For more Informationplease call1-800-Belden1General Description:22 AWG stranded (7x30) TC conductors, polypropylene insulation, twisted pair, overall Beldfoil shield(100% coverage), 22 AWG stranded TC drain wire, PVC jacket.Physical Characteristics (Overall)ConductorAWG:# Pairs AWG Stranding Conductor Material1227x30TC - Tinned CopperTotal Number of Conductors:2InsulationInsulation Material:Insulation Material Wall Thickness (mm)PP - Polypropylene0.2032Outer ShieldOuter Shield Material:Outer Shield Trade Name Type Outer Shield Material Coverage (%)Beldfoil®Tape Aluminum Foil-Polyester Tape100Outer Shield Drain Wire AWG:AWG Stranding Drain Wire Conductor Material227x30TC - Tinned CopperOuter JacketOuter Jacket Material:Outer Jacket Material Nom. Wall Thickness (mm)PVC - Polyvinyl Chloride0.508Overall CableOverall Nominal Diameter: 3.429 mmPairPair Color Code Chart:Number Color1Black & RedMechanical Characteristics (Overall)Operating Temperature Range:-20°C To +75°CUL Temperature Rating:60°CBulk Cable Weight:20.835 Kg/KmMax. Recommended Pulling Tension:120.101 NMin. Bend Radius/Minor Axis:38.100 mmApplicable Specifications and Agency Compliance (Overall)Applicable Standards & Environmental ProgramsNEC/(UL) Specification:CMRinformation, and belief at the date of its publication. The information provided in this Product Disclosure is designed only as a general guide for the safe handling, storage, and any other operation of the product itself or the one that it becomes a part of. This Product Disclosure is not to be considered a warranty or quality specification. Regulatory information is for guidance purposes only. Product users are responsible for determining the applicability of legislation and regulations based on their individual usage of the product.Belden declares this product to be in compliance with EU LVD (Low Voltage Directive 2014/35/EU).。
1.2.2 YJ53241YJ53241六类四对非屏蔽双绞线(LSNH)说明：YJ53241是一款符合ANSI/TIA/和ISO/IEC 11801六类标准所有要求、易于安装的低烟无卤线缆。
四对UTP（非屏蔽双绞线）电缆，包紧的护套外部印有长度标志。
线缆内部有十字线对隔离芯，内有剥线绳。
可以支持6类标准上的所有应用。
应用：支持当前6类应用，比如千兆位以太网、100 Base TX、100 Base VG AnyLan以及155 ATM、622 ATM等应用。
特点和标准高灵活性设计，易于电缆安装与穿线适用于BELDEN系统质量保证每芯线都带有彩色护套，线对中的两根线颜色互配，方便安装适用标准：NEC/（UL）规范：UL444ISO/IEC 11801 2nd edition (2002)ANSI/TIA/EIA (2002) Category 6NEMA Category 6,燃烧测试：UL燃烧测试：UL1581，VW-1IEC燃烧测试：IEC60332-1，IEC 61034，IEC 60754技术规格结构：非屏蔽4 对双绞线导体：23AWG 实心铜线，导体直径：0.572mm ±绝缘层：聚烯烃护皮：LSNH-低烟无卤外直径： 6.5 mm电气特性：（20摄氏度）额定互感电容（1kHz）nF/100 m最大直流电阻@20°C Ω/100 m传播延迟偏差(100 MHz) 45 ns/100m特性阻抗（4-100 MHz*) 100 ± 15Ω最大线对不平衡对地电容330pF/100mNVP 70%最大传播时延@100MHz 538ns/100m直流电阻不平衡最大@20°C 5%最大操作电压80V RMS*: 根据ISO/IEC 11801 category 6 线缆要求, 2002 年9 月.机械特性：温度范围-操作-20°C - +75°C最小弯曲半径-安装32.5 mm最大可承受拉力(建议) 150 N订货信息:型号描述长度(ft. /m) YJ53241 4 PR#23 AWG LSNH 1000/305六类接插件2.2.1 GigaFlex PS6+ 六类模块GigaFlex PS6+ 六类模块说明GigaFlex PS6+模块是模块化连接产品线中的一种新压接式UTP连接器，完全满足ISO/IEC 11801:2002 的相关要求。
