Original Creation Date: 12/02/96Last Update Date: 12/20/96Last Major Revision Date: 12/02/96MNLM103-3.0-H REV 0A0MILITARY DATA SHEETREFERENCE DIODEGeneral DescriptionThe LM103 is a two-terminal monolithic reference diode electrically equivalent to a breakdown diode. The device makes use of the reverse punch-through of double-diffused transistors, combined with active circuitry, to produce a breakdown characteristic which is ten times sharper than single-junction zener diodes at low voltages. Breakdown voltages from 3.0V to 3.9V are available; and, although the design is optimized foroperation between 100uA and 1mA, it is completely specified from 10uA to 10mA. Noteworthy features of the device are:- Exceptionally sharp breakdown- Low dynamic impedance from 10uA to 10mA- Planar, passivated junctions for stable operation - Low capacitanceThe LM103, is useful in a wide range of circuit applications from level shifting to simple voltage regulation. It can also be employed with operational amplifiers in producingbreakpoints to generate nonlinear transfer functions. Finally, its unique characteristics recommend it as a reference element in low voltage power supplies with input voltages down to 4V.NS Part NumbersLM103H-3.0-SMD*LM103H-3.0/883Industry Part NumberLM103Prime DieLM103Controlling Document7702806XA*ProcessingMIL-STD-883, Method 5004Quality Conformance InspectionMIL-STD-883, Method 5005Subgrp Description Temp ( C)o 1Static tests at +252Static tests at +1253Static tests at -554Dynamic tests at +255Dynamic tests at +1256Dynamic tests at -557Functional tests at +258A Functional tests at +1258B Functional tests at -559Switching tests at +2510Switching tests at +12511Switching tests at-55MILITARY DATA SHEET MNLM103-3.0-H REV 0A0(Absolute Maximum Ratings)(Note 1)Power Dissipation(Note 2)250mWReverse Current20mAForward Current100mAOperating Temperature Range-55 C to 125 CStorage Temperature Range-65 C to 150 CMaximum Junction Temperature150 CLead Temperature(Soldering, 60 seconds)300 CThermal ResistanceThetaJA292 C/WMetal Can Pkg (Still Air @ 0.5W)(500LF/Min Air flow @ 0.5W)147 C/WThetaJCMetal Can Pkg58 C/WESD Tolerance(Note 3)TBDNote 1:Absolute Maximum Ratings indicate limits beyond which damage to the device may occur.Operating Ratings indicate conditions for which the device is functional, but do notguarantee specific performance limits. For guaranteed specifications and testconditions, see the Electrical Characteristics. The guaranteed specification applyonly for the test conditions listed. Some pwerformance characteristics may degradewhen the device is not operated under the listed test conditions.Note 2:The maximum power dissipation must be derated at elevated temperatures and is dictated by Tjmax (maximum junction temperature), ThetaJA (package junction toambient thermal resistance), and TA (ambient temperature). The maximum allowablepower dissipation at any temperature is Pdmax = (Tjmax - TA)/ThetaJA or the numbergiven in the Absolute Maximum Ratings, whichever is lower.Note 3:Human body model, 1.5K Ohms in series with 100pF.MNLM103-3.0-H REV 0A0MILITARY DATA SHEETElectrical CharacteristicsDC PARAMETERS:(The following conditions apply to all the following parameters, unless otherwise specified.)DC:Tolerance = +10%.SYMBOL PARAMETER CONDITIONS NOTES PIN-NAME MIN MAX UNITSUB-GROUPSVz Zener Voltage Ir = 400uA2, 3 2.70 3.30V130.87V2318V3Ir = 1mA2, 3 2.70 3.30V130.87V2318V3Ir = 2mA2, 3 2.70 3.30V130.87V2318V3Ir = 3mA2, 3 2.70 3.30V130.87V2318V3Delta Vz/ Delta Ir Zener VoltageChange10uA < Ir < 100uA120mV110uA < Ir < 100uA200mV2, 3100uA < Ir < 1mA50mV1100uA < Ir < 1mA70mV2100uA < Ir < 1mA60mV31mA < Ir < 5mA150mV11mA < Ir < 5mA200mV2, 3Ir Reverse LeakageCurrent Vr = Vz -200mV (test uses Vz readingfrom Ir = 400uA subgroup 1)5uA150uA2, 3Vf Forward VoltageDrop If = 5mA-0.7-1V1-0.5-1.5V2, 3Rr Reverse DynamicImpedanceIr = 3mA +5%25Ohms1Delta Vz/ Delta t TemperatureCoefficient ofZener Voltage100uA < Ir < 1mA, -55 C < TA < 125 C1-8mV/C1Vn Peak-to-PeakBroadband NoiseVoltage1Hz < f < 100KHz, Ir = 1mA11000uV1Rr Rev. DynamicImpedanceIr = 0.3mA160Ohms1MNLM103-3.0-H REV 0A0MILITARY DATA SHEETElectrical CharacteristicsDC PARAMETERS:(Continued)(The following conditions apply to all the following parameters, unless otherwise specified.)DC:Tolerance = +10%.SYMBOL PARAMETER CONDITIONS NOTES PIN-NAME MIN MAX UNITSUB-GROUPSDelta Vz / Delta Ir Zener VoltageChange10uA < Ir < 1mA1260mV1, 2,3DC PARAMETERS: DRIFT VALUES(The following conditions apply to all the following parameters, unless otherwise specified.)DC:Tolerance = +10%. "Deltas not required on B-Level product. Deltas required for S-Level product ONLY as specified on Internal Processing Instructions (IPI)."Vz Zener Voltage Ir = 400uA-0.070.07V1Ir = 1mA-0.070.07V1Ir = 2mA-0.070.07V1Ir = 3mA-0.070.07V1 Note 1:Guaranteed parameter not tested.Note 2:Tests 1 to 4 are set on the Teradyne based on the nominal Zener Voltage of thedevices being tested. Limits are as shown. Acceptable Deltas would be as shown.Tolerance is 10%. Nominal Zener Voltage is last two digits of device name.Note 3:Test 1 to 4 at extreme temperatures can be datalogged (for purposes of computingtemp-coefficient) but have no set limits. The limits listed in the Min and Maxcolumns are those tested in the programs (for all Zener Voltages).。

LM50SOT-23Single-Supply Centigrade Temperature SensorGeneral DescriptionThe LM50is a precision integrated-circuit temperature sen-sor that can sense a −40˚C to +125˚C temperature range us-ing a single positive supply.The LM50’s output voltage is lin-early proportional to Celsius (Centigrade)temperature (+10mV/˚C)and has a DC offset of +500mV.The offset al-lows reading negative temperatures without the need for a negative supply.The ideal output voltage of the LM50ranges from +100mV to +1.75V for a −40˚C to +125˚C temperature range.The LM50does not require any external calibration or trimming to provide accuracies of ±3˚C at room temperature and ±4˚C over the full −40˚C to +125˚C temperature range.Trimming and calibration of the LM50at the wafer level as-sure low cost and high accuracy.The LM50’s linear output,+500mV offset,and factory calibration simplify circuitry re-quired in a single supply environment where reading nega-tive temperatures is required.Because the LM50’s quiescent current is less than 130µA,self-heating is limited to a very low 0.2˚C in still air.Applicationsn Computers n Disk Drivesn Battery Management n Automotive n FAX Machines n Printersn Portable Medical Instruments n HVACnPower Supply ModulesFeaturesn Calibrated directly in degree Celsius (Centigrade)n Linear +10.0mV/˚C scale factor n ±2˚C accuracy guaranteed at +25˚C n Specified for full −40˚to +125˚C range n Suitable for remote applicationsn Low cost due to wafer-level trimming n Operates from 4.5V to 10V n Less than 130µA current drainn Low self-heating,less than 0.2˚C in still air nNonlinearity less than 0.8˚C over tempConnection DiagramOrder SOT-23Supplied As Number Device MarkingLM50BIM3T5B 1000Units on Tape and ReelLM50CIM3T5C 1000Units on Tape and ReelLM50BIM3X T5B 3000Units on Tape and ReelLM50CIM3XT5C3000Units on Tape and ReelTypical ApplicationSOT-23DS012030-1Top ViewSee NS Package Number MA03BDS012030-3FIGURE 1.Full-Range Centigrade Temperature Sensor (−40˚C to +125˚C)July 1999LM50SOT-23Single-Supply Centigrade Temperature Sensor©1999National Semiconductor Corporation Absolute Maximum Ratings(Note1)Supply Voltage+12V to−0.2V Output Voltage(+V S+0.6V)to−1.0V Output Current10mA Storage Temperature−65˚C to+150˚C Lead Temperature:SOT Package(Note2):Vapor Phase(60seconds)215˚C Infrared(15seconds)220˚C T JMAX,MaximumJunction Temperature150˚C ESD Susceptibility(Note3):Human Body ModelMachine Model2000V250V Operating Ratings(Note1)Specified Temperature Range:T MIN to T MAX LM50C−40˚C to+125˚C LM50B−25˚C to+100˚C Operating Temperature Range−40˚C to+150˚C θJA(Note4)450˚C/W Supply Voltage Range(+V S)+4.5V to+10VElectrical CharacteristicsUnless otherwise noted,these specifications apply for V S=+5V DC and I LOAD=+0.5µA,in the circuit of Figure1.Boldface limits apply for the specified T A=T J=T MIN to T MAX;all other limits T A=T J=+25˚C,unless otherwise noted.Parameter Conditions LM50B LM50C Units(Limit)Typical Limit Typical Limit(Note5)(Note5)Accuracy T A=+25˚C±2.0±3.0˚C(max) (Note6)T A=T MAX±3.0±4.0˚C(max)T A=T MIN+3.0,−3.5±4.0˚C(max) Nonlinearity(Note7)±0.8±0.8˚C(max) Sensor Gain+9.7+9.7mV/˚C(min) (Average Slope)+10.3+10.3mV/˚C(max) Output Resistance2000400020004000Ω(max) Line Regulation+4.5V≤V S≤+10V±0.8±0.8mV/V(max) (Note8)±1.2±1.2mV/V(max) Quiescent Current+4.5V≤V S≤+10V130130µA(max) (Note9)180180µA(max) Change of Quiescent+4.5V≤V S≤+10V 2.0 2.0µA(max) Current(Note9)Temperature Coefficient of+1.0+2.0µA/˚C Quiescent CurrentLong Term Stability(Note10)T J=125˚C,for±0.08±0.08˚C1000hoursNote1:Absolute Maximum Ratings indicate limits beyond which damage to the device may occur.DC and AC electrical specifications do not apply when operating the device beyond its rated operating conditions.Note2:See AN-450“Surface Mounting Methods and Their Effect on Product Reliability”or the section titled“Surface Mount”found in a current National Semicon-ductor Linear Data Book for other methods of soldering surface mount devices.Note3:Human body model,100pF discharged through a1.5kΩresistor.Machine model,200pF discharged directly into each pin.Note4:Thermal resistance of the SOT-23package is specified without a heat sink,junction to ambient.Note5:Limits are guaranteed to National’s AOQL(Average Outgoing Quality Level).Note6:Accuracy is defined as the error between the output voltage and10mv/˚C times the device’s case temperature plus500mV,at specified conditions of volt-age,current,and temperature(expressed in˚C).Note7:Nonlinearity is defined as the deviation of the output-voltage-versus-temperature curve from the best-fit straight line,over the device’s rated temperature range.Note8:Regulation is measured at constant junction temperature,using pulse testing with a low duty cycle.Changes in output due to heating effects can be com-puted by multiplying the internal dissipation by the thermal resistance.Note9:Quiescent current is defined in the circuit of Figure1.Note10:For best long-term stability,any precision circuit will give best results if the unit is aged at a warm temperature,and/or temperature cycled for at least46 hours before long-term life test begins.This is especially true when a small(Surface-Mount)part is wave-soldered;allow time for stress relaxation to occur.The ma-jority of the drift will occur in the first1000hours at elevated temperatures.The drift after1000hours will not continue at the first1000hour rate.2Typical Performance Characteristics To generate these curves the LM50was mounted to a printed circuit board as shown in Figure2.Thermal ResistanceJunction to AirDS012030-21Thermal Time ConstantDS012030-22Thermal Response in Still Airwith Heat Sink(Figure2)DS012030-23Thermal Responsein Stirred Oil Bathwith Heat SinkDS012030-24Start-Up Voltagevs TemperatureDS012030-25Thermal Response in StillAir without a Heat SinkDS012030-26Quiescent Current vs Temperature(Figure1)DS012030-27Accuracy vs TemperatureDS012030-28Noise VoltageDS012030-29 3Typical Performance CharacteristicsTo generate these curves the LM50was mounted to a printedcircuit board as shown in Figure 2.(Continued)1.0MountingThe LM50can be applied easily in the same way as other integrated-circuit temperature sensors.It can be glued or ce-mented to a surface and its temperature will be within about 0.2˚C of the surface temperature.This presumes that the ambient air temperature is almost the same as the surface temperature;if the air temperature were much higher or lower than the surface temperature,the ac-tual temperature of the LM50die would be at an intermediate temperature between the surface temperature and the air temperature.To ensure good thermal conductivity the backside of the LM50die is directly attached to the GND pin.The lands and traces to the LM50will,of course,be part of the printed cir-cuit board,which is the object whose temperature is being measured.These printed circuit board lands and traces will not cause the LM50s temperature to deviate from the de-sired temperature.Alternatively,the LM50can be mounted inside a sealed-end metal tube,and can then be dipped into a bath or screwed into a threaded hole in a tank.As with any IC,the LM50and accompanying wiring and circuits must be kept insulated and dry,to avoid leakage and corrosion.This is especially true if the circuit may operate at cold temperatures where conden-sation can occur.Printed-circuit coatings and varnishes suchas Humiseal and epoxy paints or dips are often used to en-sure that moisture cannot corrode the LM50or its connec-tions.Temperature Rise of LM50Due to Self-Heating (Thermal Resistance,θJA )SOT-23SOT-23no heat sink *small heat fin **Still air 450˚C/W260˚C/W Moving air180˚C/W*Part soldered to 30gauge wire.**Heat sink used is 1⁄2"square printed circuit board with 2oz.foil with part at-tached as shown in Figure 2.2.0Capacitive LoadsThe LM50handles capacitive loading very well.Without any special precautions,the LM50can drive any capacitive load.The LM50has a nominal 2k Ωoutput impedance (as can be seen in the block diagram).The temperature coefficient of the output resistors is around 1300ppm/˚C.Taking into ac-count this temperature coefficient and the initial tolerance of the resistors the output impedance of the LM50will not ex-ceed 4k Ω.In an extremely noisy environment it may be nec-essary to add some filtering to minimize noise pickup.It is recommended that 0.1µF be added from V IN to GND to by-Supply Voltage vs Supply CurrentDS012030-30Start-Up ResponseDS012030-31DS012030-19FIGURE 2.Printed Circuit Board Used for Heat Sink to Generate All Curves.1⁄2"Square Printed Circuit Boardwith 2oz.Foil or SimilarDS012030-7FIGURE 3.LM50No Decoupling Requiredfor Capacitive LoadDS012030-8FIGURE 4.LM50C with Filter for Noisy Environment 42.0Capacitive Loads(Continued)pass the power supply voltage,as shown in Figure 4.In a noisy environment it may be necessary to add a capacitor from the output to ground.A 1µF output capacitor with the 4k Ωoutput impedance will form a 40Hz lowpass filter.Sincethe thermal time constant of the LM50is much slower than the 25ms time constant formed by the RC,the overall re-sponse time of the LM50will not be significantly affected.For much larger capacitors this additional time lag will increase the overall response time of the LM50.3.0Typical ApplicationsDS012030-17*R2≈2k with a typical 1300ppm/˚C drift.FIGURE 5.Block DiagramDS012030-11FIGURE 6.Centigrade Thermostat/Fan ControllerDS012030-13FIGURE 7.Temperature To Digital Converter (Serial Output)(+125˚C Full Scale)53.0Typical Applications(Continued)DS012030-14FIGURE8.Temperature To Digital Converter(Parallel TRI-STATE®Outputs forStandard Data Bus toµP Interface)(125˚C Full Scale)DS012030-16FIGURE9.LM50With Voltage-To-Frequency Converter And Isolated Output(−40˚C to+125˚C;100Hz to1750Hz)6Physical Dimensions inches(millimeters)unless otherwise notedLIFE SUPPORT POLICYNATIONAL’S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE EXPRESS WRITTEN APPROVAL OF THE PRESIDENT AND GENERAL COUNSEL OF NATIONAL SEMICONDUCTOR CORPORATION.As used herein:1.Life support devices or systems are devices orsystems which,(a)are intended for surgical implantinto the body,or(b)support or sustain life,andwhose failure to perform when properly used inaccordance with instructions for use provided in thelabeling,can be reasonably expected to result in asignificant injury to the user.2.A critical component is any component of a lifesupport device or system whose failure to performcan be reasonably expected to cause the failure ofthe life support device or system,or to affect itssafety or effectiveness.National SemiconductorCorporationAmericasTel:1-800-272-9959Fax:1-800-737-7018Email:support@National SemiconductorEuropeFax:+49(0)180-5308586Email:europe.support@Deutsch Tel:+49(0)180-5308585English Tel:+49(0)180-5327832Français Tel:+49(0)180-5329358Italiano Tel:+49(0)180-5341680National SemiconductorAsia Pacific CustomerResponse GroupTel:65-2544466Fax:65-2504466Email:sea.support@National SemiconductorJapan Ltd.Tel:81-3-5639-7560Fax:81-3-5639-7507 SOT-23Molded Small Outline Transistor Package(M3)Order Number LM50BIM3,or LM50CIM3NS Package Number MA03BLM50SOT-23Single-SupplyCentigradeTemperatureSensor National does not assume any responsibility for use of any circuitry described,no circuit patent licenses are implied and National reserves the right at any time without notice to change said circuitry and specifications.。

Optoway SPS-3150WG**********************************************************************************************************************************************************************************************************************************************************************************************************************************************OPTOWAY TECHNOLOGY INC. No .38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303Tel: 886-3-5979798 Fax: 886-3-59797371SPS-3150WG / SPS-3150AWG (RoHS Compliant)3.3V / 1310 nm / 125/155 Mbps Digital Diagnostic LC SFP SINGLE-MODE TRANSCEIVER **********************************************************************************************************************************************************************FEATURESl Hot-Pluggable SFP Footprint LC Optical Transceiver l Small Form-Factor Pluggable (SFP) MSA compatible l Compliant with SONET OC-3 LR-1/ SDH STM-1 (L-1.1)l SFF-8472 Digital Diagnostic Function l AC/AC Coupling according to MSA l Distance up to 50 kml Single +3.3 V Power Supply l RoHS Compliantl -10 to 85o C Operation: SPS-3150WG l -40 to 85o C Operation: SPS-3150AWGl Class 1 Laser International Safety Standard IEC-60825 CompliantAPPLICATIONSl ATM Switches and Routersl SONET / SDH Switch Infrastructure l Fast Ethernet ApplicationsDESCRIPTIONThe SPS-3150WG series single mode transceiver is small form factor pluggable module for bi-directional serial optical data communications such as SONET OC-3 / SDH STM-1 and Fast Ethernet. It is with the SFP 20-pin connector to allow hot plug capability. Digital diagnostic functions are available via an I 2C. This module is designed for single mode fiber and operates at a nominal wavelength of 1310 nm. The transmitter section uses a multiple quantum well laser and is a class 1 laser compliant according to International Safety Standard IEC-60825. The receiver section uses an integrated InGaAs detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC.LASER SAFETYThis single mode transceiver is a Class 1 laser product. It complies with IEC-60825 and FDA 21 CFR 1040.10 and 1040.11. The transceiver must be operated within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.ORDER INFORMATIONP/No. Bit Rate (Mb/s) SONET /SDH Distance (km) Wavelength (nm) Package Temp. (o C) TX Power (dBm) RX Sens. (dBm) RoHS Compliant SPS-3150WG 125 / 155 LR-1/L-1.1 50 1310 LC SFP with DMI -10 to 85 0 to -5 -34 Yes SPS-3150A WG125 / 155 LR-1/L-1.1 50 1310 LC SFP with DMI -40 to 85 0 to -5-34 YesAbsolute Maximum RatingsParameterSymbol Min Max Units NotesStorage TemperatureTstg -40 85 o COperating Case Temperature Topr -10 -40 85 85 o C SPS-3150WG SPS-3150AWG Power Supply VoltageVcc-0.53.6VRecommended Operating ConditionsParameterSymbol Min Typ Max Units / NotesPower Supply VoltageVcc 3.1 3.3 3.5 VOperating Case Temperature Topr -10 -40 85 85 oC / SPS-3150WG oC / SPS-3150AWGPower Supply Current I CC (TX+RX)200 300 mA Data Rate125/155200Mb/sTransmitter Specifications (-10o C < Topr < 85o C, 3.1V < Vcc < 3.5V)Parameter Symbol Min Typ Max Units NotesOpticalOptical Transmit Power Po -5 --- 0 dBm 1Output Center Wavelength λ1280 1310 1350 nmOutput Spectrum Width ∆λ--- --- 4 nm RMS (σ)Extinction Ratio E R10 --- --- dBOutput Eye Compliant with Bellcore TR-NWT-000253 and ITU recommendation G.957Optical Rise Time t r 2 ns 10 % to 90% Values Optical Fall Time t f 2 ns 10 % to 90% Values Relative Intensity Noise RIN -120 dB/HzElectricalData Input Current – Low I IL-350 µAData Input Current – High I IH350 µADifferential Input Voltage V IH - V IL0.5 2.4 V Peak-to-PeakTX Disable Input Voltage – Low T DIS, L0 0.5 V 2TX Disable Input Voltage – High T DIS, H 2.0 Vcc V 2TX Disable Assert Time T ASSERT10 µsTX Disable Deassert Time T DEASSERT 1 msTX Fault Output Voltage -- Low T FaultL0 0.8 V 3TX Fault Output Voltage -- High T FaultH 2.0 Vcc+0.3 V 31. Output power is power coupled into a 9/125 µm single mode fiber.2. There is an internal 4.7K to 10K ohm pull-up resistor to VccTX.3. Open collector compatible,4.7K to 10K ohm pull-up to Vcc (Host Supply Voltage).Receiver Specifications(-10o C < Topr < 85o C, 3.1V < Vcc < 3.5V)Parameter Symbol Min Typ Max Units NotesOpticalSensitivity Sens -34 dBm 4Maximum Input Power Pin -8 dBm 4Signal Detect -- Asserted Pa --- -34 dBm Transition: low to high Signal Detect -- Deasserted Pd -47 --- --- dBm Transition: high to low Signal detect -- Hysteresis 1.0 --- dBWavelength of Operation 1200 --- 1600 nmElectricalDifferential Output Voltage V OH– V OL0.6 2.0 VOutput LOS Voltage -- Low V OL0 0.8 V 5Output LOS Voltage -- High V OH 2.0 Vcc+0.3 V 54. Measured at 2-1 PRBS at BER 1E-10.5. Open collector compatible, 4.7K to 10K ohm pull-up to Vcc (Host Supply Voltage).*********************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303***********************************************************************************************************************************************************************OPTOWAY TECHNOLOGY INC. No .38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303PINSignal NameDescriptionPINSignal Name Description1 TX GND Transmitter Ground11 RX GND Receiver Ground2 TX Fault Transmitter Fault Indication12 RX DATA OUT- Inverse Receiver Data Out 3 TX Disable Transmitter Disable (Module disables on high or open)13 RX DATA OUT+ Receiver Data Out 4 MOD-DFE2 Modulation Definition 2 – Two wires serial ID Interface14 RX GND Receiver Ground5 MOD-DEF1 Modulation Definition 1 – Two wires serial ID Interface15 Vcc RX Receiver Power – 3.3V ±5% 6 MOD-DEF0 Modulation Definition 0 – Ground in Module16 Vcc TX Transmitter Power – 3.3V ±5% 7 N/C Not Connected 17 TX GNDTransmitter Ground 8 LOS Loss of Signal 18 TX DATA IN+ Transmitter Data In9 RX GND Receiver Ground 19 TX DATA IN- Inverse Transmitter Data In 10RX GNDReceiver Ground20TX GNDTransmitter GroundModule DefinitionModule DefinitionMOD-DEF2 PIN 4 MOD-DEF1 PIN 5 MOD-DEF0 PIN 6 Interpretation by Host 4SDASCLLV-TTL LowSerial module definitionprotocolModule Definition 4 specifies a serial definition protocol. For this definition, upon power up, MOD-DEF(1:2) appear as no connector (NC) and MOD-DEF(0) is TTL LOW. When the host system detects this condition, it activates the serial protocol. The protocol uses the 2-wire serial CMOS E 2PROM protocol of the ATMEL AT24C01A/02/04 family of components.*********************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303。
