Dominion® KX II特色优点硬件特色下一代硬件架构高性能的下一代视频硬件Dominion KX II 是真正具有高级硬件和软件功能的下一代切换器。
创新设计的 KVM-over-IP 其性能、可靠性、可用性、兼容性和安全性都达到了新水平。
Dominion KX II 的 KVM-over-IP 引擎使用 Raritan 的下一代技术为用户提供虚拟机架端性能。
下一代硬件的特性包括超高速屏幕刷新、1600x1200远程分辨率、先进的色彩校准和基于服务器的视频优化。
具有故障切换功能的双电源为提升可靠性和冗余，所有 Dominion KX II 型号都配备了双交流输入、双电源和自动故障切换以支持企业数据中心中使用的冗余电源配器。
如果电源发生故障，客户将通过前面板 LED、SNMP 陷阱、日志消息或者通过管理器得到通知。
为键盘、鼠标和 USB 媒体提供四个 USB 端口Dominion KX II 为本地键盘、鼠标和 USB 媒体配备了四个 USB 2.0 端口，其中三个位于后面板，一个位于前面板。
具有故障切换功能的双千兆以太网端口通过冗余的双千兆以太网端口提供高可用性。
如果一个以太网切换器或接口卡发生故障，Dominion KX II 将自动切换到其它端口继续操作。
多种硬件型号多种硬件型号使一个、两个或四个远程用户能够同时访问 16、32 或64* 台服务器。
Raritan 是首家也是唯一一家提供 64 端口数字 KVM 切换器的供应商。
1U 或 2U 外形规格Dominion KX464 是 2U 解决方案。
其它 KX II 型号只有 1U 的高度。
Dominion KX II 能够极其有效地节省机架空间。
Cat5 线缆Dominion KX II 采用标准、经济的 Cat5 (UTP) 线缆互连各台服务器。
服务器与 Dominion KX II 设备的距离最远可达 45 米。
多平台计算机接口模块 (CIM) Dominion KX II 支持通过多平台 CIM 连接到 PS/2®、USB 和 Sun 服务器。
VIAVI SolutionsData Sheet VIAVIThird Generation Multiple Application Platform (MAP-300)The VIAVI Solutions Multiple Application Platform (MAP-300) is an optical test and measurement platform optimized for compact cost-effective development and manufacturing of optical communications technology.Key Featuresy Available in rackmount, reverse-rackmount and benchtop mainframe configurationsy HTML-based graphical user interface gives consistent user experience both locally and remotelyy Field-replaceable controller includes an integrated 3.5-inch LCD touchscreen for network and system status y Support for USB 3.0 port, 15.6-inch external monitor, and ethernety Optional GPIB, additional ethernet ports and additional USB and trigger modulesy SCPI logical interface for automation programming, with remote programming supported via TCP/IP (LXI) over ethernet, GPIB and direct socket y Multi-user capabilityy Backward compatible with MAP2xx series cassettes and remote-control support y Hot swappable modulesy Supports the MAP-Series asset management tool MAPccApplicationsy General purpose fiber-optic lab use y Manufacturing test automation y DWDM/WSS test y Connectivity IL/RLy Polarization scrambling and OSNRCompliancey MAP Series cassettes include amplifier and sourcecassettes classified as either Class 3B or Class 1M Laser products. While operating in a MAP Series mainframe, cassettes meet the requirements of the IEC 60825-1 standard and comply with 21 CFR 1040.10 and 1040.11, except for deviations pursuant to Laser Notice 50, dated June 24, 2007.From the original Multiple Application Platform (MAP) system released in 2001 as part of JDSU to the new third generation MAP-300 Series, the MAP system is the heart of the VIAVI optical test solutions for labs and manufacturing. With unmatched scalability , users can be assured that our solutions will meet their current and future needs. MAP-300 provides the foundation to our entire portfolio, enabling scalability and efficiency for manufacturing optical network elements, modules and components.Customer Focused InnovationThe new MAP-300 builds upon the proven strengths of the MAP System while adding innovation where it matters most for our customers. Backwards compatible support for the installed automation base, combined with several new features, including an HTML-based GUI for multi-user environments, gives our customers the capabilities they need to achieve their goals. We can’t wait to see what you will accomplish with the new MAP-300!MAP-300 ConfigurationsThe MAP-300 mainframe, like its predecessor, is offered in both benchtop and rackmount versions as either threeor eight slot mainframe configurations. The eight-slot can also provided in a reverse rack-mount configuration. MAP-380 Eight-Slot MainframesEach MAP-380 mainframe consists of a 3U chassis that can house up to eight cassettes, plus a field-replaceable controller. The MAP-380 mainframe is available in rackmount, reverse-rackmount, and benchtopconfigurations.Figure 2 - MAP-380 rackmount and benchtop mainframes, rear viewFigure 1 - MAP-380 rackmount and benchtop mainframes front viewFigure 3 - MAP-380 reverse rackmount mainframes, front and rear viewMAP-330 Three-Slot MainframesEach MAP-330 mainframe consists of a 3U chassis that can house up to three cassettes, plus a field-replaceable controller. The rackmount versions are half 19” rack wide, so two units can be mounted side-by-side. An optional touch screen can be docked on the mainframe of a benchtop three-slot chassis for an easy portable, self-contained system.Figure 4 - MAP-330 benchtop mainframe, front and rear viewFigure 5 - MAP-330 benchtop mainframe with 15.6-inch touchscreen docked, front viewFigure 6 - MAP-330 3U half 19-inch rackmount mainframe, front viewSimple, Intuitive Graphical ControllerThe MAP-300 chassis includes a 3.5-inch touch screen that supports intuitive swipes for easy navigation. This local touchscreen provides access to connection and configuration settings.Users can access the MAP-300 GUI from a mainframe locally or remotely via Ethernet. The MAP-300 GUI allows multi-user access via a supported web browser by entering the IP address acquired from the controller in the location field of the web browser. The slot configuration of a mainframe is represented by widgets (one per slot) on the MAP-300 dashboard. When a slot is populated, the widget representing that slot identifies the cassette and provides quick access to the main device settings. The user can change the size of the widget to see more detail on specific cassettes. A detailed view of a cassette is available, whilst still having a complete view of all other slots.The settings panel gives you access to network and system settings, as well as remote chassis and license settings if available. The MAP-300 can be rebooted or placed in standby mode using through the GUI or local touchscreen.Figure 7 - MAP-300 local touchscreenFigure 8 - MAP-380 Dashboard GUI example.Control InterfacesAs a full-fledged member of the MAP family , all remote interfaces can interoperate with the three-slot and eight-slot versions. It includes optimized Interchangeable Virtual Instrument (IVI) drivers for ease of use with popular application-development environments, such as LabVIEW, Visual C++, Visual Basic, and LabWindows™, to provide full control of the modules and drop-in instrument programming capabilities. These capabilities let test programmers focus on test-level functions and sequences rather than the details required to communicate with the specific modules in the MAP system. The IVI drivers also include a simulation mode that lets developers capture system configurations so they can perform most of their development offline, freeing hardware for other purposes. These features make test automation development and debugging fast and easy. All MAP series module and platform commands conform to the Standard Commands for Programmable Instruments (SCPI) command language.Extensive Input/Output InterfacesAll mainframe configurations include: y Ethernet port for remote communication.y 4 USB host ports for installing peripheral devices, including USB drives, a mouse, and a keyboard. y One USB host port for the optional touchscreen.y Integrated 3.5-inch LCD touchscreen for network and system status information.y All mainframes can support up to two field-installable additional accessory modules for control and triggering. Available modules include (1) IEEE-488 (GPIB), (2) dual trigger LXI-compliant LDVS driver ports, and (3) three USB 3.0 ports and one Ethernet interface.Users who are comfortable with the General Purpose Interface Bus (GPIB)remote interface can order the field-installable option at any time.Automation Remote Use 1(Optional)Automation Remote Use 2(Optional)Automation Remote Use 3(Optional)MAP Control Center (MAPcc)VIAVI now offers the MAP Control Center (MAPcc), an asset management tool for MAP mainframes and cassettes. The MAPcc simplifies network management via a single screen that lists a full inventory of all your assets, enabling you to explore internal and external mainframes as well as the cassettes present in those mainframes. From the list of available mainframes, you can retrieve IP addresses, firmware versions and serial numbers, and you can search for a specific type of cassette, fiber or connector. The MAPcc lets you upgrade multiple mainframes at the same time using the upgrade center, as well as retrieve log files.MAP Chassis Selection GuideVIAVI offers a variation of chassis, the table below summaries their key attributes of each chassis and why it would be ideal for you.SpecificationsMainframe SpecificationsThe table below provides specifications for MAP-300 mainframes. For MAP Series cassettes, refer to the user guide for each cassette.Mainframe ChassisCapacity (Single-width cassettes) 3 cassettes8 cassettes Rackmount Kit OptionalBenchtop Kit OptionalController (MAP-300CLD-B)Operating System LinuxLocal T ouchscreen 3.5-in touchscreen for network/system status controls, 320 x 240 resolution Power Supply100 to 240 V AC, 50/60 Hz, Auto-switchingPower Consumption450 VA MAX450 VA MAXField Replaceable Y esBays for Plug-in Modules2Native Ports/InterfacesUSB 3.0 Host 1 frontUSB 3.0 (Mouse, Keyboard, etc.) 4 rearEthernet 10/100/1000BASE-T 1 rearMonitor port 1 rearOptical Plug-in Modules GPIB, USB/LAN Expansion, TriggerAutomationDriver Type IVI compliantStandard/Protocol LXI, VXI-11, SCPIDriver Compatibility LabView TM, LabWindows TM, Microsoft® Visual C++,Microsoft® Visual Basic®Accessibility Multiuser sharing supportWeb GUI Compatibility Google Chrome, Mozilla Firefox or Microsoft EdgeLaser Interlock (See the MAP Series Safety and Compliance Reference Guide, 22112369-325, for more information.) Local Interlock Software controlledRemote Interlock2-pin terminal block at rear controllerMechanicalDimensions of rackmount (W x H x D)24.61 x 13.26 x 38.63 cm(9.6 x 5.2 x 15.2 in)48.26 x 13.26 x 38.63 cm(19 x 5.2 x 15.2 in)Dimensions of benchmount (W x H x D) 26.43 x 15.49 x 44.27 cm(10.4 x 6.1 x 17.5 in)46.94 x 15.49 x 44.27 cm(18.5 x 6.1 x 17.5 in)WeightBenchtop Mainframe10 kg (22 lb)12.6 kg (27.7 lb) Rackmount Mainframe7.4 kg (16.3 lb) 10.8 kg (23.8 lb) EnvironmentOperating T emperature0 to 50°CStorage T emperature-30 to 60°CRelative Humidity5% to 85% non-condensingOptional 15.6-inch Touchscreen (MAP-300AKD) SpecificationsDock to Benchtop MainframeMAP-330SupportedMAP-380Not SupportedPower/Interface to MainframeMAP-330USB cable or docking connectorMAP-380USB cableWeight 2.7 kg (5.95 lb)Ordering InformationFor more information on this or other products and their availability, please contact your local VIAVI account manager or VIAVI directly at 1-844-GO-VIAVI (1-844-468-4284) or to reach the VIAVI office nearest you, visit /contacts.MAP-300 MainframesMAP-300 Accessories and Replacement Parts11 Third Generation Multiple Application Platform (MAP-300)LightDirect and LightTest Modular Families for the MAP SystemMAP mainframes are the foundation to our entire portfolio of functional modules, enabling scalability and efficiency for manufacturing optical network elements and modules. The MAP-300 series replaces the highly successful MAP-200. It is compatible with all our current cassettes and legacy cassette (all -C1, -C2 and -B1 modules). The cassette modules fall into two different families, the LightT est turn-key solutions and LightDirect configurable solutions to meet each customer’s exact needs.The LightDirect family includes a wide range of foundational optical test modules that are used in simple bench test applications, or combined in larger, multi-modules customer driven automated test systems. They are easy-to-control, single-functionality modules.© 2020 VIAVI Solutions Inc.Product specifications and descriptions in this document are subject to change without notice.map300-ds-lab-nse-ae 30190857 904 0920Contact Us +1 844 GO VIAVI (+1 844 468 4284)To reach the VIAVI office nearest you, visit /contacts.VIAVI SolutionsThe LightT est family are application specific, integrated test solutions that leverage the power of the MAP Series Super-Application or PC based software. Built with specialized MAP modules or assemblies of LightDirect modules, LightT est solutions are typically used in bench test applications but can also be combined in larger, multi-modules customer driven automated test systems.Passive Connector Test SolutionsThe VIAVI Solutions passive component/connector test solution (PCT) consists of a powerful family of modules, software, and peripherals for testing IL, RL, physical length, and polarity of optical connectivity products. Leveraging the modularity and connectivity of the VIAVI MAP platforms.Single Fiber Insertion Loss and Return Loss Test SystemThe PCT-rm is a MAP-220 based Single mode Insertion Loss (IL) and Return Loss (RL) test meter for single fiber connector applications. Part of the MAP Series PCT solution family , it features fully EF-compliant multimode Insertion Loss test meters with connector adapters that can be configured for all connectivity applications to ensure maximized productivity.Swept Wavelength SystemmSWS-C1 are swept wavelength test solutions for manufacturing and new device development of passive DWDM devices, ROADMs & Circuit Packs. Provides full characterization of wavelength.Optical Component Environmental Test SystemsAt the core of OCETS Plus is a pair of custom-grade programmable switches (1xN configuration). OCETS switches are specified to higher levels of IL repeatability and background RL than analogue-grade switches.。
KVM管理系统综述1.1概述KVM是键盘（Keyboard）、显示器(Video)、鼠标(Mouse)的缩写。
KVM技术的核心思想是：通过恰当的键盘、鼠标和显示器的配置，实现系统和网络的高可管理性，提高管理人员的工作效率、节约机房面积，降低网络服务器系统的总体拥有成本（TCO）。
利用KVM主机切换系统，即用一套或数套KVM在多个不同操作系统的多台主机之间切换，就可以实现使用一套外设去访问和操作一台以上主机的功能。
KVM 主机切换系统除了KVM配件外，还包括切换设备和特制的各种联结电缆。
使用KVM主机切换系统前后的物理结构变化图如图所示：KVM主机切换系统的物理结构如图所示1.2方案拓扑图KVM集中控管拓扑图 (见下图)1.3方案设计在机房内共选用2台32口切换主机，放置在弱电列头柜内。
系统最大可以支持8个用户同时对机房中64台服务器及串口设备进行控制和操作。
每台切换主机还可以提供1个本地用户，通过放置在机柜内的键盘、鼠标、显示器在本地进行管理。
解决方案优点：远程用户可以在任意地点通过IP网络访问机房内设备（管理人员统一对用户划分管理权限），支持MODEM拨号的远程访问控制。
机房本地预留个本地控制端口，工作人员可以在控制室内进行管理。
通过集中远程管理，真正实现无人机房解决方案。
扩展简洁便利，只需要添加相应的数字切换器即可增加远程IP管理员所能控制的设备数量。
1.4产品优势Dominion KX系列产品是目前RARITAN公司数字KVM产品线中的最高端产品，Dominion KX基本上集成了RARITAN公司近20年KVM开发经验，并融会了许多客户的意见，所以在产品的许多方面做到了创新。
●高性能，高集成1．每台Dominion KX 可以连接16/32台服务器，大大提高系统的集成度。
2．服务器与控制操作台（用户）之间不受地域限制，传输通过TCP/IP 协议完成。
Dominion KX对数据中心服务器及其他设备提供独立的管理通道。
KVM切换器五大品牌
第一名：A VOCENT（美国）
全球著名KVM品牌，其高端数字KVM在全球占有率最高，主要客户是一些世界大型企业，在国内主要是政府部门，但价格高，在国内主要是代理方式销售，现已被爱默生电气收购。
第二名：Raritan(美国)
全球著名KVM品牌，是A VOCENT全球范围的主要竞争对手，其独创的虚拟媒体技术是其主要的销售亮点和技术竞争手段。
第三名：鸿通科技（国内）
鸿通科技是国内高端数字KVM唯一厂家，对受控设备进行实时屏幕录像，虚拟媒体功能和ES5000集中管理平台是其最大的技术优势。
该企业是本土最近几年崛起的一匹黑马，技术上和美国的两家企业不相上下，打破了以前两家在国内的垄断地位，性价比很高。
第四名：Aten(台湾)
较早进入KVM市场的厂家，主要销售中低端模拟KVM产品，其国内由腾达科技代理销售。
近年来由于国内本土企业的发展，其产品性价比较低，故逐渐被国内其它品牌挤压取代，其国内市场占有率和品牌价值逐年下降。
第五名：Rextron(台湾)
较早进入KVM的另一台湾企业，其产品性能和外观都还不错，但其由于国内主要合作代理商推广不利及自身定位不清，现在品牌知名度已大大下降，在加上国内本土企业的挤压，其市场占有率也逐年下降。
1、DKX2系列产品1.1、DKX2系列架构DKX2由两大组件组成：数字式KVM切换器与计算机接口模块(CIM)。
DKX2是一款安全的企业级数字式切换器，可以让2名、3名、5名或10名使用者同时进行BIOS层级的控制，最多可以让一台KVM操作台控制64台服务器及其它IT设备以及给目标服务器作虚拟映射，远程安装软件或补丁。
它将服务器的控制权安全地放在通过验证的使用者手中，无论他们是在公司外、公司内，还是在机架旁，当本地使用者对切换器进行访问时，都不会阻塞远程使用者的访问。
DKX2可以通过各种常用的网络浏览器进行访问，可以使用大部份主要的操作系统。
DKX2是一款业内唯一的双电源、双千兆以太网口高冗余的即插即用、1U、2U的设备，完全可以自给自足，几分钟内即可安装完毕。
它结合了坚固的安全性、灵活性、整合了远程电源控制，以及目前最高品质的视频（远程与本地均支持1600X1200的分辨率）。
调制解调器能确保在无法使用网络或网际网络之时，仍然能够对重要服务器进行紧急访问。
当与力登的CommandCenter® Secure Gateway整合时，DKX2则提供单一浏览的全企业控制功能。
CIM内置发送器，一端直接连接每台电脑，另一端通过五类双绞线输出到DKX2系列切换器服务器端口。
并且内置检测程序，可以自动检测所连接服务器的信号类型，其信号仿真技术可以模拟服务器正常运行所需要的键盘、鼠标信号。
当DKX2设备意外掉电或5类双绞线脱落的情况下，此项技术确保服务器仍然正常运行，从而维护了服务器运行的稳定性和数据的安全性。
CIM有多种规格可选，以适应不同种类的机型，实现多平台兼容操作。
KX2配合D2CIM-VUSB模块还有智能鼠标同步效果，无需改变服务器的任何鼠标属性，也可做到远程鼠标与本地鼠标的同步。
KX连接拓扑：1.2、DKX2技术特点DKX2系列产品是目前RARITAN公司数字KVM产品线中的最高端产品，DKX2基本上集成了RARITAN公司20余年KVM开发经验，并融会了许多客户的意见，所以在产品的许多方面做到了创新。
