect incoming system POSITIVE wire to terminal labeled L1 on unprotected end (labeled as LINE ).1.3.2 Parallel Wiring ApplicationsIMPORTANT:FILTER SHOULD BE LOCATED SO THAT THE SHORTEST POSSIBLE CON-DUCTOR LENGTH MAY BE USED. CONDUCTORS SHOULD BE TWISTED TOGETHER TO REDUCE IMPEDANCE FACTOR. EXCESSIVE WIRE LENGTH AND SHARP BENDS DEGRADE FILTER PERFORMANCE; THEREFORE, AVOID EXCESSIVE WIRE LENGTH AND SHARP BENDS.•Connect incoming system GROUND wire to terminal labeled GND on unprotected end (labeled as LINE ).For AC Applications•Connect incoming system NEUTRAL wire to terminal labeled L2/NEU on unprotected end (labeled as LINE ).•Connect incoming system HOT wire to terminal labeled L1 on unprotected end (labeled as LINE ).For DC Applications•Connect incoming system NEGATIVE wire to terminal labeled L2/NEU on unprotected end (labeled as LINE ).•Connect incoming system POSITIVE wire to terminal labeled L1 on unprotected end (labeled as LINE ).ote:N For grounded or isolated control transformer secondary, DO NOT CONNECT Ground terminal on either LINE or EQUIP side.1.3.3 Dry Contact WiringConnect ALARM leads to Normally Open (N/O) or Normally Closed (N/C) terminals as required.1.3.4 Telephone Line ProtectionConnecting telephone line to protection.•Assemble RJ-14 modular plugs to LINE and EQUIP telephone cables.•Connect circuit as follows: Circuit 1 = Pins 2 and 3; Circuit 2 = Pins 1 and 4.• Insert modular plugs into LINE and EQUIP modular jacks.•Assure that telephone circuits are operational.ote:N For ungrounded or isolated control transformer secondary, DO NOT CONNECT Ground terminal on either LINE or EQUIP side.1.4 Apply PowerApply power to system. Indicator light(s) should glow and alarm contacts should move to normal state. If the light(s) does not glow, remove power and contact supplier.Instruction Manual IM01005027E Rev. 4 Effective October 2018Installation Instructions for Eaton Surge Protective Device XXCFXXX30-RJEatonElectrical Sector1000 Eaton Boulevard Cleveland, OH 44122United States877-ETN-CARE (877-386-2273) © 2018 EatonAll Rights ReservedPrinted in USAPublication No. IM01005027E / TBG000473 October 2018Eaton is a registered trademark.All other trademarks are property of their respective owners.Agency ApprovalsXXCFXXX30-RJ UL1449 4th Edition, UL1283 7th Edition Type 2 SPDTerminal Connections Wire clamping terminals, 10-18 AWG (UL), 10-22 AWG (CSA)Torque 12 in-lbOperating Temperature-40F(-40C) to +140F(+60C)System voltagesDC48 - 149 Vdc, 150 - 300 VdcAC100 - 127 Vac, 128 - 230 VacCircuit Breaker40A, 240V/415V, 10kA Min. AIC Rating(Eaton P/N:FAZ-C40/1-NA-SP)Amps*30Input Power Frequency50/60 HzWarranty 5 Years, 10 Years if registered on /spd RoHS Compliant Yes* Amp rating is for series connection only. Parallel connection is not current dependent.Purchaser’s right under the warranty shall consist solely of requiring Eaton to repair, or at Eaton’s sole discretion, replace, free of charge, F.O.B. factory, and defective items received at said factory or failure to give any advice or recommendations by Eaton shall not constitute any warranty by or impose any liability upon Eaton. The foregoing constitutes the sole and exclusive liability of Eaton AND IS IN LIEU OF ANY AND ALL OTHER WARRANTIES EXPRESSED, IMPLIED OR STATUTORY AS TO THE MERCHANTABILITY, FITNESS FOR PURPOSE SOLD, DESCRIPTION, QUALITY, PRODUCTIVENESS OR ANY OTHER MATTER.In no event shall Eaton be liable for special or consequential dam-ages or for delay in performance of the warranty.This warranty does not apply if the prod1uct has been misused, abused, altered, tampered with, or used in applications other than specified on the nameplate. At the end of the warranty period, Eaton shall be under no further warranty obliga-tion expressed or implied.The product covered by this warranty certificate can only be repaired or replaced by the factory. For help on troubleshooting the Critical Protection Product, or for warranty information, call 1-800-809-2772, Option 4, sub-option 2. Repair or replacement units will be returned collect. If Eaton finds the return to be a manufacturer’s defect, the product will be returned prepaid.。

冰山嘉德全自动冷库控制器（V1.0）●控制和人机交互界面采用独立的分体式设计，便于灵活配置。

●3个控制风机运行的继电器输出。

●1个控制供液电磁阀的继电器输出。

●1个控制回气电磁阀的继电器输出。

●1个控制旁通电磁阀的继电器输出。

●1个控制热氨冲霜电磁阀的继电器输出。

●1个控制水冲霜电磁阀继电器输出。

●1个控制排水管加热的继电器输出。

●1路用于自动控制的压力传感器或湿度传感器（4~20mA）信号输入。

●2路或4路（回风、出风）温度传感器信号输入。

●1路风机电流信号输入（电流互感器二次输出电流0~5A，可选）。

●9个用于控制和安全保护的开关量输入。

●控制器供电电源：24Vdc。

●控制部分有两个完全独立的RS485通信端口。

COMA用于和显示器相连，COMB为今后扩展备用。

●显示部分也有两个完全独立的RS485通信端口。

一个用于和控制器相连，另一个用于和上位机通信，进行远程控制和管理。

●通信采用RS485 Modbus RTU协议。

运行手册概述全自动冷库控制器（以下简称控制器）作为冰山嘉德公司因应当今信息化大潮提出的透明冷库概念的一部分，具有网络通信和远程控制功能。

该控制器可根据冷库运行状况实行对冷库的相关设备进行自动控制。

除此之外，它可以经过通信网络将冷库运行的工作状态及相关数据送往上位机，以便进行远程监控。

本手册是控制器的使用及操作说明，在手册中详细的说明了控制器的使用场合、功能用途、外部接线方式、参数设定方法、具体操作步骤、按钮功能说明、故障信息解释等内容。

使用控制器前，用户务必先详细阅读并了解本手册的内容。

一、工作原理全自动冷库控制器是一种利用微处理器数字控制技术对冷库进行全自动控制的装置。

它实时地对回风及出风温度进行跟踪采样，对冷库冷设备的工作状态进行检测，并按照设定的控制参数和控制逻辑对冷库设备（风机、加热器、供液、冲霜）进行控制。

全自动冷库控制器由两部分组成：GC1719-LCS控制单元和CAM1-LCS操作显示单元。

管状电机使用说明书
一、产品简介
管状电机是一种特殊类型的电动机，其外形呈管状，具有较小
的体积和轻便的特点。

该电机采用先进的技术和制造工艺，具有高效、低噪音和可靠的性能。

广泛应用于家用电器、机械设备以及工
业自动化等领域。

本使用说明书旨在帮助用户了解管状电机的使用
方法和注意事项，确保您能够正确、安全地操作该产品。

二、安全注意事项
1. 在使用前，请先阅读本使用说明书，并按照指引正确使用管
状电机，以避免可能的危险和损坏。

2. 请确保在使用管状电机时周围环境清洁、干燥，并远离易燃、易爆物品。

3. 在使用过程中，请不要随便拆解或改变管状电机的结构，以
免引起电器故障或损坏。

4. 当电源线损坏时，务必由专业人员进行更换，不得私自修复
或使用。

5. 使用完毕后，请及时关闭电源并拔出插头，以防可能的电击和火灾。

三、使用方法
1. 使用环境准备:
（1）请确保工作环境符合产品要求，温度、湿度、气压等环境参数均在允许范围内。

（2）请确保电源电压与电机额定电压相匹配，不得超过额定电压。

2. 电源连接：
（1）将电源线的插头插入对应的插座中，并确保插头与插座连接牢固。

（2）检查电源线是否损坏或接触不良，若发现问题请及时更换或修复。

3. 开关操作：
（1）将电机的电源开关置于“关闭”位置。

剑杆织机电控箱（v1.0）操作使用说明书（无锡龙力机械）该剑杆织机电控箱，主要由PLC、传感器、继电器、按钮、信号灯等组成。

控制箱采用先进的高可靠性的OMRON PLC为控制核心，PLC是在工业中广泛采用的自动化电控产品，PLC强大的抗干扰能力，大大提高织机工作的稳定性和可靠性，为织机高效率提供了有力保障。

1、驱动能力储纬器45V AC 50W离合器24VDC,60VDC制动器24VDC,150VDC三色灯24VDC 3*5W电磁阀24VDC,220V AC2、工作环境电源电压AC 380V±5％50HZ环境温度-10---45°C环境湿度10----90％RH(不能凝结露水)1、把电控箱与织机连接好，拧上航空插头。

2、接上380V三相交流电源，注意保护接地线必须与电控箱外壳可靠连接。

1、主电机、电磁离合器、寻纬电机、储纬器线是否连接良好。

2、放纬电磁铁、抬纬器的电源线是否接好。

3、三色灯、纬纱传感器、接近开关接插件是否连接良好。

4、各按钮、钮子开关是否良好，位置是否正确。

1、断纬停车：黄色信号灯亮，织机定位停车，自动倒纬（倒纬数由程式定）。

2、断经停车：红色信号灯亮，织机定位停车。

（是否倒纬有程式定）3、正常停车：织机定位停，自动倒纬数与断经停车相同。

4、寻纬：分自动寻纬与手动寻纬，寻纬电机具有延时保护。

程式设定：按住停车按钮，拨动程式开关即可选择所需寻纬程式。

程式查看：拨动程式开关并保持，红灯闪烁次数即为所选程式。

5、接近开关：当接近开关安装不到位或者损坏，织机将自动停车，同时黄灯红灯闪烁。

1、合上电箱空气开关。

2、启动主电机，绿色信号灯亮，检查电机转向（顺时针）。

3、打开多臂罩壳，装入纹板纸。

4、按动点车按钮数下，查看织机有无异常。

5、合上电箱内试车钮子开关，启动织机。

6、关掉试车钮子开关，检查停车位置，调试停车位置，调整定位停车接近开关，使织机停在310-320°左右。
